Smeg CPF92IMX Technical sheet

CPF92IMX

Cooker, 90x60 cm, Portofino, Stainless steel, Hob type: Induction, Type of main oven: Thermo­ventilated, Type of second oven: Static, A, A

TYPE

Product Family: Cooker • Cooker size: 90x60 cm • Energy type: Electric • N. of ovens: 2 • Hob type: Induction • Type of main

oven: Thermo-ventilated • Type of second oven: Static • Cleaning system: Vapor Clean • EAN code: 8017709297343

AESTHETICS

Colour: Stainless steel • Aesthetics: Portofino • Material: Stainless steel • Door: With frame • Command panel finish: Finger

friendly stainless steel • Hob colour: Stainless steel • Handle: Smeg Portofino • Controls colour: Stainless steel • Display: Touch •

Handle Colour: Brushed stainless steel • Control knobs: Smeg Portofino • Glass type: Grey • No. of controls: 8 • Feet: Black •

Storage compartment: Door

PROGRAMS / FUNCTIONS

Traditional cooking functions: Static, Fan assisted, Circulaire, Eco, Large grill, Fan grill (large), Fan assisted bottom • Cleaning

functions: Vapor clean • Other functions: Defrost by time

PROGRAMS / FUNCTIONS AUXILIARY OVEN

Cooking functions cavity 2: 3 • Traditional cooking functions, cavity 2: Static, Small grill, Bottom

HOB OPTIONS

Multizone Option: Yes • Limited Power Consumption Mode: Yes • Limited Power Consumption Mode in W: 3700, 4800, 7400 W

OPTIONS MAIN OVEN

Timer: Yes • End of cooking acoustic alarm: Yes • Minimum Temperature: 50 °C • Maximum temperature: 260 °C

OPTIONS AUXILIARY OVEN

Minimum Temperature: 50 °C • Maximum temperature: 245 °C

HOB TECHNICAL FEATURES

Total no. of cook zones: 5 • 1st zone position: Front left • 2nd zone position: Rear left • 3rd zone position: Central • 4th zone

position: Rear right • 5th zone position: Front right • 1st zone type: Induction - multizone • 2nd zone type: Induction - multizone •

3rd zone type: Induction - single • 4th zone type: Induction - single • 5th zone type: Induction - single • 1st zone dimensions: 21.0

x19.0 cm • 2nd zone dimensions: 21.0x19.0 cm • 3rd zone dimensions: Ø 27.0 cm • 4th zone dimensions: Ø 18.0 cm • 5th zone

dimensions: Ø 21.0 cm • 1st zone power: 2.10 kW • 2nd zone power: 1.60 kW • 3rd zone power: 2.30 kW • 4th zone power:

1.20 kW • 5th zone power: 2.30 kW • 1st zone booster power: 2.30 kW • 2nd zone booster power: 1.85 kW • 3rd zone booster

power: 3.00 kW • 4th zone booster power: 1.40 kW • 5th zone booster power: 3.00 kW

MAIN OVEN TECHNICAL FEATURES

Net volume of the cavity: 70 l • Cavity material: Ever Clean enamel • No. of shelves: 5 • Type of shelves: Metal racks • No. of

lights: 1 • Light type: Halogen • Light Power: 40 W • Fan number: 1 • Cooking time setting: Start and Stop • Door opening: Flap

down • Light when oven door is open: Yes • Removable door: Yes • Full glass inner door: Yes • Removable inner door: Yes •

Total no. of door glasses: 3 • No.of thermo-reflective door glasses: 2 • Safety Thermostat: Yes • Cooling system: Tangential •

Grill type: Electric • Grill elememt: 1700 W • Large grill - Power: 2700 W • Lower heating element power: 1200 W • Upper

heating element - Power: 1000 W • Circular heating element - Power: 2000 W • Temperature control: Electronic

SECOND OVEN TECHNICAL FEATURES

Net volume of the second cavity: 35 l • Cavity material: Ever Clean enamel • No. of shelves: 4 • Type of shelves: Metal racks •

No. of lights: 1 • Light type: Incandescent • Light Power: 25 W • Fan number: 1 • Door opening: Flap down • Removable door:

Yes • Full glass inner door: Yes • Removable inner door: Yes • No. total door glasses: 3 • No. thermo-reflective door glasses: 2 •

Safety Thermostat: Yes • Cooling system: Tangential • Grill type: Electric • Grill element - power: 1300 W • Large grill - Power:

1900 W • Lower heating element - power: 700 W • Upper heating element - Power: 600 W • Temperature control: Electro-

mechanical
