Sonic WALL TELE 3 User guide
COMP REHEN SIV E IN TE R NE T SE C UR IT Y
™
S o n i c WALL T E L E 3
I N T E R N E T S E C U R I T Y A P P L I A N C E
Dedicated security ASIC for fast firewall
and 3DES VPN performance
IPSec VPN delivers secure access through
any IPSec-compliant VPN gateway
Easy management interface reduces
deployment time and costs
The TELE3 Internet security appliance is an easy-to-deploy, enterprise-class firewall and VPN connectivity
solution for telecommuters and day-extenders who require fast and secure access to their orga n i z a t i o n ’ s
n e t work resources.With its intuitive Web management interface and administration wizards, the T E L E 3
reduces the time and cost of installing and managing secure connectivity access.
The desktop TELE3 provides hardened firewall protection with an ICSA-cert i f i e d , stateful packet inspection
f i r ewall with integrated IPSec V P N . The TELE3 delivers fast, secure access to corporate resources and
is compatible with any manufacturer’s IPSec-compliant VPN gateway.
Built on SonicWALL's dedicated security A S I C , the TELE3 delivers the fastest performance in its class
with hardware-accelerated 3DES V P N . By offloading processing overhead associated with encry p t i o n ,
the security ASIC guarantees the best performance for broadband connections.
The TELE3 also supports the comprehensive portfolio of SonicWALL security serv i c e s , including Netwo r k
Anti-Virus, Content Filtering, and Authentication Service.This eliminates the cost and complexity of
integrating separate devices and software packages.
The TELE3 requires no operating system maintenance often found in
software-based security products. The TELE3 fits perfectly into a
l a r ge corporate network infrastructure and can be manage d
by a wide arr ay of local or remote options including CLI,
We b - i n t e r f a c e , and SNMP. For centralized manage m e n t
and policy setting, the SonicWALL Global Manage m e n t
System is designed to reduce administration ove r h e a d
as security requirements scale.
The TELE3 Internet security appliance meets the
demands of telecommuting programs and adapts to
network security threats, protecting an organization’s
valuable data.
S O N I C W A L L T E LE 3 F EAT U RE S A N D BE N EF I TS
S o n i c WALL T E L E 3
I N T E R N E T S E C U R I T Y A P P L I A N C E
IPSec V P N . The T E L E 3 ’s enterprise-class VPN delivers fast, secure access
to corporate resources and is compatible with any manufacturer’s
IPSec-compliant VPN gateway.
Comprehensive Security Solution. The TELE3 provides eve rything needed
for secure connectivity and supports SonicWA L L’s comprehensive port f o l i o
of security services, such as Network Anti-Virus Content Filtering , and
Authentication Serv i c e , without the need to install separate devices and
software packages.
I C S A - C e rtified Stateful Pa c ket Fi r e wa l l . The TELE3 adheres to industry
standards for enterprise-class firewall protection with ICSA-cert i f i e d ,s t a t e f u l
packet inspection technology.
Powerful A rchitecture with Dedicated Security A S I C . Built on SonicWA L L ' s
dedicated security A S I C , the TELE3 delivers breakthrough performance with
hardware-accelerated 3DES VPN.By offloading processing overhead
associated with encry p t i o n , the security ASIC guarantees the best possible
performance for broadband connections.
S O NI C W A L L T E LE 3 T E CH N IC A L SP EC I FI C AT I O N S
Processor: Toshiba-133MHz with
SonicWALL’s security ASIC
RAM: 16 MB
Flash Memory: 4 MB
Interfaces: (1) WAN
10/100 Base-T auto-sensing
(1) LAN
10/100 Base-T auto-sensing
(1) Serial Port
Firewall Performance: 75 Mbps
Firewall Nodes: 5 Nodes
Concurrent Connections: 6,000
3DES (168-Bit): 20 Mbps
VPN Tunnels: 5 Tunnels
Dimensions: 8.25 x 6.5 x 2.0 inches
Weight: 1.1 lbs. (.48 kg)
LEDs: Status (Power, Test)
AutoUpdate Security. S o n i c WA L L’s AutoUpdate service sends automatic
alerts of new software and feature updates as soon as they’re available
to ensure administrators keep network security current and lower
maintenance costs.
Flexible Remote Management. The TELE3 fits perfectly into a large
corporate network infrastructure and reduces administration overhead
because it can be managed locally, on a device-by-device basis using
CLI,or globally using SonicWALL Global Management System.
Complete Network Protocol Support. The TELE3 supports the full
complement of broadband connectivity requirements, including NAT and
D H C P, to allow all users to share a broadband Internet connection. It also
supports Point-to-Point Protocol over Ethernet (PPPoE),a widely used
protocol for DSL connections.
Intuitive Web Management Interface. The TELE3 includes an easy-to-use
Web management interface and administration wizards to dramatically
reduce the time and cost of deploying secure connectivity.
Power: 100V to 240V AC
(20.9 x 16.5 x 5.1 cm)
Ethernet (Link,100,Activity)
Standards: TCP/IP, UDP, ICMP, HTTP, RADIUS,
Certifications: ICSA Firewall
Regulatory Compliance: EMC: FCC Class B,ICES-003 B,
Environment: Temperatures 40-105º F,5-40º C
IPSec,IKE,SNMP, FTP, DHCP,
PPPoE
CE,VCCI B,C-Tick
Safety: UL,cUL,TUV/GS
Humidity 5-90% non-condensing
1) Power LED
2) WAN Port LEDs
3) LAN Port LEDs
4) Test LED
1 2 3 4 65 7
SONICW A L L TELE3 P ROD U C T PART N U M BERS
01-SSC-2910 SonicWALL TELE3 (US/Canada)
01-SSC-2911 SonicWALL TELE3 (International)
01-SSC-2912 SonicWALL TELE3 (Japan)
SO NI C W A L L VAL U E -A DD E D S E C U R I T Y S ERV I C E S
S o n i c WALL Internet security appliances integrate seamlessly
with an expanding array of value-added security services
to provide a comprehensive security solution.
SonicWALL,Inc.
1143 Borregas Avenue
Sunnyvale,CA 94089-1306
© 2002 SonicWALL, I n c .SonicWALL is a registered trademark of SonicWALL, I n c .Other product and company names mentioned herein may be
t rademarks and/or registered trademarks of their respective companies. Specifications and descriptions subject to change without notice.
DS_1002_TELE3
T: 408.745.9600
F: 408.745.9300
For more information on these SonicWALL security serv i c e s ,
please visit our Web site at
w w w. s o n i c w a l l . c o m / p r o d u c t s / s e rv i c e s . a s p
www.sonicwall.com
5) Serial Port
6) 10/100 Ethernet
Ports LAN, WAN
7) Power Input
SonicWALL's ICSA-certified Internet
security appliances consistently receive awa rds
from industry-leading publications.
