Installation Guide Windsensor-IEN101010 3
Notes on this Guide SMA Solar Technology AG
1 Notes on this Guide
This installation guide describes how to install and commission the anemometer. Store this installation
guide where it will be accessible at all times.
1.1 Validity
This installation guide is valid for the upgrade kit of the anemometer.
1.2 Target Group
This installation guide is intended for the installer.
1.3 Symbols Used
The following types of safety instructions and general information appear in this document as
described below:
DANGER!
"DANGER" indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING!
"WARNING" indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION!
"CAUTION" indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
CAUTION!
"NOTICE" indicates a situation that can result in property damage if not avoided.
Information
Information provides tips that are valuable for the optimum operation of the product.
4 Windsensor-IEN101010 Installation Guide
SMA Solar Technology AG Safety
2 Safety
2.1 Appropriate Usage
The anemometer is a sensor intended to measure horizontal wind force outdoors. The provided
performance data can be processed by the Sunny SensorBox. Use the anemometer exclusively for
purposes indicated in the installation guide and the indicated application range. Use only SMA
Solar Technology AG original accessories or accessories recommended by SMA Solar Technology.
Read the accompanying documentation for the anemometer and the communication product
carefully before connecting the anemometer.
2.2 Safety Precautions
General safety precautions to avoid bodily harm
• Lay cables so that no one stands on them or trips over them.
• Work on rooftops entails a safety risk, and requires special safeguards to be implemented.
General information in order to avoid damage to the device.
• Damage to the sensors as a result of incorrect connection to the Sunny Boy Control Plus or
Sunny Central Control. Before connecting, read the corresponding installation guide and use
the enclosed circuit diagram when commissioning the Sunny Central Control.
• Integrate the sensor into the existing lightning protection.
• Protect your PV plant components against overvoltage from outside by connecting the sensors
to an overvoltage protector. When using the sensors with the Sunny Central, the corresponding
overvoltage protectors can be ordered as an option from Sunny Central.
Installation Guide Windsensor-IEN101010 5
