Socket Mobile Wireless LAN CF Card User Manual

11Mbps Wireless LAN CF

Card

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Date of Issue: January. 25th, 2002

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Technical Support

The firmware and driver version of the Wireless LAN CF Card is displayed on the utility About tab. Users could download and upgrade the latest software version from the supplier’s web site or refer to the sales contact for the latest software information. If you have difficulty resolving the problem while installing or using the Wireless LAN CF Card, please contact the supplier for support.

About This Manual

11Mbps Wireless LAN CF Card User Manual is first published on January, 2002. The manual includes procedures for the setup of the 11Mbps Wireless LAN CF Card under Windows CE 3.0, Pocket PC 2002, Windows XP, Windows 2000, Windows 98, Windows ME and Windows NT. Take a moment to read through this manual and familiarize yourself with wireless technology.

Software Information

The software package works only on the Wireless LAN CF Card and Wireless LAN PCMCIA Card, and contains the following versions of driver and utility programs.

For CE Windows System:

Driver -- Version 1.1.0 and above

Utility -- Version 1.1.0 and above

For Windows XP/2000/NT/98/ME Systems:

Driver -- Version 4.0.7

Utility -- Version 4.0.7

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

FCC Information

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation.

Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-located or operating in conjunction with any other antenna

or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Table of Contents

Chapter 1 About Wireless LAN CF Card............................................1

1-1 Features and Benefits................................................................................1

1-2 Applications..............................................................................................2

1-3 Product Kit................................................................................................3

1-4 LED Information.......................................................................................3

Chapter 2 Install the CF Card for Pocket PC 2002/Win CE3.0..........4

2-1 System Requirements.................................................................................4

2-2 Before Getting Started...............................................................................4

2-3 Install the Setup Utility.............................................................................7

2-4 Install the Wireless LAN CF Card.............................................................9

Chapter 3 Set the CF Card under Pocket PC 2002/WinCE3.0.........10

3-1 Using Wireless LAN Utility Under Pocket/Handheld PC........................10

Chapter 4 Install the CF Card for Windows XP/2000/NT/98/ME...18

4-1 System Requirements...............................................................................18

4-2 Insert the Wireless LAN CF Card...........................................................18

4-3 Set up Wireless LAN CF Card for Windows XP......................................19

4-4 Set up Wireless LAN CF Card for Windows 2000...................................24

4-5 Set up Wireless LAN CF Card for Windows NT 4.0................................27

4-6 Set up Wireless LAN CF Card for Windows 98/ME................................30

4-7 Remove the Wireless LAN PC Card........................................................33

Chapter 5 Set the CF Card under Windows XP/2000/NT/98/ME...35

5-1 Install the WLAN Utility..........................................................................35

5-2 Using the WLAN Utility...........................................................................37

Limited Warranty.................................................................................47

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

About Wireless LAN CF Card 1

The 11Mbps IEEE 802.11b Wireless LAN CF Card is a standard CF typeⅡ interface adapter integrated with wireless LAN technology. It provides you the easiest and fastest way to access

your wireless and wired network. The Wireless LAN CF Card, which utilizes the latest advancement of PC industry – Compact Flash technology, allows you to install and use the card easier than ever before. 11Mbps data rate gives equivalent Ethernet speed to access corporate network or the Internet in a wireless environment. When installed, 11Mbps Wireless LAN CF Card is able to communicate with any 802.11 and 802.11b compliant products.

1-1 Features and Benefits

1. Fully IEEE 802.11b compatible.

2. Direct Sequence Spread Spectrum (DSSS) technology provides robust, interference-resistant and secure wireless connection.

3. Supports 1, 2, 5.5 and 11 Mbps data rate.

4. Working range up to 800 ft. in an open environment.

5. Seamless connectivity to wired Ethernet and PC network LAN’s augments existing networks quickly and easily.

6. Greater flexibility to locate or move networked PCs.

7. Wireless connection without the cost of cabling.

8. Easy to install and user friendly, just Plug and Play.

9. Low power consumption.

10. Supports a variety of operating systems (Pocket PC 2002, WinCE/Win98/ME/NT/2000/XP)

11. 64-bit and 128-bits WEP encryption capable.

12. Provides Window-based Diagnostic Tools, most notably, Site Survey, Link Quality Test and Access Point Browser.

-1-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

1-2 Applications

11Mbps Wireless LAN CF Card offers a fast, reliable and cost-effective solution for wireless client access to the network in applications like these:

1. Remote access to corporate network information

E-mail, file transferring and terminal emulation.

2. Difficult-to-wire environments

Historical or old buildings, asbestos installations, and open area where wiring is difficult to deploy.

3. Frequently changing environments

Retailers, manufacturers and those who frequently relocate the workplace.

4. Temporary LANs for special projects or peak time

C1. Trade shows, exhibitions and construction sites where a temporary network will be

practical.

C2. Retailers, airline and shipping companies need additional workstations during peak

period.

C3. Auditors requiring workgroups at customer sites.

5. Access to database for mobile workers

Doctors, nurses, retailers, accessing their database while being mobile in the hospital, retail store or office campus.

6. SOHO (Small Office and Home Office) users

SOHO users who need easy and quick installation of a small computer network.

7. High security connection

The secure wireless network can be installed quickly and provide flexibility. (Please refer to page 14 (under Windows CE) and 40 (under Windows XP/2000/98/ME/NT) for encryption configuration.)

-2-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

LINK

er Save mode

1-3 Product Kit

11Mbps Wireless LAN CF Card comes with the following items. Please go through each item below. If any listed item is not included or found damaged, please contact your local dealer.

11Mbps Wireless LAN CF Card

11Mbps Wireless LAN CF Card………………….…………………….….….. x 1

Wireless LAN CF Card Product CD …………………..…………………….... x 1

11Mbps Wireless LAN CF Card QIG……….…………..…………………..… x 1

CF/PCMCIA Adapter (Optional)…………………………………………….… x 1

1-4 LED Information

The 11Mbps Wireless LAN CF Card has one LED indicator. The behavior of the indicator is described as below:

Link LED

Solid Green – Associated with the

Access Point or Ad-Hoc wireless workstation. Blinking Green – Not connecting to

the Access Point or Pow enabled.

-3-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Install the CF Card for

Pocket PC 2002/WinCE 3.0

This chapter describes the instructions that guide you through the proper hardware installation of your 11Mbps Wireless LAN CF Card for Pocket PC 2002 and Windows CE 3.0 operating system.

2-1 System Requirements

In order to use the 11Mbps Wireless LAN CF Card, your computer must be equipped with the following:

Pocket PC (PPC) Handheld PC (HPC)

Compaq: IPAQ (CPU: Strong ARM) ■ Sharp: Telios (MIPS R3000)

HP: Jonada 525 and 548 (CPU: SH3) ■ HP: Jornada 720 (Strong ARM)

Casio: All models (MIPS R4000) ■ Intel: Pentium/X86 CPU

.....

More to come, check with supplier’s website.

2-2 Before Getting Started

Before installing the driver and utility of the Wireless LAN CF Card for the Pocket PC/Handheld PC, you need to first establish a connection between host PC and PDA device with Microsoft Active Sync. Instructions are as follows:

-4-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Step 1: Install the Microsoft Active Sync program that came with your PDA Product CD.

Follow the on-screen instructions to install the Active Sync on the host computer.

Step 2:

computer and the Pocket PC using a serial cable, a USB cable, or an infrared link. (Refer to your Pocket PC manual for instructions. A “Get Connected “ message will pop-up. Click Next to proceed.

Upon completion of installation, establish an ActiveSync connection between the host

-5-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Step 3:

The ActiveSync will start looking for your Pocket PC/Handheld PC to get connected.

Step 4:

below figure.

Once the connection has been made, you will see the “connected” message shown as

-6-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

2-3 Install the Setup Utility

Step 1:

ActiveSync Program, insert the CD-ROM into the CD-ROM drive and run the setup utility

nb825.exe

( automatically. Click

After successfully forming a connection between host PC and PDA device with

) for Windows CE operating system. The InstallShield Wizard will launch

to continue.

Step 2: An InstallShield Wizard window appears. Click

to proceed.

-7-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

YES

Step 3:

default application install directory.

Click

when prompted to install the Compact Flash Card driver and utility in the

Step 4: Follow on-screen instructions to install the Setup Utility. Click

the installation.

Finish

to complete

-8-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

2-4 Install the Wireless LAN CF Card

Step 1: Insert the 11Mbps Wireless LAN CF Card into the CF slot on your PDA. The PDA

will auto-detect the Wireless LAN CF Card and automatically install the corresponding driver and utility.

Step 2: Assign an IP address to your Wireless LAN CF Card. You may either set the

Wireless LAN CF Card to obtain an IP address from your DHCP server, or to be assigned with a fixed IP address.

Step 3: Reset your PDA.

Upon completion of installation, the Wireless LAN CF Card will start to look for an Access Point with Green LED blinking. The Green LED will stay steady once the Wireless LAN CF Card successfully associates with an Access Point. To configure the Wireless LAN CF Card please proceed to the next chapter.

-9-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

Set the CF Card under Pocket PC 2002/Win CE3.0

This chapter gives you assistance with detailed description of setting the 11Mbps Wireless LAN CF Card with the Wireless LAN Utility under Pocket/Handheld PC.

3-1 Using Wireless LAN Utility Under Pocket/Handheld PC

The 11Mbps Wireless LAN CF Card is a ready-to-use device. Its default settings perform for a typical computer and it is ready to use. In special situations however, you may adjust configuration settings depending on how you would like to manage your wireless network. The Wireless LAN Utility provides you an easy interface to make configuration changes and perform user-level diagnostics on your Wireless LAN CF Card.

Step 1: Go to

Setting

Infrastructure Wireless LAN

Start --> Settings

” icon.

. Simply install the Wireless LAN CF Card onto your

. Go to the

System

tab, and click the “

Wireless LAN

-10-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com

A configuration window appears. The Wireless LAN Utility provides the 5 following items for you to configure and monitor the 11Mbps Wireless LAN CF Card.

Status

The

tab displays the current status of the Wireless LAN CF Card.

Adapter Firmware Domain Channel MAC Address Sync to AP -

with.

BSSID -

with.

Link Quality -

LAN CF Card and an Access Point.

Signal Level -

frames that are received from the Access Point.

Displays the name of the Wireless LAN CF Card.

- Displays the firmware version of your Wireless LAN CF Card.

- The regulated operating frequency per country. Displays the current channel that the Wireless LAN CF Card is using.

It is a hardware identification number that distinguishes the unit from others.

Displays the ESSID of the Access Point that the Wireless LAN CF Card associates

Shows MAC Address of the Access Point that the Wireless LAN CF Card associates

Link quality monitors the quality of the data transmission between the Wireless

This bar graph displays signal strength as reported by the radio, averaged over all

-11-

PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
