SoMo® 650 Handheld Computer

User’s Guide

12/2008 Document # 6410-00287 H

COPYRIGHT NOTICE

Socket, the Socket logo, SoMo, SocketCare, SocketScan, Connect!Agent, and Wi-Fi Companion are trademarks or registered trademarks of Socket Mobile, Inc. Bluetooth and the Bluetooth logos are registered trademarks owned by Bluetooth SIG, Inc., U.S.A. and licensed to Socket Mobile, Inc. Wi-Fi and the Wi-Fi logo is a registered trademark of the Wi-Fi Alliance. All other brand and product names are trademarks of their respective holders.

The SoMo 650 includes technology licensed under European Community Registered Design Nos. 000745245-0001, 0007452450002 and 000745245-0003.

Reproduction of the contents of this manual without the permission of Socket Mobile is expressly prohibited. Please be aware that the products described in this manual may change without notice.

Feel free to contact Socket Mobile at:

Socket Mobile, Inc.

39700 Eureka Drive Newark, CA 94560-4808 USA

Other than the above, Socket Mobile can assume no responsibility for anything resulting from the application of information contained in this manual.

Please refrain from any applications of the SoMo 650 that are not described in this manual. Please refrain from disassembling the SoMo 650. Disassembly of this device will void the product warranty.

You can track new product releases, software updates and technical bulletins by visiting the Socket Mobile website at:

www.socketmobile.com

IMPORTANT SAFETY INSTRUCTIONS

Please read and follow these safety instructions before using your device for the first time, and save them for future reference.

• Keep away from extremely hot, cold or humid conditions.

• Avoid using in dusty environments.

• Do not allow the device to get wet.

• Avoid strong force, shock or vibrations.

• Do not open your device. Any attempts to open this device

will void the warranty.

• Do not place objects on top of the device.

• Avoid removing the battery without turning off the device.

• Do not charge the device in extremely hot or cold conditions.

• Please only use the supplied USB synchronization cable.

• Please do not use other chargers or adapters, as these may

damage your device.

• Do not remove SD/MMC or CF cards while they are being

accessed.

• Do not use this device in damp, wet or rainy conditions.

• Do not insert metal objects into the sync/charging port of the

SoMo.

• Keep the SoMo and its accessories away from children.

Package Contents 6 SoMo 650 Configurations 7 System Compatibility Requirements 7 Additional Accessories 8 Product Registration 8 SocketCare™ Service Program 8 Hardware Features 9 Charging/Sync Cradle 12 About the Socket Software 13 About the Socket Software 13

2 | GETTING STARTED 15

Step 1: Install the Battery 15 Step 2: Charge the Battery 16 Step 3: Set up your SoMo 650 17 Step 4: Install ActiveSync on a Host PC 18 Step 5: Connect the SoMo to the Computer 19

3 | USING THE SOMO 650 22

Buttons 22 Hold switch 22 Stylus 23 Adding a USB Keyboard/Mouse 23 Start Menu 23 Online Help 23 Wireless Radio Manager 24

4 | WI-FI COMPANION 26

Turning on the Wi-Fi Radio 27 Main Screen of Wi-Fi Companion 29 Wi-Fi Status Icon 29 Wi-Fi Finder 30 Finding and Connecting to a WLAN 31

5 | SOCKETSCAN AND CONNECT!AGENT FOR

CORDLESS BAR CODE SCANNERS 34

SocketScan Icons 35 Step 1: Prepare the Scanning Hardware 36 Step 2: Enable Cordless Scanning 36 Step 3: Connect Scanner to SoMo 37 Step 4: Start Application 38 Step 5: Scan Bar Codes 39

6 | SOCKETSCAN FOR PLUG-IN SCANNERS AND

READERS 40

Step 1: Assign a Trigger Button 41 Step 2: Start SocketScan 41 Step 3: Insert the Card 42 Step 4: Start Application 43 Step 5: Scan or Read Data 44

APPENDICES

LIMITED WARRANTY 63 DISCLAIMER 64 REGULATORY COMPLIANCE 67

1 | INTRODUCTION

Thank you for purchasing the SoMo 650 handheld computer. The SoMo 650 makes small- to mid-sized deployments possible and affordable for a wide range of mobile business applications, including sales force automation, inventory management, patient care, merchandising, and more. This durable, customizable device has premium features such as true business-class Bluetooth

technology to keep you

Wi-Fi connected wherever you go.

Pre-loaded with Socket device drivers and software utilities, the SoMo 650 can be deployed out of the box with a wide range of Socket data collection, network access or device connection peripherals to create a custom solution that meets your specific business requirements.

PACKAGE CONTENTS

• SoMo 650 handheld computer

• Lithium-ion battery

• Stylus

• USB sync/power cable

• AC adapter

• 2 rubber screw caps

• Quick Start Guide

• Getting Started CD with software and documentation

• Sync/charging cradle (SoMo 650-M only)

• Belt carrying case (SoMo 650-M only)

• 2.5mm to 3.5mm audio headset adapter (SoMo 650-M only)

• Audio headset with microphone (SoMo 650-M only)

and

SOMO 650 CONFIGURATIONS

Configuration Windows Mobile version Region Language Part Number

North America

EMEA

North America

EMEA

Not country specific

North America

EMEA English

English

English 8560-00003

Spanish 8560-00006

Brazilian Portuguese

English

Spanish

German

French

Italian

Iberian Portuguese

English

Standard includes Bluetooth and Wi-Fi

DX - for direct exchange applications (Bluetooth & Wi-Fi removed)

Rx – for healthcare applications (case features antibacterial additive)

5.0 for Pocket PC

6 Classic

5.0 for Pocket PC

6 Classic

SYSTEM COMPATIBILITY REQUIREMENTS

Before you start using your new SoMo 650, you should have a host computer ready for synchronization.

• For Windows Vista, the Windows Mobile Device Center is

required. Download it free from the Microsoft website at

www.microsoft.com/windowsmobile/devicecenter.mspx

• For Windows 2000/XP, Microsoft

ActiveSync® software version

4.2 or greater is required for Windows Mobile 5.0, and version

4.5 or greater is required for Windows Mobile 6.0/6.1. Download the latest version using the link in the Getting Started CD.

8560-00001

8560-00002

8560-00005

8560-00004

8560-00011

8560-00008

8560-00007

8560-00009

8560-00010

8560-00012

8560-00013

8560-00014

8560-00015

CHAPTER 1: INTRODUCTION 7

In order to install ActiveSync, your Windows 2000/XP computer must meet the following minimum requirements:

• Intel

Pentium® processor (minimum 233 MHz)

• 64 MB RAM

• 120 MB disk space

• CD-ROM drive

• USB port

• SVGA (or compatible) graphics card supporting 256 colors

• Microsoft

Internet Explorer 6.0

In order to install the Windows Mobile Device Center, your Windows Vista computer must have Windows Vista Ultimate, Enterprise, Business, Home Premium, Home Basic or Server “Longhorn”

ADDITIONAL ACCESSORIES

A variety of accessories can be purchases separately online, as well as replacements for items included with the SoMo 650. For more information, visit: www.socketmobile.com/products/accessories/

PRODUCT REGISTRATION

Socket highly recommends that all customers register their products. Registered users benefit from priority technical support and can choose to receive special offers for future products and upgrades and the latest new product information.

SOCKETCARE

™

SERVICE PROGRAM

SocketCare is an enhanced service program available for the SoMo 650 for an additional cost. It provides the following benefits (benefits vary with program level):

• Faster turnaround for product repair or replacement

• Faster response for technical support inquiries

• Accidental damage coverage

• Exclusive telephone access to technical support

Standard SocketCare must be purchased within 90 days of your SoMo purchase, and premium SocketCare must be purchased at the same time as your SoMo purchase. For more information, please visit:

www.socketmobile.com/support.

HARDWARE FEATURES

Front

Wireless Status LED (Blue/Green) – indicates Bluetooth®, Wi-Fi®

Battery Status/Alarm LED (Red/Green)

3.5" TFT LCD touch screen

Calendar shortcut button

Besides the power button, you can also turn on the SoMo 650 by pressing any of the four application buttons (Calendar, messaging, Today or contacts shortcut button).

4 5

6 7

Messaging shortcut

9 8

button

5-way navigation button

Microphone

Today shortcut button

Contacts shortcut button

10.

Power button

CHAPTER 1: INTRODUCTION 9

SoMo 650 Status Indicator LEDs

LED LED Behavior Meaning

Wireless Status LED

Battery Status/ Alarm LED

Flashing blue Bluetooth radio is on

Flashing green Wi-Fi radio is on

Flashing blue and green Bluetooth and Wi-Fi radios are on

Flashing red Alarm/Notification, including Low

Battery Notification

OFF Running on battery power

Solid red light when connected to charger

Solid green light when connected to charger

Charging

Fully charged

Back

1. Battery cover

2. Battery cover release

3. Speaker

Left

1 2

1. Hands-free (headset/microphone) connector (lift rubber cover

to access)

2. Left programmable application button (launches Voice Notes

by default)

3. Hold switch (disables screen and all buttons)

DC-in connector (lift rubber cover to access)

Right

1. Right programmable application button (launches radio

manager by default)

Top (with card slot cover open)

2 3

1. Stylus holder and stylus

2. SD (Secure Digital)/SDIO/MMC (MultiMedia Card) slot (lift

rubber cover to access)

3. CF (CompactFlash) slot (lift rubber cover to access)

CHAPTER 1: INTRODUCTION 11

Bottom

1 2

USB synchronization/host cable connector

Soft reset button

CHARGING/SYNC CRADLE

If your version of the SoMo 650 does not include a cradle, you can buy it separately at: www.socketmobile.com/products/accessories/

The cradle can act as a USB hub, featuring two USB ports that can be used to connect a keyboard, mouse or other USB device. It also features a spare battery charger that enables you to charge a spare battery while also powering/charging the SoMo 650 in the cradle.

Front

26-pin docking connector

USB port status LEDs

Charging status LED

Back

Spare battery charger

USB ports 1 and 2 26-pin connector

BOUT THE SOCKET SOFTWARE

The Socket software listed below comes pre-loaded on the SoMo 650, along with any related device drivers. Except for Wi-Fi Companion, they all are designed for use with a Socket peripheral product, which must be purchased separately.

SocketScan

directly from any Socket data collection peripheral into any open Windows program on the SoMo. It works with both plug-in and cordless data collection products from Socket.

Connect!Agent™ simplifies Bluetooth by automatically setting up and managing the wireless connection between the SoMo 650 and a Socket cordless bar code scanner, serial adapter or modem.

Wi-Fi Companion

it easy to monitor, set up and troubleshoot your Wi-Fi connection.

Modem Utilities enable you to configure your Socket modem for any country and adjust settings such as V.92 features like Modem-on-Hold.

Ethernet Utilities feature an auto-launch setting to help you save time when you connect your SoMo to a LAN network.

™

enters bar code, RFID or magnetic stripe data

™

provides a rich graphical interface that makes

Power jack

CHAPTER 1: INTRODUCTION 13

Serial Drivers enable out of the box compatibility with the Socket CF Serial I/O Card.

For software updates, please visit:

www.socketmobile.com/support/downloads/

Note: This User’s Guide does not cover how to use the Modem, Ethernet or Serial Utilities. For instructions, please refer to the manuals that came with your Socket peripherals.

2 | GETTING STARTED

STEP 1: INSTALL THE BATTERY

1. Remove the battery cover of the SoMo 650. Press the release

button on the bottom of the battery cover and use the thumb of your opposite hand to slide the battery cover off the SoMo.

2. Place the included battery into the battery compartment, so

that the battery’s bar code label is face up, near the bottom of the device.

Replace the

NOTE:

fasten the battery cover.

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN

INCORRECT TYPE. DISPOSE OF BATTERIES ACCORDING TO YOUR LOCAL REGULATIONS FOR BATTERY DISPOSAL.

cover.

After changing the battery, please make sure you

CHAPTER 2: GETTING STARTED 15

STEP 2: CHARGE THE BATTERY

Connect the AC adapter to the DC-in connector on the left side of the device, as shown below.

Alternatively, you can use the cradle, if included with your version of the SoMo 650.

Plug the AC adapter into a suitable wall socket.

NOTE: The SoMo 650 should be charged for 4 hours before

first use. Afterwards, charge the device as needed according to its battery level.

NOTE: While charging, the power LED will be red. When

charging is complete, it will change to green.

NOTE: The charging cradle included with the SoMo 650-M has

a compartment for charging an extra battery. You can charge an extra battery and the device simultaneously in the cradle.

STEP 3: SET UP YOUR SOMO 650

NOTE: Make sure the SoMo 650 is fully charged before

proceeding.

Slide the hold switch on the left side of your SoMo 650 up to the unlocked position.

Hold switch

IMPORTANT! SLIDE THE SWITCH UP, OR THE DEVICE WILL NOT

WORK!

Turn on your SoMo 650 by pressing the small power button on the front (top right-hand corner).

Power button

Follow the onscreen instructions to set up your SoMo 650.

CHAPTER 2: GETTING STARTED 17

STEP 4: INSTALL ACTIVESYNC ON A HOST PC

NOTE: For Windows Vista, use the Windows Mobile Device

Center, which you can download free from the Microsoft website at: www.microsoft.com/windowsmobile/en-

us/help/synchronize/device-center.mspx

NOTE: Do not connect your SoMo 650 to your host computer

until ActiveSync or the Windows Mobile Device Center has been installed.

NOTE: For Windows 2000/XP, ActiveSync version 4.2 or

greater is required to connect to Windows Mobile 5.0, and version 4.5 or greater is required to connect to Windows Mobile 6.

Close any programs running on your computer.

Insert the SoMo 650 Companion CD into the computer's CDROM drive. The CD's welcome page will appear.

Click Next.

The welcome page may appear different for different SoMo versions.

Follow the instructions to install Microsoft ActiveSync.

After installation, the ActiveSync icon will appear on your computer’s system tray (usually on the lower right-hand corner of the screen).

NOTE: Refer to the ActiveSync online Help for information on

how to use the software. To restart this setup program, simply re-insert the

CD into the CD-ROM drive.

STEP 5: CONNECT THE SOMO TO THE COMPUTER

Connect with the Sync Cable

Plug the USB sync cable into the connector on the bottom of your SoMo 650. Plug the other end of the USB sync cable into a suitable USB port on your computer. It is recommended that you also connect the AC adapter.

to computer USB port

CHAPTER 2: GETTING STARTED 19

Connect with the Cradle

If your version of the SoMo 650 does not include a cradle, you can buy it separately at: www.socketmobile.com/products/accessories/

Insert the SoMo 650 into the cradle. Use the USB sync cable to connect the cradle to a host computer. It is recommended that you also connect the AC adapter into the cradle.

STEP 6: SET UP YOUR DEVICE PARTNERSHIP

Windows 2000/XP: When you connect your SoMo 650 to your computer for the first time, the New Partnership wizard will automatically appear on your computer screen.

Windows Vista: When you connect your SoMo 650 to your computer for the first time, the Windows Mobile Device Center will automatically start. Click Set up your device.

NOTE: If the New Partnership wizard does not automatically

appear, open ActiveSync manually by clicking the

Start menu > All Programs > Microsoft ActiveSync.

Follow the setup wizard to set up the partnership. Once

Windows

completed, the first synchronization will start automatically.

After the synchronization is complete, you will see that the Calendar, Contacts and Tasks on your SoMo 650 have been updated.

The next time you wish to use the Windows Mobile Device Center or ActiveSync, you just need to plug your SoMo 650 into your computer. The synchronization software will then open automatically and update your device.

CHAPTER 2: GETTING STARTED 21

3 | USING THE SOMO 650

This chapter explains how to use your SoMo 650 through its buttons, the hold switch, stylus, Start menu, online Help, and the Radio Manager.

BUTTONS

Your SoMo 650 has several buttons, as follows:

• Power button

• Left programmable application button (defaulted to Voice

Notes default)

• Right programmable application button (defaulted to Radio

Manager)

• Calendar shortcut button

• Contacts shortcut button

• 5-way navigation button

• Messaging shortcut button

• Today shortcut button

For more information on the position of these buttons, please refer to the diagrams in Chapter 1, “Introduction.”

For more information on the soft reset button, please refer to Appendix B, “Resetting the SoMo 650”

HOLD SWITCH

The hold switch located on the left side can be used to prevent accidental input by disabling all buttons and the screen of the SoMo 650. Any applications or wireless connections running on the device will remain active. To put your device on hold, move the switch in the down position.

NOTE: The hold switch is not related to the software lock

function accessible from the Today screen

NOTE: When the hold switch is activated, by default, the

screen will turn black, and the screen and all buttons on the

sides and front of the SoMo will be disabled, including the power button

NOTE: To enhance your user experience, Socket has a Hold

Switch Utility that enables you to configure the hold switch settings. For more information, please see Appendix D.

STYLUS

You can use the stylus in three ways.

• Tap an item: Use to select an option, similar to left-clicking a

computer mouse.

• Tap and hold an item: Reveals a submenu, if available.

Similar to right- clicking a computer mouse.

• Drag: Hold the stylus against the screen and drag to highlight

multiple items, or to move the position of an item. Similar to left-clicking and dragging a computer mouse.

ADDING A USB KEYBOARD/MOUSE

If you are using the SoMo 650-M, you can enter information by docking the SoMo in the cradle and using the cradle’s two USB ports to connect a keyboard and/or mouse.

START MENU

From the Start menu, you can access programs, settings and Help

topics. The Start menu can be accessed by tapping

ONLINE HELP

Your SoMo 650 contains online help files. These can be accessed in two main ways:

1. Press > Help > Contents for a list of Help topics.

2. To access Help for any particular application, open the

application and then tap

CHAPTER 3: CONTROLLING THE SOMO 23

> Help.

WIRELESS RADIO MANAGER

Windows Mobile 5.0

1. Open the Socket Radio Manager. Press the button on the

right side of the SoMo 650. Alternatively, tap the Wi-Fi and Bluetooth status line in the Today screen.

2. In the Radio Manager, a red “x” appears on the Bluetooth or

Wi-Fi button when the radio is off. Tap on the button to turn on the radio.

NOTE: Wi-Fi Companion software automatically launches after

Wi-Fi is turned on

NOTE: Flight mode turns off Bluetooth and Wi-Fi. When f

mode is disabled, the previously running wireless radio(s will turn on again

Windows Mobile 6

1. Open the Microsoft Wireless Manager. Press the button on

the right side of the SoMo 650. Alternatively, tap the Wi-Fi and Bluetooth status line in the Today screen.

light

)

2. In the Wireless Manager, an “x” appears next to the Wi-Fi or

Bluetooth icon when the radio is off. Tap on the button to turn on the radio.

NOTE: Wi-Fi Companion software automatically launches after

Wi-Fi is turned on

CHAPTER 3: CONTROLLING THE SOMO 25

4 | WI-FI COMPANION

Wi-Fi Companion is a powerful and easy-to-use utility for managing Wi-Fi connections from your SoMo 650 mobile computer. Intuitive graphics display connection properties at a glance. Tap on icons to quickly perform a variety of networking tasks. For advanced users, the software also offers advanced diagnostic tools and connection statistics.

Wi-Fi Companion comes pre-loaded on the SoMo 650, providing you the best user experience with the mobile computer’s built-in Wi-Fi radio.

ADDITIONAL DOCUMENTATION

This chapter covers basic instructions for using Wi-Fi Companion on the SoMo 650. For detailed instructions, please refer to the User’s Guide available in the CD and online at:

www.socketmobile.com/support/downloads/

USEFUL LINKS

Download software updates from:

www.socketmobile.com/support/downloads/

To check which version of Wi-Fi Companion is installed in your SoMo, in the main screen of Wi-Fi Companion, tap About.

For information about Enhanced Wi-Fi Companion (e-WFC), which offers advanced business security and is Cisco Compatible Extensions (CCX) 4.0 certified, please visit:

www.socketmobile.com/products/software/

TURNING ON THE WI-FI

RADIO

Wi-Fi Companion automatically launches after you turn on the Wi-Fi radio.

1. Open the Radio Manager. Press the button

of the SoMo 650. Alternatively, you can t Bluetooth status line in the Today screen.

on the right side

ap on the Wi-Fi and

2. In the radio manager, an “x” will appear on the Wi-Fi button

to indicate that the Wi-Fi radio is off. Tap on the button to turn on the radio. The “x” will di

sappear.

Windows Mobile 5.0 Windows Mobile 6

CHAPTER 4: WI-FI COMPANION 27

3. The Wi-Fi status icon will appear at the top of the screen. The

icon varies based on your connection status. Tap on the icon to view the main screen of Wi-Fi Companion. To view the different

versions of the icon, please refer to the chart on the

next page.

Windows Mobile 5.0 Windows Mobile 6

NOTE: If you tap Enable Flight Mode (Windows Mobile 5.0) or

All (Windows Mobile 6), the Bluetooth and Wi-Fi radios will

radio(s) were running, so when you later tap Disable Flight Mode or All, the same one(s) will turn on again.

both be disabled. The manager will remember which wireless

MAIN SCREEN OF WI-FI COMPANION

The screen content varies depending on your connection status.

Your device properties.

• Device name

• IP address

• Packets sent and

received

The icon always appears regardless of connection status. Tap to view more IP addresses or access the radio manager.

Encryption status. Tap to access a certificate

a utility

man gement for WPA or 802.1x if needed.

}

Access point/remote device properties.

• SSID (network name)

• Connection duration

• Signal quality rating and percentage

• MAC address (also known as BSSID)

• Channel number (in black circle)

Tap for Wi-Fi Finder.

Wi-Fi status icon. Tap to acce screen from outside the utility

Valid IP address. Tap to access email, the Internet, ping or trace route.

Data rate. Tap to view signal strength and data rate distribution.

WI-FI STATUS ICON

The icon appears at the top of every screen when Wi-Fi Companion is running.

ss this

Associated or Connected. Number of bars indicates signal strength.

Networks available.

Searching for networks.

Networks out of range but configured.

CHAPTER 4: WI-FI COMPANION 29

WI-FI FINDER

The Wi-Fi Finder displays a list of WLAN networks found in range. To access the Wi-Fi Finder, tap on the large tower icon in the bottom right corner of the m in screena of Wi-Fi Companion.

list by type.

Tap on any listing t expand details.

Tap and hold stylus on any listing to manage profiles and/or connect.

W -FI FINDER ICONS

e Tap to filter th

Current connection

Signal strength of strongest AP (access point)/ad hoc radio

WEP encryption, WPA (PSK), WPA (TKIP), WPA2 or 802.1x

No encryption

Channel number

p to sort the list. Ta

Tap on the MAC address line to view AP Details.

Profile saved

802.11b, 802.11g

FINDING AND CONNECTING TO A WLAN

Ask your network administrator for the necessary security settings for your WLAN. If the WLAN uses 802.1x, WPA or WPA2, you need to install authentication certificate(s) before you can connect. Refer to the Wi-Fi Companion User’s Guide for instructions on the Socket certificate utility.

1. In the

2. Wi-Fi Finder

main screen of Wi-Fi Companion, tap

on the tower icon, or tap Tools | Wi-Fi Finder.

will appear, listing WLANs detected in range. Tap

on any W

LAN in the list to view additional properties.

If desired, tap on the

Type or Sort by drop-down menus to

change how the list is displayed.

ur WLAN is no

If yo t listed, tap Refresh at the bottom of the screen.

CHAPTER 4: WI-FI COMPANION 31

3. If Wi-Fi Finder cannot find your WLAN because it

s SSID

(network name) is hidden, tap New at the bottom of the screen.

A wizard will launch to help you create a profile for your network. Complete the wizard, entering the security s obtained from your network administrato

ettings

4. If your WLAN does not have a profile (i.e., no folder icon is

shown next to it), tap and hold your stylus on the WLAN in the list. In the pop-up menu, tap Get Connected.

A wizard will launch to help you create a profile for the selected SSID. Complete the wizard, entering the security settings obtained from your network administrator.

5. After a profile is saved, if the WLAN is in range, the SoM

automatically try to connect to it.

o connect to another network in the list, tap and hold your

T stylus on the WLAN. In the pop-up menu, tap Connect.

o will

CHAPTER 4: WI-FI COMPANION 33

5 | SOCKETSCAN AND CONNECT!AGENT

FOR

SocketScan software sends data from your Socket Cordless Hand Scanner Series 7 or Cordless Ring Scanner Series 9 into any application running on the SoMo 650. This lets you use Socket data collection peripherals without having to program custom applications. The software comes pre-loaded on the SoMo 650.

Connect!Agent software makes Bluetooth easy to use by automatically setting up and managing the connection between your CHS or CRS and the SoMo 650.

DDITIONAL DOCUMENTATION

This chapter covers basic instructions for using SocketScan and Connect!Agent on the SoMo 650 with a Socket cordless bar code scanner. For detailed instructions, please refer to the User’s Guide available in the CD and online at:

www.socketmobile.com/support/downloads/datacollection/

CORDLESS BAR CODE SCANNERS

USEFUL LINKS

Download software updates from:

www.socketmobile.com/support/downloads/datacollection/

To check which version of SocketScan or Connect!Agent is installed in your SoMo, in the main screen of Wi-Fi Companion, tap About.

SocketScan Icons

The icon indicates whether SocketScan is connected to your

cket cordless bar code scanner and is ready to read data. The

on appears at the bottom of the Today screen.

Icon Meaning

No Socket data collection device detected.

Ready to scan bar codes with the Cordless Hand Scanner

Ready to scan bar codes with the Cordless Ring Scanner.

CHAPTER 5: SOCKETSCAN AND CONNECT!AGENT 35

STEP 1: PREPARE THE SCANNING HARDWARE

Refer to your CHS or CRS manual for hardware preparation instructions. You will need to install and charge the battery/batteries. If using the CHS, you may also w the tether. If using the CRS, you will also need to assemble the str

aps.

ant to attach

STEP 2: ENABLE CORDLESS SCANNING

1. Tap Start | Settings | System tab | Socket Scanner

Settings.

2. Tap on the CS tab at the bottom of the screen. Check Enable

Cordless Scanner support.

3. Tap ok to save your changes.

STEP 3: CONNECT SCANNER TO SOMO

1. If using the CRS, put on the scanner. Refer to the CRS man

ual

for instructions.

2. Turn on your bar code scanner. Refer to your scanner manua

for in

structions.

. Tap Start | Programs | SocketScan folder | SocketScan.

SocketScan will launch, running in the background.

4. Tap ok to exit the folder. Tap x to exit Progra

5. The SocketScan icon will appear at the bottom of th

screen. Tap

on the icon. In the pop-up menu, tap Connect CS.

ms.

e Today

6. Connect!Agent will begin searching for the scanner.

7. After Connect!Agent finds the scanner, it will automatically

connect, indicated by a beep. The SocketScan icon at the bottom of the Today screen will also change to indicate the connection.

CHAPTER 5: SOCKETSCAN AND CONNECT!AGENT 37

STEP 4: START APPLICATION

1. Start the application that you want to enter data into (e.g.,

Excel Mobile). From the Today screen, tap Start | Programs and select your program.

2. Make sure a docu

ment, spreadsheet or form is open in your

program.

Place the cursor where you want data from the next scan to

3. be entered.

STEP 5: SCAN BAR CODES

1. Press the trigger button to scan a bar code. Please refer to

your scanner manual for the correct technique.

2. When data is read, it should appear in your document.

Depending on which scanner you have, it may also beep, or the LED may change colors to indicate a successful scan.

By default, the cursor automatically advances to the next cell or line, ready for the next scan/read.

NOTE: Wait for the “Good Scan” indication before you scan

more data. If you try to scan too fast, the device can lock up until you stop scanning.

NOTE: If the data does not appear how you expect it and you

are using Excel Mobile, check the cell formatting.

CHAPTER 5: SOCKETSCAN AND CONNECT!AGENT 39

6 | SOCKETSCAN FOR PLUG-IN

SCANNERS AND READERS

SocketScan software sends data from your Socket bar code scanner, RFID reader or magnetic stripe reader into any application running on the SoMo 650. This lets you use Socket data collection peripherals without having to program custom applications. The software comes pre-loaded on the SoMo 650.

his chapter contains generic instructions for using SocketScan

T on

the SoMo 650 with these products:

•

Secure Digital Scan Card Series 3

•

CF Mag Stripe Reader Card Series 4

•

CompactFlash Scan Card Series 5

•

CF RFID Reader Card Series 6

For

specific instructions, please refer to the User’s Guide for your

spe

cific Socket data collection product, available in the installation CD that came with the data collection product as well as online at:

w.socketmobile.com/support/downloads/datacollection

STEP 1: AS

SIGN A TRIGGER BUTTON

NOTE: This step is

Card 4E.

NOT required for the CF Mag Stripe Reader

NOTE: For the CF RFID Reader-Scan Card 6M/6P, multiple

trigger buttons need to be assigned. Please refer to RFID card manual for instructions.

your

1. Tap Start | Settings | Buttons.

2. From the Button list, tap to select a button to trigger your

scanner. For best ergonomics, the left or right button is recommended. In the drop-down menu, select SocketScan. Tap ok.

STEP 2: START SOCKETSCAN

1. Tap Start | Programs | Socket

2. A SocketScan icon

should appear at the bottom of the

Today screen indicating that no data collection device has been inserted.

CHAPTER 6: SOCKETSCAN FOR PLUG-INS 41

Scan folder | SocketScan.

STEP 3: INSERT THE CARD

1. Open the slot cover at the top of the SoMo 650, then insert

the card into the appropriate slot. Make sure the card is right side up. D in too hard.

o not insert the card upside-down or force the card

2. When SocketScan is running, a SocketScan icon will appear at

the bottom of the Today screen. Make sure the appropriate icon appears to indicate that your device is ready to collect data.

Icon Meaning

No Socket data collection device detected.

Ready to scan bar codes with the Secure Digital Scan Card

Ready to read magnetic stripe data with the CF Mag Stripe Reader Card

wiReady to scan bar codes th the CF Scan Card 5E/5M/5P

or CF RFID Reader-Scan Card 6M/6P

Ready to scan bar codes with the CF Scan Card 5X

Ready to read RFID tags with the CF RFID Reader Card

NOTE: If you insert the card before starting SocketScan, no

icon will appear.

STEP 4: START APPLICATION

1. Start the application that you want to enter data into (e.g.,

Excel Mobile). From the Today screen, tap Start | Programs and select your program.

2. Make sure a document, spreadsheet or form is open in your

program.

3. Place the cursor where you want data from the next scan/read

to be entered.

CHAPTER 6: SOCKETSCAN FOR PLUG-INS 43

STEP 5: SCAN OR READ DATA

1. Scanning/RFID

read an RFID tag. Please refer to your scanner manual for the correct technique.

Mag Stripe

with the magnetic stripe facing the SoMo 650.

: Press the trigger button to scan a bar code or

: Swipe a magnetic stripe card through the slot,

in your document. 2. When data is read, it should appear

Depending on which scanner/reader you have, it may also beep, or the LED may change colors to indicate a successful scan.

By default, the cursor automatically advances to the next cell or line, ready for the next scan/read.

NOTE: Wait for the “Good Scan” indication before you scan

more data. If you try to scan too fast, the device can lock up until you stop scanning.

NOTE: If the data does not appear how you expect it and you

are using Excel Mobile, check the cell formatting.

CHAPTER 6: SOCKETSCAN FOR PLUG-INS 45

APPENDIX A

PECIFICATIONS

Processor Intel PXA270@624MHz CPU Memory SDRAM: 128MB

NAND Flash: 256MB

Display 65K colors TFT LCD, 3.5”

16 bit-per-pixel 240 (w) x 320 (L) resolution (QVGA size) portrait and landscape modes, default portrait mode. Glass analog resistive touch panel White LED backlight

Audio Headset Jack: 2.5mm, 4-ring type, support for

both Voice & Stereo music 0.5W speaker Omni-directional microphone

Connectors SoMo 650

DC-in (5V, 1A)

USB synchronization/host cable connect

Cradle

Docking connector

DC-in (5V, 3A)

USB synchronization cable connector

USB connector x 2 (Type A)

Wireless Connectivity

not included with SoMo

( 650DX)

Mass Storage & Expansion Slots USB USB 1.1 support host/client (x2) (Cradle only)

Battery

Bluetooth: v2.0 + EDR Class 2 IEEE® 802.11b/g WLAN with fast roaming Cisco CCX 4.0 certified with Enh software (available separately)

User accessible SD/SDIO/MMC expansion slot CF I/O Type II expansion slot

Standard: 3.7V 1200 mAh, rechargeable, Lithium-ion Extended: 3.7V 2600 mAh rechargeable, Lithium-ion (extended battery available separately or with SoMo 650EB or SoMo 650Rx)

anced Wi-Fi Companion

Dimensions

With standard battery:

5.00 x 2.94 x 0.81 inches (127 x 74.60 x 20.6 mm)

ight: 6.25 oz (177 g) (including stylus)

With extended battery:

5.00 x 2.94 x 0.98 inches (127

Weight: 7.20 oz (

204 g) (including stylus)

Operating Temperature ° F) 0° to +40° C (+32° to +120

x 74.60 x 25 mm)

Storage Temperature

Humidity

Drop Specification

ESD Specification

Operating Systems Available

Pre-Loaded Software

-25° to 75° C (-13° to 167° F)

95% non-condensing

covered with

Multiple 1 meter drops to concrete vinyl

+/- 8kV air discharge, +/- 8kV direct discharge

Microsoft

Windows Mobile® 5.0 for Pocke

Microsoft Windows Mobile 6 C

lassic

t PC

Note: If you have a SoMo 650 running Windows Mobile

5.0, an upgrade for Windows Mobile 6 is available.

Program Calc

mable Home Screen

ulator MSN Messenger Client Wo

rd Mobile

Exc

el Mobile PowerPoint Mobile IE Mobile Outlook Mobile .NET Compact Framework v2.0 Windows Media Player 10.2 Mobile ActiveSync Client v4.x Socket Wi-Fi Companion Socket SocketScan™ Socket Connect!Agent

™

Socket Modem Utilities Socket Ethernet Utilities Socket Serial I/O drivers

The SoMo 650 running Windows Mobile 5.0 also includes the Socket Radio Manager.

APPENDIX A: SPECIFICATIONS 47

APPENDIX B

ARE AND MAI

NOTE: For important safety and usage instructions, please

refer to page 3.

eaning the SoMo:

With the device switched off, clean the SoMo 650 by wiping it

•

with a soft, clean h that is lint-free and slightly moistened. Do not allow the earpiece, microphone, speaker, card slots, sync/charging po other metal surfaces to get wet.

Do not wipe the with any corrosive liquid or coarse

• SoMo

objects. This can damage the outer surface of the device.

Carrying or Storing the

• Mo mperature

Do not leave the So in extremely high or low te environments.

• Remove the battery of the SoMo if it is not going to be used

for a long period of time. Store the SoMo and its battery in a cool, dark, and dry plac

rt or

NTENANCE

clot

SoMo:

APPENDIX C

ESETTING THE SOMO 650

he SoMo 650 supports the three levels of reset defined by

T Mic

rosoft for Windows Mobile powered devices:

Soft Reset - sometimes called a “warm” reset

•

Hard Reset - sometimes called a “cold” reset

•

• Clean Reset - sometimes called a “clean boot”

Each of these resets is designed to clear different levels of data storage and impact the hardware differently.

Additionally, removing the battery and any external sources of

ower from the SoMo 650 will result in the equivalent of a reset.

The following Table summarizes the system impact under the

odes of operation:

State of SoMo All Installed

650 After: Applications

and Registry with

Settings

Soft Reset No impact Stopped Lost No impact Hard Reset No impact Stopped Lost Lost Clean Reset Removed Stopped Lost Lost Battery &

external power removed for less than 5 minutes

Battery & external power removed for more than 10 minutes

No impact Stopped Lost No impact

No impact Stopped Lost Lost

Running

Programs

Data

Associated

Running

Programs

Note: The SoMo 650 has a battery backup device that maintains the date and time if the battery and all external power sources are removed. If the SoMo 650 does not have a battery or external power source for more than 10 minutes, the date and time will be lost, and the battery backup device must be recharged for at least 10 minutes before it will properly maintain the date and time.

Date and

Time

APPENDIX C: RESETTING THE SOMO 650 49

Soft Reset

A soft reset is like reb ng a omp er. It is des applications and clear out temporary data associ

n s ar dele . A soft re

ning programs. No file e ted set is the lowest

ru level of reset, (i.e., it clears the least amount of the device st

It can also be used to stop application programs that are “hung” and do not respond to external input. Since Wind powered devices do not normally shut down an it is started, this is one way to stop all applications

To perform a soft reset:

Using the tip of your stylus, lightly press the So

side the hole on the bottom of your SoMo 650 and then

in release.

ooti c ut igned to stop all

ated with

ate).

ows Mobile

application after

ft Reset button

50 | APPENDIX C: RESETTING THE SOMO 650

Hard Reset

A hard reset is designed to clear all processor states, running programs, and user data. It also drives the hardware reset li the processor, thereby clearing all system states, including the date and time. This reset should be used to remove the operating sy

stem from a “hung” or “frozen” state because of a fatal

program or operating system error.

A hard reset will clear all user-installed settings, applications, and data from RAM (Random Access Memory). It is usefu

l for clearing

some states that are not normally cleared with a Soft Reset

To perform a hard reset:

Press and hold the Calendar and Contacts shortcut butto your S

oMo 650.

While holding the two buttons, using the tip of your stylus, lightly press the Reset button inside the hole on the bottom of your SoMo 650.

ne to

ns on

Press the two shortcut buttons with the index and middle finger of one hand. Hold the stylus in your other hand to press the reset button and then release.

Keep pressing the two buttons until a splash screen appears with the Socket logo and then disappears.

After the Socket Splash Screen disappears, release the two buttons and follow the onscreen instructions.

APPENDIX C: RESETTING THE SOMO 650 51

Clean Reset

A clean reset is designed to revert the device to its factory default settings (or the latest service pack ROM update). All installed programs, data and registry settings will be cleared. A clean reset also drives the processor with a hardware reset, thus clearing all system states, including the date and time.

CAUTION: A CLEAN RESET IS MORE POWERFUL THAN A SOFT OR

HARD RESET. IT WILL DELETE ALL USER APPLICATION FILES AND FOLDERS. WHEN YOU PERFORM A CLEAN RESET, FORMATS, PREFERENCES AND OTHER SETTINGS INCLUDING DATE AND TIME ARE RESTORED TO THEIR AND ENTRIES, EXCEPT THOSE STORED IN ROM, WILL BE ERASED

NOTE: If you set a security password on the SoMo 650 and

forget it, a clean reset will remove the password setting.

o perform a clean reset:

Press and hold the Left Programmable Application Button, the Calendar and Contacts shortcut buttons on your SoMo 650.

FACTORY DEFAULTS. ALL DATA, RECORDS

52 | APPENDIX C: RESETTING THE SOMO 650

While holding the three buttons, using the tip of your stylus,

your SoMo 650 and then release.

om of lightly press the Reset button inside the hole on the bott

It is recommended that you hold the SoMo 650 in your left hand. Press the left programmable action button with your left thumb and the two shortcut buttons with your left index and middle finger. Hold the stylus in your right hand to press the reset button.

APPENDIX C: RESETTING THE SOMO 650 53

Keep pressing all three buttons until a splash screen appears with the Socket logo and then disappears.

After the Socket Splash Screen disappears, release the three buttons and follow the onscreen instructions.

54 | APPENDIX C: RESETTING THE SOMO 650

APPENDIX D

PGRADING THE ROM IMAGE

ADVANCED USERS ONLY!

You can purchase ROM image upgrades from the Socket website.

WARNING! You will lose all data files and applications during the upgrade process!

STEP 1: Power the Device

Make sure the battery has enough power or plug the SoMo 650 into an external power source using the charging cable/cradle.

STEP 2: Back up Data on the Device

If you have any data on the SoMo 650, please back it up before you run the update.

STEP 3: Transfer Files using a Memory Card

IMPORTANT! It is not recommended to transfer the files using ActiveSync or the Windows Mobile Device Center!

The directory SOMO650 containing the ROM image files must be moved to the SoMo 650 with a SD or CF memory card. Make sure your memory card has at least 40 MB of free space.

1. On your PC, use My Computer or Windows Explorer to locate

the directory SOMO650, which contains the upgrade files.

2. Copy the SOMO650 directory to your memory card.

DO NOT change the name of the folder!

3. Insert the memory card into the SoMo 650.

APPENDIX D: UPGRADING THE ROM IMAGE 55

STEP 4: Install th

Press and hold the Right programmable applicatio and the Calendar and Contacts shortcut buttons o

e Files

n button,

n your

SoMo 650.

While holding the three buttons, use the stylus to quickly

press the Reset button inside the hole on the bottom of your SoMo 650. Keep holding the Right programmable application button.

Reset button

Calendar shortcut button

Contacts shortcut button

Right programmable application button

56 | APPENDIX D: UPGRADING THE ROM IMAGE

An EBOOT screen will appear w

ith a timer, counting down

from 5 seconds.

IMPORTANT! Keep holding the Right programmable application b

therwise the installation will be aborted.

utton until the timer reaches 0 seconds!

The SoMo 650 will begin to download and update the ROM image.

APPENDIX D: UPGRADING THE ROM IMAGE 57

After the installation reports, “Update completed!” the Socket splash scre

en will appear for about 30 seconds.

The Windows Mobile splash screen will appear for about 30 seconds.

The Windows Welcome wizard will prompt you to set up Window

s Mobile. Follow the instructions on your screen.

After setting up Windows Mobile, the Today screen will appear, and the SoMo 650 is ready to use.

58 | APPENDIX D: UPGRADING THE ROM IMAGE

APPENDIX E

OLD SWITCH UTILITY

The Hold Switch Utility enables you to change the default behavior of the hold switch located on the left side of the SoMo 650 handheld computer. By default, when the hold switch is activated, the SoMo screen turns off.

NOTE: The Hold Switch Utility is included in SoMo ROM

version 1.1.xx and later. Check your ROM version by tapping Start |.Settings | System tab | System Info.

NOTE: If your SoMo does not include the Hold Switch Utility,

download it from: www.socketmobile.com/support/downloads Follow the installation instructions in the release notes.

NOTE: When the hold switch is activated, any connection

programs running on the SoMo will remain active.

NOTE: By default, the SoMo will automatically suspend

according to settings chosen in the Power applet. To access the applet, tap Start | Settings | System tab | Power.

1. Tap Start | Settings | System tab | Hold Switch.

s or

APPENDIX E: HOLD SWITCH UTILITY | 59

2. Use the utility to c

onfigure your settings.

• Leave screen enabled: Select to keep the screen on

when the hold switch is activated. A dialog will report that the hold switch is activated. Tapping ok or deactivating the hold switch will close the dialog.

NOTE: When the SoMo is reset, this option is

automatically re-enabled.

• Disable backlight: Select to keep the screen on but

disable the backlight, recommended for conserving battery life.

60 | APPENDIX E: HOLD SWITCH UTILITY

• Disable auto-suspend: Select to keep

the SoMo alive when the hold switch is activated, regardless of settings chosen in the Power applet.

NOTE: Use this option with caution to avoid

accidental depletion of the SoMo battery.

• Launch program when switch is activated: Use the

menu to select a program for the SoMo to automatically launch when the hold switch is activated (in the down position).

• Launch program when switch is deactivated: Use

the menu to select a program for the SoMo to automatically launch when the hold switch is deactivated (in the up position).

3. After entering your settings, tap ok.

APPENDIX E: HOLD SWITCH UTILITY | 61

APPENDIX F

HNICAL SUPPORT TEC

If you have trouble installing or using the SoMo 650, Socket has different support options to help you.

Online Knowledge Base:

Search for articles, Frequently Asked Questions or Hot Topics any time, day or night.

Online Requests:

Register your product and submit a question to our Technical Support Team. www.socketmobile.com/support/support/login.asp

By Phone:

You can reach our Tier 1 Technical Support by calling either of these numbers:

• USA & Canada Toll-Free: 800-279-1390

• Direct: +1- 510-933-3020

www.socketmobile.com/support/

Click FAQs

IMITED WARRANTY

Socket Mobile, Inc. (Socket) warrants this

aterial and workmanship, under normal use and service, for one (1)

ear from the date of purchase.

EXCLUDES: Consumables such as batteries, cables, cases, straps, and chargers (90 day coverage only).

An extended warranty is availab information, please visit: www.socketmobile.com/support

Incompatibility is not a defect covered by the Socket warranty. During the warranty period, Socket will, at its option, repair or replace the

efective product at no charge when furnished with proof of retail

d purchase, provided tha authorized Socket Service Center.

he returned product must be accompanied by a return material

uthorization (RMA) number issued by Socket or by a Socket Authorized

a Service Center container or equivalent and you must pay the shipping charges to Socket. Socket will pay surface shipping charges back to any location in the contiguous Un retail purchaser and is not transferable.

ocket may, at its option, replace or repair the product with new or

S reconditioned parts and the return property. Socket warrants the repaired or replaced products to be free from defects in material or workmanship for ninety (90) days after the return shipping date, or for the remainder of the original warranty period, whichever is greater.

. If you ship the product, you must use the original

t you deliver the product to Socket or to an

ited States. This warranty applies only to the original

le separately for the SoMo. For more

product against defects in

ed product becomes Socket's

This warranty does not cover the replacement of products damaged by abuse, accident, misuse or misapplication, nor as a result of service or modification other than by Socket. This warranty is void if you install batteries into the product that were not supplied by Socket.

SOCKET IS NOT RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING DAMAGE TO PROPERTY AND, TO THE EXTENT PERMITTED BY LAW, DAMAGES FOR PERSONAL INJURY. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not allow limitation of implied warranties, or the exclusion or limitation of incidental or consequential damages, so that the above limitations or exclusions may not apply to you. This warranty

gives you specific lega other rights which vary from state to stat

This product may contain fully tested, recycled parts, warranted as if new.

l rights and you may also have e.

For warranty information, please visit: www.socketmobile.com/support

LAIMER

DISC

EXCEPT TO THE EXTENT EXPRESSLY WARRANTED BY SOCK COMMUNICATIONS, INC, THIS PRODUCT IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. EXCEPT TO THE EXTENT REQUIRED BY LAW, SOCKET DOES NOT ASSUME ANY PRODUCT LIABILITY ARISING OUT OF, OR IN CONNECTION WITH, THE APPLICATION OR USE OF ANY PRODUCT OR APPLICATION DESCRI HEREIN.

BED

LIMITED SOFTWARE WARRANTY

LIMITED WARRANTY. SOCKET warrants that the original disk or CD RO is freeM from defects for 90 days from the date of delivery of the SOFTWARE.

CUSTOMER REMEDIES. SOCKET’S entire liability and your exclusive remedy shall be, at SOCKET return of the price paid o

r (b) replacement of the SOFTWARE which does not meet SOCKET’S Limited Warranty and which is returned to SOCKET with a copy of your receipt. Any replacement SOFTWARE will be warranted for the remainder of the original warranty period or 30 days, whichever is longer. THESE REMEDIES ARE NOT AVAILABLE OUTSIDE OF THE UNITED STATES OF AMERICA.

’S option, either (a)

NO OTHER WARRANTIES. SOCKET disclaims all other warranties, e express or implied, including but not limited to implied warr

ither

anties of merchantability and fitness for a particular purpose, with respect to the SOFTWAR

E and the accompanying written materials. This limited warranty gives you specific legal rights. You may have others which vary from state to state.

NO LIABILITY FOR CONSEQUENTIAL DAMAGES. In no event shall SOCKET or its suppliers be liable for any damages whatsoever (including, without limitation, damages for loss of business profits, business interruption, loss of business information, or other pecuniary loss) arising out of the use of or inability to use the SOFTWARE, even if SOCKET has been advised of the possibility of such damages. Because some states do not allow the exclusion or limitation of liability for consequential or incidental damages, the above limitation may not apply to you.

EXPORT LAW ASSURANCES. You may not use or otherwise export or reexport the SOFTWARE except as authorized by United States law and laws of the jurisdiction in which the SOFTWARE was obtained. In particular, but without limitation, none of the SOFTWARE may be used or otherwise exported or reexported (a) into (or to a national or resident of) a United States embargoed country or (b) to anyone on the U.S. Treasury Department’s list of Specially Designated Nationals or the U.S. Department of Commerce’s Table of Denial Orders. By using the SOFTWARE, you represent and warrant that you are not located in, under control of, or a national or resident of any such country or on any such list.

GOVERNMENT END USERS. If the SOFTWARE is supplied to the U. S. Government, the SOFTWARE is classified as “restricted computer software” as defined in clause 52.227-19 of the FAR. The U. S.

Government ‘ ause 52.22719 of the FAR

s rights to the SOFTWARE are as provided in cl

CONTROLLING LAW AND SEVERABILITY. This License shall be governed by the laws of the United States and the State o

f California. If for any reason a court of competent jurisdiction finds any provision, or portion thereof, to be unenforceable,

the

remainder of this License shall continue in full force and effect.

REGULATORY COMPLIANCE

FCC: Part 15, Class B Industry Canada CE: EN Anatel NOM, COFETEL RoHS and WEEE compliant Electrical Safety EN60950, UL, CUL EMI/RFI Wi-Fi Alliance Certification Bluetooth Certification (BQB test), Bluetooth QD ID B012762 USB IF Test Microsoft Windows Mobile 5.0, 6 Logo Test Certification EU/International: EN301 489-1, -17 EN61000-4-2: 1995, ESD ± 8kV air/±4kV contact EN61000-4-3: 1997, radiated Immunity 3V/m EN61000-4-4: 1995, EFT ± 0.5kV EN61000-4-5: 1995, Surge ± 0.5kV EN61000-4-6: 1

FCC Interference Statement (USA)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

FCC Caution: Any changes or modifications not expressly

pproved by th ould void the

a e party responsible for compliance c user's authority to op

erate this equipment.

vice complThis de

subject

to the following two conditions: (1) This device may not cause harmful in interference received, includ

ies with Part 15 of the FCC Rules. Operation is

terference, and (2) this device must accept any

ing interference that may cause

undesired operation.

IMPORTANT: RADIATION EXPOSURE STATEMENT

THIS EQUIPMENT COMPLIES WITH FCC RADIATION EXPOSUR LIMITS S END USERS MUST FOLLOW THE SPECIFIC OPERATING INSTRUCTIONS FOR SATISFYING TO MAINTAIN COMPLIANCE WITH FCC RF EXP COMPLIANCE REQUIREMENTS, PLEASE FOL INSTRUCTIONS AS DOCUMENTED

ET FORTH FOR AN UNCONTROLLED ENVIRONMENT.

RF EXPOSURE COMPLIANCE.

OSURE

LOW OPERATION

IN THIS MANUAL.

his PDA has beT

luetooth and WLAN are transmitting simultaneously. This PDA

must not be co-located or operating in conjun

en tested and demonstrated compliance when

ction with any

other antenna or transmitter.

For body worn operation, this device has been tested and meets the FCC RF exposure guidelines when used with the Socket accessories supplied or designated for this product. Use of oth accessories may not ensure compliance with FCC RF exposure

guidelines."

Industry Canada Statement:

This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this

ust accept any interference received, includingm

interference

that may cause undesired operation.

IMPORTANT: RADIATION EXPOSURE STATEMENT

THIS EQUIPMENT COMPLIES WITH IC RADIATION EXPOSURE LIMITS SET FORTH FOR AN UNCONTROLLED ENVIRONMENT.

SERS MUST FOLLOW THE SPECIFIC OPERATING

END U

device

INSTRUCTIONS FOR SATISFYING RF EXPOSURE COMPLIA TO MAINTAIN COMPLIANCE WITH IC RF EXPOSURE COMPLIANCE REQUIREMENTS, PLEASE FO INSTRUCTIONS AS DOCUMENTED IN THIS MANUAL.

LLOW OPERATION

NCE.

European Union Notice:

Radio products with the CE marking comply with the R&TTE Directive (1999/5/EC), t

ow Voltage Directive (73/23/EEC) issued by the Commission of

he EMC Directive (89/336/EEC) and the

the European Community.

Com

pliance with these directives implies conformity to the

foll

owing

Eur

opean Norms:

•

EN 60950 Product Safety

•

EN 300 328 Technical requirement for radio equipment

•

EN 301 489-1/-17 General EMC requirements for radio equipment

Brazil:

Este produto está homologado pela ANATEL, de acordo com o procedimentos regulamentado a

tende aos requisitos técnicos aplicados.

Para maiores informaçðes, consulte o site da ANATEL –

www.anatel.gov.br

s pela Resoluçao 242/2000, e

Certificado de Homologação No 1270-08-4603 (01)07898915959 67 3

“Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estaçðes do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.”

xico:

M: 0802CE05828

COFETEL: RCPSOSO08-0567

12/2008 Printed in U.S.A.

Socket Mobile SoMo 650 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

COPYRIGHT NOTICE

IMPORTANT SAFETY INSTRUCTIONS

TABLE OF CONTENTS

1 | INTRODUCTION

PACKAGE CONTENTS

SOMO 650 CONFIGURATIONS

SYSTEM COMPATIBILITY REQUIREMENTS

ADDITIONAL ACCESSORIES

PRODUCT REGISTRATION

HARDWARE FEATURES

CHARGING/SYNC CRADLE

2 | GETTING STARTED

STEP 1: INSTALL THE BATTERY

STEP 2: CHARGE THE BATTERY

STEP 3: SET UP YOUR SOMO 650

STEP 4: INSTALL ACTIVESYNC ON A HOST PC

STEP 5: CONNECT THE SOMO TO THE COMPUTER

3 | USING THE SOMO 650

BUTTONS

HOLD SWITCH

STYLUS

ADDING A USB KEYBOARD/MOUSE

START MENU

ONLINE HELP

WIRELESS RADIO MANAGER

4 | WI-FI COMPANION

MAIN SCREEN OF WI-FI COMPANION

WI-FI STATUS ICON

WI-FI FINDER

FINDING AND CONNECTING TO A WLAN

SocketScan Icons

STEP 1: PREPARE THE SCANNING HARDWARE

STEP 2: ENABLE CORDLESS SCANNING

STEP 3: CONNECT SCANNER TO SOMO

STEP 4: START APPLICATION

STEP 5: SCAN BAR CODES

STEP 2: START SOCKETSCAN

STEP 3: INSERT THE CARD

STEP 4: START APPLICATION

STEP 5: SCAN OR READ DATA

Soft Reset

Hard Reset

Clean Reset

REGULATORY COMPLIANCE
