Socket Mobile D750 Users Manual
DURASCAN
TM
socketmobile.com
Bluetooth Barcode Scanner
SERIES 700
Model D750
www.socketmobile.com
Application Mode (MFi-SPP) Setup for Apple® iOS 22
TABLE OF CONTENTS
Application Mode (SPP)
• Android 17
• Windows PC 20
• Windows (Peripherals) 20
Basic Mode (HID)
• Android 13
• Windows PC 14
• Windows (Peripherals) 15
Battery Charger & Battery Warning 40-44
Bluetooth Connection 25
Bluetooth Connection Modes 11
Bluetooth Unpairing 24
Command Barcodes 26
Helpful Resources 34
Optional Charging Accessories 8
TABLE OF CONTENTS
Package Contents 4
Powering on/off 9
Product Information 5
Product Specifications 33
Safety, Compliance & Warranty 35-46
Scanning Barcodes 10
Status Indicators 30
DuraScan
PACKAGE CONTENTS
D750
Lanyard
AC adapter* & USB to
DC plug cable
*Use the plug that is
regionally appropriate
Thank you for choosing Socket Mobile!
Let’s get started!
© 2010-2016 Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, and
SocketScan are registered trademarks or trademarks of Socket Mobile, Inc. The
Bluetooth word mark and logo are registered trademarks of the Bluetooth SIG, Inc.
USA, and any use by Socket Mobile, Inc. is under license. All other trademarks and
trade names contained herein may be those of their respective owners.
PRODUCT INFORMATION
Scanner head
Green/Red LED
Bluetooth LED (Blue)
Battery LED (Green/Yellow/Red)
Trigger button
Power button*
Direct Current
Product label
Lanyard
Pins for
charging
cradle
*Also used for keyboard Pop-up in Basic Mode (HID) only
5
1. Attach the Lanyard (optional)
SCANNER SETUP
Detach the string loop of the tether from the lanyard. Then feed the
string loop through the slot. Pull tight so the string loop is secure,
reattach the string loop to the tether from the Lanyard.
6
6 Hours
CHARGE THE BATTERY
The scanner must be fully charged before rst use. Please allow 6 hours
uninterrupted charging for the initial battery charge.
For the Scanner, lift the rubber ap to access the power connector.
• Red LED = Charging
• Green LED = Fully charged
Important: Charging from a computer USB port is not reliable and
not recommended.
Battery warning: Do not remove the pre-installed battery.
The DuraScan contains a rechargable lithium-ion battery.
The battery may be replaced with a Socket Mobile battery
replacement kit. See socketmobile.com for replacement battery.
See other battery warning at pg. 39
7
Charging with Cradle or QX Stand is
OPTIONAL CHARGING ACCESSORIES
optional (available separately).
Charging Cradle QX Stand
Battery charger warning: Only use the dedicated charger
provided for this unit. See more battery charger warnings at pg. 41
8
POWERING ON/OFF
Power button
Powering On:
Press and hold down the small
power button until the LED turns
blue and the scanner beeps twice
(low-high).
Powering Off/ Disconnecting:
Press and hold down the small
power button until the scanner
beeps twice (high-low).
The scanner can power off
automatically if it is not connected
within 5 minutes and it is
connected within 2 hours of
inactivity.
9
1D Barcode
SCANNING BARCODES
Aim the scan beam straight
across the entire barcode.
Trigger button
2D Barcode
Aim at the center.
Scanning Barcodes
1. Hold the scanner a few inches from the barcode.
2. Aim, press and hold the trigger button.
By default, the scanner will beep, vibrate, and the LED will ash green
to conrm successful scan.
Caution: Do not stare directly into the LED beam.
10
Connect your scanner using one of the following Bluetooth connection
BLUETOOTH CONNECTION MODES
modes:
Bluetooth Connection Proles
Bluetooth Mode Description
Basic Mode (HID)
(Default)*
Human Interface
Device Prole
Application Mode
(SPP)
Serial Port Prole
Application Mode
(MFi-SPP)
Apple Specic
Serial Prole
*By default, the scanner is set to Basic Mode (HID).
• “NO” software installation needed
• Connects to most devices
• Good for barcodes containing small amounts of
data
• Scanner appears like a keyboard to host device
• Software installation required
• More efcient and reliable data communications
for barcodes containing lots of data
• Must use with an App developed to work with
iOS devices
• Apple MFI tested and certied
• If you have an application that supports Socket
Mobile Scanners this is the mode you want to use
11
Operating System Connection Options
BLUETOOTH CONNECTION MODES
Operating
Systems
(OS)
Android Android 2.1 & later Yes Yes N/A
Devices
Bluetooth
HID
Support
Bluetooth
SPP
Support
Bluetooth
Apple
Serial
Specic
(MFi Mode)
Apple iOS
Windows
Mobile
Windows PC Windows 7, 8, 10 Yes Yes N/A
Mac OS
Note: To switch from one mode to the other you must remove the
pairing information from both devices - host computer and the scanner.
(see unpairing procedure on page 21)
12
iPod, iPhone, &
iPad
Windows Mobile
6.x
Mac OS X 10.4 to
10.X
Mac Books, Mac
Mini, & iMac
Yes N/A Yes
Yes Yes N/A
Yes No N/A
Android: Connect Android Device in Basic Mode (HID)
BASIC MODE
1. Power on the scanner. Make sure the scanner is
discoverable (unpaired).
2. Touch Home | Menu | Settings | Wireless & Networks |
Bluetooth settings
3. Make sure the device has Bluetooth “On” and scan for devices.
4. In the list of found devices, select Socket scanner [xxxxxx]. Tap Pair.
5. The scanner will connect to the Android device.
6. The scanner will beep once after it has connected and is ready to scan
barcodes.
13
Apple: Connect Apple iOS Device or Mac OS Device Basic Mode (HID)
BASIC MODE
In this mode the scanner works and behaves just like a keyboard.
Therefore, scanner will work with Safari, Notes, and any other
applications that supports an active cursor.
1. Power on the scanner. Make sure the scanner is
discoverable (unpaired).
2. Start a Bluetooth device search.
• iOS: Tap Settings | General | Bluetooth. Turn on Bluetooth.
A Bluetooth device search will begin.
• Mac OS: Click System Preferences | Internet & Wireless | Bluetooth.
In Bluetooth preferences, select the On checkbox. Click Set up New
Device... A Bluetooth device search will begin.
3. In the device list, tap on Scanner [xxxxxx]. Tap Pair.
4. The Scanner will connect to the Apple device.
5. The Scanner will beep once after it has connected and is ready to scan
barcodes.
14
