Socket Mobile D700, D730, D740, D745, D750 User Manual

DuraScan

®

700 Series User Guide

socketmobile.com

Bluetooth® wireless technology

700, 730, 740, 745, 750, 755  760

Barcode Scanner

www.socketmobile.com

Package Contents 4

TABLE OF CONTENTS

Optional Charging Accessories 5

Product Information 6

Attach Wrist Strap 7

Charge the Battery 8

Powering On/Off 9

Scanning Barcodes 10

Bluetooth Connection Modes 11-12

Bluetooth Connection Roles/Reconnection 13-15

Setup using Application Mode

• Apple® 16-17

• Android 18-19

• Windows PC 20

Setup without software application (Basic Mode):

• Apple® 21

• Android 22

• Windows PC 23

Pairing Reset (Bluetooth connection) 24

TABLE OF CONTENTS

Factory Reset 25

Restore Method 26

Battery Replacement 27

Quick Programming 28-33

Status Indicators 34-37

Product Specifications 38-39

Supported Symbologies 40-42

Safety, Bluetooth, Compliance & Warranty 43-49, 52-55

Battery Warning Statements 50-51

DuraScan

PACKAGE CONTENTS

D700 Series

Charging CableWrist Strap

Thank you for choosing Socket Mobile!

Let’s get started!

© 2021 Socket Mobile, Inc. All rights reserved. Socket®, the Socket Mobile logo, SocketScan™, DuraScan®, Battery
Friendly® are registered trademarks or trademarks of Socket Mobile, Inc. Microsoft® is a registered trademark of
Microsoft Corporation in the United States and other countries. Apple®, iPad®, iPad Mini®, iPhone®, iPod Touch®,
and Mac iOS® are registered trademarks of Apple, Inc., registered in the U.S. and other countries. The Bluetooth®
Technology word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such
marks by Socket Mobile, Inc. is under license. Other trademarks and trade names are those of their respective
owners.

Available separately

OPTIONAL CHARGING ACCESSORIES

Chrn Stnd

AC Power Suppl

International Adapters

available

For all optional accessories visit our Socket Store.

Chrn CrdleChrn Doc

5

PRODUCT INFORMATION

Scan Indicator Light

Bluetooth Light (Blue)

Battery Light
(Green/Yellow/Red)

Scan button

Power button*

Scanner head

Product label

Power Connector

Battery Door

Stand Attachment

Lanyard Eyelet

Charging pins

The DuraScan 700 Series has a protection rating of IP54 for dust and water protection.

Socket Mobile’s barcodes scanners can be wiped clean with a cloth dampened with
isopropyl alcohol or water. Or, the barcode scanners can be wiped clean with a Sani­Cloth.

Warning: DO NOT IMMERSE IN WATER (scanner’s mechanics could be damaged)

*Also used to display the on-screen keyboard in Basic Mode (iOS only).

6

Attch the Wrst Strp (optional)

ATTACH WRISTRAP

1. Detach the string loop of the tether from the wrist strap.

2. Feed the string loop through the eyelet.

3. Pull the tether through the string loop.

4. Pull tight so the string loop is secure.

5. Reattach the string loop’s tether to the wrist strap.

7

CHARGE THE BATTERY

To open

The scanner must be fully charged before first use. Please allow 8
hours uninterrupted charging for the initial battery charge.

Lift the rubber flap to access the power connector.

• Yellow Light = Charging

• Green Light = Fully charged

Importnt: Charging from a computer USB port is not reliable
and not recommended.

Rubber Flap

Power Adapter

8

POWERING ON/OFF

Power button

Powern On

Press and hold down the small
power button until the Battery
light turns on and the scanner
beeps twice (low-high).

Powern Off/ Dsconnectn

Press and hold down the small
power button until the scanner
beeps twice (high-low) and all
lights turn off.

The scanner will power off
automatically if device is not
connected within 5 minutes.
Scanner connected to a device
will power off within 2 hours if
idle/inactive.

9

1D/2D Brcode nd OCR

SCANNING BARCODES

Aim the scan beam straight

across the entire barcode

Trigger button

Scnnn Brcodes

1. Hold the scanner a few inches from the barcode.

2. Aim, press and hold the trigger button.

By default, the scanner will beep, vibrate, and the scan indicator
will flash green to confirm a successful scan.

Cuton: Do not stare directly into the scanner’s light beam.

10

Opertn Sstem Connecton Optons

BLUETOOTH CONNECTION MODES

Operating

Systems

(OS)

Android

Devices

Android 4.0.3 &

later

Bluetooth

HID

Support

Yes Yes N/A

Bluetooth

SPP

Support

Bluetooth

Apple
Serial

Specific

(MFi

Mode)

Apple iOS

Windows

PC

Mac OS

Note: To switch from one mode to the other you must remove the
pairing information from both devices - host device and the scanner.
(see pairing reset procedure on page 24)

iPod, iPhone, &

iPad

Windows 7, 8, 10 Yes Yes N/A

Mac OS X 10.4 to

10.X

Mac Books, Mac

Mini, & iMac

Yes N/A Yes

Yes No N/A

11

Connect your scanner using one of the following Bluetooth

BLUETOOTH CONNECTION MODES

connection modes:

Bluetooth Connecton Profles

Bluetooth Mode Description

Bsc Mode
(HID) *Defult

Human Interface
Device Profile

App Mode
(SPP)

Serial Port
Profile

App Mode
(MF-SPP)

Apple Specific
Serial Profile

• NO software installation needed

• Connects to most devices

• Good for barcodes containing small amounts
of data

• Scanner interacts with host device like a
keyboard

For Android or Windows

1. Software installation is required

2. More efficient and reliable data
communications for barcodes containing lots
of data

3. If you have an application that supports
Socket Mobile Scanners this is the mode
recommended

For iOS Devices

1. Must use with an App developed to work with
iOS devices

2. Software installation is required

3. If you have an iOS application that supports
Socket Mobile Scanners this is the mode to
use

*B defult, the scnner s set to Bsc Mode (HID)

12

Advanced users only.

BLUETOOTH CONNECTION ROLES

Basic Mode (HID) Keyboard

Changes a scanner in HID-Peripheral mode to HID-Keyboard mode.

For Mac OS, Apple iOS, and other smart devices.

Basic Mode (HID) Peripheral

Changes a scanner in HID-Keyboard mode to HID-Peripheral mode.

For some MS Windows or Android mobile devices.

Scan only with scanner in Application Mode (SPP)
*For Windows PC only.

Acceptor (default)

Configures the scanner to accept a Bluetooth connection puts the
scanner in discoverable mode.

Initiator

Configures the scanner to initiate a connection to a computer/device
with the Bluetooth Device Address specified in the barcode.

The barcode must be formatted in Code 128 and contain the data
#FNIaabbccddeeff# such that aabbccddeeff is the Bluetooth device
address of the computer/device you want to connect to the scanner.

You must create a custom barcode for each computer/device that
you want to connect to the scanner.

You can use barcode generating software or website (e.g., http://
barcode.tec-it.com)

13

DATA MODE-FOR SPP MODE ONLY

Advanced users only.

Packet Mode (default)

Configures the scanner to transmit decoded data in packet format.

Raw Mode - Android and Windows only

Configures the scanner to transmit decoded data in raw (unpacketed)
format.

14

BLUETOOTH RECONNECTION

All Bluetooth Connection Modes are OK.

Important! After scanning this command barcode, power off and
power on the scanner to make sure it is configured properly.

Enable Automatic Reconnection from scanner (default)

Configure the scanner to automatically initiate a connection to the
last paired computer/device after the scanner is powered on.

Disable Automatic Reconnection from scanner

Configure the scanner to wait for a computer/device to initiate a
Bluetooth connection after the scanner is powered on.

15

SET UP-APPLE IOS APP MODE

Scan QR Code using your host device to download Socket Mobile
Companion app to pair your scanner.

To set up using the Socket Mobile Companion app, watch Youtube video
for demonstration.

For quc set up

1. Power on the scanner. Make sure the scanner is discoverable
(unpaired). The Blue light should be blinking fast.

2. Scan barcode. The scanner will beep 3 times.

App Mode (MFi-SPP)

3. Turn on Bluetooth on the Apple device. Go to Settings >

Bluetooth.
A Bluetooth devices search will begin.

16

SET UP-APPLE IOS APP MODE

4. Tap Socket D700[xxxxxx] in the list of other devices found. After

a few seconds the status will change to “Connected” and the scanner
blue LED will stop blinking and turn solid blue.

Note: The characters in brackets are the last 6 characters of the
Bluetooth Address.

5. Launch your scanner-enabled Application. The scanner will beep

once indicating that it is connected to the appropriate application.

Now you are ready to scan barcodes!

Please check with your scanner application vendor or visit

www.socketmobile.com/appstore to confirm your scanner-enabled

application supports the scanner.

17
