Specifications and Main Features
- Model Numbers: 11W6 и 11W7
- Type: Drop Feed Sewing Machine 1
- Drive: Hand Drive Attachment (model 11W6) and Motor Drive (model 11W7)
- Included Accessories: Bobbin Winder, Needle, Drip Pan, Oiler, Screw Driver and Wrench - Stitching Capability: Suitable for stitching or joining tape belts on spinning and twisting frames
- Construction: Built for durability with multiple, replaceable parts
- Parts Compatibility: Parts from models 11W6 and 11W7 are interchangeable/incompatible for certain components
- Drop Feed Mechanism: Allows for Layering of the fabric which causes the sewing process to be more simple
- Large Balance Wheel: 53 inches in diameter with a 24 inch belt groove, generous proportions facilitate operation ease
- Attachments: Includes adjustable belt guide attachments and knee lifters which enhance control during operation
- Dimensions: Manual doesn't specify its dimensions
Weight: Manual doesn’t specify it either
Frequently Asked Questions
- Q: The Model 11W6 and 11W7, what type of sewing do they do?
A: They are built to work in spinning and twisting frames making use of tape belts that are stitched or joined.
- Q: Does it come with the accessories integrated in this machine?
A: Yes, it comes with a bobbin winder, screws, and needles, these are present in both models.
- Q: Are the components of 11W6 model cross-compatible with the parts of 11W7 model?
A: Yes, components of both the models are interchangeable in practice with some restrictions.
- Q: What is the specification in terms of the driving technique employed for each model?
A: A hand driving attachment is designed for use in the Model 11W6, whereas a motor drive is incorporated in the Model 11W7.
- Q: Are there any options for further attachments or modification?
A: Yes, there are options for adjustable belt guides as well as knee lifters for improved control when sewing.
- Q: How are the stitches fed in these models?
A: In both machines a drop feed mechanism is used to allow smooth feeding of the fabric during sewing.
