Smc 6128PL2 Installation Guide

TigerSwitch 10/100

24-Port Fast Ethernet Switch

◆ 24 auto-MDI/MDI-X 10/100BASE-TX ports

◆ 10BASE-T/100BASE-TX ports support PoE capabilities

◆ Two 10/100/1000BASE-T RJ-45 ports

◆ Two Gigabit RJ-45/SFP combination ports

◆ 12.8 Gbps of aggregate bandwidth

◆ Supports IP Clustering

◆ Non-blocking switching architecture

◆ Spanning Tree Protocol, and RSTP

◆ Up to eight LACP or static 8-port trunks

◆ RADIUS and TACACS+ authentication

◆ Rate limiting for bandwidth management

◆ CoS support for four-level priority

◆ Full support for VLANs with GVRP

◆ IP Multicasting with IGMP Snooping

◆ Manageable via console, Web, SNMP/RMON

Installation Guide

Installationsanleitung

SMC6128PL2

TigerSwitch 10/100
Installation Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

20 Mason
Irvine, CA 92618
Phone: [phone]

February 2007

Pub. # 150000050500A

Information furnished by SMC Networks, Inc. (SMC) is believed to be
accurate and reliable. However, no responsibility is assumed by SMC for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or oth­erwise under any patent or patent rights of SMC. SMC reserves the right to
change specifications at any time without notice.

Copyright © 2007 by

SMC Networks, Inc.

20 Mason

Irvine, CA 92618

All rights reserved. Printed in Taiwan

Trademarks:

SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of SMC
Networks, Inc. Other product and company names are trademarks or registered trademarks of their
respective holders.

L

IMITED

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be
free from defects in workmanship and materials, under normal use and service, for the
applicable warranty term. All SMC products carry a standard 90-day limited warranty from
the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion,
repair or replace any product not operating as warranted with a similar or functionally
equivalent product, during the applicable warranty term. SMC will endeavor to repair or
replace any product returned under warranty within 30 days of receipt of the product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by registering
new products within 30 days of purchase from SMC or its Authorized Reseller. Registration
can be accomplished via the enclosed product registration card or online via the SMC web
site. Failure to register will not affect the standard limited warranty. The Limited Lifetime
warranty covers a product during the Life of that Product, which is defined as the period of
time during which the product is an “Active” SMC product. A product is considered to be
“Active” while it is listed on the current SMC price list. As new technologies emerge, older
technologies become obsolete and SMC will, at its discretion, replace an older product in its
product line with one that incorporates these newer technologies. At that point, the obsolete
product is discontinued and is no longer an “Active” SMC product. A list of discontinued
products with their respective dates of discontinuance can be found at:
http://www.smc.com/index.cfm?action=customer_service_warranty.

All products that are replaced become the property of SMC. Replacement products may be
either new or reconditioned. Any replaced or repaired product carries either a 30-day limited
warranty or the remainder of the initial warranty, whichever is longer. SMC is not responsible
for any custom software or firmware, configuration information, or memory data of
Customer contained in, stored on, or integrated with any products returned to SMC pursuant
to any warranty. Products returned to SMC should have any customer-installed accessory or
add-on components, such as expansion modules, removed prior to returning the product for
replacement. SMC is not responsible for these items if they are returned with the product.

Customers must contact SMC for a Return Material Authorization number prior to returning
any product to SMC. Proof of purchase may be required. Any product returned to SMC
without a valid Return Material Authorization (RMA) number clearly marked on the outside
of the package will be returned to customer at customer’s expense. For warranty claims within
North America, please call our toll-free customer support number at [phone].
Customers are responsible for all shipping charges from their facility to SMC. SMC is
responsible for return shipping charges from SMC to customer.

W

ARRANTY

v

L

IMITED WARRANTY

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR
REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE
FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN
LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,
EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE,
INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR
AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF ITS PRODUCTS. SMC SHALL NOT BE LIABLE
UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THE
ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY
CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER
INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR
ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY
ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT
OR TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR
INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE
DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR
OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE
SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR
INTERRUPTION OF ITS PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED
RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES
OR THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS
WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the active
SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans,
and cables are covered by a standard one-year warranty from date of purchase.

vi

SMC Networks, Inc.

20 Mason

Irvine, CA 92618

C

OMPLIANCESS

FCC - Class A

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.

You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.

You may use unshielded twisted-pair (UTP) for RJ-45 connections - Category 3 or better for 10 Mbps
connections, Category 5 or better for 100 Mbps connections, Category 5, 5e, or 6 for 1000 Mbps
connections. For fiber optic connections, you may use 50/125 or 62.5/125 micron multimode fiber or
9/125 micron single-mode fiber.

Industry Canada - Class A

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital
apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,”
ICES-003 of the Department of Communications.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils
numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,”
NMB-003 édictée par le ministère des Communications.

Japan VCCI Class A

PSE Alarm

本製品に同梱いたしております電源コードセットは、
本製品専用です。本電源コードセットは、本製品以外の
製品並びに他の用途でご使用いただくことは出来ません。
製品本体に同梱された電源コードセットを利用し、他製品
の電源コードセットを使用しないで下さい。

vii

C

OMPLIANCESS

CE Mark Declaration of Conformance for EMI and Safety
(EEC)

This information technology equipment complies with the requirements of the Council Directive 89/
336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic
Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the
Amendment Directive 93/68/EEC. For the evaluation of the compliance with these Directives, the
following standards were applied:

RFI
Emission:

Immunity: • Product family standard according to EN 55024:1998

LVD: • EN 60950-1:2001

War ni ng :
Attention:

• Limit class A according to EN 55022:1998

• Limit class A for harmonic current emission according to EN 61000-3-2/
1995

• Limitation of voltage fluctuation and flicker in low-voltage supply system
according to EN 61000-3-3/1995

• Electrostatic Discharge according to EN 61000-4-2:1995
(Contact Discharge: ±4 kV, Air Discharge: ±8 kV)

• Radio-frequency electromagnetic field according to EN 61000-4-3:1996
(80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)

• Electrical fast transient/burst according to EN 61000-4-4:1995 (AC/DC
power supply: ±1 kV, Data/Signal lines: ±0.5 kV)

• Surge immunity test according to EN 61000-4-5:1995
(AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)

• Immunity to conducted disturbances, Induced by radio-frequency fields:
EN 61000-4-6:1996 (0.15 - 80 MHz with 1 kHz AM 80% Modulation: 3
V/m)

• Power frequency magnetic field immunity test according to
EN 61000-4-8:1993
(1 A/m at frequency 50 Hz)

• Voltage dips, short interruptions and voltage variations immunity test
according to EN 61000-4-11:1994 (>95% Reduction @10 ms, 30%
Reduction @500 ms, >95% Reduction @5000 ms)

Do not plug a phone jack connector in the RJ-45 port. This may damage this device

Les raccordeurs ne sont pas utilisés pour le système téléphonique!

viii

C

OMPLIANCESS

Safety Compliance

Warning: Fiber Optic Port Safety

CLASS I

LASER DEVICE

When using a fiber optic port, never look at the transmit laser
while it is powered on. Also, never look directly at the fiber TX
port and fiber cable ends when they are powered on.

Avertissment: Ports pour fibres optiques - sécurité sur le plan optique

DISPOSITIF LASER

DE CLASSE I

Ne regardez jamais le laser tant qu'il est sous tension. Ne regar­dez jamais directement le port TX (Transmission) à fibres
optiques et les embouts de câbles à fibres optiques tant qu'ils
sont sous tension.

Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit

LASERGER
DER KLASSE I

ÄT

Niemals ein Übertragungslaser betrachten, während dieses
eingeschaltet ist. Niemals direkt auf den Faser-TX-Anschluß
und auf die Faserkabelenden schauen, während diese einge­schaltet sind.

Power Cord Safety

Please read the following safety information carefully before installing the switch:

WARNING:

• The unit must be connected to an earthed (grounded) outlet to comply with international
safety standards.

• Do not connect the unit to an A.C. outlet (power supply) without an earth (ground)
connection.

• The appliance coupler (the connector to the unit and not the wall plug) must have a
configuration for mating with an EN 60320/IEC 320 appliance inlet.

• The socket outlet must be near to the unit and easily accessible. You can only remove power
from the unit by disconnecting the power cord from the outlet.

• This unit operates under SELV (Safety Extra Low Voltage) conditions according to IEC

60950. The conditions are only maintained if the equipment to which it is connected also
operates under SELV conditions.

Installation and removal of the unit must be carried out by qualified personnel only.

ix

C

OMPLIANCESS

France and Peru only

This unit cannot be powered from IT† supplies. If your supplies are of IT type, this unit must be
powered by 230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection point
labelled Neutral, connected directly to earth (ground).

Power Cord Set

U.S.A. and
Canada

Denmark The supply plug must comply with Section 107-2-D1, Standard

Switzerland The supply plug must comply with SEV/ASE 1011.
U.K. The supply plug must comply with BS1363 (3-pin 13 A) and be fitted

Europe The supply plug must comply with CEE7/7 (“SCHUKO”).

†

Impédance à la terre

The cord set must be UL-approved and CSA certified.
The minimum specifications for the flexible cord are:

- No. 18 AWG - not longer than 2 meters, or 16 AWG.

- Type SV or SJ

- 3-conductor
The cord set must have a rated current capacity of at least 10 A
The attachment plug must be an earth-grounding type with NEMA

5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.

DK2-1a or DK2-5a.

with a 5 A fuse which complies with BS1362.
The mains cord must be <HAR> or <BASEC> marked and be of

type HO3VVF3GO.75 (minimum).

The mains cord must be <HAR> or <BASEC> marked and be of
type HO3VVF3GO.75 (minimum).

IEC-320 socket.

Veuillez lire à fond l'information de la sécurité suivante
avant d'installer le Switch:

AVERTISSEMENT:

qualifié.

• Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas
de connexion de mise à la terre (mise à la masse).

• Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la masse) afin de respecter
les normes internationales de sécurité.

• Le coupleur d’appareil (le connecteur du groupe et non pas la prise murale) doit respecter une
configuration qui permet un branchement sur une entrée d’appareil EN 60320/IEC 320.

• La prise secteur doit se trouver à proximité de l’appareil et son accès doit être facile. Vous ne
pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de
cette prise.

• L’appareil fonctionne à une tension extrêmement basse de sécurité qui est conforme à la
norme IEC 60950. Ces conditions ne sont maintenues que si l’équipement auquel il est
raccordé fonctionne dans les mêmes conditions.

L’installation et la dépose de ce groupe doivent être confiés à un personnel

x

C

OMPLIANCESS

France et Pérou uniquement:

Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations sont
du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par le
biais d’un transformateur d’isolement à rapport 1:1, avec un point secondaire de connexion portant
l’appellation Neutre et avec raccordement direct à la terre (masse).

Cordon électrique - Il doit être agréé dans le pays d’utilisation
Etats-Unis et

Canada:

Danemark: La prise mâle d’alimentation doit respecter la section 107-2 D1 de la

Suisse: La prise mâle d’alimentation doit respecter la norme SEV/ASE 1011.
Europe La prise secteur doit être conforme aux normes CEE 7/7

Le cordon doit avoir reçu l’homologation des UL et un certificat de la
CSA.

Les spe'cifications minimales pour un cable flexible sont AWG No.
18, ouAWG No. 16 pour un cable de longueur infe'rieure a` 2 me'tres.

- type SV ou SJ

- 3 conducteurs
Le cordon doit être en mesure d’acheminer un courant nominal d’au

moins 10 A.
La prise femelle de branchement doit être du type à mise à la terre

(mise à la masse) et respecter la configuration NEMA 5-15P (15 A,
125 V) ou NEMA 6-15P (15 A, 250 V).

norme DK2 1a ou DK2 5a.

(“SCHUKO”)
LE cordon secteur doit porter la mention <HAR> ou <BASEC> et

doit être de type HO3VVF3GO.75 (minimum).

Bitte unbedingt vor dem Einbauen des Switches die fol­genden Sicherheitsanweisungen durchlesen:

WARNUNG:

• Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose angeschlossen werden.

• Das Gerät muß an eine geerdete Steckdose angeschlossen werden, welche die internationalen
Sicherheitsnormen erfüllt.

• Der Gerätestecker (der Anschluß an das Gerät, nicht der Wandsteckdosenstecker) muß einen
gemäß EN 60320/IEC 320 konfigurierten Geräteeingang haben.

• Die Netzsteckdose muß in der Nähe des Geräts und leicht zugänglich sein. Die
Stromversorgung des Geräts kann nur durch Herausziehen des Gerätenetzkabels aus der
Netzsteckdose unterbrochen werden.

• Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen (Sicherheitskleinstspannung)
gemäß IEC 60950. Diese Bedingungen sind nur gegeben, wenn auch die an das Gerät
angeschlossenen Geräte unter SELV-Bedingungen betrieben werden.

Die Installation und der Ausbau des Geräts darf nur durch Fachpersonal erfolgen.

xi

C

OMPLIANCESS

Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden:
Schweiz Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen

Europe Das Netzkabel muß vom Typ HO3VVF3GO.75

einhalten.

(Mindestanforderung) sein und die Aufschrift <HAR> oder
<BASEC> tragen.

Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”).

Warnings and Cautionary Messages

Warning: This product does not contain any serviceable user parts.

Warning: Installation and removal of the unit must be carried out by qualified personnel

Warning: When connecting this device to a power outlet, connect the field ground lead

Warning: This switch uses lasers to transmit signals over fiber optic cable. The lasers are

Caution: All interconnecting LAN cables and devices receiving PoE (Power over

Caution: Do not plug a phone jack connector in the RJ-45 port. This may damage this

Caution: Use only twisted-pair cables with RJ-45 connectors that conform to FCC

Caution: Wear an anti-static wrist strap or take other suitable measures to prevent

only.

on the tri-pole power plug to a valid earth ground line to prevent electrical
hazards.

compliant with the requirements of a Class 1 Laser Product and are inherently
eye safe in normal operation. However, you should never look directly at a
transmit port when it is powered on.

Ethernet) power from a switch must be contained within the same building.

device. Les raccordeurs ne sont pas utilisé pour le système téléphonique!

standards.

electrostatic discharge when handling this equipment.

Warnings (In German)

Achtung: Dieses Produkt enthält keine Teile, die eine Wartung vom Benutzer benötigen.

Achtung: Wenn das Gerät an eine Steckdose angeschlossen wird, muß der Masseanschluß

Achtung: Dieses Gerät nutzt Laser zur Signalübertragung über Glasfasern. Die Laser

am dreipoligen Netzstecker mit Schutzerde verbunden werden, um elektrische
Gefahren zu vermeiden.

entsprechen den Anforderungen an eine Lasereinrichtung der Klasse 1 und sind
durch ihre Bauart im normalen Betrieb sicher für die Augen. Trotzdem sollte
niemals direkt in den einen Übertragungskanal geblickt werden, wenn er
eingeschaltet ist.

xii

C

OMPLIANCESS

Environmental Statement

The manufacturer of this product endeavours to sustain an environmentally-friendly policy
throughout the entire production process. This is achieved though the following means:

• Adherence to national legislation and regulations on environmental production standards.

• Conservation of operational resources.

• Waste reduction and safe disposal of all harmful un-recyclable by-products.

• Recycling of all reusable waste content.

• Design of products to maximize recyclables at the end of the product’s life span.

• Continual monitoring of safety standards.

End of Product Life Span

This product is manufactured in such a way as to allow for the recovery and disposal of all included
electrical components once the product has reached the end of its life.

Manufacturing Materials

There are no hazardous nor ozone-depleting materials in this product.

Documentation

All printed documentation for this product uses biodegradable paper that originates from sustained
and managed forests. The inks used in the printing process are non-toxic.

Purpose

This guide details the hardware features of the switch, including the physical and performance-related
characteristics, and how to install the switch.

Audience

The guide is intended for use by network administrators who are responsible for installing and setting
up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area
Networks).

Diese Anleitung ist für die Benutzung durch Netzwerkadministratoren vorgesehen, die für die
Installation und das einstellen von Netzwerkkomponenten verantwortlich sind; sie setzt Erfahrung
bei der Arbeit mit LANs (Local Area Networks) voraus.

Related Publications

The following publication gives specific information on how to operate and use the management
functions of the switch:

The

SMC6128PL2 Management Guide

Also, as part of the switch’s firmware, there is an online web-based help that describes all management
related features.

xiii

C

OMPLIANCESS

xiv

T

ABLE OF

C

ONTENTS

1 About the TigerSwitch . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Switch Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Power-over-Ethernet Capability . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Network Management Options . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Description of Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

10/100BASE-T Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

SFP Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Port and System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Power Supply Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Expandability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

2 Network Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Introduction to Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Application Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Supplying PoE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Collapsed Backbone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Network Aggregation Plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Remote Connection with Fiber Cable . . . . . . . . . . . . . . . . . . . . . 2-5

Making VLAN Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Application Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

3 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Selecting a Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Ethernet Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Equipment Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Optional Rack-Mounting Equipment . . . . . . . . . . . . . . . . . . . . . 3-3

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Desktop or Shelf Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

xv

T

ABLE OF CONTENTS

Installing an Optional SFP Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Connecting to a Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Connecting to the Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Wiring Map for Serial Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

4 Making Network Connections . . . . . . . . . . . . . . . . . . . 4-1

Connecting Network Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Twisted-Pair Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Power-over-Ethernet Connections . . . . . . . . . . . . . . . . . . . . . . . 4-2

Cabling Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Connecting to PCs, Servers, Hubs and Switches . . . . . . . . . . . . 4-3

Network Wiring Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Fiber Optic SFP Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Connectivity Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

1000BASE-T Cable Requirements . . . . . . . . . . . . . . . . . . . . . . . 4-8

1000 Mbps Gigabit Ethernet Collision Domain . . . . . . . . . . . . . 4-9

100 Mbps Fast Ethernet Collision Domain . . . . . . . . . . . . . . . 4-10

10 Mbps Ethernet Collision Domain . . . . . . . . . . . . . . . . . . . . 4-10

Cable Labeling and Connection Records . . . . . . . . . . . . . . . . . . . . . . . 4-11

A Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

Diagnosing Switch Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Power and Cooling Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

In-Band Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

B Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1

Twisted-Pair Cable and Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . B-1

10/100BASE-TX Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . B-2

Straight-Through Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Crossover Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

1000BASE-T Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . B-5

Cable Testing for Existing Category 5 Cable . . . . . . . . . . . . . . . B-5

C Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-1

Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

Switch Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2

xvi

T

ABLE OF CONTENTS

Management Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

D Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . D-1

E German Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Eine Site Auswählen (Selecting a Site) . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Montage (Rack Mounting Instructions) . . . . . . . . . . . . . . . . . . . . . . . . . E-2

Rack-Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2

Anschluss an eine Stromquelle (Connecting to a Power Source) . . . . . E-3

Glossary

Index

xvii

T

ABLES

Table 1-1 Port Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Table 1-2 System Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Table 3-1 Serial Cable Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Table 4-1 Maximum 1000BASE-T Gigabit Ethernet Cable Length . . 4-9
Table 4-2 Maximum 1000BASE-SX Gigabit Ethernet Cable Length 4-9
Table 4-3 Maximum 1000BASE-LX Gigabit Ethernet Cable Length 4-9
Table 4-4 Maximum 1000BASE-ZX Gigabit Ethernet Cable Length 4-9

Table 4-5 Maximum Fast Ethernet Cable Length . . . . . . . . . . . . . . . 4-10

Table 4-6 Maximum Ethernet Cable Length . . . . . . . . . . . . . . . . . . . 4-10

Table A-1 Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Table B-1 10/100BASE-TX MDI-X and MDI Port Pinouts . . . . . . . B-2

Table B-2 1000BASE-T MDI and MDI-X Port Pinouts . . . . . . . . . . . B-5

Table D-1 TigerSwitch 10/100 Products and Accessories . . . . . . . . . .D-1

xviii

F

IGURES

Figure 1-1 Front and Rear Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Figure 1-2 Port Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Figure 1-3 System Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Figure 1-4 Power Supply Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Figure 2-1 PoE Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Figure 2-2 Collapsed Backbone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Figure 2-3 Network Aggregation Plan . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Figure 2-4 Remote Connection with Fiber Cable . . . . . . . . . . . . . . . 2-5

Figure 2-5 Making VLAN Connections . . . . . . . . . . . . . . . . . . . . . . . 2-6

Figure 3-1 RJ-45 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Figure 3-2 Attaching the Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Figure 3-3 Installing the Switch in a Rack . . . . . . . . . . . . . . . . . . . . . 3-5

Figure 3-4 Attaching the Adhesive Feet . . . . . . . . . . . . . . . . . . . . . . . 3-6

Figure 3-5 Inserting an SFP Transceiver into a Slot . . . . . . . . . . . . . 3-7

Figure 3-6 Power Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Figure 3-7 Serial Port (DB-9 DTE) Pin-Out . . . . . . . . . . . . . . . . . . . 3-9

Figure 4-1 Making Twisted-Pair Connections . . . . . . . . . . . . . . . . . . 4-3

Figure 4-2 Network Wiring Connections . . . . . . . . . . . . . . . . . . . . . . 4-5

Figure 4-3 Making Fiber Port Connections . . . . . . . . . . . . . . . . . . . . 4-7

Figure B-1 RJ-45 Connector Pin Numbers . . . . . . . . . . . . . . . . . . . . B-1

Figure B-2 Straight-through Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Figure B-3 Crossover Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

xix

xx

C

P

HAPTER

A

BOUT THE

T

IGERSWITCH

Overview

The SMC6128PL2 is an intelligent PoE switch with 24 10/100BASE-T
ports, two 10/100/1000BASE-T ports and two Gigabit combination

1

ports

that are comprised of a RJ-45 port and an SFP transceiver slot.
There is also an SNMP-based management agent embedded on the main
board. This agent supports both in-band and out-of-band access for
managing the switch.

The switch provides a broad range of powerful features for Layer 2
switching, delivering reliability and consistent performance for your
network traffic. They bring order to poorly performing networks by
segregating them into separate broadcast domains with IEEE 802.1Q
compliant VLANs, and empower multimedia applications with multicast
switching and CoS services.

System Indicator

SMC6128PL2

Link/Act

System

RATING

100~240V-

3A50~60HZ

ort Status Indicators

25

27

28

26

10/100 Mbps RJ-45 Ports

1000BASE-T/SFP Ports

25 27

26 28

1

TigerSwitch10/100

27 28

Power Socket

Console Port

Figure 1-1 Front and Rear Panels

1. RJ-45 ports shared with a SFP tranceiver slots. If an SFP transceiver is plugged in, the cor­responding RJ-45 port is disabled.

1-1

A

BOUT THE TIGERSWITCH

Switch Architecture

These switches employ a wire-speed, non-blocking switching fabric. This
permits simultaneous wire-speed transport of multiple packets at low latency
on all ports. These switches also features full-duplex capability on all ports,
which effectively doubles the bandwidth of each connection.

These switches use store-and-forward switching to ensure maximum data

integrity. With store-and-forward switching, the entire packet must be
received into a buffer and checked for validity before being forwarded. This
prevents errors from being propagated throughout the network.

Power-over-Ethernet Capability

The switch’s 24 10/100 Mbps ports support the IEEE 802.3af
Power-over-Ethernet (PoE) standard that enables DC power to be supplied
to attached devices using wires in the connecting Ethernet cable. Any 802.3af
compliant device attached to a port can directly draw power from the switch
over the Ethernet cable without requiring its own separate power source.
This capability gives network administrators centralized power control for
devices such as IP phones and wireless access points, which translates into
greater network availability.

For each attached 802.3af-compliant device, the switch automatically senses
the load and dynamically supplies the required power. The switch delivers
power to a device using the two data wire pairs in UTP or STP. Each port can
provide up to 15.4 W of power at the standard -48 VDC voltage.
Independent overload and short-circuit protection for each port allows the
switch to automatically shut down a port’s power when limits are exceeded.

Network devices such as IP phones, wireless access points, and network
cameras, typically consume less than 10 W of power, so they are ideal for
Power-over-Ethernet applications.

1-2

D

ESCRIPTION OF HARDWARE

Network Management Options

These switches contain a comprehensive array of LEDs for “at-a-glance”
monitoring of network and port status. They also include a management
agent that allows you to configure or monitor the switch using its embedded
management software, or via SNMP applications. To manage a switch, you
can make a direct connection to the RS-232 console port (out-of-band), or
you can manage it through a network connection (in-band) using Telnet, the
on-board Web agent, or Windows-based network management software.

For a detailed description of the switch’s advanced features, refer to the
SMC6128PL2 Management Guide.

Description of Hardware

10/100BASE-T Ports

The PoE switch base unit contains 24 10BASE-T/100BASE-TX RJ-45
ports. All ports support automatic MDI/MDI-X operation, so you can use
straight-through cables for all network connections to PCs or servers, or to
other switches or hubs. (See “10/100BASE-TX Pin Assignments” on page
B-2.)

Each of these ports support auto-negotiation, so the optimum transmission
mode (half or full duplex), and data rate (10 or 100 Mbps) can be selected
automatically. If a device connected to one of these ports does not support
auto-negotiation, the communication mode of that port can be configured
manually.

Each port also supports IEEE 802.3x auto-negotiation of flow control, so
the switch can automatically prevent port buffers from becoming saturated.

SFP Slots

The Small Form Factor Pluggable (SFP) transceiver slots are shared with two
of the RJ-45 ports. In its default configuration, if an SFP transceiver
(purchased separately) is installed in a slot and has a valid link on its port, the
associated RJ-45 port is disabled and cannot be used. The switch can also be
configured to force the use of an RJ-45 port or SFP slot, as required.

1-3

A

25

27

26

28

Link/Act

System

BOUT THE TIGERSWITCH

Port and System Status LEDs

The LEDs, which are located on the front panel for easy viewing, are shown
below and described in the following table.

Port Status LEDs

Figure 1-2 Port Status LEDs

Table 1-1 Port Status LEDs

LED Condition Status

RJ-45 Ports

Link/ACT
(Link/
Activity)

On/Blinking
Green

On/Blinking
Amber

Off There is no valid link on the port.

Combination Gigabit Port Status LEDs

The port has a valid 100 Mbps link. Blinking
indicates activity.

The port has a valid 10 Mbps link. Blinking
indicates activity.

1-4

Gigabit/Combination Ports

Upper LED On/Blinking

Green

Off There is no valid link on the port.

Lower LED On/Blinking

Amber

Off There is no valid link on the port.

The port has a valid 10/100 Mbps link. Blinking
indicates activity.

The port has a valid 1000 Mbps link. Blinking
indicates activity.

D

25

27

26

28

Link/Act

System

ESCRIPTION OF HARDWARE

System Status LED

Figure 1-3 System Status LED

Table 1-2 System Status LED

LED Condition Status

System On Green Internal power is operating normally.

On Amber Internal power supply has failed.

Off Power off or failure.

1-5

A

BOUT THE TIGERSWITCH

Power Supply Sockets

There is one standard power socket on the rear panel of each switch for the
AC power cord.

Power Socket Console Port

RATING
100~240V­3A50~60HZ

Figure 1-4 Power Supply Sockets

Features and Benefits

Connectivity

• 24 10/100BASE-T ports plus 2 Gigabit combination ports (RJ-45/SFP)

and 2 Gigabit 1000BASE-T ports.

• Auto-negotiation enables each RJ-45 port to automatically select the

optimum speed (10 or 100 Mbps), and the communication mode (half or
full duplex) if this feature is supported by the attached device; otherwise
the port can be configured manually.

• Independent RJ-45 10/100BASE-T ports with auto MDI/MDI-X

pinout selection.

• Unshielded (UTP) cable supported on all RJ-45 ports: Category 3, 4 or 5

for 10 Mbps connections, Category 5 for 100 Mbps connections, and
Category 5 or better for 1000 Mbps connections.

• IEEE 802.3-2005 Ethernet, Fast Ethernet, Gigabit Ethernet compliance

ensures compatibility with standards-based hubs, network cards and
switches from any vendor.

1-6

F

EATURES AND BENEFITS

Expandability

• 2 Small Form Factor Pluggable (SFP) transceiver slots (shared with

1000BASE-T ports)

• Supports 1000BASE-SX and 1000BASE-LX, 1000BASE-ZX and other

SFP-compatible transceivers.

Performance

• Transparent bridging

• Switching table with a total of 8K MAC address entries

• Provides store-and-forward switching

• Supports wire-speed filtering and forwarding

• Supports flow control, using back pressure for half duplex and IEEE

802.3x for full duplex

• Broadcast storm control

Management

• “At-a-glance” LEDs for easy troubleshooting

• Network management agent:

• Manages switch in-band or out-of-band

• Supports Telnet, SNMP/RMON and Web-based interface

1-7

A

BOUT THE TIGERSWITCH

1-8

C

HAPTER

N

ETWORK

P

LANNING

Introduction to Switching

A network switch allows simultaneous transmission of multiple packets via
non-crossbar switching. This means that it can partition a network more
efficiently than bridges or routers. The switch has, therefore, been recognized
as one of the most important building blocks for today’s networking
technology.

When performance bottlenecks are caused by congestion at the network
access point (such as the network card for a high-volume file server), the
device experiencing congestion (server, power user, or hub) can be attached
directly to a switched port. And, by using full-duplex mode, the bandwidth of
the dedicated segment can be doubled to maximize throughput.

When networks are based on repeater (hub) technology, the distance between
end stations is limited by a maximum hop count. However, a switch turns the
hop count back to zero. So subdividing the network into smaller and more
manageable segments, and linking them to the larger network by means of a
switch, removes this limitation.

2

A switch can be easily configured in any Ethernet, Fast Ethernet, or Gigabit
Ethernet network to significantly boost bandwidth while using conventional
cabling and network cards.

2-1

N

ETWORK PLANNING

Application Examples

The SMC6128PL2 is not only designed to segment your network, but also to
provide a wide range of options in setting up network connections. Some
typical applications are described in the following pages.

Supplying PoE

The switch is an excellent choice for supplying power to connected PoE
devices such as web cameras, IP telephones or access points. You can easily
connect a PoE device to a switch port and allow power to be supplied over
the connecting cable. Each of the 24 ports on the switch can provide power
to a connected device.

In the figure below, the switch is supplying power to three PoE devices. It is
also providing dedicated 100 Mbps full-duplex data connections to the
devices. In addition, other non-PoE devices can be connected to the switch.

2-2

89

10

SMC6128PL2

1234567

1

Console

Link/Act

System

2

11 12

25

27

28

26

Power-over-Ethernet Devices

Figure 2-1 PoE Connections

11

121314

131415 16

18 19

20

21 222324

17

23

24

25 27

26

25

26 28

TigerSwitch10/100

Pwr

Link/Act

Diag

PoE

RPS

25

Mode

26

Stack

PoE/Link

27 28

Access Point

A

PPLICATION EXAMPLES

Collapsed Backbone

The SMC6128PL2 is an excellent choice for mixed Ethernet, Fast Ethernet,
and Gigabit Ethernet installations where significant growth is expected in the
near future. In a basic stand-alone configuration, it can provide direct
full-duplex connections to workstations or servers. When the time comes for
further expansion, just connect to another hub or switch using one of the
Fast Ethernet ports built into the front panel or a Gigabit Ethernet port on a
plug-in SFP transceiver.

In the figure below, the switch is operating as a collapsed backbone for a
small LAN. It is providing dedicated 100 Mbps full-duplex connections to
workstations and 1000 Mbps full-duplex connections to power users and
servers. In addition, connected IP phones and wireless access points are
receiving PoE power from the switch.

SMC6128PL2

...

Servers

1 Gbps
Full Duplex

25

Link/Act

System

27

28

26

...

Workstations

100 Mbps
Full Duplex

25 27

26 28

TigerSwitch10/100

27 28

...

Workstations

10 Mbps
Full Duplex

Power-over-Ethernet Devices

10/100 Mbps
Full Duplex

Standard LAN

PoE

Figure 2-2 Collapsed Backbone

2-3

N

ETWORK PLANNING

Network Aggregation Plan

With 24 parallel bridging ports (i.e., 24 distinct collision domains), the switch
can collapse a complex network down into a single efficient bridged node,
increasing overall bandwidth and throughput.

In the figure below, the 10/100BASE-TX ports on the switch are providing
100 Mbps connectivity through layer 2 switches. In addition, the switch is
also connecting several servers at 1000 Mbps.

SMC6128PL2

Link/Act

System

SMC6128PL2

25

27

Link/Act

System

28

26

25 27

TigerSwitch10/100

26 28

27 28

25

27

28

26

SMC6128PL2

25 27

TigerSwitch10/100

26 28

27 28

25

27

Link/Act

System

28

26

25 27

26 28

Server Farm

TigerSwitch10/100

27 28

10/100 Mbps Segments

...

...

Figure 2-3 Network Aggregation Plan

2-4

A

0

PPLICATION EXAMPLES

Remote Connection with Fiber Cable

Fiber optic technology allows for longer cabling than any other media type. A
1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a
1000BASE-LX (SMF) link up to 5 km, and a 1000BASE-ZX link up to 100
km. This allows the switch to serve as a collapsed backbone, providing direct
connectivity for a widespread LAN.

A 1000BASE-SX SFP transceiver can be used for a high-speed connection
between floors in the same building, a 1000BASE-LX SFP transciever can be
used to connect to other buildings in a campus setting, and a 1000BASE-ZX
SFP transceiver can be used for a long-haul connection to a remote site.

The figure below illustrates the switch connecting multiple segments with
fiber cable.

Headquarters

Server Farm

Remote Switch

SMC6128PL2

SMC6128PL2

Link/Act

System

1000BASE-SX MMF
(550 meters)

25

27

Link/Act

System

28

26

25 27

TigerSwitch10/100

26 28

27 28

25

27

28

26

Remote Switch

SMC6128PL2

25

Link/Act

System

26

27

28

10/100/1000 Mbps Segments

...

...

Figure 2-4 Remote Connection with Fiber Cable

25 27

26 28

1000BASE-LX SMF
(5 kilometers)

25 27

TigerSwitch10/100

26 28

27 28

TigerSwitch10/10

27 28

2-5

N

ETWORK PLANNING

Making VLAN Connections

These switches support VLANs which can be used to organize any group of
network nodes into separate broadcast domains. VLANs confine broadcast
traffic to the originating group, and can eliminate broadcast storms in large
networks. This provides a more secure and cleaner network environment.

VLANs can be based on untagged port groups, or traffic can be explicitly
tagged to identify the VLAN group to which it belongs. Untagged VLANs
can be used for small networks attached to a single switch. However, tagged
VLANs should be used for larger networks, and all the VLANs assigned to
the inter-switch links.

These switches also support multiple spanning trees which allow VLAN
groups to maintain a more stable path between all VLAN members. This can
reduce the overall amount of protocol traffic crossing the network, and
provide a shorter reconfiguration time if any link in the spanning tree fails.

2-6

Testing

Note:

R&D

VLAN 2

VLAN 1

Tagged

Ports

VLAN 3

Finance

VLAN 4

SMC6128PL2

Link/Act

System

Untagged Ports

Marketing

VLAN

unaware

switch

25

27

28

26

Tagged Port

Finance

VLAN 3

VLAN 1

25 27

26 28

27 28

R&D

VLAN 2

Figure 2-5 Making VLAN Connections

When connecting to a switch that does not support IEEE 802.1Q VLAN
tags, use untagged ports.

TigerSwitch10/100

VLAN
aware
switch

Testing

A

PPLICATION NOTES

Application Notes

1. Full-duplex operation only applies to point-to-point access (such as

when a switch is attached to a workstation, server or another switch).
When the switch is connected to a hub, both devices must operate in
half-duplex mode.

2. Avoid using flow control on a port connected to a hub unless it is

actually required to solve a problem. Otherwise back pressure jamming
signals may degrade overall performance for the segment attached to the
hub.

3. As a general rule the length of fiber optic cable for a single switched link

should not exceed:

•1000BASE-SX: 550 m (1805 ft) for multimode fiber.

•1000BASE-LX: 5 km (3.2 miles) for single-mode fiber.

•1000BASE-ZX: 100 km (62 miles) for single-mode fiber.

However, power budget constraints must also be considered when
calculating the maximum cable length for your specific environment.

2-7

N

ETWORK PLANNING

2-8

C

HAPTER

I

NSTALLING THE

S

WITCH

Selecting a Site

TigerSwitch units can be mounted in a standard 19-inch equipment rack or
on a flat surface. Be sure to follow the guidelines below when choosing a
location.

• The site should:

- be at the center of all the devices you want to link and near a power
outlet.

- be able to maintain its temperature within 0 to 45 °C (32 to 113 °F) and
its humidity within 10% to 90%, non-condensing

- provide adequate space (approximately two inches) on all sides for
proper air flow

- be accessible for installing, cabling and maintaining the devices

3

- allow the status LEDs to be clearly visible

• Make sure twisted-pair cable is always routed away from power lines,
fluorescent lighting fixtures and other sources of electrical interference,
such as radios and transmitters.

• Make sure that a separate grounded power outlet that provides 100 to 240
VAC, 50 to 60 Hz, is within 2.44 m (8 feet) of each device and is powered
from an independent circuit breaker. As with any equipment, using a
filter or surge suppressor is recommended.

3-1

I

NSTALLING THE SWITCH

Ethernet Cabling

To ensure proper operation when installing the switch into a network,
make sure that the current cables are suitable for 10BASE-T,
100BASE-TX or 1000BASE-T operation. Check the following criteria
against the current installation of your network:

• Cable type: Unshielded twisted pair (UTP) or shielded twisted pair (STP)
cables with RJ-45 connectors; Category 3 or better for 10BASE-T,
Category 5 or better for 100BASE-TX, and Category 5 or better for
1000BASE-T.

• Protection from radio frequency interference emissions

• Electrical surge suppression

• Separation of electrical wires (switch related or other) and
electromagnetic fields from data based network wiring

• Safe connections with no damaged cables, connectors or shields

3-2

RJ-45 Connector

Figure 3-1 RJ-45 Connections

E

QUIPMENT CHECKLIST

Equipment Checklist

After unpacking the switch, check the contents to be sure you have
received all the components. Then, before beginning the installation, be
sure you have all other necessary installation equipment.

Package Contents

• TigerSwitch 10/100, SMC6128PL2

• Four adhesive foot pads

• Bracket Mounting Kit containing two brackets and eight screws for

attaching the brackets to the switch

•Power Cord

• RS-232 console cable

• This Installation Guide

• Management Guide CD

Optional Rack-Mounting Equipment

If you plan to rack-mount the switch, be sure to have the following
equipment available:

• Four mounting screws for each device you plan to install in a rack—these

are not included

• A screwdriver (Phillips or flathead, depending on the type of screws used)

3-3

I

NSTALLING THE SWITCH

Mounting

The switch units can be mounted in a standard 19-inch equipment rack or
on a desktop or shelf. Mounting instructions for each type of site follow.

Rack Mounting

Before rack mounting the switch, pay particular attention to the following
factors:

• Temperature: Since the temperature within a rack assembly may be
higher than the ambient room temperature, check that the
rack-environment temperature is within the specified operating
temperature range. (See page C-2.)

• Mechanical Loading: Do not place any equipment on top of a
rack-mounted unit.

• Circuit Overloading: Be sure th at the sup ply circuit to the rack assembly
is not overloaded.

• Grounding: Rack-mounted equipment should be properly grounded.
Particular attention should be given to supply connections other than
direct connections to the mains.

3-4

M

OUNTING

To rack-mount devices:

1. Attach the brackets to the device using the screws provided in the

Bracket Mounting Kit.

27

T

ig

e

rS

w

it

c

h

1

0

/1

0

28

27

0

28

Figure 3-2 Attaching the Brackets

2. Mount the device in the rack, using four rack-mounting screws (not

provided).

25 27

26 28

TigerSwitch10/100

27

28

Figure 3-3 Installing the Switch in a Rack

3-5

I

NSTALLING THE SWITCH

3. If installing a single switch only, turn to “Connecting to a Power

Source” at the end of this chapter.

4. If installing multiple switches, mount them in the rack, one below the

other, in any order.

Desktop or Shelf Mounting

1. Attach the four adhesive feet to the bottom of the first switch.

8

72
2

8

2

6

0

0

/1
0

1

2

h
c

it
w

S
r

e

g
i
T

7

2

5
2

8

2

6
2

7

2

5
2

System

Link/Act

2

L

P

8

2

1

6

C

M

S

Figure 3-4 Attaching the Adhesive Feet

2. Set the device on a flat surface near an AC power source, making sure

there are at least two inches of space on all sides for proper air flow.

3. If installing a single switch only, go to “Connecting to a Power Source”

at the end of this chapter.

4. If installing multiple switches, attach four adhesive feet to each one.

Place each device squarely on top of the one below, in any order.

3-6

I

NSTALLING AN OPTIONAL

SFP T

Installing an Optional SFP Transceiver

25 27

RANSCEIVER

26 28

TigerSwitch10/100

27 28

Figure 3-5 Inserting an SFP Transceiver into a Slot

The SFP slots support the following optional SFP transceivers:

• 1000BASE-SX

• 1000BASE-LX

• 1000BASE-ZX
To install an SFP transceiver, do the following:

1. Consider network and cabling requirements to select an appropriate

SFP transceiver type.

2. Insert the transceiver with the optical connector facing outward and

the slot connector facing down. Note that SFP transceivers are keyed
so they can only be installed in one orientation.

3. Slide the SFP transceiver into the slot until it clicks into place.

Note: SFP transceivers are hot-swappable. The switch does not need

to be powered off before installing or removing a transceiver.
However, always first disconnect the network cable before
removing a transceiver.

Note: SFP transceivers are not provided in the switch package.

3-7

I

RATING

100~240V-

3A 50~60HZ

NSTALLING THE SWITCH

Connecting to a Power Source

To connect a device to a power source:

1. Insert the power cable plug directly into the socket located at the back

of the device.

Figure 3-6 Power Socket

2. Plug the other end of the cable into a grounded, 3-pin socket.

Note: For International use, you may need to change the AC line

cord. You must use a line cord set that has been approved for
the socket type in your country.

3. Check the front-panel LEDs as the device is powered on to be sure

the Power LED is lit. If not, check that the power cable is correctly
plugged in.

3-8

C

ONNECTING TO THE CONSOLE PORT

Connecting to the Console Port

The DB-9 serial port on the switch’s front panel is used to connect to the
switch for out-of-band console configuration. The on-board configuration
program can be accessed from a terminal or a PC running a terminal
emulation program. The pin assignments used to connect to the serial port
are described in the following figure and table.

1

5

6 9

Figure 3-7 Serial Port (DB-9 DTE) Pin-Out

Wiring Map for Serial Cable

Table 3-1 Serial Cable Wiring

Switch’s 9-Pin

Serial Port

Null Modem PC’s 9-Pin

DTE Port

2 RXD (receive data) <------------------------- 3 TXD (transmit data)

3 TXD (transmit data) -------------------------> 2 RXD (receive data)

5 SGND (signal ground) --------------------------- 5 SGND (signal ground)

No other pins are used.

The serial port’s configuration requirements are as follows:

• Default Baud rate—9,600 bps

• Character Size—8 Characters

• Parity—None

• Stop bit—One

•Data bits—8

3-9

I

NSTALLING THE SWITCH

3-10

C

HAPTER

M

AKING

C

Connecting Network Devices

The SMC6128PL2 is designed to interconnect multiple segments (or
collision domains). It can be connected to network cards in PCs and
servers, as well as to hubs, switches or routers. It may also be connected to
devices using optional SFP tranceivers.

If 802.3af-compliant PoE devices are connected to the switch’s
10/100 Mbps ports, the switch automatically supplies the required power.

Twisted-Pair Devices

Each device requires an unshielded twisted-pair (UTP) cable with RJ-45
connectors at both ends. Use Category 5, 5e or 6 cable for 1000BASE-T
connections, Category 5 or better for 100BASE-TX connections, and
Category 3 or better for 10BASE-T connections.

N

ETWORK

ONNECTIONS

4

4-1

M

AKING NETWORK CONNECTIONS

Power-over-Ethernet Connections

The PoE switch automatically detects an 802.3af-compliant device by its
authenticated PoE signature and senses its required load before turning on
DC power to the port. This detection mechanism prevents damage to
other network equipment that is not 802.3af compliant.

Note: Power-over-Ethernet connections work with all existing Category

3, 4, 5, 5e or 6 network cabling, including patch cables and
patch-panels, outlets, and other connecting hardware, without
requiring modification.

The switch delivers power to a device using the two signal wire pairs in
UTP or STP cable (RJ-45 pins 1, 2, 3, and 6). The switch can provide up to

15.4 W of power continuously on each 10/100 Mbps port. However,

taking into account some power loss over the cable run, the amount of
power that can be delivered to a terminal device is 12.95 W. If a device
draws more than 15.4 W, from a port, an overload condition occurs and
the port turns off the power.

The switch controls the power and data on a port independently. Power
can be requested from a device that already has a data link to the switch.
Also, the switch can supply power to a device even if the port’s data
connection has been disabled. The power on a port is continuously
monitored by the switch and it will be turned off as soon as a device
connection is removed.

4-2

T

WISTED-PAIR DEVICES

Cabling Guidelines

The RJ-45 ports on the switch supports automatic MDI/MDI-X pinout
configuration, so you can use standard straight-through twisted-pair cables
to connect to any other network device (PCs, servers, switches, routers, or
hubs).

See Appendix B for further information on cabling.

Caution: Do not plug a phone jack connector into an RJ-45 port.
This will damage the switch. Use only twisted-pair cables with
RJ-45 connectors that conform to FCC standards.

Connecting to PCs, Servers, Hubs and Switches

1. Attach one end of a twisted-pair cable segment to the device’s RJ-45

connector.

Figure 4-1 Making Twisted-Pair Connections

2. If the device is a PC card and the switch is in the wiring closet, attach

the other end of the cable segment to a modular wall outlet that is
connected to the wiring closet. (See “Network Wiring Connections”
on page 4.) Otherwise, attach the other end to an available port on the
switch.

4-3

M

AKING NETWORK CONNECTIONS

Make sure each twisted pair cable does not exceed 100 meters (328 ft)
in length.

3. As each connection is made, the Link LED (on the switch)

corresponding to each port will light to indicate that the connection is
valid.

Note: Avoid using flow control on a port connected to a hub unless it is

actually required to solve a problem. Otherwise back pressure
jamming signals may degrade overall performance for the segment
attached to the hub.

Network Wiring Connections

Today, the punch-down block is an integral part of many of the newer
equipment racks. It is actually part of the patch panel. Instructions for
making connections in the wiring closet with this type of equipment
follows.

1. Attach one end of a patch cable to an available port on the switch, and

the other end to the patch panel.

2. If not already in place, attach one end of a cable segment to the back

of the patch panel where the punch-down block is located, and the
other end to a modular wall outlet.

3. Label the cables to simplify future troubleshooting.

4-4

F

IBER OPTIC

SFP D

EVICES

Switch

7

2

5

2

L

P

8

2

1

6

C

M

S

5

2

2

t

c

A

/

k

n

i

L

2

m

e

t

s

y

S

6

2

2

7

8

0

0

1

/

c

0

t

i

1

w

h

S

r

e

g

i

T

8

2
6

2

8

2
7

2

Equipment Rack
(side view)

Punch-Down Block

Patch Panel

Wall

Figure 4-2 Network Wiring Connections

Fiber Optic SFP Devices

An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX, or
1000BASE-ZX) can be used for a backbone connection between switches,
or for connecting to a high-speed server.

Each multimode fiber optic port requires 50/125 or 62.5/125 micron
multimode fiber optic cabling with an LC connector at both ends. Each
single-mode fiber port requires 9/125 micron single-mode fiber optic
cable with an LC connector at both ends.

Warning: This switch uses lasers to transmit signals over fiber optic

cable. The lasers are compliant with the requirements of a
Class 1 Laser Product and are inherently eye safe in normal
operation. However, you should never look directly at a
transmit port when it is powered on.

4-5

M

AKING NETWORK CONNECTIONS

Warning: When selecting a fiber SFP device, considering safety, please

make sure that it can function at a temperature that is not less
than the recommended maximum operational temperature of
the product. You must also use an approved Laser Class 1 SFP
transceiver.

Hinweis: Bei der Wahl eines Glasfasertransceivers muß für die

Beurteilung der Gesamtsicherheit beachtet werden, das die
maximale Umgebungstemperatur des Transceivers für den
Betrieb nicht niedriger ist als die für dieses Produkts. Der
Glasfasertransceiver muß auch ein überprüftes Gerät der Laser
Klasse 1 sein.

1. Remove and keep the LC port’s rubber cover. When not connected to
a fiber cable, the rubber cover should be replaced to protect the optics.

2. Check that the fiber terminators are clean. You can clean the cable
plugs by wiping them gently with a clean tissue or cotton ball
moistened with a little ethanol. Dirty fiber terminators on fiber cables
will impair the quality of the light transmitted through the cable and
lead to degraded performance on the port.

3. Connect one end of the cable to the LC port on the switch and the
other end to the LC port on the other device. Since LC connectors are
keyed, the cable can be attached in only one orientation.

4-6

25 27

F

IBER OPTIC

SFP D

EVICES

26 28

TigerSwitch 10/100

27 28

Figure 4-3 Making Fiber Port Connections

4. As a connection is made, check the Link LED on the switch
corresponding to the port to be sure that the connection is valid.

The 1000BASE-SX, 1000BASE-LX and 1000BASE-ZX fiber optic ports
operate at 1 Gbps full duplex, with auto-negotiation of flow control. The
maximum length for fiber optic cable operating at Gigabit speed will
depend on the fiber type as listed under “1000 Mbps Gigabit Ethernet
Collision Domain” on page 4-9.

4-7

M

AKING NETWORK CONNECTIONS

Connectivity Rules

When adding hubs (repeaters) to your network, please follow the
connectivity rules listed in the manuals for these products. However, note
that because switches break up the path for connected devices into
separate collision domains, you should not include the switch or connected
cabling in your calculations for cascade length involving other devices.

1000BASE-T Cable Requirements

All Category 5 UTP cables that are used for 100BASE-TX connections
should also work for 1000BASE-T, providing that all four wire pairs are
connected. However, it is recommended that for all critical connections, or
any new cable installations, Category 5e (enhanced Category 5) or
Category 6 cable should be used. The Category 5e specification includes
test parameters that are only recommendations for Category 5. Therefore,
the first step in preparing existing Category 5 cabling for running
1000BASE-T is a simple test of the cable installation to be sure that it
complies with the IEEE 802.3ab standards.

4-8

C

1000 Mbps Gigabit Ethernet Collision Domain

Table 4-1 Maximum 1000BASE-T Gigabit Ethernet Cable Length

Cable Type Maximum Cable

Length

Category 5, 5e, 6 100-ohm UTP or
STP

Table 4-2 Maximum 1000BASE-SX Gigabit Ethernet Cable Length

Fiber Size Fiber

62.5/125 micron
multimode fiber

50/125 micron
multimode fiber

Table 4-3 Maximum 1000BASE-LX Gigabit Ethernet Cable Length

Fiber Size Fiber

9/125 micron
single-mode fiber

Bandwidth

160 MHz/km 2-220 m (7-722 ft) LC

200 MHz/km 2-275 m (7-902 ft) LC

400 MHz/km 2-500 m (7-1641 ft) LC

500 MHz/km 2-550 m (7-1805 ft) LC

Bandwidth

N/A 2 m - 5 km (7 ft - 3.2

100 m (328 ft) RJ-45

Maximum Cable
Length

Maximum Cable
Length

miles)

ONNECTIVITY RULES

Connector

Connector

Connector

LC

Table 4-4 Maximum 1000BASE-ZX Gigabit Ethernet Cable Length

Fiber Size Fiber

Bandwidth

9/125 micron
single-mode fiber

N/A 70 m - 100 km (43 ft -

Maximum Cable
Length

62 miles)

Connector

LC

Note: For link spans exceeding 70 km, you may need to use premium

single mode fiber or dispersion shifted single mode fiber.

4-9

M

AKING NETWORK CONNECTIONS

100 Mbps Fast Ethernet Collision Domain

Table 4-5 Maximum Fast Ethernet Cable Length

Type Cable Type Max. Cable

100BASE-TX Category 5 or better 100-ohm UTP

or STP

Length

100 m (328 ft) RJ-45

10 Mbps Ethernet Collision Domain

Table 4-6 Maximum Ethernet Cable Length

Type Cable Type Max. Cable

Length

10BASE-T Twisted Pair, Categories 3, 4, 5 or

better 100-ohm UTP

100 m (328 ft) RJ-45

Connector

Connector

4-10

C

ABLE LABELING AND CONNECTION RECORDS

Cable Labeling and Connection Records

When planning a network installation, it is essential to label the opposing
ends of cables and to record where each cable is connected. Doing so will
enable you to easily locate inter-connected devices, isolate faults and
change your topology without need for unnecessary time consumption.

To best manage the physical implementations of your network, follow
these guidelines:

• Clearly label the opposing ends of each cable.

• Using your building’s floor plans, draw a map of the location of all

network-connected equipment. For each piece of equipment, identify
the devices to which it is connected.

• Note the length of each cable and the maximum cable length

supported by the switch ports.

• For ease of understanding, use a location-based key when assigning

prefixes to your cable labeling.

• Use sequential numbers for cables that originate from the same

equipment.

• Differentiate between racks by naming accordingly.

• Label each separate piece of equipment.

• Display a copy of your equipment map, including keys to all

abbreviations at each equipment rack.

4-11

M

AKING NETWORK CONNECTIONS

4-12

A

PPENDIX

T

ROUBLESHOOTING

Diagnosing Switch Indicators

Table A-1 Troubleshooting Chart

Symptom Action

Power LED is Off • Power supply is disconnected.

• Check connections between the switch, the power cord, and
the wall outlet.

•Contact your dealer for assistance.

Power LED is
Amber

Diag LED is
Flashing Amber

Link LED is Off • Verify that the switch and attached device are powered on.

• Internal power supply has failed.

• Contact your local dealer for assistance.

• Power cycle the switch to try and clear the condition

• If the condition does not clear, contact your dealer for
assistance

• Be sure the cable is plugged into both the switch and
corresponding device.

• If the switch is installed in a rack, check the connections to the
punch-down block and patch panel.

• Verify that the proper cable type is used and its length does not
exceed specified limits.

• Check the adapter on the attached device and cable
connections for possible defects. Replace the defective
adapter or cable if necessary.

A

A-1

T

ROUBLESHOOTING

Power and Cooling Problems

If the power indicator does not turn on when the power cord is plugged in,
you may have a problem with the power outlet, power cord, or internal
power supply. However, if the unit powers off after running for a while,
check for loose power connections, power losses or surges at the power
outlet, and verify that the fans on the unit are unobstructed and running
prior to shutdown. If you still cannot isolate the problem, then the internal
power supply may be defective.

Installation

Verify that all system components have been properly installed. If one or
more components appear to be malfunctioning (such as the power cord or
network cabling), test them in an alternate environment where you are sure
that all the other components are functioning properly.

In-Band Access

You can access the management agent in the switch from anywhere within
the attached network using Telnet, a Web browser, or other network
management software tools. However, you must first configure the switch
with a valid IP address, subnet mask, and default gateway. If you have
trouble establishing a link to the management agent, check to see if you
have a valid network connection. Then verify that you entered the correct
IP address. Also, be sure the port through which you are connecting to the
switch has not been disabled. If it has not been disabled, then check the
network cabling that runs between your remote location and the switch.

Note: The management agent can accept up to four simultaneous Telnet

sessions. If the maximum number of sessions already exists, an
additional Telnet connection will not be able to log into the
system.

A-2

A

PPENDIX

C

ABLES

Twisted-Pair Cable and Pin Assignments

For 10/100BASE-TX connections, a twisted-pair cable must have two
pairs of wires. For 1000BASE-T connections the twisted-pair cable must
have four pairs of wires. Each wire pair is identified by two different colors.
For example, one wire might be green and the other, green with white
stripes. Also, an RJ-45 connector must be attached to both ends of the
cable.

Caution: Each wire pair must be attached to the RJ-45 connectors in a

specific orientation.

Caution: DO NOT plug a phone jack connector into any RJ-45 port.

This will damage the switch. Use only twisted-pair cables with
RJ-45 connectors that conform with FCC standards.

The figure below illustrates how the pins on the RJ-45 connector are
numbered. Be sure to hold the connectors in the same orientation when
attaching the wires to the pins.

B

8

1

Figure B-1 RJ-45 Connector Pin Numbers

8

B-1

C

ABLES

10/100BASE-TX Pin Assignments

Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for
RJ-45 connections: 100-ohm Category 3 or better cable for 10 Mbps
connections, or 100-ohm Category 5 or better cable for 100 Mbps
connections. Also be sure
does not exceed 100 meters (328 feet).

Data and PoE power are delivered on the standard two wire pairs (pins 1,
2, 3, and 6). Since the RJ-45 ports on the switch base unit support
automatic MDI/MDI-X operation, you can use straight-through cables for
all network connections to PCs or servers, or to other switches or hubs. In
straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are
connected straight through to pins 1, 2, 3, and 6 at the other end of the
cable. When using any RJ-45 port on this switch, you can use either
straight-through or crossover cable.

Table B-1 10/100BASE-TX MDI-X and MDI Port Pinouts

Pin MDI Signal Name MDI-X Signal Name

1 Receive Data plus (RD+)

and GND (Positive V

2 Receive Data minus (RD-) and

3

6

4, 5, 7, 8

Note: The “+” and “-” signs represent the polarity of the wires that make up
each wire pair.

and GND (Positive V

Transmit Data plus (TD+)
and -48V feeding power
(Negative V

Transmit Data minus (TD-)
and -48V feeding power
(Negative V

Not used Not used

that the length of any twisted-pair connection

Transmit Data plus (TD+)

port

port

)

port

)

port

)

)

and -48V feeding power
(Negative V

Transmit Data minus (TD-)
and -48V feeding power
(Negative V

Receive Data plus (RD+)
and GND (Positive V

Receive Data minus (RD-)
and GND (Positive V

port

port

)

)

port

port

)

)

B-2

T

WISTED-PAIR CABLE AND PIN ASSIGNMENTS

Straight-Through Wiring

If the twisted-pair cable is to join two ports and only one of the ports has
an internal crossover (MDI-X), the two pairs of wires must be
straight-through. (When auto-negotiation is enabled for any RJ-45 port on
this switch, you can use either straight-through or crossover cable to
connect to any device type.)

You must connect all four wire pairs as shown in the following diagram to
support Gigabit Ethernet connections.

EIA/TIA 568B RJ-45 Wiring Standard

10/100BASE-TX Straight-through Cable

White/Orange Stripe

Orange

End A

1
2
3
4
5
6
7
8

White/Green Stripe

Blue

White/Blue Stripe

Green

White/Brown Stripe

Brown

Figure B-2 Straight-through Wiring

1
2
3
4
5
6
7
8

End B

B-3

C

ABLES

Crossover Wiring

If the twisted-pair cable is to join two ports and either both ports are
labeled with an “X” (MDI-X) or neither port is labeled with an “X”
(MDI), a crossover must be implemented in the wiring. (When
auto-negotiation is enabled for any RJ-45 port on this switch, you can use
either straight-through or crossover cable to connect to any device type.)

You must connect all four wire pairs as shown in the following diagram to
support Gigabit Ethernet connections.

10/100BASE-TX Crossover Cable

White/Orange Stripe

Orange

End A

1
2
3
4
5
6
7
8

White/Green Stripe

Blue

White/Blue Stripe

Green

White/Brown Stripe

Brown

1
2
3
4
5
6
7
8

End B

B-4

Figure B-3 Crossover Wiring

T

WISTED-PAIR CABLE AND PIN ASSIGNMENTS

1000BASE-T Pin Assignments

All 1000BASE-T ports support automatic MDI/MDI-X operation, so you
can use straight-through cables for all network connections to PCs or
servers, or to other switches or hubs.

The table below shows the 1000BASE-T MDI and MDI-X port pinouts.
These ports require that all four pairs of wires be connected. Note that for
1000BASE-T operation, all four pairs of wires are used for both transmit
and receive.

Use 100-ohm Category 5, 5e or 6 unshielded twisted-pair (UTP) or
shielded twisted-pair (STP) cable for 1000BASE-T connections. Also be
sure

that the length of any twisted-pair connection does not exceed 100

meters (328 feet)

Table B-2 1000BASE-T MDI and MDI-X Port Pinouts

Pin MDI Signal Name MDI-X Signal Name

Bi-directional Data One Plus (BI_D1+) Bi-directional Data Two Plus (BI_D2+)

1

Bi-directional Data One Minus (BI_D1-) Bi-directional Data Two Minus (BI_D2-)

2

Bi-directional Data Two Plus (BI_D2+) Bi-directional Data One Plus (BI_D1+)

3

Bi-directional Data Three Plus (BI_D3+) Bi-directional Data Four Plus (BI_D4+)

4

Bi-directional Data Three Minus (BI_D3-) Bi-directional Data Four Minus (BI_D4-)

5

Bi-directional Data Two Minus (BI_D2-) Bi-directional Data One Minus (BI_D1-)

6

Bi-directional Data Four Plus (BI_D4+) Bi-directional Data Three Plus (BI_D3+)

7

Bi-directional Data Four Minus (BI_D4-) Bi-directional Data Three Minus (BI_D3-)

8

.

Cable Testing for Existing Category 5 Cable

Installed Category 5 cabling must pass tests for Attenuation, Near-End
Crosstalk (NEXT), and Far-End Crosstalk (FEXT). This cable testing
information is specified in the ANSI/TIA/EIA-TSB-67 standard.
Additionally, cables must also pass test parameters for Return Loss and
Equal-Level Far-End Crosstalk (ELFEXT). These tests are specified in the

B-5

C

ABLES

ANSI/TIA/EIA-TSB-95 Bulletin, “The Additional Transmission
Performance Guidelines for 100 Ohm 4-Pair Category 5 Cabling.”

Note that when testing your cable installation, be sure to include all patch
cables between switches and end devices.

Adjusting Existing Category 5 Cabling to Run 1000BASE-T

If your existing Category 5 installation does not meet one of the test
parameters for 1000BASE-T, there are basically three measures that can be
applied to try and correct the problem:

1. Replace any Category 5 patch cables with high-performance Category
5e or Category 6 cables.

2. Reduce the number of connectors used in the link.

3. Reconnect some of the connectors in the link.

B-6

S

Physical Characteristics

Ports

24 10/100BASE-TX, with auto-negotiation
2 10/100/1000BASE-T Ports
2 Combination Gigabit Ports (RJ-45/SFP)

Network Interface

Ports 1-24: RJ-45 connector, auto MDI/X

10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)

Ports 25-28: RJ-45 connector, auto MDI/X

1000BASE-T: RJ-45 (100-ohm, UTP cable; Category 5, 5e, or 6)

Buffer Architecture

4 Mbits

A

PPENDIX

C

PECIFICATIONS

Aggregate Bandwidth

12.8 Gbps

Switching Database

8K MAC address entries

LEDs

System:

Power (Power Supply), Diag (Diagnostic)

Port:

Link/Act (Link/Activity)

Weight

4.13kg (9.11 lbs)

C-1

S

PECIFICATIONS

Size

4.3 x 44 x 17.1 cm (1.7 x 17.3 x 6.7 in.)

Temper at ur e

Operating: 0 to 45 °C (32 to 113 °F)

Storage: -40 to 70 °C (-40 to 158 °F)

Humidity

Operating: 10% to 90% (non-condensing)

Power Supply

Internal, auto-ranging transformer: 100 to 240 V, 50-60 Hz, 3 A

Power Consumption

225 Watts maximum

Maximum Current

0.25 A @ 115 VAC

0.12 A @ 230 VAC

Switch Features

Forwarding Mode

Store-and-forward

Throughput

Wire speed

Flow Control

Full Duplex: IEEE 802.3x
Half Duplex: Back pressure

C-2

Management Features

In-Band Management

Telnet, HTTP or SNMP manager

Out-of-Band Management

RS-232 DB-9 console port

Software Loading

TFTP in-band, or XModem out-of-band

Standards

IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3z and 802.3ab Gigabit Ethernet
IEEE 802.1D (Bridging)
IEEE 802.3x full-duplex flow control
IEEE 802.1Q (Virtual LAN)
ISO/IEC 8802-3

M

ANAGEMENT FEATURES

Compliances

CE Mark

Emissions

FCC Class A
Industry Canada Class A
EN55022 (CISPR 22) Class A
EN 61000-3-2/3
VCCI Class A

Immunity

EN 61000-4-2/3/4/5/6/8/11

C-3

S

PECIFICATIONS

Safety

UL / CUL (UL 60950-1, CSA 22.2 NO60950-1)
TUV/GS (EN60950-1)
CB (IEC60950-1)

C-4

A

PPENDIX

O

RDERING INFORMATION

Table D-1 TigerSwitch 10/100 Products and Accessories

Product Number Description

SMC6128PL2 24 10/100BASE-TX ports, and four Gigabit

combination ports that are comprised of a RJ-45
port and an SFP transceiver slots.

SMCBGSLCX1 1-port 1000BASE-SX Small Form Pluggable (SFP)

mini-GBIC transceiver

SMCBGLLCX1 1-port 1000BASE-LX Small Form Pluggable (SFP)

mini-GBIC transceiver

SMCBGZLCX1 1-port 1000BASE-ZX Small Form Pluggable

(SFP) mini-GBIC transceiver

D

D-1

O

RDERING INFORMATION

D-2

A

PPENDIX

G

ERMAN INSTRUCTIONS

Eine Site Auswählen (Selecting a Site)

Die Schalter können in ein Standard-19-Zoll-Ausrüstungsgestell oder auf
eine flache Ebene montiert werden.

Zum Auswählen eines Standortes beachten Sie bitte die nachstehenden
Richtlinien.

• Die Site sollte:

- Sich in der Mitte aller anzuschließenden Geräte sowie in der Nähe
einer Netzsteckdose befinden;

- Imstande sein, eine Temperatur zwischen 0 und 45 °C (32 und 113°F)
und eine Feuchtigkeit innerhalb von 5% bis 95% (nichtkondensierend)
beizubehalten;

- In einem genügend weiten Abstand (ungefähr 5 cm oder zwei Zoll)
von allen Seiten fur eine ausreichende Beluftung aufgestellt werden;

- Für das Installieren, die Kabelverlegung und für Wartungen und
Reparaturen leicht zugänglich sein.

E

- Die LED-Statusanzeigedioden mussen stets klar und leicht sichtbar
sein.

• Sicherstellen, dass das verdrehte Kabel stets weg von anderen
Stromkabeln, Neonleuchteinrihtungen und anderen Quellen von
moglichen elektrischen Storungen verlegt wird, wie z. B. von Radios und
Transmittern.

E-1

G

ERMAN INSTRUCTIONS

• Sicherstellen, dass das Gerät an eine separate Stromquelle mit
Erdanschlus mit einer Netzspannung von 100 bis 240 V AC
(Wechselstromspannung), 50 bis 60 Hz, und innerhalb in einem Abstand
von 2,44 m (8 Fus) zu jedem Gerät installiert wird und on einem
separaten Trennschalter bzw. Leistungsschalter mit Strom versorgt wird.
Fur alle Geräte wird empfohlen, einen Filter oder einen
Überspannungsschutz zu verwenden.

Montage (Rack Mounting Instructions)

Switch-Einheiten können an ein standardmäßiges 19-Zoll
Einrichtungsrack, einen Arbeitstisch oder ein Regal montiert werden.
Folgend finden Sie die Montageanweisungen für jeden Positionstyp.

Rack-Montage

Beachten Sie die folgenden Faktoren, bevor Sie die Rack-Montage
beginnen:

• Temperatur: Da die Temperatur innerhalb einer Rackeinheit höher als die
Raumumgebungstemperatur sein kann, stellen Sie bitte sicher, dass die
Rackumgebungstemperatur innerhalb des angegebenen
Betriebstemperaturbereichs liegt. (Siehe "Temperatur" auf Seite C-2.)

• Mechanische Last: Stellen Sie kein Gerät auf eine Rack-Montageeinheit.

• Stromüberlastung: Stellen Sie sicher, dass der Netzkreis der Rackeinheit
nicht überlastet wird.

• Erdung: Die Rack-Montageeinheit muss richtig geerdet werden.
Besondere Acht sollten Sie bei Verbindungen geben, die nicht direkt zum
Netz führen.

E-2

A

RATING

100~240V-

3A 50~60HZ

NSCHLUSS AN EINE STROMQUELLE

(C

ONNECTING TO A POWER SOURCE

So montieren Sie Geräte an ein Rack:

1. Befestigen Sie die Metallwinkel mit den im Metallwinkel-Montageset

erhältlichen Schrauben an dem Gerät.

2. Befestigen Sie das Gerät mit vier Rackmontageschrauben (nicht

beigelegt) an dem Rack.

3. Wenn Sie nur einen Switch installieren, dann springen Sie bitte über zu

"Verbinden mit einer Stromquelle" auf Seite 3-8 am Ende dieses
Kapitels.

4. Wenn Sie mehrere Switches installieren möchten, dann montieren Sie

sie untereinander in einer beliebigen Reihenfolge.

Anschluss an eine Stromquelle (Connecting to a Power Source)

So verbinden Sie das Gerät mit einer Stromquelle:

1. Stecken Sie den Stecker des Netzkabels direkt in den Anschluss an der

Rückseites des Gerätes ein.

)

Abbildung 3-6: Stromanschlüsse

2. Verbinden Sie das andere Ende des Kabels mit einer

Schutzkontaktsteckdose („Schuko-Steckdose“, mit Erdungszungen an
den Seiten).

E-3

G

ERMAN INSTRUCTIONS

Hinweis: Im Ausland müssen Sie eventuell ein anderes Netzkabel

verwenden. Wählen Sie dazu ein zugelassenes, für die
Steckdosen des jeweiligen Landes passendes Netzkabel.

3. Überzeugen Sie sich davon, dass das Gerät mit Strom versorgt wird:

Die Betrieb-LED („Power“) an der Vorderseite muss leuchten. Falls
nicht, schauen Sie nach, ob das Netzkabel richtig eingesteckt ist.

E-4

G

LOSSARY

10BASE-T

IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of
Category 3, 4, or 5 UTP cable.

100BASE-TX

IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of
Category 5 UTP cable.

1000BASE-LX

Specification for long-haul Gigabit Ethernet over two strands of 50/125,

62.5/125 or 9/125 micron core fiber cable.

1000BASE-SX

IEEE 802.3z specification for Gigabit Ethernet over two strands of 50/125
or 62.5/125 micron core fiber cable.

1000BASE-T

IEEE 802.3ab specification for Gigabit Ethernet over 100-ohm Category
5, 5e or 6 twisted-pair cable (using all four wire pairs).

1000BASE-ZX

Specification for long-haul Gigabit Ethernet over two strands of 9/125
micron core fiber cable.

Auto-Negotiation

Signalling method allowing each node to select its optimum operational
mode (e.g., speed and duplex mode) based on the capabilities of the node
to which it is connected.

Glossary-1

Bandwidth

The difference between the highest and lowest frequencies available for
network signals. Also synonymous with wire speed, the actual speed of the
data transmission along the cable.

Collision

A condition in which packets transmitted over the cable interfere
other. Their interference makes both signals unintelligible.

Collision Domain

Single CSMA/CD LAN segment.

CSMA/CD

CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the
communication method employed by Ethernet, Fast Ethernet, or Gigabit
Ethernet.

End Station

A workstation, server, or other device that does not forward traffic.

Ethernet

A network communication system developed and standardized by DEC,
Intel, and Xerox, using baseband transmission, CSMA/CD access, logical
bus topology, and coaxial cable. The successor IEEE 802.3 standard
provides for integration into the OSI model and extends the physical layer
and media with repeaters and implementations that operate on fiber, thin
coax and twisted-pair cable.

with each

Fast Ethernet

A 100 Mbps network communication system based on Ethernet and the
CSMA/CD access method.

Glossary-2

Gigabit Ethernet

A 1000 Mbps network communication system based on Ethernet and the
CSMA/CD access method.

Full Duplex

Transmission method that allows two network devices to transmit and
receive concurrently, effectively doubling the bandwidth of that link.

IEEE

Institute of Electrical and Electronic Engineers.

IEEE 802.3

Defines carrier sense multiple access with collision detection (CSMA/CD)
access method and physical layer specifications.

IEEE 802.3ab

Defines CSMA/CD access method and physical layer specifications for
1000BASE-T Gigabit Ethernet.

IEEE 802.3ae

Defines the access method and physical layer specifications for 10GBASE
10-Gigabit Ethernet.

IEEE 802.3u

Defines CSMA/CD access method and physical layer specifications for
100BASE-TX Fast Ethernet.

IEEE 802.3x

Defines Ethernet frame start/stop requests and timers used for flow
control on full-duplex links.

IEEE 802.3z

Defines CSMA/CD access method and physical layer specifications for

Glossary-3

1000BASE Gigabit Ethernet.

LAN Segment

Separate LAN or collision domain.

LED

Light emitting diode used for monitoring a device or network condition.

Local Area Network (LAN)

A group of interconnected computer and support devices.

Media Access Control (MAC)

A portion of the networking protocol that governs access to the
transmission medium, facilitating the exchange of data between network
nodes.

Modal Bandwidth

Bandwidth for multimode fiber is referred to as modal bandwidth because
it varies with the modal field (or core diameter) of the fiber. Modal
bandwidth is specified in units of MHz per km, which indicates the
amount of bandwidth supported by the fiber for a one km distance.

MIB

An acronym for Management Information Base. It is a set of database
objects that contains information about the device.

Network Diameter

Wire distance between two end stations in the same collision domain.

RJ-45 Connector

A connector for twisted-pair wiring.

Switched Ports

Glossary-4

Ports that are on separate collision domains or LAN segments.

TIA

Telecommunications Industry Association

Transmission Control Protocol/Internet Protocol (TCP/IP)

Protocol suite that includes TCP as the primary transport protocol, and IP
as the network layer protocol.

UTP

Unshielded twisted-pair cable.

Virtual LAN (VLAN)

A Virtual LAN is a collection of network nodes that share the same
collision domain regardless of their physical location or connection point
in the network. A VLAN serves as a logical workgroup with no physical
barriers, allowing users to share information and resources as though
located on the same LAN.

Glossary-5

Glossary-6

I

NDEX

Numerics

10 Mbps connectivity rules 4-10
1000BASE-T

pin assignments
ports

1-3

100BASE-TX

pin assignments
ports 1-3

10BASE-T

pin assignments
ports 1-3

B-5

B-2

B-2

A

accessories, ordering D-1
adhesive feet, attaching 3-6
air flow requirements
application example 2-2

3-1

B

brackets, attaching 3-5
buffer size
buffers, saturation of

C-1

1-3

C

cable

Ethernet cable compatibility 3-2

labeling and connection records
cleaning fiber terminators
compliances

C-3

EMC

C-4

safety
connectivity rules

10 Mbps
console port

pin assignments 3-9

4-10

4-6

4-11

contents of package 3-3
cooling problems
cord sets, international 3-8

A-2

D

desktop mounting 3-6
device connections 4-1

E

electrical interference, avoiding 3-1
equipment checklist
Ethernet connectivity rules 4-10

3-3

F

features C-3

management
switch 1-6

fiber cables 4-5
flow control, IEEE 802.3x
full duplex connectivity 2-1

1-7

1-3

G

grounding for racks 3-4

I

IEEE 802.3x flow control 1-3
indicators, LED
installation

connecting devices to the switch
desktop or shelf mounting
port connections
power requirements 3-1
problems A-2
rack mounting

1-4

3-6

4-1

3-4

4-3

Index-1

I

NDEX

site requirements 3-1, E-1
wiring closet connections

Introduction 2-1

4-4

L

laser safety 4-5
LED indicators

1-4

Link
Power 1-5

location requirements 3-1, E-1

M

management

1-3

agent
features 1-7, C-3
out-of-band 1-3

1-3

SNMP
Web-based 1-3

mounting the switch

3-4

in a rack
on a desktop or shelf 3-6

multimode fiber optic cables

4-5

N

network

connections
examples 2-2

4-1

O

ordering information D-1
out-of-band management

1-3

P

package contents 3-3
pin assignments B-1

console port
DB-9

port saturation 1-3
ports, connecting to 4-1
power, connecting to

3-9

3-9

3-8

R

rack mounting 3-4
rear panel receptacles 1-6
RJ-45 port 1-3

connections
pinouts B-5

rubber foot pads, attaching 3-6

4-1

S

screws for rack mounting 3-3
site selelction
SNMP agent 1-3
specifications

compliances
environmental C-2
physical
power C-2

standards, compliance C-3
status LEDs
surge suppressor, using

3-1

C-3

C-1, E-1

1-4

3-1

T

Telnet A-2
temperature within a rack
TigerSwitch 10/100 Products and

Accessories

troubleshooting

in-band access
power and cooling problems

twisted-pair connections

3-4

D-1

A-2

A-2

4-1

Index-2

W

Web-based management 1-3

I

NDEX

Index-3

I

NDEX

Index-4

FOR TECHNICAL SUPPORT, CALL:

From U.S.A. and Canada (24 hours a day, 7 days a week)

(800) SMC-4-YOU; Phn: [phone]; Fax: [phone]

From Europe: Contact details can be found on www.smc.com

INTERNET

E-mail addresses:

[e-mail]

Driver updates:

http://www.smc.com/index.cfm?action=tech support drivers downloads

World Wide Web:

http://www.smc.com/

FOR LITERATURE OR ADVERTISING RESPONSE, CALL:

U.S.A. and Canada: (800) SMC-4-YOU Fax [phone]
Spain: 34-91-352-00-40 Fax [phone]
UK: 44 (0) 871 277 98 02 Fax [phone]
France: 33 (0) 1 55 64 04 55 Fax [phone]
Italy: 39 02 739 12 68 Fax [phone]
Benelux: 31 (0) 654 776 790 Fax [phone]
Central Europe: 49 (0) 89 92861-0 Fax [phone]
Nordic and Baltics: 46 (0) 566 622 83 Fax [phone]
Eastern Europe: 420 266 794 421 Fax [phone]
Sub-Saharian Africa: 27 012 661 0232 Fax [phone]
North West Africa: 34 93 477 4920 Fax [phone]
CIS: 34 93 477 4920 Fax [phone]
PRC: 86-10-6235-4958 Fax [phone]
Taiwan: 886-2-8797-8006 Fax [phone]
Asia Pacific: (65) 238 6556 Fax [phone]
Korea: 82-2-553-0860 Fax [phone]
Japan: 81-45-224-2332 Fax [phone]
Australia: 61-2-8875-7887 Fax [phone]
India: 91-22-8204437 Fax [phone]

If you are looking for further contact information, please visit www.smc.com.

20 Mason
Irvine, CA 92618
Phone: [phone]

Model Numbers: SMC6128PL2
Publication Number: 150000050500A E022007-JC-R01
