Sitecom WLX-2002 User Manual [nl]

WLX-2002

Introduction

Thank you for purchasing the Sitecom WLX-2002 Wi-Fi Access Point N300. It complies
with wireless 802.11b/g/n standards and can create a Wi-Fi network with data
transmission rates of up to 300Mbps. With the WLX-2002, you can enjoy high-speed
wireless networking throughout your home without additional cabling. The WLX-2000
features a WPS button which allows you to connect to the access point with a simple click
of a button.

Not only is the WLX-2002 very compact, it is designed with a built-in power adapter. This
design allows you to plug it directly into an electrical outlet, eliminating the need for an
additional power cable. You can easily install it where your Wi-Fi signal needs
enhancement and enjoy high-speed wireless performance without any hassles.

The latest 802.11n technology is built into the WLX-2000 to broaden its wireless
coverage and to eliminate dead spots within the wireless range. The WLX-2000 complies
with wireless 802.11b/g/n standards and can reach data transmission rates of up to
300Mbps when connected to wireless 802.11n devices. It provides faster and more
reliable wireless connections than standard 802.11b/g wireless networks.

This product can be used safely in the countries listed below:

This product complies with the following European Union regulations:

Table of Contents

1 KEY FEATURES ........................................................................................ 6

2 PACKAGE CONTENTS ............................................................................... 7

3 CAUTIONS .............................................................................................. 8

4 PRODUCT LAYOUT ................................................................................... 9

5 NETWORK + SYSTEM REQUIREMENTS ..................................................... 11

6 WLX-2002 PLACEMENT ........................................................................... 11

8 BRINGING UP THE WLX-2002 .................................................................. 12

9 INITIAL SETUP WLX-2002 ....................................................................... 13

11 BASIC SETTINGS ................................................................................. 15

12 ADVANCED SETTINGS .......................................................................... 16

13 TOOLBOX SETTINGS ............................................................................ 22

Features

Advantages

Incredible Data Rate up to
300Mbps*

Heavy data payloads such as MPEG
video streaming

IEEE 802.11n Compliant and
backwards compatible with

802.11b/g

Fully Interoperable with IEEE

802.11b / IEEE802.11g compliant
devices with legacy protection

Support 802.1x authenticator,

802.11i (WPA/WPA2, AES)

Provide mutual authentication (Client
and dynamic encryption keys to
enhance security

Easy to use web-based GUI

Graphical User Interface for network
configuration and management
purposes.

WPS Button

Easily connect your clients with just
the push of a button.

1 KEY FEATURES

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g, n chipset used.
Actual throughput may vary. Network conditions and environmental factors lower actual
throughput rate. All specifications are subject to change without notice.

2 PACKAGE CONTENTS

Open the package carefully, and make sure that none of the items listed below are
missing. Do not discard the packing materials, in case of return; the unit must be
shipped back in its original package.

1. The WLX-2002 Wall Mount Access Point N300

2. A Quick Install Guide

3. A CD (User’s Manual)

4. A Warranty card

5. An UTP cable

3 CAUTIONS

This device’s design and manufacturer has your safety in mind. In order to safely and
effectively use this device, please read the following before usage.

3.1 Usage Cautions

The user should not modify this device. The environmental temperature should be within +5
~ +35 degrees Celsius.

3.2 Power

The device’s power voltage is AC 230v. When plugging in the device, make sure it cannot get
damaged or be subject to pressure. To reduce the risk of electric shock, unplug the device
first before cleaning it. Never connect the device to the power in a humid or dusty area.

3.3 Repair

If the device has a problem, you should take it to an appointed repair center and let the
specialists do the repair. Never repair the device yourself, you might damage the device or
endanger yourself.

3.4 Disposing of the device

When you dispose of the device, be sure to dispose of it appropriately. Some countries may
regulate disposal of an electrical device, please consult with your local authority.

3.5 Others

When using this device, please do not let it come into contact with water or other liquids. If
water is accidentally spilled on the device, please use a dry cloth to absorb the spillage.
Electronic products are vulnerable, when using please avoid shaking or hitting the device, and
do not press the buttons too hard.

Do not let the device come into contact with water or other liquid.
Do not disassemble, repair or change the design of the device, any damage done will

not be included in the repair policy.

Avoid hitting the device with a hard object, avoid shaking the device and stay away

from magnetic fields.

If during electrostatic discharge or a strong electromagnetic field the device will

malfunction, unplug the power cable. The product will return to normal performance
the next time it is powered on.

Description

Network Port

You can use this port to connect to a wired modem or

router to add wireless functionality.

OPS Button

You can use this button to connect using OPS.

OPS Button functions:

Press 0-5 seconds: WPS registrar

Press 15+ seconds: reset to factory defaults.

4 PRODUCT LAYOUT
