Skytex Skypad 706, SP 706 User Manual

7” Multimedia Tablet

SP706

User Manual

IMPORTANT NOTICES

This package may contain plastic bags or other
materials that pose a hazard to children. Be sure to
dispose of all packaging materials after opening.

To avoid damaging the screen, do not touch it with
excessive force or with any object other than your

nger. For best response, make sure your hands are

clean before using the touch screen controls.

The battery used in this Tablet may present a re or
chemical burn if misused. Don’t heat or incinerate the
Tablet. Don’t leave it in a place subject to direct
sunlight, or in a car with windows closed. Don’t
connect to a power source from another manufacturer.

This may result in the risk of re or electric shock.

SKYTEX is not responsible for any loss or damages
incurred from your access to third pary content, Apps,
or services and expressly disclaims all warranties of
any kind.

To avoid damage and data corruption do not remove
a memory card while data is being written to or read
from the card. As an example, do not remove the card

while playing a video or music le stored on the card.

The available menu items are dependent on the unit.
All illustrations are for reference only.

Customer Use Only:

Enter the model number of your Tablet and save for

reference.

Model #: _________________________________

Serial #: _________________________________

Be especially cautious with applications that request
access to many functions or to a signicant amount of
your data. You are responsible for the results of
applications installed on your tablet.

The Tablet’s “mass storage mode” is compatible with
many operating systems including: Windows
7, 8 or higher, Mac OS X or Linux.

For recycling or disposal information about this product,
visit our website, or contact your local recycling centers
or the Electronics Industries Alliance: www.eiae.org.

Company Trademarks

SKYTEX logo is a trademark of SKYTEX TECHNOLOGY
INC. Android is a trademark of Google Inc. Use of this
trademark and Google Play are subject to Google
Permission. HDMI, the HDMI logo are trademarks or
registered trademarks of HDMI Licensing, LLC. All other
trademarks and logos are property of their respective
owners unless indicated otherwise.

®

XP, Vista,

1

FCC COMPLIANCE

This Table complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This Tablet may not cause harmful interference, and
(2) This Tablet must accept any interference received, including interference that may cause undesired operation.
Note: This Tablet has been tested and found to comply with the limits for Class B digital devices, pursuant to Part

15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This Tablet generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this Tablet does cause harmful interference to radio or
television reception, which can be determined by turning the Tablet off and on, the user is encouraged to attempt
to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the Tablet and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV techinician for help.

Use of shielded cable is required to comply with Class B limits in Subpart B of part 15 of the FCC rules. Do not
make any changes or modications to the Tablet unless otherwise specied in the manual. If such changes or
modications should be made, you could be required to stop using the Tablet.

2

SAFETY NOTICES

1. Read and retain these instructions for future
reference.

2. Warnings on the product and User Manual
instructions should always be adhered to.

3. Cleaning: Do not use liquid cleaners or aerosol
cleaner. Use a damp soft cloth for cleaning.

4. Adapters: Use UL certied adapters recommended
by SKYTEX. Other adapters may be hazardous or
void your warranty.

5. Moisture & Water: Do not use near water such as
a bath tub, kitchen sink, laundry tub, or swimming
pool.

6. Ventilation: Should there be slots and openings in
the Tablet, they are provided for ventilation to ensure
reliable operation of and protection from overheating.
These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar
surface.

7. Power Sources: This Tablet should be operated from
the type of power source indicated on the rating label.
Consult your product dealer or our website for more
information. For products intended to operate from
battery power or other sources, refer to the operating
intructions.

8. Overloading: Do not overload wall outlets,
extension cords, or integral convenience receptables

as this can result in a risk of re or electric shock.

9. Object and Liquid Entry: Never put objects of any
kind on to or into this product through openings as
they may touch dangerous voltage points or short
out parts that could result in a re or electric shock.
Never spill liquid of any kind on the product.

10. Servicing: Do not attempt to service this product
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards and will
void your warranty. Refer all servicing to qualied
service personnel.

11. Damage Requiring Service: Unplug this product
from the wall outlet and refer servicing to qualied
service personnel: a) when the power-supply is
damaged; b) if liquid has been spilled; c) if the
product has been exposed to rain or water;
d) if the product does not operate normally; e) if the
product has been dropped or damaged in any way
(voids warranty); f) when the product exhibits a
distinct change in performance.

12. Heat: The product should be kept away from heat
sources such as radiator, heat register, stove, or
other products that generate heat.

13. Replacement Parts: Unauthorized substitutions
when servicing this product may result in re,
electric shock, or other hazards. Make sure your

service technician has used parts specied by the

manufacturer.

3

TABLE OF CONTENTS

Important Notices .......................................................................................................................................1

FCC Compliance ........................................................................................................................................2

Safety Notices ............................................................................................................................................3

Table of Contents .......................................................................................................................................4

Introduction .................................................................................................................................................5

Tablet Controls & Descriptions ...................................................................................................................6-7

Charging Your Tablet .................................................................................................................................8

Power ON/OFF/STANDBY .........................................................................................................................9

Connecting To a Wireless Network ............................................................................................................10

Install Apps .................................................................................................................................................11

Browse the Web .........................................................................................................................................12

Settings: Date, Time, Screen Time Out ......................................................................................................13

Home Screen Applications .........................................................................................................................14

Discover Application Shortcuts ...................................................................................................................15

Notications Bar / Connecting HDMI to HDTV / Using micro-USB.............................................................16

Transfer Music / Video / Photos .................................................................................................................17

Playing Music / Video .................................................................................................................................18

Video Streaming / Insert Memory Card ......................................................................................................19

Camera & Video Chat.................................................................................................................................20

Setting Up Your Email ................................................................................................................................21

Troubleshooting ..........................................................................................................................................22

Specications .............................................................................................................................................23

Warranty & Support ....................................................................................................................................24

4

INTRODUCTION

Thank you for purchasing the new SKYTEX 7” Tablet with 800X480 multi-touch display. It is designed
to keep you entertained and engaged for hours at a time. With 8GB of internal storage and MicroSD card slot (for
up to an additional 32GB), you can house a large library of games, movies, music, eBooks, photos and document

les.

The Tablet also features a web cam and 2MP rear camera for life’s special moments.

Discover and download thousands of your favorite Android Apps from the Skytex App Store*. Skytex Apps are
optimized specifically for your screen size bringing you the best experience possible in which to view them. In
addition, 5GB of free cloud storage is provided through the CloudLink
business friendly Apps.

It is recommended that you read this user manual completely before first use. Visit our website at www.skytex.com

to register your tablet and review additional information and updated FAQ’s.

PACKAGE CONTENTS: Tablet, USB Cable, AC Adapter.

* Approximately 1.5GB of Internal storage is used for the OS, system files and pre-installed Apps.

**Poweredby Good e-Reader.

®

Toobox which includes many of today’s

5

TABLET CONTROLS AND DESCRIPTIONS

1

4

5

2

3

1. Front camera Front facing camera for video chat.

2. Volume + Press and hold to increase volume.

3. Volume - Press and hold to decrease volume.

4. Power On/Off Press and hold momentarily to turn on; when powering off you will be asked to conrm.

5. 3.5mm Jack Audio connection to listen to stereo earphones or powered speakers.

6. Reset Press to reset the tablet.

6

6

TABLET CONTROLS AND DESCRIPTIONS

9

7

8

13 12 11

7. Micro-USB OTG Connect to a computer to transfer les or use with a keyboard/mouse.

8. MicroSD Card Slot Load external storage memory card (up to an additional 32GB).

9. Rear camera Take photos using the display as viewnder.

10. Speaker Listen through speaker unless earphone jack is connected. Sound will mute.

11. Open Apps Key Tap to view open applications. Swipe to the left to close and save battery life.

12. Home Key Tap to go to the Home Launcher Screen.

13. Back Key Tap to go back to the previous page.

10

7

CHARGING YOUR TABLET

The Tablet comes with a built-in rechargeable battery that should be charged fully prior to rst use. Connect the
AC adapter to your Tablet via the micro-USB Input on the bottom of the Table (illustrated below). Disconnect the
Tablet when it is fully charged.

A full charge and discharge (15% or below) cycle is recommended to maximize the battery’s life and performance.

If the battery is completely drained please allow the Tablet at least 10-15 minutes to recharge prior to turning it on.

NOTE: When charging the Tablet while powered OFF, the battery indicator appears momentarily. Although the

battery indicator disappears, the Tablet will continue to charge. To view if the battery is continuing to charge,
tap the Power button once.

8

POWER ON/OFF/STANDBY MODE

ON: Press and hold the Power button until the Tablet’s
loading screen appears. Once the lock screen appears,

unlock the Tablet by swipping your nger from the left

‘Unlock’ icon to the right ‘Unlock’ icon (illustrated below).
Should the display ‘Timeout’ (or go black) before you
are able to unlock the Tablet, press the Power button
for one second th turn the display back on.

OFF: Press and hold the Power button until the
Tablet options appear. The options will prompt you
to tap ‘OK’ to power the Tablet off or ‘Cancel’ to
return back to the Home screen.

STANDBY: To enter Standby Mode, simply tap and
release the Power button. To wake from Standby,
tap and release the Power button.

NOTE: Leaving the Tablet in Standby Mode when not
in use will result in battery drain. Switch the Tablet off
completely to conserve power between charges.

9

CONNECTING TO A WIRELESS NETWORK

NOTE: To connect your Tablet to the Internet you must have an Internet connection and a wireless network.

A. Open the Apps Tray > Select ‘Settings’ > Switch the ‘Wi-Fi’ option from ‘OFF’ to ‘ON’ by tapping
the ‘OFF’ icon.

B. A list of networks will appear to the right of the screen > Select your network and enter the
password/network key.
C. Tap ‘Connect’ to complete the connection

Tip: Check the “Show Password” box to verify password was entered correctly.

10

WiFi

REQUIREMENTS:

A wireless router or an access point through a
broadband Internet connection is required. You
must know the name of your network, password,
and whether your network is secured. The
settings may be found on your wireless router
and/or its user manual.

NOTE: If you were connected to a network
previously, your Tablet will automatically

reconnect once your Wi-Fi is turned ‘ON’.

If your network ID is not listed, tap the
SCAN icon located on the top right corner
of the screen.

INSTALL APPS

A. Tap the App and search or browse by
Category for popular apps to download on to your
Tablet. Select the desired App to download and
install. (You must be connected to a wireless
network.)

B. NOTE: When your download has completed, you
will be prompted to install the App. Tap ‘Install’
and when completed the App will appear in your
App Tray.

Discover and manage pre-populated productivity
apps within CloudLink’s Toobox that includes 5GB of

free cloud storage; Catch Notes; Ofce Suite to view

docs, spreadsheets; PowerPoint; premium Apps
available.

®

®

The Skytex App Store is stocked with the
most popular free Apps that have been “optimized”

specically for the screen size on your Tablet.

Hundred more are optimized for release weekly.

Purchase Apps from the Amazon App Store.

Check their Free App of the Day Promotion

featured daily.

11

BROWSE THE WEB

Bookmark a Favorite Page

A. Scroll to the top of the desired web page.
B. Tap the start on the URL > Tap ‘OK.’

12

Your Tablet is equipped with a full HTML Web Browser
that enables you to view web pages.

A. To access the Web Browser select the icon
from the App Tray.
B. To enter a URL, tap the URL eld at the top of the
browser and enter the desired link using the

QWERTY keyboard.

C. Tap ‘Go’ to load the page.

SETTINGS: Date, Time, & Screen Timeout

Manual Time Setting
A. Open the App Tray > Select ‘Settings’ > Scroll
down to and tap ‘Date & Time’ > Select ‘Set Time’
> Set the hour and minute by tapping the arrow
keys; then tap ‘Set.’
Manual Date Setting
A. Open the App Tray > Select ‘Settings’ > Scroll
down to and tap ‘Date & Time’ > Select ‘Set Date’
> Set the month, date, and year by tapping the
arrow keys; then tap ‘Set.’

Auto Date & Time
A. Open the App Tray > Select ‘Settings’
> Scroll down to and tap ‘Date & Time’ > Select
‘Automatic Date & Time’ to check the box.

NOTE: The ‘Automatic Date & Time’ option sets the
date and time using the network provided. Should an
incorrect time zone appear, tap ‘Select Time Zone’

Screen Timeout
A. Open the App Tray > Select ‘Settings’
> ‘Display’ > ‘Sleep.’
B. A dialogue box will appear with several options to
choose from. Tap the length of time (in seconds or
minutes) before the Tablet goes black (to conserve
battery life).

and nd the appropriate time zone.

13

HOME SCREEN APPLICATIONS

Home Launcher Screen
This is your starting point. The Home Launcher screen

consists of 5 screens (slide nger left or right across
the screen to view). You’ll nd pre-installed AppLink

shortcuts of the most popular Apps used today, that
are ready for download once you connect to the
Internet.

NOTE: Apps that are running in the background will
take up valuable memory and drain battery resources.
Take the icon to view any open Apps, then
swipe toward the left to close them.

14

Add or Remove Favorite Apps from App Tray

A. To open the App Tray tap the icon located at
the upper right hand corner of the Tablet to display
all of the applications that have been pre-installed
or downloaded to your Tablet.
B. To add to the Home Launcher screen, tap and hold
the desired App. Release the icon onto the Home
screen.
C. To remove an App from the Home Launcher
screen, tap and hold the icon until it enlarges, then
slide to remove to Trash.

DISCOVER APP SHORTCUTS

Your Home launcher screens feature pre-installed Apps shortcuts and AppLinks for your convenience.
They are ready for download once you connect to the Internet. Several examples are described below.

Music - Access music les installed on your Tablet.

App Tray - Access all Apps that are installed on to your Tablet.

Settings - View and modify settings for Wireless network, display, battery, menu language, etc.

Internet Browser - Access the world wide web when connected to a wireless network.

File Manager - View all your les installed on your Tablet.

Gallery - Access photos and videos you have installed on your Tablet.

®

Skytex App Store - Thousands of the most popular Android Apps specically optimized for your tablet display!

Get Kindle - Download and again access to millions of eBooks, magazines, newspapers, audio books, games,
blogs, and more.

Cloudlink - Discover and manage pre-populated productivity suite content from CloudLink’s Toobox including
5GB of free cloud storage.

Get Amazon - One of (up to 12) pre-installed AppLinks direct you to download the actual App once connected
to a wireless network. When installed the App will be located in your App Tray. It is recommended to delete
the “Get” AppLink once the actual App is downloaded and installed, to reserve space on your Home screen.

15

NOTIFICATIONS BAR / CONNECT TO TV / USING micro-USB

NOTIFICATIONS BAR
The Notications Bar, located at the top left of the Home Launcher screen displays new messages, alerts and

icons that show the time, wireless network status, battery charge, progress of download, connectivity of Bluetooth*
or micro-USB, alarm setup, and more.

Back Home Open Apps App Tray

Back - Tap to go back to the previous page.
Home - Tap to go to the Home Launcher Screen.
Open Apps - Tap to view open applications. Swipe to

the left to close and save battery life.
App Tray - Access all applications installed on to the
Tablet.

HDMI*

Your Tablet features an HDMI output to display its content digitally to your HDTV. Enjoy the benets of high
denition video by connecting an optional mini-HDMI HD cable (available at the SKYTEX store at www.skytex.com).

Micro-USB
Your Tablet offers true versatility when using the micro-USB port. Cables are available at the SKYTEX online store.
Keyboard/Mouse - connect an optional keyboard or mouse using an optional micro-USB OTG cable.
Ethernet Adapter - connect your Tablet to a wired Internet network using an optional Ethernet to USB dongle.
3G Wireless - connect an optional 3G wireless modem dongle. *Insert your SIM card into it and use your Tablet

when Wi-Fi isn’t available.
Transfer Files & Additional Storage - connect a ash drive using the cable provided with your Tablet.

*- When available

16

TRANSFER MUSIC / VIDEO / PHOTOS

A. Connect your Tablet to your PC via the USB cable.

B. A USB symbol will appear in the Notications

Bar / Bottom Bar.
C. Select the symbol that appears > Tap USB
Connect > Turn on USB Storage.
D. You are now able to drag-and-drop your music,

video, and photo les between your Tablet and PC.

NOTE: Your Tablet will be recognized as an external
drive.Once completed, tap ‘Turn off USB Storage’ and
remove Tablet from your PC.

17

PLAYING MUSIC / VIDEO

Watch Videos
A. Go to the App Tray and select ‘Gallery’

B. Select the video le to view.

C. Once the video begins, you may select playback.

View Photos
A. Go to the App Tray and select ‘Gallery’

B. Tap on photo les you would like to view.

18

Play Music
A. Go to the App Tray then tap ‘Music’ App.
B. Select the desired song and adjust volume settings
to your liking.
C. To exit out of the App, tap ‘Home’ or ‘Back.’
D. To stop music playback, go back to the Music App
and tap ‘Pause.’

NOTE: Hearing experts advise against the constant
use of headphones played at high volume. Constant
exposure to higher volumes may lead to hearing loss.
Should you experience ringing in the ears or hearing
loss, discontinue use.

VIDEO STREAMING / INSERT MEMORY CARD

VIDEO STREMING
Your Tablet is capable of streaming videos directly from the
Internet or via 3
streaming video applications are available through the Skytex
App Store for download on to the Tablet. Prior to streaming

video les, download the application of your choice.

INSERTING A MICROSD CARD
Your Tablet will accept a MicroSD memory card to add up
to an additional 32GB of storage for videos, music, photos,
documents, and more.
Align an optional memory card with the card slot. Make
certain the metal contacts are facing downward. Slide
the card carefully into the spring-loaded slot until it clicks
securely.
To remove safely, enter SETTINGS and STORAGE to view
options. Tap UNMOUNT SD card, then push the memory card
with your thumbnail further into the slot until it springs outward
of the slot. Do not remove card while any apps is in use.

NOTE:
Do not attempt to insert objects other than a MicroSD memory card into the card slot. A compatible memory card

should t easily into the card slot. If you encounter resistance, check the alignment of the card. Do not attempt to

force the card in. Avoid touching the gold contacts of the memory card.

rd

party streaming applications. Popular

19

CAMERA & VIDEO CHAT

Web Camera Functions

A. Tap the Trash Can icon to delete.
B. Tap Menu > ‘Set Picture As’ to set the photo as the
Tablet’s background.

Video Chat
A. Download and install your favorite video chat app
from the Skytex App Store or 1Mobile Market.
B. The Webcam is set as the default camera for
video chat.

20

Rear Camera Functions

A. Open the ‘Camera’ application by tapping the
Camera icon
B. Switch between front and rear camera by tapping
the Switch icon.
C. Capture images shown on the display by tapping
D. Tap the thumbnail of an image that appears to view
or edit the photo.
E. You may also view your photos with the ‘Gallery’
app

SETTING UP YOUR EMAIL

A. From your App Tray, tap the ‘Email’ icon to enter the Email client.

B. Enter an Email address and a password.
C. After you have entered your information press ‘Next’ to move to the next step.
D. The Email app will test the incoming and outgoing mail servers. Once completed you will be prompted
to enter an account name and your name.
E. The account name is used to identify the name of the account on the Tablet.

F. Your name will be displayed on all outgoing messages sent from the Email app on your Tablet.

NOTE: Certain Email providers will require you to enter more details about the type of account you are using.
You will have three choices: POP3, IMAP, and Exchange. If unsure of your account type, please contact
your Email provider for more information.

21

TROUBLESHOOTING

For more updated FAQs and troubleshooting tips, visit us at www.skytex.com/support.

Symptom Solution

My touchscreen is not responding.
How do I reset the tablet?

The battery drained completely
and now it won’t turn on...

I inserted a MicroSD card. Where

are my les located?

1Mobile Market states a ‘Network
Error’ message when I attempt a
download.

My Wi-Fi says it’s ‘Disconnected’
after I attempt to connect.

22

To reset, rst make sure the power source is unplugged. Press and

hold the Power button for 10 seconds and then plug the power
source back in. Press the Power button for another 2-3 seconds.
To erase all data on the Tablet go to Settings > Backup & reset >

Factory Data Reset. ALL DATA WILL BE LOST.

After inserting the card, nd your les in the “File Manage” application.
Go to the App tray; open ‘File Manager’, Select SD card icon to
access les.

The App requires an update to the most recent version. Visit

http://www.1mobile.com on your Tablet’s browse and download

the updated version.

The Disconnected status means that the tablet is not connected to
any network. Make sure the correct password is entered when
connecting to your wireless network. This password could be on the
bottom of the router or a password that was created by someone

when the Wi-Fi device was originally set up.

SPECIFICATIONS

HD Display Type:
Processor Type:
Operating System:
Storage Capacity:
Internal Memory:
Memory Card Supported:
Wireless LAN:
HDMI:
Cameras:
Micro-USB:
Stereo Headphone Output:
Tablet Dimensions:
Tablet Weight:
Battery Capacity:
Input Voltage, Power Adapter:
Limited Warranty:

7” 800 x 480 Capacitive Touchscreen Display

1.2GHz Processor + Mali-400MP
Android 4.2.2 Jelly Bean
8GB* Internal Storage
512MB RAM
MicroSD Expansion to 32GB

802.11b/g/n
None

VGA Front / 2MP Rear

Yes

3.5mm

7.53”(L) x 4.57”(W) x 0.47”(D)
11 oz.
Up to 8 hours
100V-240VAC, 50/60Hz, 5V Output (UL Listed)
1 Year Parts & Labor

1

2

NOTE:
1 - * Available storage capacity will be less due to operating system and pre-installed software applications.
2 - Based on theoretical discharge speeds. Actual usage may be lower.

23

WARRANTY & SUPPORT

SKYTEX Technology Inc. warrants against defects in material and workmanship for a period of one year from
original purchase date when purchased from an authorized U.S. reseller/retailer by the original purchaser or is a
consumer who received the Tablet as a gift. You must retain and provide the original bill of sale (or photocopy)
as proof of purchase in case the Tablet requires service. Retain the original box and inner packaging to ship if
necessary.

Your Responsibility

Warranty service shall be provided after a return authorization number (RMA#) is provided to you by our customer

support representative. For one year, SKYTEX will provide at no charge, service repairs using new or replacement

parts. In certain cases your Tablet may be replaced with a refurbished model that meets or exceeds factory

specications. Service provided or refurbished replacement is warranted for the duration of the original warranty

period or 45 days, whichever is greater. Warranty extends to defects in materials or workmanship and does not
cover cosmetic imperfections, damage incurred during shipment to SKYTEX, misuse, accidental drops that crack
the screen, connection to improper equipment, or repairs by an authorized party. Write the RMA number on the
package; include a copy of the store receipt and description of the issue with the product and serial number.

How to Obtain Warranty Service

If after following the User Guide, should you nd it necessary to contact Customer Support, email or call between
9 AM - 5:30 PM Monday - Friday (Pacic Time). Have your date of purchase, seriel number, and a full

understanding of the issue ready for your representative. You are responsible for the transporation costs and
protective packaging associated with shipping the product to SKYTEX safely. Ship the Tablet using a service that
provides tracking information.

Customer Support

Monday - Friday 9:00 AM - 5:30 PM
Phone: [phone] Email: [email protected] Website: www.skytex.com

24
