Sitecom WL-405 DATASHEET

P. 1-1.

Internet

Watch your home

Watch your office or warehouse

RoHS

compliant

Designed in Europe

Data sheet:
WL-405

Product code :
Product name :
EAN code :

WL-405

Wireless Internet Security Camera

8716502022564

The Wireless Internet Security Camera 150N is ideal for wireless
monitoring of various spaces at home (baby’s bedroom or your
living room) or the o ce (reception area or warehouse). By
connecting the camera to your wireless network, you can
access the live images recorded by the camera from any
desktop PC or notebook using the Internet or Intranet. All you
need is a web browser and an IP address. With the camera you
can keep an eye on your home or o ce at any time from any
location. Because of the extensive wireless range, the camera
does not need to be placed near the router, thereby oering
optimum exibility.

Internet Camera

Watch your home or oce
from anywhere

in the world

Motion detection

Automatic recording and
notication via email

Excellent wireless performance

150 Mbps speed
and reliable range

Box content:

• Wireless Internet Security Camera 150N

• Power Adapter, User manual

• CD incl. camera software, Mounting stand

Easiest setup and security

Create a safe wireless
connection in
just one click

System requirement:

• Compatible with all operating systems

• CD-rom drive

FOR USE IN

P. 1-2.

Technical specifications:
WL-405

• Network Protocols: TCP/IP, DHCP, SMTP, NTP, HTTP, FTP, NTP, RTP, RTSP, UPnP (Discovery only)

• Network Interface: 1 Ethernet 10/100 BaseT (RJ45)

wired LAN connection, 1T1R wireless LAN, based on 802.11n technology

• LED’s: 2

• Power Adapter: 5V DC External

• Lens: F2.8mm @F2.8 Fixed Focus lens (cell phone size) in socket type

• Supported resolutions: 640x480 (VGA); 320x240 (QVGA); 160x120 (QQVGA)

• Video streaming: MPEG4; MJPEG

• Dual mode: MPEG4; MJPEG

• Also supports RTP/RTSP streaming and Mobile streaming
