Sony A3624021 User Guide

Manual for

’08.1

Easy Search/Contents/
Precautions

Before Using the
Handset

Voice/
Videophone Calls

PushTalk

Phonebook

Sound/Display/
Light Settings

Security Settings

Camera

i-mode/i-motion/
i-Channel

Mail

i-αppli

Osaifu-Keitai/
ToruCa

GPS Function

Full Browser

Data Display/Edit/
Management

Music&Video Channel/
Music Playback

Other Convenient
Functions

Character Entry

Network Services

PC Connection

Overseas Use

Appendix/External
Devices/Troubleshooting

Index/
Quick Manual

NTT DoCoMo W-CDMA/GSM/GPRS System Mobile Phone

Thank you for your purchase of the new “FOMA SO905iCS” mobile phone.

For proper use of the FOMA SO905iCS, read this manual and each manual attached to other
optional devices carefully before and while you use the FOMA SO905iCS. For more information on
manuals, contact the inquiries on the backcover of this manual.
The FOMA SO905iCS is the efficient partner of yours. Please handle the FOMA SO905iCS with
care and use it regularly for a long time.

Before using the FOMA terminal

Because a FOMA terminal operates using radio frequencies, it cannot be used inside a tunnel, underground,

●

in a building or other locations where radio waves do not reach the FOMA terminal, in locations with weak radio
wave condition, or outside of the FOMA’s service area. The FOMA services may not be available on high upper
floors of high-rise apartments or buildings, even if you can see no obstructions around you. On occasion, your
calls may become disconnected even in areas with strong radio wave condition, even if you are not moving, or
even if there are 3-antenna marks in the FOMA terminal’s display.

Please use discretion and mind your manners when using the FOMA terminal in public areas or crowded/quiet

●

places to keep from bothering others.

Note that because the FOMA terminal operates on radio frequencies, your calls are at risk of being intercepted

●

by the third party. However, the W-CDMA/GSM/GPRS system automatically scrambles all calls through a
private call feature. Therefore, even if the third party successfully intercepts your call, they will only hear noise.

The FOMA terminal operates on radio frequencies by converting voice into digital signals. If the caller moves

●

into an area of adverse radio wave condition, the digital signal may not be restored accurately, and the voice
received in the call may differ slightly from the actual voice.

The user hereby agrees that the user shall be solely responsible for the result of the use of SSL. Neither

●

DoCoMo nor the certifiers as listed herein make any representation and warranty as for the security in the use
of SSL. In the event that the user shall sustain damage or loss due to the use of SSL, neither DoCoMo nor the
certifiers shall be responsible for any such damage or loss.
Certifiers: VeriSign Japan K.K., Cybertrust, Inc., GlobalSign K.K., RSA Security Inc., and SECOM Trust Systems

●

The FOMA terminal has FOMA Plus-Area and FOMA HIGH-SPEED Area support.

Co., Ltd.

The FOMA terminal can be used only via the FOMA network provided by DoCoMo and DoCoMo’s roaming

●

area.

Always keep the information you save in the FOMA terminal (e.g. phonebook entries, schedules, text memos,

●

record messages, voice memos, videophone messages) in a separate note. Even if the data may be lost as a
result of malfunction, repair, change, or other handling of the FOMA terminal, under no condition will DoCoMo
be held liable for any lost data saved in the FOMA terminal.

It is strongly recommended to save important data in the microSD memory card. Also, if you have a PC,

●

you can transfer/save data such as phonebook entries, mail, schedules in your PC using the DoCoMo keitai
datalink.

Before using this manual

●

The FOMA terminal supports the Kisekae tool (P.123). When you use the Kisekae tool to change the design of



the menu display, some menu types may change the menu structure depending on the frequency in use. The
digits assigned to menu items may not be applied.
In this case, you cannot operate the FOMA terminal as explained in this manual, so please change the menu to



the Standard menu or reset the menu settings (P.35, 124).

The latest information on this manual is ready for download at the NTT DoCoMo’s website.

“User’s Manual Download”

ˎ

(http://www.nttdocomo.co.jp/english/support/manual/index.html)

The URL and contents of the website are subject to change without notice.

※

Information on Using the Manual and How to Look up in the Manual

This manual guides you through the operating instructions with step-by-step screen
examples for each operating procedure to ensure that you operate the FOMA terminal
properly.

How to Look up in the Manual

■

This manual employs several search methods so that it can provide the most appropriate way
to find a page relating to your desired function or service flexibly according to your need or
situation.

For details, see the next page.

Index (P.474)

◆

Search by a function or service name known to you or a function name to be displayed on
the FOMA terminal’s display.

Easy Search (P.4)

◆

Search a function that you want to know or you consider useful to know from a listing
sorted by purpose or by a function name.

Headings on the cover (Cover page)

◆

Search the description page of a desired function in the order of “Cover page” → “Chapter
opening page (the first page of a chapter)” → “Description page”. The opening page of
each chapter contains detailed contents of the chapter.

Contents (P.6)

◆

Search by purpose or a function name starting from chapters that are categorized by
functions.

Main functions (P.8)

◆

Search for main functions of SO905iCS, such as new and useful functions.

List of menus (P.416)

◆

The menu items, which appear on the display of the FOMA SO905iCS, and default settings
at the time of purchase are listed.

Quick Manual (P.490)

◆

The basic operations of the FOMA terminal are explained briefly. Cut and fold these pages
into a booklet and take it with you for convenient reference. The Quick Manual for “Overseas
Use” is also included for convenient reference when the FOMA terminal is used abroad.

Please note that “FOMA SO905iCS” is called the “FOMA terminal” in this “Manual for FOMA

●

SO905iCS”.

This manual describes the functions that can be performed using the microSD memory card.

●

To use these functions, you need the optional microSD memory card.

About the microSD memory card (P.302)

ˎ

Reproduction or reprint of all or part of this manual without prior permission is forbidden.

●

The contents of this manual are subject to change without notice.

●

1

A function, referred to as “Notify caller ID” here, can be searched in diverse ways as

Before Using the

Handset

Part Names and Functions ................................

Opening/Closing the FOMA Terminal ................

About the Style ..................................................

Using the Displays .............................................

Selecting the Menu ............................................

Using the UIM ....................................................

Attaching and Removing the Battery Pack ........

Charging the FOMA Terminal ............................

Checking the Battery Level ................................

Powering On/Off ................................................

Setting the Basic Functions ...............................

Setting the Date and Time .................................

Notifying the Recipient of Your Phone Number ..

CheckingYour Own Phone Number ..................

......................... 26

......................... 29

......................... 29

......................... 30

......................... 33

......................... 36

......................... 39

......................... 40

....

<Battery level>

42

....

<Power on/off>

43

....

<Initial setting>

43

........

<Date/time>

44

.

<Notify caller ID>

45

....

<Own number>

45

follows.

Index

(P.474)

Search by a function or service name known to you or a function name to be displayed on
the FOMA terminal’s display.

Ｎｏｔｉｆｙ Ｃａｌｌｅｒ ＩＤ

Ｓｅｔ Ｎｏｔｉｆｉｃａｔｉｏｎ

Ｃｈｅｃｋ ｓｔａｔｕｓ

Ｓｅｌｅｃｔ

ＭＥＮＵ

Easy Search

er info ....................318

e program .............. 337

...................... 336, 338

program ................. 335

............................... 317

a ............................... 45

ument .................... 329

ch to mail ...............208

kmark ..................... 332

ture screen ............332

te ........................... 317

il ............................ 318

il info disp .............330

(P.4)

N

Name ................................ 121

Network search mode ....... 411

Network security code ......130

Network service ................ 387

Notification display .............. 32

Notify caller ID ....................45

Nuisance Call Blocking

Service ......................... 390

Number of protected data

items............................. 462

P.45
To the descr­iption page
of the “Notify
caller ID”.

Search a function that you want to know or you consider useful to know from a listing sorted
by purpose or by a function name.

P.45

Useful Functions for a Call

your phone number

Sending

Switching to videophone

Putting a current call
Adjusting the

volume of a caller’s voice

or keeping it anonymous

during a voice call ...............Chg. to videophone

on hold

............................................Holding

...Notify caller ID

......................Volume

Headings on the cover

(P.45)

(P.54)
(P.68)
(P.112)

(Cover page)

To the descr­iption page
of the “Notify
caller ID”.

Search the description page of a desired function in the order of “Cover page” → “Chapter
opening page (the first page of a chapter)” → “Description page”. The opening page of
each chapter contains detailed contents of the chapter.

Easy Search/Contents/
Precautions

Before Using the
Handset

Voice/
Videophone Calls

PushTalk

Phonebook

P.45
To the descr­iption page
of the “Notify
caller ID”.

2

Typical layout of the operating instructions page

■

Function name

Index

Chapter title

Operation procedure
described step by
step

A display sample if
important for proper
operation

Useful information,
additional information,
and points of caution

Notifying the Recipient of Your Phone Number

When placing a call, your phone number can be shown in the display of the

Before Using the Handset

recipient’s phone you are calling.

The caller ID is important personal information. Carefully decide whether you want to notify a



recipient of your caller ID.

1

From the Menu, select [Settings] → [Management] → [NW Services] → [Notify
Caller ID] → [Set Notification] and press .

The network security code screen appears.

2

Select [Notify]/[Not notify] and press .

[Notify] :

Ｓｅｌｅｃｔ Ｃａｌｌｅｒ ＩＤ
ｎｏｔｉｆｉｃａｔｉｏｎ
ｓｅｔｔｉｎｇ

 Ｎｏｔｉｆｙ

 Ｎｏｔ ｎｏｔｉｆｙ

If you hear a guidance asking to send the caller ID when you place a call, call again after

●

setting the Set Notification to [Notify] or by adding “186” before the recipient’s phone
number.

Your phone number (caller ID) is notified to the recipient.

[Not notify] :

Your phone number (caller ID) is not notified to the recipient.

The Notify caller ID is set.

To check the setting

From the Menu, select [Settings] → [Management] → [NW Services]

[Notify Caller ID] → [Check setting].

→

<Notify caller ID>

Section title
An outline and objectives of

the function

Additional notes and
restrictions of the function

Options listed in the display
and their descriptions

Additional information relating
to the procedure

Page number

Please note that the above page is only for explanation purpose and is partly different from the actual page.

※

About the menu operation

■

45

Throughout this manual the operations for selecting from the menu are described as follows.

Actual operations



Ｄｉｓｐｌａｙ

Ｓｔａｎｄ−ｂｙ ｄｉｓｐｌａｙ
Ｓｕｂ ｄｉｓｐｌａｙ
Ｂａｃｋｌｉｇｈｔ
Ｐｏｗｅｒ ｓａｖｅｒ

Ｍｅｎｕ ｓｅｔｔｉｎｇ
Ｋｉｓｅｋａｅ ｓｅｔｔｉｎｇ
Ａｎｉｍａｔｉｏｎ
Ｆｏｎｔ ｓｉｚｅ

Press (MENU).

Typical description of the operations



Use to
move the cursor to [Settings]
and press

１ｍｉｎ

(Select).

Ｃａｌｌ

Ｉｎｃｏｍｉｎｇ ｓｅｔ

Ｍｉｓｓｅｄ ｃａｌｌ

ＯＮ
Ｖｉｄｅｏｐｈｏｎｅ
Ｃａｌｌ ｄｉｓｐｌａｙ
Ｃａｌｌ ａｓｓｉｓｔ
Ｃａｌｌ ｓｅｔｔｉｎｇ
Ｃａｌｌ ｑｕａｌｉｔｙ
Ｈｅａｄｓｅｔ ｓｅｔｔｉｎｇ
Ｓｅｌｆ ｍｏｄｅ

  ＯＦＦ

Ｍｅｌｏｄｙ Ｃａｌｌ

Use to move
the cursor to [Call] and

(Select).

press

Ｉｎｃｏｍｉｎｇ ｓｅｔ

Ｉｎｃｏｍｉｎｇ ｃａｌｌ

Ｉｎｃｏｍｉｎｇ Ｖ．ｐｈｏｎｅ
ＰｕｓｈＴａｌｋ
Ｍａｉｌ
ＭｅｓｓａｇｅＲ
ＭｅｓｓａｇｅＦ

Use to move the
cursor to [Incoming set]
and press

From the Menu, select [Settings] → [Call] → [Incoming set] and press .

Display examples and illustrations used in this manual are just images for explanations and

●

may be different from actual ones.

Some parts of the keys are deformed or omitted in

●

the illustration in this manual.

Display examples in this manual show the conditions based on the Kisekae menu (White

●

Scrapbook) of the main body color: WHITE, the Color theme setting (White & Gold), and
Clock set to [Digital clock1]. The position of the clock in the display in this manual is different
from the default position.

The shorter form “Osaifu-Keitai-compatible i-αppli” is used for “Osaifu-Keitai-compatible

●

i-αppli software supporting IC card function” in this manual.

Actual key

Illustration in this manual

(Select).

3

Easy Search/Contents/Precautions

Easy Search

You can search the function that you want to know with simple words.

Useful Functions for a Call

your phone number

Sending

Switching to videophone

Putting a current call
Adjusting the

on hold

volume of a caller’s voice

or keeping it anonymous

during a voice call ...............Chg. to videophone

............................................Holding

......................Volume

...Notify caller ID

When Being Unable to Answer a Call

(P.45)

(P.54)
(P.68)
(P.112)

Putting an incoming call
Informing of
Public mode (Power off)

Recording

Videophone message

inability to talking

a message ......................................................Record message/

on hold

.......................................On hold

on the phone ................Public mode (Drive mode)

(P.68)

(P.72)

(P.69)

(P.70)

How to Customize the Melody and Indicator

ring tone

Using a
Select phone/mail Illum.
Changing a
Adjusting the
Setting the
Changing the
Muting the
Muting the
Setting the

, etc. specific to individual callers ...........Des phone/mail tone/

ring tone

vibrator

keypad sound
sound when canceling the Lock key

Manner mode

.........................................................Ring tone

volume of the ring tone

to notify incoming calls and mail .........Vibrator

color of the indicator

.................................................Keypad sound

.................................................Manner mode

...........................Ring volume

...............................Color

......Keyguard rel

(P.109)

(P.97)

(P.109)

(P.110)

(P.110)

(P.111)

(P.111)

(P.115)

How to Customize the Display

Learning what the

Switching

Changing the
Displaying the
Changing the

icons

in the display represent ...............Use display

the menu

display

stand-by display

calendar

font size

in the stand-by display .................Stand-by display

......................................................Font size

...........................................Menu setting

.......................................Stand-by display

(P.127)

(P.30)

(P.33

)

(P.117)
(P.118)

4

Useful Functions for Mail

Deco-mail

Sending
Sending an

Sorting

received mail

...........................................................


..............................................................File attachment

automatically

Useful Functions for the Camera

Compose and send Deco-mail

(P.208)

.............................Sort inbox/Sort outbox

Easy Search/Contents/Precautions

(P.204)

(P.222)

Changing the
Performing the
Turning on/emitting the
Flash
Saving an image directly to the

Displaying

recording size

Panorama shoot

photo light/flash

a recorded


...........................................Select size

.....................................Panorama

........................Photo light

microSD memory card

.........................................My picture

(P.170)

...Select save to

(P.158)

(P.165)

(P.170)

(P.173)

(P.286)

For Secure Operations of the FOMA Terminal

Locking the FOMA terminal

location in case you misplace it ............................................Omakase Lock

Displaying saved

Rejecting
Rejecting

secret

a call if no caller’s phone number is presented

a call from a caller who is not saved in the Phonebook

Storing the Phonebook data and
other information

Omakase Lock is a paid service and Data Security Service is a paid service that requires a subscription.

※

to prevent data loss ...........................Data Security Service

from a remote

contents .......................................Secret display

...Denied no ID

...Reject unknown

(P.136)

※

(P.141)

(P.144)

(P.146)

※

(P.147)

Other Useful Functions

Suppressing the consumption

Reading the
Using the
Using the
Exchanging information using
Listening to
Using the FOMA terminal as an
Using the FOMA terminal as a
Using the FOMA terminal
Upgrading to the latest
Updating

For information on how to search the other operations than described above, see “Information

ˎ

on Using the Manual and How to Look up in the Manual” (P.1).

The Quick Manual is included for convenient reference, in which operating instructions on the

ˎ

most commonly used functions are summarized (P.490).

QR and bar codes

GPS function

....................................................GPS function

microSD memory card

music

..............................................................MUSIC Player

overseas

software

security

to the latest safeguards ........................Scan function

of the battery ............Power saver

......................................Bar code reader

.................................microSD memory card

infrared communication

alarm clock

calculator

.......................................Software update

....................Alarm

.........................Calculator

..................................Int’l roaming

...Infrared communication

(P.122)

(P.179)

(P.260)

(P.302)

(P.323)

(P.338)

(P.356)

(P.368)

(P.406)

(P.452)

(P.458)

5

Easy Search/Contents/Precautions

Contents

Before Using the Handset

Part names and functions, Open/close the FOMA terminal, Style, Use display, Select menu,
UIM, Attach and remove battery pack, Charge the FOMA terminal, Battery level, Power on/
off, Initial setting, Date/time, Notify caller ID, Own number

Voice/Videophone Calls

Place voice/videophone call, Change to videophone/voice call, Redial/Received record,
Chaku-moji, WORLD CALL, Receive voice/videophone call, Any key answer, Slide open
setting, Setting when folded, Public mode, Record message/Videophone message, Call
Chara-den, Videophone setting, and so on...

PushTalk 79

What is PushTalk?, Originate PushTalk call, Receive PushTalk call, Add to PushTalk
phonebook, Originate from the PushTalk phonebook, Delete a PushTalk phonebook entry,
PushTalk setting, and so on...

Phonebook 93

About phonebooks, Add to FOMA terminal phonebook, Add to UIM phonebook, Group
setting, Display phonebook, Search phonebook, Phonebook setting, Edit phonebook,
Delete phonebook, Memory status, 2-touch dial, Data Security Service, and so on...

Sound/Display/Light Settings

Incoming set, Set basic tone, Volume, Manner mode, Stand-by display, Animation, Call
display, Backlight, Menu setting, Kisekae setting, Kisekae menu, Font size, Select language,
and so on...

Security Settings

About security codes, Change code, UIM setting, Cancel the PIN lock, Lock all, Omakase
Lock, Self mode, Personal data lock, Key dial lock, Lock key, Record display, Secret display,
Mail security, Data security, Accept/Reject call, Denied no ID, Set ring start time, Reject
unknown, Data Security Service, and so on...

Camera 149

Record still images, Camera’s standard functions, Shoot mode, Record movies, Change the
camera settings, Adjust the camera, Set the camera operation, Bar code reader, and so on...

i-mode/i-motion/i-Channel 181

What is i-mode?, i-mode menu, Display sites, Change i-mode password, Internet
connection, Bookmark, Screen Memo, Acquire image, Download, i-mode setting, SSL
certificate, User certificate, What is i-motion?, Download i-motion, What is i-Channel?,
Display i-Channel, i-Channel setting, and so on...

Mail 201

What is i-mode mail?, Mail menu, Compose and send mail, Compose and send Deco-mail,
Template, File attachment, Save mail, Receive option, Check new message, Received/sent/
saved mail, Mail setting, MessageR/MessageF, What is Early Warning “Area Mail”?, Area

6

Mail setting, Compose and send SMS, and so on...

Before using the FOMA terminal
Information on Using the Manual and How to Look up

in the Manual ............................................................. 1

Easy Search ...............................................................4

Main Functions of the FOMA SO905iCS .................... 8

Making Full Use of SO905iCS ! ................................ 10

Safety Precautions (Observe Strictly) ....................... 12

Handling Precautions ............................................... 19

Intellectual Property Right ........................................ 22

Supplied and Optional Accessories .......................... 24

25

49

107

129

i-αppli

233

What is i-αppli?, Download, Run i-αppli, Auto-start, i-αppli stand-by, Manage i-αppli, and
so on...

Osaifu-Keitai/ToruCa 249

What is Osaifu-Keitai?, Start an Osaifu-Keitai-compatible i-αppli, What is ToruCa?, Obtain a
ToruCa card, Display ToruCa, Manage ToruCa cards, ToruCa setting, IC act. notice, IC card
lock, and so on...

GPS Function 259

Position location, Location provision, Location notice, Location history, and so on…

Full Browser 275

Display website, Key operations, Manage bookmark, Full Browser setting

Data Display/Edit/Management

My picture, Music slide show, Edit photo, i-motion, Edit movie, Chara-den, Music, Melody,
Kisekae Tool, microSD memory card, Data Box, Infrared communication, iC communication,
My document, and so on...

Music&Video Channel/Music Playback

What is Music&Video Channel?, What is MUSIC Player?, Transfer music data, Download
Chaku-Uta Full

“Chaku-Uta Full” is a registered trademark of Sony Music Entertainment Corporation.

ˎ

®

, Play back music data, Manage playlist, MUSIC Player setting, and so on...

285

333

Other Convenient Functions 347

Multiaccess, Multitask, Edit slide setting, Lifetime Calendar, easy BlogUp, Alarm, Schedule,
My Selection, Display rotated appli, Voice memo, Call duration/cost, Calculator, Text Memo,
Jog setting, Reset settings, Reset all data&set, and so on...

Character Entry

Enter text, Enter common phrases, Pictographs/symbols, Cut/Copy/Paste, Reset data,
Download dictionary, and so on...

377

Network Services 387

Voice Mail Service, Call Waiting Service, Call Forwarding Service, Nuisance Call Blocking
Service, Caller ID Display Request Service, Dual Network Service, English Guidance
Service, Service Numbers, Arrival Call Act, Remote Control, Multi Number Service, 2in1,
and so on...

PC Connection 399

About data communication, Before using data communication, Preparations and flow of
data communication, AT commands, About the supplied CD-ROM, Introduction of DoCoMo
keitai datalink

Overseas Use 405

Overview of international roaming, Available services, Place call, Receive call, Network
search mode, PLMN setting, Operator name display, Roaming Guidance, Oversea service,
and so on…

Appendix/External Devices/Troubleshooting

List of menus, Enjoy with Picture Motion Browser, Troubleshooting, Software update, Scan
function, Specifications, and so on...

415

Index/Quick Manual 473

Index, Quick Manual, Quick Manual for “Overseas Use”

Easy Search/Contents/Precautions

7

Easy Search/Contents/Precautions

Main Functions of the FOMA SO905iCS

“FOMA” is the name of NTT DoCoMo’s mobile service based on the W-CDMA
(Wideband Code Division Multiple Access) system, which has been approved as a
global standard of third generation (3G) wireless communication systems (IMT-2000
or International Mobile Telecommunications-2000).

It’s amazing because it’s i-mode

i-mode is an online service that enables you to take advantage of valuable
information from i-mode Menu sites (Program) and i-mode compatible sites.
This service also enables you to exchange e-mail with great ease.

i-mode mail/Deco-mail/Deco mail pict.

Besides the main body of text, you can attach up
to 10 files (JPEG, ToruCa, PDF, etc.) of up to 2M
bytes in total. The FOMA terminal also supports
Deco-mail and Deco-mail pictographs, allowing
you to create and send more impressive mail
by providing a diversity of expression, such as
changing font color and size and using effect of
background color on mail main body (P.202).

Mega i-αppli/Virtual game

By downloading i-αppli from a relevant site, you can
enjoy games or obtain automatically updated information,
such as about market shares and weather.
Mega i-αppli is supported, enabling you to enjoy games
that require large amounts of memory, such as high
resolution 3D games and full-featured role playing games.
Additionally, the virtual games which are operated by
sensuously such as “tilting” the mobile phone are also
supported (P.234).

Compatible with High-Speed Communication

The FOMA HIGH-SPEED Area is supported a high­speed communication of the maximum reception
speed 3.6Mbps and maximum transmission speed
384kbps can be achieved (P.400).

International Roaming

You can use the same FOMA terminal, phone
number, and mail address as used in Japan when
you are overseas (supported GSM/3G areas). A
voice/videophone call, i-mode, i-mode mail, SMS,
and network services are available (P.406).

GPS

You can use various services using the location
information you obtain by GPS, such as viewing
the map of your location, searching for information
on your neighborhood, notifying your location
information by attaching it to mail, letting the
FOMA terminal to navigate you to the destination.
The Map appli is preinstalled and allows you to
use the high-definition map easily (P.260).

8

Chaku-Uta Full®/Uta-hodai/

Music&Video Channel※/Video clip

Music&Video Channel is a paid service that

※

requires a subscription.
Chaku-Uta Full® that allows you to download a
whole track of music and Uta-hodai that allows you
to enjoy favorite music as much as you want by
the fixed fee are supported.
Also, Music&Video Channel is supported to
download a music program during the night only
by setting it in advance and enjoy it. You can enjoy
program with video by the SO905iCS. Moreover,
because i-motion up to 10MB is supported, video
clip which allows you to enjoy a music clip of a
whole track of music is supported (P.334, 340).

Osaifu-Keitai/ToruCa

Once you download the Osaifu-Keitai-compatible
i-αppli, you can use the FOMA terminal to
deposit e-money to the IC card incorporated
in the terminal as well as to check your credit
balance and purchase history on a relevant site.
Furthermore, the i-αppli for “DCMX” credit service
provided by DoCoMo is preinstalled (P.240). The
“iC transfer service” is also supported, which
allows you to easily transfer data stored on the IC
card to another one in a case such when replacing
a FOMA terminal with a new model.
ToruCa is an e-card which you can obtain from
a reading device (reader/writer) or site and
exchanges with others easily using e-mail or
infrared communication (P.250).

Kisekae Tool

You can download data such as a display of your
favorite character from i-mode and change the
stand-by display and menu display to the data
at once. For SO905iCS, you can also change the
orders of the menu items based on your usage
and customize the menu display to your taste
(P.123, 125).

You can select the items quickly by scrolling the JOG
upward and downward. The JOG gives you more
convenient operations with the 4-way keys (P.28).

Stand-by books

Plus JOG

There are eight unique preinstalled Flash contents
which display various information such as bits of
knowledge, general knowledge, and picture books
wave after wave every time when the stand-by
display appears.
You can set your favorite content selecting from
the [Preinstalled] folder in My picture of the Data
Box and enjoy it (P.118).

Quick deco. Mail Function

Fun Deco-mail is available with simple steps (P.206).

“POBox Pro 2.0” and Convenient Text Input

The FOMA terminal is provided with the prediction
conversion function “POBox Pro 2.0” (Predictive
Operation Based On eXample Pro 2.0). Pressing

horizontally in the “POBox Pro 2.0”, enabling
to select the target word. Also, switching tabs
allows you to enable the speedy selection of the
matching words list (P.379).

allows you to move vertically and

Security Settings (P.129)

You can use voice call and packet communication
simultaneously. You can receive i-mode mail even
when you are in a call and you can also make a
call while you are using i-mode (P.348).

High-Definition Wide VGA Liquid-Crystal Screen Display

Multiaccess

A 2.7-inch high-resolution full wide liquid-crystal
screen display is employed. Not only you can
enjoy viewing websites, but also perform mail and
i-mode operations in the large screen comfortably.

Lifetime Calendar

The Lifetime Calendar allows you to display an
image, mail, Schedule, and Phonebook (birthday)
data directly from the Calendar and provides
you with more pleasant way of retrieving your
memories saved in the FOMA terminal (P.351).

Infrared Communication/Infrared Remote Control

You can exchange data with other FOMA terminals
using the infrared communication function. You can
also use the FOMA terminal to operate equipment
such as a TV that is provided with infrared remote
control. Moreover, the FOMA terminal supports
the high-speed infrared communication standard
IrSimple, allowing you to transfer high-quality images
to compatible devices at a high speed (P.323, 327).

Easy Search/Contents/Precautions

If you misplace the FOMA terminal, it can be

Omakase Lock

locked by your request. You can cancel the lock
as well. See the contact address at the backcover
of this manual for inquiries (P.136). Please note
that Omakase Lock is a paid service＊.

When you subscribe to this service together

＊

with your request to suspend the FOMA terminal
or while the FOMA terminal is suspended, the
service charge is not required.

Omakase Lock allows the FOMA terminal to be

ˎ

locked by a request from a subscriber of the
UIM inserted in the FOMA terminal. Note that
if the UIM subscriber and user of the FOMA
terminal are different, the FOMA terminal may
be locked without knowledge of the user by
request of the subscriber.

Data Security Service

You can save the Phonebook, images, and mail
of the FOMA terminal at the Data Security Service
Center, and restore the data stored at the Center
in case you lose any of it. You can also use a PC
to edit/manage the data stored at the Center and
update the FOMA terminal with newly edited data.
See the “Mobile Phone User’s Guide 【i-mode
FOMA version” to learn about the precautions and
details on how to use the Data Security Service
when you use this service. See the contact
address at the backcover of this manual for
inquiries. Data Security Service is a paid service
that requires a subscription (P.147).

Comprehensive Line-up of Network Services

Voice Mail Service (Paid) (P.388)

ˎ

Call Forwarding Service (Free) (P.389)

ˎ

Caller ID Display Request Service (Free) (P.391) ˎ Dual Network Service (Paid) (P.391)

ˎ

English Guidance Service (Free) (P.391)

ˎ

2in1 (Paid) (P.394)

ˎ

Call Waiting Service (Paid) (P.389)

ˎ

Nuisance Call Blocking Service (Free) (P.390)

ˎ

Multi Number Service (Paid) (P.393)

ˎ

】

9

Easy Search/Contents/Precautions

 →  最高１０℃  

１０

Making Full Use of SO905iCS !

Videophone

You can have a face-to-face conversation
with a person in the distance. You can hear
the person’s voice from the speaker without
changing any settings, so you can start a
conversation soon. You can switch a call
to a videophone call during a voice call
without hanging up as well (P.50).

Image of a person
you are talking to

Your image

PushTalk

You can communicate among several persons
(up to five persons including yourself) with a
simple operation of selecting recipients from
the PushTalk phonebook and pressing
(P.80).

Chaku-moji

You can send a message that is displayed
in the recipient’s Incoming call display
while calling the recipient. The recipient
can know the purpose of the call or feelings
of the caller from a message even before
the recipient answers (P.58).

Ｉｎｃｏｍｉｎｇ ｃａｌｌ

Ｕｒｇｅｎｔ

Caller

Recipient

Originating
a call

Chaku-moji

Recipient

I’ll arrive soon.

Recipient

Recipient
(Speaker)

i-Channel

You can receive graphical information such as News or weather.
You can also get rich and detailed information that is created with Flash (P.185) by selecting
your favorite channel from a list of available channels (P.198).

Unsubscribed Subscribed

Connect

i-Channel is a paid service that requires a subscription.

※

10

(i.ch)

Camera

The effective number of pixels: 5,110,000 and 3× optical zoom are employed. Also the FOMA
terminal has full recording functions such as the face-detecting auto-focus function or high­intensity flash and allows you to use as a real digital camera. The optical zoom can be also
used when recording a movie and you can record a movie up to 640×480 dots.
Moreover, you can enjoy using convenient functions such as “easy BlogUp” posting a
recorded image on a blog by simple steps, Deco-Snap, Panorama, or adding location
information on an image.

Graphical menu that enables you to set in a
twinkling by visual and dynamic operations

Face detection function that enables you to
record a people’s face more beautiful (up to
three faces detectable)

Ｓｅｌｅｃｔ ｓｉｚｅ

×

８６４）

Ｓｔｂｙ（４８０

Ｐｈｏｔｏｇｒａｐｈ ｉｍａｇｅ ｔｏ ｆｉｔ ｔｈｅ
ｓｉｚｅ ｏｆ ｓｔａｎｄｂｙ ｄｉｓｐｌａｙ

2in1

Easy Search/Contents/Precautions

2in1 is a service that allows you
to use two phone numbers, two
mail addresses, and special mode
functions to make one mobile

A mode

Phone No. : 090-AAAA-AAAA
Address : [e-mail]
Phonebook : For A mode

phone work like using two mobile
phones separately. Phonebooks,
mail boxes, redial/received
records, stand-by displays, etc.
can be managed by the “A mode”
and “B mode” separately and also
you can use the “Dual mode” to
manage both the A and B modes
at the same time (P.394).

2in1 is a paid service that requires a subscription.

※

Phone/mail
by A mode

Phonebook A
Mail box A
Records A
Voice mail A

・・

MUSIC Player

You can use the MUSIC Player
to play back Chaku-Uta Full
downloaded from a music
distribution site or music data that
was saved in the microSD memory
card using Windows Media
Player or Napster

®

. Also, a music
program of up to one hour that
is reserved for the Music&Video
Channel and automatically
distributed during the night can
be played back (P.336).

®

Music CDPCChaku-Uta Full® distribution site

Dual mode

Phonebook A/B
Mail box A/B
Records A/B
Voice mail A/B

・・

FOMA terminal

(microSD memory card)

B mode

Phone No. : 090-BBBB-BBBB
Address : [e-mail]
Phonebook : For B mode

Phone/mail
by B mode

Phonebook B
Mail box B
Records B
Voice mail B

・・

11

Easy Search/Contents/Precautions

Safety Precautions
(Observe Strictly)

For safe and proper use of the FOMA terminal,
please read the “Safety Precautions” prior to
use. Keep the Manual in a safe place for future
reference.
ALWAYS observe the safety precautions
since they intend to prevent personal injury or
property damage.

The following symbols indicate the different

■

levels of injury or damage that may result
if the guidelines are not observed and the
FOMA terminal is used improperly.

Failure to observe
these guidelines

DANGER

WARNING

CAUTION

The following symbols indicate specific

■

directions.

Indicates prohibited actions.

Don’t

may immediately
result in death or
serious injury.
Failure to observe
these guidelines
may result in
death or serious
injury.
Failure to
observe these
guidelines may
result in injury
and property
damage.

Indicates compulsory actions in
accordance with instructions.

Do

Indicates to remove the power

Unplug

“Safety Precautions” are described in the

■

following categories:

Handling the FOMA Terminal, Battery Pack,

Handling the FOMA Terminal .....................................14

Handling the Battery Pack..........................................16

Handling the Adapter (including the charger) ...........17

Handling the UIM .......................................................18

Handling the FOMA Terminal Near

plug from the outlet.

Adapter (including the charger), and UIM ...12

Electronic Medical Equipment ...................... 18

Handling the FOMA Terminal, Battery Pack,
Adapter (including the charger), and UIM

DANGER

Do not use, store, or leave the

FOMA terminal, battery pack,
adapter, or UIM in a place subject to

Don’t

high temperature such as close to
fire, under direct sunlight, or in a car
on an extremely hot day.

Doing so may cause the device
to be deformed or damaged, or
the battery pack to leak, overheat,
explode, catch fire, or deteriorate
in performance and longevity. Also,
part of the case may heat up and
cause burns.

12

No

Disassembly

No

liquids

No wet

hands

Indicates not to disassemble.

Indicates not to use where it
could get wet.

Indicates not to handle with wet
hands.

No

Disassembly

Do not disassemble or modify the

FOMA terminal, battery pack, or
adapter and do not directly solder
the battery pack to the FOMA
terminal.

Doing so may cause accident such
as fire, injury or electric shock, or
malfunction. Also, it may cause
the battery pack to leak, overheat,
explode, or catch fire.

Do not get the FOMA terminal,

battery pack, or adapter wet.

If liquids such as water or pet urine

No

liquids

get into the device, it may cause
overheating, electric shock, fire,
malfunction, or injury. Be careful
where and how you use the device.

Use the battery packs and adapters

(including chargers) specified for the
FOMA terminal by DoCoMo.

Do

The use of products that are not
specified may cause the FOMA
terminal, battery pack, or other
device to leak, overheat, explode,
catch fire, or malfunction.

Battery Pack SO02, Desktop Holder
SO08, FOMA AC Adapter 01/02,
FOMA DC Adapter 01/02, FOMA
Portable Charging Adapter 01,
FOMA Dry Battery Adapter 01,
FOMA AC Adapter 01 for Global
use, FOMA USB Cable with Charge
Function 01

Contact our service counter (DoCoMo

※

shop, etc.) for information on other
compatible products.

WARNING

Do not place the FOMA terminal,

battery pack, adapter (including
the charger), or UIM inside cooking

Don’t

appliance such as a microwave oven
or high-pressure containers.

Doing so may cause the battery
pack to leak, overheat, explode,
or catch fire, or the FOMA terminal
and adapter (including the charger)
to overheat, smoke, catch fire, or
damage the circuit parts.

Do not subject the FOMA terminal,

battery pack, or adapter to excessive
force or throw it.

Don’t

Doing so may cause the battery
pack to leak, overheat, explode, or
catch fire, or cause the device to
malfunction or catch fire.

Do not allow the charge and external

connection terminals to come in
contact with conducting foreign

Don’t

substances (a piece of metal, pencil
lead, etc.). Never allow these objects
to get into the FOMA terminal,
battery pack, or adapter.

Doing so may cause fire or
malfunction due to short circuits.

Power off the mobile phone before

you step into a place where
flammable gas can leak, such as

Do

Do not charge the battery as well

gas stations.

because it may cause gas to ignite.

Keep the mobile phone powered
off even when you use the Osaifu­Keitai in gas station premises or
other similar place.

(When the IC card lock is set,
cancel the lock and then power off
the mobile phone.)

If you notice anything unusual about

the FOMA terminal, battery pack,
or adapter such as an unusual

Do

odor, overheating, discoloration
or deformation during operation,
charging or storage, immediately
perform the following measures.

1. Remove the power plug from the
power outlet or cigarette lighter
socket.

2. Power off the FOMA terminal.

3. Remove the battery pack from the
FOMA terminal.

Failure to do so may cause the
device to overheat, explode, or
catch fire, or the battery pack to
leak.

CAUTION

Do not place on an unstable or

inclined platform.

Doing so may cause the device to

Don’t

fall and cause injury or malfunction.

Easy Search/Contents/Precautions

Continued

13

Easy Search/Contents/Precautions

Do not keep in a place that is very

humid, dusty, or subject to high
temperature.

Don’t

Doing so may cause malfunction.

If children use the FOMA terminal,

parents or guardians should give
them the proper instructions for use.

Do

Make sure that they use the FOMA
terminal as instructed.

Failure to do so may cause injury.

Keep the FOMA terminal, battery

pack, adapter, and UIM out of the
reach of babies and infants.

Do

Failure to do so may cause
accidental swallowing or injury.

Be careful especially when you

use the FOMA terminal while it has
been continuously connected to the

Do

adapter (including the charger) for a

If you continue using i-αppli or

long period of time.

talking on the videophone for a long
period of time with the battery being
charged, the temperature of the
FOMA terminal, battery pack, and
adapter (including the charger) may
rise.

If you are directly in contact with
hot parts for a long period of time, it
may cause your skin to become red,
itch, or develop a rash depending
on your physical condition and also
it may cause low-temperature burn.

Handling the FOMA Terminal

WARNING

Do not aim the infrared data port

towards eyes when using the
infrared communication.

Don’t

Doing so may affect your eyes.
Also, aiming it towards other
infrared devices may interfere with
the operation of these devices.

Do not turn on the photo light with

the lighting luminescence part close
to the eyes.

Don’t

Doing so may cause vision
impairment or accident by dazzling
eyes or surprising.

Do not leave the FOMA terminal in

a place such as the dashboard near
the automobile air bag, which can

Don’t

have an adverse effect on the phone
when it inflates.

Doing so may cause accidents
such as an injury, malfunction,
or breakage, in case the air bag
inflates.

Do not put the FOMA terminal in

your breast pocket or inside pocket
if you are wearing any electronic

Don’t

medical equipment.

If the FOMA terminal is used close
to electronic medical equipment, it
may cause malfunction.

Do not allow a foreign substance

such as water and other liquids,
metal parts, or flammables to get in

Don’t

the UIM or microSD memory card
insertion slot on the FOMA terminal.

Doing so may cause fire, electric
shock, or malfunction.

Do not turn on the light toward a

driver such as of a car.

Doing so may disturb driving and

Don’t

cause an accident.

Power off the FOMA terminal in a

place where the use is prohibited
such as in airplane or hospital.

Do

Failure to do so may affect
electronic equipment and electronic
medical equipment. If you set the
automatic power-on function, cancel
it before powering off the FOMA
terminal.
Follow the instructions of each
medical facility for the use of mobile
phones on their premises.

14

Prohibited acts such as mobile
phone usage on board an airplane
may be punished by law.

Always keep the FOMA terminal

away from your ear when you talk
setting the hands-free function. Also,

Do

when you play game or play back
music connecting the Earphone/
Microphone to the FOMA terminal,
adjust the volume adequately.

If the volume is too loud, it may
cause difficulty in hearing.
Moreover, if you barely hear the
surrounding sounds, it may cause
an accident.

If you have a weak heart, set the

vibrator or ring volume carefully.

Failure to do so may affect your

Do

heart.

If you hear thunder while using the

FOMA terminal outdoors, power off
immediately, and take shelter in a

Do

safe place.

Failure to do so may cause injury or
electric shock from the lightning.

Power off the FOMA terminal near

electronic devices or equipment
operating on high precision control

Do

or weak signals.

Failure to do so may interfere with
the operation of electronic devices
or equipment.

The followings are some electronic

※

devices or equipment that you should
be careful of:
Hearing aids, implantable cardiac



pacemaker, implantable cardioverter
defibrillator, other electronic medical
equipment, fire detector, automatic
door, and other automatically controlled
devices or equipment.
If you use an implantable cardiac



pacemaker, implantable cardioverter
defibrillator, or other electronic
medical equipment, check with the
relevant medical electronic equipment
manufacturer or vendor whether the
operation can be affected by radio
waves.

Be careful about broken glasses or

exposed internal from the FOMA
terminal if the display or the camera

Do

lens is broken.

The display and the camera lens are
designed not to be shattered when
broken using the plastic panel. But
they may cause injury if you touch
a cut surface or exposed portion
mistakenly.

CAUTION

Do not swing the FOMA terminal

around by holding the strap.

The FOMA terminal may hit you or

Don’t

others and doing so may cause
accident such as injury or damage
to the FOMA terminal or other
property.

To use the Motion tracking functions,

make sure that your surroundings
are safe to play, grip the FOMA

Don’t

terminal firmly, and do not shake it
around unnecessarily.

Motion tracking is a function to
operate the FOMA terminal by titling
or shaking. If you shake it too much
and it hits a person or objects, it
may cause a serious accident or
damage.

Do not hit a person or objects by the

strap while using the Motion tracking
functions when you attach the

Don’t

strap made of metal to the FOMA
terminal.

Doing so may cause accidents such
as malfunction or damage.

Do not place a magnetic card,

etc. near the FOMA terminal or
let it caught by the closed FOMA

Don’t

terminal.

Magnetic data on bankcards, credit
cards, telephone cards, floppy
disks, etc. may be erased.

Easy Search/Contents/Precautions

Continued

15

Easy Search/Contents/Precautions

Do not place magnetized devices

near the FOMA terminal.

The strong magnetism may interfere

Don’t

with the operation.

If the display is mistakenly damaged

and when the liquid crystal is
broken, do not drink, absorb, or get

Don’t

it on your skin.

If the liquid crystal gets on your eye

or mouth, rinse with clean running
water, and get medical treatment
immediately.

Also, if it gets on your skin or

clothes, use something such as
alcohol to wipe off and wash it with
soap in clear water.

Failure to do so may cause
blindness or injury on your skin.

Do not bring your ear closer to the

speaker when the ring tone sounds
or melody is played back on the

Don’t

FOMA terminal.

Doing so may cause difficulty in
hearing.

In rare cases, using the FOMA

terminal may interfere with the
operation of electronic devices in

Do

some types of vehicle.

If there is any interference, do not
use the FOMA terminal when driving
for safety reasons.

The use of the FOMA terminal may

cause itching, rashes, eczema,
or other symptoms depending

Do

on the user’s physical condition.
Immediately stop using and get
medical treatment in such a case.

Metals are used as listed below:

Where it

Camera
ring

Plus JOG Aluminum

Material Surface treatment

is used

Nickel C hrome plating

base alloy

finish
Anodized

aluminum finishing

Be careful not to get your finger,

palm, or the strap caught in the
closed FOMA terminal when you

Do

close and open it.

Failure to do so may cause injury or
damage.

Handling the Battery Pack

Check the type of the battery by the label on

■

the battery pack.

Display Type of Battery

Li-ion Lithium Ion Battery

DANGER

Do not touch the battery pack

terminal with a metal object such
as a wire. Also, do not carry or keep

Don’t

the battery pack together with metal
objects such as a necklace.

Doing so may cause the battery
pack to leak, overheat, explode, or
catch fire.

Do not forcibly attach the battery

pack to the FOMA terminal. Also,
make sure to attach the battery pack

Don’t

in the correct direction.

Doing so may cause the battery
pack to leak, overheat, explode, or
catch fire.

Do not throw the battery pack into

fire.

Doing so may cause the battery

Don’t

pack to leak, overheat, explode, or
catch fire.

Do not stick a nail into the battery

pack, hit it with a hammer, or step
on it.

Don’t

Doing so may cause the battery
pack to leak, overheat, explode, or
catch fire.

16

If the battery fluid gets into your

eyes, do not rub, rinse with clean
running water, and get medical

Do

treatment immediately.

Failure to do so may cause
blindness.

WARNING

If any abnormality caused by an

external shock, such as deformation
or damages by falling is found in the

Don’t

battery pack, stop using the battery
pack immediately.

Failure to do so may cause the
battery pack to leak, overheat,
explode, or catch fire, or cause the
device to malfunction or catch fire.

Stop charging if the FOMA terminal

is not charged within the specified
charging time.

Do

Failure to do so may cause the
battery pack to leak, overheat,
explode, or catch fire.

If the battery pack leaks or hears

an unusual odor, immediately stop
using and move it away from fire.

Do

The leaking liquid may ignite fire,
catch fire, or explode.

Be careful about your pet not to bite

the battery pack.

Failure to do so may cause the

Do

battery pack to leak, overheat,
explode, or catch fire, or cause the
device to malfunction or catch fire.

CAUTION

Do not dispose of the battery pack

together with other garbage.

The battery pack may become

Don’t

the source of fire or environmental
destruction. Take the used battery
pack to our service counter
(DoCoMo shop, etc.) after insulating
it by affixing an adhesive tape
on the terminal of it or follow the
instructions of the local authorities
in charge of collecting used battery
packs.

Do not charge the wet battery pack.

Doing so may cause the battery
pack to overheat, catch fire, or

Don’t

explode.

If the battery fluid gets on your skin

or clothes, immediately stop using
the battery pack and rinse with clean

Do

running water thoroughly.

Failure to do so may cause injury on
your skin.

Handling the Adapter (including
the charger)

WARNING

Do not use the adapter (including the

charger) if the cord of the adapter or
the power cord is damaged.

Don’t

Doing so may cause electric shock,
overheating, or fire.

Do not use the AC adapter or

desktop holder in a very humid or
steamy place such as bathroom.

Don’t

Doing so may cause electric shock.

Easy Search/Contents/Precautions

The DC adapter is for use in vehicles

with a negative ground. Do not use it
in vehicles with a positive ground.

Don’t

Doing so may cause fire.

Continued

17

Easy Search/Contents/Precautions

Do not touch the FOMA terminal

and adapter (including the charger)
if you hear thunder.

Don’t

Doing so may cause injury or
electric shock from the lightning.

Do not short-circuit the charge

terminal of the charger while the
power plug is connected to the

Don’t

power outlet or cigarette lighter
socket. Do not touch the charge
terminal with your hands, fingers, or
any part of your body.

Doing so may cause fire,
malfunction, electric shock, or injury.

Place the charger or the desktop

holder on a stable platform while
charging. Do not cover or wrap the

Don’t

charger or the desktop holder with a
cloth or bedding.

The FOMA terminal may fall off the
charger or heat up and cause fire or
malfunction.

Do not place any heavy objects on

the cord of the adapter (including
the charger) or the power cord.

Don’t

Doing so may cause electric shock
or fire.

Do not touch the cord of the adapter

(including the charger) or the power
outlet with wet hands.

No wet

hands

Doing so may cause electric shock.

Use the adapter only on the

specified power supply and voltage.

Failure to do so may cause fire or

Do

malfunction. Use the AC adapter
available overseas when you use
the phone overseas.

AC adapter: AC 100 V
DC adapter: DC 12 V/24 V

(exclusively used for vehicles

with a negative ground)
AC adapter available overseas:
AC 100 to 240 V

(Make sure to connect the

adapter to a household AC power

outlet.)

If the fuse of the DC adapter is

blown, replace it with the specified
fuse.

Do

The use of a fuse other than
specified one may cause fire or
malfunction. See the user’s manual
supplied with the adapter for the
specified fuse.

Clean dust from the power plug.

Failure to do so may cause fire.

Do

When you connect the AC adapter

to the power outlet, make sure that
it does not come in contact with a

Do

metal object such as a metal strap
and insert it firmly.

Failure to do so may cause electric
shock, short circuit, or fire.

18

Hold the power plug, not the cord of

the adapter (including the charger)
or the power cord, when you remove

Do

the adapter (including the charger)
from the power outlet or cigarette
lighter socket.

Pulling the cord may damage it and
cause electric shock or fire.

Remove the power plug from the

power outlet when not used for a
long period of time.

Unplug

Failure to do so may cause electric
shock, fire, or malfunction.

If liquid such as water gets into the

adapter, immediately remove it from
the power outlet or cigarette lighter

Unplug

socket.

Failure to do so may cause electric
shock, smoking, or fire.

Before cleaning, remove the power

plug from the power outlet or
cigarette lighter socket.

Unplug

Failure to do so may cause electric
shock.

Handling the UIM

CAUTION

Please be careful not to touch a cut

surface when you remove the UIM
(IC portion).

Do

Failure to do so may damage your
hand or fingers.

Handling the FOMA Terminal Near
Electronic Medical Equipment

The following instructions observe

■

the guidelines of the Electromagnetic
Compatibility Conference, Japan to protect
electronic medical equipment from radio
waves from mobile phones.

WARNING

Please observe the following

guidelines in medical facilities.

Do not take the FOMA terminal

ˎ

Do

into the operating rooms, ICU
(Intensive Care Unit), or CCU
(Coronary Care Unit).

Power off the FOMA terminal

ˎ

inside hospital wards.

Power off the FOMA terminal in

ˎ

the lobby and other places if
there are any electronic medical
equipment operating in the
vicinity.

Follow the instructions of each

ˎ

medical facility when they specify
areas forbidding to use and
carrying a mobile phone.

If you set the automatic power-

ˎ

on function, cancel it before
powering off the FOMA terminal.

Power off the FOMA terminal in

crowded places such as rush-hour
trains. There may be a person with

Do

an implantable cardiac pacemaker or
implantable cardioverter defibrillator
near you.

The radio waves from the FOMA
terminal may affect the operation
of implantable cardiac pacemaker
or implantable cardioverter
defibrillator.

If you use an implantable cardiac

pacemaker or implantable
cardioverter defibrillator, keep the

Do

FOMA terminal more than 22 cm
away from the implant at all times.

The radio waves from the FOMA
terminal may affect the operation
of implantable cardiac pacemaker
or implantable cardioverter
defibrillator.

If you need to use electronic medical

equipment other than implantable
cardiac pacemaker or implantable

Do

cardioverter defibrillator outside
medical facilities such as treating
at home, check with the relevant
medical electronic equipment
manufacturer or vendor whether the
operation may be affected by radio
waves.

The radio waves from the FOMA
terminal may affect the operation of
electronic medical equipment.

Easy Search/Contents/Precautions

19

Easy Search/Contents/Precautions

Handling Precautions

Common Precautions

◆

Do not expose to water.

●

The FOMA terminal, battery pack, adapter

ˎ

(including the charger), and UIM are not
waterproof. Do not use them in a humid place
such as bathroom or in the rain. If you carry the
FOMA terminal on your body, perspiration may
corrode the internal parts of the FOMA terminal
and cause malfunction. Note that if a trouble is
diagnosed as exposure to water or other liquid,
repairs of the FOMA terminal may not be covered
by the Warranty or it may not be possible to
repair such phones. In that case, even if the
FOMA terminal can be repaired, it is repaired at
the owner’s expense.

Clean the FOMA terminal with a dry soft

●

cloth (such as used for cleaning eyeglasses).

The color liquid crystal display of the FOMA

ˎ

terminal has a special coating on it for better
visibility. Do not use unnecessary force to wipe the
display when you are cleaning it with a dry cloth.
The display and its coating may be damaged.
Handle the display with care and use a dry soft
cloth (such as used for cleaning eyeglasses)
to clean it. If the display is left with water drops
or stains, stains may become permanent or the
display coating may be peeled off.

Do not use alcohol, thinner, benzene, cleaning

ˎ

detergent, etc. to clean the FOMA terminal.
These chemicals may erase the printing on the
FOMA terminal or cause discoloration.

Clean the terminals occasionally with a dry

●

cotton swab.

Soiled terminals may cause poor connection and

ˎ

loss of power. If the terminals are dirty, use a dry
cloth or cotton swab to wipe them clean.

Do not leave the FOMA terminal near the air

●

conditioning vent.

Extreme temperature changes may produce

ˎ

condensation and corrode the internal parts of
the FOMA terminal, causing it to malfunction.

Make sure to use the FOMA terminal or

●

battery pack without excessive force.

If you put the FOMA terminal in a bag full of items

ˎ

or sit down with the FOMA terminal in the pocket
of your clothe, it may damage the display, and
internal circuit board, and the battery pack and
cause the FOMA terminal to malfunction.
Also, while the external device is connected to
the External connection terminal or Earphone/
Microphone jack, it may damage the connector
and cause malfunction.

Make sure to see the user’s manuals

●

supplied with the FOMA terminal, battery
pack, adapter (including the charger), and
desktop holder.

Do not rob or scratch the display with metal.

●

The display may get scratched and it may cause

ˎ

malfunction or damage.

FOMA Terminal Precautions

◆

Do not use the FOMA terminal in extremely

●

hot or cold places.
Use the FOMA terminal within a temperature



range of 5°C to 35°C and a humidity range
of 45% to 85%.

Using the FOMA terminal near ordinary

●

phone, television or radio may cause
interference in these electric appliances.
Make sure to move far away from them when
using the FOMA terminal.

Note down the information saved in the

●

FOMA terminal in a separate note and keep
it safely.

Under no condition will DoCoMo be held liable

ˎ

for any damaged or lost data saved in the FOMA
terminal.

Do not plug the connector of the external

●

device into the External connection terminal
or Earphone/Microphone jack at the slant
and pull it while connecting.

Doing so may cause malfunction or damage to

ˎ

the FOMA terminal.

Do not close the FOMA terminal with an

●

object including the strap left inside.

Doing so may cause malfunction or damage to

ˎ

the FOMA terminal.

The FOMA terminal could become warm

●

while in use and charging. This condition is
not abnormal. You can continue using the
FOMA terminal.

Do not leave the camera under direct

●

sunlight.

If you do so, some of the phone parts may melt

ˎ

or become faded.

Use the FOMA terminal with the covers of

●

the Earphone/Microphone jack, External
connection terminal, and microSD memory
card slot closed.

Failure to do so may get dust or water inside and

ˎ

cause malfunction.

Do not use the FOMA terminal without the

●

back cover.

Doing so may cause the battery pack fall,

ˎ

malfunction, and damage.

Do not stick extremely thick sticker on the

●

display or keypad.

Doing so may cause malfunction.

ˎ

20

Do not remove the microSD memory card or

●

power off the FOMA terminal while using the
microSD memory card.

Doing so may cause data loss or malfunction.

ˎ

If you conduct any criminal behavior using

●

the FOMA terminal that is a nuisance to the
public, you may be subjected to punishment
by authorities in accordance with related laws
or ordinances (nuisance prevention act, etc.).

Please be considerate of the privacy of individuals

around you when taking and sending photos using
camera-equipped mobile phones.

Battery Pack Precautions

◆

The battery pack is a consumable accessory.

●

Even if the operating time of the FOMA terminal

ˎ

varies depending on the operating conditions
and other factors, when the length of time you
can use the FOMA terminal with a fully charged
battery becomes unusually short, it is time to
replace the battery pack. Purchase the battery
pack specified in this manual.

Charge the battery pack in an environment

●

with the proper ambient temperature (5°C to
35°C).

Make sure to charge the battery pack before

●

you use the FOMA terminal for the first time
or when you have not been using it for a long
period of time.

The operating time of the battery pack varies

●

depending on the operating environment and
the secular degradation of the battery pack.

Depending on the use condition, the battery

●

pack may be inflated as it comes to the end
of its life. This is not a malfunction.

Do not store or leave the battery pack with

●

the condition of which the battery level is 0.

Doing so may decrement the performance or

ˎ

shorten the life of the battery pack.

Adapter (including the charger)

◆

Precautions

Charge the battery pack in an environment

●

with the proper ambient temperature (5°C to
35°C).

Do not charge in the following places.

●

Places that are very humid, dusty or exposed to

ˎ

strong vibrations.

Near ordinary phone, TV or radio.

ˎ

The adapter (including the charger) could

●

become warm while charging. This condition
is not abnormal. You can continue charging
the battery.

When you charge the battery pack using the

●

DC adapter, keep the car engine running.

Charging the battery with the engine turned off

ˎ

may drain your car battery.

When you use the power outlet with a

●

mechanism to prevent the plug from being
removed, follow the instructions on the
outlet’s user’s manual.

Do not give a strong impact to the adapter.

●

Also, do not bend or deform the charging
pins or pin guide on the adapter.

If you do so, the adapter may not work properly.

ˎ

UIM Precautions

◆

Do not use unnecessary force to insert/

●

remove the UIM.

The UIM could become warm while it is in

●

use. This condition is not abnormal. You can
continue using the card.

Do not inser t and use the UIM with another

●

IC card reader/writer. Please note that
you are wholly liable for any damage or
malfunction as a result of such action.

Always keep the IC portion clean when you

●

use the card.

Use a dry soft cloth (such as used for

●

cleaning eyeglasses) for cleaning and
maintenance of the UIM.

Note down the information saved in the UIM

●

in a separate note and keep it safely.

Under no condition will DoCoMo be held liable

ˎ

for any damaged or lost data saved in the UIM.

Take an expended UIM to our service

●

counter (DoCoMo shop, etc.) for proper
disposal in order to protect the environment.

Do not use the UIM in extremely high or low

●

temperature.

Do not carelessly damage, contact, or short

●

circuit an IC.

Doing so may cause data loss or malfunction.

ˎ

Do not drop a UIM or subject it to impact.

●

Doing so may cause malfunction.

ˎ

Do not bend a UIM or place a heavy object

●

on it.

Doing so may cause malfunction.

ˎ

Do not insert the UIM on which any label or

●

seal is stuck into the FOMA terminal.

Doing so may cause malfunction.

ˎ

Continued

Easy Search/Contents/Precautions

21

FeliCa Reader/Writer

◆

Easy Search/Contents/Precautions

The FeliCa reader/writer function of the

●

FOMA terminal uses extremely weak radio
waves, so that no license is required for use
as a radio station.

The FeliCa reader/writer function of the

●

FOMA terminal uses frequencies in the

13.56MHz range. If there is another reader/
writer used in the neighborhood, keep
enough distance from it. Attention should be
also paid to assure that no other radio station
which uses the same frequency range exists
near the FOMA terminal.

Caution

◆

Never use the modified FOMA terminal.

●

Using the modified equipment is against the
Radio Law.

The FOMA terminal satisfies certificates such as
the technology standard agreement of the specific
wireless equipment based on the Radio Law. The
model sticker of the FOMA terminal shows “

” as the proof of it.

ク

If you modify the inside of the FOMA terminal by
taking screws off, the certificates such as the
technology standard agreement, are counted as
invalid.
Using the FOMA terminal, while the certificates
such as the technology standard agreement are
invalid, is against the Radio Law, so that never use
it under those conditions.

Be careful using the FOMA terminal while

●

driving a vehicle.

Holding the mobile phone with a hand while

ˎ

driving applies the penal regulations.

When you are compelled to receive a call, tell

“Call you back” to the caller using the hands-free
funcion and park the vehicle in a safe place to
place a call.

Use the FeliCa reader/writer function only in

●

Japan.

The FeliCa reader/writer function of the FOMA

ˎ

terminal is designed to conform to the Japanese
radio standard. Overseas use of this function
may be subject to punishment.

Use the IC card authentication function only

●

in Japan.

The IC card authentication function of the FOMA

ˎ

terminal is designed to conform to the Japanese
radio standard. Overseas use of this function
may be subject to punishment.

22

技適マー

Intellectual Property Right

Copyright and Right of Portrait

◆

Copyrighted contents you recorded or obtained from
sites or Internet home pages using this product by
downloading or other means, such as documents,
images, music data, software, are prohibited from
reproduction, transformation and transmission over
public lines without consent of the copyright holders,
unless intended for personal use or any other purpose
permitted by law.
Note that some performances, shows, and exhibitions
may not allow photography, movie shooting, or sound
recording even for personal use.

You should also refrain from taking a picture of other
people and disclosing it by such means as posting it
on a site on the Internet without their consent because
of possible infringement of their right of portrait.

Trademarks

◆

“FOMA”, “mova”, “i-mode”, “i-Channel”, “PushTalk”,

ˎ

“PushTalkPlus”, “ToruCa”, “i-αppli”, “i-αppliDX”,
“i-motion”, “i-area”, “Deco-mail”, “Chara-den”,
“Short Mail”, “mopera U”, “mopera”, “DoPa”,
“WORLD CALL”, “WORLD WING”, “Chaku-motion”,
“FirstPass”, “Dual Network”, “DCMX”, “iD”, “Public
mode”, “Security Scan”, “2in1”, “sigmarion”,
“musea”, “V-live”, “visualnet”, “IMCS”, “OFFICEED”,
“Chokkan Game”, “FOMA” logo, “i-mode” logo,
“i-αppli” logo, “DCMX” logo, “iD” logo, “WORLD
WING” logo, and “HIGH SPEED” logo are trademarks
or registered trademarks of NTT DoCoMo.

“Catch Phone (Call waiting service)” is a registered

ˎ

trademark of Nippon Telegraph and Telephone
Corporation.

Free Dial logo mark is a registered trademark of NTT

ˎ

Communications Corporation.

®

is a registered trademark or trademark of

McAfee

ˎ

McAfee, Inc. and/or its affiliates in the U.S. and/or
other countries.

G-GUIDE, G-GUIDE MOBILE,

ˎ

and their logos are registered
trademarks in Japan of U.S.
Gemstar-TV Guide International,
Inc. and/or its affiliates.

QuickTime is a registered trademark of Apple Inc.,

ˎ

in the U.S. and other countries.

Powered by JBlend™ Copyright 2002-2007

ˎ

Aplix Corporation. All rights reserved.
JBlend and JBlend-related trademarks
are trademarks or registered trademarks
of Aplix Corporation in Japan and other
countries.

” is a registered trademark of FeliCa Networks,

“

ˎ

Inc.

microSD logo is a trademark.

ˎ

“Multitask” is a registered trademark of NEC

ˎ

Corporation.

Microsoft

ˎ

®

are trademarks or registered trademarks of the
U.S. Microsoft Corporation in the U.S. and other
countries.

, Windows®, and Windows Vista

®

Windows Media

ˎ

or trademark of Microsoft Corporation in the United
States and/or other countries.

Napster is a registered trademark of Napster, LLC.

ˎ

and/or its affiliates in the US and/or other countries.

Mascot Capsule

ˎ

Corporation.

“PostPet” is a registered trademark of So-net

ˎ

Entertainment Corporation.

POBox is a trademark of Sony Corporation.

ˎ

“BestPic” is a registered trademark of Sony Ericsson

ˎ

Mobile Communications AB.

“+JOG”, “Stand-by books”, “RealityMAX”, and

ˎ

“Ericle” are trademarks or registered trademarks of
Sony Ericsson Mobile Communications Japan, Inc.

Java and Java-related trademarks are trademarks or

ˎ

registered trademarks of the U.S. Sun Microsystems,
Inc. in the U.S. and other countries.

ImageStar is a registered trademark of Ainix

ˎ

Corporation.

QR code is a registered trademark of Denso Wave

ˎ

Inc.

IrSimple™, IrSS™, and IrSimpleShot™ are

ˎ

trademarks of Infrared Data Association

Other system names and/or product names

ˎ

mentioned in this manual are generally trademarks
or registered trademarks of their respective owners.
The trademark symbol ™ and registered trademark
symbol

Others

◆

Contains Flash

ˎ

Adobe
Adobe Systems Incorporated
Flash Lite copyright ©
1995-2007 Adobe Macromedia
Software LLC. All rights
reserved.

Adobe Reader copyright © 1984-2007 Adobe

Systems Incorporated. All rights reserved.

Adobe, Flash, Flash Lite and Reader are either

registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or
other countries.

GestureTek technology is installed in this product.

ˎ

Copyright © 2007, Gesture Tek, Inc. All rights
reserved.

Content owners use Windows Media digital rights

ˎ

management technology (WMDRM) to protect their
intellectual property, including copyrights. This
device uses WMDRM software to access WMDRM­protected content.
If the WMDRM software fails to protect the content,
content owners may ask Microsoft to revoke the
software’s ability to use WMDRM to play or copy
protected content.
Revocation does not affect unprotected content.
When you download licenses for protected content,
you agree that Microsoft may include a revocation
list with the licenses. Content owners may require
you to upgrade WMDRM to access their content.
If you decline an upgrade, you will not be able to
access content that requires the upgrade.

®

is either a registered trademark

®

is a trademark of the HI

®

are omitted hereafter in this manual.

®

®

Lite™ and

Reader® technology by

®

.

This product contains

ˎ

NetFront Browser and
NetFront Sync Client of
ACCESS CO., LTD.
ACCESS and NetFront are
trademarks or registered
trademarks of ACCESS CO., LTD. in Japan and
other countries.
Copyright © 2007 ACCESS CO., LTD. All rights
reserved.

This product incorporates a program module

ˎ

developed by Independent JPEG Group.

FeliCa is a contactless IC card technology

ˎ

developed by Sony Corporation. FeliCa is a
registered trademark of Sony Corporation.

Powered by Mascot Capsule

ˎ

Built with Linter Database.

ˎ

Copyright © 2006-2007 Brycen Corp., Ltd.
Copyright © 1990-2003 Relex, Inc., All rights
reserved.

POBox technology has been developed by Sony

ˎ

Computer Science Laboratories, Inc.

This product is under the licensing agreement of

ˎ

the MPEG-4 Visual Patent Portfolio License, and is
approved for private and non-profit uses, such as
those indicated below.

For recording MPEG-4 Visual standards-compliant

-

movie (hereinafter referred to as MPEG-4 Movie).

For playing back MPEG-4 Movie recorded by a

-

consumer who uses the product for private and
non-profit activities.

For playing back MPEG-4 Movie recorded by a

-

provider who owns an MPEG-4 license.

To use this product for other applications, such



as promotional activities, company use, or profit­making endeavor, contact U.S. MPEG LA, LLC.

This product includes software

ˎ

licensed from Symbian Software Ltd.
Symbian, Symbian OS, and all Symbian-related
trademarks and logos are trademarks or registered
trademarks of Symbian Software Ltd.
© 1998-2007 Symbian Software Ltd. All rights
reserved.

Windows Title Conventions

◆

Windows 2000 is an abbreviation of the Microsoft

ˎ

Windows® 2000 Professional operating system.

Windows XP is an abbreviation of the Microsoft

ˎ

Windows® XP Professional operating system or

®

Windows® XP Home Edition operating

Microsoft
system.

Windows Vista is an abbreviation of the Windows

ˎ

Vista™ (Home Basic, Home Premium, Business,
Enterprise, Ultimate).

®

Easy Search/Contents/Precautions

®

®

23

Easy Search/Contents/Precautions

Supplied and Optional Accessories

Supplied accessories

■

FOMA SO905iCS

(w/warranty and back cover SO09)

Optional accessories

■

FOMA AC Adapter 01/02

(w/warranty and user’s manual)

Manual for FOMA SO905iCS
(this manual)

(w/Quick Manual P.490)

Battery Pack SO02

Li-ion

FOMA SO905iCS CD-ROM

(“Manual for PC connection
setting” (PDF format) and “Kuten
Code List” (PDF format) are
included)

Desktop Holder SO08

(w/user’s manual)

Other optional accessories (P.435)

ˎ

24

Before Using the

Handset

Part Names and Functions ........................................................................................ 26

Opening/Closing the FOMA Terminal ........................................................................ 29

About the Style .......................................................................................................... 29

Using the Displays ..................................................................................................... 30

Selecting the Menu .................................................................................................... 33

Using the UIM ............................................................................................................ 36

Attaching and Removing the Battery Pack ................................................................ 39

Charging the FOMA Terminal .................................................................................... 40

Checking the Battery Level ...................................................................

Powering On/Off ...................................................................................

Setting the Basic Functions ..................................................................

Setting the Date and Time ........................................................................

Notifying the Recipient of Your Phone Number ..................................

Checking Your Own Phone Number .....................................................

<Battery level>

<Power on/off>

<Initial setting>

<Date/time>

<Notify caller ID>

<Own number>

42

43

43

44

45

45

25

Part Names and Functions

Before Using the Handset

Connecting the Flat-plug Earphone/

Microphone with Switch (optional)



In-Camera

Use to record a still image or movie (P.155, 167) or
send the image at your side during a videophone call
(P.50).



Display (P.30)



Charge Indicator/FeliCa Sign

Lights in red while charging the battery (P.41).
Lights in green during iC communication or when the
FOMA terminal comes within the communication range
with the reading device (P.251, 328).



Mail Key

In the stand-by display, press to display the Mail menu
(P.202) and press for over a second to perform the
Check new message (P.212, 227).
Press to select an item in the guide display (P.33).



MENU Key

Press to display the menu (P.33, 349).

26



Call/Hands-free Switch Key

Press to place a voice call or start talking on the phone
of a voice, videophone, or PushTalk call.
Press during a call to switch ON/OFF of the hands-free
function (P.53).



Keypad

Enter phone numbers or text (P.426).
In the stand-by display, press for over a second to
display the Reset display (P.372).
In the stand-by display, press for over a second to
check your current location (P.260).



/IC Card Lock Key

In the stand-by display, press for over a second to lock
the IC card function or cancel the lock. To cancel the
lock, enter the Security code (P.258).



Earpiece

The caller’s voice is heard from here.



Plus JOG

Ͱ

Incoming Indicator

Flashes when receiving a call/mail. It flashes when there
is a missed call or new mail/unread message (P.126).
Flashes while obtaining the location information using
the GPS function (P.260).

ͱ

In the stand-by display, press to display the i-mode
menu (P.182) and press for over a second to display
the i-αppli folder list display (P.235).
Press to select an item in the guide display (P.33).

Ͳ

Press to place or receive a videophone call (P.52, 66).
In the stand-by display, press to display the Channel
list display (P.198) and press for over a second to
activate the MUSIC Player (P.341).
Press to select an item in the guide display (P.33).

ͳ

Press to cancel the current operation.
In the i-αppli stand-by display, press to operate the
software (P.243).
In the stand-by display, press for over a second to turn
off the notification icon (P.32).

ʹ

Press to power on/off the FOMA terminal (P.43).
Press to hang up or end the multitask functions.
Press while receiving a voice or videophone call to put
a call on hold (P.68).

͵

In the stand-by display, press for over a second to set/
cancel the Public mode (Drive mode) (P.69).

Ͷ

Microphone

Picks up the sound of your voice. Do not cover it with
your hand.

ͷ

Back Cover

͸

FeliCa Mark

Indication for a built-in IC card.
Hold this mark to the reading device to use the Osaifu­Keitai. You can send and receive data by placing the
FeliCa mark of the FOMA terminal over that of another
FOMA terminal provided with the iC communication
function. You cannot remove the IC card (P.251, 328).

͹

Photo Light/Flash

Turn on/emit light when recording with the Out-camera
(P.170).

ͺ

Out-Camera

Use to record a still image or movie (P.155, 167) or send
the surrounding image during a videophone call (P.50).

ͻ

FOMA Antenna

The antenna is incorporated in the main body. To talk
on the phone with better condition, do not cover the
antenna with your hands.

(P.28)

i-mode/i-αppli Key

i-Channel Key

Clear Key

Power/End/Hold Key

#/Public Mode (Drive Mode) Key

(P.39)

ͼ

Lens Cover

In the stand-by display or the menu display, open to
activate the Camera mode.
During the Camera mode, close to end the Camera
mode (P.150).

ͽ

Auto Timer Indicator

Lights during the Camera mode. Flashes while
recording or activating the Auto timer (P.150, 169).

;

Speaker

Sounds including the ring tone are heard from here.

Ϳ

Manner/ Key

In the stand-by display, press to display the Manner
mode display (P.116) and press for over a second to
set/cancel the Manner mode (P.115).
Press to scroll a page to the previous display.

΀

Memo/ Key

In the stand-by display, press to display the Record
msg display (P.73) and press for over a second to set/
cancel the Record message (P.72).
Press to scroll a page to the next display.

΁

Play Key

In the stand-by display, press for over a second to
display/play back a still image or movie (P.296, 297).

΂

Shutter Key

Press to record using the camera (P.155, 167).
Press halfway down to perform the Auto Focus when
you are recording a still image (P.155).

΃

Charge Terminal Pins

΄

microSD Memory Card Slot

Insert a microSD memory card here (P.303). Do not
pull the cover forcibly.

΅

External Connection Terminal

Connect the AC adapter (optional), FOMA USB Cable
with Charge Function 01 (optional), etc. (P.41, 311). Do
not pull the cover forcibly.

Ά

Earphone/Microphone Jack

Connect the Flat-plug Earphone/Microphone with
Switch (optional), etc. Other traditional Earphone/
Microphone with Switch (optional) is also available
by connecting it through the Earphone Plug Adapter
(optional). Do not pull the cover forcibly (P.370).

·

Lock Key

Slide to lock the keypad or cancel the lock (P.140).

Έ

PushTalk Key

Press to originate or receive a PushTalk call (P.82, 84).
In the stand-by display, press to display the PushTalk
phonebook (P.85).

Ή

Brightness Sensor

Adjust the display light brightness and set ON/OFF
of the keypad light automatically to adapt for the
surrounding brightness (P.121).

Ί

Infrared Data Port

When you perform infrared communication (P.323) or
use the FOMA terminal as a remote control (P.327),
point this port to the target device or equipment.

΋

Strap Attachment

Attach the strap here.

(P.41)

Continued

Before Using the Handset

27

+JOG (Plus JOG)

Before Using the Handset

Left
arrow keyUparrow key

Down arrow
key

JOG

Right
arrow key

Operation

Up arrow
key

Down
arrow key

Left arrow
key

Right arrow
key

JOG

Symbols in

this manual

Description

Move the cursor upward. Press for
over a second to move the cursor
continuously.
Press in the stand-by display to display
the Data Box.
Move the cursor downward. Press
for over a second to move the cursor
continuously.
Press in the stand-by display to display
the Phonebook.
Move the cursor to the left. Press for
over a second to move the cursor
continuously.
Or, press to return to the previous
display.
Press in the stand-by display to display
the Received record.
Move the cursor to the right. Press
for over a second to move the cursor
continuously.
Or, press to go to the next display.
Press in the stand-by display to display
the Redial record.
Set a selected item.
When you scroll it upward and
downward, the cursor moves upward
and downward.
If you keep scrolling it, the cursor keeps
moving.
In the stand-by display, when you
scroll it upward, the Data Box appears,
and when you scroll it downward, the
Phonebook appears.
You can set the action of it in the
matching words list while entering
words (P.381).

For the operations in the horizontal orientation, the 4-way keys are written according to the key

●

positions in the horizontal orientation of the FOMA terminal. The normal operations of
become

, operations for become . Also, the scrolling directions of the JOG

upward and downward in the normal operations become to the left and right.

You can set the scrolling amount of the JOG and functions to be activated when the JOG is

●

scrolled in the stand-by display, and also preset the JOG to be disabled (P.372).

28

Opening/Closing the FOMA Terminal

When you open/close the FOMA terminal, hold the FOMA terminal in your hand.
To open the FOMA terminal, slide the front surface of the display side upward. To
close it, slide the front surface of the display side downward.

When you open the FOMA terminal, be careful not to touch the keypad. Failure to do so may

●

cause malfunction.

About the Style

You can use the FOMA terminal in the vertical orientation or horizontal orientation
tilted with an angle of 90 degrees.

Vertical orientation

■

Horizontal orientation

■

Before Using the Handset

Normally use the FOMA terminal in the
vertical orientation.

To record by the camera, use the FOMA terminal
in the horizontal orientation. Some functions can
also be used in the horizontal orientation.

The following functions can be used in

ˎ

the horizontal orientation.

- Shoot by photo (P.155)

- Movie shoot (P.167)

- Full Browser (P.277)

- Display an image (P.296)

- Play back a movie (P.297)

- Music slide show (P.287)

29

Using the Displays

For details on the icons in the Camera mode, see P.154.

ˎ

Before Using the Handset

The position of the clock in the display can be changed (P.118).

ˎ

〜ʹ
͵〜;

Clock (P.44, 118)

30































Ｍｉｓｓｅｄ ｃａｌｌ

 →  最高１０℃  

Ϳ

/ / / Radio wave condition

(Strong  Weak)

/ During i-mode (P.183)/During i-mode

communication

/

During packet communication/While sending/

receiving packet communication data
Full Browser activating
During Full Browser (P.276)
During Full Browser communication
Full Browser activating (PC mode)
During Full Browser (PC mode)

During Full Browser communication (PC mode)

(During Full Browser communication, the icon

becomes animation.)

Outside of the service area
Self mode is set (P.137)
A card other than the UIM is inserted

While using the infrared communication function

(P.325)/During iC communication (P.328)

While the infrared remote control is

being used (P.327)

While an SSL site is displayed (P.183)/While

i-αppli software downloaded from an SSL

site is running (P.236)/While the software

update is using SSL communication (P.455)

/ /

Unread i-mode mail (P.210)/Unread SMS

(P.231)/Unread i-mode mail and unread SMS

１

１０

Notification display (P.32)

i-Channel Telop text (P.199)

Guide display (P.33)

 / /


 /















The FOMA terminal is full of received i-mode
mail and SMS/The UIM is full of SMS/The
FOMA terminal is full of received i-mode
mail and SMS and the UIM is full of SMS
Mail at the i-mode center/The i-mode center is full

Unread Area Mail (P.229)

/ Unread Message R/F (P.226)/The

FOMA terminal is full of Message R/F.

/ Message R/F at the i-mode center/

The i-mode center is full

/

Unread Message R (P.226), the FOMA
terminal is full of Message F/Unread
Message R, Message F at the i-mode center

/

Unread Message R (P.226), the
i-mode center is full of Message F/The
FOMA terminal is full of Message R,
the i-mode center is full of Message F

/

Unread Message F (P.226), the FOMA
terminal is full of Message R/Unread
Message F, Message R at the i-mode center

/ Unread Message F (P.226), the

i-mode center is full of Message R/
The FOMA terminal is full of Message
R, Message F at the i-mode center

/ Message R at the i-mode center, the

FOMA terminal is full of Message F/
Message R at the i-mode center, the
i-mode center is full of Message F

/















 /i-α











Ͱ




ͱ






Ͳ





ͳ
ʹ

͵




The i-mode center is full of Message R,

Message F at the i-mode center/The

i-mode center is full of Message R, the

FOMA terminal is full of Message F

While providing location information

by GPS/While accepting to provide

location information during the period

of accepting the location request

While rejecting to provide location information

during the period of accepting the location request

During GPS positioning

(Blue)/ (Red)

While connecting to the 3G network (Packet

communication: able)/While connecting to the

3G network (Packet communication: disable)

/

While connecting to the GSM network/

While connecting to the GPRS network

/

While running i-αppli (i-αppli stand-by

display)/While running i-αppli DX

ppli stand-by display is set/i-αppli

DX stand-by display is set (P.243)
The USB mode setting is set to

Communication mode (P.311)
The USB mode setting is set to

microSD mode (P.311)

/

/ /

The USB mode setting is set to MTP

mode: Connecting/Transferring/

Transfer completed/Error (P.311)

While using a hands-free device (P.65)
Secret display is [ON] (P.141)

While the microSD memory card is inserted (P.303)

(Flashes during preparation for access after

insertion of the microSD memory card)

While the microSD memory card management

information is being updated (P.310)

During a voice call
During a videophone call (P.50)

During PushTalk communication (P.80)

While using PushTalkPlus (P.89)
During 64K data communication

/ /

1/2/3 or more tasks are being executed

(P.349) (

is in progress on the MUSIC Player)

changes to while playback

While data in the MUSIC Player is being updated

/ / / Battery level (P.42)

Current time (Displayed in 24-hour

format in other than the stand-by display)

When the Clock is set to [Pict clock], the clock

ˎ

is displayed in the stand-by display (P.118).

Ͷ




ͷ




͸
͹




ͺ
ͻ

ͼ




ͽ














;














The vibrator is set for incoming calls (P.110)

The vibrator is set for incoming mail (P.110)

The vibrator is set for incoming calls

and mail (P.110)

The FOMA terminal’s display is manufactured based on the leading edge technologies, and

●

Ϳ

Incoming call ring volume is OFF (P.109)
Incoming mail ring volume is OFF (P.109)

Incoming call and mail ring volumes

are OFF (P.109)
Manner mode is set ( is pink) (P.115)

Silent mode is set (P.115)

Original manner mode is set ( is
blue) (P.115)

Public mode (Drive mode) is set (P.69)

Personal data lock is set (P.138)
Key dial lock is set (P.139)
Personal data lock and Key dial lock

are set (P.138, 139)
IC card lock is set (P.258)
During Music&Video Channel

reservation (P.335)
Alarm is set (P.356)

Schedule alarm is set (P.360)

Alarm and Schedule alarm are set (P.358, 360)
/

Record message is set ( is white) (P.72)

There are non-played back record

messages (

There is no non-played back record

message (

/

Record message is OFF

is light blue)

is blue)

(There are record messages) ( is gray)

There are non-played back record

messages (

There is no non-played back record

message (

The number of recorded messages is

displayed at

messages becomes full, “
/

Videophone message is set ( is green) (P.72)

There are non-played back videophone

messages (

There is no non-played back

videophone message (

/

Videophone message is OFF

is light blue)

is blue)

. When the number of recorded

” appears.

is light blue)

is blue)

(There are videophone messages) ( is gray)

There are non-played back videophone

messages (

There is no non-played back

videophone message (

The number of recorded videophone

messages is displayed at

the number of recorded videophone

messages becomes full, “

is light blue)

is blue)

Lock key is set (P.140)

some pixels unlit or lit may appear constantly in the display. This is not a malfunction.

Continued

Before Using the Handset

. When

” appears.

31

Notification Display

An icon is displayed in the notification display to alert you, for example, when you

Before Using the Handset

cannot answer a call. The icon is displayed from the left in the order of the latest event.
Move the cursor to the icon to display the text information and select the icon to
check the notification information. The icon is turned off by checking the notification
information or pressing for over a second.

Icon Text information Description

Missed call X

New mail X
Mail at center Mail is held at the i-mode center (P.211).
New MessageR X Message R is received (P.226).
New MessageF X Message F is received (P.226).
New ToruCa X A ToruCa card is obtained from a reading device (P.252).
New Record msg A record message is recorded (P.72).
New V.phone msg A videophone message is recorded (P.72).

3

※

Exceed cost limit The total cost has exceeded the upper limit (P.367).
Voice Mail X

USB cable cncted The FOMA USB Cable with Charge Function 01 (optional), etc.

PB update failed The Phonebook auto-update at the Data Security Service Center

Stand-by SW error i-αppli stand-by display security error has occurred (P.243).
Download completed Downloading the Music&Video Channel is completed (P.335).
Download failed Downloading the Music&Video Channel is failed (P.335).
Answer X Location information is requested (P.266).
Update complete The software update is completed (P.456).
Check for update There is confirmation of a software update (P.456).
Update notification The software update is necessary (P.454).
Update schedule Downloading the software is complete. Overwrite the software

Update completed The pattern definition auto-update was completed successfully

3

※

Update definitions The pattern definition auto-update was failed. The update is still

3

※

SW not terminated There is an active function (excluding the i-αppli stand-by

3

※

1 When 2in1 is set to the Dual mode, the number of data is displayed separately for Number

※

A/Number B.

2 When 2in1 is set to the Dual mode, the total number of mail sent to Address A and Address B

※

is displayed.

3 Even when you press

※

1

※

2

※

1

※

There is a missed call of a voice, videophone, or PushTalk call,
or 64K data communication (P.71).
i-mode mail/SMS is received (P.210, 231).

A record message is saved at the Voice Mail Service Center
(P.388).

is being connected (P.311).

has failed (P.105).

with new one (P.454).

(P.460).

required (P.460).

display) (P.349).

for over a second, the icon is not turned off.

32

Guide Display

To utilize the FOMA terminal’s functions, use the 4-way keys (Up/Down/Left/Right
arrow keys), the JOG, the Mail key, the i-mode/i-αppli key, the MENU key, and the
i-Channel key according to the instructions shown in the guide display.

Display Operation Display Operation

ＭＥＮＵ

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

ｉ．ｃｈ

Press .

ＭＥＮＵ

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

ｉ．ｃｈ

Press .

Before Using the Handset

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

ＭＥＮＵ

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

ＭＥＮＵ

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

ＭＥＮＵ

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

ＭＥＮＵ

The guide display does not appear in the stand-by display at the time of purchase. To

●

Press or scroll

ｉ．ｃｈ

Press or scroll

ｉ．ｃｈ

Press .

ｉ．ｃｈ

Press .

ｉ．ｃｈ

up.

down.

ＭＥＮＵ

ＭＥＮＵ

ＭＥＮＵ

ｉ−ｍｏｄｅＭａｉｌ

Ｌｉｎｋ

Ｌｉｎｋ

Ｌｉｎｋ

ｉ．ｃｈ

ｉ−ｍｏｄｅＭａｉｌ

ｉ．ｃｈ

ｉ−ｍｏｄｅＭａｉｌ

ｉ．ｃｈ

Press .

Press .

Press .

display it, set the Soft key to [ON] (P.117).

The display may differ from the above depending on websites and i-αppli software.

●

Selecting the Menu

Press (MENU) to display the Menu display. You can select the menu display from
[Kisekae menu]/[Standard menu]/[My Selection].

The Kisekae menu is displayed at the time of purchase.

ˎ

You can change the menu when you start or settings of icons for the Standard menu, and you

ˎ

can switch the Kisekae menus (P.122, 125).

Ｃｈｇ．ＭＥＮＵ

Ｓｅｌｅｃｔ

ＴＡＳＫ Ｋｉｓｅｋａｅ

Main body color: SILVER Main body color: WHITE Main body color: PINK

Continued

33

Kisekae menu

Menu name Description

My Selection Used to access My Selection.

Before Using the Handset

Imaging Used to access Camera, Movie, easy BlogUp, Music slide show, and

i-mode Used to access an i-mode function.
Mail Used to access an i-mode mail and SMS functions.
iαppli Used to access an i-αppli function.
Phone Used to access mainly related to Phone such as Phonebook, Call

Data Box Used to access data such as those saved in My picture, MUSIC,

MUSIC Used to access MUSIC player and Music&Video Channel functions.
Osaifu-Keitai Used to access IC card content, DCMX, and ToruCa functions.
Own number Used to display the own phone number.
LifeKit Used to access functions such as Bar code reader, Receive Ir data,

Settings Used to set items such as Display, Call, Application, Lock/Security,

You can turn on/off the Standard menu guide by pressing (Help ON)/ (Help OFF).

●

Functions displayed in gray are not available.

●

When another function is activated or the FOMA terminal is connected to a PC while the USB

●

mode setting is set to [MTP mode], the Standard menu is displayed by pressing

The Kisekae menu at the time of purchase varies depending on the color of the FOMA

●

terminal and the displayed menu changes based on the Kisekae Tool. The descriptions of
this manual are written based on the Kisekae menu (White Scrapbook) of the main body
color: WHITE and the Color theme setting (White & Gold).

For the list of menus in the Standard menu, see P.416.

●

Stand-by pictures.

record, PushTalk phonebook, and Record message.

Music&Video Channel, i-motion, Melody, My document, Kisekae Tool,
and Chara-den.

microSD, Camera, Movie, Lifetime Calendar, Alarm, Schedule, Text
Memo, Calculator, Data Security Service, and GPS.

and Management.

.

Selecting a Function from the Menu Display

A function can be executed easily by going through the menus.

1

Press (MENU).

The menu display appears.

2

Use to select a menu and press .

The function associated to the menu is selected.

You can execute a function in the menu display by pressing a key on the keypad. For the

●

functions that can be executed using a number key, see the list of menus (P.416).

34

Selecting a Function from the Function Menu

Ｆｕｎｃ Ｃｒｅａｔｅ

Ｓｅｌｅｃｔ

Ｔｅｘｔ Ｍｅｍｏ ｌｉｓｔ

１／４

Ｂｏｏｋ ａｉｒｌｉｎｅ ｔｉｃｋｅｔ

Ｍｉｌｋ ａｎｄ ｓｕｇａｒ 
０９０ＸＸＸＸＸＸＸＸ
１２３４５

The Function menu is a menu that plays an auxiliary role for each function.
Whenever the Function menu is available, [Func] appears in the guide display. Press

to display a list of available Function menus.

The contents of the Function menu vary depending on the functions and displays. For details,

ˎ

see the description of operation for the individual option.

When the numbers and symbols are displayed in the Function menu, press a key on the

ˎ

keypad to activate a function.

Ｅｄｉｔ

Ｄｅｌｅｔｅ
Ｃｏｐｙ Ｔｅｘｔ ｍｅｍｏ

Ｓａｖｅ ｔｏ ｍｉｃｒｏＳＤ

(Func) +

ＭＥＮＵ

Function menus displayed in gray are not available.

●

Ｓｅｎｄ Ｉｒ ｄａｔａ
ｉＣ ｔｒａｎｓｍｉｓｓｉｏｎ

Ｃｌｏｓｅ

Ｓｅｌｅｃｔ

ＭＥＮＵ

Ｅｄｉｔ

Ｄｅｌｅｔｅ

Ｄｅｌｅｔｅ ｏｎｅ

Ｃｏｐｙ Ｔｅｘｔ ｍｅｍｏ

Ｓｅｌｅｃｔ＆ｄｅｌｅｔｅ

Ｓａｖｅ ｔｏ ｍｉｃｒｏＳＤ

Ｄｅｌｅｔｅ ａｌｌ
Ｓｅｎｄ Ｉｒ ｄａｔａ
ｉＣ ｔｒａｎｓｍｉｓｓｉｏｎ

Ｃｌｏｓｅ

Ｓｅｌｅｃｔ

ＭＥＮＵ

Switching the Menu Display

You can switch the menu (Kisekae menu, Standard menu, and My Selection) to be
displayed temporarily.

At the time of purchase, the activated menu when you press

ˎ

Kisekae menu. To change the activated menu, display the menu to be changed and press
(Chg.MENU) for over a second.

1

Press (MENU) in the stand-by display and press (Chg.MENU).

Kisekae menu Standard menu My Selection

in the stand-by display is the

Before Using the Handset

(Chg.MENU) (Chg.MENU)

Ｃｈｇ．ＭＥＮＵ

Ｓｅｌｅｃｔ

ＴＡＳＫ Ｋｉｓｅｋａｅ

Ｃｈｇ．ＭＥＮＵ

ＴＡＳＫ

Ｓｅｌｅｃｔ

Ｈｅｌｐ ＯＮ

Ｃｈｇ．ＭＥＮＵ

Ｓｅｌｅｃｔ

ＴＡＳＫ Ｄｅｌｅｔｅ

(Chg.MENU)

When you use the Kisekae tool to change the design of the menu display, some menu types

●

may change the menu structure depending on the frequency in use. The digits assigned to
menu items may not be applied.
In this case, you cannot operate the FOMA terminal as explained in this manual, so please



change the menu to the Standard menu or reset the menu settings (P.124).

Ｅｘｃｈａｎｇｅ

35

Using the UIM

The UIM (FOMA card) records user information such as your phone number. Insert a

Before Using the Handset

UIM in the FOMA terminal to use it.

Inserting/Removing the UIM

When inserting/removing the UIM (FOMA card), make sure to power off and close the
FOMA terminal, remove the battery pack, and perform the operation with the FOMA
terminal held with your hand.

If you insert the UIM forcibly, it may be damaged.

ˎ

Inserting the UIM

■

1

Pull the tab and then pull
out the tray.

Pull out the tray until it stops.

Tab

Removing the UIM

■

1

Pull the tab and then pull out the tray.

2

Lift up the UIM with your finger to take it out.

When you remove the UIM from the tray, be careful not to damage the terminal of the battery

●

pack.

Make sure to keep a removed UIM safely.

●

2

Place the UIM on the tray
with the IC side facing
up.

Align the notches of the tray
and UIM.

Notch

3

Push the tray until it
stops.

About the UIM Security Code

You can set two Security codes, namely “PIN1” and “PIN2”, for the UIM (FOMA card).
These codes are set to “0000” at the time of subscription. You can change them to
any 4- to 8-digit number you want (P.133).

36

About the Function for Restricting UIM Operation

The FOMA terminal provides a function for restricting UIM (FOMA card) operation in
order to protect your data and files. If you record a videophone message or download
files or data from sites or mail while the UIM is inserted in the FOMA terminal, the UIM
operation restriction function is automatically set for these data and files.

When you replace the UIM with another one or if you do not have a UIM inserted in the FOMA

ˎ

terminal, you are unable to display or play back the data or files for which the UIM operation
restriction function is set or if they are sent using the infrared or iC communication or attached
to mail.

The target data for operation restriction is as follows:

ˎ

- Image (including GIF animation, Flash, and Stamp&Frame) - Deco-mail pictograph

- Image downloaded from the Data Security Service Center - Movie/i-motion

- Downloaded Kisekae tool - Chara-den

- Chaku-Uta

- File attached to i-mode mail (excluding a ToruCa card) - Melody

- Message R/F attached file (melody/image) - PDF data

- Mail template (including target data for restriction) - Videophone message

- Image inserted in Deco-mail or a signature -

- i-αppli (including i-αppli stand-by display) - Downloaded dictionary

- Screen Memo (including target data for restriction)

- Image trimmed from PDF data (downloaded PDF data only)

“

” appears for the data with UIM operation restriction. Depending on the data, “ ” may not

ˎ

appear and a message may appear instead when you select the data.

“Chaku-Uta” is a registered trademark of Sony Music Entertainment Corporation.

ˎ

If you replace the UIM with another one or use the FOMA terminal without inserting a UIM

●

when data targeted by the UIM operation restriction function is set for the stand-by display,
call image, and ring tone, then the sound and image settings are reset to the default
settings. In this case, the sound and image you have set and the actual sound and image
may be different.

You cannot set the UIM operation restriction function for data received using the infrared or

●

iC communication, the microSD memory card, or DoCoMo keitai datalink or images recorded
with the built-in camera.

If you use the UIM on another i-Channel-compatible terminal, the Telop text does not appear.

●

When the information is automatically updated or if you press
information, the Telop text starts running automatically.

®

/Chaku-Uta Full® -

Image inserted in a ToruCa(detail) card

Movable contents-compatible data

(i.ch) to receive latest

Before Using the Handset

Settings Saved in the UIM

The following settings are saved in the UIM (FOMA card). If you replace the UIM with
another one, the settings in the new UIM come into effect.

- Select language - SSL certificate - SMS setting - UIM setting

Continued

37

About the Differences in UIM Functions

A UIM (FOMA card) (blue) has the following functional differences from a UIM (green/

Before Using the Handset

white).

Item UIM (blue)

Number of digits that can be saved for a phone
number in the UIM phonebook
User certificate operation for using FirstPass Unavailable Available P.195
Use of WORLD WING service Unavailable Available P.38
Service Numbers (Use of [
(Contact for Repairs) and [
(General Inquiries))

ドコモ故障問合せ

ドコモ総合案内・受付

Maximum

20 digits

]

Unavailable Available P.392

]

WORLD WING

WORLD WING is the DoCoMo’s FOMA international roaming service that enables you to place
or receive a call using the same mobile phone number even if you are overseas, just by using
the UIM (green/white) and a WORLD WING service-compatible FOMA terminal.

If you subscribed to the FOMA services after September 1, 2005, you already have WORLD

※

WING and no application is required. If you declined to use WORLD WING when you
subscribed to the FOMA services or cancel the WORLD WING service halfway, you need to
make an application again to use WORLD WING.

If you subscribed to the FOMA services before August 31, 2005 and did not make an

※

application to “WORLD WING”, you need to make a separate application.

This service is not available in some service charge plans.

ˎ

If you should lose your UIM (green/white) or have it stolen abroad, please report it to

ˎ

DoCoMo and take steps to cancel the use of the UIM as soon as possible. For information
on where to call, see “General Inquiries” on the backcover of this manual. Note that you are
still liable for the call and communication charge incurred after the loss or theft occurred.

UIM (green/

white)

Maximum

26 digits

Page

P.98

38

Attaching and Removing the Battery Pack

When attaching/removing the battery pack, make sure to power off and close the
FOMA terminal.

If you attach the battery pack forcibly, the terminal on the FOMA terminal may be damaged.

ˎ

Holding too hard or attaching/removing the back cover in a manner other than described below

ˎ

may damage it.

Attaching the battery pack

■

1

Slide to remove the back
cover in the direction of
the arrow while pressing
it at the dent portion
with your finger.

Dent portion

3

Align the back cover with the
grooves on the FOMA terminal
while holding it almost closed
(about 3 mm clearance) and slide
it in the direction of the arrow.

2

Hold the battery pack with the
recycle-mark side up, align the
terminal of the battery pack
with that of the FOMA terminal,
and push it into place.

Terminal

Removing the battery pack

■

1

Slide to remove the back
cover in the direction of the
arrow while pressing it at the
dent portion with your finger.

Dent portion

2

Raise to remove the
battery pack in the
direction of the arrow by
holding it by the tab.

Tab

Battery Pack

To make full use of the FOMA terminal, make sure to use the Battery Pack SO02.

Life of the battery pack

■

The battery pack is a consumable part. The usage duration of the battery per one charge
decreases gradually each time the battery is recharged. When the usage duration per one
charge becomes about half that of a new battery pack, the life of the battery pack is assumed
to be almost over. It is recommended that you replace the battery pack ahead of time.
Depending on the usage condition, the battery pack may be inflated as it comes to the end of
its life. This is not a malfunction.
If you continue using i-αppli or talking on the videophone for a long period of time with the
battery being charged, the life of the battery pack may become shorter.

Before Using the Handset

Return all spent battery packs to NTT DoCoMo or a dealer, or a recycling
shop to protect the environment.

Li-ion

39

Charging the FOMA Terminal

At the time of purchase, the battery pack is not fully charged. Make sure to fully

Before Using the Handset

charge the battery pack before using the FOMA terminal for the first time.

About Charging the FOMA Terminal

For details, see the user’s manual of the FOMA AC Adapter 01/02 (optional), FOMA AC Adapter

ˎ

01 for Global use (optional), or FOMA DC Adapter 01/02 (optional).

The FOMA AC Adapter 01 is only compatible with AC 100 V. The FOMA AC Adapter 02 and

ˎ

FOMA AC Adapter 01 for Global use are compatible with AC 100 V to AC 240 V.

The shape of the AC adapter’s power plug is only for use with AC 100 V (domestic

ˎ

specification). For using the AC adapter which is compatible with AC 100 V to AC 240 V
overseas, a plug adapter that fits the electrical outlets in the country you stay is needed. Do not
use an electrical transformer for overseas use to charge the FOMA terminal.
Make sure to attach the battery pack in the FOMA terminal before connecting it to the optional AC Adapter,

ˎ

Desktop Holder, or DC Adapter. If the battery pack is not attached, the FOMA terminal cannot be charged.
If you use a function such as videophone, data communication, and i-

ˎ

charging may stop because of high temperature of the FOMA terminal. The charging may not even start if the
FOMA terminal is in high temperature. Wait until the temperature of the FOMA terminal falls and restart charging.

If the charge indicator of the FOMA terminal flashes in red, wait until the temperature of the

ˎ

FOMA terminal falls or remove the battery pack and attach it back again.
If it continues to flash in red, the battery pack may be defective. Stop charging immediately



and contact our service counter (DoCoMo shop, etc.).

Do not charge the battery pack for a long period of time (more than 24 hours) with the FOMA

ˎ

terminal powered on. If the FOMA terminal is powered on when charging is completed, the
battery level decreases. This causes the FOMA terminal to restart charging. If you remove the
FOMA terminal while it is recharging, the following conditions may occur.

- The battery level is low. - The battery alarm sounds. - The operation time is short.

Estimated charging time/Battery time

■

Charging time

(AC adapter)

ab. 140m FOMA/3G 3G Moving state : ab. 380h Voice call : ab. 220m

The charging time is an estimated time for charging when the battery pack is empty and the FOMA terminal

ˎ

is powered off. When charging with the FOMA terminal powered on, the charging time becomes longer.
The continuous call time is an estimated time for a call when the FOMA terminal can send/receive radio waves properly.

ˎ

The continuous stand-by time is an estimated battery time available on the FOMA terminal when

ˎ

it is closed and can receive radio waves properly. The continuous stand-by time during the
stationary state indicates the average battery time available on the FOMA terminal that is placed
stationary when it is closed and can receive radio waves properly. The continuous stand-by time
during the moving state indicates the average battery time available on the FOMA terminal that
is placed in mixture of the following states: “stationary”, “moving”, and “outside of the service
area” when it is closed and within an area where it can receive radio waves properly.

Note that the call (communication) time and stand-by time may be reduced to about half of the time indicated

ˎ

above depending on the operating environment such as the charge level of the battery, how functions are set,
and temperature, and radio wave condition in the area where a call is placed (outside of the service area or area
with weak radio wave condition). Similarly, the call (communication) time and stand-by time become shorter than
the above when you use i-mode communication. Besides calls and i-mode communication, the battery time is
also reduced when you are composing i-mode mail, starting a downloaded i-αppli or i-αppli stand-by display,
performing data communication, executing multiaccess, using the camera, and using the MUSIC Player.

Network

GSM Auto Stationary state : ab. 520h Voice call : ab. 220m

3G/GSM

setting

Auto Moving state : ab. 380h

Continuous stand-by time Continuous call time

Stationary state : ab. 520h

40

ppli while charging the battery, the

α

(ab.: about, h: hour, m: minute)

Videophone call : ab. 120m

How to Charge the FOMA Terminal

Charge the battery pack using the optional Desktop Holder SO08 with the FOMA AC
Adapter 01/02 connected. Make sure to see the user’s manuals of the Desktop Holder
and AC Adapter. The battery pack cannot be charged alone.

1

Insert the connector of the AC adapter
horizontally with the engraved side facing
outside into the terminal (the side labeled
“AC

2

Lift the power plug of the AC adapter and
plug it into an AC 100 V outlet.

3

Insert the FOMA terminal, which has the
battery pack attached, to the desktop
holder and push it into place.

Charging starts and the red charge indicator is
turned on. The indicator is turned off when charging
is completed.

When you charge while the FOMA terminal is
powered on

The battery level icon flashes and the Charge
sound is heard. When charging is completed,
the icon changes from flashing to lighting and
the Charge sound is heard.

You can set to mute the Charge sound with the

ˎ

4

When the charging is completed, lift to
remove the FOMA terminal while holding
the desktop holder.

5

Remove the power plug of the AC adapter
from the AC 100 V outlet.

Charging with the AC adapter only

■

To remove the AC adapter, make sure to

ˎ

pull it horizontally while holding the release
buttons pressed. Pulling it forcibly may cause
malfunction.

”) of the desktop holder.

アダプタ

Set basic tone (P.111).

Open the
terminal cover.

■

Insert the connector horizontally
with the engraved side facing up.

Release buttons

1

Terminal

Insert the connector

AC adapter

horizontally with
the engraved side
facing outside.

Charge indicator

AC adapter

2

5

3

4

Charging with the DC adapter

With the optional FOMA DC Adapter 01/02,
you can charge the battery pack by using
the cigarette lighter socket of a vehicle
(12 V/24 V). For details, see the user’s
manual of the DC adapter.

Insert the connector horizontally
with the engraved side facing up.

Open the
terminal cover.

Power
indicator

Plug

Connector

Before Using the Handset

Charge indicator

Continued

41

During iC communication or when the FOMA terminal comes within the communication

●

range with the reading device while charging the battery, the Charge indicator and FeliCa

Before Using the Handset

Sign light at the same time.

When not using the AC adapter for a long period of time, remove its power plug from the AC

●

outlet.

Make sure that the phone strap, etc. does not get caught in between the FOMA terminal and

●

the desktop holder.

The fuse (2.0 A) of the DC adapter is a consumable part. Purchase an equivalent fuse from

●

an automobile parts store when it is necessary to replace the fuse.

Checking the Battery Level

<Battery level>

The estimated battery level is indicated in the display.

Display Charge level

Sufficiently charged.
Slightly low.
Very low. Charge.

(Flashes)

When the battery level becomes nearly 0, the screen

●

shown to the right appears and warning sound is heard.
The sound may be suppressed by other sound, etc.
in operation. It is heard again when the battery level is

The battery level is 0. Charge.

Ｆｉｎｉｓｈ ｏｐｅｒａｔｉｏｎ
ａｎｄ ｃｈａｒｇｅ
ｂａｔｔｅｒｙ

    Ｃｈａｒｇｅ ｂａｔｔｅｒｙ

0 and the function you are performing is terminated.
During a call, the warning sound is heard from the
earpiece and the call is terminated when another
warning sound is heard after about 20 seconds. If
you do not charge the battery, the FOMA terminal is
automatically powered off after about 60 seconds.

Checking the Battery Level with the Sound and Display

The confirmation beep does not sound when the volume of the keypad sound is [OFF] (P.111).

ˎ

1

From the Menu, select [Settings] → [Management] → [Battery level] and
press .

The current battery level is displayed using bars in the display and the confirmation beep
sounds according to the remaining battery level.

Ｂａｔｔｅｒｙ ｌｅｖｅｌ Ｂａｔｔｅｒｙ ｌｅｖｅｌ Ｂａｔｔｅｒｙ ｌｅｖｅｌ Ｂａｔｔｅｒｙ ｌｅｖｅｌ

Sufficiently charged. Slightly low. Very low. Battery level 0.
(three beeps) (two beeps) Charge. (one beep) Charge. (no beeps)

42

Powering On/Off

When you power on the FOMA terminal, the screen informing to execute the software update

ˎ

automatically may appear (P.452).

1

Press (PWR) for over two seconds.

<Power on/off>

The FOMA terminal is powered on, the display and the keypad lights
are turned on, and an animation is displayed. After a while, the stand-by
display appears.

If you have set the PIN1 code setting to [ON], the PIN1 code input

ˎ

screen appears. Enter the PIN1 code and press

(OK) (P.131).

To power off

Press (PWR) for over two seconds.

If you replace the UIM with another one (except when the Omakase Lock is set), you need to

●

enter a 4- to 8-digit Security code when the FOMA terminal is powered on. When the entered
code is correct, the stand-by display appears. If you enter a wrong Security code five times
consecutively, the FOMA terminal is powered off. (You can still power on the FOMA terminal,
however.)

Before Using the Handset

Setting the Basic Functions

<Initial setting>

The Initial setting can be used to make basic settings such as the Date/time and
Security code. See the respective pages for details about the settings.

Available setting items

■

Item Description

Date/time Set the date and time of the FOMA terminal (P.44).
Change code Change the Security code (P.132).
Keypad sound Set the volume of the tone to sound when you press the key (P.111).
Location request Set whether to provide positioning information (P.267).
All font size setting Set the size of fonts to be used for displaying the Phonebook, Call record,

Mail, i-mode sites, and Input text display (P.127).

1

From the Menu, select [Settings] → [Management] → [Initial setting] and
press .

Ｉｎｉｔｉａｌ ｓｅｔｔｉｎｇ

Ｄａｔｅ／ｔｉｍｅ

   Ｙｅｔ

Ｃｈａｎｇｅ ｃｏｄｅ
Ｋｅｙｐａｄ ｓｏｕｎｄ

１
Ｌｏｃａｔｉｏｎ ｒｅｑｕｅｓｔ
         Ｙｅｔ
Ａｌｌ ｆｏｎｔ ｓｉｚｅ ｓｅｔｔｉｎｇ
         Ｙｅｔ

2

Set each item.

If you perform the Reset all data&set or do not change the Security code of the FOMA

●

terminal or settings of the Location request or All font size setting, the message “Initial
setting is incomplete. Execute?” appears when you power on the FOMA terminal. When you
select [Yes], the display in step 1 appears and you can perform the initial setting.

43

Setting the Date and Time

You can set the date and time either by automatically correcting the time based on

Before Using the Handset

the time information obtained from the DoCoMo network or by manually setting the
time.

Example: Correcting the time automatically

1

From the Menu, select [Settings] → [Management] → [Date/time] and press

.

Ｄａｔｅ／ｔｉｍｅ

Ａｕｔｏ ｔｉｍｅ ａｄｊｕｓｔ

Ｍａｎｕａｌ ｃｌｏｃｋ ｓｅｔ

2

Select [ON] at [Auto time adjust].

[ON] :

Correct the date and time automatically.

[OFF] :

Do not correct the date and time automatically. Set the time using the Manual clock

set.

To set the time manually

Select [Manual clock set] → [Yes] and enter the year and date within the range from
2000/01/01 to 2050/12/31, the time in 24-hour format (00:00 to 23:59), and select time
zone. Press

When you set the Auto time adjust to [ON], the date and time are corrected automatically

●

when the FOMA terminal is powered on with a UIM installed. Note, however, that there may
be an error lasting several seconds. The time cannot be automatically corrected in the
following cases.

- Outside of the service area (The time may not be corrected automatically even inside the
service area depending on the radio wave condition.)

- While i-αppli is running

The date and time settings are retained even when you replace the battery pack. However,

●

if you leave the FOMA terminal without a battery pack or with a fully expended battery pack,
the date and time may be reset to “----/--/-- --- --:--”. In this case, set the date and time once
again.

If the date and time are not set, functions that use the clock, such as the current time icon,

●

Schedule, Alarm, i-αppli Auto-start, and calendar/clock display cannot be used. The date
and time for the Redial/Received record and the date and time on images shot with the
camera are also not recorded.

When you receive time correction information from the network of the carrier to which the

●

FOMA terminal is connected during international roaming, the time is automatically corrected
when the Auto time adjust is set to [ON].
When the time is corrected to the local time, the date and time used for the Redial/Received



record and sent/received mail also are corrected to the local time and “
however, that some overseas networks may not perform time correction.

[Auto time adjust] :

[Manual clock set] :

 ＯＮ

(Complete).

Set the time automatically.
Enter the time manually. When you set the time

using the Manual clock set, the Auto time adjust is
set to [OFF].

” appears. Note,

<Date/time>

44

Notifying the Recipient of Your Phone Number

<Notify caller ID>

When placing a call, your phone number can be shown in the display of the
recipient’s phone you are calling.

The caller ID is important personal information. Carefully decide whether you notify a recipient

ˎ

of your caller ID.

1

From the Menu, select [Settings] → [Management] → [NW Services] → [Notify
Caller ID] → [Set Notification] and press

2

Select [Notify]/[Not notify] and press .

.

The Notify caller ID is set.

To check the setting

From the Menu, select [Settings] → [Management] → [NW Services] → [Notify Caller ID]

[Check setting].

→

The setting, whether to originate a PushTalk call with/without the caller ID, follows this setting.

●

If you hear a guidance asking to send the caller ID when you place a call, call again after

●

setting the Set Notification to [Notify] or by adding “186” before the recipient’s phone
number. The caller ID is not displayed even if you add “186” when you originate a PushTalk
call.

You cannot set the Notify Caller ID when the FOMA terminal is outside of the service area.

●

Checking Your Own Phone Number

<Own number>

Your phone number can be checked. You can also save your name, mail address,
etc.

If the Own number is saved as Secret, the data other than your phone number is not displayed.

ˎ

Set the Secret display to [ON] to display all data.

Number B does not appear on the Own number display of the B mode at the time of purchase.

ˎ

To display Number B, perform the Check service (P.47).

1

From the Menu, select [Own number] and press .

  Ｂａｓｉｃ Ｄｅｔａｉｌ

０９０ＸＸＸＸＸＸＸＸ
ｄｏｃｏｍｏ．ｔａｒｏ．
ｏ．ｎｅ．ｊｐ

 ドコモ太郎

ト゛コモタロウ
ＯＦＦ

Your phone number appears at [ ]. If the data other than a phone
number is saved, that data also appears.

＠ｄｏｃｏｍ

△△

To place a call

Press , move the cursor to a phone number, and press .

To originate a PushTalk call

Press , move the cursor to a phone number, and press .

To send i-mode mail

Press , move the cursor to a mail address, and press (Mail).

To check the image

Press , move the cursor to the image, and press (Play).

To switch the Own number display between the A and B modes when 2in1
is set to the Dual mode

Press (Number A)/ (Number B).

Before Using the Handset

Continued

45

You cannot originate a PushTalk call from the Own number display of the B mode.

●

When you replace the UIM (From 2in1 subscriber to 2in1 subscriber) while 2in1 is used, to

●

Before Using the Handset

obtain a correct Number B, you need to perform the 2in1 function OFF (P.396) first, and then
set the 2in1 to ON again.
When you replace the UIM (From 2in1 subscriber to 2in1 non-subscriber), perform the 2in1



function OFF.

When you replace the UIM while 2in1 is used, you need to reset all the items of the personal

●

data at the B mode (P.47).

Saving Your Personal Data

You can save your personal data such as your name, postal address, and mail
address, and check saved data in the Own number display and quote this data in the
text input display.

1

Press (Edit) in the Own number display.

  Ｂａｓｉｃ Ｄｅｔａｉｌ

０９０ＸＸＸＸＸＸＸＸ

  ＯＦＦ

2

Save each item at the Basic display.

Icon Settings

Enter your mail address within 50 half-width alphanumeric characters and
symbols.

Enter your name within 16 full-width or 32 half-width characters.
When entering your name, the reading is automatically entered.

To edit the reading, enter a reading within 32 half-width characters.

ˎ

Select [ON]/[OFF] of the Secret.

To display the entry saved as Secret, set the Secret display to [ON].

ˎ

46

3

Press and save each item at the Detail display.

Icon Settings

Select an image from My picture/i-motion of the Data Box or record one.

You can set the following files.

ˎ

Category File format File size Image size

My picture GIF/JPEG Max. 100K bytes Max. [QVGA(240×320)]
i-motion

※

Some i-motion may not be set.

※

It may take time to display a large-sized image.

ˎ

To use an image after recording it by the camera, select [Camera]/[Movie] (P.155,

ˎ

167).
You can record an image in the following sizes.

Still image Out-camera Max. [QVGA(240×320)]

Movie Max. [VGA(640×480)]

To specify no image, select [None].

ˎ

To check the image, move the cursor to the image and press

ˎ

Enter the postal code of your home address within seven half-width digits.
Enter the postal address of your home within 64 full-width or 128 half-width

characters.
Enter your home phone number within 26 digits.
Enter your home mail address within 50 half-width alphanumeric characters and

symbols.
Enter the name of your office within 64 full-width or 128 half-width characters.

Enter the postal code of your office address within seven half-width digits.
Enter the postal address of your office within 64 full-width or 128 half-width

characters.
Enter your office phone number within 26 digits.
Enter your office mail address within 50 half-width alphanumeric characters and

symbols.
Enter your birthday within the range from 1900/01/01 to 2050/12/31.

MP4 Max. 10M bytes Max. [VGA(640×480)]

In-camera [QCIF(176×144)]

Before Using the Handset

(Play).

4

Press (Complete).

Your personal data is saved.

To reset to the default settings

From the Function menu in the Own number display, select [Reset all] → [Yes].

To register Number B at the Own number display of the B mode

In the Own number display of the B mode, from the Function menu, select [Check service].

At [ ] your phone number is displayed and at [ ] and [ ] Additional Nos. set for the Multi

●

Number Service are displayed. These numbers cannot be edited or deleted.

At the time of purchase, your mail address does not appear. Check your mail address by

●

selecting
[Confirm Mail Address]. When you change your mail address, edit the Own number display
accordingly.

When you replace the UIM while 2in1 is used, you need to reset all the items of the personal

●

data at the B mode (P.46).

(i-mode) → [i Menu] → [English iMenu] → [Options] → [Mail Settings]

→

47

Voice/Videophone Calls

Placing Voice/Videophone Calls

■

What is Videophone?.................................................................................................. 50

Placing a Voice/Videophone Call ................................................................................ 51

Switching to/from Voice/Videophone Call ............

Using the Redial/Received Record ...............................

Setting the Chaku-moji ............................................................................

Changing the Caller ID Setting ON/OFF for an Individual Call ....................

Placing a Call by Specifying a Condition ................................................................... 60

Setting a Prefix .....................................................................................

Placing an International Call ...............................................................

Placing a Call by Specifying a Sub-address ..........................................

Setting the Alarm When Reconnecting a Dropped Call ...................

Improving Voice Clarity by Suppressing Background Noise ................

Talking Hands-free While Driving ...................................................

Receiving Voice/Videophone Calls

■

Receiving a Voice/Videophone Call ............................................................................ 65

Receiving a Call by Switching to/from Voice/Videophone Call ................................... 66

Pressing a Key on the Keypad to Receive a Call ..............................

Opening the FOMA Terminal to Receive a Call ..............................

Setting the Operation for the FOMA Terminal Being Closed during a Call

Using the Low Voice Feature ..............................................................

Putting a Call on Hold during a Call..............................................................

When You Are/Were Unable to Answer a Voice/Videophone Call

■

Putting a Call on Hold ..................................................................................

Using the Public Mode (Drive Mode) ..................................

Using the Public Mode (Power off) ........................................

Checking the Missed Calls ......................................................................

Recording Caller’s Messages When Unable to Answer Calls

Recording a Caller’s Message When Unable to Answer a Call Just Receiving

Playing Back/Deleting a Record Message/Videophone Message/Voice Memo ........ 74

Using Chara-den ....................................................................................................... 75

Setting the Videophone Operation ...............................................

Setting Notice for Switching between Voice and Videophone Calls

<Chg. to videophone/Chg. to voice call>

<Redial record/Received record>

<Chaku-moji>

<186/184>

<Prefix setting>

<WORLD CALL>

<Sub-address>

<Reconnect alarm>

<Reduce noise>

<Hands-free mode>

<Any key answer>

<Slide open setting>

<Setting when folded>

........

<Whisper mode>

<Holding>

<On hold>

<Public mode (Drive mode)>

<Public mode (Power off)>

<Missed call>

<Record message/Videophone message>

........

<Quick record message>

.....

<Videophone setting>

<Videophone switch notice>

.......

54

55

58

60

61

61

63

64

64

64

67

67

67

68

68

68

69

70

71

72

74

76

78

49

What is Videophone?

You can use the videophone function between DoCoMo videophone compatible
terminals. You can use videophone to talk to the recipient/caller while looking at each
other’s image. You can send a still image, substitute image, or Chara-den character

Voice/Videophone Calls

instead of your own.
DoCoMo’s videophone complies with “3G-324M
standard”. The FOMA terminal cannot be connected to a videophone that uses a
different system.

1 3G-324M

※

Global standard for third-generation mobile videophones.



2 3GPP (3rd Generation Partnership Project)

※

Local standardization committee set up for development of common technology



specifications related to third-generation mobile wireless communication systems (IMT-2000).

Using the Display during a Videophone Call

1

※

standardized by 3GPP

※

2

for global



: During videophone call



Videophone image (Large)



Display an image of a person you are talking to (default



setting).

Videophone image (Small)



Display your image (default setting).



Call duration





Display the call duration in the hh:mm:ss format.



Outgoing image status



: Camera image is being sent.



: A still image is being sent.



: A Chara-den character is being sent.






  



Zoom magnification





Display the zoom magnification bar.



: Hands-free ON



: Photo light ON



Mode



: Mode for operating full-body actions



: Mode for operating parts actions



: Mode for sending touch-tones (DTMF)



50

Operations during a Videophone Call

Switch between camera
image/substitute image
Switch cameras Press

Switch ON/OFF of the hands­free operation
Zoom-in/-out image Press

Put a call on hold From the Function menu, select [Holding]. To cancel this function,

Switch the display From the Function menu, select [Display setting].
Switch the quality of the
outgoing image

Select a substitute image From the Function menu, select [Select sub image].
Switch ON/OFF of the photo
light
Display your phone number From the Function menu, select [Own number].
Switch to a voice call From the Function menu, select [Chg. to voice call] (when placing

Operation Key operation

When you switch to the Out-camera with the lens cover closed, the message “Please open

●

the lens cover” appears and the substitute image is sent.

Press
display is switched between camera image/substitute image.

switched between the In-/Out-camera.
You can also switch between the In-/Out-camera by opening/
closing the lens cover.
Press
is switched.

camera.

press

From the Function menu, select [Visual preference]. When you
finish a call, the image quality set for the Visual preference of the
Videophone setting is restored.

From the Function menu, select [Photo light] (when using the Out­camera only).

a videophone call only).

(MySide/Sub). Every time you press the key, the

(In/Out). Every time you press the key, the camera is

( ). Every time you press the key, the ON/OFF setting

(Zoom in) / (Zoom out) when recording with the Out-

.

Placing a Voice/Videophone Call

Check the radio wave condition and enter a phone number.

Example: Placing a voice call

1

Enter a phone number in the stand-by display.

You can enter a phone number of up to 80 digits.

ˎ

Make sure to include the area code, even for a local call.

ˎ

When you press the wrong number

Press to delete the entered digits one by one from the right. Press

for over a second to delete all digits.

Voice/Videophone Calls

Continued

51

2

Press .

Ｃａｌｌｉｎｇ

Voice/Videophone Calls

3

Press to hang up.

See P.59 for sending the Chaku-moji and P.60 for placing a voice or videophone call by

●

specifying the condition.

For a voice call, you can also place it in the order of step 2 → step 1. Press and enter a

●

phone number, and the call is dialed automatically after about five seconds.

You are charged for digital communication even if you send a substitute image during a call.

●

If the videophone call is not connected, the following messages appear in the display. The

●

displayed message may not correctly represent the status of the recipient depending on the
type of the phone of the recipient or whether the recipient has subscribed to any network
service.

Check number, then redial The phone number is no longer in use.
Busy The recipient is talking on the phone.

Busy with packet
transmission
Outside of service area/
power off
Set Caller ID to ON This message appears when the call was connected without a

Please try voice call This message appears when the Call Forwarding Service is set

Connection failed This message appears when none of the above reasons apply.
Please make your call
from the i-mode web page
Upper limit has been
exceeded. Connection failed

If you use the FOMA terminal to place a videophone call to emergency numbers (110, 119,

●

and 118), it automatically switches to voice call dialing.

A ringing sound is heard when the call is connected.

To place a videophone call

Press (V.phone). When the call is answered, your image is sent to
the recipient and the call is switched to the hands-free operation that
allows you to hear the recipient’s voice from the speaker.

When 2in1 is set to the Dual mode

Select [Number A]/[Number B] (P.394).

When a busy tone sounds

The line is busy. Press to hang up and call again after a while.

When you hear a guidance

Call again according to the guidance.

Message Description

(This message may appear also during packet communication
on some recipient’s terminals.)
The recipient is using packet communication.

The recipient is in a place where radio waves do not reach or
the phone is powered off.

Caller ID (when a call is placed to Visual Net or other sites).

on the recipient’s phone and the terminal to which the call was
forwarded is not equipped with the videophone function.
(As of December 2007, this message may appear also when
the Voice Mail Service is set on the recipient’s phone.)

To view V-Live contents, visit and view an official i-mode site
once, and then place a videophone call.
The upper limit set to the plan with a Limit (Type Limit or Family
Wide Limit) has been exceeded.

52

When you place a videophone call to a terminal that is not equipped with a videophone

●

function, or when a recipient is outside of the service area or the phone is powered off (even
if the FOMA terminal has the videophone function), your call is not connected. When you
place a videophone call to a terminal that is not equipped with a videophone function and
the Auto redial(voice) is set to [ON], the recipient’s terminal disconnects your videophone
call before it is connected, and the FOMA terminal redials the call as a voice call. If,
however, you dial a wrong number such as an ISDN synchronous 64kbps or PIAFS access
points, or ISDN videophone that is not 3G-324M (as of December 2007) compatible, the
above operations may not take place. Note also that you may be charged for the call.

Using the Hands-free Function

When you switch to the hands-free operation during a call, you can hear the caller’s
voice from the speaker and talk hands-free.

Example: Switching to the hands-free operation during a voice call

1

Press ( ) during a call.

Ｔａｌｋｉｎｇ

Ｃａｌｌ ｄｕｒａｔｉｏｎ 

Talk into the FOMA terminal from a distance of 30 cm or less.

●

The call is switched to the hands-free operation and “ ” appears.

To cancel the hands-free function

Press ( ) again.

０：０３

When you finish the call, the hands-free operation is automatically

ˎ

canceled.

Entering a Pause, Timer, or +

You can include a pause, timer, or + in a phone number (within 80 digits in all) to
place a call.
The phone number and pause, timer, or + can be saved together in the Phonebook.

Pause and timer are valid only for a voice call.

ˎ

Voice/Videophone Calls

Entering a pause “P”

If you enter “P (pause)” between the phone number and touch-tones when you book
a ticket or play back your home answering machine, the touch-tones are sent by
separating the numbers at the pause (P).

1

Press in the phone number input display.

“P” is entered.

To send touch-tones saved in the Phonebook

When the touch-tones are displayed after you place a call from the Phonebook, press

(Call).

Some receiver devices may not be able to accept touch-tones.

●

Continued

53

Entering a timer “T”

To dial an inside line number following an outside line number, enter “T (timer)” between the
outside and inside line numbers. After a preset interval in seconds, the inside line number
is dialed following the outside line number. An interval of about one second is added for

Voice/Videophone Calls

every timer (T) entry. You can enter “T” consecutively to make the interval longer.

1

Press for over a second in the phone number input display.

“T” is entered.

Entering a “+”

If you enter “+” at the beginning of a phone number when the Auto conversion of the
Int’l dial assist setting is set to [ON], a call is dialed by automatically adding the set
international access number (set to “009130010” at the time of purchase).

1

Press for over a second in the stand-by display.

“+” is entered.

You may not be able to place the call if you enter other than a phone number after “+” or

●

enter only “+”.

Switching to/from Voice/Videophone Call

<Chg. to videophone/Chg. to voice call>

A caller can switch to/from voice/videophone call during a call.

This function can be used only between terminals that can switch between voice and

ˎ

videophone calls. A recipient must preset the V.ph switch notice to [Indication ON] (P.78).

Example: Switching from voice call to videophone call

1

Press (Func) during a voice call, select [Chg. to videophone], and press .

[Yes] :

   Ｃｈａｎｇｅ ｔｏ 

ｖｉｄｅｏｐｈｏｎｅ？

    Ｙｅｓ

Ｎｏ

2

Select [Yes] and press .

Ｃｈｇ．ｔｏ ｖｉｄｅｏｐｈｏｎｅ

Switch the call from voice call to videophone call.

[No] :

Return to the voice call without switching the call.

To switch from videophone call to voice call

From the Function menu, select [Chg. to voice call] → [Yes]. When the
call is switched to the voice call, the hands-free operation is canceled.

The recipient’s image
A substitute image may
appear according to the
setting on the recipient’s
terminal.

While the call is switched, an animation is displayed and you hear a guidance notifying you that a
call is switched.
When the call is switched to the videophone call, your image is sent to the recipient and the call is
switched to the hands-free operation that allows you to hear the recipient’s voice from the speaker.

54

If packet communication is in progress, it is disconnected and the FOMA terminal is

●

switched to videophone.

When the call is put on hold on the recipient or while the recipient is performing packet

●

communication, you cannot switch to videophone.

The switching operation takes about five seconds. It may take time depending on the radio

●

wave condition.

Switching to/from voice/videophone call may not be performed in some radio wave

●

condition, and the phone may be disconnected.

You are not charged while “Chg. to videophone”/“Chg. to voice call” is displayed.

●

Every time you switch, the call duration starts from 0 seconds. When you finish the call, the

●

total call duration is displayed for each of the voice and videophone calls.

Voice/Videophone Calls

Using the Redial/Received Record

<Redial record/Received record>

Up to 30 previously placed/received calls are saved as call records with their dates/times,
phone numbers, and names. The phone numbers or names appear in descending order from
the most recent call. For a PushTalk call, the group name or the first member’s name appears.

When 2in1 is used, up to 30 redial/received records of Number A and Number B can be saved

ˎ

for each separately. When 2in1 is set to the Dual mode or OFF, up to 30 redial/received records
of both numbers appear in descending order from the most recent call at once.

The call records of Number A and Number B are defined by different colors for each. The

ˎ

displayed color varies depending on the Color theme setting of the Kisekae setting (P.124).
Also, you can set the color for Number B from [dark]/[light] at the Disp. call/rcv. No. of 2in1 (P.396).

Redial record Dial frequency record Received record



Ｒｅｃｖ Ｆｒｅｑ Ｒｅｄｉａｌ

 ２／１３ １０：３２

 ドコモ二郎

２／１２ １０：３０
０９０ＸＸＸＸＸＸＸＸ
 ２／１２  ９：３５
 ドコモ一郎
 ２／１１ １０：３２
 携帯はる子
 ２／１０ ２２：１５
 ○○○同好会
 ２／１０ １０：２８
 携帯あき子

Call type



/

/

/
/

/ /




Placed/received voice call / Missed voice call (“

※

frequency record)
Placed/received videophone call / Missed videophone call

※

(“

” appears in case of the Dial frequency record)
Received 64K data communication / Missed 64K data communication
Originated/received PushTalk call / Missed PushTalk call
PushTalk type (to one person)/(to multiple persons)/(PushTalkPlus)
With Chaku-moji (Displayed only in the Received record)

” appears when the Record message/Videophone message is recorded.

“

※

Phone type



Mobile1 Mobile2 Public phone
Videophone Home phone Office phone
Home FAX Office FAX QUICKCAST

The phone type icons do not appear when the Personal data lock is set.

ˎ

Ｒｅｃｖ Ｒｅｄｌ ＤｉａｌＦｒｅｑ
 ドコモ一郎

ドコモ二郎
 ドコモ二郎
 携帯あき子
 携帯はる子
 ○○○同好会

０９０ＸＸＸＸＸＸＸＸ
 携帯あき子
 △△△クラブ

０３ＸＸＸＸＸＸＸＸ

０８０ＸＸＸＸＸＸＸＸ
 携帯なつ子





Ｆｒｅｑ Ｒｅｄｌ Ｒｅｃｅｉｖｅｄ

２／１３ １０：３２
 ドコモ二郎

２／１２ １０：３０
０９０ＸＸＸＸＸＸＸＸ
 ２／１２  ９：３５
 ドコモ一郎
 ２／１１ １０：３２
 携帯はる子
 ２／１０ ２２：１５
 ○○○同好会
 ２／１０ １０：２８
 携帯あき子




” appears in case of the Dial

Continued

55

Example: Displaying the Redial record

1

Press ( ) in the stand-by display.

The Redial record display appears.

To display the Received record

Voice/Videophone Calls

Press ( ) in the stand-by display.

To display the Dial frequency record

Press in the Redial record display.

To display phone numbers

When saved in the Phonebook, the name and phone type of a recipient are displayed instead
of the phone number. Press
numbers. The display is not switched when a group name for a PushTalk call is displayed.

To place a voice call

Move the cursor to a call record and press .

To place a videophone call

Move the cursor to a call record and press (V.phone).

To originate a PushTalk call

Move the cursor to a call record and press .

To send mail

You can send mail to a person whose phone number and mail address are saved in the
Phonebook. Move the cursor to a call record and from the Function menu, select [Reply by
mail]→ a mail address. Compose mail and send it.

To save in a group of the PushTalk phonebook

When you perform PushTalk communication among several persons saved in the PushTalk
phonebook, move the cursor to a received record of the PushTalk call (
select a group, and press

If the same phone number has been repeatedly called, only the most recent call is saved

●

in the Redial record. Note, however, that when you originate a PushTalk call, individual
PushTalk communication among several persons are recorded.

If you switch the call between voice and videophone during a call, the call you placed/

●

received first is saved in the Redial/Received record.

When a caller uses a “Dial-in” phone number, the phone number displayed may be different

●

from the caller’s dial-in number.

When you place a voice or videophone call from the Received record, a Chaku-moji

●

recorded in the Received record is not sent.

When the date and time are corrected to the local time during international roaming, “ ”

●

appears next to the name/phone number (P.44).

to switch the display temporarily between names and phone

), press (Save),

(Complete).

56

Displaying the Detailed Information of the Redial/Received Record

1

From the call record display, select a call record and press (Detail).

Redial record Received record

Ｒｅｄｉａｌ

 ＵｓｒＳｅｔ

２／１０ Ｓｕｎ
１０：０５

 ドコモ太郎

０９０ＸＸＸＸＸＸＸＸ

 付加番号

１

０９０ＸＸＸＸＸＸＸＸ

The following icons show the Multi Number type.

ˎ

Call type

Phone type

Multi Number type

基本契約番号

(Basic Number)

When you select a call record of a PushTalk call, [ ] group name, [ ] caller name (Received

●

Ｒｅｃｅｉｖｅｄ

２／１０ Ｓｕｎ
１０：０５

 ドコモ太郎

０９０ＸＸＸＸＸＸＸＸ
１２ｓｅｃ

 付加番号

１
０９０ＸＸＸＸＸＸＸＸ
Ｕｒｇｅｎｔ

1

付加番号

(Additional No.1)

Call type

Phone type
Ring time for a missed call

Multi Number type
Chaku-moji message

2

付加番号

(Additional No.2)

record only), and all members are displayed.

Deleting the Redial/Received Record

The call records are retained even if the FOMA terminal is powered off. If you do not
wish others to know the previously dialed records, delete one or all of the call records.

If you delete either a redial record or a dial frequency record, both records are deleted.

ˎ

Example: Deleting a call record

1

From the call record display, select a call record and press (Func).

The Function menu appears.

To delete several call records

From the Function menu, select [Delete] → [Select&delete], select call records, press

(Complete), and select [Yes].

To delete all call records

From the Function menu, select [Delete] → [Delete all], enter the Security code, and select
[Yes].

2

Select [Delete] → [Delete one] → [Yes] and press .

The selected call record is deleted.

If you perform the Delete all when 2in1 is used, all the Call records of Number A and Number

●

B are deleted, regardless of the 2in1 mode.

Voice/Videophone Calls

57

Setting the Chaku-moji

When you place a voice or videophone call, you can send a message (Chaku-moji)
that is displayed in the recipient’s Incoming call display in order to notify the purpose
of the call even before this recipient answers.

Voice/Videophone Calls

Ｉｎｃｏｍｉｎｇ ｃａｌｌ

Ｕｒｇｅｎｔ

For more details about the Chaku-moji or compatible models, see the DoCoMo’s website or

ˎ

“Mobile Phone User’s Guide 【Network services】”.

Charge is required for the Chaku-moji sender, but no charge for a recipient.

ˎ

Chaku-moji cannot be used for PushTalk calls.

ˎ

When you use the FOMA terminal overseas, you cannot send or receive a Chaku-moji message.

ˎ

Chaku-moji
Chaku-moji disappears when you start talking on the phone.
Chaku-moji can be checked in the detailed information display of the Received Record (P.57).

Editing Chaku-moji Messages

You can save up to 10 Chaku-moji messages.

1

From the Menu, select [Settings] → [Management] → [NW Services]
[Chaku-moji]→ [Create message] and press .

To delete a Chaku-moji message

Move the cursor to a Chaku-moji message and from the Function menu, select [Delete
one]→ [Yes]. To delete all Chaku-moji messages, from the Function menu, select [Delete
all], enter the Security code, and select [Yes].

2

Press (Edit) and enter a Chaku-moji message.

Enter a message within 10 characters regardless of pictographs, symbols, full-width, or half-width.
The Chaku-moji message is saved.

<Chaku-moji>

→

Setting the Display for Chaku-moji Being Received

You can set the display style to be used when you receive a Chaku-moji message.

1

From the Menu, select [Settings] → [Management] → [NW Services]
[Chaku-moji]→ [Set Message display] and press .

58

Ｓｅｔ Ｍｅｓｓａｇｅ ｄｉｓｐｌａｙ

  Ｄｉｓｐｌａｙ ａｌｌ Ｍｓｇｓ

Ｏｎｌｙ ｎｕｍｂｅｒｓ ｉｎ ＰＢ

Ｏｎｌｙ ｃａｌｌｓ ｗ／ＩＤ

Ｈｉｄｅ ａｌｌ ｍｅｓｓａｇｅｓ

[Display all Msgs] :

[Only numbers in PB] :

[Only calls w/ID] :

[Hide all messages] :

Receive and display all Chaku-moji.
Receive and display Chaku-moji sent only from

callers who are saved in the Phonebook. You
cannot receive Chaku-moji from a caller who is
saved in the Phonebook as Secret unless the
Secret display is set to [ON].

Receive and display Chaku-moji sent only from

callers who notify their caller IDs.

Do not receive or display any Chaku-moji.

→

2

Select the Chaku-moji display style and press .

The display style for Chaku-moji is set.

Placing a Call with a Chaku-moji Message

You can place a voice or videophone call together with a Chaku-moji message.

1

Enter a phone number in the stand-by display and press (Option).

The Call menu appears.

2

Select [Chaku-moji] and press .

Ｓｅｌｅｃｔ ｔｈｅ ｗａｙ
 ｔｏ ｉｎｐｕｔ
 ｃｈａｋｕ−ｍｏｊｉ

 Ｎｏｎｅ ｓｐｅｃｉｆｉｅｄ

Ｃｒｅａｔｅ ｍｅｓｓａｇｅ
 Ｓｅｌｅｃｔ ｍｅｓｓａｇｅ

[None specified] :
[Create message] :

[Select message] :

[Sent messages] :

3

Compose/Select a Chaku-moji message.

The Chaku-moji message is composed/selected.

4

Select another call condition and press (Call).

Ｃａｌｌｉｎｇ

The call is dialed according to the selected Chaku-moji message and call
condition.

Ｕｒｇｅｎｔ

Place a call without a Chaku-moji message.
Create a Chaku-moji message and place a call.

Enter a message within 10 characters regardless of
pictographs, symbols, full-width, or half-width.

Select a saved Chaku-moji message and place a

call. (This menu appears only when the Chaku-moji
message is saved.)

Select a sent Chaku-moji message and place a call. Up
to 10 Chaku-moji messages can be saved. (This menu
appears only when there is a sent Chaku-moji message.)

Voice/Videophone Calls

When a Chaku-moji is received by the recipient, “ ” appears in the sender’s terminal

●

display and charge is required.

If the recipient does not receive the Chaku-moji, “ ” appears. In this case, there is no

●

charge. (For example, when the recipient’s terminal does not have Chaku-moji support or
if the Chaku-moji was received in a condition other than that set using the Set Message
display menu.)

If the recipient’s terminal has the following settings or conditions, Chaku-moji cannot be

●

delivered to this recipient and the call is not saved in the Received record of the recipient’s
terminal. “
transmission.

- When the recipient’s terminal is outside of the service area



- When the recipient’s terminal is powered off



- When the Public mode (Drive mode) is set



- When the To answer the Record message is set to 0 seconds, etc.



Even if a Chaku-moji was delivered successfully to the recipient, “ ” or “ ” may not be

●

displayed in the sender’s terminal display depending on the radio wave condition. In this

” or “ ” is not displayed on the sender’s terminal and there is no charge for this

case, charge is required.

If you place a videophone call with a Chaku-moji while the Auto redial(voice) is set to [ON],

●

the Chaku-moji is sent even when this call is redialed as a voice call.

59

Changing the Caller ID Setting ON/OFF for an Individual Call

You can choose whether to notify a recipient of your phone number (caller ID) every
time you place a call.

The caller ID is important personal information. Carefully decide whether you want to notify a

Voice/Videophone Calls

ˎ

recipient of your caller ID.

You can use the following methods to notify or not notify your caller ID.

Presetting for all calls Use the Set Notification to set [Notify]/[Not notify] (P.45).
Setting in the Phonebook Add “186/184” to the recipient’s phone number when you save it in the

Setting when you place
a call

When you place a call by pressing after dialing a phone number with “186/184”, the

●

phone number is saved in the Redial record with “186/184”.

You cannot set whether to notify the caller ID when you originate a PushTalk call even when

●

you add “186/184”.

Phonebook (P.95).
Set [Call with ID]/[Call without ID] at the Caller ID of the Option call
display after dialing a recipient’s phone number (P.60).
Enter “186/184” before dialing a recipient’s phone number (P.51).

To notify the caller ID

Press 186 + Phone number + .

Not to notify the caller ID

Press 184 + Phone number + .

Placing a Call by Specifying a Condition

When you place a call, you can set a call condition at the Option call display such as
selecting a call type or whether to notify a recipient of your phone number for each call.

1

Enter a phone number in the stand-by display and press (Option).

60

Ｏｐｔｉｏｎ ｃａｌｌ

Ｐｈｏｎｅ ｎｕｍｂｅｒ

Ｃａｌｌ ｍｅｔｈｏｄ

Ｖｏｉｃｅ ｃａｌｌ

Ｃａｌｌｅｒ ＩＤ

Ｎｏｎｅ ｓｐｅｃｉｆｉｅｄ

Ｖ．ｐｈｏｎｅ ｏｕｔｇｏｉｎｇ ｉｍｇ

Ｍｙ ｓｉｄｅ
Ｃｈａｋｕ−ｍｏｊｉ
   Ｎｏｎｅ ｓｐｅｃｉｆｉｅｄ
Ｐｒｅｆｉｘ

[Call method]
[Caller ID]

: Select [Voice call]/[Videophone]/[PushTalk]/[SMS].
: Select whether to notify your phone number to the

recipient. When you select [None specified], follow
the setting of the Set Notification.

[V.phone outgoing img]

Select an image to be sent when placing a
videophone call.

[Chaku-moji]
[Prefix] :

: Compose/select a Chaku-moji message (P.59).

Place a voice or videophone call by selecting a

saved prefix (P.61). (This item appears only when a
prefix is saved.)

[Int’l prefix] :

Place a voice or videophone call by selecting a

saved international access number (P.63). (This item
appears only when you enter a phone number with a
preceding “+”.)

[Country code] :

Place a voice or videophone call by selecting a

saved country code (P.63).

[2in1 call number]
[Multi Number]

: Select a Caller ID when 2in1 is set to the Dual mode.

: Select a Caller ID when the Multi Number call is set

to [ON].

:

<186/184>

2

Set each item.

3

Press (Call).

The call is dialed according to the set call condition.

A call condition which cannot be set does not appear.

●

You cannot place a call even if you set [Prefix], [Int’l prefix], or [Country code] from the Call

●

condition if a phone number you dialed exceeds 81 digits when the call condition is added.

Voice/Videophone Calls

Setting a Prefix

<Prefix setting>

You can save up to three specific numbers (prefixes) to be added at the beginning of
a phone number when you place a call.

1

From the Menu, select [Settings] → [Call] → [Call assist] → [Prefix setting]
and press .

Ｐｒｅｆｉｘ ｓｅｔｔｉｎｇ

Ｎｕｍｂｅｒ

Ｎｕｍｂｅｒ

Ｎｕｍｂｅｒ

2

Select a number and press .

The number input display appears.

3

Enter a prefix and press (OK).

Enter a prefix within 26 digits.

Placing an International Call

<WORLD CALL>

With WORLD CALL, you can place an international call from a DoCoMo mobile phone.

The users who subscribe to the FOMA services are automatically signed up for the “WORLD

ˎ

CALL” service when the agreement is concluded. (Excluding users who choose to refuse the
WORLD CALL service.)

Placing an international call by entering a phone number

■

009130−010−Country code

You can save the above procedure in the Phonebook of the FOMA terminal.

ˎ

If an area code begins with “0”, omit the “0” when dialing (except when calling ordinary

ˎ

phones, etc. in Italy).

Area code

−−

(City code)

Phone number

Continued

61

Placing an international call by using “+”

■

When you enter “+” at the beginning of a phone number, you can place an international call
without entering an international access number such as “009130010” (P.54).

The Auto conversion of the Int’l dial assist is set to [ON] at the time of purchase. An

ˎ

Voice/Videophone Calls

international access number is entered automatically.

(for over a second)

You can save the above procedure in the Phonebook of the FOMA terminal.

ˎ

If an area code begins with “0”, omit the “0” when dialing (except when calling ordinary

ˎ

phones, etc. in Italy).

You can place calls to about 240 countries and regions in the world.

ˎ

Charges for this service are billed together with the monthly call charges.

ˎ

No application fees or monthly basic charges are required.

ˎ

This service is not available in some service charge plans.

ˎ

Change in the dial procedure for international calls.

ˎ

Since mobile communication such as mobile phones is beyond the scope of the “MYLINE”

Country code

−

Area code

−−

(City code)

Phone number

service, “MYLINE” service is not available also for WORLD CALL. With the introduction of
“MYLINE” service, however, the dial procedure for international calls on mobile phones has
been changed. Note that the old dial procedure (excluding “010” from the above mentioned
dial procedure) is not available.

For the WORLD CALL details, call the “General Inquiries” on the backcover of this manual.

ˎ

To use an international call service company other than DoCoMo, contact them directly.

ˎ

If you have an overseas specific 3G mobile phone, you can connect to an international

ˎ

videophone by selecting videophone after the above dialing method.

See the NTT DoCoMo’s website for information about countries to which a videophone call

※

can be connected and telecommunication companies.

A recipient’s image displayed on the FOMA terminal may be fuzzy or a call may not be

※

connected successfully depending on the terminal to which the international videophone is
connected.

Setting a Number Other Than WORLD CALL

You can save up to three international access numbers and up to 30 country codes to
be added at the beginning of a phone number in order to place an international call
from Japan. You can automatically add the international access number by entering
“+” when you place a call. You can automatically convert the first digit “0” of the
phone number to a country code when you place a call from the Phonebook, etc.

1

From the Menu, select [Settings] → [Management] → [NW Services] → [Int’l
dial assist] and press .

Ｉｎｔｌ ｄｉａｌ ａｓｓｉｓｔ

Ａｕｔｏ ｃｏｎｖｅｒｓｉｏｎ

Ｉｎｔｌ ｐｒｅｆｉｘ
      Ｗｏｒｌｄ Ｃａｌｌ
Ｃｏｕｎｔｒｙ ｃｏｄｅ
         日本

[Auto conversion] :

 ＯＮ

[Int’l prefix] :

[Country code] :

Set whether an international access number is

automatically added.

Save an international access number and set the

Auto assist number. You can also add an international
access number by selecting [Int’l prefix] at the Option
call display when you place a call.

Save a country code. You can add a country code by

selecting [Country code] at the Option call display
when you place a call.

62

2

Select [ON]/[OFF] at [Auto conversion].

[ON] :

Automatically add the additional number you set for the Int’l prefix.

[OFF] :

Do not automatically add the additional number.

3

Select [Int’l prefix] and press .

The Int’l prefix setting display appears.

4

Select an input field and press .

Ｉｎｔｌ ｃａｌｌ１

Ｎａｍｅ
   Ｗｏｒｌｄ Ｃａｌｌ
Ｉｎｔｌ ａｃｃｅｓｓ Ｎｏ．
   ００９１３００１０

5

Enter a name in the name field and an international access number in the
international access number field.

Enter a name within 10 full-width characters or 20 half-width characters and an international
access number within 10 digits.

6

Press (Complete) and press .

The international access number is saved.

To set the Auto assist number

Move the cursor to the input field and press (Auto). “ ” appears to the left of the Auto
assist number.

7

Select [Country code] and press .

The Set country code display appears.

8

Select an input field and press .

Ｃｏｕｎｔｒｙ ｃｏｄｅ２３

Ｃｏｕｎｔｒｙ Ｎａｍｅ

Ｃｏｕｎｔｒｙ ｃｏｄｅ

9

Enter a country name in the country name field and a country code in the
country code field.

Enter a country name within seven full-width characters or 14 half-width characters and a
country code within five digits.

“+” is already entered in the country code field.

ˎ

10

Press (Complete).

The country code is saved.

To set the Auto assist number

Move the cursor to the input field and press (Auto). “ ” appears to the left of the Auto
assist number.

Voice/Videophone Calls

Placing a Call by Specifying a Sub-address

<Sub-address>

You can set to place a call to a specific phone or communication device by specifying
a sub-address.

The sub-address is also used when you select a content in V-Live.

ˎ

1

From the Menu, select [Settings] → [Call] → [Call assist] → [Sub-address]
and press .

[ON] :

Recognize the numbers after “ ” as a sub-address.

[OFF] :

Do not recognize the numbers after “

” as a sub-address.

Continued

63

2

Select [ON]/[OFF] and press .

The Sub-address is set.

To place a call by specifying a sub-address

In the stand-by display, enter a phone number + + sub-address and press either

Voice/Videophone Calls

or (V.phone).

Even if the Sub-address is set to ON, “ ” is not recognized as the sub-address separator

●

but as part of a phone number in the following cases: where it is at the beginning of a phone
number and immediately after a number entered using Prefix/Int’l prefix/Country code of the
Option call display for placing a call.

Setting the Alarm When Reconnecting a Dropped Call

<Reconnect alarm>

This function automatically reconnects the call interrupted during a voice,
videophone, or PushTalk call due to the radio wave condition, such as in a tunnel or
between buildings, right after the radio wave condition is recovered. You can set an
alarm tone when a call is reconnected.

1

From the Menu, select [Settings] → [Call] → [Call setting] → [Recnct ALM]
and press .

[High] :

Sound the high alarm tone.

[Low] :

Sound the low alarm tone.

[OFF] :

Do not sound the alarm tone.

2

Select the type of the alarm tone and press .

The alarm tone during reconnection is set.

The recipient does not hear any sound while the radio wave is interrupted.

●

The time required for reconnection depends on the usage and radio wave condition. The

●

average reconnection time is about 10 seconds and the caller is charged for the time spent
for reconnection.

Improving Voice Clarity by Suppressing Background Noise

<Reduce noise>

You can suppress background noise during a voice or videophone call or during
playing back an answering message set for the record message.

1

From the Menu, select [Settings] → [Call] → [Call quality] → [Reduce noise]
and press .

[ON] :

Suppress background noise.

[OFF] :

Do not suppress background noise.

2

Select [ON]/[OFF] and press .

The Reduce noise is set.

Talking Hands-free While Driving

<Hands-free mode>

You can place or receive a voice call using a hands-free device by connecting the
FOMA terminal to a device such as the In-Car Hands-Free Kit 01 (optional) or car
navigation system.
For details about the operation of the hands-free device, see the user’s manual of the
device. When you use the In-car Hands-free Kit, you need the FOMA In-Car Hands­Free Cable 01 (optional).

64

The incoming call display and ring tone operation follow the FOMA terminal settings.

●

When a setting is made for hearing sound from the hands-free device, a ring tone sounds

●

from the hands-free device even if the FOMA terminal is set to the Manner mode or its Ring
volume is set to [OFF].

Even if you connect the FOMA terminal to a hands-free device, the Public mode (Drive

●

mode) and Record message function operate normally.

When a setting is made for hearing sound from the FOMA terminal, the operation when the

●

FOMA terminal is closed during a call follows the Setting when folded. When a setting is
made for hearing sound from the hands-free device, the call continues even if the FOMA
terminal is closed regardless of the setting of the Setting when folded.

When you use the In-Car Hands-Free Kit 01, “ ” appears. If you use any other commercially

●

available car adapter, “

” may appear.

Receiving a Voice/Videophone Call

When you receive a voice or videophone call, you are notified by flashing indicator,
ring tone, vibrator, etc. The operation for an incoming call varies depending on the
settings of the Incoming set, Manner mode, etc.

Example: Receiving a voice call

1

When receiving a call, press .

Ｉｎｃｏｍｉｎｇ ｃａｌｌ

Ｕｒｇｅｎｔ

Chaku-moji (P.58)

Ｔａｌｋｉｎｇ

Ｃａｌｌ ｄｕｒａｔｉｏｎ

A phone number appears in the display when a caller sends it.

When you receive a videophone call

Your image is sent to the caller and the call is switched to the hands­free operation that allows you to hear the caller’s voice from the
speaker.

When the caller notifies you of the phone number

When saved in the Phonebook, the name and phone number of a
caller are displayed. If you saved the same phone number for several
names in the Phonebook, the name stored using the smallest memory
number is displayed. The Des phone tone, Des call display, and Select
phone Illum. saved in the Phonebook are used.

When the caller does not notify you of the phone number

The reason why the phone number is not displayed appears.

Non-display

reason

 ０：０３

User Unset When a call is received from a caller who does not notify

Description

the caller’s phone number intentionally.
PublicPhone When a call is received from a public phone, etc.
Unavailable When a call is received from a caller who cannot notify

the caller’s phone number, such as from overseas and

from an ordinary phone through call forwarding services

(however, the caller’s phone number may be displayed

depending on the intermediary telephone company).

To connect a call to the Voice Mail Service Center

From the Function menu, select [FWD to Voice Mail].

To forward a call to a forwarding number

From the Function menu, select [Call Forwarding].

To reject a call

From the Function menu, select [Call Rejection].

Continued

Voice/Videophone Calls

65

2

Press to hang up.

When you receive a voice call, you can answer it by pressing (Call) instead of .

●

When you set the Any key answer to [ON], you can also press

to , , or to

answer a call (P.67).

Voice/Videophone Calls

. To answer a call with a substitute image, press (Sub) (P.76).

When the Slide open setting is set to [Calling], you can answer a voice/videophone call just

●

When you receive a videophone call, you can answer it by pressing (V.phone) instead of

●

by opening the FOMA terminal (P.67).

If you receive a videophone call while the Manner mode is set, the screen for confirming

●

whether the hands-free operation is set to ON appears. If you do not want to use the hands­free operation, select [No].

You can preset the hands-free function of a videophone call to [OFF] (P.77).

●

You may hear beeps (ring tone during a call) while talking on the FOMA terminal.

●

If [Answer] is set for the Arrival Call Act with the Voice Mail Service, the Call Forwarding



Service, or the Call Waiting Service subscribed, the beeps (the ring tone during a call) sound
and the following operations are available when there is another incoming call during a call:
<Contents of subscription>



- The Voice Mail Service .............Forward a call to the Voice Mail Service Center.



- The Call Forwarding Service .... Forward a call to a forwarding number.



- The Call Waiting Service ........... Put the active call on hold and answer the incoming call.



Receiving a Call by Switching to/from Voice/Videophone Call

A caller can switch between voice and videophone calls during a call. When the
caller switches the voice call to the videophone call, a recipient can select whether to
send a camera image.

This function can be used only between terminals that can switch between voice and

ˎ

videophone calls. Preset the V.ph switch notice to [Indication ON] (P.78).

Example: When the voice call is switched to the videophone call

1

When the screen for confirming whether to send your own image appears
during a voice call, select [Yes] and press .

Ｃｈｇ．ｔｏ ｖｉｄｅｏｐｈｏｎｅ

While the call is switched, an animation is displayed and you hear a
guidance notifying you that a call is switched.

66

Ｓｅｎｄ
ｃａｍｅｒａ ｉｍａｇｅ

Ｙｅｓ
    Ｎｏ

[Yes] :

Send a camera image to the caller’s phone display.

[No] :

Send a preinstalled image to the caller.

When the videophone call is switched to the voice call

The call is automatically switched to the voice call. When the call is
switched to the voice call, the hands-free operation is canceled.

When the call is switched to the videophone call, your image is sent to
the caller and the call is switched to the hands-free operation that allows
you to hear the caller’s voice from the speaker.

Pressing a Key on the Keypad to Receive a Call

<Any key answer>

You can set to answer a call by pressing a key on the keypad instead of pressing
when you receive a voice or PushTalk call.

1

From the Menu, select [Settings] → [Call] → [Call assist] → [Any key ans]
and press .

[ON] :

Enable to answer a voice or PushTalk call also by pressing to , , or .

[OFF] :

Disable to answer a voice or PushTalk call by pressing

To answer a voice call, press

PushTalk call).

2

Select [ON]/[OFF] and press .

The Any key ans is set.

or (Call) ( , , or (Answer) for a

to , , or .

Voice/Videophone Calls

Opening the FOMA Terminal to Receive a Call

<Slide open setting>

You can set to answer a call by opening the FOMA terminal instead of pressing
when you receive a voice, videophone, or PushTalk call.

1

From the Menu, select [Settings] → [Management] → [Slide setting] → [Slide
open setting] and press .

[Calling] :

[OFF] :

2

Select [Calling]/[OFF] and press .

The Slide open setting is set.

Setting the Operation for the FOMA Terminal Being Closed during a Call

Enable to answer a voice, videophone, or PushTalk call by opening the FOMA terminal.
Disable to answer a voice, videophone, or PushTalk call by opening the FOMA terminal.

<Setting when folded>

You can end a call, put a call on hold, or continue the conversation just by closing
the FOMA terminal during a voice/videophone call. You can also end or continue a
call, or switch a call to the hands-free operation by closing the FOMA terminal during
PushTalk communication.

1

From the Menu, select [Settings] → [Management] → [Slide setting]

→

[Setting when folded] and press .

Ｓｅｔｔｉｎｇ ｗｈｅｎ ｆｏｌｄｅｄ

Ｖｏｉｃｅ ｃａｌｌ／Ｖ．ｐｈｏｎｅ

 Ｃｏｎｔｉｎｕｏｕｓ ｃａｌｌ

ＰｕｓｈＴａｌｋ

Ｓｐｅａｋｅｒ ｃａｌｌ

2

Select the Setting when folded at [Voice call/V.phone].

[Holding] :

[Mute] :

[Disconnect] :

[Continuous call] :

The Seting when folded during a voice or videophone call is set.

[Voice call/V.phone] :

[PushTalk] :

Put the call on hold. Both you and the recipient hear the melody “Hamabe no
uta”. During a videophone call, the preinstalled image is sent to the recipient.

Put the call on hold with the voice muted. During a videophone call, a

substitute image is sent to the recipient (P.76).
Hang up the call.
Continue a conversation.

Set the operation for the FOMA terminal being

closed during a voice/videophone call.

Set the operation for the FOMA terminal being

closed during PushTalk communication (P.91).

Continued

67

When the Flat-plug Earphone/Microphone with Switch (optional) is connected, the Setting

●

when folded is disabled and the call continues even if you close the FOMA terminal. If it is
during a videophone call that you close the FOMA terminal, a substitute image is sent.

Using the Low Voice Feature

Voice/Videophone Calls

<Whisper mode>

You can set the FOMA terminal so that the recipient can hear your voice at a normal
volume level even if you speak in low voice during a voice call.

1

Press during a call.

Ｔａｌｋｉｎｇ

Ｗｈｉｓｐｅｒ ｍｏｄｅ 

The call is switched to the Whisper mode and the message “Whisper
mode” is displayed.

To cancel the Whisper mode

１２：３４

Press again.

When you finish a call, the Whisper mode is canceled automatically.

ˎ

Putting a Call on Hold during a Call

The call can be put on hold during a voice or videophone call so that your voice
cannot be heard by the recipient.

Even if the call is put on hold, the caller is charged for the call.

ˎ

1

Press (Func) during a call, select [Holding], and press .

Both you and the recipient hear the melody “Hamabe no uta”. During a videophone call, a
preinstalled image is sent to the recipient.

To cancel the Holding

Press .

Putting a Call on Hold

If you cannot answer a voice or videophone call immediately, you can put the call on hold.

Even if the answer is put on hold, the caller is charged for the calling charge.

ˎ

Example: Putting a voice call on hold

1

When receiving a call, press (HLD).

Ｏｎ ｈｏｌｄ

Ｃａｌｌ ｄｕｒａｔｉｏｎ

The answer is put on hold.
The guidance to inform the caller that you are currently unable to answer
the call is played back. During a videophone call, a preinstalled image is

 ０：０３

sent to the recipient.

If you press

ˎ

disconnected.

<On hold>

while the call is put on hold, the call on hold is

<Holding>

68

2

When ready to answer the call, press .

The On hold is canceled and you can talk.

If you have signed up for the Voice Mail or Call Forwarding Service, you can select [FWD

●

to Voice Mail] or [Call Forwarding] from the Function menu while you are receiving a call, in
order to use those services.

Voice/Videophone Calls

Using the Public Mode (Drive Mode)

<Public mode (Drive mode)>

The Public mode is an automated answering service which takes into account the
manners in highly public places. When the Public mode is set, the guidance is
played back to inform the caller that you are unable to answer the call because you
are driving or in a place where talking on a mobile phone should be avoided (trains,
buses, or movie theaters), and then the call is disconnected.

The Public mode can be set or canceled even if “

ˎ

The Public mode cannot be used during data communication.

ˎ

1

Press ( ) for over a second in the stand-by display.

The Public mode is set and “ ” appears.

When the Manner mode and the Public mode are set simultaneously,

ˎ

the Public mode has priority.

To cancel the Public mode

Press ( ) for over a second in the stand-by display. The Public
mode is canceled and “

When the Public mode (Drive mode) is set

■

Even if there is an incoming call, the ring tone does not sound and you cannot answer it.

ˎ

The notification icon of missed call appears and the call is saved in the Received record.
The guidance for the Public mode is played back to inform the caller that you are unable
to answer the call because you are driving or in a place where talking on a mobile phone
should be avoided (trains, buses, or movie theaters), and then the call is disconnected.

Even if there is an incoming PushTalk call, you cannot answer it. The notification icon of

ˎ

missed call appears and the call is saved in the Received record. If the received call is for
the PushTalk communication among several persons, the message “Driving” appears in the
On PushTalk display of the members.

The call can be placed normally.

ˎ

The following tones do not sound and the vibrator, etc. does not operate.

ˎ

- Ring tone - Alarm tone - Schedule alarm

- Battery alarm - Alarm for the Call cost limit - i-αppli software sound

- Charge sound - ToruCa receive completion tone - Position location sound

- Location notice sound - Loc. provide/accept tone - Loc. provide/check tone

For operation for an incoming call when the Public mode (Drive mode) and each network

ˎ

service are set simultaneously, see “Operation for an incoming call when network services
and the Public mode (Drive mode/Power OFF) are set” (P.70).

” is displayed.

” disappears.

69

Using the Public Mode (Power off)

<Public mode (Power off)>

The Public mode (Power off) is an automated answering service which takes into
account the manners in highly public places. When the Public mode (Power off) is
set, the guidance is played back to inform the caller that you are unable to answer

Voice/Videophone Calls

the call because you are in a place where it is required to power off a mobile phone
(such as in hospitals, airplanes, and near priority seats in trains), provided that there
is an incoming call when the FOMA terminal is powered off, and then the call is
disconnected.

1

Press + .

The Public mode (Power off) is set. (No change appears on the stand-by display.)

To cancel the Public mode (Power off)

Press + .

To check the setting

Press + .

When the Public mode (Power off) is set

■

If there is an incoming call when the FOMA terminal is powered off or you are outside of

ˎ

the service area or in a location without the radio wave, the guidance for the Public mode
(Power off) is played back to inform the caller that you are unable to answer the call because
you are in a place where it is required to power off a mobile phone, and then the call is
disconnected.

You cannot answer an incoming PushTalk call. If the received call is for the PushTalk

ˎ

communication among several persons, the message “
PushTalk display of the members.

For operation for an incoming call when the Public mode (Power OFF) and each network

ˎ

service are set simultaneously, see “Operation for an incoming call when network services
and the Public mode (Drive mode/Power OFF) are set” (P.70).

Disconnect” appears in the On

Operation for an incoming call when network services and the Public mode (Drive
mode/Power OFF) are set

Service When a voice call is received When a videophone call is received

The Voice
Mail
Service※1

The Call
Forwarding
Service※1

2

※

The Call
Waiting
Service※3

After the guidance for the Public mode
is played back, the call is connected to
the Voice Mail Service Center.

After the guidance for the Public mode
is played back, the call is forwarded to
a forwarding number.

After the guidance for the Public mode
is played back, the call is disconnected.

The video guidance for the Public
mode is not played back and the call
is connected to the Voice Mail Service
Center.
The video guidance for the Public
mode is not played back and the call is
forwarded to a forwarding number. If the
forwarding number of the phone which is
not compliant with 3G-324M videophone
call, the call is disconnected.
After the video guidance for the Public
mode is played back, the call is
disconnected.

70

Service When a voice call is received When a videophone call is received

The
Nuisance
Call
Blocking
Service

The Caller
ID Display
Request
Service

1 If you set the ring time of the Voice Mail or Call Forwarding Service to 0 seconds, the

※

guidance for the Public mode is not played back and a call is not saved in the Received
record, either.

2 You can set whether the guidance is played back to a caller with the “1429” setting of the

※

Call Forwarding Service.

3 The operation for an incoming call is written for the Public mode (Drive mode).

※

After the guidance is played back

ˎ

to inform the caller that the call is
not able to be connected, the call is
disconnected if the caller is saved as
a nuisance caller.

After the guidance for the Public

ˎ

mode is played back, the call is
disconnected if the caller is not
saved as a nuisance caller.

After the caller ID request guidance is

ˎ

played back, the call is disconnected
if the caller does not notify the phone
number.

After the guidance for the Public

ˎ

mode is played back, the call is
disconnected if the caller notifies the
phone number.

After the video guidance is played

ˎ

back to inform the caller that the call
is not able to be connected, the call
is disconnected if the caller is saved
as a nuisance caller.

After the video guidance for the

ˎ

Public mode is played back, the call
is disconnected if the caller is not
saved as a nuisance caller.

After the video guidance for the

ˎ

caller ID request is played back to
the caller, the call is disconnected if
the caller does not notify the phone
number.

After the video guidance for the

ˎ

Public mode is played back to the
caller, the call is disconnected if the
caller notifies the phone number.

Voice/Videophone Calls

Checking the Missed Calls

<Missed call>

When you are unable to answer an incoming call or receive new mail, the notification
icon (P.32) appears in the stand-by display.
If a voice, videophone, or PushTalk call or 64K data communication is not answered,
“ ” appears in the stand-by display. The received record shows the date/time and
the person who called (P.55).

1

Press (Link) in the stand-by display and select the notification icon.

The text information for the notification icon appears.

To check the Received record

Select “ ” (Missed call).

To delete the notification icon

Press for over a second. “ ” also disappears when the Received
record is displayed.

Ｍｉｓｓｅｄ ｃａｌｌ

１

Text information
Notification icon

71

Recording Caller’s Messages When Unable to Answer Calls

<Record message/Videophone message>

When the Record message/Videophone message is set, the FOMA terminal can
record a caller’s message when you are unable to answer a call.

The FOMA terminal can record up to three record messages and videophone messages,

Voice/Videophone Calls

ˎ

each for up to about 15 seconds. If three record messages have been recorded, the Record
message does not function. Similarly, when three videophone messages have been recorded,
the Videophone message does not function. Delete unnecessary record messages or
videophone messages.

When the Public mode (Drive mode) is set, the Record message/Videophone message dose

ˎ

not operate.

1

Press for over a second in the stand-by display.

The Record message/Videophone message is set and “ ”/“ ” appears.

To cancel the Record message/Videophone message

Press for over a second in the stand-by display. The Record
message/Videophone message is canceled.

When you are outside of the service area, the Record message does not function. Use the

●

Voice Mail Service (Paid).

When Receiving a Call

Ｐｌａｙ ａｎｓｗｅｒ ｍｅｓｓａｇｅ

ドコモ一郎

The answering message is played back to the caller after the ring tone
sounds for the set duration.

To talk to the caller

Press .

When you receive a videophone call

The answering message is played back and the answering image is
displayed to the caller. Press
press

(Sub), you can answer the call with a substitute image.

(V.phone) to talk to the caller. If you

72

Ｎｅｗ Ｒｅｃｏｒｄ ｍｓｇ

Notification
icon

Tex t
information

The notification icon “

” (New Record msg) or “ ” (New V.phone msg)

appears in the stand-by display.

To display the text information

Press (Link) in the stand-by display and move the cursor to “ ”
or “

”.

To play back a record message/videophone message

Press (Link) in the stand-by display and select “ ” or “ ”.

To delete the notification icon

Press for over a second. “ ” or “ ” also disappears when the
record message/videophone message is played back.

Setting the Operation of the Record Message

1

Press in the stand-by display, select [Set rec msg], and press .

Ｓｅｔ ｒｅｃｏｒｄ ｍｅｓｓａｇｅ

Ｓｅｔ 

Ｔｏ ａｎｓｗｅｒ 

Ａｎｓｗｅｒ ｉｍｇ（Ｖ．ｐｈｏｎｅ）
    テレヒ゛
Ｒｅｃｏｒｄ ｉｍｇ（Ｖ．ｐｈｏｎｅ）
    テレヒ゛

2

Enter the time before starting the answering message at [To answer].

Enter from 000 to 120 seconds.

3

Select an image to be sent when answering a call from My picture of the Data
Box at [Answer img(V.phone)].

You can set the following files.

ˎ

※

4

Select an image to be sent when recording the caller’s image from My picture
of the Data Box at [Record img(V.phone)].

You can set the following files.

ˎ

※

5

Press (Complete).

The operation of the Record message is set.

When the Voice Mail or Call Forwarding Service and the Record message are set

●

simultaneously, and if you want to give priority to the Record message, set the time before
starting the answering message for the Record message shorter than the ring time for the
Voice Mail or Call Forwarding Service.

 ＯＦＦ

   ０１３ ｓｅｃ

 （０００−１２０）

電話動作中

電話動作中

Category File format File size Image size

My picture GIF/JPEG Max. 50K bytes Max. [QCIF(W176×H144)]

You cannot set an image with file restrictions or a frame image.

Category File format File size Image size

My picture GIF/JPEG Max. 50K bytes Max. [QCIF(W176×H144)]

You cannot set an image with file restrictions or a frame image.

Voice/Videophone Calls

73

Recording a Caller’s Message When Unable to Answer a Call Just Receiving

<Quick record message>

You can start the Record message for temporary use when you receive a voice or
videophone call even if the Record message is [OFF].

If three record messages are recorded when the FOMA terminal receives a voice call, the

Voice/Videophone Calls

ˎ

Quick record message function cannot be operated. Similarly, if three videophone messages
are recorded when it receives a videophone call, the Quick record message function cannot be
operated.

1

Press while receiving a call.

Ｐｌａｙ ａｎｓｗｅｒ ｍｅｓｓａｇｅ

ドコモ一郎

The answering message is played back to the caller.

To talk to a caller

Press .

When you receive a videophone call

The answering message is played back and the answering image is
displayed to the caller. Press
press

(Sub), you can answer the call with a substitute image.

(V.phone) to talk to the caller. If you

Playing Back/Deleting a Record Message/Videophone Message/Voice Memo

You can play back or delete a recorded record message/videophone message and
voice memo (P.365).

Playing Back a Record Message/Videophone Message/Voice Memo

Example: Playing back a record message

1

Press in the stand-by display, select [Play rec msg], and press .

Ｐｌａｙ ｒｅｃｏｒｄ ｍｅｓｓａｇｅ

 ２／１２  ９：３５

 ドコモ一郎

２／ ５ ２２：００
Ｕｓｅｒ Ｕｎｓｅｔ
 ２／ ５  ７：５０

 携帯あき子

2

Select a record message and press (Play).

Ｐｌａｙ ｒｅｃｏｒｄ ｍｅｓｓａｇｅ

 ２／１２  ９：３５

 ドコモ一郎

To play back a videophone message

Press in the stand-by display and select [Play Vphone msg].

To play back a voice memo

Press in the stand-by display and select [Play voice memo].

To display phone numbers

When saved in the Phonebook, the name and phone type of a caller
are displayed instead of the phone number. Press

to switch the
display temporarily between names and phone numbers. The display
is not switched when a voice memo is displayed.

The record message is played back.

To stop the playback

Press (Stop).

To play back the previous/next record message

Use during playback to play back the previous record message
and

during playback to play back the next record message.

74

Deleting a Record Message/Videophone Message/Voice Memo

You can record up to three record messages, three videophone messages, and three
voice memos. Delete unnecessary record/videophone messages or voice memos.

Example: Deleting a record message

1

Press in the stand-by display, select [Play rec msg], and press .

To delete a videophone message

Press in the stand-by display and select [Play Vphone msg].

To delete a voice memo

Press in the stand-by display and select [Play voice memo].

To delete all record messages

From the Function menu, select [Delete all], enter the Security code, and select [Yes].

2

Select a record message and press (Func).

The Function menu appears.

3

Select [Delete one] → [Yes] and press .

The selected record message is deleted.

Using Chara-den

When you place a videophone call, you can send a character instead of a camera
image. You can press keys on the keypad to move a character or some character’s
mouth to correspond to the voice on the microphone.

For details about the action lists of the preinstalled Chara-den characters, see P.298.

ˎ

1

Press ( ) in the stand-by display, select [Chara-den], and press .

The Chara-den list appears.

2

Select a Chara-den file, press (Func), select [Call Chara-den], and press

.

The screen for selecting the method of entering the phone number appears.

3

Select the method, press , and enter the phone number.

4

Press (V.phone).

The videophone call is dialed with a Chara-den character set as the
substitute image.

To switch between the full-body action and parts action modes

Press (Change).

To display the action list

Press (List).

To switch to the mode for sending touch-tones (DTMF)

From the Function menu, select [DTMF send mode].

To switch to the Chara-den action operating mode

©SEGA

When the mode for sending touch-tones (DTMF) is set, the Chara-den action cannot be

●

operated.

From the Function menu, select [Action input mode].

Voice/Videophone Calls

75

Setting the Videophone Operation

<Videophone setting>

Setting the Display to Be Used in a Videophone Call

You can set the image to be displayed on the videophone images (Large) and (Small)

Voice/Videophone Calls

during a videophone call.

1

From the Menu, select [Settings] → [Call] → [Videophone] → [Display
setting] and press .

[Main-Other side] :

[Main-My side] :

[Other side only] :

[My side only] :

2

Select a display method and press .

The Display setting is set.

Display the recipient’s/caller’s image on the videophone image (Large)

and your image on the videophone image (Small).

Display your image on the videophone image (Large) and the recipient’s/

caller’s image on the videophone image (Small).

Display the recipient’s/caller’s image only on the videophone image

(Large).

Display your image only on the videophone image (Large).

Setting a Video to Be Sent to the Recipient/Caller

You can set whether to send a camera image to the recipient when you place a
videophone call. You can also set an image from either My picture or Chara-den as a
substitute image if you do not want to send a camera image.

1

From the Menu, select [Settings] → [Call] → [Videophone] → [Set outgoing
image] and press .

Ｓｅｔ ｏｕｔｇｏｉｎｇ ｉｍａｇｅ

Ｃａｍｅｒａ ｉｍａｇｅ   ＯＮ

Ｓｕｂｓｔｉｔｕｔｅ ｉｍａｇｅ

アイアイ

76

2

Select [ON]/[OFF] at [Camera image].

[ON] :

Send a camera image to the recipient when you place a videophone call.

[OFF] :

Send a substitute image to the recipient when you place a videophone call.

3

Select a substitute image from My picture/Chara-den of the Data Box at
[Substitute image].

You can set the following files.

ˎ

Category File format File size Image size

My picture GIF/JPEG Max. 50K bytes Max. [QCIF(W176×H144)]
Chara-den

You cannot set an image with file restrictions or a frame image.

※

The Set outgoing image is set.

−

Max. 100K bytes

−

Setting the Videophone Image Quality

You can set the quality of an image to be sent to the recipient.

1

From the Menu, select [Settings] → [Call] → [Videophone] → [Visual
preference] and press .

[Prefer img qual] :

[Normal] :

[Prefer motion] :

2

Select the quality of an image to be sent and press .

The Visual preference is set.

Send an image with priority on image quality.
Send an image by keeping a balance between image quality and

movement.

Send an image with priority on movement.

Redialing by Voice Call When the Videophone Is Not Connected

When the videophone call is not connected, the FOMA terminal automatically redials
by voice call. When the videophone call is connected successfully, the FOMA terminal
does not redial by voice call.

1

From the Menu, select [Settings] → [Call] → [Videophone] → [Auto
redial(voice)] and press .

[ON] :

Redial by voice call.

[OFF] :

Do not redial by voice call.

2

Select [ON]/[OFF] and press .

The Auto redial(voice) is set.

You are charged for a call instead of digital communication when you redial by voice call.

●

Using the Hands-free Function

You can set whether to use the hands-free function during a videophone call.

1

From the Menu, select [Settings] → [Call] → [Videophone] → [Hands-free]
and press .

[ON] :

You hear the recipient’s/caller’s voice from the speaker during a videophone call.

[OFF] :

You hear the recipient’s/caller’s voice from the earpiece during a videophone call.

2

Select [ON]/[OFF] and press .

The Hands-free is set.

When the Flat-plug Earphone/Microphone with Switch (optional) is connected to the FOMA

●

terminal, you hear a recipient’s voice from the Earphone/Microphone, regardless of the
Hands-free setting.

Voice/Videophone Calls

Continued

77

Setting How to Answer a Videophone Call during i-mode

You can set how to answer a videophone call received during i-mode or packet
communication, for example, sending or receiving mail.

Voice/Videophone Calls

1

From the Menu, select [Settings] → [Call] → [Videophone] → [V.ph while
packet] and press

[Prefer V.phone] :

[Prefer packet] :

[V.ph voicemail] :

[Call forwarding] :

2

Select the operation to be performed when you receive a videophone call
during i-mode communication and press .

The V.ph while packet is set.

.

Receive a videophone call. When you answer the videophone call, the

packet communication in progress is disconnected.

Continue the packet communication without receiving a videophone call.

The received call is saved in the Received record.
Connect a received videophone call to the Voice Mail Service Center.
Connect a received videophone call to a forwarding phone number.

Setting Notice for Switching between Voice and Videophone Calls

<Videophone switch notice>

You can set whether to notify the recipient/caller that the FOMA terminal is capable of
switching between voice and videophone calls.

You cannot perform this setting when you are outside of the service area or in a place where

ˎ

radio waves do not reach, or during a voice or videophone call.

1

From the Menu, select [Settings] → [Management] → [NW Services] → [V.ph
switch notice] and press .

Ｖ．ｐｈ ｓｗｉｔｃｈ ｎｏｔｉｃｅ

Ｉｎｄｉｃａｔｉｏｎ ＯＮ

Ｉｎｄｉｃａｔｉｏｎ ＯＦＦ
Ｃｈｅｃｋ ｓｅｔｔｉｎｇ

2

Select [Indication ON] → [Yes] and press .

When you do not want to notify

Select [Indication OFF] → [Yes].

To check the setting

Select [Check setting].

78

PushTalk

What is PushTalk? ..................................................................................................... 80

Originating a PushTalk Call ....................................................................................... 82

Adding a Member during PushTalk Communication .................................................. 83

Receiving a PushTalk Call ......................................................................................... 84

Saving Data in the PushTalk Phonebook .................................................................. 85

Originating a PushTalk Call Using the PushTalk Phonebook .................................... 87

Deleting a PushTalk Phonebook Entry ...................................................................... 88

Using the PushTalk Phonebook ...........................................................

Setting the PushTalk Operation .......................................................

<PushTalkPlus>

<PushTalk setting>

89

89

79

What is PushTalk?

You can communicate among several persons (up to five persons including yourself)
with a simple operation of pressing
recipients, and pressing

. Every time you press (speak), you are charged for

to display the PushTalk phonebook, selecting

PushTalk communication.

For more details on PushTalk or compatible models, see the DoCoMo’s website or “Mobile

PushTalk

ˎ

Phone User’s Guide 【Network services】”.

PushTalkPlus

The PushTalkPlus is a service that allows you to communicate simultaneously with up to 20
persons (including yourself). It also allows you to use PushTalk more conveniently by using the
shared phonebook on the network or checking the status of members.

For details about operations, see the general information which you are handed when you

※

subscribe to the service.

You need to subscribe to PushTalkPlus separately.

※

Using the Display during PushTalk Communication

: During PushTalk communication



: Hands-free ON





Active speaker



The phone number (or the member name when the speaker





is saved in the Phonebook) appears



Myself] : You are currently the active speaker (you

[

can speak)



User Unset] : The Caller ID of the caller is set to [OFF]

[

?] : The active speaker is not identified

[

No indication) : There is no active speaker (open status)

(

Group name



Displayed only in the display of the caller who originated a



call using a group

Members



The phone number (or the member name when the member



is saved in the Phonebook) appears

User Unset] : The Caller ID of the caller is set to [OFF]

[

Communication status



Connected : The caller who originated a PushTalk call
Connected : Currently participating in the PushTalk

communication
Calling※ : The recipient’s terminal is ringing
Disconnect※ : The recipient ended the PushTalk

session, does not answer the call, or is

outside of the service area. Otherwise

the recipient’s terminal is powered off
Driving※ : Public mode (Drive mode) is set

These icons appear only when PushTalk communication

※

is performed among several persons.

Ｏｎ ＰｕｓｈＴａｌｋ

  ドコモ一郎

 ○○○同好会

ドコモ一郎   
ドコモ三郎



ドコモ二郎   
０９０ＸＸＸＸＸＸＸＸ



Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ
 Ｄｉｓｃｏｎｎｅｃｔ

Ｃａｌｌｉｎｇ

80

Operations during PushTalk Communication

Operation Key operation

Speak When the floor is open, you can speak only while you press and

Add a member Press

Switch ON/OFF of the
hands-free operation
Adjust the volume of the
caller’s voice
Terminate a PushTalk call Press

Receive a voice call Press

Each speech session granted by obtaining the floor is time limited. The obtained floor is

●

released after the time limit. The PushTalk communication is terminated if no member takes
over the floor within a certain interval.

When there is any change in PushTalk communication status or a member takes over the

●

floor, the signal tone sounds.

You cannot use i-mode during PushTalk communication.

●

When other functions are activated, you cannot obtain the floor. However, when you activate

●

a function while you have the floor, you can speak while you press and hold

When you receive a videophone call, data communication, or a PushTalk call during

●

PushTalk communication, a new call is saved in the Received record and the current
PushTalk call is continued.

hold

.
While another member has the floor, you cannot get it even if you
press

PushTalk call.
Press
switched.
Press

If you receive a voice call, the PushTalk communication is terminated.
The operation for an incoming voice call while using PushTalk can be
customized (P.90).

.

(Add). This operation is enabled only when you originate a

( ). Every time you press the key, the ON/OFF setting is

.

.

(P.65).

.

PushTalk

81

Originating a PushTalk Call

You cannot originate a PushTalk call during a voice call, a videophone call, or data

ˎ

communication, or while the B mode is set in 2in1.

If you originate a PushTalk call during i-mode communication, the i-mode communication is

ˎ

terminated. Originating a PushTalk call while running i-αppli also stops the i-αppli.

Number B of 2in1 cannot be used for PushTalk and PushTalkPlus services.

ˎ

PushTalk

1

Enter a phone number in the stand-by display.

2

Press .

Ｄｉａｌｉｎｇ ＰｕｓｈＴａｌｋ

０９０ＸＸＸＸＸＸＸＸ

When you originate a PushTalk call, it is switched to the hands-free
operation that allows you to hear the signal tone from the speaker.

Ｃｏｎｎｅｃｔｅｄ

To speak

Press while the floor is open. You can speak while you press and
hold

.

Ｏｎ ＰｕｓｈＴａｌｋ

 Ｍｙｓｅｌｆ

０９０ＸＸＸＸＸＸＸＸ

3

Press to end the communication.

You cannot use PushTalk to place a call to emergency numbers (110, 119, and 118).

●

You cannot set whether to notify the caller ID when you originate a PushTalk call even if you

●

add “186/184”.

The setting whether to originate a PushTalk call with/without the caller ID follows the setting

●

of the Set Notification (P.45).

When you set the Set Notification to [Notify], all members including added members are

●

notified the phone numbers of the person who originates and all members. When you set
it to [Not notify], [User Unset] is displayed in the fields of the speaker and all members
including added members.

If you set [Call with ID]/[Call without ID] of the caller ID at the Option call display when you

●

originate a PushTalk call, the phone numbers of yours and all members are/are not notified
to all members based on the selected call condition.

When you originate a PushTalk call, if the Set Notification is set as well as the Call condition

●

is set at the Option call display, the following priority is applied.

1. Call condition selected at the Option call display when originating a PushTalk call



2. Set Notification



82

Originating a PushTalk Call from the Call Record

You can originate a PushTalk call using the Redial and Received records.

You cannot originate a PushTalk call using the call records of Number B when 2in1 is used.

ˎ

Example: Originating a PushTalk call from the Received record

1

Press ( ) in the stand-by display.

The Received record display appears.

2

Select a received record and press .

When a PushTalk call is originated, the signal tone sounds.

If a member is disconnected during PushTalk communication among several persons, the

●

disconnected member can come back to the session using the Redial/Received record as
long as the other members continue it. When the PushTalk communication is already ended,
the call is going to be a new one.

Adding a Member during PushTalk Communication

If you originate a PushTalk call, you can add a member during PushTalk
communication.You can add members up to the maximum number allowed for
communication (up to five persons including yourself) and also place a second call to
a non-participating member.

Example: Selecting a member from the PushTalk phonebook

1

Press (Add) during PushTalk communication.

The screen for selecting the method of adding a member appears.

[View PushTalk PB] :

[View phonebook] :

[Direct input] :

2

Select [View PushTalk PB] and press .

Ｍｅｍｂｅｒ

携帯あき子

携帯なつ子
携帯はる子

ドコモ一郎
ドコモ二郎

Select a member from the PushTalk phonebook.
Select a member from the FOMA terminal phonebook.
Enter a phone number directly.

To select a member from a group

Press (Group) and select a group.

PushTalk

3

Select a member and press .

“ ” appears for the selected member.

4

Press (Complete).

The Members to add display appears.

5

Press (Call).

Ｏｎ ＰｕｓｈＴａｌｋ

 Ｍｙｓｅｌｆ

携帯あき子   
ドコモ一郎   
ドコモ二郎   
携帯はる子

The FOMA terminal starts calling the selected member.

Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ
 Ｃａｌｌｉｎｇ

Continued

83

Members added during PushTalk communication are not displayed in the detailed

●

information of the Redial/Received record.

You can add a party who uses a PushTalk-compatible model, as a PushTalk group member.

●

However, this added member is not displayed on the displays of non-compatible models
and the signal tone does not sound either.

Receiving a PushTalk Call

PushTalk

When you receive a PushTalk call, you are notified by flashing indicator, ring tone,
vibrator, etc. The operation for an incoming PushTalk call varies depending on the
settings of the Incoming set, Manner mode, etc.

If you receive a PushTalk call during a voice call, the PushTalk call is not connected. The

ˎ

notification icon of missed call appears and the call is saved in the Received record. A
PushTalk call received during a videophone call or data communication is not connected,
either. The call is not saved in the Received record.

When receiving a PushTalk call during i-mode communication, the setting for the i-mode arrival

ˎ

act is applied.

1

When you receive a PushTalk call, press or .

ＰｕｓｈＴａｌｋ Ｇｒ ｃａｌｌ

 ドコモ一郎

ドコモ三郎
 ドコモ二郎

０９０ＸＸＸＸＸＸＸＸ

When the call is answered, it is switched to the hands-free operation that
allows you to hear the recipient’s voice from the speaker.

When you do not want to answer the call

Press .

Ｏｎ ＰｕｓｈＴａｌｋ

  ドコモ二郎

ドコモ一郎    
ドコモ三郎    
ドコモ二郎    
０９０ＸＸＸＸＸＸＸＸ

The names of the members appear. If the member is not saved in the
Phonebook, this member’s phone number appears instead.

When the person who originates a PushTalk call sets the Set

ˎ

Ｃｏｎｎｅｃｔｅｄ
Ｃｏｎｎｅｃｔｅｄ
Ｃｏｎｎｅｃｔｅｄ
Ｃａｌｌｉｎｇ

Notification to [Notify], all members including added members are
notified the phone numbers of the person who originates and all
members. When the person sets it to [Not notify], all members are
displayed as [User Unset].

To speak

Press while the floor is open. You can speak while you press and
hold

2

Press to end the communication.

You can answer a PushTalk call by pressing (Answer) instead of or . When

●

you set the Any key answer to [ON], you can also press

.

to , , or to answer
a PushTalk call (P.67). When the Slide open setting is set to [Calling], you can answer a
PushTalk call just by opening the FOMA terminal (P.67).

A PushTalk call cannot be put on hold.

●

When you receive a PushTalk call originated from a caller who is saved as a nuisance caller,

●

the call is rejected. The notification icon of missed call appears and the call is saved in the
Received record.

84

Saving Data in the PushTalk Phonebook

You can save up to 1,000 members in the PushTalk phonebook.
Members you want to save in the PushTalk phonebook must be also saved in the
FOMA terminal phonebook. You can save only one phone number in the PushTalk
phonebook for each FOMA terminal phonebook entry. The name of a member
displayed in the PushTalk phonebook is diverted from that saved in the FOMA
terminal phonebook.

When 2in1 is set to the B mode, you cannot save data in the PushTalk phonebook.

ˎ

When 2in1 is set to the Dual mode, you cannot save the phonebook data for which the

ˎ

Phonebook 2in1 setting is set to [B] in the PushTalk phonebook.

When 2in1 is set to the A mode, the member for which the Phonebook 2in1 setting is set to [B]

ˎ

is not displayed.

1

Press in the stand-by display and press (Func).

The Function menu appears.

2

Select [Create] and press .

The screen for selecting the saving method appears.

[View phonebook] :

[Direct input] :

3

Select [View phonebook] and press .

The FOMA terminal phonebook appears.

4

Select an entry → a phone number and press .

Ｄｅｔａｉｌ Ｓｅｔｔｉｎｇ

Ｂａｓｉｃ

ドコモ太郎

０１５

０９０ＸＸＸＸＸＸＸＸ

Select from the FOMA terminal phonebook.
Save new data in the FOMA terminal phonebook and then save it in the

PushTalk phonebook.

Follow the same steps as in “Add to FOMA terminal phonebook” (P.95,

ˎ

step 3 to 6).

The phone number is saved in the PushTalk phonebook and “ ” appears
in the entry in the FOMA terminal phonebook.

PushTalk

When you save a person saved as Secret in the FOMA terminal phonebook in the PushTalk

●

phonebook, the entry is not displayed in the PushTalk phonebook. To display the name, set
the Secret display to [ON] (P.141).

Setting a Group

You can originate a PushTalk call to several recipients by saving them in a group as
members beforehand.
You can save up to 20 groups in the PushTalk phonebook, 19 members for each
group.

Continued

85

Saving a Group

1

Press in the stand-by display and press (Func).

The Function menu appears.

2

Select [Group setting] and press .

PushTalk

The Group setting display appears.

To display group numbers

When saved, group icons are displayed instead of group numbers. Press to switch
the display temporarily between group icons and group numbers.

3

Select a group and press .

Ｅｄｉｔ ｇｒｏｕｐ ３

Ｇｒｏｕｐ ｎａｍｅ

   グループ

３

Ｉｃｏｎ

4

Enter a group name at [Group name].

Enter a group name within 10 full-width or 21 half-width characters.

5

Select a group icon at [Icon].

6

Press (Complete).

The group is saved in the PushTalk phonebook.

Saving a Member to a Group

1

Press in the stand-by display and press (Group).

The Group list display appears.

2

Select a group and press .

The Member list display of the selected group appears.

3

Press (Edit).

Ｓｅｌｅｃｔ ｍｅｍｂｅｒ

    ４／１９

携帯あき子

携帯なつ子

携帯はる子
ドコモ一郎
ドコモ二郎

86

4

Select a member and press .

“ ” appears on the selected member.

To cancel all selections

Press (Rel all).

5

Press (Complete).

The selected member is saved in the group.

Originating a PushTalk Call Using the PushTalk Phonebook

If you save persons as members in the PushTalk phonebook, you can originate a
PushTalk call to several persons.

When 2in1 is set to the B mode, you cannot use the PushTalk phonebook.

ˎ

When 2in1 is set to the Dual mode, you cannot use members for which the Phonebook 2in1

ˎ

setting is set to [B].

1

Press in the stand-by display, select a member, and press .

Ｍｅｍｂｅｒ

携帯あき子

携帯なつ子

携帯はる子
ドコモ一郎
ドコモ二郎

2

Press .

Ｄｉａｌｉｎｇ ＰＴ ｇｒｏｕｐ

携帯あき子
 携帯はる子
 ドコモ一郎
 ドコモ二郎

“ ” appears for the selected member.

To display phone numbers

Press to switch the display temporarily between names and
phone numbers.

When a PushTalk call is originated, the signal tone sounds.

PushTalk

Ｏｎ ＰｕｓｈＴａｌｋ

 Ｍｙｓｅｌｆ

携帯あき子   
携帯はる子   
ドコモ一郎   
ドコモ二郎

3

Press to end the communication.

Ｃａｌｌｉｎｇ
 Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ

To speak

Press while the floor is open. You can speak while you press and
hold

.

Originating a PushTalk Call from the Group

1

Press in the stand-by display and press (Group).

Ｇｒｏｕｐ

 ○○○同好会

△△△クラブ
 ○△○愛好会
 グループ
 グループ
 グループ
 グループ
 グループ
 グループ
 グループ
 グループ
 グループ

４
５
６
７
８
９
１０
１１
１２

To display group numbers

When saved, group icons are displayed instead of group numbers.
Press

to switch the display temporarily between group icons and

group numbers.

Continued

87

2

Select a group and press .

Ｄｉａｌｉｎｇ ＰＴ ｇｒｏｕｐ

○○○同好会
 携帯あき子

携帯はる子
 ドコモ一郎
 ドコモ二郎

PushTalk

When a PushTalk call is originated, the signal tone sounds.

To originate a call to specific members by selecting them from a group

Select a group → members and press .

Ｃａｌｌｉｎｇ
 Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ
 Ｃｏｎｎｅｃｔｅｄ

To speak

Press while the floor is open. You can speak while you press and
hold

.

Ｏｎ ＰｕｓｈＴａｌｋ

 Ｍｙｓｅｌｆ

 ○○○同好会

携帯あき子   
携帯はる子   
ドコモ一郎   
ドコモ二郎

3

Press to end the communication.

When originating a PushTalk call to a group, you can originate a call to up to four members

●

even if more than five members are saved in the group.

Deleting a PushTalk Phonebook Entry

You can delete members saved in the PushTalk phonebook using three methods.

Example: Deleting a member

1

Press in the stand-by display.

To delete several members

From the Function menu, select [Delete] → [Select&delete], select members, press

(Delete), and select [Yes]/[Delete from main].

To delete all members

From the Function menu, select [Delete] → [Delete all], enter the Security code, and select
[Yes]/[Delete from main].

When 2in1 is used, the screen informing to delete members of all modes of the

ˎ

Phonebook 2in1 setting appears. If you select [Yes], the members of all modes of the
Phonebook 2in1 setting are deleted.

To reset a group to the default setting

Press (Group), move the cursor to a group and from the Function menu, select [Reset
group] → [Yes].

2

Select a member and press (Func).

The Function menu appears.

3

Select [Delete] → [Delete one] → [Yes] and press .

The selected member is deleted.

To delete the selected member from the FOMA terminal phonebook

Select [Delete] → [Delete one] → [Delete from main].

88

Using the PushTalk Phonebook

<PushTalkPlus>

You can connect to the network and use the PushTalkPlus service (P.80).

To use the PushTalkPlus service, you must subscribe to this service.

ˎ

1

Press in the stand-by display and press (Func).

The Function menu appears.

2

Select [NW connection] → [Yes] and press .

The call is connected to the network.

PushTalk

Setting the PushTalk Operation

<PushTalk setting>

Setting Whether to Answer a Call Automatically

You can set whether to answer an incoming PushTalk call automatically using the
hands-free function.

1

From the Menu, select [Settings] → [Application] → [PushTalk] → [Auto
answer setting] and press .

[ON] :

A PushTalk call you receive is answered automatically using the hands-free function.

When the Manner mode is set, the call is not answered automatically.

[OFF] :

A PushTalk call you receive is answered by pressing

2

Select [ON]/[OFF] and press .

The Auto answer setting is set.

, , etc.

Setting the Ring Time

If you select [OFF] for the Auto answer setting, set the ring time of the PushTalk call.

1

From the Menu, select [Settings] → [Application] → [PushTalk] → [Set ring
time] and press .

Enter the ring time within 01 to 60 seconds.

2

Enter the Push Talk ring time.

The Set ring time is set.

Continued

89

Setting How to Answer a Voice Call during PushTalk Communication

You can set how to answer a voice call when you receive it during PushTalk
communication.

1

From the Menu, select [Settings] → [Application] → [PushTalk] → [P-Talk
arrival act] and press

PushTalk

[Answer] :

[Call Rejection] :

[Voice Mail] :

[Call Forwarding] :

2

Select the operation to be performed when you receive a voice call during

Receive a voice call and you can answer it.
Reject an incoming voice call. The missed call notification icon appears

and the call is saved in the Received record.
Connect an incoming voice call to the Voice Mail Service Center.
Connect an incoming voice call to a forwarding number.

.

PushTalk communication and press .

The P-Talk arrival act is set.

Setting Whether to Receive a PushTalk Call during i-mode

You can set whether to receive a PushTalk call by disconnecting i-mode if there is any
incoming PushTalk call during i-mode or i-mode communication.

1

From the Menu, select [Settings] → [Application] → [PushTalk] → [i-mode
arrival act] and press .

[Prefer PushTalk] :

[Prefer i-mode] :

2

Select the preferred function and press .

The i-mode arrival act is set.

Receive the PushTalk call and disconnect i-mode. After the PushTalk call

is finished, the previous display reappears.

Continue i-mode without receiving a PushTalk call. The missed PushTalk

call is not saved in the Received record.

Using the Hands-free Function

You can set whether to use the hands-free function during PushTalk communication.

1

From the Menu, select [Settings] → [Application] → [PushTalk] → [Hands­free] and press .

[ON] :

You hear a member’s voice from the speaker during PushTalk communication.

[OFF] :

You hear a member’s voice from the earpiece during PushTalk communication.

2

Select [ON]/[OFF] and press .

The Hands-free is set.

When the Flat-plug Earphone/Microphone with Switch (optional) is connected to the FOMA

●

terminal, you hear a member’s voice from the Earphone/Microphone, regardless of the
Hands-free setting.

When the FOMA terminal is opened while the Manner mode is set, you cannot answer a call

●

using the hands-free function regardless of the Hands-free setting.

90

Setting the Operation for the FOMA Terminal Being Closed during PushTalk Communication

You can end a call or switch a call to the hands-free operation by closing the FOMA
terminal during PushTalk communication. You can also continue the communication.

1

From the Menu, select [Settings] → [Management] → [Slide setting]
[Setting when folded] → [PushTalk] and press

[Continuous call] :

[Speaker call] :

[Finish] :

2

Select an operation when the FOMA terminal is closed during the

Continue the PushTalk communication.
You hear a member’s voice from the speaker during PushTalk

communication.

Hang up the PushTalk call.

.

communication and press .

The Setting when folded is set.

The Setting when folded is disabled when the Flat-plug Earphone/Microphone with Switch

●

(optional) is connected to the FOMA terminal and the call remains connected through the
Earphone/Microphone even if you close the FOMA terminal.

→

PushTalk

91

Phonebook

Phonebooks the FOMA Terminal Can Use ................................................................ 94

Saving an Entry in the FOMA Terminal Phonebook

Saving an Entry in the UIM Phonebook .................................

Saving the Redial/Received Record in the Phonebook ............................................. 99

Saving a Group ..................................................................................

Displaying the Phonebook ....................................................................................... 101

Searching the Phonebook .........................................................

Setting the Display of the Phonebook .......................................

Editing a Phonebook Entry .............................................................

Deleting a Phonebook Entry .......................................................

Checking the Number of Entries Saved ...........................................

Dialing Quickly to Frequently Called Numbers ....................................

Storing (Restoring/Updating) the Phonebook at the Data Security Service Center

<Add to FOMA terminal phonebook>

...

<Add to UIM phonebook>

<Group setting>

<Search phonebook>

<Phonebook setting>

<Edit phonebook>

<Delete phonebook>

<Memory status>

<2-touch dial>

<Data Security Service>

...

95

98

100

102

102

103

103

104

104

105

93

Phonebooks the FOMA Terminal Can Use

The FOMA terminal is equipped with two types of phonebooks, the FOMA terminal
phonebook, which you can set up with various functions, and the UIM (FOMA card)
phonebook, which can be used with other FOMA terminals. Use either phonebook to
your convenience.

You can also use the PushTalk phonebook dedicated for PushTalk that can be created using

ˎ

data saved in the FOMA terminal phonebook (P.85).

The table below shows the data you can save in each phonebook.

Phonebook

Data to be saved

Number of data
entries
Group You can sort entries in groups from Group 0

Phone number
to be saved

Mail address to
be saved

Image to be
saved

Other data to be
saved

Group to be
saved

You can use phonebook data saved in your UIM when this UIM is used on another FOMA

ˎ

terminal.

94

FOMA terminal phonebook UIM phonebook

You can save up to 1,000 entries. You can save up to 50 entries.

to 19.
You can save up to three numbers for each
phonebook entry and a total of up to 3,000
numbers in the Phonebook.
You can save one number for each
phonebook entry in the PushTalk phonebook.
You can select from nine types of icons, such
as [

Public] and [ Mobile1].

You can save up to three addresses for each
phonebook entry and a total of up to 3,000
addresses in the Phonebook.
You can also save one Secret code for each
address.
You can select from five types of icons, such
as [

Mobile1] and [ Home].

You can save one Des call display and one
Des substitute image for each phonebook
entry. You can save up to 1,000 each of still
image and Chara-den files in the Phonebook.
You can save one name, reading, memory
number, location information, postal code,
postal address, and birthday for each
phonebook entry.
You can also set one type of Des phone tone,
Des mail tone, Select phone Illum., Select
mail Illum., and Secret for each phonebook
entry.
You can save one group name and group
icon for each group.

You can also set one type of Des call display,
Des phone tone, Des mail tone, Select phone
Illum., and Select mail Illum. for each group.

You can sort entries in groups
from Group 0 to 10.
You can save one number for
each phonebook entry.

You cannot select icons. “
saved automatically.

You can save one address for
each phonebook entry.

You cannot select icons. “
saved automatically.

You cannot save images.

You can save one name and
reading for each phonebook
entry.

You can save one group name for
each group. You cannot change
a group name with [

]. You cannot select icons.

し

Unavailable

” is

” is

グループな

For the order of priority between call image, ring tone, and incoming indicator color, see P.111.

●

When you receive a call or mail from a person saved as Secret, the regular ring tone,

●

incoming image and incoming indicator color are used, and a name of the caller/sender is
not displayed. To enable the settings of a person saved as Secret or a group that includes a
person saved as Secret, set the Secret display to [ON].

When 2in1 is used, the phonebook is automatically switched to the available one according

●

to the 2in1 modes. When you save data in the phonebook, the Phonebook 2in1 setting is
automatically set according to a compatible 2in1 mode. You can also change the Phonebook
2in1 setting by each data or group (P.395).

Please note that when you change models and attempt to transfer the saved data to a new

●

mobile phone at our service counter (DoCoMo shop, etc.), you may not be able to copy it to
the FOMA terminal depending on the specifications of your new phone.

Phonebook

Saving an Entry in the FOMA Terminal Phonebook

<Add to FOMA terminal phonebook>

Up to 1,000 entries can be saved in the FOMA terminal phonebook.

1

Press ( ) in the stand-by display and press (Create).

2

Select [Main memory] and press .

Ｄｅｔａｉｌ

Ｂａｓｉｃ Ｓｅｔｔｉｎｇ

０００
   グループなし

  Ｐｕｂｌｉｃ

Ｍｏｂｉｌｅ１



ＯＦＦ



3

Save each item at the Basic display.

Icon Settings

Enter a name within 16 full-width or 32 half-width characters.
When entering a name, the reading is automatically entered.

ˎ

Enter a memory number from 000 to 999. The smallest available memory number is
automatically entered. Enter a name/phone number/mail address to change it.
Select a group. [
number/mail address to change it.
Enter within 26 digits per phone number. You can save the pause (P), timer (T), “+”,
“#”, and sub-address separator (

ˎ

Select a phone number type icon. [ Public] is automatically entered. Enter a
phone number to change it.
Enter within 50 half-width alphanumeric characters and symbols per mail address.

ˎ

Select a mail address type icon. [ Mobile1] is automatically entered. Enter a mail
address to change it.

To save an entry in the UIM phonebook

Select [UIM] (P.98).

To edit the reading, enter the reading within 32 half-width characters.

グループなし

] is automatically entered. Enter a name/phone

).

If a phone number is saved with the “184” or “186”, SMS cannot be sent to this

phone number even if you select it.

When sending mail to an i-mode terminal (including a Mova terminal), you need

to specify only the mail address portion before the @ mark.

Continued

95

Phonebook

4

Icon Settings

When the recipient saves a Secret code in a mail address (phone number@
docomo.ne.jp), enter the Secret code. When sending mail, the Secret code is
automatically added.

When you save a mail address as “phone number + Secret code@docomo.

ˎ

ne.jp” in the Phonebook, if you save a Secret code, you cannot send mail or
reply mail to this address. To avoid this problem, change the mail address to
“phone [e-mail]” and save a Secret code.

The Secret code is masked by “

ˎ

[ON], it is displayed in numbers.

To save your Secret code, see the “Mobile Phone User’s Guide 【i-mode】 FOMA

ˎ

version”.

Select [ON]/[OFF] of the Secret.

To display the entry saved as Secret, set the Secret display to [ON].

ˎ

”. Only when the Secret display is set to

＊＊＊＊

Press and save each item at the Detail display.

Icon Settings

Select an image from My Picture/i-motion of the Data Box or record a new one to
be used as the Des call display that is displayed when placing/receiving a voice
or videophone call, right after receiving mail, or when displaying the individual
Phonebook entry.

You can set the following files.

ˎ

Category File format File size Image size

My picture GIF/JPEG Max. 100K bytes Max. [QVGA(240×320)]
i-motion※MP4 Max. 10M bytes Max. [VGA(640×480)]

Some i-motion may not be set.

※

It may take time to display a large-sized image.

ˎ

To use an image after recording it by the camera, select [Camera]/[Movie] (P.155,

ˎ

167). You can record an image in the following sizes.

Still image Out-camera Max. [QVGA(240×320)]

Movie Max. [VGA(640×480)]

To specify no image, select [None].

ˎ

To check the image, move the cursor to an image and press

ˎ

Add the location information from the Position location, Location history, or image
(P.273). When the location information is saved, the message “Has loc. info”
appears.

Enter a postal code within seven half-width digits.

Enter a postal address within 64 full-width or 128 half-width characters.

Enter a birthday within the range from 1900/01/01 to 2050/12/31.

In-camera [QCIF(176×144)]

(Play).

96

5

Press and save each item at the Setting display.

Icon Settings

Select the Des substitute image to be sent during a videophone call from My
picture/Chara-den of the Data Box.

You can set the following files.

ˎ

Category File format File size Image size

My picture GIF/JPEG Max. 50K bytes Max. [QCIF(176×144)]
Chara-den

To specify no substitute image, select [None]. A substitute image or your own

ˎ

image set in the Set outgoing image (P.76) is sent.

−

Max. 100K bytes

−

Select a ring tone from MUSIC/i-motion/Melody of the Data Box to be used as the
Des phone tone/Des mail tone that sounds when receiving a voice or videophone
call and right after receiving mail.

You can set the following files. You can select a Chaku-Uta

ˎ

®

from [i-motion].

Category File format File size Image size

MUSIC

AAC-LC/

※

HE-AAC

Max. 5M bytes

−

i-motion※MP4 Max. 10M bytes Max. [VGA(640×480)]
Melody SMF/MFi Max. 350K bytes

Some files may not be set.

※

When you select a Chaku-Uta Full
ranges from [MUSIC], the screen for selecting a type of setting appears. If you
select [Full song], the entire track of Chaku-Uta Full

®

that has a choice of specified playback

®

you select [Point], the specified playback range of Chaku-Uta Full

−

is set for the ring tone. If

®

is set for the

ring tone.

To specify no ring tone, select [None].

ˎ

To mute the ring tone, select [Silent].

ˎ

To check the ring tone, move the cursor to the ring tone and press

ˎ

(Play).

Select a color for the Select phone/mail Illum. that flashes when receiving a voice or
videophone call and right after receiving mail. When you move the cursor to a color,
the incoming indicator flashes accordingly.

To specify no color, select [None].

ˎ

6

Press (Complete).

The entered data is saved in the FOMA terminal phonebook.

If you set [None] for the Des call display, Des phone/mail tone, or Select phone/mail

●

Illum., then the call image, ring tone, and indicator color saved for the Group setting are
automatically used for the respective function. If these settings are not saved in the Group
setting, the Incoming set (P.108) or Animation (P.120) is used.

If you set an i-motion with video and sound tracks for the Des mail tone, the i-motion image

●

appears when mail reception is completed.

If you set an i-motion for the Des call display, the image set for the Animation is displayed

●

when you place a voice or videophone call.

If you set an i-motion or Chaku-Uta Full® for the Des phone/mail tone or set an i-motion for

●

the Des call display, the settings may be changed in some cases.

Phonebook

97

Saving an Entry in the UIM Phonebook

Up to 50 entries can be saved in the UIM (FOMA card) phonebook.

1

Press ( ) in the stand-by display and press (Create).

2

Select [UIM] and press .

Phonebook

3

Ｂａｓｉｃ

   グループなし

Save each item.

Icon Settings

Enter a name within 10 full-width or 21 half-width characters. If you use a mixture of
full-width and half-width characters or half-width katakana characters for the name,
the number of characters that you can save is limited to 10 characters.
When entering a name, the reading is automatically entered.

ˎ

Select a group. When entering a name/phone number/mail address, group [

ループなし

Enter a phone number within 26 digits (20 digits for some types of UIM).
Enter a mail address within 50 half-width alphanumeric characters and symbols.

If you use symbols for the mail address, you may not be able to save up to the
maximum allowable number of characters.

ˎ

To save an entry in the FOMA terminal phonebook

Select [Main memory] (P.95).

To edit the reading, enter the reading within 12 full-width katakana characters or

25 half-width alphanumeric characters. If you use a mixture of full-width and half­width characters for the reading, the number of characters that you can save is
limited to 12 characters.

] is automatically entered.

When sending mail to an i-mode terminal (including a Mova terminal), you need

to specify only the mail address portion before the @ mark.

<Add to UIM phonebook>

グ

4

Press (Complete).

The entered data is saved in the UIM phonebook.

Data copied from the FOMA terminal phonebook or received using a function such as the

●

infrared or iC communication may not be saved correctly.

98
