Si-tex GPS-95CPi User Manual

- 1 -
TABLE OF CONTENTS
Important Notice
GPS-95CP(i) Color LCD Charting System
Welcome ……………………………………………………… 11 Introduction ……………………………………………………… 12 Display Unite ……………………………………………………… 14 Interconnecting diagram …………………………………… 15 The Keyboard ……………………………………………………… 16
Display Modes
Display Modes ……………………………………………………… 17
1. Full Chart Display …………………………………………… 18
2. Plotter Display …………………………………………… 20
3. Lat/Lon Display …………………………………………… 21
4. Highway Display …………………………………………… 22
5. Steering Display …………………………………………… 23
6. Nav data Display …………………………………………… 24
Operations
Edit ……………………………………………………………… 25
MOB ……………………………………………………………… 27
Mark ……………………………………………………………… 28
1. Creating Mark
2. Changing Mark symbol
3. Changing Mark color
4. Deleting Mark
5. Editing Mark.
WPT(Waypoint) …………………………………………………… 29
1. Creating destination point
2. Creating WPT.
3. Selecting WPT.
4. Editing WPT.
- 2 -
Route ……………………………………………………………… 30
1. Instant Route
2. Creating Route
3. Selecting Route
4. Deleting Route
5. Reversing Route
6. Setting Point
7. Edit the existing route
8. Editing Route
Track ……………………………………………………………… 31
1. Track On/Off
2. Changing Track Color
3. Deleting Track
4. Change Track page
5. Loading Track
User Data ………………………………………………………… 31
Display On/Off ……………………………………………………… 32
Map Orientation …………………………………………………… 32
1. True motion
2. North up
3. Course up
4. Head up
GPS Setup 1/2 ……………………………………………………… 33
1. Datum
2. Satellite Information
3. Latitude Modification
4. Longitude Modification
5. Smoothing set
6. Average COG.
7. Average SOG.
8. Lat/Lon Unit
9. GPS Receiving Port
0. Coordinate System
- 3 -
Setup 1/2 ……………………………………………………… 34
1. Distance/Speed unit
2. Present Position Size
3. Track Size
4. Track Display Interval
5. Time Interval
6. Distance Interval
7. Heading Line Length
8. True/Magnetic
9. Compass Modification
0. TD Setup
Setup 2/2 ……………………………………………………… 35
1. Displaying Time Setup
2. Data Output
3. Land Color Select
4. Chart Change
5. Reset
6. WPT Name Font Size
7. SOG Setup
8. Save Track
9. Load Track
0. Depth unit
Maintenance ……………………………………………………… 37
1. System Information
2. Chart Information
3. Keyboard Test
4. GPS Simulator
5. Language
Alarms ………………………………………………………………… 38
1. Arrival Alarm
2. Arrival Radius
3. XTE Alarm
4. XTE Radius
5. Anchor Alarm
6. Anchor Radius
- 4 -
7. Interval Alarm
8. Interval Time
9. Course Alarm
0. Course Alarm Range
User Data Edit ……………………………………………………… 39
1. Track On/Off
2. Track Color
3. Track Deletion
4. Mark Symbol
5. Mark Color
6. Skip Routes
7. Route Forward/Reverse
AIS System ……………………………………………………… 40
Plotter Menu ……………………………………………………… 42
1. Track
2. Navigating
3. Mark
4. Object Information
Cursor Menu ……………………………………………………… 42
1. WPT
2. Mark
3. Range/Bearing
4. Object Information
Find …………………………………………………………………43
1. Port Services
2. Port by names
3. Port by distance
4. Tide stations
5. Wrecks
6. Obstructions
Installation ………………………………………………………………… 45
Display Unit Location
- 5 -
Display Unit Installation
Power Connection
Reference ………………………………………………………………… 47 Care and Cleaning NMEA GPS ………………………………………………………………………… 48 How GPS works Position Fixing Accuracy: HDOP The Installation of The GPS ANT.
- 6 -
- 7 -
Important Notice
Manual Handling
Keep this manual in a safe place where you can access it quickly. This Manual must be passed to a new owner of the GPS-95CP(i) when it is transferred.
The Global Positioning System (GPS) consists of a total 24 GPS satellites that orbit the earth, enabling you to determine your position anywhere in the world, 24 hours a day, if you can receive satellite signals. During actual navigation, carefully compare the position data with all available navigation sources such as Loran C, Decca, other navigators, charts, visual navigation, depth, water temperature and others. It is your responsibility to make navigation judgments.
DGPS Operation Note:
Your position can be improved by DGPS correction. However, when you are communicating with other ships, you may use a DGPS corrected position but they may not. Make your position source known during communication.
The Electronic Chart:
Only official authorized charts and notices to mariners contain all the information needed for the safety of navigation and, as always remember, the user is responsible for their prudent use.
- 8 -
Pictorials
This manual uses the following symbols for easy understanding safety instructions. Always follow these instructions carefully.
WARNING
Always follow this safety instruction to prevent death or injury.
CAUTION
Follow this safety instruction to avoid possible injury or damage to your property. This symbol is a CAUTION or WARNING label indicating the safety instruction.
WARNING
This symbol is an Electrical Shock WARNING label.
This symbol is an instruction that you must not violate. (This symbol instructs NOT to disassemble the system components)
This symbol is an operation instruction that you must follow. (This symbol shows the main power OFF instruction.)
WARNING <For System Operators> Always follow this instruction to prevent death or personal injury.
Turn power off During abnormality.
If smoke or a smell of burning occurs, a fire or an electrical short circuit may result. Turn the power switch OFF and shut down the power supply immediately. Never try to repair the system yourself. Call for service.
Do not open
Case.
High voltage exists in the instrument. Contact with voltage may cause possible injury or death.
Do not touch
back side of the equipment.
Harmful line voltage is present on back side of the equipment. Never try to touch back side while power is turned on.
Avoid
excessive shock to display unit.
The LCD display module contains a liquid. Do not apply any mechanical shock to the display. If the display broken, liquid may leak and injure your skin and eyes.
Do not use with poor ventilation.
If you cover this unit or use in an enclosed place, it may malfunction or become damaged as a result of overheating. Use only where there is sufficient ventilation.
- 9 -
Installation Cautions <For service Personnel>
Follow installation instructions to avoid personal injury and system malfunction.
Installation in rigid location.
Mount your GPS-95CP(i) on a rigid frame or base to prevent your unit from working loose.
Use correct Installation materials.
Use the installation materials provided in the standard accessory pack only. If you use hardware of insufficient strength, your system may loosen causing damage.
Keep away from direct sunlight.
Keep your system out of direct sunlight as it may become damaged by overheating.
Keep away from water.
Take care not to get water on or in your unit as it may be damaged and/or cause an electrical shock.
Keep away from heat source.
Keep your system away from other heat source as it may malfunction, be damaged, or burn.
Use correct power source.
Operate your system within the specified power voltage. An incorrect power supply may cause damage.
Maintenance Cautions<For Maintenance Personnel>
Use the following safety precaution internal inspection.
Discharge capacitors.
High voltage may be retained in the capacitors in the high-tension circuit several minutes after you have turned the power switch off.
Check that power is OFF
To prevent an electrical injury due to erroneous power switching, make sure that the main power supply and the system power switch are both in the off position. Additionally, attach a safety label showing that service is in progress.
Avoid EMI.
Take care not to damage the ESDs (Electrostatic Sensitive Devices) by static electricity from carpet and cloths.
Avoid dust.
Wear a safety mask so as not to breath in dust during inspection or cleaning inside your system instruments.
- 10 -
Operation Notes <For operators>
Observe the following operation notes, otherwise the system failure or deterioration can result. And periodical inspection and maintenance are required for keeping the system in an optimum condition.
Backup important data.
The waypoint and other registered data may become unreadable by unexpected failure. We recommend recording this data separately on optional user or SD-picture card.
WARNING
This product is designed to assist a navigation. When you are sailing, use the certified chart from the Government or IMO.
- 11 -
GPS-95CP(i) Color LCD Charting System
Welcome
The GPS-95CP(i) Color LCD Charting System opens a new chapter of performance and integration in vessel navigation system display and management. Whether you are a Cruiser or Sport fisherman or both, GPS-95CP gives you the information you need.
CAUTION
The GPS-95CP(i) is a Color LCD Charting Systems that employs the latest in proven technology to provide accurate navigation information. The Plotter functions of the GPS-95CP are totally dependent upon the capability of the navigation source to provide accurate position information. This device is only an aid to navigation. It should be used in conjunction with all other navigation accuracy. For safety, always resolve any uncertainty before continuing navigation.
CAUTION
Electronic charts are derived from geographical data – including official government charts – which we believe to be accurate. They are neither verified nor approved by Hydrographic Authorities. Electronic charts in GPS-95CP(i) are designed only to ease and speed navigation calculations and so must not be relied upon as a primary source of navigation information, but rather a backup to the use of official government charts and prudent navigation habits. There is no direct relationship between the color of water areas and their depth. The navigator shall always query the area for depth information and use the official paper chart.
CAUTION
The performance of LCD displays are degraded by continuous direct exposure to ultraviolet rays. Locate your GPS-95CP(i) Display away from direct sunlight. When not in use, keep the display covered.
DISPLAY BREAKAGE WARNING
The LCD display module contains a liquid. If the display is broken and the liquid contacts your skin, wash it off immediately in running water for 15 minutes. If the liquid contacts your eyes, immediately flush your eyes with running water for 15 minutes. Contact a physician if any abnormal symptom is experienced.
- 12 -
GPS-95CP(i) Color LCD Charting System
Introduction
The GPS-95CP(i) Color LCD Charting System is a premium multifunction command and control center. It combines in one unit, display of worldwide cartography, and GPS navigation. GPS­95CP(i) front panel keyboard and its large screen with wide viewing area make placement easy. Although GPS-95CP(i) offers many advanced features, operation is simplified through the use of popup menus similar to those found on personal computers. Also, the front panel keyboard has specific keys for direct access to the most used functions and settings.
Equipment Supplied
GPS-95CP(i) Display
unit
GPS ANT.
(except 95CPi)
Manual
Protector Mounting Bracket Knobs
Power cable
- 13 -
GPS-95CP(i) Color LCD Charting System
GETTING STARTED
This getting Started section will help you become acquainted with the displays and the front
panel keyboard functions of your GPS-95CP Color LCD Charting System. This section is
intended to demonstrate the main functions and basic operation of your GPS-95CP System.
More detailed procedures may be found in the Operation section.
GPS-95CP(i) has built-in simulators that present realistic displays of cartography and GPS.
Note: Simulators are interactive so the front panel keyboard can be used to browse through
menus and change setting in the same manner as actual operation. The internal simulators allow
GPS-95CP(i) to operate without having antennas or remote sensors connected. However, it is
necessary to connect the power cable to 12 to 36 Vdc power source. Please refer to
Power
Connection
in the installation section.
If GPS-95CP is already installed on your vessel, simulators are still useful for
familiarity with displays and practice with operating procedures.
- 14 -
GPS-95CP(i) Color LCD Charting System
Display Unit
The heart of the GPS-95CP(i) Color LCD Charting System is the display unit. Within the display unit are the powerful central processor and integrated display system, built-in cartography. The bright 4.3 inch active matrix color LCD, is easily viewed over a wide area on the bridge or nav center.
Keyboard
Knobs
Mounting Bracket
- 15 -
GPS-95CP(i) Color LCD Charting System
Interconnecting diagram
MINI JACK Connect to PC (by Serial Port)
SD Card Slot
USB
Connect to PC
(by USB)
C-MAP Slot
GPS Antenna
(Except 95CPi)
Power (12V ~ 36V) Data In/Out (RX/TX)
Speaker
- 16 -
The
Keyboard
[ZOOM-IN] Change the chart of scale bigger in plotter [ZOOM-OUT] Change the chart of scale smaller in plotter [MENU] Menu opens menu to select options [GOTO]
[MAIN SCREEN]
Selects function to display on Full Chart Display, Plotter Display, LAT/LOT Display, Highway Display, Steering Display, Nav data Display. (* When the menu or the cursor appears, it’s used for ESC.
[ENTER] Completes pending selection or operation
[MARK/MOB]
Mark: Places a mark on the plotter main screen. MOB: Is a special navigation function that immediately stores your present position as a waypoint and activates navigation to the stored coordinates.
[BRT/PWR]
BRT: Brightness adjust the brightness in day mode or night. PWR: Turns On/Off
[CURSOR PAD]
Cursor On and use to move the cursor, select menu items, scroll lists, select options, change settings in plotter (*To make the cursor deleted, press [MAIN SCREEN].
How to use [BRT/PWR]
Use PWR: To turn off the power, keep pressing the [BRT/PWR] until the end of count down.
Use BRT: Press [BRT/PWR] quickly and the brightness can be controlled. Use the arrow keys of the cursor to control the brightness and the contrast.
Cursor pad
Zoom in & Zoom out
Select display mode & cancel
- 17 -
Display Modes
Your unit has six-display modes. Press the [MAIN SCREEN] key to choose a display mode. Each time the key is pressed, the display mode changes in the sequence shown below.
[
Full Chart Displa
y]
[
Plotter Displa
y]
[
Lat/Lot Displa
y]
[
Nav Data Display]
[Highway Display] [Steering Display]
- 18 -
Display Modes
1. Full Chart Display
This mode provides GPS information and the chart.
i) GPS Information
[GPS Information]
Present Position
Scale
Present position in latitude and longitude
Course over Ground T: True M: Magnetic
Date
Track Information
Satellites Information
Receiver status
Mark Information
Scale
Speed over Ground
Loading...
