SmartRG PL62 User Manual
Quick Start Guide
PL60 /PL62AC
This Quick Start Guide shows you how to set up and begin using your new powerline
adapters.
REQUIREMENTS
Safety Notice:
l The socket-outlet shall be installed near the equipment and shall be easily access-
ible.
l le socle de prise de courant doit être installé à proximité du matériel et doit être
aisément accessible.
Minimum requirements for using the PL60 and PL62AC are:
l Ethernet Network interface (10, 100 or 1000 Mbps transfer rate)
l Router with Internet connection and one available LANport
l An electrical outlet available for each adapter
For best results:
l Place the adapter in a regular wall outlet with no other devices plugged in. Con-
necting this product to a power strip or surge suppression device may adversely
affect the performance.
l Avoid using in an electrical outlet that is near high power consumption appliances
such as a washer, dryer, refrigerator, microwave, hair dryer or air conditioning unit.
l If you have connection problems, temporarily plug in both adapters in the same
room. If the Data LED on both units is illuminated, the adapters are functioning properly and your home's electrical wiring is contributing to the connection problems.
LED INDICATORS
The LEDs on the front of the PL60 can help you
understand the current state of your adapters.
LED Action Meaning
Power Adapter is on.
Adapter is setting up security
Adapter is in power-save mode
Ethernet Ethernet port is connected
No Ethernet connection
Data Adapter is syncing
Data transfer rate is > 80Mbps
Data transfer rate is between 50Mbps and 80Mbps
Data transfer rate is < 50Mbps
No compatible units found with same encryption key
Wireless
PL62AC only
(
Legend: Steady Glow Blinking Not Connected or Off
)
Wi-fi radio is on
Wi-fi radio is pairing with a wi-fi device via WPS
3
