AS-2500-2 Remote
Computer Reset
Version 1.00
Table of Content
TABLE OF CONTENT .......................2
INTRODUCTION ................................3
INSTALLATION..................................3
PROGRAM THE ACCESS CODE ....3
VERIFY THE ACCESS CODE ..........3
OPERATION ........................................3
TECH SUPPORT - 916-786-6186 .......3
WARRANTY ........................................4
Al Sandige Page 2 12/05/01
Introduction
The AS-2500-2 allows you to reset your
computer by just calling into the AS-2500-2 and
entering your access code. On detection of the
correct access code, the AS-2500-2 will RESET the
computer connected to it. The four digit access code
can be verified or changed by the user.
This unit has two methods for resetting a
computer: momentary power down and dry close
contact. When the correct access code is entered,
the unit can shut off power to the computer for 20
seconds; or optionally close the dry close contact.
The 20 second off time is needed for adequate
protection of the computer's power supply. If you
don't want to turn the computer's power off, you can
have the dry close contact connected across the reset
button on your computer and the AS-2500-2, when it
activates, will cause a momentary HARD reset to
your computer.
4) Enter your new four digit access code (the * and
# cannot be used in your access code); you will
hear a pulsating acknowledgment tone.
5) Now hang up and place the switch on the back
of the unit, to the NORMAL position.
Verify the access
code
1) Put the switch on the back of the AS-2500-2 to
the PROGRAM position and call the unit.
2) You will hear a confirmation tone.
3) After the confirmation tone, dial a touch tone #;
you will hear a pulsating acknowledgment tone.
4) The unit will play the access code to you
through a series of BEEPS, i.e. the code 1 2 3 4
will give you: 1 BEEP, two second pause, 2
BEEPS, pause, 3 BEEPS, pause and 4 BEEPS
(NOTE: you will get 10 BEEPS for a 0).
5) Now hang up and place the switch on the back
of the unit, to the NORMAL position.
Installation
ELECTRONICS
RESET PROGRAM
MO DEL:
S/N:
CODE :
SW ITCHED
SW ITCH
NORMAL
TA D
Wal l
Phone
Jack
LINE
Program the
access code
1) Put the switch on the back of the unit to the
PROGRAM position and call the AS-2500-2.
2) You will hear a confirmation tone.
3) After the confirmation tone, dial a touch tone *;
you will hear a pulsating acknowledgment tone.
Operation
Simply call the AS-2500-2 and enter your
access code after the BEEPS; the AS-2500-2 will
momentarily short the RESET SWITCH output on
the back of the unit, and it will cut power to the
computer for 30 seconds.
Tech Support -
916-786-6186
If you have any problems getting the unit to
work properly feel free to give us a call. Technical
Support is available between the hours of 7:30 AM
and 4:30 PM Pacific Time, Monday through Friday.
Al Sandige Page 3 12/05/01
WARRANTY
This SKUTCH PRODUCT is warranted against
defects for a period of one (1) year from the date of
the original invoice. Within this period, we will
repair it without charge for parts and labor. To
obtain warranty service the product must be
returned, at the customer's expense, to SKUTCH
Electronics along with a copy of the original invoice.
After the unit has been repaired, SKUTCH will ship
the PRODUCT back via UPS GROUND service at
our expense. If any other form of return shipment is
requested, the customer will pay for 100% of the
shipping cost.
This Warranty does not apply if in the sole
opinion of SKUTCH Electronics, the PRODUCT
has been damaged by lightning or any other Acts of
God, or by accident, misuse, neglect, or improper
packing, shipping, modification or servicing by
other than an authorized SKUTCH Service Center.
EXCEPT AS SPECIFICALLY PROVIDED IN
THIS AGREEMENT, THERE ARE NO OTHER
WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OR
MERCHANTABILITIES OR FITNESS FOR A
PARTICULAR PURPOSE AND IN NO EVENT
SHALL SKUTCH ELECTRONICS BE LIABLE
FOR LOSS OF PROFITS OR BENEFITS,
INDIRECT, SPECIAL, CONSEQUENTIAL OR
OTHER SIMILAR DAMAGES ARISING OUT OF
ANY BREACH OF THIS WARRANTY OR
OTHERWISE.
Al Sandige Page 4 12/05/01
