Smart WM700EW User Manual
INSTALLATION AND MAINTENANCE
INSTRUCTIONS
Manufacturer is not responsible for any transcription errors or misprints contained in this handbook
furthermore the manufacturer reserves the right to make any modification on the products which
might be deemed necessary or useful this being in the user’s interest without altering their basic
operating or safety features
!
2!
DIMENSIONS & ELECTRICAL DATA PAGE 3
DESCRIPTION & PARTS BREAKDOWN PAGE 4
CONTENTS OF CARTON PAGE 5
WARNINGS PAGE 6
INSTALLATION PAGE 7-8-9
ELECTRICAL CONNECTIONS & WARNINGS PAGE 10
USE PAGE 12
MAINTENANCE & CLEANING PAGE 12-13
SPARE PARTS & TECHNICAL PAGE 14
WARRANTY'S PAGE 15-16
!
3!
Dear User
We are sincerely grateful to you for purchasing one of our products we are sure that this modern functional and
easy to use appliance, built with the finest materials and components will satisfy all your needs.
We kindly ask you to read very carefully the instructions within this handbook as to enable you to obtain safety
and quality results.
The appliance must be installed only by an expert technician in compliance with the instructions provided
the manufacturer declines all responsibility for improper installation
TECHNICAL DATA
VOLTAGE: 120 V FREQUENCY: 60 Hz
TOTAL RATING: 1500 WATTS AMPS: 1 2.5 AMPS
!
4!
2
3
1: SWITCH FOR ELECTRIC
ELEMENTS
1
2/3: RESIDUAL HEAT INDICATORS
RADIANT ELECTRIC
HEATING ELEMENT
SMOOTH GLASS 750 W
RADIANT ELECTRIC
HEATING ELEMENT
UNDULATING GLASS 750
W
DESCRIPTION OF THE HOT PLATES
!
5!
CONTENTS OF CARTON
● UPPER SOCKET PUNCH ( TO USE AS TEMPLATE FOR
DRILLING )
● BBQ WITH FIXING WALL BRACKET
● INSTRUCTION MANUAL
● LOWER SOCKET PUNCH (TO USE AS TEMPLATE FOR
DRILLING )
● OIL DRAIN CUP
● RAZER SCRAPER FOR PLATES
GLASS SUPPORT
WALL FIXING BRACKET
OIL DRAIN CUP
POCKETS FOR OBJECTS
!
6!
IMPORTANT SAFEGUARDS
a) Read all instructions.
b) Do not touch hot surfaces. Use handles or knobs.
c) To protect against electrical shock do not put immerse cord or plugs in water or other
liquid.
d) Close supervision is necessary when any appliance is used by or near children.
e) Unplug from outlet when not in use and before cleaning. Allow to cool before putting on
or taking off parts.
f) Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair, or adjustment.
g) The use of accessory attachments, not recommended by the manufacturer may cause
injuries.
h) Do not let cord hang over edge of table or counter or touch hot surfaces.
i)!Do!not!place!on!or!near!a!hot!gas!or!electric!burner!or!in !a!h eate d!o ve n!
j) Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
k) Always attach plug to appliance first then plug cord into the wall outlet. To disconnect,
turn the control to OFF, then remove plug from wall outlet.
l) Do not use appliance for other than intended use.
m) Fuel, such as charcoal briquettes, is not to be used with appliance.
n) Use only on properly grounded outlet.
o) Do not clean this product with a water spray or the like.
p)!SAVE!THESE!INSTRUCTIONS!
