SMART Technologies SBID-6086S SPECIFICATIONS

Was this document helpful?

78 1/8" (198.5 cm)

48 1/8" (122.1 cm)

4 7/8"

(12.4 cm)

smarttech.com/docfeedback/171586

Specifications

SMARTBoard® 6086S interactive display

Overview

The SMART Board® 6086S interactive display with SMART Learning Suite is the
hub of your classroom.

The 4K Ultra HD LED interactive display provides optimal image clarity and wide
viewing angles. SMART's exclusive and proprietary Tool Explorer™ platform
allows a wide range of accessories to cater to different subject matter, learning
styles, and student needs. Unique Simultaneous Tool Differentiation allows
multiple users to write simultaneously with a pen, move objects with a finger,
and erase digital ink with a palm—all without switching tools, providing
uninterrupted collaboration. The display’s advanced HyPr Touch™ with InGlass™
touch technology provides a natural, intuitive writing and touch experience
with high accuracy and low latency.

See smarttech.com for more information.

Dimensions and weights

1

Dimensions

As an ENERGY STAR® certified signage display, the SMARTBoard 6086S interactive display meets strict
energy efficiency guidelines set by the U.S. Environmental Protection Agency and Department of Energy.

Weight

192 lb. (87 kg)

Shipping dimensions (includingpallet)

86" × 57" × 10 3/8"
(218.6 cm × 144.7 cm × 26.4 cm)

Shipping weight

240 lb. (109 kg)

2

1

All dimensions± 1/8" (0.3 cm). All weights ± 2 lb. (0.9 kg).

2

Product shipsupright

smarttech.com/kb/171586 1

Specifications

SMARTBoard6 086S interactive display – ModelSBID-608 6S

Highlights

HyPr Touch with InGlass HyPr Touch with InGlass advanced optical technology ensures highly accurate writing and

drawing

Tool Explorer The Tool Explorer proprietary tool platform supports virtually unlimited pen and tool recognition

Ambient light sensor Screen automatically dims or brightens, ensuring comfortable viewing in all lighting conditions

Hardware

Interaction

Touch technology HyPr Touch with InGlass

Multitouch capabilities Up to 20 simultaneous interaction points

3

Object Awareness™ Behavior adjusts automatically to the tool or object you’re using, whether it’s a pen, finger,

eraser, or palm

Simultaneous Tool Differentiation

Multiple users can touch the display and use pens and erasers at the same time for a natural,
fully collaborative experience

Pen ID™ Multiple users can write independently and simultaneously, using different colored ink

Tool Explorer Support for virtually unlimited pen and tool recognition

Silktouch™ Ultra-smooth finish that allows you to use the display for hours without finger burn

Display

Type LCD with LEDback light

Aspect ratio 16:9

Optimal resolution

4K UHD (3840 × 2160) at 60 Hz

(HDMI inputs)

Brightness (maximum) 350 cd/m²

Pixel dimensions 0.429 mm × 0.429 mm

Viewing angle 178°

Response time 8 ms

Ambient light sensor Yes

Proximity sensor Yes

Infrared sensor Yes

3

Chrome OS™ is limited to 10 simultaneoustouches, including gestures. Automatic pen recognition, plus palm, pen, and eraser differentiation are av ailable in supported

applications.

smarttech.com/kb/171586 2

Specifications

SMARTBoard6 086S interactive display – ModelSBID-608 6S

Room temperature and
humidity sensors

4

Yes

100BASE-T Ethernet Two external ports for a 4-port Fast Ethernet switched network that connects the interactive

display to a network and an external device, such as a computer

Wireless Wi-Fi and Bluetooth® disabled at setup and cannot be reenabled

Audio Two 20 W integrated front-facing speakers

Noise level <32 dBA

Included cables and

accessories

1 Country-specific power cable
1 USB cable
2 Pens (red and black)
2 Eraser
1 Remote control
2 AAA batteries for the remote control
1 WM-SBID-200 wall mount

Mounting holes For a standard VESA 600 mm × 400 mm mounting plate

Lower mounting holes 11" (28 cm) from the bottom of the interactive display

Mounting bracket depth Minimum depth of 1 1/2" (3.7 cm) for all components on the back of the interactive display for

airflow

Accessory holes M4 mounting points located at the top, bottom, left, and right for SMART approved accessories

Software

Included software SMART Ink® and SMART Product Drivers

SMART Notebook® basic version
Bonus one-year subscription to SMART Learning Suite (including SMARTNotebook software)

Connectors

Convenience panel

1 HDMI® 2.0 in with HDCP 1.4 and HDCP2.2 support
2 USB 3.0 Type-A (for media)
1 USB 3.0 Type-B (for touch)

4

Temperatureand humidity data is not available when iQ features are disabled.

smarttech.com/kb/171586 3

Specifications

SMARTBoard6 086S interactive display – ModelSBID-608 6S

Connector panel

1 Accessory slot (for OPS devices)
1 USB 3.0 Type-A (for media)
1 USB 2.0 Type-A (for service use only)
3 USB 3.0 Type-B (for touch)
2 HDMI 2.0 in with HDCP 1.4 and HDCP2.2 support
1 HDMI 2.0 out
1 VGA in
1 Stereo 3.5 mm in
1 Stereo 3.5 mm out
1 S/PDIF out
2 RJ45
1 RS-232 in
1 RS-232 out

Back of display

1 AC power in
1 AC power out

Installation requirements

Interactive display See the SMARTBoard 6000S and 6000S Pro series interactive displays installation and

maintenance guide (smarttech.com/kb/171414)

Room computers and guest laptops

General requirements See SMARTNotebook software release notes

4K UHD Video card that can support 3840 × 2160 resolution at 60 Hz

See Minimum requirements for Ultra High Definition or 4K on your interactive flat panel

Mini-computers

General requirements See SMARTNotebook software release notes

Dimensions Smaller than 4 3/4"×4 3/4"×1 1/4" (12cm×12cm×3.3cm)

Weight Less than 10lb. (4.5kg)

Mounting VESA 75mm×75mm or 100mm×100mm mounting pattern (two mounting points: left and

right)

Cable requirements

HDMI Maximum length: 23' (7 m)

NOTES

l A certified Premium High Speed HDMI Cable is required for a display resolution of 3840 ×

2160 at more than 30 Hz (such as 50 or 60 Hz).

l The performance of cables longer than 23' (7 m) is highly dependent on the cable’s

quality.

smarttech.com/kb/171586 4

Specifications

SMARTBoard6 086S interactive display – ModelSBID-608 6S

USB 2.0 USB 2.0 certified

Hi-Speed (480 Mbps) support
Maximum length: 16' (5 m)

USB 3.0 USB 3.0 certified

SuperSpeed (5 Gbps) support
Maximum length: 9' (3 m)

NOTES

l SMART supports only installations that use directly connected video and USB cables,

AC-powered extenders, or USB extenders purchased from SMART.

l You might be able to use higher-grade cables that are longer than specified. If you have

problems with such a cable or an extender of any type, test the connection with a shorter
cable before contacting SMART Support.

Important Using cables that exceed these maximum lengths can produce unexpected results, such as

degraded picture quality or USB connectivity. Refer to Installation best practices for SMART
product s (smarttech.com/kb/171035) for comprehensive information about cables and
extensions for SMART hardware products.

Storage and operating requirements

Power requirements 100V to 240V AC, 50 Hz to 60 Hz

Power consumption a t 77°F (25°C)

Standby mode <0.5 W

Normal operating 172 W

Operating temperature 41–95°F (5–35°C)

Storage temperature -4–140°F (-20–60°C)

Humidity 5–80% relative humidity, non-condensing

Certification and compliance (partial)

U.S. / Canada UL, FCC, ISED, CONEG Packaging, Proposition 65

EU / EEA / EFTA / UK CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign

Australia / NewZealand RCM

Performance standards ENERGY STAR®, HDMI, USB

5

5

Product availability may vary by region.

smarttech.com/kb/171586 5

Specifications

SMARTBoard6 086S interactive display – ModelSBID-608 6S

Purchasing information

Order number

SBID-6086S SMARTBoard 6086S interactive display and SMARTLearningSuite

Optional accessories

TS-4PEN-MC Tool Explorer multicolor 4-pen bundle (orange, purple, green, blue) with magnetic penwell

TS-PEN-HLITE Tool Explorer double-ended Highlighter (yellow & green)

TS-PEN-MAGIC Tool Explorer Magic Pen

Other See smarttech.com/accessories

Warranty information

SMART Assure warranty Includes advanced hardware replacement and access to onsite support. Terms and conditions

vary by region. Contact your local reseller or distributor for information and visit

smarttech.com/warranty.

smarttech.com/support
smarttech.com/contactsupport
