DuraScan

PACKAGE CONTENTS

D700

Lanyard

Charging Cable

Thank you for choosing Socket Mobile!

Let’s get started!

© 2017 Socket Mobile, Inc. All rights reserved. Socket®, the Socket Mobile logo, SocketScan™,
DuraScan®, Battery Friendly® are registered trademarks or trademarks of Socket Mobile, Inc. Micro­soft® is a registered trademark of Microsoft Corporation in the United States and other countries.
Apple®, iPad®, iPad Mini®, iPhone®, iPod Touch®, and Mac iOS® are registered trademarks of Apple,
Inc., registered in the U.S. and other countries. The Bluetooth® Technology word mark and logos are
registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Socket Mobile,
Inc. is under license. Other trademarks and trade names are those of their respective owners.

PRODUCT INFORMATION

Scanner head

Scan Indicator Light

Bluetooth Light (Blue)

Battery Light (Green/Yellow/Red)

Trigger button

Power button*

Power Connector

The D700 has a protection rating of IP54 for dust and water protection. It is also made with
antimicrobial to help provide protection against bacteria.

Socket Mobile’s barcodes scanners can be wiped clean with a cloth dampened with isopropyl
alcohol or water. Or, the barcode scanners can be wiped clean with a Sani-Cloth.

Warning: DO NOT IMMERSE IN WATER (scanner’s mechanics could be damaged)

DO NOT USE BLEACH FOR CLEANING (scanner’s material property may be aected)

Product label

Stand Attachment

Lanyard Eyelet

Charging pins

*Also used to display the on-screen keyboard in Basic Mode (iOS only).

5

Attach the Lanyard (optional)

SCANNER SETUP

1. Detach the string loop of the tether from the lanyard.

2. Feed the string loop through the eyelet.

3. Pull the tether through the string loop.

4. Pull tight so the string loop is secure.

5. Reattach the string loop’s tether to the lanyard.

6

CHARGE THE BATTERY

Power Adapter

Rubber Flap

To open

The scanner must be fully charged before rst use. Please allow 6 hours

uninterrupted charging for the initial battery charge.

Lift the rubber ap to access the power connector.

• Yellow Light = Charging

• Green Light = Fully charged

Important: Charging from a computer USB port is not reliable and
not recommended.

7

Available separately

OPTIONAL CHARGING ACCESSORIES

Charging Cradle Charging Stand AC Power Supply

International Adapters

available

For all optional accessories visit our Socket Store.

8

POWERING ON/OFF

Power button

Powering On:

Press and hold down the small
power button until the Battery
light turns on and the scanner
beeps twice (low-high).

Powering O/ Disconnecting:

Press and hold down the small
power button until the scanner
beeps twice (high-low) and all

lights turn o.

The scanner will power o

automatically if device is not con­nected within 5 minutes. Scanner
connected to a device will power

o within 2 hours if idle/inactive.

9

1D Barcode

SCANNING BARCODES

Aim the scan beam straight

across the entire barcode.

Trigger button

Scanning Barcodes

1. Hold the scanner a few inches from the barcode.

2. Aim, press and hold the trigger button.

By default, the scanner will beep, vibrate, and the scan indicator will

ash green to conrm a successful scan.

Caution: Do not stare directly into the scanner’s light beam.

10

Connect your scanner using one of the following Bluetooth connection

BLUETOOTH CONNECTION MODES

modes:

Bluetooth Connection Proles

Bluetooth Mode Description

Basic Mode (HID)
(Default)*

Human Interface

Device Prole

Application Mode

(SPP)

Serial Port Prole

Application Mode

(MFi-SPP)

Apple Specic
Serial Prole

• NO software installation needed

• Connects to most devices

• Good for barcodes containing small amounts of
data

• Scanner interacts with host device like a keyboard

For Android or Windows

1. Software installation is required

2. More ecient and reliable data communications
for barcodes containing lots of data

3. If you have an application that supports Socket
Mobile Scanners this is the mode recommended

For iOS Devices

1. Must use with an App developed to work with

iOS devices

2. Software installation is required

3. If you have an iOS application that supports

Socket Mobile Scanners this is the mode to use

*By default, the scanner is set to Basic Mode (HID).

11

Operating System Connection Options

BLUETOOTH CONNECTION MODES

Bluetooth

Operating

Systems

(OS)

Android

Apple iOS

Windows PC Windows 7, 8, 10 Yes Yes N/A

Mac OS

Note: To switch from one mode to the other you must remove the
pairing information from both devices - host device and the scanner. (see
unpairing procedure on page 21)

Devices

Android 4.0.3 &

later

iPod, iPhone, &

iPad

Mac OS X 10.4 to

10.X

Mac Books, Mac

Mini, & iMac

Bluetooth

HID

Support

Yes Yes N/A

Yes N/A Yes

Yes No N/A

Bluetooth

SPP

Support

Apple
Serial

Specic

(MFi Mode)

12

Android: Connect Android Device in Basic Mode

BASIC MODE

In this mode the scanner functions and communicates similar to a key­board. Therefore, scanner will work with Notes, and any other
application that supports an active cursor.

1. Power on the scanner. Make sure the scanner is
discoverable (unpaired) and the blue light blinks fast.

2. Settings | Bluetooth.

3. Make sure the device has Bluetooth “On” to scan for devices.

4. In the list of found devices, select D700 [xxxxxx]. Tap Pair.

5. The scanner will connect to the Android device.

6. The scanner will beep once after it has connected.

*If you have trouble connecting or pairing with host device, turn host

device’s Bluetooh o/on, and/or perform factory reset to the scanner

(see page 44).

Now you are ready to scan barcodes!

13

Apple: Connect Apple iOS Device or Mac OS Device Basic Mode

BASIC MODE

In this mode the scanner functions and communicates similar to a key­board. Therefore, scanner will work with Safari, Notes, and any other
application that support an active cursor.

1. Power on the scanner. Make sure the scanner is
discoverable (unpaired). The Blue light blinks fast.

2. Start a Bluetooth device search.

• Settings | Bluetooth: Turn on Bluetooth and search for device.

• Mac OS: Click System Preferences | Bluetooth. A Bluetooth device
search will begin.

3. In the device list, tap on D700 [xxxxxx]. Tap Pair.

4. The scanner will connect to the Apple device.

5. The scanner will beep once after it has connected.

Now you are ready to scan barcodes!

To use the virtual keyboard while the scanner is connected double tap on
the power button. See YouTube video for demonstration.

14

BASIC MODE

Windows: Connect Windows Device in Basic Mode

In this mode the scanner functions and communicates similar to a
keyboard. Therefore, scanner will work with Notes, and any other
application that support an active cursor.

Highly recommended, allows two-way communications with Android, or
Windows Devices. Scanner-enabled app software installation
required.

1. Turn Bluetooth on for your device. Go to Settings > Bluetooth. A
Bluetooth Devices search will begin.

2. Tap Socket D700[xxxxxx] in the list of Devices found. After a few
seconds the “Not Paired” status will change to “Connected” or
“Paired” and the scanner blue light will stop blinking and turn solid
blue.

Now you are ready to scan barcodes!

15
