Sirius Satellite Radio SIR-ALP1 User Manual

Sirius™ Connect USB interface board

Installation Instructions

This is for the SIR-ALP1

Disclaimers:

• Modifying the radio may void any outstanding warranty it may have.

• This product is not affiliated with Sirius Satellite Radio in any way.

• There are no warranties expressed or implied by purchase of this product.

• All boards are tested and verified 100% before shipping.

• While every care has been taken to provide a quality product, I cannot guarantee the board to

function correctly if installation is not done according to the instructions in this guide.

• I am not liable for misuse of this product. Misuse includes improper installation, damage to the

board or radio while trying to install, and illegal use of the modified radio.

Tools needed:

1. Small Philips screwdriver (p1).

2. Elbow grease.

3. A double sided mirror.

Screws already removed to save me some time.

Using the small Philips screwdriver, remove the 7 screws in the SILVER case.

(3 on each side, 1 on top)

Page 1 of 13

Created On Tuesday, March 14, 2006

Sirius™ Connect USB interface board

Installation Instructions

Separate the two sections (neat engineering huh?)

Page 2 of 13

Created On Tuesday, March 14, 2006

Sirius™ Connect USB interface board

Installation Instructions

Remove the top, and remove the pc board inside

There are 4 screws that need to removed be removed.

Install the new board. Secure with same screws.

(Look, I even put some in.)

Page 3 of 13

Created On Tuesday, March 14, 2006

Sirius™ Connect USB interface board

Installation Instructions

Begin assembling the radio…
