Sony A3880016 User Manual

Contents
Getting started......................5
Assembly............................................5
Turning on the phone.........................6
Help....................................................7
Charging the battery..........................8
Phone overview..................................9
Memory............................................15
Entering text.....................................16
Walkman™ .........................17
PlayNow™........................................21
TrackID™ ........................................22
Record sound ..................................24
Transferring and
handling content.................25
Sending content to another
Transferring content to and from
a computer.......................................27
Using Bluetooth™ wireless
technology........................................28
Calling..................................31
Messaging...........................40
Email.................................................42
1
Imaging ...............................45
Web feeds........................................52
Synchronising.....................54
Synchronising using an Internet
More features......................56
Flight mode......................................56
Update Service.................................56
Tasks................................................59
Ringtones.........................................61
Applications.....................................62
Troubleshooting..................65
2
Sony Ericsson W508 Walkman™
This User guide is published by Sony Ericsson Mobile Communications AB or its local affiliated company, without any warranty. Improvements and changes to this User guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2009 Publication number: xxxx-xxxx.1 Attention: Some of the services and features
described in this User guide are not supported by all networks and/or service providers in all areas. Without limitation, this applies to the GSM International Emergency Number 112. Please contact your network operator or service provider to determine availability of any specific service or feature and whether additional access or usage fees apply.
Please read the Important information before you use your mobile phone.
Your mobile phone has the capability to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be liable in any way for your improper use of additional content or other third party content.
Smart-Fit Rendering is a trademark or a registered trademark of ACCESS Co., Ltd.
Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc. and any use of such mark by Sony Ericsson is under license.
The Liquid Identity logo, SensMe, PlayNow, MusicDJ, PhotoDJ, TrackID and VideoDJ are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB.
TrackID™ is powered by Gracenote Mobile MusicID™. Gracenote and Gracenote Mobile MusicID are trademarks or registered trademarks of Gracenote, Inc.
WALKMAN, WALKMAN logo, Sony, Memory Stick Micro™, M2™ and Media Go are trademarks or registered trademarks of Sony Corporation.
PictBridge is a trademark or registered trademark of Canon Kabushiki Kaisha Corporation.
Style-Up is a trademark or registered trademark of Sony Ericsson Mobile Communications AB.
Google™, Google Maps™, YouTube and the YouTube logo are trademarks or registered trademarks of Google, Inc.
SyncML is a trademark or registered trademark of Open Mobile Alliance LTD.
Ericsson is a trademark or registered trademark of Telefonaktiebolaget LM Ericsson.
Adobe Photoshop Album Starter Edition is a trademark or registered trademark of Adobe Systems Incorporated in the United States and/or other countries.
T9™ Text Input is a trademark or a registered trademark of Tegic Communications. T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No.
3
1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.
This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft.
Content owners use Windows Media digital rights management technology (WMDRM) to protect their intellectual property, including copyrights. This device uses WMDRM software to access WMDRM­protected content. If the WMDRM software fails to protect the content, content owners may ask Microsoft to revoke the software's ability to use WMDRM to play or copy protected content. Revocation does not affect unprotected content. When you download licenses for protected content, you agree that Microsoft may include a revocation list with the licenses. Content owners may require you to upgrade WMDRM to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.
This product is licensed under the MPEG-4 visual and AVC patent portfolio licenses for the personal and non-commercial use of a consumer for (i) encoding video in compliance with the MPEG-4 visual standard ("MPEG-4 video") or the AVC standard ("AVC video") and/or (ii) decoding MPEG­4 or AVC video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed by MPEG LA to provide MPEG-4 and/or AVC video. No license is granted or shall be implied for any other use. Additional information including that relating to promotional, internal and commercial uses and licensing may be obtained from MPEG LA, L.L.C. See http://www.mpegla.com. MPEG Layer-3 audio decoding technology licensed from Fraunhofer IIS and Thomson.
Java, JavaScript and Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
End-user license agreement for Sun Java Platform, Micro Edition.
1. Restrictions: Software is confidential copyrighted information of Sun and title to all copies is retained by Sun and/or its licensors. Customer shall not modify, decompile, disassemble, decrypt, extract, or otherwise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in part.
2. Export Regulations: Software including technical data, is subject to U.S. export control laws, including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Customer agrees to comply strictly with all such regulations and acknowledges that it has the responsibility to obtain licenses to export, re-export, or import Software. Software may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba, Iraq, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any country to which the U.S. has embargoed goods; or (ii) to anyone on the U.S. Treasury Department's list of Specially Designated Nations or the U.S. Commerce Department's Table of Denial Orders. 3. Restricted rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS
252.227-7013(c) (1) and FAR 52.227-19(c) (2) as applicable.
Restricted Rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS
4
252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable.
Other product and company names mentioned herein may be the trademarks of their respective owners.
Any rights not expressly granted herein are reserved. All illustrations are for illustration only and may not
accurately depict the actual phone.
Instruction symbols
These symbols may appear in the User guide.
Note Tip Warning
> Use a selection or navigation key
to scroll and select. See Navigation on page 14.
Getting started
Assembly
Before you start using your phone, you need to insert a SIM card and the battery.
To insert the SIM card
1
Remove the battery cover.
Getting started 5
2
Slide the SIM card into its holder with the gold-coloured contacts facing down.
To insert the battery
b
1
2
Attach the battery cover.
Turning on the phone
To turn on the phone
1
Press and hold down .
2
Enter your SIM card PIN, if requested, and select OK.
3
Select a language.
4
Follow the instructions to use the setup wizard for basic settings and useful tips.
If you want to correct a mistake when you enter your PIN, press .
SIM card
The SIM (Subscriber Identity Module) card, which you get from your network operator, contains information about your subscription. Always turn off your
6 Getting started
phone and detach the charger before you insert or remove the SIM card.
You can save contacts on the SIM card before you remove it from your phone. See To copy names and numbers to the SIM card on page 34.
PIN
You may need a PIN (Personal Identification Number) to activate the services and functions in your phone. Your PIN is supplied by your network operator. Each PIN digit appears as *, unless it starts with emergency number digits, for example, 112 or 911. You can see and call an emergency number without entering a PIN.
If you enter the wrong PIN three times in a row, the SIM card is blocked. See SIM card lock on page 63.
Standby
After you have turned on your phone and entered your PIN, the name of the network operator appears. This view is called standby. Your phone is now ready for use.
Using other networks
Making and receiving calls, using messaging, and data transfer, for example, Internet-based services,
outside your home network (roaming), may incur additional costs. Contact your operator for more information.
Help
In addition to this User guide, Feature guides and more information are available at www.sonyericsson.com/support.
Help and information are also available in your phone.
To access the User guide
•
Select Menu > Settings > User help > User guide.
To view tips and tricks
•
Select Menu > Settings > User help > Tips and tricks.
To view information about functions
•
Scroll to a function and select Info, if available. In some cases, Info appears under Options.
To view the phone demonstration
•
Select Menu > Entertainment > Demo tour.
Getting started 7
To view the phone status
•
Press and then press the volume key. Phone, memory and battery information is shown.
Charging the battery
The phone battery is partly charged when you buy it.
To charge the battery
1
Connect the charger to the phone. It takes approximately 2.5 hours to fully
charge the battery. Press a key to view the screen.
2
Remove the charger by tilting the plug upwards.
You can use your phone while it is charging. You can charge the battery at any time and for more or less than 2.5 hours. You can interrupt the charging without damaging the battery.
8 Getting started
Phone overview
1 Video call camera*
1
2
3
4
5
6
7
8
9
10 11
12
2 Ear speaker 3 Screen 4 Selection keys 5 Call key 6 Activity menu key 7 Microphone 8 Connector for charger, handsfree and
USB cable 9 End key, On/off key 10 C key (Clear) 11 Navigation key 12 Silent key
Getting started 9
13 Media player key - play/stop
22
21
23
17
18
19
16
14
15
20
13
14 Media player key - next/fast forward 15 Screen light sensor 16 Volume, digital zoom keys 17 Battery cover 18 Keylock switch 19 Memory Stick Micro™ (M2™) slot 20 Loudspeaker 21 Media player key - previous/rewind 22 External display 23 Main camera
10 Getting started
*Video call camera may not be available in every market.
Getting started 11
Menu overview*
PlayNow™
Camera
Radio
Calls**
All
Answered
Dialled
Missed
Internet
Messaging
Write new Inbox/Conversations Messages Email IM Call voicemail
Contacts
Myself New contact
Organiser
File manager **
Alarms Applications Video call Calendar Tasks Notes Synchronisation Timer Stopwatch Calculator Code memo
Entertainment
Online services TrackID™ Location services Games VideoDJ™ PhotoDJ™ MusicDJ™ Remote control Record sound Demo tour
Media
Photo Music Video Games Web feeds Settings
WALKMAN
Settings
General
Profiles Time & date Language Update service Gesture control Voice control New events Shortcuts Flight mode Security Setup wizard Accessibility Phone status Master reset
Sounds & alerts
Ring volume Ringtone Silent mode Increasing ring Vibrating alert Message alert Key response
Display
Wallpaper Main menu layout Theme Startup screen Screen saver Clock size Brightness
12 Getting started
Edit line names
Calls
Speed dial Smart search Divert calls Switch to line 2 Manage calls Time & cost Show/hide my no. Handsfree Open to answer
Connectivity
Bluetooth USB Phone name Synchronisation Device management Mobile networks Data communication Internet settings Streaming settings Message settings SIP settings Accessories
User help
User guide Settings download Basic setup Tips and tricks
* Some menus are operator-, network- and subscription­dependent.
** You can use the navigation key to scroll between tabs in submenus. For more information, see Navigation on page 14.
Getting started 13
Navigation
To access the main menu
•
When Menu appears on the screen, press the centre selection key to select
Menu.
•
If Menu does not appear on the screen, press
, and then press the centre
selection key to select Menu.
To navigate the phone menus
•
Press the navigation key , , or
to move through the menus.
To select actions on the screen
•
Press the left, centre or right selection key.
To view options for an item
•
Select Options to, for example, edit.
To end a function
•
Press .
To return to standby
•
Press .
To navigate your media
1
Select Menu > Media.
2
Scroll to a menu item and press .
3
To go back, press .
To delete items
•
Press
to delete items such as
numbers, letters, pictures and sounds.
Tabs
Tabs may be available. For example, Calls have tabs.
To scroll between tabs
•
Press the navigation key
or .
Shortcuts
You can use keypad shortcuts to go directly to functions from standby.
To use navigation key shortcuts
•
Press , , or to go directly to a function.
14 Getting started
To edit a navigation key shortcut
1
Select Menu > Settings > General > Shortcuts.
2
Scroll to an option and select Edit.
3
Scroll to a menu option and select
Shortc..
Main menu shortcuts
Menu numbering starts from the top left icon and moves across and then down row by row.
To go directly to a main menu item
•
Select Menu and press
– ,
, or .
The Main menu layout must be set to Grid. See To change the main menu
layout on page 61.
Activity menu
The activity menu gives you quick access to:
•
New events – missed calls and new
messages.
•
Running apps – applications that are
running in the background.
•
My shortcuts – add your favourite
functions to access them quickly.
•
Internet – quick access to the
Internet.
To open the activity menu
•
Press .
Memory
You can save content on the memory card, in the phone memory and on the SIM card. Photos and music are saved on the memory card, if a memory card is inserted. If not, or if the memory card is full, photos and music are saved in the phone memory. Messages and contacts are saved in the phone memory, but you can choose to save them on the SIM card.
Memory card
You may have to purchase a memory card separately.
Your phone supports Memory Stick Micro™ (M2™) memory card adding more storage space to your phone. It can also be used as a portable memory card with other compatible devices.
You can move content between a memory card and the phone memory. See Handling content in the phone on page 25.
Getting started 15
To insert a memory card
•
Remove the battery cover and insert the memory card with the gold­coloured contacts facing down.
Phone language
You can select a language to use in your phone.
To change the phone language
1
Select Menu > Settings > General > Language > Phone language.
2
Select an option.
Entering text
You can use multitap text input or T9™ Text Input to enter text. The T9 Text Input method uses a built-in dictionary.
To change text input method
•
When you enter text, press and hold down .
To shift between capitals and lower­case letters
•
When you enter text, press .
To enter numbers
•
When you enter text, press and hold down
– .
To enter full stops and commas
•
When you enter text, press
.
To enter a symbol
1
When you enter text, select Options > Add symbol.
2
Scroll to a symbol and select Insert.
To enter text using T9™ Text Input
1
Select, for example, Menu > Messaging > Write new > Message.
2
If is not displayed, press and hold down to change to T9 Text Input.
3
Press each key only once, even if the letter you want is not the first letter on the key. For example, to write the word “Jane”, press , , , . Write the whole word before looking at the suggestions.
4
Use or to view suggestions.
5
Press to accept a suggestion.
16 Getting started
To enter text using multitap
1
From standby select, for example,
Menu > Messaging > Write new > Message.
2
If is displayed, press and hold down
to change to multitap text input.
3
Press – repeatedly until the desired letter appears.
4
When a word is written, press to add a space.
To add words to the built-in dictionary
1
When you enter text using T9 Text Input, select Options > Spell word.
2
Write the word using multitap input and select Insert.
Walkman™
You can listen to music, audio books and podcasts. Use Media Go™ to transfer content to and from your phone. For more information, see
Transferring content to and from a computer on page 27.
Stereo portable handsfree
To use a handsfree
•
Connect a portable handsfree. Music stops when you receive a call and resumes when the call has ended.
Walkman™ 17
Walkman™ player
You can use the media player keys to control the Walkman™ player when the phone is closed. The keys must be unlocked. For information on how to unlock the keys, see To unlock the media player keys on page 65.
To play music
1
When the phone is open, select Menu > Media > Music.
2
Browse by category using the navigation key.
3
Scroll to a title and select Play.
You can use
to start playing music when the phone is closed. starts the last used music application, that is the Walkman™ player or the radio.
To stop playing music
•
To fast forward and rewind
•
When the phone is closed, press and hold down or .
To move between tracks
•
When the phone is closed, press or .
To minimise the player
•
When the phone is open, select Options > Minimise.
To return to the player
•
When the phone is open and you are not in any menu, press .
Shake control
To switch tracks
18 Walkman™
1
When the phone is closed and music is playing, press and hold down and move the phone to the right with a flick of your wrist to go to the next track.
2
To go to the previous track, use the same action to the left.
To shuffle tracks
•
When the phone is closed and music is playing, press and hold down and shake your phone.
To change the volume
1
When the phone is closed and music is playing, hold the phone out in front of you facing upwards.
2
Press and hold down and bend your arm upwards towards you to increase the volume. To decrease the volume, repeat the action in the opposite direction.
Playlists
You can create playlists to organise your music. You can add tracks and folders to a playlist. It may take a few minutes for the phone to create a playlist.
Walkman™ 19
To create a playlist
1
When the phone is open, select Menu > Media > Music > Playlists.
2
Scroll to New playlist and select Add.
3
Enter a name and select OK.
4
For each track you want to add, scroll to the track and select Mark.
5
Select Add to add the marked tracks to the playlist.
To add tracks to a playlist
1
When the phone is open, select Menu > Media > Music > Playlists.
2
Select a playlist.
3
Scroll to Add music and select Add.
4
For each track you want to add, scroll to the track and select Mark.
5
Select Add to add the marked tracks to the playlist.
SensMe™
With SensMe™ you can create playlists in two ways, by mood or from all the tracks in your phone. By mood, you first use Media Go™ to transfer tracks to your phone. Information such as mood, tempo and chords is then added. The tracks are displayed as dots on a map with two axes. In the All view, all the tracks in your phone are placed randomly on the map.
To create a playlist by mood
1
When the phone is open, select Menu > Media > Music.
2
Scroll to SensMe™ and select Open.
3
Press , , or .
4
5
To preview different tracks, press ,
, or .
6
To choose an area of tracks, select
Add and press or .
7
To create the playlist and play it in the Walkman™ player, select Create.
8
Select Options > Save playlist.
9
Enter a name and select OK.
To create a playlist from All view
1
When the phone is open, select Menu > Media > Music.
2
Scroll to SensMe™ and select Open.
3
Press
, , or .
20 Walkman™
4
Make sure you are in All view. If you are not, select All.
5
To preview different tracks, press ,
, or .
6
To choose an area of tracks, select
Add and press or .
7
To create the playlist and play it in the Walkman™ player, select Create.
8
Select Options > Save playlist.
9
Enter a name and select OK.
Audio books
If you use Media Go™ to transfer audio books to your phone from a computer, you can listen to the audio books in your phone. It may take a few minutes before a transferred audio book appears in the list of available audio books.
To access audio books
•
When the phone is open, select Menu > Media > Music > Audio books.
You can find audio books in formats other than M4B and those that do not have ID3v2 chapter tags in the Tracks folder.
Buy Now
If you subscribe to a music service allowing limited, non-permanent use with your phone, you can mark a track you are interested in buying later. The
next time you synchronise your music with Windows Media® Player on a computer with enabled Internet access, you should be asked if you want to buy the track you marked earlier. If you accept, the track is downloaded to your computer and your selected music service account is charged. This service requires a subscription and account with a downloadable music service, a computer with Microsoft® Windows Media® Player 11 or subsequent compatible version of Windows Media® Player, and a USB computer connection.
You cannot see that a track is marked. You cannot unmark tracks you have already marked.
To mark a track
•
When the phone is open and the track you want to mark is playing, press and hold down .
PlayNow™
When you select PlayNow™ you enter PlayNow™ arena, where you can download music, games, ringtones, themes and wallpapers. You can preview or listen to content before you purchase and download it to your
Walkman™ 21
phone. If you cannot use PlayNow™ and PlayNow™ arena, see I cannot use
Internet-based services on page 66.
This service is not available in all countries.
For extended functionality, you can also access the PlayNow™ arena Web shop on a computer from www.playnow-arena.com. For more information, go to www.sonyericsson.com/support to read the PlayNow™ arena Feature guide.
To use PlayNow™
1
Select Menu > PlayNow™.
2
Scroll through PlayNow™ arena and follow the instructions to preview and purchase content.
TrackID™
TrackID™ is a music recognition service. You can search for title, artist and album name for a track you hear playing through a loudspeaker or on the radio in your phone. If you cannot use TrackID™, see I cannot use Internet-based services on page 66.
To search for track information
•
When you hear a track through a loudspeaker, select Menu >
Entertainment > TrackID™ > Start.
•
When the radio in your phone is playing select Options > TrackID™.
For best results, use TrackID™ in a quiet area.
Online music and video clips
You can view video clips and listen to music by streaming them to your phone from the Internet. If you cannot use the Internet, see I cannot use Internet- based services on page 66.
To select a data account for streaming
1
Select Menu > Settings > Connectivity > Streaming settings > Connect using:.
2
Select the data account to use.
3
Select Save.
To stream music and video clips
1
Select Menu > Internet.
2
Select Options > Go to > Bookmarks.
3
Select a link to stream from.
22 Walkman™
Video player
To play videos
1
Select Menu > Media > Video > Videos.
2
Scroll to a title and select Play.
To stop playing videos
•
Press the centre selection key.
To fast forward and rewind
•
Press and hold down
or .
To move between videos
•
Press or .
To change the volume
•
Press the volume key up or down.
To change the video screen size
1
Select Options > Video size.
2
Select an option.
To save a picture from a video clip
1
To pause the video clip, press the centre selection key.
2
To save the paused image as a picture, select Options > Save picture.
Radio
You can use the media player keys to control the radio when the phone is closed. The keys must be unlocked. For information on how to unlock the keys, see To unlock the media player
keys on page 65.
Do not use your phone as a radio in places where this is prohibited.
To turn on the radio
1
Connect a handsfree to the phone.
2
When the phone is open, select Menu > Radio.
You can use
to turn on the radio when the phone is closed. starts the last used music application, that is the radio or the Walkman™ player.
Walkman™ 23
To search for channels automatically
•
When the phone is open, select Search.
To search for channels manually
•
When the phone is closed, press or .
To change the volume
•
Press the volume key up or down.
To minimise the radio
•
When the phone is open, select Options > Minimise.
To return to the radio
•
When the phone is open, select Menu > Radio.
Saving channels
You can save up to 20 preset channels.
To save channels automatically
•
When the phone is open, select Options > Auto save.
To save channels manually
1
When the phone is open and you have found a radio channel, select Options > Save.
2
Scroll to a position and select Insert.
To select saved channels
1
When the phone is open, select
Options > Channels.
2
Select a radio channel.
To switch between saved channels
•
When the phone is closed, press and hold down or .
MusicDJ™
You can compose and edit your own melodies to use as ringtones. Pre­arranged sounds with different characteristics are available.
To compose a melody
1
Select Menu > Entertainment > MusicDJ™.
2
Select to Insert, Copy or Paste sounds.
3
Use
, , or to scroll between
the sounds.
4
Select Options > Save melody.
Record sound
In some countries or states it is required by law that you inform the other person before recording the call.
24 Walkman™
To record a sound
•
Select Menu > Entertainment > Record sound > Record.
To record a call
1
During an ongoing call, select Options > Record.
2
To save the recording, select Save.
To listen to a recording
1
Select Menu > Organiser > File manager.
2
Scroll to Music and select Open.
3
Scroll to a recording and select Play.
Transferring and handling content
You can transfer and handle content such as pictures and music.
You are not allowed to exchange some copyright-protected material. identifies a protected item.
You can use File manager to handle content saved in the phone memory or on a memory card. Tabs and icons in File manager show where the content is saved. If the memory is full, delete some content to create space.
To view memory status
1
Select Menu > Organiser > File manager.
2
Select Options > Memory status.
3
Select Memory card or Phone.
To select more than one item in a folder
1
Select Menu > Organiser > File manager.
2
Scroll to a folder and select Open.
3
Select Options > Mark > Mark several.
4
For each item you want to mark, scroll to the item and select Mark.
Transferring and handling content 25
Loading...
+ 57 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
