Smeg ST1108, ST1108S User Manual

INSTRUCTION MANUAL

GGUUIIDDEEFFOORRUUSSIINNGGTTHHEEDDIISSHHWWAASSHHEERRAANNDDTTHHEEWWAASSHHIINNGGPPRROOGGRRAAMMS

Contents

1. Description of the controls________________________________16

2. Troubleshooting _______________________________________25

Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need about the right conditions for the proper, safe use of your dishwasher. The individual sections are laid out to provide you with a step-by-step guide to all your appliance's functions; the texts are easy to understand and are complete with detailed illustrations. This user-friendly manual will provide answers to all your questions about use of the dishwasher. For any other information about use and maintenance of the dishwasher, read the enclosed manual carefully.

USER INSTRUCTIONS: useful information is provided for the use of the washing programs and all the dishwasher's functions.



User instructions

1. Description of the controls

1.1 Upper panel

All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off etc. procedures are only possible when the door is open.

ON/OFF BUTTON

Pressing this button energises the appliance.

SELECTED PROGRAM INDICATOR LIGHTS

Illumination of this light denotes the program selected and the

occurrence of a fault (troubleshooting).

PROGRAM SELECTION BUTTON

By pressing this button in sequence it is possible to select the desired

program.

SALT WARNING LIGHT

Illumination of this light signals that salt container is empty.

RINSE AID WARNING LIGHT

Illumination of this light signals that rinse aid dispenser is empty.

EXTRA PROGRAM BUTTON

This button gives access to the one of the five extra programs (see

table).

EXTRA PROGRAM LIGHT

Illuminates to indicate that one of the five extra programs (see table) is

going to be executed.

PROGRAM DELAY BUTTON

Press this button to delay the start of the program by up to 9 hours.

9 INFORMATION DISPLAY

(certain models only)

(on some models only)



User instructions

SETTING THE WASHING PROGRAM AND SWITCHING ON

To select the most suitable program for the dishes to be washed refer to the table below, which indicates the most appropriate program according to dish type and degree of soiling.

After using the table to identify the most appropriate washing program:

• press the

INDICATOR LIGHT (2)

• keep pressing the

ON/OFF

button

to illuminate;

PROGRAM SELECTION

indicator light corresponding to the desired program illuminates;

• close the door; after about 2" the program will start. While it is in progress, the relative

LIGHT

being executed).

(1)

and wait for the

button

PROGRAM

(3)

until the

will flash (indicating that the program is

PROGRAMME,

NUMBER & SYMBOL

run the soak program with half loads.

Only

(**) When the "

RINSE

DELICATE

AUTO 60-70

BIO

AUTO 40-50

LOAD CROCKERY

AND CUTLERY

Pans and dishes for

rinsing and drying

with normal dirt

Normally soiled dishes, including dried-on residue

with normal dirt

" or "

Dishes

AUTO 60-70

PROGRAM

PROGRESS

Cold rinse Rinse at 68°C Dry

Cold prewash Wash at 45°C Cold rinse Rinse at 68°C Dry

Cold prewash Wash at 50°C Wash at 65°C Cold rinse Rinse at 68°C Dry

Cold prewash Wash at 50°C Cold rinse Rinse at 55°C Dry

" program is selected, the dishwasher

DURATION CONSUMPTION

MINUTES

(2)

WATER

LITRES (1)

45' 9 0,8

59' 12 0,90

(**) (**) (**)

85' 16 1,10

recognises the type of dirt and automatically adjusts the washing parameters as appropriate.

(1) Average power consumption with the softener set on

level 2

(2) The cycle duration and power consumption may vary according to the water and room temperatures, and the type and amount of dishes.

POWER KWh (2)



User instructions

PROGRAMME,

NUMBER & SYMBOL

run the soak program with half loads.

Only

SUPER

SOAK

QUICK

AUTO 40-50

ECO

(*) EN 50242

INTENSIVE

To execute programs

LOAD CROCKERY

AND CUTLERY

pans and dishes,

Pans and dishes

a further wash

Wash immediately

after use for dishes

with normal dirt

Wash immediately

after use for dishes

with normal dirt

Normally soiled

pans and dishes,

dried-on residue

6,7,8,9,10

PROGRAM

PROGRESS

Very dirty

even with

dried-on dirt

awaiting

Dishes

with light dirt

including

Prewash at 45°C Wash at 70°C 2 cold rinses Rinse at 70°C Dry

Cold prewash

Wash at 38°C Cold rinse Rinse at 68°C

Cold prewash Wash at 40°C Wash at 55°C Cold rinse Rinse at 68°C Dry

Wash at 55°C Cold rinse Rinse at 68°C Dry

Wash at 70°C 2 cold rinses Rinse at 70°C Dry

users must first press the

DURATION CONSUMPTION

MINUTES

(2)

WATER

LITRES (1)

105’ 20 1,50

9' 5

45' 13 0,70

(**) (**) (**)

175' 13 1,01

85' 17 1,45

extra programs button (6)

(*) Reference program as per EN 50242 standard.

(**) When the "

AUTO 40-50

" or "

AUTO 60-70

" program is selected, the dishwasher recognises the type of dirt and automatically adjusts the washing parameters as appropriate.

(–) Not present.

(1) Average power consumption with the softener set on

level 2

(2) The cycle duration and power consumption may vary according to the water and room temperatures, and the type and amount of dishes.

POWER KWh (2)



The washing cycle will not take place if the dishwasher door is left open or not properly closed.

User instructions

TABLE FOR CERTIFICATION BODIES

Reference standard EN 50242

Reference program ECO Load 10 place-settings Type of detergent B Amount of detergent 25 g Rinse aid setting Depending on the model 3/4 or 4/6

1.2 Washing programs

Before starting a washing program make sure that:

• The water supply tap is

• The

• The baskets have been

• The spray arms are able to

• The dishwasher door is

correct amount of detergent

dispenser

obstruction.

open.

has been added to the

correctly loaded.

rotate freely

securely closed

and without

EXTRA PROGRAMS

(6)

Button which can be selected directly using the program selector button. This button must be pressed (the light comes on) "main" program (1, 2, 3, 4 or 5). This function pressed again (the light goes out) if the user wishes to execute one of the 5 main programs at the next cycle.

gives access to

is retained in the memory

five extra programs

, so the button has to be

in addition to the ones

after

selection of the



User instructions

DELAYING THE PROGRAM

PROGRAM DELAY

The the program by up to operated at the time of day of your choice. Press the button several times in succession and the display will show the delay with which the appliance will start, beginning from

CANCELLING THE CURRENT PROGRAM

• To cancel the currently selected program, open the door and hold down the until the simultaneously (the word "end" is displayed on the window).

9 hours.

PROGRAM SELECTION (3)

indicator lights

(8)

button

can be pressed to delay the start of

This means that the dishwasher can be

9 hours

for programs 4 and 5 illuminate

button for a few seconds



• Close the door.

• After approximately 1 minute the dishwasher will advance to the end

of cycle.

CHANGING THE PROGRAM

To change the program in progress, simply open the door and select a new program. When the door is closed the dishwasher will automatically select the new program.

User instructions

TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT

• Always try to run the dishwasher

• Do not wash the dishes in running water.

• Use the washing program that is

load.

• Do not carry out any preliminary rinsing.

• If available, connect the dishwasher to a hot water supply up to 60°C.

• When possible,

the end of the washing cycle: the residual air and heat will dry the dishes perfectly.

TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT THE ENVIRONMENT

The phosphates contained in dishwasher detergents are harmful to the environment. To avoid using excessive amounts of detergent and to save on electricity, observe the following:

•

separate

to aggressive detergents and high temperatures;

•

do not pour

disable the drying cycle

the more delicate items from dishes that are more resistant

the detergent directly on the dishes.

fully loaded

most appropriate

for each type of

and leave the door open at

If the door has to be opened while washing is in progress, the program will be interrupted. The relative light will keep flashing and a beeper will signal that the cycle has not been completed. You must wait about

before closing the door to restart the program. When the door is

minute

closed the program will continue from where it was interrupted. This operation should might cause problems in execution of the program.

only be carried out if strictly necessary

, because it



User instructions

ADJUSTING THE WATER SOFTENING SYSTEM

electronically

or by

Depending on model, the setting may be made means of a

selector switch

ELECTRONIC SETTING (models with display)

N.B.:

for the setting below to be possible, a washing program other than

the soak program must be set.

Press the

PROGRAM DELAY

button

(8)

and keep it pressed until the preset value appears followed by a full stop (normally 3.). Release the button then press it again in succession to display the value required, referring to the table.

The 6 setting levels available will appear in this order:

3.,4.,5.,0.,1.,2.

When the value required appears on the display, release the button;

5 seconds

after

the system automatically returns to setting of the

program delay, and the setting will be made with the chosen value.

N.B.:

the display shows the water hardness setting and the program delay. The dot (.) after the number indicates that the water hardness setting is being displayed. If the dot (.) does not appear, the program delay is being displayed.



WATER HARDNESS TABLE

WATER HARDNESS

German Degrees (°dH) French Degrees (°dF)

0 - 5 0 - 9 0.

6 - 11 10 - 19 1. 12 - 21 20 - 36 2. 22 - 33 37 - 59 3. 34 - 45 60 - 79 4. 46 - 53 80 - 107 5.

SETTING

Contact your local water board for information on the hardness of your water supply.

User instructions

SWITCH SETTING (models without display)

According to the machine model, the selector which acts on the adjustment may be located:

• inside the plastic locking ring located on the the dishwasher;

• inside the water softener, just below the cap.

Both allow for adjustment to 5 settings:

right-hand

side, inside

WATER HARDNESS TABLE

WATER HARDNESS

German Degrees (°dH) French Degrees (°dF)

0 - 4 0 - 7 Setting N. 1 NO SALT

5 - 9 8 - 15 Setting N. 1 10 - 17 16 - 30 Setting N. 2 18 - 26 31 - 45 Setting N. 3 27 - 35 46 - 60 Setting N. 4 36 - 47 61 - 80 Setting N. 5

SETTING

Contact your local water board for information on the hardness of your water supply.


