SONAMP® DSP AMPLIFIERS
DSP 2-150 MKII, DSP 8-130 MKII & DSP 2-750 MKII
MULTI-CHANNEL POWER AMPLIFIERS
Product Overview
Building on the legacy of the SONAMP 260, the industry’s first
purpose-built distributed audio amplifier, Sonance is pleased to
announce the next generation of class-leading amplifiers. The new
DSP amplifier line delivers game changing features, audiophile
grade circuitry, robust power and unrivaled installation flexibility.
Features and Benefits
• High resolution 24 bit/96 kHz processing DAC capable of
4608 KBPS audio playback.
• IP and IR controllable via for the ultimate in
installation flexibility.
• Powerful, audiophile grade Class-D amplification, rated and
certified at 8 and 4 ohms & stable to 2 ohms.
• Compact form factor allows for space savings in the
equipment rack with ample power to the speakers.
• Class-D design is 93% efficient for maximum power
output with minimal power usage. Meets EU power
saving standards.
• Terminal blocks will accept up to 12AWG speaker cable for
longer runs and higher performance.
At the heart of the SONAMP DSP amplifier is the
(Sonance Advanced Room Correction) web interface featuring 50+
Sonance designed DSP presets, preloaded for effortless DSP
without the need for additional hardware or calibration. A built in
10-band parametric EQ allows for additional DSP customization.
• Full array of input/output connectivity for maximum
installation flexibility: Line input/loop outputs; IP, IR, audio
and voltage triggers; Ethernet jack for network connectivity.
• Bridgeable channels for applications when even more power
is required.
• Certified to worldwide safety standards.
(TUV to UL standards, CE, RCM, C-Tick, RoHS, WEEE).
Meets FCC standards.
• Rack ears and removable feet included.
• Digital Input Module compatible
DSP 2-150 MKII
DSP 8-130 MKII
DSP 2-750 MKII
DSP 2-150 MKII Dimensions
Dimensions with Feet
Width: 8 5/8” (219mm)
Height: 2 1/8” (54mm)
Depth: 16 13/16” (427mm)
Dimensions with Rack Ears & without Feet
Width: 19” (482mm)
Height: 1 3/4” (44mm)
Depth: 16 13/16” (427mm)
Depth
Width w/ Rack Ears
Width
Height w/o Feet
Height w/o Feet
DSP 2-150 MKII
Width w/ Rack Ears
DSP 2-150 MKII DSP 2-150 MKII
(2) DSP 2-150 amplifiers shown
with optional Rack Mount Bracket
Height w/ Feet
DSP 2-150 MKII DSP 2-150 MKII
DSP 2-150 MKII
DSP 2-150 MKII
DSP 2-150 MKII
DSP 2-150 MKII
Shown with optional Rack Mount Bracket
SPECIFICATIONS
Number of Channels
SPECIFICATIONS
UOM
SKU
Frequency Response
Total Harmonic
Distortion (THD):
(1kHz) @ 8 ohms
(1kHz) @ 4 ohms
Rack Space
Requirement
Dimensions w/ Feet
(W x H x D)
Dimensions w/ Rack Ears
w/o Feet (W x H x D)
AC Voltage
AC Fuse
Shipping Weight
Power Output (RMS):
RMS per channel
@ 8 ohms
RMS per channel
@ 4 ohms
RMS per channel
Bridged @ 8 ohms
DSP 2-150 MKII
SKU
UOM
Number of Channels
Power Output (RMS):
RMS per channel
@ 8 ohms
RMS per channel
@ 4 ohms
RMS per channel
Bridged @ 8 ohms
Frequency Response
Total Harmonic
Distortion (THD):
(1kHz) @ 8 ohms
(1kHz) @ 4 ohms
AC Voltage
AC Fuse
Dimensions w/ Feet
(W x H x D)
Dimensions w/ Rack Ears
w/o Feet (W x H x D)
93378
Each
2 (1 stereo pair)
150 Watts
(2 channels driven)
224 Watts
(2 channels driven)
473 Watts
5Hz – 50kHz
0.07%
0.06%
100-120V@60Hz,
220-240V@50Hz
5A (T5-AL ~ 250V)
8 5/8” x 2 1/8” x 16 13/16”
(219mm x 54mm x 427mm)
19” x 1 3/4” x 16 13/16”
(482mm x 44mm x 427mm)
Rack Space
Requirement
Shipping Weight
1U
11 lbs (5.0kg)
DSP 8-130 MKII Dimensions
Dimensions with Feet
Width: 17 1/4” (438mm)
Height: 2 1/8” (54mm)
Depth: 16 13/16” (427mm)
Dimensions with Rack Ears & without Feet
Width: 19” (482mm)
Height: 1 3/4” (44mm)
Depth: 16 13/16” (427mm)
Depth
Width w/ Rack Ears
Width
Height w/o Feet
DSP 8-130 MKII
DSP 8-130 MKII
DSP 8-130 MKII
Height w/ Feet
DSP 8-130 MKII
SPECIFICATIONS
DSP 8-130 MKII
SKU
UOM
Number of Channels
Power Output (RMS):
RMS per channel
@ 8 ohms
RMS per channel
@ 4 ohms
RMS per channel
Bridged @ 8 ohms
Frequency Response
Total Harmonic
Distortion (THD):
(1kHz) @ 8 ohms
(1kHz) @ 4 ohms
AC Voltage
93331
Each
8 (4 stereo pairs)
130 Watts
(8 channels driven)
145 Watts
(8 channels driven)
300 Watts
5Hz – 50kHz
0.1%
0.03%
100-120V@60Hz,
220-240V@50Hz
AC Fuse
Dimensions w/ Feet
(W x H x D)
Dimensions w/ Rack Ears
w/o Feet (W x H x D)
Rack Space
Requirement
Shipping Weight
15A (T15-AL ~ 250V)
17 1/4” x 2 1/8” x 16 13/16”
(438mm x 54mm x 427mm)
19” x 1 3/4” x 16 13/16”
(482mm x 44mm x 427mm)
1U
18 lbs (8.2kg)
DSP 2-750 MKII Dimensions
Dimensions with Feet
Width: 17 1/4” (438mm)
Height: 3 7/8” (98mm)
Depth: 17 7/32” (437mm)
Dimensions with Rack Ears & without Feet
Width: 19” (482mm)
Height: 3 1/2” (88mm)
Depth: 17 7/32” (437mm)
Depth
Width w/ Rack Ears
Width
Height w/o Feet
DSP 2-750 MKII
DSP 2-750 MKII
DSP 2-750 MKII
Height w/ Feet
DSP 2-750 MKII
SPECIFICATIONS
DSP 2-750 MKII
SKU
UOM
Number of Channels
Power Output (RMS):
RMS per channel
@ 8 ohms
RMS per channel
@ 4 ohms / 70V
RMS per channel
Bridged @ 8 ohms
Frequency Response
Total Harmonic
Distortion (THD):
(1kHz) @ 8 ohms
(1kHz) @ 4 ohms
AC Voltage
93379
Each
2 (1 stereo pair)
500 Watts
(2 channels driven)
750 Watts
(2 channels driven)
2000 Watts
5Hz – 50kHz
0.4%
0.3%
100-120V@60Hz,
220-240V@50Hz
AC Fuse
Dimensions w/ Feet
(W x H x D)
Dimensions w/ Rack Ears
w/o Feet (W x H x D)
Rack Space
Requirement
Shipping Weight
15A (T15-AL ~ 250V)
17 1/4” x 3 7/8” x 17 7/32”
(438mm x 98mm x 437mm)
19” x 3 1/2” x 17 7/32”
(482mm x 88mm x 437mm)
2U
23.3 lbs (10.6kg)
Associated Products
Digital Input Module (DIM)
SKU# 93099
Compatible with DSP 2-150 MKII,
DSP 8-130 MKII (1 or 2)
and DSP 2-750 MKII
Rack Mount Bracket for
Sonamp 2-100 & DSP 2-150
SKU# 93098
Note: Allows two 1/2 rack width amps to be
rack mounted together in a 1U rack space.
LIMITED TWO (2) YEAR WARRANTY
Sonance warrants to the first end-user purchaser that this Sonance-brand product (“Product”), when purchased from an authorized Sonance
Dealer/Distributor, will be free from defective workmanship and materials for two (2) years. Sonance will at its option and expense during the
warranty period, either repair the defect or replace the Product with a new or remanufactured Product or a reasonable equivalent.
©2015 Sonance. All rights reserved.
Sonance and Sonamp are registered trademarks of Dana Innovations.
Due to continuous product improvement, all features and specifications are subject to change without notice.
For the latest Sonance product specification information visit our website: www.sonance.com
SONANCE • 991 Calle Amanecer • San Clemente, CA 92673 USA
(949) 492-7777 • FAX: (949) 361-5151 • Technical Support: (949) 492-7777
www.sonance.com
