ADVANTAGE SONANCE CINEMA SERIES SPEAKERS
Sonance Cinema® Series in-wall speakers deliver film soundtracks and music with reference clarity and realism, even
in the largest home theater rooms. These all-new home theater speakers combine elegant, modern style with uncompromised in-wall home theater performance. The all new micro-trim grilles, 0.20” of trim, give the Cinema Series a
clean, sleek appearance that seamlessly integrates into any designed space. Music, special effects, and dialogue are
reproduced perfectly without cluttering your home theater with imposing speaker boxes.
LCR1 LCR2 CINEMA SUB SUR1 SUR2
The new Cinema LCR is designed
to provide outstanding performance
in a home theater system while
maintaining a slim profile on the
wall. The advanced custom-designed
drivers, crossover, and full MDF
enclosure combine to reproduce a
dynamic range of film soundtracks
and music with startling clarity
and realism.
The Cinema LCR is a symmetrical
array, allowing it to be positioned
vertically or horizontally without a
compromise in performance.
Sonance subwoofers deliver
powerful, low-distortion bass in any
room. Anodized aluminum woofer
cones combine with heavily-braced
sealed enclosures to deliver roomshaking bass, while keeping cabinet
size to a minimum, maximizing
installation options.
The front-mounted controls and
recessed amplifiers allow these
subwoofers to be tucked-away
under shelves or installed flush
with walls.
The Cinema Surround compliments
the performance of the Cinema
LCR for side and back wall
surround applications. With its
dual compliment of customdesigned midranges and tweeters,
it produces a diffuse soundfield
that will envelop the listening area
without giving away its location.
Page 3
REINVENT SONANCE CINEMA SERIES SPEAKERS
The all-new Cinema Series speakers combine the aesthetic appeal of the award-winning Sonance Visual Performance®
Series and the reference-quality sound of Sonance speakers. Sonance Cinema Series speakers transform just about
any room into a movie theater. They surround you in sound, capturing every nuance of the romance, the drama, and
the action with prestine clarity. The new Sonance Cinema Series speakers are made of top quality high-performance
materials which ensure that each speaker will generate perfect sound.
Micro-trim grille design
The new Sonance Cinema Series speakers feature Visual Performance grilles that effortlessly blend into the
home theater - letting you focus on the movie experience and not the speakers.
Coaxial midrange / tweeter drivers
The new Cinema LCR and SUR speakers feature a unique coaxial midrange/high-frequency driver. The
midrange driver features a low-prole cone that does not compromise the performance of the tweeter
mounted in its center. This arrangement results in extremely consistent off-axis frequency response that
provides the same reference-quality sound to every listener, not just those sitting in the “sweet spot”.
Dual and quad woofers
The new Cinema Series speakers feature two woofers in the LCR1 and SUR1 and four woofers in the LCR2
and SUR2. In a typical installation, using single woofer speaker reections off the oor and ceiling can cause
dips in the frequency response up to 6dB. With a dual woofer speaker, these dips are minimized since the two
woofers will be unequal distance from these reective surfaces. In a dual or quad woofer speaker, 3dB is the
maximum amount of cancelation that can occur. This, combined with the coaxial driver, produces a speaker
with the highest degree of sonic accuracy and the lowest room placement sensitivity.
Laminated cones
The midrange and woofer drivers both have cones featuring a laminate of carbon ber and Rohacell®. These
two materials combine to make a cone that is very light, non-resonant and extremely stiff. Additionally, the
density of the cone material prevent sound produced by the backs of the drivers from being transmitted
through the cone material, a common problem with less dense materials.
Integrated ¾” medium density fiberboard (MDF) enclosure
All of the Cinema Series models feature an integrated enclosure made from ¾”-thick MDF. The enclosure’s
density and rigidity prevents sound leakage from the speaker’s rear, minimizing sound intrusion into adjacent
spaces. In addition, the MDF is non-resonant, which minimizes the sonic colorations that can rob lm
soundtracks of clarity and impact.
Enclosure damping material
To minimize the transfer of vibrational energy from the Cinema enclosure to its surrounding wall, the inner
surfaces of the enclosure are lined with a visco-elastic dampening laminate. This damping material turns the
vibrational energy into heat which is then dissipated inside the enclosure.
Die-cast baskets
All the woofer and midrange drivers feature custom die-cast aluminum baskets for maximum rigidity. These
baskets not only keep the placement of the voice consistent they are also non-ferrous and do not drain any of
the magnetic eld away from the driver’s motor system.
ENJOY GREAT MOVIE SOUND THAT FILLS YOUR SENSES. SONANCE MAKES IT REAL.
• Provides powerful detail and clarity just like in a movie theater.
• Produces outstanding musical reproduction and superior power handling for your movie soundtracks.
• Surrounds the audience in a true theater experience.
• Features all new, one-piece, micro-trim grilles that effortlessly blend into your home theater space.
• Non-resonant, integrated ¾” MDF enclosures promote natural, uncolored sound and minimize sound spillover into
adjacent rooms.
• Available in two configurations: the LCR2/SUR2 four-woofer design for the largest home theaters, and the LCR1/SUR1
two-woofer design for home theater designs up to 3,000 cubic feet.
Page 4
SPECIFICATIONS Sonance Cinema Series Speakers
Tweeter:
Midrange:
Woofer:
Frequency Resp:
Impedance:
Power Handling:
Sensitivity:
Grille Material:
Dimensions:
(W x H x D)
Cutout Dimensions:
(W x H)
Shipping Weight:
LCR
Left, Center, Right
LCR1 LCR2
1” (25mm) silk dome,
ferrofluid-cooled
4” (100mm) carbon fiber/
Rohacell laminated cone with a
rubber surround
Two 5¼” (133mm) carbon fiber/
Rohacell laminated cones with
rubber surrounds
70Hz – 20kHz ±3dB
6 ohms nominal; 4 ohms minimum
5 watts minimum;
150 watts maximum
90dB SPL (2.83V/1 meter)
Perforated steel
87/8” x 217/8” x 37/8”
(225mm x 556mm x 98mm)
7½” x 20½”
(191mm x 521mm)
19 lbs (8.6kg) each
1” (25mm) silk dome,
ferrofluid-cooled
4” (100mm) carbon fiber/
Rohacell laminated cone with a
rubber surround
Four 5¼” (133mm) carbon fiber/
Rohacell laminated cones with
rubber surrounds
70Hz – 20kHz ±3dB
6 ohms nominal; 4 ohms minimum
5 watts minimum;
200 watts maximum
92dB SPL (2.83V/1 meter)
Perforated steel
87/8” x 347/8” x 37/8”
(225mm x 886mm x 98mm)
7½” x 33½”
(191mm x 851mm)
29 lbs (13.2kg) each
Surround Side, Surround Back
Tweeter:
Midrange:
Woofer:
Frequency Resp:
Impedance:
Power Handling:
Sensitivity:
Grille Material:
Dimensions:
(W x H x D)
Cutout Dimensions:
(W x H)
Shipping Weight:
SUR
SUR1
Two 1” (25mm) silk domes,
ferrofluid-cooled
Two 3” (76mm) carbon fiber/
Rohacell laminated cones with
rubber surrounds
Two 5¼” (133mm) carbon fiber/
Rohacell laminated cones with
rubber surrounds
70Hz – 20kHz ±3dB
6 ohms nominal; 4 ohms minimum
5 watts minimum;
150 watts maximum
90dB SPL (2.83V/1 meter)
Perforated steel
87/8” x 217/8” x 37/8”
(225mm x 556mm x 98mm)
7½” x 20½”
(191mm x 521mm)
19 lbs (8.6kg) each
SUR2
Two 1” (25mm) silk domes,
ferrofluid-cooled
Two 3” (76mm) carbon fiber/
Rohacell laminated cones with
rubber surrounds
Four 5¼” (133mm) carbon fiber/
Rohacell laminated cones with
rubber surrounds
70Hz – 20kHz ±3dB
6 ohms nominal; 4 ohms minimum
5 watts minimum;
200 watts maximum
92dB SPL (2.83V/1 meter)
Perforated steel
87/8” x 347/8” x 37/8”
(225mm x 886mm x 98mm)
7½” x 33½”
(191mm x 851mm)
29 lbs (13.2kg) each
Woofer:
Freq resp:
Ampli fier:
Input s:
Outputs:
Grill e ma terial:
Cabin et f inish:
Adjustments:
Dimen sions :
(W x H x D)
Shipping Weight:
SUB
8-100
8” (2 03mm) anod ized alumi num c one,
rubber sur round
35Hz - 25 0Hz ±3dB
100 w atts
Line-level and speaker-level
High-pa ss fil tered line-l evel a nd sp eaker level
Black cloth
High-g loss black
Front-accessible level, crossover, phase
and b ypass
12” x 14” x 1 2”
(305mm x 355mm x 305mm)
40 lbs. (18kg) each
CINEMA SUB
SUB
10-150
Woofer:
Freq resp:
Ampli fier:
Input s:
Outputs:
Grill e ma terial:
Cabin et f inish:
Adjustments:
Dimen sions :
(W x H x D)
Shipping Weight:
10” ( 254mm ) ano dized aluminum cone,
rubber sur round
28Hz - 25 0Hz ±3dB
150 w atts
Line-level and speaker-level
High-pa ss fil tered line-l evel a nd sp eaker level
Black cloth
High-g loss black
Front-ac cessi ble l evel, crossover, ph ase
and b ypass
14” x 16” x 1 4”
(355mm x 406mm x 355mm)
60 lbs. (27kg) each
Woofer:
Freq resp:
Ampli fier:
Input s:
Outputs:
Grill e ma terial:
Cabin et f inish:
Adjustments:
Dimen sions :
(W x H x D)
Shipping Weight:
SUB
12-250
12” (305mm) anodized aluminum cone,
rubber surround
22Hz - 250Hz ±3dB
250 watts
Line-level and speaker-level
High-pass filtered line-level and speaker level
Black cloth
High-gloss black
Front-accessible level, crossover, phase
and bypass
15” x 18” x 16”
(381mm x 457mm x 406mm)
70 lbs. (31.5kg) each
Page 5
HEART-POUNDING SOUND EFFECTS, SOARING MUSIC.
You and your guests will enjoy movies exactly the way
the filmmakers intended them to be heard with Sonance
Cinema Series speakers.
Sonance, the first high fidelity in-wall speaker company,
continues to push reference-quality speaker performance
using the highest quality materials while also designing
them to blend seamlessly into your home theater.
Page 6
212 AVENIDA FABRICANTE
SAN CLEMENTE, CA
92672-7531
T 949 492 7777
F 949 361 5579
INVENT. LEAD. REINVENT.
1982
Designed the first in-wall speaker
for home custom installation
1983
Development of the Sonance I
1986
Invented the first in-wall
subwoofer—unique dual driver
speaker using vent technology
1988
Developed the first 3-channel
amplifier—bass, left and right
1989
Introduced the first in-wall
speaker with adjustable high
frequency control
1991
Developed Sonamp® 260, the
first amplifier for multi-room use
1994
Created the first in-wall home
theater speaker with pivoting
weeter
1997
Patented Amplified Volume Control
technology for multi-room audio
1998
Launched the first THX® Ultra
in-wall speaker system
2001
Patented the Sonic Eye®, a coaxially
mounted, pivoting midrange and
tweeter mechanism
©2008 Sonance, all rights reserved. Sonance, Visual Performance, Sonamp, iPort, Sonance Architectural Series, Sonic Eye, Ellipse, Merlot, Sonance Symphony Extreme, and Single Stereo Technology are
registered trademarks of Dana Innovations. Rohacell is a registered trademark of Degussa GmbH. THX is a registered trademark of THX, Ltd. BBE is a registered trademark of BBE Sound, Inc. Apple and iPod are
registered trademarks of Apple, Inc. Santoprene is a registered trademark of Monsanto Company.
All features and specifications are subject to change without notice. For the latest Sonance product information, go to : www.sonance.com 33-5161
2002
Invented the Ellipse®, the world’s
first speaker designed specifically
for in-celing home theater
2002
Introduced the world’s first
customizable multi-room
amplifier–Sonamp SAT275 with
SmartAmp bay for install modules
2003
Developed the industry’s first
in-wall and in-ceiling high fidelity
speakers for extreme temperatures,
moisture and marine environments
—Sonance Symphony Extreme
2004
Inroduced iPort®, the first in-wall
music system for the Apple iPod
2005
Launched the Sonamp 275SE, the
first home audio amplifier with
professional market BBE® sound
enhancement technology
2006
Introduced the first truly flush-mount
in-wall and in-ceiling speaker line.
The Sonance Architectural® Series
2007
Introduced Visual Performance Series
2008
Introduced Cinema Series Speakers
®
®
