SMC Networks SMC6724L2GSSC, SMC6724L2GLSC User Manual

TigerSwitch Module

Gigabit Uplink Module for
TigerSwitch 10/100 Switches

User Guide

SMC6724L2GSSC

SMC6724L2GLSC

TigerSwitch Module
User Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

6 Hughes
Irvine, CA 92618
Phone: [phone]

August 2001

Pub. # 150547-102 R02

Information furnished by SMC Networks, Inc. (SMC) is believed to
be accurate and reliable. However, no responsibility is assumed by
SMC for its use, nor for any infringements of patents or other rights
of third parties which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of
SMC. SMC reserves the right to change specifications at any time
without notice.

Copyright © 2001 by

SMC Networks, Inc.

6 Hughes

Irvine, CA 92618

All rights reserved. Printed in Taiwan

Trademarks:

SMC is a registered trademark; and TigerSwitch ia a trademark of
SMC Networks, Inc. Other product and company names are trade­marks or registered trademarks of their respective holders.

L

IMITED WARRANTY

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products
to be free from defects in workmanship and materials, under normal use and
service, for the applicable warranty term. All SMC products carry a standard 90-day
limited warranty from the date of purchase from SMC or its Authorized Reseller.
SMC may, at its own discretion, repair or replace any product not operating as
warranted with a similar or functionally equivalent product, during the applicable
warranty term. SMC will endeavor to repair or replace any product returned under
warranty within 30 days of receipt of the product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by
registering new products within 30 days of purchase from SMC or its Authorized
Reseller. Registration can be accomplished via the enclosed product registration
card or online via the SMC web site. Failure to register will not affect the standard
limited warranty. The Limited Lifetime warranty covers a product during the Life of
that Product, which is defined as the period of time during which the product is an
“Active” SMC product. A product is considered to be “Active” while it is listed on
the current SMC price list. As new technologies emerge, older technologies become
obsolete and SMC will, at its discretion, replace an older product in its product line
with one that incorporates these newer technologies. At that point, the obsolete
product is discontinued and is no longer an “Active” SMC product. A list of
discontinued products with their respective dates of discontinuance can be found at
http://www.smc.com/smc/pages_html/support.html.

All products that are replaced become the property of SMC. Replacement products
may be either new or reconditioned. Any replaced or repaired product carries
either a 30-day limited warranty or the remainder of the initial warranty, whichever
is longer. SMC is not responsible for any custom software or firmware,
configuration information, or memory data of Customer contained in, stored on, or
integrated with any products returned to SMC pursuant to any warranty. Products
returned to SMC should have any customer-installed accessory or add-on
components, such as expansion modules, removed prior to returning the product
for replacement. SMC is not responsible for these items if they are returned with the
product.

Customers must contact SMC for a Return Material Authorization number prior to
returning any product to SMC. Proof of purchase may be required. Any product
returned to SMC without a valid Return Material Authorization (RMA) number
clearly marked on the outside of the package will be returned to customer at
customer’s expense. For warranty claims within North America, please call our
toll-free customer support number at [phone]. Customers are responsible for
all shipping charges from their facility to SMC. SMC is responsible for return
shipping charges from SMC to customer.

i

L

IMITED WARRANTY

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR
REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE
FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU
OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER
IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING
WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH
THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS. SMC
SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THE ALLEGED DEFECT IN THE PRODUCT DOES NOT
EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE,
NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS
TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED
USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR
TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS
PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR
THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY
SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the
active SMC price list. Under the limited lifetime warranty, internal and external
power supplies, fans, and cables are covered by a standard one-year warranty from
date of purchase.

SMC Networks, Inc.

6 Hughes

Irvine, CA 92618

ii

C

OMPLIANCES

FCC - Class A

This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause interference to
radio communications. It has been tested and found to comply with the limits for a
Class A computing device pursuant to Subpart B of Part 15 of FCC Rules, which are
designed to provide reasonable protection against such interference when operated in a
commercial environment. Operation of this equipment in a residential area is likely to
cause interference, in which case the user, at his own expense, will be required to take
whatever measures may be required to correct the interference. You are cautioned that
changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.

You may use 50/125 or 62.5/125 micron multimode fiber optic cable or 9/125 micron
single-mode fiber optic cable for SC or ST-type connections.:

War ni ngs:1

. Wear an anti-static wrist strap or take other suitable measures to prevent

electrostatic discharge when handling this equipment.

2

. When connecting this hub to a power outlet, connect the field ground

lead on the tri-pole power plug to a valid earth ground line to prevent
electrical hazards.

iii

C

OMPLIANCES

EC Conformance Declaration - Class A

SMC contact for these products in Europe is:

SMC Networks Europe,
Edificio Conata II,
Calle Fructuós Gelabert 6-8, 2
08970 - Sant Joan Despí,
Barcelona, Spain.

This information technology equipment complies with the requirements of the
Council Directive 89/336/EEC on the Approximation of the laws of the Member
States relating to Electromagnetic Compatibility and 73/23/EEC for electrical
equipment used within certain voltage limits and the Amendment Directive 93/68/
EEC. For the evaluation of the compliance with these Directives, the following
standards were applied:

RFI Emission: • Limit class A according to EN 55022:1998

• Limit class A for harmonic current emission according to
EN 61000-3-2/1995

• Limitation of voltage fluctuation and flicker in low-voltage
supply system according to EN 61000-3-3/1995

Immunity: • Product family standard according to EN 55024:1998

• Electrostatic Discharge according to EN 61000-4-2:1995
(Contact Discharge: ±4 kV, Air Discharge: ±8 kV)

• Radio-frequency electromagnetic field according to
EN 61000-4-3:1996
(80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)

• Electrical fast transient/burst according to EN 61000-4-4:1995
(AC/DC power supply: ±1 kV, Data/Signal lines: ±0.5 kV)

• Surge immunity test according to EN 61000-4-5:1995
(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)

• Immunity to conducted disturbances, Induced by
radio-frequency fields: EN 61000-4-6:1996
(0.15 - 80 MHz with 1 kHz AM 80% Modulation: 3 V/m)

• Power frequency magnetic field immunity test according to
EN 61000-4-8:1993
(1 A/m at frequency 50 Hz)

• Voltage dips, short interruptions and voltage variations
immunity test according to EN 61000-4-11:1994
(>95% Reduction @10 ms, 30% Reduction @500 ms, >95%
Reduction @5000 ms)

LVD: • EN 60950 (A1/1992; A2/1993; A3/1993; A4/1995; A11/1997)

o

, 4a,

iv

C

OMPLIANCES

Industry Canada - Class A

This digital apparatus does not exceed the Class A limits for radio noise emissions from
digital apparatus as set out in the interference-causing equipment standard entitled
“Digital Apparatus,” ICES-003 of the Department of Communications.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques,” NMB-003 édictée par le ministère des Communications.

Japan VCCI Class A

Taiwan BSMI Class A

Australia AS/NZS 3548 (1995) - Class A

SMC contact for products in Australia is:

SMC Communications Pty. Ltd.
Suite 18, 12 Tryon Road,
Lindfield NSW2070,
Phone: [phone]
Fax: [phone]

v

C

OMPLIANCES

vi

T

ABLE OF

Description of Hardware . . . . . . . . . . . . . . . . . . . . . . . .1

Installing the Module . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Equipment Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Handling the Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

TigerSwitch Gigabit Uplink Modules . . . . . . . . . . . . . . . . . . . . 11

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

SMC6724L2GSSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

SMC6724L2GLSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . .13

C

ONTENTS

vii

T

ABLE OF CONTENTS

viii

D

ESCRIPTION OF

SMC’s TigerSwitch™ Gigabit Extender Module provides a Gigabit
fiber port that can be used for a high-speed backbone or server
connection.

The SMC6724L2GSSC contains one 1000BASE-SX multimode fiber
port that can be connected to a site up to 550 m (1805 ft) away.
The SMC6724L2GLSC contains one 1000BASE-LX single-mode fiber
port that can be connected to a site up to 5 km (16,404 ft) away.

1000BASE-SX Module

SMC6724L2GSSC

1000BASE-LX Module

SMC6724L2GLSC

TX

TX

H

RX

RX

ARDWARE

Gigabit Port LEDs

The switch’s front panel provides LEDs that indicate the presence
of modules installed in the rear-panel slots. Port status LEDs are
also provided on the front of the switch for “at-a-glance” network
monitoring. The following table details the indicator functions
provided by the module.

Extender Module LEDs

LEDs Condition Status

Status On A module is installed in this slot.

Off No module is installed in this slot.

1

D

ESCRIPTION OF HARDWARE

2

I

NSTALLING THE

CAUTION: The SMC6724L2GSSC and SMC6724L2GLSC modules
are designed for the SMC6724L2 and SMC6724L3. These modules
may only be installed in these switches. Do not try to install them
in any other TigerSwitch units.

Contact your distributor for advice on newly released switches that
may be designed for use with this module.

The TigerSwitch 10/100 Extender Module is field installable. Just
follow the instructions below.

M

ODULE

Equipment Checklist

After unpacking the Gigabit Extender Module, check the contents
of the box to be sure you have received the following items:

• One SMC6724L2GSSC or SMC6724LGLSC Gigabit Extender
Module

• SMC Warranty Registration Card

•This User Guide

3

I

NSTALLING THE MODULE

Handling the Modules

CAUTION: The modules can easily be damaged by electrostatic

discharge.

To prevent electrostatic damage, observe the following guidelines:

• Do not remove the module from its packaging until you are
ready to install it.

Do not touch any of the module’s pins, connectors or components

•

• Hold the module only by its edges or front panel.

• Wear an anti-static wristband connected to a suitable earth
ground whenever handling the module.

• Store or transport this module only in appropriate anti-static
packaging.

Instructions

CAUTION: The switch must be powered off before installing or

replacing any module.

1. Power off the switch: Disconnect the AC power cord from

the switch. If a redundant power unit (RPU) is present,
disconnect its DC cable connection to the switch.

2. Remove network cables: If you are replacing a module,

remove the cable attached to the port on the module.

3. Loosen the screws on the installed module or slot

faceplate: Using your fingers or a flathead screwdriver, turn

the screws securing the module (or faceplate on the slot) in a
counter-clockwise direction until they are free of the chassis.
Be sure not to completely remove the screws from the module
or faceplate.

.

4

I

NSTALLING THE MODULE

4. Remove the installed module or faceplate: Firmly pull on

the screws until the module is free of the switch. Carefully
slide the module straight out of the slot.

Keep the original faceplate for future use. If you should
remove the module, replace the faceplate to prevent dust and
debris from entering the unit and to maintain proper air flow.

Slot 2Slot 1

5. Insert the new module into the switch: Holding the new

module with the text on the front panel upright, carefully slide
the module into the lower slot on the rear panel, and press
gently until it snaps into place. Be sure the new module’s front
panel is flush with the switch panel.

Slot 2Slot 1

1000BASE-SXModule

5

I

NSTALLING THE MODULE

6. Secure the new module: Secure the new module in place by

screwing the attached screws clockwise into the switch’s
chassis. Tighten them enough to secure the module, but not so
tight as to prevent them from being unscrewed by hand.

7. Connect the network cable: Connect fiber cable to the port

on the newly installed module. See “Cable Specifications” on
page 9 in this guide for further information.

8. Power on the switch: Reconnect the previously removed

power sources to the switch. Check the switch's front-panel
LED indicators to ensure that the module is operating correctly.
Refer to the table of LEDs on page 1 for a description of the
LED indications. If the module does not respond, see
“Troubleshooting” on page 7.

Slot 2Slot 1

More details concerning connection options and network
applications can be found in the TigerSwitch 10/100 User Guide.
Information on the module’s configuration options can be found in
the Management Guide that is included with the base unit.

6

T

ROUBLESHOOTING

If you experience any problems with the module, check the
following items before contacting SMC Technical Support:

• Ensure that the switch with the Gigabit Extender Module is
powered up.

• Ensure that the device attached to the module is powered up
and operating correctly.

• Ensure that the module is properly seated in the slot.

• Verify that the attached device is configured to match the

communication mode used by the module (1 Gbps and full
duplex).

• Check the connectors on both ends of the cable to be sure they
are properly engaged. When attaching fiber cable to an SC-type
port, be sure the plug clicks into place to ensure that it is
properly seated.

• If you are using fiber optic cable with an ST-type connector (in
conjunction with the SC-ST Converter*), try switching the TX
and RX connectors.

• Be sure the fiber terminators are clean. You can clean the cable
plugs by wiping them gently with a clean tissue or cotton ball
moistened with a little ethanol. Dirty fiber terminators on fiber
optic cables will impair the quality of the light transmitted
through the cable.

You may use an SC-ST Converter (SMC Part Number:

*

99-012034-091) to attach fiber cable with an ST-type
connector to the SC-type port on the Gigabit Extender Module.

7

T

ROUBLESHOOTING

8

C

Cable Specifications

Cable Types and Specifications

Cable Type Max. Length Connector

1000BASE-SX 50/125 or 62.5/125

micron core multimode
fiber (MMF)

1000BASE-LX 9/125 micron core

single-mode fiber (SMF)

1000BASE-SX Fiber Specifications

Fiber Diameter Fiber Bandwidth Cable Length Range

62.5/125 micron MMF 160 MHz/km 2 - 220 m (7 - 722 ft)

200 MHz/km 2 - 275 m (7 - 902 ft)

50/125 micron MMF 400 MHz/km 2 - 500 m (7 - 1641 ft)

500 MHz/km 2 - 550 m (7 - 1805 ft)

See the following
table

5 km (16,404 ft) SC

ABLES

SC or ST

9

C

ABLES

10

S

PECIFICATIONS

TigerSwitch Gigabit Uplink Modules

General

Communication Mode

Full duplex, auto-negotiation for flow control

Communication Rate

1000 Mbps

LED Indicators

Status - one per module

Size

7.2 x 9.1 x 2.4 cm (2.83 x 3.58 x 0.94 in.)

Power Consumption

4 W maximum

Temperature

Operating: 0 to 50 °C (32 to 122 °F)
Storage: -40 to 70 °C (-40 to 158 °F)

Humidity

5% to 95%

Standards

IEEE 802.3z Gigabit Ethernet
ISO/IEC 8802-3

Compliances

CE Mark
Emissions

FCC Class A
VCCI Class A

11

S

PECIFICATIONS

Industry Canada Class A
EN55022 (CISPR 22) Class A
EN 61000-3-2/3
C-Tick - AS/NZS 3548 (1995) Class A

Immunity

EN 61000-4-2/3/4/5/6/8/11

Warranty

Limited Lifetime

SMC6724L2GSSC

Ports

1 1000BASE-SX

Network Interface

SC connector:

62.5/125 or 50/125 micron multimode fiber cable

SMC6724L2GLSC

Ports

1 1000BASE-LX

Network Interface

SC connector:

9/125 micron single-mode fiber cable

12

O

RDERING INFORMATION

TigerSwitch 10/100 Products and Accessories

Product Number Description

SMC6724L2 24-port Fast Ethernet switch with two media

SMC6724L2GSSC Gigabit module with one 1000BASE-SX

SMC6724L2GSST SMC6724L2GSSC + SC-ST converter

SMC6724L2GLSC Gigabit Module with one 1000BASE-LX

SMC6724L2GT Gigabit module with one 1000BASE-T port

SMC6724L2FSSC Extender module with one 100BASE-FX

SMC6724L2FMSC Extender module with one 100BASE-FX

SMC6724L2FMST SMC6724L2FMSC + SC-ST converter

99-012034-091 SC to ST plug converter for fiber optic module

expansion slots

multimode fiber (SC-type connector)

single-mode port (SC-type connector)

(RJ-45 connector)

single-mode fiber port (SC-type connector)

multimode fiber port (SC-type connector)

13

O

RDERING INFORMATION

14
