Skil SANDER 7207,7208 Instructions Manual

SANDER
7207 (F0157207..)
7208 (F0157208..)

SKIL Europe BV - Konijnenberg 60 03/08 2610396117
4825 BD Breda - The Netherlands

ME77

www.skileurope.com

ORIGINAL INSTRUCTIONS . . . . . . . . . . . . . 7

NOTICE ORIGINALE . . . . . . . . . . . . . . . . . . 9

ORIGINALBETRIEBSANLEITUNG . . . . . .

13

ORIGINELE GEBRUIKSAANWIJZING. . . . 16

BRUKSANVISNING I ORIGINAL . . . . . . . . 19

ORIGINAL BRUGSANVISNING . . . . . . . . . 22

ORIGINAL DRIFTSINSTRUKS. . . . . . . . . .

25

ALKUPERÄISET OHJEET . . . . . . . . . . . . . 27

MANUAL ORIGINAL . . . . . . . . . . . . . . . . . 30

MANUAL ORIGINAL. . . . . . . . . . . . . . . . . . 34

ISTRUZIONI ORIGINALI . . . . . . . . . . . . . . 37

EREDETI HASZNÁLATI UTASÍTÁS. . . . . . 40

PÒVODNÍM NÁVODEM K POUÎÍVÁNÍ . . . 43

OR‹J‹NAL ‹fiLETME TAL‹MATI . . . . . . . . . 46

INSTRUKCJÑ ORYGINALNÑ. . . . . . . . . . . 49

ОДЛИННИК РУКОВОДСТВА

ПО ЭКСПЛУАТАЦИИ . . . . . . . . . . . . . . . .

52

ОРИГІНАЛЬНА ІНСТРУКЦІЯ

З ЕКСПЛУАТАЦІЇ . . . . . . . . . . . . . . . . . . .

56

ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ . . . . . . 60

INSTRUCØIUNI DE FOLOSIRE

ORIGINALE . . . . . . . . . . . . . . . . . . . . . . . .

63

ОРИГИНАЛНО РЪКОВОДСТВО

ЗА ЕКСПЛОАТАЦИЯ . . . . . . . . . . . . . . . .

66

PÔVODN¯ NÁVOD NA POUÎITIE. . . . . . . 70

ORIGINALNE UPUTE ZA RAD . . . . . . . . . 73

ORIGINALNO UPUTSTVO ZA RAD. . . . . . 76

IZVIRNA NAVODILA. . . . . . . . . . . . . . . . . . 79

ALGUPÄRANE KASUTUSJUHEND. . . . . . 82

INSTRUKCIJÅM ORI˛INÅLVALODÅ. . . . . 85

ORIGINALI INSTRUKCIJA . . . . . . . . . . . . . 88

GB

F

D

NL

S

DK

N

FIN

E

P

I

H

CZ

TR

PL

RU

UA

GR

RO

BG

SK

HR

SRB

SLO

EST

LV

LT

2

F

B

A

CD

E

E

F

G

B

A

CD

NOT STANDARD INCLUDED NOT STANDARD INCLUDED

7207 / 7208

1

2

7207

7208

100

Watt

1,0 kg

EPTA 01/2003

3

4

B

A

5

6

3

4

B A

7

E

E

8

F

G

9 0

7208

72087207

5

!

@

6

#a

$

#

b

%

7

GB

Sander 7207/7208
INTRODUCTION

• This tool is intended for dry sanding and fi nishing of
wood, painted surfaces, plastic and fi ller

• Read and save this instruction manual 3

TECHNICAL SPECIFICATIONS 1
TOOL ELEMENTS 2

A Delta tip
B Button for changing foot plates
C Support plate
D Louvre attachment
E Dust bag (7207) / Dust box (7208)
F On/off switch
G Spot light (7208)

SAFETY

GENERAL SAFETY INSTRUCTIONS

WARNING! Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers to
your mains-operated (corded) power tool.

1) WORK AREA SAFETY

a) Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive

atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

c) Keep children and bystanders away while operating

a power tool. Distractions can cause you to lose
control.

2) ELECTRICAL SAFETY

a) Power tool plugs must match the outlet.

Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools.

Unmodifi ed plugs and matching outlets will reduce risk
of electric shock.

b) Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of
electric shock.

d) Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase

the risk of electric shock.

e) When operating a power tool outdoors,

use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk
of electric shock.

f) If operating a power tool in a damp location is

unavoidable, use an earth leakage circuit breaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.

3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use

common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.

A moment of inattention while operating power tools
may result in serious personal injury.

b) Use personal protective equipment. Always wear

eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.

c) Prevent unintentional starting. Ensure the switch is

in the off-position before connecting to power
source, picking up or carrying the tool. Carrying

power tools with your fi nger on the switch or energising
power tools that have the switch on invites accidents.

d) Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.

e) Do not overreach. Keep proper footing and balance

at all times. This enables better control of the power
tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long

hair can be caught in moving parts.

g) If devices are provided for the connection of dust

extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection

can reduce dust-related hazards.

4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power

tool for your application. The correct power tool will

do the job better and safer at the rate for which it was
designed.

b) Do not use the power tool if the switch does not turn

it on and off.

Any power tool that cannot be controlled

with the switch is dangerous and must be repaired.

c) Disconnect the plug from the power source before

making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures

reduce the risk of starting the power tool accidentally.

8

d) Store idle power tools out of the reach of children

and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained
users.

e) Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly

maintained power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc.,

in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations

different from those intended could result in a
hazardous situation.

5) SERVICE

a) Have your power tool serviced by a qualified repair

person using only identical replacement parts.

This will ensure that the safety of the power tool is
maintained.

SAFETY INSTRUCTIONS FOR SANDERS

• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working

• Always keep the cord away from moving parts of the
tool; direct the cord to the rear, away from the tool

• When you put away the tool, switch off the motor and
ensure that all moving parts have come to a complete
standstill

• Use completely unrolled and safe extension cords with
a capacity of 16 Amps (U.K. 13 Amps)

• In case of electrical or mechanical malfunction,
immediately switch off the tool and disconnect the plug

• We recommend to use original SKIL-accessories as
listed at the back of this instruction manual

• This tool should not be used by people under the age of
16 years

• The noise level when working can exceed 85 dB(A);
wear ear protection

• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug

• Never use the tool when cord is damaged; have it
replaced by a qualifi ed person

• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool (tools
with a rating of 230V or 240V can also be connected to
a 220V supply)

• This tool is not suitable for wet sanding

• Do not work materials containing asbestos (asbestos
is considered carcinogenic)

• Dust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause
allergic reactions and/or respiratory diseases to the
operator or bystanders); wear a dust mask and work

with a dust extraction device when connectable

• Certain kinds of dust are classifi ed as carcinogenic
(such as oak and beech dust) especially in conjunction
with additives for wood conditioning; wear a dust

mask and work with a dust extraction device when
connectable

• Follow the dust-related national requirements for the
materials you want to work with

• When sanding metal, sparks are generated; do not use
dustbag/dustbox and keep other persons and
combustible material from work area

• Do not touch the moving sanding sheet

• Do not continue to use worn, torn or heavily clogged
sanding sheets

• Wear protective gloves, safety glasses, close-fi tting
clothes and hair protection (for long hair)

• Always disconnect plug from power source before
making any adjustment or changing any accessory

WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):

• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug

• If for any reason the old plug is cut off the cord of this
tool, it must be disposed of safely and not left
unattended

USE

• Mounting of sanding sheet 4

! disconnect the plug
! the dust suction requires the use of perforated

sanding sheets

! perforation in sanding sheet should correspond

with perforation in sanding foot
! replace worn sanding sheets in time
! always use the tool with the total sanding surface

covered with sanding paper

- mount VELCRO sanding sheet as illustrated

• Mounting support plate 5

- remove VELCRO sanding sheet

- remove delta tip A while pushing button B

- mount support plate C as illustrated

• Mounting special sanding attachments 6

- mount desired sanding attachment to support

plate C as illustrated

- mount corresponding VELCRO sanding sheet to

sanding attachment

- 3 sanding positions

• Mounting “Louvre” attachment 7

- remove VELCRO sanding sheet

- remove delta tip A while pushing button B

- mount “Louvre” attachment as illustrated

• Dust suction 8

- mount dustbox E/dustbag E

9

- empty dustbox E/dustbag E regularly for optimal dust
pick-up performance

! do not use dustbox/dustbag when sanding metal

• On/off switch

- switch on/off the tool by pushing switch F 2
forward/backwards

! before the sanding surface reaches the

workpiece, you should switch on the tool

! before switching off the tool, you should lift it

from the workpiece

• Spot light 9 (7208)
Spot light G automatically lights on when activating

switch F

• Holding and guiding the tool 0

! while working, always hold the tool at the grey-

coloured grip area(s)

- guide the tool parallel to the working surface

! do not apply too much pressure on the tool; let

the sanding surface do the work for you

- do not tilt the tool in order to avoid unwanted
sanding marks

- keep the ventilation slots uncovered

APPLICATION ADVICE

• Use the tool with its standard foot plate for large
working surfaces, corners and edges !

• Use the tool with the special sanding attachments for
hard-to-reach places @

• The fl exible sanding attachment is intended for

- rounding edged surfaces #a

- all rounded surfaces with a maximum diameter of 10

cm #b

• When the delta-tip is worn or damaged at the top, you
may extend its service life twice by removing it, turning
it 120° and putting it back (also applicable to delta
sanding sheet) $

• Never use the same sanding sheet for wood and metal

• Recommended sanding sheet grits:
coarse - for removing paint;

for sanding of extremely rough wood
medium - for sanding of rough or plain wood
fi ne - for smoothing of wood;

for fi nishing of bare wood;

for smoothing surfaces with old paint

• Use different grit sizes when the working surface is
rough:

- start sanding with coarse or medium grit

- fi nish with fi ne grit

• For more tips see www.skileurope.com

• Vibration level

The vibration emission level stated at the back of this

instruction manual has been measured in accordance
with a standardised test given in EN 60745; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned

- using the tool for different applications, or with

different or poorly maintainted accessories, may
signifi cantly increase the exposure level

- the times when the tool is switched off or when it is
running but not actually doing the job, may
signifi cantly reduce the exposure level

! protect yourself against the effects of vibration by

maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns

MAINTENANCE / SERVICE

• Always keep tool and cord clean (especially the
ventilation slots)

- remove adhering sanding dust with a brush

! disconnect the plug before cleaning

• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skileurope.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and
packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2002/96/EC on

waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility

- symbol % will remind you of this when the need for

disposing occurs

F

Ponceuse 7207/7208
INTRODUCTION

• Cet outil sert au ponçage et au polissage à sec du bois,
des surfaces peintes, du plastique et du mastic

• Lisez et conservez ce manuel d’instructions 3

SPECIFICATIONS TECHNIQUES 1
ELEMENTS DE L’OUTIL 2

A Patin triangulaire
B Bouton pour remplacer la semelle de ponçage
C Plaque de support
D Accessoire à fente
E Sac à poussière (7207) / Réservoir à poussière (7208)
F Interrupteur marche/arrêt
G Eclairage (7208)

✎

92

93

CE DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with the following
standards or standardized documents: EN 60 745, EN 55 014, in accordance with the provisions of the directives 2006/95/EC,
2004/108/EC, 98/37/EC (until Dec. 28, 2009), 2006/42/EC (from Dec. 29, 2009 on).
NOISE/VIBRATION Measured in accordance with EN 60 745 the sound pressure level of this tool is 71 dB(A) and the sound power
level 82 dB(A) (standard deviation: 3 dB), and the vibration 14.3 m/s

2

(hand-arm method; uncertainty K = 1.5 m/s2).

Technical file at: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE DÉCLARATION DE CONFORMITÉ Nous déclarons sous notre propre responsabilité que ce produit est en conformité avec les

normes ou documents normalisés suivants: EN 60 745, EN 55 014, conforme aux réglementations 2006/95/CE, 2004/108/CE,
98/37/CE (jusqu’au 28.12.2009), 2006/42/CE (à partir du 29.12.2009).
BRUIT/VIBRATION Mesuré selon EN 60 745 le niveau de la pression sonore de cet outil est 71 dB(A) et le niveau de la puissance
sonore 82 dB(A) (déviation standard: 3 dB), et la vibration 14,3 m/s

2

(méthode main-bras; incertitude K = 1,5 m/s2).

Dossier technique auprès de: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger Verantwortung, daß dieses Produkt mit den folgenden Normen oder

normativen Dokumenten übereinstimmt: EN 60 745, EN 55 014, gemäß den Bestimmungen der Richtlinien 2006/95/EG,
2004/108/EG, 98/37/EG (bis 28.12.2009), 2006/42/EG (ab 29.12.2009).
GERÄUSCH/VIBRATION Gemessen gemäß EN 60 745 beträgt der Schalldruckpegel dieses Gerätes 71 dB(A) und der Schal­leistungspegel 82 dB(A) (Standard- abweichung: 3 dB), und die Vibration 14,3 m/s

2

(Hand-Arm Methode; unsicherheit K = 1,5 m/s2).

Technische Unterlagen bei: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE CONFORMITEITSVERKLARING Wij verklaren, dat dit product voldoet aan de volgende normen of normatieve documenten:

EN 60 745, EN 55 014, overeenkomstig de bepalingen van de richtlijnen 2006/95/EG, 2004/108/EG, 98/37/EG (tot 28-12-2009),
2006/42/EG (vanaf 29-12-2009).
GELUID/VIBRATIE Gemeten volgens EN 60 745 bedraagt het geluidsdrukniveau van deze machine 71 dB(A) en het
geluidsvermogen-niveau 82 dB(A) (standaard deviatie: 3 dB), en de vibratie 14,3 m/s

2

(hand-arm methode; onzekerheid K = 1,5 m/s2).

Technisch dossier bij: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE KONFORMITETSFÖRKLARING Vi intygar och ansvarar för, att denna produkt överensstämmer med följande norm och

dokument: EN 60 745, EN 55 014, enl. bestämmelser och riktlinjema 2006/95/EG, 2004/108/EG, 98/37/EG (till 28.12.2009),
2006/42/EG (from 29.12.2009).
LJUD/VIBRATION Ljudtrycksnivån som uppmätts enligt EN 60 745 är på denna maskin 71 dB(A) och ljudeffektnivån 82 dB(A)
(standard deviation: 3 dB), och vibration 14,3 m/s

2

(hand-arm metod; onoggrannhet K = 1,5 m/s2).

Teknisk tillverkningsdokumentation finns hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE KONFORMITETSERKLÆRING Vi erklærer under almindeligt ansvar, at dette produkt er i overensstemmelse med følgende

normer eller normative dokumenter: EN 60 745, EN 55 014, i henhold til bestemmelserne i direktiverne 2006/95/EF, 2004/108/EF,
98/37/EF (indtil 28.12.2009), 2006/42/EF (fra 29.12.2009).
STØJ/VIBRATION Måles efter EN 60 745 er lydtrykniveau af dette værktøj 71 dB(A) og lydeffektniveau 82 dB(A) (standard deviation:
3 dB), og vibrationsniveauet 14,3 m/s

2

(hånd-arm metoden; usikkerhed K = 1,5 m/s2).

Teknisk dossier hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE SAMSVARSERKLÆRING Vi erklærer at det er under vårt ansvar at dette produkt er i samsvar med følgende standarder eller

standard- dokumenter: EN 60 745, EN 55 014, i samsvar med reguleringer 2006/95/EF, 2004/108/EF, 98/37/EF (frem til 28.12.2009),
2006/42/EF (fra 29.12.2009).
STØY/VIBRASJON Målt ifølge EN 60 745 er lydtrykknivået av dette verktøyet 71 dB(A) og lydstyrkenivået 82 dB(A) (standard
deviasjon: 3 dB), og vibrasjonsnivået 14,3 m/s

2

(hånd-arm metode; usikkerhet K = 1,5 m/s2).

Tekniske underlag hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE TODISTUS STANDARDINMUKAISUUDESTA Todistamme täten ja vastaamme yksin siitä, että tämä tuote en allalueteltujen

standardien ja standardoimisasiakirjojen vaatimusten mukainen EN 60 745, EN 55 014, seuraavien sääntöjen mukaisesti
2006/95/EY, 2004/108/EY, 98/37/EY (28.12.2009 asti), 2006/42/EY (29.12.2009 alkaen).
MELU/TÄRINÄ Mitattuna EN 60 745 mukaan työkalun melutaso on 71 dB(A) ja yleensä työkalun äänen voimakkuus on 82 dB(A)
(keskihajonta: 3 dB), ja tärinän voimakkuus 14,3 m/s

2

(käsi-käsivarsi metodi; epävarmuus K = 1,5 m/s2).

Tekninen tiedosto kohdasta: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE DECLARACION DE CONFORMIDAD Declaramos bajo nuestra sola responsabilidad que este producto está en conformidad

con las normas o documentos normalizados siguientes: EN 60 745, EN 55 014, de acuerdo con las regulaciones 2006/95/CE,
2004/108/CE, 98/37/CE (hasta el 28.12.2009), 2006/42/CE (a partir del 29.12.2009).
RUIDOS/VIBRACIONES Medido según EN 60 745 el nivel de la presión acústica de esta herramienta se eleva a 71 dB(A) y el nivel de
la potencia acústica 82 dB(A) (desviación estándar: 3 dB), y la vibración a 14,3 m/s

2

(método brazo-mano; incertidumbre K = 1,5 m/s2).

Expediente técnico en: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

GB

F

D

NL

S

N

FIN

E

08 SKIL Europe BV A. v.d. Kloot

DK

94

08 SKIL Europe BV A. v.d. Kloot

ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ Мы с полной ответственностыо заявляем, что это изделие соответствует следующим
стандартам или станда ртизованным документам: EN 60 745, EN 55 014, в соответсувии с инструкциями 2006/95/EC,
2004/108/EC, 98/37/EC (до 28.12.2009), 2006/42/EC (начиная с 29.12.2009).
ШУМНОСТИ/ВИБРАЦИИ При измерении в соответствии co стандартoм EN 60 745 уровень звукового давления для этого
инструмента составляет 71 дБ (A) и уровeнь звуковой мощности - 82 дБ (A) (стандартное отклонение: 3 dB), и вибрации ­14,3 м/с

2

(по методу для рук; недостоверность K = 1,5 м/с2).

Техническая документация у: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

RU

CE ВІДПОВІДНІСТЬ Ми заявляємо, що відповідність даного продукту наступним стандартам і регулюючим документам
повністю нашою відповідальністю: EN 60 745, EN 55 014, відповідно до положень директив 2006/95/EG, 2004/108/EG,
98/37/EG до 28.12.2009 p.), 2006/42/EG (після 29.12.2009 p.).
ШУМ/ВІБРАЦІЯ Зміряний відповідно до EN 60 745 рівень тиску звуку даного інструменту 71 дБ(А) i потужність звуку
82 дБ(А) (стандартне відхилення: 3 дБ), i вібрація 14,3 м/с

2

(ручна методика; похибка K = 1,5 м/с2).

Технічні документи в: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

UA

CE ∆ΗΛΩΣΗ ΣYMBATOTΗΤΑΣ ∆ηλώνουµε υπευθύνως τι το προϊν αυτ είναι κατασκευασµένο σύµφωνα µε τους εξής
κανονισµούς ή κατασκευαστικές συστάσεις: EN 60 745, EN 55 014, κατά τις διατάξεις των κανονισµών της Κοινής Αγοράς
2006/95/EK, 2004/108/EK, 98/37/EK (έως 28.12.2009), 2006/42/EK (απ 29.12.2009).
ΘΟΡYΒΟ/ΚΡΑ∆ΑΣΜΟYΣ Μετρηµένη σύµφωνα µε EN 60 745 η στάθµη ακουστικής πίεσης αυτού του εργαλείου ανέρχεται
σε 71 dB(A) και η στάθµη ηχητικής ισχύoς σε 82 dB(A) (κοινή απκλιση: 3 dB), και ο κραδασµς σε 14,3 m/s

2

(µεθοδος

χειρς/βραχίονα - ανασφάλεια K = 1,5 m/s

2

).

Τεχνικς φάκελος απ: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

GR

OÂWIADCZENIE ZGODNOÂCI CE Niniejszym oÊwiadczamy ponoszàc osobistà odpowiedzialnoÊç, ˝e produkt wykonany jest
zgodnie z nast´pujàcymi normami i dokumentami normalizujàcymi: EN 60 745, EN 55 014, z godnie z wytycznymi 2006/95/EU,
2004/108/EU, 98/37/EU (do 28.12.2009), 2006/42/EU (od 29.12.2009).
HA¸ASU/WIBRACJE Pomiarów dokonano zgodnie z normà EN 60 745 ciÊnienie akustyczne narz´dzia wynosi 71 dB(A) zaÊ poziom
mocy akustycznej 82 dB(A) (poziom odchylenie: 3 dB), zaÊ wibracje 14,3 m/s

2

(metoda d∏oƒ-r´ka; b∏àd pomiaru K = 1,5 m/s2).

Dokumentacja techniczna: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

PL

CE DECLARAÇÃO DE CONFIRMIDADE Declaramos sob nossa exclusiva responsabilidade que este producto cumpre as

seguintes normas ou documentos normativos: EN 60 745, EN 55 014, conforme as disposições das directivas 2006/95/CE,
2004/108/CE, 98/37/CE (até 28.12.2009), 2006/42/CE (a partir de 29.12.2009).
RUÍDO/VIBRAÇÕES Medido segundo EN 60 745 o nível de pressão acústica desta ferramenta é 71 dB(A) e o nível de potência
acústica 82 dB(A) (espaço de erro: 3 dB), e a vibração 14,3 m/s

2

(método braço-mão; incerteza K = 1,5 m/s2).

Processo técnico em: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

P

CE DICHIARAZIONE DI CONFORMITÀ Dichiaramo, assumendo la piena responsabilità di tale dichiarazione, che il prodotto è

conforme alle seguenti normative e ai relativi documenti: EN 60 745, EN 55 014 in base alle prescrizioni delle direttive 2006/95/EG,
2004/108/EG, 98/37/EG (fino al 28.12.2009), 2006/42/EG (a partire dal 29.12.2009).
RUMOROSITÀ/VIBRAZIONE Misurato in conformità al EN 60 745 il livello di pressione acustica di questo utensile è 71 dB(A) ed il livello
di potenza acustica 82 dB(A) (deviazione standard: 3 dB), e la vibrazione 14,3 m/s

2

(metodo mano-braccio; incertezza K = 1,5 m/s2).

Fascicolo tecnico presso: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

I

CE MINÖSÉGI TANUSITVANY Teljes felelösségünk tudatában kijelentjük, hogy jelen termék a következö szabványoknak vagy
kötelezö hatósági elöírásoknak megfelel: EN 60 745, EN 55 014, a 2006/95/EK, 2004/108/EK, 98/37/EK (2009.12.28-ig), 2006/42/EK
(2009.12.29-tŒl kezdve) elöírásoknak megfelelöen.
ZAJ/REZGÉS Az EN 60 745 alapján végzett mérések szerint ezen készülék hangnyomás szintje 71 dB(A) a hangteljesítmény szintje
82 dB(A) (normál eltérés: 3 dB), a rezgésszám 14,3 m/s

2

(kézre-ható érték; szórás K = 1,5 m/s2).

A mıszaki dokumentáció a következŒ helyen található: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

H

CE STRVZUJÍCÍ PROHLÅ◊ENÍ Potvrzujeme na odpovπdnost, Ωe tento v¥robek odpovídå nåsledujícím normåm nebo normativním
podkladüm: EN 60 745, EN 55 014, podle ustanovení smπrnic 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES (od

29.12.2009).
HLUÇNOSTI/VIBRACÍ Mπ®eno podle EN 60 745 çiní tlak hlukové vlny tohoto p®ístroje 71 dB(A) a dávka hluçnosti 82 dB(A)
(standardní odchylka: 3 dB), a vibrací 14,3 m/s

2

(metoda ruka-paΩe; nepfiesnost K = 1,5 m/s2).

Technická dokumentace u: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CZ

CE STANDARDIZASYON BEYANI Ye¤ane sorumlu olarak, bu ürünün afla¤ıdaki standartlara veya standart belgelerine uygun
oldu¤unu beyan ederiz: EN 60 745, EN 55 014, yönetmeli¤i hükümleri uyarınca 2006/95/EG, 2004/108/EG, 98/37/EG (28.12.2009
tarihine kadar), 2006/42/EG (29.12.2009 tarihinden itibaren).
GÜRÜLTÜ//T‹TREfiIM Ölçülen EN 60 745 göre ses basıncı bu makinanın seviyesi 71 dB(A) ve çal›flma s›ras›ndaki gürültü 82 dB(A)
(standart sapma: 3 dB), ve titreflim 14,3 m/s

2

(el-kol metodu; tolerans K = 1,5 m/s2).

Teknik belgelerin bulundu¤u merkez: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

TR

95

08 SKIL Europe BV A. v.d. Kloot

DECLARAØIE DE CONFORMITATE CE Declaråm pe proprie råspundere cå acest product este conform cu urmåtoarele standarde
sau documente standardizate: EN 60 745, EN 55 014, în conformitate cu regulile 2006/95/CE, 2004/108/CE, 98/37/CE (pânå la

28.12.2009), 2006/42/CE (începând cu 29.12.2009).
ZGOMOT/VIBRAØII Måsurat în conformitate cu EN 60 745 nivelul de presiune a sunetului generat de acest instrument este de
71 dB(A) iar nivelul de putere a sunetului 82 dB(A) (abaterea standard: 3 dB), iar nivelul vibraøiilor 14,3 m/s

2

(metoda mînå - braø;

incertitudine K = 1,5 m/s

2

).

Documentaøie tehnicå la: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

RO

CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на изцяло наша отговорност, че това изделие е съобразено със
следните стандарти или стандартизирани документи: EN 60 745, EN 55 014, в съответствие с нормативната уредба на
2006/95/EG, 2004/108/EG, 98/37/EG (до 28.12.2009), 2006/42/EG (от 29.12.2009).
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 60 745 нивото на звуково налягане на този инструмент е 71 dB(A) а
нивото на звукова мощност е 82 dB(A) (стандартно отклонение: 3 dB), а вибрациите са 14,3 m/s

2

(метод ръка-рамо;

неопределеност K = 1,5 m/s

2

).

Подробни технически описания при: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

BG

CE IZJAVA O USKLA ĐENOSTI Izjavljujemo uz punu odgovornost da je ovaj proizvod usklađen sa slijedeçim normama i
normativnim dokumentima: EN 60 745, EN 55 014, prema odredbama smjernica 2006/95/EG, 2004/108/EG, 98/37/EG (do

28.12.2009), 2006/42/EG (od 29.12.2009).
BUCI/ VIBRACIJAMA Mjereno prema EN 60 745, prag zvuãnog tlaka ovog elektriãnog alata iznosi 71 dB(A) a jakost zvuka
82 dB(A) (standardna devijacija: 3 dB), a vibracija 14,3 m/s

2

(postupkom na ‰aci-ruci; nesigurnost K = 1,5 m/s2).

Tehniãka dokumentacija se moÏe dobiti kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

HR

CE IZJAVA O USKLA ĐENOSTI Pod punom odgovorno‰çu izjavljujemo da je ovaj proizvod usklađen sa sledeçim standardima ili
standardizovanim dokumentima: EN 60 745, EN 55 014, u skladu sa odredbama smernica 2006/95/EG, 2004/108/EG, 98/37/EG (do

28.12.2009), 2006/42/EG (od 29.12.2009).
BUKA/VIBRACIJE Mereno u skladu sa EN 60 745, nivo pritiska zvuka ovog alata iznosi 71 dB(A), a jaãina zvuka 82 dB(A) (normalno
odstupanje: 3 dB), a vibracija 14,3 m/s

2

(mereno metodom na ‰aci-ruci; nesigurnost K = 1,5 m/s2).

Tehniãka dokumentacija kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

SRB

IZJAVA O USTREZNOSTI CE Odgovorno izjavljamo, da je ta izdelek v skladu z naslednjimi standardi ali standardnimi dokumenti:
EN 60 745, EN 55 014, v skladu s predpisi navodil 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES (od 29.12.2009).
HRUP/VIBRACIJA Izmerjeno v skladu s predpisom EN 60 745 je raven zvoãnega pritiska za to orodje 71 dB(A) in jakosti zvoka
82 dB(A) (standarden odmik: 3 dB), in vibracija 14,3 m/s

2

(metoda ‘dlan-roka’; netoãnost K = 1,5 m/s2).

Tehniãna dokumentacija se nahaja pri: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

SLO

CE VASTAVUSDEKLARATSIOON Kinnitame ainuvastutajana, et see toode vastab järgmistele standarditele või
normdokumentidele: EN 60 745, EN 55 014 vastavalt direktiivide 2006/95/EÜ, 2004/108/EÜ, 98/37/EÜ (kuni 28.12.2009),
2006/42/EÜ (alates 29.12.2009) nõuetele.
MÜRA/VIBRATSIOON Vastavalt kooskõlas normiga EN 60 745 läbi viidud mõõtmistele on antud seadme helirõhk 71 dB(A) ja
helitugevus 82 dB(A) (standardkõrvalekalle: 3 dB), ja vibratsioon 14,3 m/s

2

(käe-randme-meetod; mõõtemääramatus K = 1,5 m/s2).

Tehniline toimik saadaval aadressil: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

EST

CE DEKLARÅCIJA PAR ATBILST±BU STANDARTIEM Mïs ar pilnu atbild¥bu pazi¿ojam, ka ‰is izstrÇdÇjums atbilst standartiem vai
standartizÇcijas dokumentiem EN 60 745, EN 55 014 un ir saska¿Ç ar direkt¥vÇm 2006/95/ES, 2004/108/ES, 98/37/ES (l¥dz

28.12.2009) un 2006/42/ES (no 29.12.2009).
TROKSNIS/VIBRÅCIJA Saska¿Ç ar standartu EN 60 745 noteiktais instrumenta rad¥tÇ trok‰¿a ska¿as spiediena l¥menis ir 71 dB(A)
un ska¿as jaudas l¥menis ir 82 dB (A) (pie tipiskÇs izkliedes: 3 dB), un vibrÇcijas intensitÇte ir 14,3 m/s

2

(strÇdÇjot rokas reÏ¥mÇ;

izkliede K = 1,5 m/s

2

).

TehniskÇ lieta no: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

LV

CE ATITIKTIES DEKLARACIJA Mes atsakingai parei‰kiame, kad ‰is gaminys atitinka tokius standartus ir normatyvinius
dokumentus: EN 60 745, EN 55 014 pagal reglament˜ 2006/95/EB, 2004/108/EB, 98/37/EB (iki 2009-12-28), 2006/42/EB
(nuo 2009-12-29) nuostatas.
TRIUK·MINGUMAS/VIBRACIJA ·io prietaiso triuk‰mingumas buvo i‰matuotas pagal EN 60 745 reikalavimus keliamo triuk‰mo
garso slògio lygis siekia 71 dB(A) ir akustinio galingumo lygis 82 dB(A) (standartinis nuokrypis: 3 dB), ir vibracijos pagreitis rankos
pla‰takos srityje tipiniu atveju yra maÏesnis, kaip 14,3 m/s

2

(paklaida K = 1,5 m/s2).

Techninò byla laikoma: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

LT

CE PREHLÁSENIE O ZHODE Vÿhradne na na√u vlastnú zodpovednos† prehlasujeme, Ωe tento vÿrobok zodpovedá nasledujúcim
normám alebo normovanÿm dokumentom: EN 60 745, EN 55 014, v súlade s predpismi 2006/95/EG, 2004/108/EG, 98/37/EG (do

28.12.2009), 2006/42/EG (od 29.12.2009).
HLUKU/VIBRÁCIÁCH Merané pod¬a EN 60 745 je úroveµ akustického tlaku tohto nástroja 71 dB(A) a úroveµ akustického vÿkonu je
82 dB(A) (√tandardná odch¥lka: 3 dB), a vibrácie sú 14,3 m/s

2

(metóda ruka - paΩa; nepresnosÈ K = 1,5 m/s2).

Súbor technickej dokumentácie sa nachádzajú na adrese: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

SK

2610393848

10x

2610393849

10x

2610393850

10x

2610393759

5x 5x 5x

2610390730

2x 2x 2x

2610393324

8x 8x 8x

2610393325

5x 5x 5x

2610393756 3x 2610393757 3x 2610393376

2610393758 3x 2610393377 3x 2610393378

2610393755 3x 2610393379 3x 2610393380

2610393847

ACCESSORIES

SKIL Nr.

SKIL Nr.SKIL Nr.SKIL Nr.
