IMPORTANT SAFETY INSTRUCTIONS
Read All Instructions Carefully Before Using This Appliance
When using an electrical appliance, basic precautions should always be followed, including the
following :
WARNING -
11. Do not leave appliance when plugged in. Unplug from outlet when not in use and before
servicing.
12. Do not use outdoors or on wet surfaces.
13. Do not allow to be used as a toy. Close attention is necessary when used near children.
14. Use only as described in this manual. Use only manufacturer's recommended attachments.
15. Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, return it to a service center.
16. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around
sharp edges or corners. Do not run appliance over cord.
Keep cord away from heated surfaces.
17. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
18. Do not handle plug or appliance with wet hands.
19. Do not put any object into openings. Do not use with any opening blocked:
keep free of dust, lint, hair, and anything that may reduce air flow.
10. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
11. Turn off all controls before unplugging.
12. Use extra care when cleaning on stairs.
13. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where
they may be present.
14. This appliance is intended for household use only and not for commercial or industrial use.
15. Do not operate the vacuum if :
- the power cord is damaged.
- the hose shows visible signs of damage.
16. Do not use without vacuum bag and/or filters in place.
17. Hold plug when rewinding the cord into cord reel. Do not allow plug to whip when rewinding.
18. The hose contains electrical wires. Do not use if damaged, cut or punctured.
Avoid picking up sharp objects.
19. To reduce the risk of electric shock, this appliance has a polarized plug.
20. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
21. Always turn off this appliance before connecting or disconnecting motorized nozzle.
22. Use only with motorized nozzle model SPB-224.
To reduce the risk of fire, electric shock, or injury :
CONTENTS
CANISTER FEATURES
HOW TO USE POWER NOZZLE
HOW TO USE CLEANING TOOLS
HOW TO REPLACE VACUUM BAG
HOW TO REPLACE FILTERS
SAFETY PRECAUTIONS
..................................................
...................................
............................................
...................................................
4 ~ 5
6 ~ 9
....................................
..................................
10
10
11
12
SAVE THESE INSTRUCTIONS
2
TROUBLESHOOTING GUIDE
...........................................
3
13
CANISTER FEATURES
CHECK
BAG
SERVICE
FILTER
POWER
BRUSH
MAX
HIGH
MED
LOW
OFF
S
U
C
T
I
O
N
POWER
BRUSH
ON
OFF
POWER CONTROL HANDLE HOSE ADAPTER
When lit, change
vacuum bag or
check for clog in
hose
When lit, change
HEPA filter
(page 11)
Light indicates
when power
nozzle is in use.
Power Levels:
MAX 100%
HIGH 75%
MED 50%
LOW 25%
OFF 0%
Increase power
Adapter
button
Flexible hose
• When separating the hose from the body, press
the adapter buttons to release the hose.
One touch
integrated wand
MAIN ON / OFF BUTTON
Decrease power
Power nozzle
On / Off
HARDWOOD FLOOR BRUSH
• For use on tile, hard wood, or linoleum floor.
On / Off Button
On-board
cleaning tools
• 3n1 multi-purpose tool
Insert end of wand into either end of
tool for multiple cleaning functions.
Canister body
Floor brush
Power nozzle
➪Please, refer to pages 6~9.
<How to Use Power Nozzle>
FLOOR BRUSH STORAGE
Parking slot
• Insert the wand holder into the parking slot on bottom or backside of unit.
• ON - Canister power is on and power nozzle is off.
• OFF - All power is off.
CORD REWIND
54
HOW TO USE POWER NOZZLE
OPERATION OPERATION
1. Turning on the Power Nozzle
The power nozzle can only be turned on if the
canister is also turned on (canister on / off
switch is located on the main body). The
power nozzle on / off switch is located on the
handle. Simply press the power nozzle on / off
switch to engage the power nozzle.
To achieve best cleaning results, slowly pass
the power nozzle back and forth over the
carpet or floor.
2. Using the Power Nozzle
After turning on the canister and power nozzle,
release the wand by pressing the left pedal on the
back side of the power nozzle (see diagram 3)
Diagram 3
Diagram 4
3. Remove / Insert the Wand From The Power
Nozzle
Removing the wand from the power nozzle
allows you, for example, to use cleaning tools
for baseboard or ceiling cleaning. To do this,
first turn the power nozzle and canister off.
Then, press the wand release collar (see
diagram 5) and pull the wand out. To reinsert
the wand into the power nozzle, simply press
the wand back into the neck of the power
nozzle. The wand will then "click" back into
place.
Diagram 5
4. Carpet Height Adjustment
Your power nozzle has six different settings to
clean a variety of carpet types and floor
surfaces. To adjust the carpet height setting of
the power nozzle, press the right pedal located
on the back of the power nozzle (see diagram
6). Each press of this pedal will adjust the
height to the next carpet height position.
To determine which setting you are currently
on, locate and look through the height indicator
window on the top of the unit (see diagram 7).
You will see one of the six settings as
mentioned earlier and detailed below:
Setting: Intended Use:
1. XHI Very plush carpet
2. HI Plush carpet
3. Auto General carpet thickness or bare
floors
4. MED Medium pile carpet
5. LO Low pile carpet
6. XLO Indoor/outdoor carpet
Diagram 6 Diagram 7
Carpet Height Notes: When using the power
nozzle, start on the "auto" setting. If pushing the
power nozzle forward feels sluggish or hard to
push, then adjust to a higher setting (i.e. HI or
XHI). If the power nozzle feels very easy to push,
you may want to lower the power nozzle for more
effective cleaning. The "Auto" setting is the
recommended setting for hard floor surfaces (i.e.
tile, vinyl, wood).
5. Warning Light
Your power nozzle comes equipped with a
circuit breaker safety system that protects it
from a jammed power nozzle situation.
Common items that cause jammed brushrolls
include socks, excessive threads, corners of
area rugs, etc. The warning indicator light on
top of the unit (see diagram 8) will change from
green to red should this condition occur.
Warning Light
Diagram 8
Circuit Breaker Switch
Diagram 9
MAINTENANCE AND CARE
1. Removing the Brushroll
IMPORTANT: Before performing any
maintenance work on the power nozzle,
always unplug the vacuum cleaner and
disconnect the wand.
Your brushroll may need to be removed at
times, for example, to cut threads that have
become tangled around the brushroll or to
replace the belt (see "Replacing the Belt").
To remove the brushroll, turn the unit over and
lift off the metal bottom plate by first
unscrewing the two bottom plate screws
located by the rear wheels (see diagram 10).
Pull out the belt cover guard (see diagram 11)
and pull the brushroll out.
If the circuit breaker trips:
a. Turn off the vacuum cleaner and power nozzle
then unplug the power cord.
b. Remove the object preventing the brushroll
from turning.
Locate the circuit breaker switch on the back of
c.
the power nozzle and press it to reset the breaker
(see diagram 9).
d.
When the unit is turned back on, the warning light
should be green and ready to go. If the breaker trips
again, repeat steps a-c again to correct the problem.
If this does not correct the problem, contact
your authorized vacuum cleaner retailer for
further assistance.
To reinstall the brushroll, reinsert the brushroll
back into the unit (make sure the belt is
attached properly). Next, insert the belt cover
guard. Then, place the metal bottom plate
back onto the unit (insert the front end of the
bottom plate first). Re-insert the two bottom
plate screws and secure.
Bottom
Plate Screws
Diagram 10 Diagram 11
76
MAINTENANCE AND CARE
DIAGRAM 1 REAR VIEW OF POWER WAND AND NOZZLE ASSEMBLY
2. Replacing the Power Nozzle Belt
IMPORTANT: Before performing any
maintenance work on the power nozzle,
always unplug the vacuum cleaner and
disconnect the wand.
To replace the power nozzle belt, you must
first remove the brushroll (see "Removing the
Brushroll"). Locate and discard broken belt.
To install new belt, locate the power nozzle
motor pulley and loop the belt around it (see
diagram 12). Place the other end of the belt
around the brushroll making sure the belt is
seated in the "belt groove" of the brushroll (see
diagram 13). Insert the brushroll back into the
brushroll tray and place the belt guard back
into position (see diagram 11). Place the
metal bottom plate back onto the unit (insert
the front end of the bottom plate first). Reinsert the two bottom plate screws and secure.
Belt
Diagram 12 Diagram 13
3. Replacing the Bulb
IMPORTANT: Before performing any
maintenance work on the power nozzle,
always unplug the vacuum cleaner and
disconnect the wand.
Turn the power nozzle over and remove the
bottom plate by first unscrewing the two
bottom plate screws located by the rear
wheels (see diagram 10). Locate and remove
the two top cover screws (see diagram 14).
Turn the power nozzle back over, push the
power nozzle neck flat, and remove the top
cover (see diagram 15). Simply pull the bulb
out (no twisting) and reinsert a factoryauthorized bulb. Place the top cover back on
the unit, turn the machine over and re-insert
the two top cover screws. Reinstall the bottom
plate.
Top Cover
Screw
DIAGRAM 2 FRONT VIEW OF POWER WAND AND NOZZLE ASSEMBLY
Diagram 14 Diagram 15
98
HOW TO USE CLEANING TOOLS
REPLACING THE FILTERS
• Open the tool cover lid to access tools.
Tool cover lid
button
• On-board tools can be attached either to the power handle or to the end of the wand.
Floor brush: effective for hard surface cleaning (wood, tile, etc)
Upholstery tool: ideal for cleaning furniture
Dusting brush: (slides off the end of the upholstery tool) for shelves, tables, etc
Crevice: designed to clean in tight spaces (i.e. between sofa cushions)
Upholstery tool
Dusting brush
Crevice tool
Floor brush
REPLACING VACUUM BAG
Dust cover
latch.
Vacuum bag
holder
Replacing the charcoal filter:
• Unplug canister and remove the hose.
• Open the dust cover and locate the charcoal filter behind the bag.
• Remove filter case and discard used filter.
• Insert new charcoal filter into filter case and re-insert case.
• Close the dust cover.
Dust cover lid
Charcoal filter
Charcoal
filter
Filter case
Replacing the S-Class HEPA filter:
• Unplug canister and remove HEPA filter cover.
• Remove and discard used HEPA filter.
• Insert new S-Class HEPA filter.
• Press the "reset filter button" located next to the S-Class HEPA filter.
• Reinsert HEPA filter cover onto the machine.
Bag collar
• Turn canister off, remove
hose, and open the dust
cover.
NOTE: The "change bag" light is located on the power handle and will light up when either the bag
is full or when a clog is detected in the machine. If upon inspection the bag is not full,
please inspect the hose or wand for a clog and remove.
• Grab the bag collar and pull the
vacuum bag out of the vacuum
bag holder. Insert new bag.
• Do not re-use vacuum bag.
• Dust cover will not close
without a bag in the unit or
when the bag is not fully
inserted.
10
HEPA filter cover latch
HEPA filter cover
NOTE : Change the S-Class HEPA filter when the "service filter" light is illuminated on the power
handle. Genuine S-Class HEPA filters cannot be washed or re-used.
S-Class HEPA filter
Reset Button
11
SAFETY PRECAUTIONS
TROUBLESHOOTING GUIDE
This vacuum cleaner should be used for normal, dry household dust and dirt.
The manufacturer cannot be held responsible for any damage caused by use or operation of the vacuum
contrary to these instructions.
If the vacuum is wrongly operated for a purpose other than that for which it is intended, no liability can be
accepted for any possible damage.
• Do not vacuum areas which contain moisture
or water, flammable matter, needles, pins, razor
blades, matches, cigarettes, etc., since they
may damage the vacuum or vacuum bag.
• Make sure a vacuum bag, a charcoal filter and a
HEPA filter are always inserted.
• When rewinding the power cord, hold the plug
before pressing the cord rewind button to
prevent the cord from whipping.
• Do not pull the power cord out beyond the red
mark.
RED MARK
• This product is equipped with a polarized
alternating current line plug (a plug having
one blade wider than the other). This plug
fits into the power outlet only one way.
This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact
an electrician to replace the obsolete outlet.
Do not defeat the safety purpose of the
polarized plug.
■ Please check each item below if you have trouble with your vacuum.
Before checking, ensure that the vacuum is unplugged from the power supply.
Problem
• Suction power is weak.
• The vacuum does not work.
• Power cord does not rewind.
• Power cord won't pull out of
the vacuum.
• Vacuum bag
• Wand or hose
• Is the hose adapter inserted
• When the vacuum bag is full or
• Power cord
• Power cord
Check Point
into the suction opening of the
vacuum completely?
any of the accessories are
blocked, the over-heating
protection for the motor is
activated.
• If vacuum bag is full, replace it.
• If clogged or blocked, remove
the object.
• Insert it completely.
• Switch off and unplug the
vacuum and check the
vacuum bag and accessories
and remove any blockages.
The vacuum can be switched
on again after approximately
20 minutes.
• Pull the power cord out a little
and press the cord rewind
button again.
• Do not pull it by force. Rewind
it a little by pressing the cord
rewind button and try pulling it
out again.
SPECIFICATIONS
Model
Rating
Power
Weight
Dimension (L X W X H)
Cord Length
• Specifications can be changed for improvement without notice.
For assistance please visit www.simplicityvac.com or call 1-888-9 Simply
S36
120V/60Hz
12 Amps
26.25 Pounds
21.3" x 11.4" x 9.8"
28 feet
Note
12
13
Loading...
