simcom SIM5210 User Manual v1.60

AT Commands Set
SIM5210_ATC_V1.60
SIM5210 AT Commands Set
Document Title: Version: Date: Status: Document Control ID:
SIM5210 AT Commands Set
General Notes SIMCom offers this information as a service to its customers, to support application and engineering efforts that use the products designed by SIMCom. The information provided is based upon requirements specifically provided to SIMCom by the customers. SIMCom has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. Furthermore, system validation of this product designed by SIMCom within a larger electronic system remains the responsibility of the customer or the customer’s system integrator. All specifications supplied herein are subject to change.
Copyright This document contains proprietary technical information which is the property of SIMCom Limited., copying of this document and giving it to others and the using or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved in the event of grant of a patent or the registration of a utility model or design. All specification supplied herein are subject to change without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2008
SIM5210_ATC_V1.60 2 3/28/2008
SIM5210 AT Commands Set
Version History
Version Chapter What is new
V1.00 New version V.160 3.6 ATI
4.4 ATD><mem><n>
4.5 ATD><n>
4.6 ATD><str>
4.11 AT+CBST
4.16 AT+VTS
5.6 AT+CSDH
5.7 AT+CMGL
6.3 AT+COPS
7.6 AT+CMEC
7.15 AT+AUTOCSQ
8.1 AT+CPBS
9.1 AT+IPR
9.2 AT$QCTER
Add a new parameter <qcn_type> Add this command Add this command Add this command Modify the description of <speed> Modify the description of AT+VTS Modify write command of AT+CSDH Modify write command of AT+CMGL Modify wirte command of AT+COPS Modify write command of AT+CMEC Add test command of AT+AUTOCSQ Modify the description of <storage> Modify the description of <speed> Modify the description of <speed>
SIM5210_ATC_V1.60 3 3/28/2008
SIM5210 AT Commands Set
Contents
General Notes....................................................................................................................................................2
Copyright...........................................................................................................................................................2
Contents.............................................................................................................................................................4
1 Introduction...............................................................................................................................................8
1.1 Scope.............................................................................................................................................8
1.2 References.....................................................................................................................................8
1.3 Abbreviations ................................................................................................................................ 8
1.4 Definitions and conventions..........................................................................................................9
2 AT interface synopsis ..............................................................................................................................10
2.1 Interface settings..........................................................................................................................10
2.2 AT command syntax.................................................................................................................... 10
2.3 AT command response ................................................................................................................10
3 General Commands................................................................................................................................. 11
3.1 Request manufacturer identification (AT+CGMI)....................................................................... 11
3.2 Request model identification (AT+CGMM)................................................................................ 11
3.3 Request revision identification (AT+CGMR).............................................................................. 11
3.4 Request product serial number identification (AT+CGSN).........................................................12
3.5 Request overall capabilities (AT+GCAP)....................................................................................12
3.6 Display product identification information (ATI)........................................................................13
3.7 Re-issue the last command given (A/).........................................................................................13
3.8 Switch to DM mode (AT$QCDMG)...........................................................................................14
3.9 Select TE character set (AT+CSCS)............................................................................................14
3.10 Request international mobile subscriber identity (AT+CIMI).....................................................15
4 Call Control Commands and Methods....................................................................................................16
4.1 Select type of address (AT+CSTA) .............................................................................................16
4.2 Call mode (AT+CMOD)..............................................................................................................16
4.3 Mobile originated call to specified number(ATD).......................................................................17
4.4 Mobile originated call using specified memory and index number (ATD><mem><n>)
4.5 Mobile originated call from active memory using index number(ATD><n>) ............................18
4.6 Mobile originated call from active memory using corresponding field(ATD><str>).................19
4.7 Answer an incoming call (ATA)..................................................................................................19
4.8 Voice hangup control (AT+CVHU).............................................................................................20
4.9 Disconnect existing voice call (ATH)..........................................................................................20
4.10 Hangup call (AT+CHUP) ............................................................................................................ 21
4.11 Select bearer service type (AT+CBST) .......................................................................................21
4.12 Radio link protocol (AT+CRLP) .................................................................................................22
4.13 Service reporting control (AT+CR).............................................................................................23
4.14 Extended error report (AT+CEER)..............................................................................................24
4.15 Cellular result codes (AT+CRC) .................................................................................................25
4.16 DTMF tone generation (AT+VTS)..............................................................................................26
4.17 Speaker mute control (AT+VMUTE)..........................................................................................26
18
SIM5210_ATC_V1.60 4 3/28/2008
SIM5210 AT Commands Set
4.18 Mic mute control (AT+CMUT)...................................................................................................27
4.19 Mic volume control (AT+CMIC) ................................................................................................27
4.20 Receive gain selection (AT+VGR).............................................................................................. 28
4.21 Auto answer incoming call (AT+AUTOANSWER) ...................................................................28
4.22 Set voice channel device (AT+CSDVC) .....................................................................................29
5 SMS Related Commands.........................................................................................................................30
5.1 Message service failure result code +CMS ERROR...................................................................30
5.2 Select message service (AT+CSMS)...........................................................................................30
5.3 Preferred message storage (AT+CPMS) ...................................................................................... 31
5.4 Message format (AT+CMGF) .....................................................................................................32
5.5 Service centre address (AT+CSCA) ............................................................................................ 33
5.6 Show text mode parameters (AT+CSDH)...................................................................................34
5.7 New message indications to TE (AT+CNMI) .............................................................................34
5.8 List messages (AT+CMGL) ........................................................................................................36
5.9 Read message (AT+CMGR)........................................................................................................38
5.10 Send message (AT+CMGS) ........................................................................................................41
5.11 Send message from storage (AT+CMSS)....................................................................................42
5.12 Write message to memory (AT+CMGW)....................................................................................43
5.13 Delete message (AT+CMGD) .....................................................................................................44
5.14 Set text mode parameters (AT+CSMP).......................................................................................44
5.15 Read message only (AT+CMGRO).............................................................................................45
5.16 Change message status (AT+CMGMT) ......................................................................................48
5.17 Set message valid period (AT+CMVP) ....................................................................................... 48
5.18 Read and delete message (AT+CMGRD).................................................................................... 49
5.19 Send message quickly (AT+CMGSO)......................................................................................... 51
5.20 Write message to memory quickly (AT+CMGWO).................................................................... 52
5.21 Set message storage full on PC (AT+PCFULL).......................................................................... 53
5.22 Send message when register on network (AT+CSETSMS) ........................................................54
6 Network Service Related Commands......................................................................................................55
6.1 Subscriber number (AT+CNUM)................................................................................................55
6.2 Network registration (AT+CREG) ..............................................................................................55
6.3 Operator selection (AT+COPS)...................................................................................................56
6.4 Facility lock (AT+CLCK) ...........................................................................................................58
6.5 Change password (AT+CPWD) ..................................................................................................59
6.6 Calling line identification presentation (AT+CLIP) ....................................................................59
6.7 Calling line identification restriction (AT+CLIR).......................................................................61
6.8 Connected line identification presentation (AT+COLP) .............................................................61
6.9 Closed user group (AT+CCUG)..................................................................................................62
6.10 Call forwarding number and conditions (AT+CCFC) .................................................................63
6.11 Call waiting (AT+CCWA) ........................................................................................................... 65
6.12 Call related supplementary services (AT+CHLD).......................................................................66
6.13 Unstructured supplementary service data (AT+CUSD) ..............................................................67
6.14 Advice of charge (AT+CAOC)....................................................................................................68
6.15 Supplementary service notifications (AT+CSSN).......................................................................69
SIM5210_ATC_V1.60 5 3/28/2008
SIM5210 AT Commands Set
6.16 List current calls (AT+CLCC).....................................................................................................70
6.17 Preferred operator list (AT+CPOL).............................................................................................71
6.18 Read operator names (AT+COPN)..............................................................................................72
6.19 Preferred mode selection (AT+CNMP).......................................................................................73
6.20 Preferred band selection (AT+CNBP).........................................................................................73
6.21 Acquisitions order preference (AT+CNAOP) .............................................................................74
6.22 Preferred service domain selection (AT+CNSDP) ......................................................................75
6.23 Inquiring UE system information (AT+CPSI).............................................................................75
6.24 Show network system mode (AT+CNSMOD)............................................................................76
7 Mobile Equipment Control and Status Commands................................................................................. 78
7.1 Phone activity status (AT+CPAS)................................................................................................78
7.2 Set phone functionality (AT+CFUN) ..........................................................................................78
7.3 Enter PIN (AT+CPIN).................................................................................................................79
7.4 Signal quality (AT+CSQ) ............................................................................................................ 80
7.5 Battery capacity query (AT+CBC) ..............................................................................................81
7.6 Mobile Equipment control mode (AT+CMEC)...........................................................................82
7.7 Keypad control (AT+CKPD).......................................................................................................82
7.8 Accumulated call meter (AT+CACM) ........................................................................................83
7.9 Accumulated call meter maximum (AT+CAMM) ......................................................................84
7.10 Price per unit and currency table (AT+CPUC)............................................................................85
7.11 Control phone to power down (AT$QCPWRDN).......................................................................85
7.12 Report Mobile Equipment error (AT+CMEE).............................................................................86
7.13 Mobile Equipment error result code (+CME ERROR)...............................................................86
7.14 Switch device between UART & USB (AT+CUUSWITCH) ..................................................... 88
7.15 Set CSQ report (AT+AUTOCSQ)...............................................................................................89
7.16 Low voltage Alarm (AT+CVALARM)........................................................................................89
7.17 Set Trigger mode of interrupt GPIO (AT+CGPIO).....................................................................90
7.18 Read ICCID in SIM card (AT+CICCID)..................................................................................... 90
7.19 Read values from register of IIC device (AT+CRIIC).................................................................91
7.20 Write values to register of IIC device (AT+CWIIC) ...................................................................91
7.21 Switch between Windows & Linux system support (AT+COMSWITCH)................................. 92
7.22 Open or Close Test Mode (AT+CSWITCHTEST)......................................................................92
8 Phonebook Related Commands...............................................................................................................94
8.1 Select phonebook memory storage (AT+CPBS) ......................................................................... 94
8.2 Read phonebook entries (AT+CPBR)..........................................................................................95
8.3 Find phonebook entries (AT+CPBF)...........................................................................................96
8.4 Write phonebook entry (AT+CPBW)..........................................................................................97
9 V24-V25 Command................................................................................................................................98
9.1 Set local baud rate temporarily (AT+IPR)...................................................................................98
9.2 Set local baud rate permanently (AT$QCTER)........................................................................... 99
9.3 Set control character framing (AT+ICF) .....................................................................................99
9.4 Set local data flow control (AT+IFC)........................................................................................ 100
9.5 Set circuit Data Carrier Detect (DCD) function mode (AT&Cx)..............................................101
9.6 Set circuit Data Terminal Ready (DTR) function mode (AT&Dx)............................................102
SIM5210_ATC_V1.60 6 3/28/2008
SIM5210 AT Commands Set
9.7 ATE enable command echo (ATEx) .......................................................................................... 102
9.8 Display current configuration (AT&V) .....................................................................................102
10 Commands for Packet Domain......................................................................................................104
10.1 Define PDP Context (AT+CGDCONT) .................................................................................... 104
10.2 Quality of Service Profile (Requested) (AT+CGQREQ)...........................................................105
10.3 Quality of Service Profile (Minimum acceptable)( AT+CGQMIN)..........................................107
10.4 Packet Domain attach or detach (AT+CGATT)......................................................................... 110
10.5 PDP context activate or deactivate(AT +CGACT).................................................................... 110
10.6 Enter data state (AT+CGDATA)................................................................................................ 111
10.7 Show PDP address (AT+CGPADDR) ....................................................................................... 112
10.8 GPRS mobile station class(AT +CGCLASS)............................................................................113
10.9 GPRS event reporting(AT +CGEREP)...................................................................................... 113
10.10 GPRS network registration status (AT+CGREG) ..................................................................... 115
10.11 Select service for MO SMS messages (AT+CGSMS)............................................................... 116
11 TCP/IP Related Commands...................................................................................................................117
11.1 Define socket PDP Context (AT+CGSOCKCONT) ................................................................. 117
11.2 Set active PDP context’s profile number (AT+ CSOCKSETPN).............................................. 118
11.3 Inquire socket PDP address AT+IPADDR.................................................................................119
11.4 Open socket( AT+NETOPEN)...................................................................................................119
11.5 Establish TCP connection (AT+TCPCONNECT)..................................................................... 119
11.6 Send TCP data (AT+TCPWRITE)............................................................................................. 120
11.7 Send UDP data (AT+UDPSEND) .............................................................................................120
11.8 Startup TCP server( A T+SER VERSTART )...............................................................................121
11.9 List all of clients’ information (AT+LISTCLIENT)..................................................................121
11.10 Disconnect specified client (AT+CLOSECLIENT) ..................................................................121
11.11 Activate specified client (AT+ACTCLIENT) ...........................................................................122
11.12 Close socket (AT+NETCLOSE)................................................................................................122
12 AT Commands sample...................................................................................................................123
12.1 SMS Commands........................................................................................................................123
12.2 TCP/IP Commands....................................................................................................................124
12.2.1 TCP Server....................................................................................................................124
12.2.2 TCP Client.....................................................................................................................124
12.2.3 UDP............................................................................................................................... 124
SIM5210_ATC_V1.60 7 3/28/2008
SIM5210 AT Commands Set
1 Introduction
1.1 Scope
This document presents the AT Command Set for SIM5210, suitable for End-User.
1.2 References
Document name Version
3GPP TS 07.07 7.8.0 3GPP TS 27.007 6.4.0 3GPP TS 27.005 5.0.0 Software Requirement Specification --- [HSDPA PCMCIA Modem Manager] 1.0
1.3 Abbreviations
For the purposes of the present document, the following abbreviations apply:
AT Attention; this two-character abbreviation is always used to start a command line to be sent
from TE to T A
CBM Cell Broadcast Message DCE Data Communication Equipment DM Diagnostic Monitor DTE Data Terminal Equipment DTMF Dual Tone Multi-Frequency ESN Electronic Serial Number ME Mobile Equipment MIC Microphone MIDI Musical Instrument Digital Interface MIDI MIN Mobile Identification Number MO Mobile Originated MS Mobile Station MT Mobile Terminated OA Outgoing Access PCS Personal Communication Services PDU Protocol Data Unit PIN Personal Identification Number PUK Personal Unlock Key RSSI Received Signal Strength Indicator SID System Identification SIM Subscriber Identity Module SMS Short Message Service SMSC Short Message Service Center TA Terminal Adaptor, e.g. a GSM data card (equal to DCE; Data Circuit terminating
SIM5210_ATC_V1.60 8 3/28/2008
SIM5210 AT Commands Set
Equipment)
TE Terminal Equipment, e.g. a computer (equal to DTE; Data Terminal Equipment) TI Teleservice Identifier UE User Equipment WCDMA Wide-band Code Division Multiple Access
1.4 Definitions and conventions
1. For the purposes of the present document, the following syntactical definitions apply:
<CR> Carriage return character <LF> Linefeed character <…> Name enclosed in angle brackets is a syntactical element. Brackets themselves do not appear. […] Optional subparameter of a command or an optional part of TA information response is
enclosed in square brackets. Brackets them selves do not appear.
2. In this document, all AT commands and return values will disply italic, but AT commands in the cutline do not follow above rule.
For example:
AT+CSQ +CSQ:25,99 OK
3. The contents between “<” and “>”are command parameters.
For example: ATD<dial_no>; In this case, <dial_no>is a parameter. User needs enter a phone number that user wants to dial.
4. The contents between “[” and “]”are optional parameters.
For example: <par1>[,<par2>]; In this case, <par2> is an optional parameter.
5. The return-results (parameters) between “[” and “]”are optional parameters, which indicate the return-results depend on specific situation.
For example: par_a[,par_b,par_c,par_d]; In this case, par_b, par_c, par_d are optional return-results.
SIM5210_ATC_V1.60 9 3/28/2008
SIM5210 AT Commands Set
2 AT interface synopsis
2.1 Interface settings
Module and DTE are using standard RS-232 interface, the default value for cluster setting is 115200bps,
eight data bits, no parity, 1 stop bit, and no data stream control.
2.2 AT command syntax
AT command start with he ader AT, and end with <CR>. If the format of AT command input was correct, the terminal will return the corresponding request information, and finally will return “OK”; Otherwise, the terminal will return “ERROR”. When parameters follow with AT command, 1) For string type, we will put quotation marks to the both side of input string, 2) For numeric string type, able to input numeric value immediately.
2.3 AT command response
The response data package for AT command could be existing between <CR><LF>.
1. If AT command implemented successful, then return “OK”;
2. If AT command syntax error, then return “ERROR”;
3. If AT command implemented failed, return “+CMS ERROR” or “+CME ERROR”.
NOTE: The following sections will ignore <CR> and <LF>.
SIM5210_ATC_V1.60 10 3/28/2008
SIM5210 AT Commands Set
3 General Commands
3.1 Request manufacturer identification (AT+CGMI)
Description
Execution command causes the TA to return the manufacturer identification text, which is intended to
permit the user of the TA to identify the manufacturer of the ME to which it is connected to.
Syntax
Test Command Response
AT+CGMI=? OK
Execution Command Response AT+CGMI <manufacturer>
OK
Defined Values
<manufacturer> the identification of manufacturer.
Implementation
AT+CGMI SIMCOM INCORPORATED OK
3.2 Request model identification (AT+CGMM)
Description
Execution command causes the TA to return model identification text, which is intended to permit the user of the TA to identify the specific model of the ME to which it is connected to.
Syntax
Test Command Response
AT+CGMM=? OK
Execution Command Response AT+CGMM <model>
OK
Defined Values
<model> the identification of model.
Implementation
AT+CGMM SIMCOM_SIM5210 OK
3.3 Request revision identification (AT+CGMR)
Description
Execution command causes the TA to return product firmware version identification text, which is intended to permit the user of the TA to identify the version , revision level or date, or other pertinent information of the ME to which it is connected to.
Syntax
SIM5210_ATC_V1.60 11 3/28/2008
SIM5210 AT Commands Set
Test Command Response
AT+CGMR=? OK
Execution Command Response AT+CGMR <revision>
OK
Defined Values
<revision> the revision identification of firmware.
Implementation
AT+CGMR
+CGMR: M6280A
OK
QCT_03_V17_0_071225_0_H2.1 1 [Aug 02 2007 11:22:39]
3.4 Request product serial number identification (AT+CGSN)
Description
Execution command causes the TA to return identification text, which is intended to permit the user of the TA to identify the individual ME to which it is connected to .
Syntax
Test Command Response
AT+CGSN=? OK
Execution Command Response AT+CGSN <sn>
OK
Defined Values
<sn> serial number identification, which consists of a single line containing the IMEI(International
Mobile station Equipment Identity) number of the ME.
Implementation
AT+CGSN 111111111111110 OK
3.5 Request overall capabilities (AT+GCAP)
Description
Execution command causes the TA reports a list of additional capabilities.
Syntax
Test Command Response
AT+GCAP=? OK
Execution Command Response AT+GCAP +GCAP: (list of <name>s)
OK
Defined Values
<name> list of additional capabilities.
+CGSM GSM function is supported +FCLASS FAX function is supported +DS Data compression is supported
SIM5210_ATC_V1.60 12 3/28/2008
SIM5210 AT Commands Set
Implementation
AT+GCAP +GCAP: +CGSM,+FCLASS,+DS OK
3.6 Display product identification information (ATI)
Description
The command is used to request the product identification informations, which consist of manufacturer identification, model identification, revision identification, internal revision, International Mobile station Equipment Identity and overall capabilities of the product.
Syntax
Execution Command Response ATI Manufacturer: <manufacturer>
Model: <model> Revision: <revision> QCN: <qcn_type> IMEI: <sn> +GCAP: list of <name>s OK
Defined Values
<manufacturer> the identification of manufacturer. <model> the identification of model. <revision> the revision identification of firmware. <qcn_type> the . identification of qcn.
<sn> serial number identification, which consists of a single line containing the
IMEI(International Mobile station Equipment Identity) number of the ME.
<name> list of additional capabilities.
+CGSM GSM function is supported
+FCLASS FAX function is supported
+DS Data compression is supported
Implementation
ATI Manufacturer: SIMCOM INCORPORATED Model: SIMCOM_SIM5210 Revision: M6280A SIM5210_QCT6280_409035_080304_V1.02 1 [Mar 04 2008 20:17:13] Internal Revision: B01V01 IMEI: 111111111111110 +GCAP: +CGSM,+FCLASS,+DS OK
3.7 Re-issue the last command given (A/)
Description
The command is used for implement previous AT command repeatedly(Except A/), and the return value depends on the last AT command.
SIM5210_ATC_V1.60 13 3/28/2008
SIM5210 AT Commands Set
Syntax
Execution Command Response A/ <the response the last AT command return>
Defined Values
None.
Implementation
AT+GCAP +GCAP: +CGSM,+FCLASS,+DS OK A/ +GCAP: +CGSM,+FCLASS,+DS OK
3.8 Switch to DM mode (AT$QCDMG)
Description
Execution command will switch current serial port to DM mode; the DM mode mainly uses for download software or read debug information. Normally, when the serial port working under AT mode, user is able to input AT command, after executing AT command, the serial port will switch to the DM mode and could not input AT command at that status.
Syntax
Test Command Response
AT$QCDMG=? OK
Execution Command Response AT$QCDMG OK
ERROR
Defined Values
1. After switching to DM mode, could not accept commonly AT commands.
2. The status will switch to DM mode when module debugging.
3. The status will resume to AT mode after restart module.
4. The baud rate can not modify by AT command under the DM mode.
Connect two calls and cut off the connection between users and them simultaneously.
Implementation
AT$QCDMG
OK
3.9 Select TE character set (AT+CSCS)
Description
Write command informs TA which character set <chest> is used by the TE. TA is then able to convert character strings correctly TE and ME character sets. Read command shows current setting and test command displays conversion schemes implemented in the TA.
Syntax
Test Command Response
SIM5210_ATC_V1.60 14 3/28/2008
SIM5210 AT Commands Set
AT+CSCS=? +CSCS: (list of supported <chset>s)
Read Command Response
AT+CSCS? +CSCS: <chset>
Write Command Response
AT+CSCS=<chset> OK
Execution Command Response AT+CSCS
Defined Values
<chest>
character set, the define is following:
“IRA”
“GSM” GSM default alphabet; this setting causes easily software flow control
“UCS2” 16-bit universal multiple-octet coded character set; UCS32 character strings
Implementation
AT+CSCS=”IRA” OK AT+CSCS? +CSCS: ”IRA” OK
OK
OK
set default value(<chest>=”IRA”)
OK
international reference alphabet.
(XON/XOFF) problems.
are
converted to hexadecimal numbers from 0000 to FFFF.
3.10 Request international mobile subscriber identity (AT+CIMI)
Description
Execution command causes the TA to return <IMSI>, which is intended to permit the TE to identify the individual SIM which is attached to ME.
Syntax
Test Command Response
AT+CIMI=? OK
Execution Command Response AT+CIMI <IMSI>
OK
Defined Values
<IMSI> International Mobile Subscriber Identity(string, without double quotes).
Implementation
AT+CIMI
460010222028133
OK
SIM5210_ATC_V1.60 15 3/28/2008
SIM5210 AT Commands Set
4 Call Control Commands and Methods
4.1 Select type of address (AT+CSTA)
Description
Write command selects the type of number for further dialing commands(D) according to GSM specifications. Read command returns the current type of number. Test command returns values supported by the TA as a compound value.
Syntax
Test Command Response
AT+CSTA=? +CSTA: (list of supported <type>s)
OK
Read Command Response
AT+CSTA? +CSTA: <type>
OK
Write Command Response
AT+CSTA=<type> OK
Execution Command Response AT+CSTA
Defined Values
<type> type of address octet in integer format; default 145 when dialing string includes international
access code character “+”, otherwise 129.
Implementation
AT+CSTA? +CSTA: 129 OK AT+CSTA=145 OK
set default value (<type>=145)
OK
4.2 Call mode (AT+CMOD)
Description
Write command selects the call mode of further dialing commands(D) or for next answering command(A). Mode can be either single or alternating. Test command returns values supported by the TA as a compound value.
Syntax
Test Command Response
AT+CMOD=? +CMOD: (list of supported <mode>s)
OK
Read Command Response
AT+CMOD? +CMOD: <mode>
SIM5210_ATC_V1.60 16 3/28/2008
SIM5210 AT Commands Set
OK
Write Command Response
AT+CMOD=<mode> OK
Execution Command Response AT+CMOD OK
Defined Values
<mode> 0 – single mode(only supported) 1 alternating voice/fax(teleservice 61) 2 alternating voice/data(bearer service 61) 3 – voice followed by data(bearer service 81)
NOTE: The value of <mode> shall be set to zero after a successfully completed alternating mode
call. It shall be set to zero also after a failed answering. The power-up, factory and user resets shall also set the value to zero . This reduces the possibility that alternating mode calls are originated or answ ered accidentally.
Implementation
AT+CMOD? +CMOD: 0 OK AT+CMOD=0 OK
4.3 Mobile originated call to specified number(ATD)
Description
Originate a call to specified number.
Syntax
Execution Command Response
ATD<n>[<mgsm>][;] OK
VOICE CALL: BEGIN
ERROR
Defined Values
<n> string of dialing digits and optionally V.25ter modifiers dialing digits: 0-9,*,#,+,A,B,C Following V.25ter modifiers are ignored: ,(comma),T,P,!,W,@
<mgsm> String of GSM modifiers: I Activates CLIR(disables presentation of own phone number to called party) I Deactivates CLIR(enables presentation of own phone number to called party) G Activate Closed User Group explicit invocation for this call only. g Deactivate Closed User Group explicit invocation for this call only. <;> The termination character ";" is mandatory to set up voice calls.It must not be used for
data and fax calls.
Implementation
SIM5210_ATC_V1.60 17 3/28/2008
SIM5210 AT Commands Set
ATD10086; OK
VOICE CALL: BEGIN
4.4 Mobile originated call using specified memory and index number
(ATD><mem><n>)
Description
Originate a call using specified memory and index number.
Syntax
Execution Command Response
ATD><mem><n>; OK
VOICE CALL: BEGIN
ERROR
Defined Values
<mem> Phonebook storage: For detailed description of storages see AT+CPBS.
"DC" ME dialed calls list "MC" ME missed (unanswered received) calls list "RC" ME received calls list "SM" SIM phonebook "ME" UE phonebook "FD" SIM fixdialling-phonebook "ON" MSISDN list "LD" Last number dialed phonebook "EN" Emergency numbers
<n> Integer type memory location in the range of locations available in the selected memory,i.e.
the index returned by AT+CPBR.
Implementation
ATD>SM3; OK
VOICE CALL: BEGIN
4.5 Mobile originated call from active memory using index number(ATD><n>)
Description
Originate a call to specified number.
Syntax
Execution Command Response
ATD><n>; OK
VOICE CALL: BEGIN
SIM5210_ATC_V1.60 18 3/28/2008
SIM5210 AT Commands Set
ERROR
Defined Values
<n> Integer type memory location in the range of locations available in the selected memory,i.e.the Index number returned by A T+CPBR. Implementation
ATD>2; OK
VOICE CALL: BEGIN
4.6 Mobile originated call from active memory using corresponding field(ATD><str>)
Description
Originate a call to specified number.
Syntax
Execution Command Response
ATD><str>; OK
VOICE CALL: BEGIN
ERROR
Defined Values
<str> string type value(“x”), which should equal to an alphanumeric field in at least one phone
book entry in the searched memories. str formatted as current TE character set specified by
AT+CSCS.
Implementation
ATD>john; OK
VOICE CALL: BEGIN
4.7 Answer an incoming call (ATA)
Description
The command is used to answer an incoming call. If there is no an incoming call and entering this command to TA, it will be result “NO CARRIER” response given.
Syntax
Execution Command Response ATA VOICE CALL: BEGIN
OK
if there is no an incoming call
NO CARRIER
Defined Values
None.
Implementation
SIM5210_ATC_V1.60 19 3/28/2008
SIM5210 AT Commands Set
ATA VOICE CALL: BEGIN
OK
4.8 Voice hangup control (AT+CVHU)
Description
Write command selects whether ATH command shall cause a voice connection to be disconnected or not. By voice connection is also meant alternating mode calls that are currently in voice mode.
Syntax
Test Command Response
AT+CVHU=? +CVHU: (list of supported <mode>s)
OK
Read Command Response
AT+CVHU? +CVHU: <mode>
OK
Write Command Response
AT+CVHU=<mode> OK
Execution Command Response AT+CVHU
Defined Values
<mode> 0 – ATH command could disconnect a voice call. 1 – ATH command ignored, but OK response given.
Implementation
AT+CVHU=0 OK AT+CVHU? +CVHU: 0
OK
set default value(<mode>=1)
OK
4.9 Disconnect existing voice call (ATH)
Description
The command is used to disconnect existing voice call. Before using ATH command to hangup a voice call, it must set AT+CVHU=0. Otherwise, ATH command will be ignored and “OK” response is given only.
Syntax
Execution Command Response ATH
Defined Values
SIM5210_ATC_V1.60 20 3/28/2008
if AT+CVHU=0
VOICE CALL: END: <time> OK
if AT+CVHU=1
OK
SIM5210 AT Commands Set
<time> Telephone connection time.
Format – HHMMSS(HH: hour, MM: minute, SS: second).
Implementation
AT+CVHU=0 OK ATH VOICE CALL: END: 000017 OK
4.10 Hangup call (AT+CHUP)
Description
The command is used to hangup the current call. If there is no active call, it will do nothing but generate “OK” response.
Syntax
Test Command Response
AT+CHUP=? OK
Execution Command Response AT+CHUP VOICE CALL: END: <time>
OK
if there is no active call:
OK
Defined Values
<time> Telephone connection time.
Format – HHMMSS(HH: hour, MM: minute, SS: second).
Implementation
AT+CHUP VOICE CALL: END: 000017 OK
4.11 Select bearer service type (AT+CBST)
Description
Write command selects the bearer service <name> with data rate <speed>, and the connection element <ce> to be used when data calls are originated. Values may also be used during mobile terminated data call setup, especially in case of single numbering scheme calls.
Syntax
Test Command Response
AT+CBST=? +CBST: (list of supported <speed>s), (list of supported
<name>s), (list of supported <ce>s) OK
Read Command Response
AT+CBST? +CBST: <speed>,<name>,<ce>
OK
SIM5210_ATC_V1.60 21 3/28/2008
SIM5210 AT Commands Set
Write Command Response
AT+CBST=<speed>[
OK
,<name>[,<ce>]]
Execution Command Response AT+CBST
set default value (0,0,1)
OK
Defined Values
<speed> 0 – autobauding(automatic selection of the speed; this setting is possible in case of
3.1 kHz modem and non-transparent service) 7 – 9600 bps 12 – 9600 bps 14 – 14400 bps 16 – 28800 bps 17 – 33600 bps 39 – 9600 bps 43 – 14400 bps 48 – 28800 bps 51 – 56000 bps 71 – 9600 bps 75 – 14400 bps 80 – 28800 bps 81 – 38400 bps 83 – 56000 bps 84 – 64000 bps 116 – 64000 bps 134 – 64000 bps
NOTE: If <speed> is set to 116 or 134, it is necessary that <name> is equal to 1 and <ce> is
equal to 0 <name> 0 GSM 1 WCDMA 4 data circuit asynchronous (RDI) <ce> 0 transparent 1 non-transparent
Implementation
AT+CBST=0,0,1 OK
AT+CBST +CBST: 0,0,1 OK
4.12 Radio link protocol (AT+CRLP)
Description
Radio Link Protocol(RLP) parameters used when non-transparent data calls are originated may be
SIM5210_ATC_V1.60 22 3/28/2008
SIM5210 AT Commands Set
altered with write command.
Read command returns current settings for each supported RLP version <verx>. Only RLP parameters
applicable to the corresponding <verx> are returned.
Test command returns values supported by the TA as a compound value. If ME/TA supports several
RLP versions <verx>, the RLP parameter value ranges for each <verx> are returned in a separate line.
Syntax
Test Command Response
AT+CRLP=? +CRLP: (list of supported <iws>s), (list of supported <mws>s),
(list of supported <T1>s), (list of supported <N2>s) [,<ver1>
[,(list of supported <T4>s)]] [<CR><LF>+CRLP: (list of supported <iws>s), (list of supported <mws>s), (list of supported <T1>s), (list of supported <N2>s) [,<ver2> [,(list of supported <T4>s)]] [...]] OK
Read Command Response
AT+CRLP? +CRLP: <iws>, <mws>, <T1>, <N2> [,<ver1> [, <T4>]]
<CR><LF>
[
+CRLP:<iws>,<mws>,<T1>,<N2>[,<ver2>[,<T4>]] [...]] OK
Write Command Response
AT+CRLP=<iws>[,<
OK
mws>[,<T1>[,<N2>[, <ver>[,<T4>]]]]]
Execution Command Response AT+CRLP OK
Defined Values
<ver>, <verx> RLP version number in integer format, and it can be 0, 1 or 2; when version
indication is not present it shall equal 1. <iws> IWF to MS window size. <mws> MS to IWF window size. <T1> acknowledgement timer. <N2> retransmission attempts. <T4> re-sequencing period in integer format.
NOTE: <T1> and <T4> are in units of 10 ms.
Implementation
AT+CRLP? +CRLP: 61,61,48,6,0 +CRLP: 61,61,48,6,1 +CRLP: 240,240,52,6,2 OK
4.13 Service reporting control (AT+CR)
SIM5210_ATC_V1.60 23 3/28/2008
SIM5210 AT Commands Set
Description
Write command controls whether or not intermediate result code “+CR: <serv>” is returned from the TA to the TE. If enabled, the intermediate result code is transmitted at the point during connect negotiation at which the TA has determined which speed and quality of service will be used, before any error control or data compression reports are transmitted, and before the intermediate result code CONNECT is transmitted.
Syntax
Test Command Response
AT+CR=? +CR: (list of supported <mode>s)
OK
Read Command Response
AT+CR? +CR: <mode>
OK
Write Command Response
AT+CR=<mode> OK
Execution Command Response AT+CR
set default value (<mode>=0)
OK
Defined Values
<mode> 0 – disables reporting 1 enables reporting <serv> ASYNC asynchronous transparent SYNC synchronous transparent REL ASYNC asynchronous non-transparent REL sync synchronous non-transparent GPRS [<L2P>] GPRS The optional <L2P> proposes a layer 2 protocol to use between the MT and the TE.
Implementation
AT+CR? +CR: 0 OK AT+CR=1 OK
4.14 Extended error report (AT+CEER)
Description
Execution command causes the TA to return the information text <report>, which should offer the user of the TA an extended report of the reason for:
- the failure in the last unsuccessful call setup(originating or answering) or in-call modification.
- the last call release.
- the last unsuccessful GPRS attch or unsuccessful PDP context activation.
- the last GPRS detach or PDP context deactivation.
Syntax
Test Command Response
SIM5210_ATC_V1.60 24 3/28/2008
SIM5210 AT Commands Set
AT+CEER=? OK
Execution Command Response AT+CEER +CEER: <report>
OK
Defined Values
<report> wrong information which is possibly occurred.
Implementation
AT+CEER +CEER: Invalid/incomplete number OK
4.15 Cellular result codes (AT+CRC)
Description
Write command controls whether or not the extended format of incoming call indication or GPRS network request for PDP context activation is used. When enabled, an incoming call is indicated to the TE with unsolicited result code “+CRING: <type>” instead of the normal RING. Test command returns values supported by the TA as a compound value.
Syntax
Test Command Response
AT+CRC=? +CRC: (list of supported <mode>s)
OK
Read Command Response
AT+CRC? +CRC: <mode>
OK
Write Command Response
AT+CRC=<mode> OK
Execution Command Response AT+CRC
Defined Values
<mode> 0 – disable extended format 1 – enable extended format <type> ASYNC asynchronous transparent SYNC synchronous transparent REL ASYNC asynchronous non-transparent REL SYNC synchronous non-transparent FAX facsimile VOICE normal voice
VOICE/XXX voice followed by data(XXX is ASYNC, SYNC, REL ASYNC or REL
ALT VOICE/XXX alternating voice/data, voice first ALT XXX/VOICE alternating voice/data, data first ALT FAX/VOICE alternating voice/fax, fax first
set default value(<mode>=0)
OK
SYNC)
SIM5210_ATC_V1.60 25 3/28/2008
SIM5210 AT Commands Set
GPRS GPRS network request for PDP context activation
Implementation
AT+CRC=1 OK AT+CRC? +CRC: 1 OK
4.16 DTMF tone generation (AT+VTS)
Description
The command is used to send a DTMF tone to network during a voice call which is connected.
Syntax
Test Command Response
AT+VTS=? +VTS: (list of supported <key>s)
OK
Write Command Response
AT+VTS=<key> OK
ERROR
Defined Values
<key> 0-9 dial from 0 to 9 numbers * dial * key # dial # key
Implementation
AT+VTS=1 OK AT+VTS=? +VTS: (0-9,*,#) OK
4.17 Speaker mute control (AT+VMUTE)
Description
The command is used to control the speaker to mute and unmute during a voice call which is
connected.
Syntax
SIM5210_ATC_V1.60 26 3/28/2008
Test Command Response
AT+VMUTE=? +VMUTE: (list of supported <mode>s)
OK
Read Command Response
AT+VMUTE? +VMUTE: <mode>
OK Write Command Response AT+VMUTE=<mode> OK
SIM5210 AT Commands Set
Defined Values
<mode> 0 – mute off 1 mute on
Implementation
AT+VMUTE=1 OK AT+VMUTE? +VMUTE: 1 OK
4.18 Mic mute control (AT+CMUT)
Description
The command is used to enable and disable the uplink voice muting during a voice call which is connected.
Syntax
Test Command Response
AT+CMUT=? +CMUT: (list of supported <mode>s)
OK
Read Command Response
AT+CMUT? +CMUT: <mode>
OK
Write Command Response
AT+CMUT=<mode> OK
Defined Values
<mode> 0 – mute off 1 mute on
Implementation
AT+CMUT=1 OK AT+CMUT? +CMUT: 1 OK
4.19 Mic volume control (AT+CMIC)
Description
The command is used to change the microphone gain level.
Syntax
Test Command Response
AT+CMIC=? +CMIC: (list of supported <gainlevel>s)
OK
Read Command Response
AT+CMIC? +CMIC: <gainlevel>
OK
SIM5210_ATC_V1.60 27 3/28/2008
SIM5210 AT Commands Set
Write Command Response AT+CMIC=<gainlevel>
Defined Values
<gainlevel> range from 0 to 15, and 0 is the lowest, 15 is the highest
Implementation
AT+CMIC=5 OK AT+CMIC ? +CMIC :5 OK AT+CMIC= ? +CMIC :(0-15) OK
OK
4.20 Receive gain selection (AT+VGR)
Description
The command causes the TA to control volume high and low.
Syntax
Test Command Response
AT+VGR=? +VGR: (list of supported <vol>s)
OK
Read Command Response
AT+VGR? +VGR: <vol>
OK
Write Command Response
AT+VGR=<vol> OK
Defined Values
<vol> range from 0 to 4, and 0 is the lowest, 4 is the highest
Implementation
AT+VGR? +VGR: 2 OK AT+VGR=4 OK
4.21 Auto answer incoming call (A T+AUTOANSWER)
Description
The command causes the module to disable and enable auto answer when there is a incoming call.
Syntax
Read Command Response
AT+AUTOANSWE R?
Write Command Response
SIM5210_ATC_V1.60 28 3/28/2008
+AUTOANSWER: <arg> OK
SIM5210 AT Commands Set
AT+AUTOANSWE
OK
R=<arg>
Defined Values
<arg> 0 – disable auto answer 1 – enable auto answer
Implementation
AT+AUTOANSWER=1
OK
AT+AUTOANSWER?
+AUTOANSWER: 1
OK
4.22 Set voice channel device (AT+CSDVC)
Description
The command causes the module to set current voice channel device.
Syntax
Test Command Response
AT+CSDVC=? +CSDVC: (list of supported <arg>s)
OK
Read Command Response
AT+CSDVC? +CSDVC: <arg>
OK
Write Command Response
AT+CSDVC=<arg> OK
Defined Values
<arg> 1 – handset 2 headset 3 speaker phone
Implementation
AT+CSDVC=2
OK
AT+CSDVC?
+CSDVC : 2
OK
SIM5210_ATC_V1.60 29 3/28/2008
SIM5210 AT Commands Set
5 SMS Related Commands
5.1 Message service failure result code +CMS ERROR
Description
Final result code +CMS ERROR: <err> indicates an error related to mobile equipment or network. The operation is similar to ERROR result code. None of the following commands in the same command line is executed. Neither ERROR nor OK result code shall be returned. ERROR is returned normally when error is related to syntax or invalid parameters.
Syntax
+CMS ERROR: <err> Defined Values
<err>
300 ME failure 301 SMS service of ME reserved 302 operation not allow ed 303 operation not supporte d 304 invalid PDU mode parameter 305 invalid text mode parameter 310 (U)SIM not inserted 311 (U)SIM PIN required 312 PH-(U)SIM PIN required 313 (U)SIM failure 314 (U)SIM busy 315 (U)SIM wrong 316 (U)SIM PUK required 317 (U)SIM PIN2 required 318 (U)SIM PUK2 required 320 memory failure 321 invalid memory index 322 memory full 330 SMSC address unknown 331 no network service 332 network timeout 340 no +CNMA acknowledgement expected 500 unknown error
Implementation
AT+CMGS=02152063366
+CMS ERROR: 304
5.2 Select message service (AT+CSMS)
Description
The command is used to select messaging service <service>.
SIM5210_ATC_V1.60 30 3/28/2008
SIM5210 AT Commands Set
Syntax
Test Command Response
AT+CSMS=? +CSMS: (list of supported <service>s)
Read Command Response
AT+CSMS? +CSMS: <service>,<mt>,<mo>,<bm>
Write Command Response
AT+CSMS=<service> +CSMS: <mt>,<mo>,<bm>
Defined Values
<service>
0 SMS AT command is compatible with GSM Phase 2 1 SMS AT command is compatible with GSM Phase 2+
<mt> Mobile Terminated Messages:
0 Type not supported 1 Type supported
<mo> Mobile Originated Messages:
0 Type not supported 1 Type supported
<bm> Broadcast Type Messages:
0 Type not supported 1 Type supported
Implementation
AT+CSMS=0
+CSMS: 1,1,1
OK
AT+CSMS?
+CSMS: 0,1,1,1
OK
AT+CSMS=?
+CSMS: (0-1)
OK
OK
OK
OK
+CMS ERROR: <err>
5.3 Preferred message storage (AT+CPMS)
Description
The command is used to select memory storages <mem1>, <mem2> and <mem3> to be used for reading, writing, etc.
Syntax
Test Command Response
AT+CPMS=? +CPMS: (list of supported <mem1>s), (list of supported
<mem2>s), (list of supported <mem3>s)
SIM5210_ATC_V1.60 31 3/28/2008
SIM5210 AT Commands Set
OK
Read Command Response
AT+CPMS? +CPMS:<mem1>,<used1>,<total1>,<mem2>,<used2>,<total2>,
<mem3>,<used3>,<total3> OK
+CMS ERROR: <err>
Write Command Response
AT+CPMS=<mem1> [,<mem2>[,<mem3>] ]
Defined Values
<mem1> string type, memory from which messages are read and deleted (commands List Messages
+CMGL, Read Message +CMGR and Delete Message +CMGD)
<mem2> string type, memory to which writing and sending operations are made (commands Send
Message from Storage +CMSS and Write Message to Memory +CMGW)
<mem3> string type, memory to which received SMS is preferred to be stored (unless forwarded
directly to TE; refer command New Message Indications +CNMI) <usedx> integer type, number of messages currently in <memx> <totalx> integer type, total number of message locations in <memx>
Implementation
AT+CPMS=? (“ME” and “MT” means FLASH message storage; “SM” and “SR” means SIM message storage.) +CPMS: ("ME","MT","SM","SR"),("ME","MT","SM","SR"),("ME","MT","SM","SR") OK AT+CPMS? +CPMS: "ME", 0, 23,"ME", 0, 23,"ME", 0, 23 OK AT+CPMS="SM","SM","SM" +CPMS: 3,40,3,40,3,40 OK
+CPMS: <used1>,<total1>,<used2>,<total2>,<used3>,<total3> OK
+CMS ERROR: <err>
5.4 Message format (AT+CMGF)
Description
The command is used to tell the TA, which input and output format of messages to use.
Syntax
Test Command Response
AT+CMGF=? +CMGF: (list of supported <mode>s)
OK
Read Command Response
AT+CMGF? +CMGF: <mode>
OK
SIM5210_ATC_V1.60 32 3/28/2008
SIM5210 AT Commands Set
Write Command Response
AT+CMGF=<mode> OK
Execution Command Response AT+CMGF
Defined Values
<mode>
0 PDU mode (default when implemented) 1 text mode
Implementation
AT+CMGF? +CMGF: 0 OK AT+CMGF=? +CMGF: (0-1) OK AT+CMGF=1 OK
set default value (<mode>=0)
OK
5.5 Service centre address (AT+CSCA)
Description
The command is used to update the SMSC address, through which mobile originated SMS are
transmitted.
Syntax
Test Command Response
AT+CSCA=? OK
Read Command Response
AT+CSCA? +CSCA: <sca>,<tosca>
OK
Write Command Response
AT+CSCA=<sca> [,<tosca>]
Defined Values
<sca> SC address, value field in string format, BCD numbers (or GSM 7 bit default alphabet
characters) are converted to characters of the currently selected TE character set, type of address given by <tosca>.
<tosca> SC address Type-of-Address octet in integer format. (When first character is + default is 145,
otherwise default is 129)
Implementation
AT+CSCA="+8613010314500" OK AT+CSCA?
OK
+CME ERROR:<err>
SIM5210_ATC_V1.60 33 3/28/2008
SIM5210 AT Commands Set
+CSCA: "+8613010314500", 145 OK
5.6 Show text mode parameters (AT+CSDH)
Description
The command is used to control whether detailed header information is shown in text mode result
codes.
Syntax
Test Command Response
AT+CSDH=? +CSDH: (list of supported <show>s)
OK
Read Command Response
AT+CSDH? +CSDH: <show>
OK
Write Command Response
AT+CSDH=<show> OK
Execution Command Response AT+CSDH
Defined Values
<show>
0 do not show header values defined in commands +CSCA and +CSMP (<sca>, <tosca>, <fo>,
<vp>, <pid> and <dcs>) nor <length>, <toda> or <tooa> in +CMT, +CMGL, +CMGR result codes for SMS-DELIVERs and SMS-SUBMITs in text mode; for SMS-COMMANDs in +CMGR result code, do not show <pid>, <mn>, <da>, <toda>, <length> or <cdata>
1 show the values in result codes
Implementation
AT+CSDH? +CSDH: 0 OK AT+CSDH=1 OK
set default value (<show>=0)
OK
5.7 New message indications to TE (AT+CNMI)
Description
The command is used to select the procedure, how receiving of new messages from the network is
indicated to the TE when TE is active, e.g. DTR signal is ON. If TE is inactive (e.g. DTR signal is OFF).
Syntax
Test Command Response
AT+CNMI=? +CNMI: (list of supported <mode>s),(list of supported
<mt>s),(list of supported <bm>s),(list of supported <ds>s),(list of supported <bfr>s)
OK
SIM5210_ATC_V1.60 34 3/28/2008
SIM5210 AT Commands Set
Read Command Response
AT+CNMI? +CNMI: <mode>,<mt>,<bm>,<ds>,<bfr>
OK
Write Command Response
AT+CNMI=<mode> [,<mt>[,<bm>[,<ds> [,<bfr>]]]]
OK
+CMS ERROR: <err>
Execution Command Response AT+CNMI
set default value(<mode>=0, <mt>=0, <bm>=0, <ds>=0,
<bfr> =0)
OK
Defined Values
<mode>
0 Buffer unsolicited result codes in the TA. If TA result code buffer is full, indications can be
buffered in some other place or the oldest indications may be discarded and replaced with the new received indications.
1 Discard indication and reject new received message unsolicited result codes when TA-TE link
is reserved (e.g. in on-line data mode). Otherwise forward them directly to the TE.
2 Buffer unsolicited result codes in the TA when TA-TE link is reserved (e.g. in on-line data
mode) and flush them to the TE after reservation. Otherwise forward them directly to the TE.
3 Forward unsolicited result codes directly to the TE. TA-TE link specific inband technique
used to embed result codes and data when TA is in on-line data mode.
<mt> the rules for storing received SMS depend on its data coding scheme, preferred memory
storage (+CPMS) setting and this value: 0 No SMS-DELIVER indications are routed to the TE. 1 If SMS-DELIVER is stored into ME/TA, indication of the memory location is routed to the
TE using unsolicited result code: +CMTI: <mem>,<index>. 2 SMS-DELIVERs (except class 2 messages and messages in the message waiting indication
group (store message)) are routed directly to the TE using unsolicited result code:
+CMT: [<alpha>],<length><CR><LF><pdu> (PDU mode enabled); or
+CMT: <oa>, [<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>,<sca>,<tosca>, <length>]<CR>
<LF><data>
(text mode enabled, about parameters in italics, refer command Show Text Mode Parameters
+CSDH). 3 Class 3 SMS-DELIVERs are routed directly to TE using unsolicited result codes defined in
<mt>=2. Messages of other data coding schemes result in indication as defined in <mt>=1.
<bm> the rules for storing received CBMs depend on its data coding scheme, the setting of Select
CBM Types (+CSCB) and this value: 0 No CBM indications are routed to the TE. 1 If CBM is stored into ME/TA, indication of the memory location is routed to the TE using
unsolicited result code: +CBMI: <mem>,<index> 2 New CBMs are routed directly to the TE using unsolicited result code:
+CBM: <length><CR><LF><pdu> (PDU mode enabled); or
+CBM: <sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data> (text mode enabled)
SIM5210_ATC_V1.60 35 3/28/2008
SIM5210 AT Commands Set
3 Class 3 CBMs are routed directly to TE using unsolicited result codes defined in <bm>=2. If
CBM storage is supported, messages of other classes result in indication as defined in
<bm>=1.
<ds>
0 No SMS-STATUS-REPORTs are routed to the TE. 1 SMS-STATUS-REPORTs are routed to the TE using unsolicited result code:
+CDS: <length><CR><LF><pdu> (PDU mode enabled); or
+CDS: <fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st> (text mode enabled) 2 If SMS-STATUS-REPORT is stored into ME/TA, indication of the memory location is routed
to the TE using unsolicited result code: +CDSI: <mem>,<index>
<bfr>
0 TA buffer of unsolicited result codes defined within this command is flushed to the TE when
<mode> 1 to 3 is entered (OK response shall be given before flushing the codes). 1 TA buffer of unsolicited result codes defined within this command is cleared when <mode> 1
to 3 is entered.
Implementation
AT+CNMI? +CNMI: 0,0,0,0,0 OK AT+CNMI=? +CNMI: (0,1,2),(0,1,2,3),(0,2),(0,1,2),(0,1) OK AT+CNMI=2,1 (unsolicited result codes after received messages.) OK
5.8 List messages (AT+CMGL)
Description
The command returns messages with status value <stat> from message storage <mem1> to the TE.
Syntax
Test Command Response
AT+CMGL=? +CMGL: (list of supported <stat>s)
OK
Write Command Response
AT+CMGL=<stat>
if text mode (+CMGF=1), command successful and SMS-SUBMITs and/or SMS-DELIVERs:
+CMGL: <index>,<stat>,<oa/da>,[<alpha>],[<scts>][,<tooa/toda>,<length>] <CR><LF><data>[<CR><LF>
+CMGL: <index>,<stat>,<da/oa>,[<alpha>],[<scts>][,<tooa/toda>,
<length>]<CR><LF><data>[...]] OK
if text mode (+CMGF=1), command successful and SMS-
SIM5210_ATC_V1.60 36 3/28/2008
SIM5210 AT Commands Set
STATUS-REPORTs:
+CMGL: <index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
[<CR><LF> +CMGL:
<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st> [...]] OK
if text mode (+CMGF=1), command successful and SMS­COMMANDs:
+CMGL: <index>,<stat>,<fo>,<ct>[<CR><LF> +CMGL: <index>,<stat>,<fo>,<ct>[...]] OK
if text mode (+CMGF=1), command successful and CBM storage:
+CMGL: <index>,<stat>,<sn>,<mid>,<page>,<pages> <CR><LF><data>[<CR><LF> +CMGL: <index>,<stat>,<sn>,<mid>,<page>,<pages> <CR><LF><data>[...]] OK
otherwise:
+CMS ERROR: <err>
Defined Values
<stat>
a. Text Mode
"REC UNREAD" received unread message (i.e. new message)
"REC READ" received read message
"STO UNSENT" stored unsent message
"STO SENT" stored sent message
"ALL" all messages b. PDU Mode
0 received unread message (i.e. new message)
1 received read message
2 stored unsent message
3 stored sent message
4 all messages
<alpha> string type alphanumeric representation of <da> or <oa> corresponding to the entry found in
MT phonebook; implementation of this feature is manufacturer specific; used character set
should be the one selected with command Select TE Character Set +CSCS.
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE character
SIM5210_ATC_V1.60 37 3/28/2008
SIM5210 AT Commands Set
set, type of address given by <toda>.
<data> In the case of SMS: TP-User-Data in text mode responses; format:
1 if <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that
TP-User-Data-Header-Indication is not set:
a. if TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default
alphabet into two IRA character long hexadecimal number. (e.g. character Π (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55))
2 if <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA
character long hexadecimal number. (e.g. octet with integer value 42 is presented to TE as
two characters 2A (IRA 50 and 65))
3. if <dcs> indicates that GSM 7 bit default alphabet is used:
a. if TE character set other than "HEX":ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default
alphabet into two IRA character long hexadecimal number
4. if <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each 8-bit
octet into two IRA character long hexadecimal number.
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message body
<data> > (or <cdata>) in characters; or in PDU mode (+CMGF=0), the length of the actual
TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length) <index> integer type, value in the range of location numbers supported by the associated memory <oa> Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE
character set, type of address given by <tooa> <pdu> In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts
each octet of TP data unit into two IRA character long hexadecimal number. (e.g. octet with
integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)) <scts> TP-Service-Centre-Time-Stamp in time-string format (refer <dt>) <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129) <tooa> TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>)
Implementation
AT+CMGL=? +CMGL: ("REC UNREAD","REC READ","STO UNSENT","STO SENT","ALL") OK AT+CMGL="ALL" +CMGL: 1,"STO UNSENT","+10011",,,145,4 abcd OK
5.9 Read message (AT+CMGR)
SIM5210_ATC_V1.60 38 3/28/2008
SIM5210 AT Commands Set
Description
The command returns message with location value <index> from message storage <mem1> to the TE.
Syntax
Test Command Response
AT+CMGR=? OK
Write Command Response
AT+CMGR=<index>
if text mode (+CMGF=1), command successful and SMS­DELIVER:
+CMGR: <stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>, <sca>, <tosca>, <length>]<CR><LF><data> OK
if text mode (+CMGF=1), command successful and SMS­SUBMIT:
+CMGR: <stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp>], <sca>, <tosca>,<length>]<CR><LF><data> OK
if text mode (+CMGF=1), command successful and SMS­STATUS-REPORT:
+CMGR: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st> OK
if text mode (+CMGF=1), command successful and SMS­COMMAND:
+CMGR: <stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<length> <CR><LF><data>]
OK
if text mode (+CMGF=1), command successful and CBM storage:
+CMGR: <stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data>
OK
otherwise:
+CMS ERROR: <err>
Defined Values
<stat>
a. Text Mode
SIM5210_ATC_V1.60 39 3/28/2008
SIM5210 AT Commands Set
"REC UNREAD" received unread message (i.e. new message) "REC READ" received read message "STO UNSENT" stored unsent message "STO SENT" stored sent message "ALL" all messages
b. PDU Mode
0 received unread message (i.e. new message) 1 received read message 2 stored unsent message 3 stored sent message 4 all messages
<alpha> string type alphanumeric representation of <da> or <oa> corresponding to the entry found in
MT phonebook; implementation of this feature is manufacturer specific; used character set should be the one selected with command Select TE Character Set +CSCS.
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>.
<data> In the case of SMS: TP-User-Data in text mode responses; format:
1 if <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that
TP-User-Data-Header-Indication is not set: a. if TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default
alphabet into two IRA character long hexadecimal number. (e.g. character Π (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55))
2 if <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number. (e.g. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65))
3. if <dcs> indicates that GSM 7 bit default alphabet is used: a. if TE character set other than "HEX":ME/TA converts GSM alphabet into current TE character set. b. if TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default
alphabet into two IRA character long hexadecimal number
4. if <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number.
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message body
<data> > (or <cdata>) in characte rs; or in PDU mode (+CMGF=0 ), the length of the actu al
TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length) <index> integer type, value in the range of location numbers supported by the associated memory <oa> Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE
character set, type of address given by <tooa> <pdu> In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts
SIM5210_ATC_V1.60 40 3/28/2008
SIM5210 AT Commands Set
each octet of TP data unit into two IRA character long hexadecimal number. (e.g. octet with
integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)) <scts> TP-Service-Centre-Time-Stamp in time-string format (refer <dt>) <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129) <tooa> TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>) <dcs> depending on the command or result code: SMS Data Coding Scheme (default 0), or Cell
Broadcast Data Coding Scheme in integer format. <fo> depending on the command or result code: first octet of SMS-DELIVER, SMS-SUBMIT
(default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer format. <mid> CBM Message Identifier in integer format. <sca> RP SC address Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set,
type of address given by <tosca> <tosca> RP SC address Type-of-Address octet in integer format (default refer <toda>) <vp> depending on SMS-SUBMIT <fo> setting: TP-Validity-Period either in integer format
(default 167) or in time-string format (refer <dt>).
Implementation
AT+CMGR=1 +CMGR: "STO UNSENT","+10011",,145,17,0,0,167,"+8613800100500",1 45 ,4 abcd OK
5.10 Send message (AT+CMGS)
Description
The command is used to send message from a TE to the network (SMS-SUBMIT).
Syntax
Test Command Response
AT+CMGS=? OK
Write Command Response
if text mode (+CMGF=1):
AT+CMGS=<da>[,<toda >]<CR>text is entered <ctrl-Z/ESC>
Defined Values
<data> In the case of SMS: TP-User-Data in text mode responses; format:
1 if <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that
TP-User-Data-Header-Indication is not set: a. if TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default
if text mode (+CMGF=1) and sending successful:
+CMGS: <mr> OK
if sending fails:
+CMS ERROR: <err>
SIM5210_ATC_V1.60 41 3/28/2008
SIM5210 AT Commands Set
alphabet into two IRA character long hexadecimal number. (e.g. character Π (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55))
2 if <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number. (e.g. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65))
3. if <dcs> indicates that GSM 7 bit default alphabet is used: a. if TE character set other than "HEX":ME/TA converts GSM alphabet into current TE character set. b. if TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default
alphabet into two IRA character long hexadecimal number
4. if <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number.
<toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129)
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message body
<data> > (or <cdata>) in characte rs; or in PDU mode (+CMGF=0 ), the length of the actu al TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<mr> TP-Message-Reference in integer format.
Implementation
AT+CMGS="13012832788"<CR> (TEXT MODE) > ABCD<ctrl-Z/ESC> +CMGS: 46 OK
5.11 Send message from storage (AT+CMSS)
Description
The command is used to send message with location value <index> from preferred message storage
<mem2> to the network (SMS-SUBMIT or SMS-COMMAND).
Syntax
Test Command Response
AT+CMSS=? OK
Write Command Response
AT+CMSS=<index> [,<da>[,<toda>]]
Defined Values
<index> integer type, value in the range of location numbers supported by the associated memory. <da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>.
if text mode (+CMGF=1) and sending successful:
+CMSS: <mr> OK
if sending fails:
+CMS ERROR: <err>
SIM5210_ATC_V1.60 42 3/28/2008
SIM5210 AT Commands Set
<mr> TP-Message-Reference in integer format. <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129)
Implementation
AT+CMSS=3 +CMSS: 0 OK AT+CMSS=3,"13012832788" +CMSS: 55 OK
5.12 Write message to memory (AT+CMGW)
Description
The command is used to store message (either SMS-DELIVER or SMS-SUBMIT) to memory storage
<mem2>.
Syntax
Test Command Response
AT+CMGW=? OK
Write Command Response
if text mode(+CMGF=1):
AT+CMGW=<oa/da>[,<t ooa/toda>[,<stat>]]<CR>
text is entered
<ctrl-Z/ESC>
Defined Values
<index> integer type, value in the range of location numbers supported by the associated memory. <da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>.
<toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129)
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message body
<data> > (or <cdata>) in characte rs; or in PDU mode (+CMGF=0 ), the length of the actu al TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<stat>
a. Text Mode
"REC UNREAD" received unread message (i.e. new message) "REC READ" received read message "STO UNSENT" stored unsent message "STO SENT" stored sent message "ALL" all messages
b. PDU Mode
0 received unread message (i.e. new message) 1 received read message
+CMGW: <index> OK
+CMS ERROR: <err>
SIM5210_ATC_V1.60 43 3/28/2008
SIM5210 AT Commands Set
2 stored unsent message 3 stored sent message 4 all messages
Implementation
AT+CMGW="13012832788" <CR> (TEXT MODE) ABCD<ctrl-Z/ESC> +CMGW: 1 OK
5.13 Delete message (AT+CMGD)
Description
The command is used to delete message from preferred message storage <mem1> location <index>.
Syntax
Test Command Response
AT+CMGD=? +CMGD: (list of supported <index>s)[,(list of supported
<delflag>s)] OK
Write Command Response
AT+CMGD=<index> [,<delflag>]
OK
+CMS ERROR: <err>
Defined Values
<delflag>
0 (or omitted) Delete the message specified in <index> 1 Delete all read messages from preferred message storage, leaving unread messages and stored
mobile originated messages (whether sent or not) untouched.
2 Delete all read messages from preferred message storage and sent mobile originated messages,
leaving unread messages and unsent mobile originated messages untouched.
3 Delete all read messages from preferred message storage, sent and unsent mobile originated
messages leaving unread messages untouched.
4 Delete all messages from preferred message storage including unread messages.
Implementation
AT+CMGD=1 OK
5.14 Set text mode parameters (AT+CSMP)
Description
The command is used to select values for additional parameters needed when SM is sent to the network
or placed in storage when text format message mode is selected.
Syntax
Test Command Response
AT+CSMP=? OK
Read Command Response
SIM5210_ATC_V1.60 44 3/28/2008
SIM5210 AT Commands Set
AT+CSMP? +CSMP: <fo>,<vp>,<pid>,<dcs>
OK
Write Command Response
AT+CSMP=<fo>[,<
OK
vp>[,<pid>[,<dcs>]]]
Defined Values
<fo> depending on the command or result code: first octet of SMS-DELIVER, SMS-SUBMIT
(default 17), or SMS-COMMAND (default 2) in integer format.
<vp> depending on SMS-SUBMIT <fo> setting: TP-Validity-Period either in integer format (default
167), in time-string format, or if is supported, in enhanced format (hexadecimal coded string
with quotes). <pid> protocol-Identifier in integer format (default 0). <dcs> SMS Data Coding Scheme (default 0), or Cell Broadcast Data Coding Scheme in integer
format depending on the command or result code.
Implementation
AT+CSMP=17,23,64,244 OK
5.15 Read message only (AT+CMGRO)
Description
The command returns message with location value <index> from message storage <mem1> to the TE,
but the message’s status don’t change.
Syntax
Test Command Response
AT+CMGRO=? OK
Write Command Response
AT+CMGRO=<index>
if text mode (+CMGF=1), command successful and SMS­DELIVER:
+CMGRO: <stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>, <sca>,
<tosca>,<length>]<CR><LF><data> OK
if text mode (+CMGF=1), command successful and SMS­SUBMIT:
+CMGRO: <stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp>], <sca>, <tosca>,<length>]<CR><LF><data>
OK
if text mode (+CMGF=1), command successful and SMS-
SIM5210_ATC_V1.60 45 3/28/2008
SIM5210 AT Commands Set
STATUS-REPORT:
+CMGRO: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
OK
if text mode (+CMGF=1), command successful and SMS­COMMAND:
+CMGRO: <stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<length>
<CR><LF><cdata>] OK
if text mode (+CMGF=1), command successful and CBM storage:
+CMGRO: <stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data>
OK
if PDU mode (+CMGF=0) and command successful:
+CMGR: <stat>,[<alpha>],<length><CR><LF><pdu> OK
otherwise:
+CMS ERROR: <err>
Defined Values
<stat>
a. Text Mode
"REC UNREAD" received unread message (i.e. new message) "REC READ" received read message "STO UNSENT" stored unsent message "STO SENT" stored sent message "ALL" all messages
b. PDU Mode
0 received unread message (i.e. new message) 1 received read message 2 stored unsent message 3 stored sent message 4 all messages
<alpha> string type alphanumeric representation of <da> or <oa> corresponding to the entry found in
MT phonebook; implementation of this feature is manufacturer specific; used character set should be the one selected with command Select TE Character Set +CSCS.
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE character
SIM5210_ATC_V1.60 46 3/28/2008
SIM5210 AT Commands Set
set, type of address given by <toda>.
<data> In the case of SMS: TP-User-Data in text mode responses; format:
1 if <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that
TP-User-Data-Header-Indication is not set: a. if TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default
alphabet into two IRA character long hexadecimal number. (e.g. character Π (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55))
2 if <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number. (e.g. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65))
3. if <dcs> indicates that GSM 7 bit default alphabet is used: a. if TE character set other than "HEX":ME/TA converts GSM alphabet into current TE character set. b. if TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default
alphabet into two IRA character long hexadecimal number
4. if <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number.
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message body
<data> > (or <cdata>) in characte rs; or in PDU mode (+CMGF=0 ), the length of the actu al
TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length) <index> integer type, value in the range of location numbers supported by the associated memory <oa> Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE
character set, type of address given by <tooa> <pdu> In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts
each octet of TP data unit into two IRA character long hexadecimal number. (e.g. octet with
integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)) <scts> TP-Service-Centre-Time-Stamp in time-string format (refer <dt>) <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129) <tooa> TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>) <dcs> depending on the command or result code: SMS Data Coding Scheme (default 0), or Cell
Broadcast Data Coding Scheme in integer format.
<fo> depending on the command or result code: first octet of SMS-DELIVER, SMS-SUBMIT
(default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer format. <mid> CBM Message Identifier in integer format. <sca> RP SC address Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set,
type of address given by <tosca> <tosca> RP SC address Type-of-Address octet in integer format (default refer <toda>) <vp> depending on SMS-SUBMIT <fo> setting: TP-Validity-Period either in integer format
SIM5210_ATC_V1.60 47 3/28/2008
SIM5210 AT Commands Set
(default 167) or in time-string format (refer <dt>).
Implementation
AT+CMGRO=6 +CMGRO: "REC READ","+8613917787249",,"06/07/10,12:09:38+32", 145 ,4, 0,0 , "+8613800210500", 145,4 abcd OK
5.16 Change message status (AT+CMGMT)
Description
The command is used to change the message status. If the status is unread, it will be changed read.
Other statuses don’t change.
Syntax
Test Command Response
AT+CMGMT=? OK
Write Command Response
AT+CMGMT=<index> OK
+CMS ERROR: <err>
Defined Values
<index> integer type, value in the range of location numbers supported by the associated memory.
Implementation
AT+CMGMT=1 OK
5.17 Set message valid period (AT+CMVP)
Description
This command is used to set valid period for sending sms
Syntax
Defined Values
Implementation
Test Command Response
AT+CMVP=? OK
Read Command Response
AT+CMVP? +CMVP:<year>,<month>,<day>,<hour>,<minute>,<second>
OK
Write Command Response
AT+CMVP=<year>, [<month>],[<day>], [<hour>],[<minute>], [<second>]
<year>,<month>,<day>,<hour>,<minute>,<second> are decimals all.
AT+CMVP=1,1,25
OK
+CMS ERROR: <err>
SIM5210_ATC_V1.60 48 3/28/2008
SIM5210 AT Commands Set
OK AT+CMVP? +CMVP: "01-01-25-00-00-00" OK
5.18 Read and delete message (AT+CMGRD)
Description
The command is used to read message, and delete the message at the same time. It integrate +CMGR
and +DMGD, but it doesn’t change the message status.
Syntax
Test Command Response
AT+CMGRD=? OK
Write Command Response
AT+CMGRD=<index>
if text mode (+CMGF=1), command successful and SMS­DELIVER:
+CMGRD: <stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>, <sca>, <tosca>,<length>]<CR><LF><data>
OK
if text mode (+CMGF=1), command successful and SMS­SUBMIT:
+CMGRD: <stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp>], <sca>,
<tosca>,<length>]<CR><LF><data> OK
if text mode (+CMGF=1), command successful and SMS­STATUS-REPORT:
+CMGRD: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
OK
if text mode (+CMGF=1), command successful and SMS­COMMAND:
+CMGRD: <stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<length> <CR><LF><cdata>] OK
if text mode (+CMGF=1), command successful and CBM
SIM5210_ATC_V1.60 49 3/28/2008
SIM5210 AT Commands Set
storage:
+CMGRD: <stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data> OK
if PDU mode (+CMGF=0) and command successful:
+CMGR: <stat>,[<alpha>],<length><CR><LF><pdu> OK
otherwise:
+CMS ERROR: <err>
Defined Values
<stat>
a. Text Mode
"REC UNREAD" received unread message (i.e. new message) "REC READ" received read message "STO UNSENT" stored unsent message "STO SENT" stored sent message "ALL" all messages
b. PDU Mode
0 received unread message (i.e. new message) 1 received read message 2 stored unsent message 3 stored sent message 4 all messages
<alpha> string type alphanumeric representation of <da> or <oa> corresponding to the entry found in
MT phonebook; implementation of this feature is manufacturer specific; used character set should be the one selected with command Select TE Character Set +CSCS.
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>.
<data> In the case of SMS: TP-User-Data in text mode responses; format:
1 if <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that
TP-User-Data-Header-Indication is not set: a. if TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default
alphabet into two IRA character long hexadecimal number. (e.g. character Π (GSM 7 bit
default alphabet 23) is presented as 17 (IRA 49 and 55))
2 if <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number. (e.g. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65))
3. if <dcs> indicates that GSM 7 bit default alphabet is used:
SIM5210_ATC_V1.60 50 3/28/2008
SIM5210 AT Commands Set
a. if TE character set other than "HEX":ME/TA converts GSM alphabet into current TE character set. b. if TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default
alphabet into two IRA character long hexadecimal number
4. if <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number.
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message body
<data> > (or <cdata>) in characte rs; or in PDU mode (+CMGF=0 ), the length of the actu al
TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length) <index> integer type, value in the range of location numbers supported by the associated memory <oa> Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit
default alphabet characters) are converted to characters of the currently selected TE
character set, type of address given by <tooa> <pdu> In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts
each octet of TP data unit into two IRA character long hexadecimal number. (e.g. octet with
integer value 42 is presented to TE as two characters 2A (IRA 50 and 65)) <scts> TP-Service-Centre-Time-Stamp in time-string format (refer <dt>) <toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character of
<da> is + (IRA 43) default is 145, otherwise default is 129) <tooa> TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>) <dcs> depending on the command or result code: SMS Data Coding Scheme (default 0), or Cell
Broadcast Data Coding Scheme in integer format.
<fo> pending on the command or result code: first octet of SMS-DELIVER, SMS-SUBMIT
(default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer format. <mid> BM Message Identifier in integer format. <sca> PSC address Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set,
type of address given by <tosca> <tosca> RP SC address Type-of-Address octet in integer format (default refer <toda>) <vp> depending on SMS-SUBMIT <fo> setting: TP-Validity-Period either in integer format
(default 167) or in time-string format (refer <dt>).
Implementation
AT+CMGRD=6 +CMGRD: "REC READ","+8613917787249",,"06/07/10,12:09:38+32",145, 4,0,0 , "+8613800210500",145,4 abcd OK
5.19 Send message quickly (AT+CMGSO)
Description
The command is used to send message from a TE to the network (SMS-SUBMIT). But it’s different
from +CMGS. This command only need one time input, and wait for “>” needless.
Syntax
SIM5210_ATC_V1.60 51 3/28/2008
Test Command Response
SIM5210 AT Commands Set
AT+CMGSO=? OK
Write Command Response
If text mode (+CMGF=1):
AT+CMGSO=<da>[,<tod a>], <text>
If PDU mode (+CMGF=0):
AT+CMGSO=<length>, <pducontent>
if text mode (+CMGF=1) and sending successful:
+CMGSO: <mr> OK
if sending fails:
+CMS ERROR: <err>
Defined Values
<mr> TP-Message-Reference in integer format. <data> In the case of SMS: TP-User-Data in text mode responses; format:
1 if <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicates that
TP-User-Data-Header-Indication is not set: a. if TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. if TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit default
alphabet into two IRA character long hexadecimal number. (e.g. character Π (GSM 7 bit
default alphabet 23) is presented as 17 (IRA 49 and 55))
2 if <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number. (e.g. octet with integer value 42 is presented to TE as two characters 2A (IRA 50 and 65))
3. if <dcs> indicates that GSM 7 bit default alphabet is used: a. if TE character set other than "HEX":ME/TA converts GSM alphabet into current TE character set. b. if TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit default
alphabet into two IRA character long hexadecimal number
4. if <dcs> indicates that 8-bit or UCS2 data coding scheme is used: ME/TA converts each 8-bit octet into two IRA character long hexadecimal number.
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message
body <data> > (or <cdata>) in characters; or in PDU mode (+CMGF=0), the length of the actual TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character
of <da> is + (IRA 43) default is 145, otherwise default is 129) <text> content of message <pducontent> content of message
Implementation
AT+CMGSO="10086","YECX" +CMGSO: 128 OK
5.20 Write message to memory quickly (AT+CMGWO)
Description
SIM5210_ATC_V1.60 52 3/28/2008
SIM5210 AT Commands Set
The command stores message (either SMS-DELIVER or SMS-SUBMIT) to memory storage <mem2>.
But it’s different from +CMGW. This command only need one time input, and wait for “>” needless.
Syntax
Test Command Response
AT+CMGWO=? OK
Write Command Response
if text mode (+CMGF=1):
AT+CMGWO=<da> [,<toda>],<text>
if PDU mode (+CMGF=0):
+CMGWO: <index> OK
+CMS ERROR: <err>
AT+CMGWO=<length>, <pducontent>
Defined Values
<index> integer type, value in the range of location numbers supported by the associated
memory
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7
bit default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>.
<toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character
of <da> is + (IRA 43) default is 145, otherwise default is 129) <text> content of message <pducontent> content of message
Implementation
AT+CMGWO="13012832788","ABCD" +CMGWO: 1 OK
5.21 Set message storage full on PC (AT+PCFULL)
Description
The command used to set message storage full on PC. This command is for PC private, the message only store in SIM or PC.
Syntax
Defined Values
SIM5210_ATC_V1.60 53 3/28/2008
Test Command Response
AT+PCFULL=? OK
Read Command Response
AT+PCFULL? +PCFULL: <arg>
OK
Write Command Response
AT+PCFULL=<arg> OK
ERROR
<arg>
SIM5210 AT Commands Set
0 unfilled 1 full
Implementation
AT+PCFULL=1 OK
5.22 Send message when register on network (AT+CSETSMS)
Description
The command is used to set a short message. It will be send when register on network.
Syntax
Defined Values
Implementation
Test Command Response
AT+CSETSMS=? OK
Write Command Response
if text mode (+CMGF=1):
AT+CSETSMS=<da> [,<toda>],<text>
OK
ERROR
if PDU mode(+CMGF=0):
AT+CSETSMS=<length>, <pducontent>
<da> Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7
bit default alphabet characters) are converted to characters of the currently selected TE character set, type of address given by <toda>.
<length> integer type value indicating in the text mode (+CMGF=1) the length of the message
body <data> > (or <cdata>) in characters; or in PDU mode (+CMGF=0), the length of the actual TP data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<toda> TP-Destination-Address, Type-of-Address octet in integer format. (when first character
of <da> is + (IRA 43) default is 145, otherwise default is 129) <text> content of message <pducontent> content of message
AT+CSETSMS="13012832788","ABCD" OK
SIM5210_ATC_V1.60 54 3/28/2008
SIM5210 AT Commands Set
6 Network Service Related Commands
6.1 Subscriber number (AT+CNUM)
Description
Execution command returns the MSISDNs related to the subscriber (this information can be stored in
the SIM or in the ME). If subscriber has different MSISDN for different services, each MSISDN is returned in a separate line.
Syntax
Test Command Response
AT+CNUM=? OK
Execution Command Response
AT+CNUM +CNUM: [<alpha 1>],<number1>,<type1>
[<CR><LF>+CNUM: [<alpha2>], <number2>,<type2> [...]] OK
+CME ERROR: <err>
Defined values
<alphax> optional alphanumeric string associated with <numberx>; used character set should be
the one selected with command Select TE Character Set +CSCS. <numberx> string type phone number of format specified by <typex>. <typex> type of address octet in integer format.
Implementation
AT+CNUM +CNUM: ,"13697252277",129 OK
6.2 Network registration (AT+CREG)
Description
Write command controls the presentation of an un soli cite d result c ode +CR EG: < stat> when <n >=1 and
there is a change in the ME network registration status.
Read command returns the status of result code presentation and an integer <stat> which shows whether
the network has currently indicated the registration of the ME.
Syntax
Test Command Response
AT+CREG=? +CREG: (list of supported <n>s)
OK
Read Command Response
AT+CREG? +CREG: <n>,<stat>
OK
+CME ERROR: <err>
SIM5210_ATC_V1.60 55 3/28/2008
SIM5210 AT Commands Set
Write Command Response
AT+CREG =<n> OK
Execution Command Response AT+CREG
Defined values
<n>
0 disable network registration unsolicited result code 1 enable network registration unsolicited result code +CREG: <stat>
<stat>
0 not registered, ME is not currently searching a new operator to register to 1 registered, home network 2 not registered, but ME is currently searching a new operator to register to 3 registration denied 4 unknown 5 registered, roaming
Implementation
AT+CREG? +CREG: 0,1 OK
set default value
OK
<n>=0)
6.3 Operator selection (AT+COPS)
Description
Write command forces an attempt to select and register the GSM/UMTS network operator. <mode> is
used to select whether the selection is done automatically by the ME or is forced by this command to operator <oper> (it shall be given in format <format>). If the selected operator is not available, no other operator shall be selected (except <mode>=4). The selected operator name format shall apply to further read commands (+COPS?) also. <mode>=2 forces an attempt to deregister from the network. The selected mode affects to all further network registration (e.g. after <mode>=2, ME shall be unregistered until <mode>=0 or 1 is selected).
Read command returns the current mode and the currently selected operator. If no operator is selected,
<format> and <oper> are omitted.
Test command returns a list of quadruplets, each representing an operator present in the network.
Quadruplet consists of an integer indicating the availability of the operator <stat>, long and short alphanumeric format of the name of the operator, and numeric format representation of the operator. Any of the formats may be unavailable and should then be an empty field. The list of operators shall be in order: home network, networks referenced in SIM, and other networks.
It is recommended (although optional) that after the operator list TA returns lists of supported <mode>s
and <format>s. These lists shall be delimited from the operator list by two commas.
Syntax
Test Command Response
AT+COPS=? +COPS: [list of supported (<stat>,long alphanumeric <oper>
,short alphanumeric <oper>,numeric <oper>[,< AcT>])s] [,(list of supported <mode>s),(list of supported <format>s)]
SIM5210_ATC_V1.60 56 3/28/2008
SIM5210 AT Commands Set
OK
+CME ERROR: <err>
Read Command Response
AT+COPS?
Write Command Response
AT+COPS=<mode> [,<format>[,<oper>[, < AcT>]]]
Execution Command Response AT+COPS OK
Defined values
+COPS: <mode>[,<format>,<oper>[,< AcT>]] OK
+CME ERROR: <err>
OK
+CME ERROR: <err>
ERROR
<mode>
0 automatic (default) 1 manual 2 force deregister 3 set only <format> 4 manual/automatic
<format>
0 long format alphanumeric <oper> 1 short format alphanumeric <oper>
2 numeric <oper> <oper> string type, <format> indicates if the format is alphanumeric or numeric. <stat>
0 unknown
1 available
2 current
3 forbidden <AcT> access technology selected
0 GSM
1 GSM Compact
2 UTRAN
Implementation
AT+COPS? +COPS: 0,0,"China Mobile Com",0 OK AT+COPS=? +COPS: (2,"China Unicom","Unicom","46001",0),(3,"China Mobile Com","DGT MPT","46
SIM5210_ATC_V1.60 57 3/28/2008
SIM5210 AT Commands Set
000",0),,(0,1,2,3,4),(0,1,2) OK
6.4 Facility lock (AT+CLCK)
Description
The command is used to lock, unlock or interrogate a ME or a network facility <fac>. Password is
normally needed to do such actions. When querying the status of a network service (<mode>=2) the response line for 'not active' case (<status>=0) should be returned only if service is not active for any <class>.
Syntax
Test Command Response
AT+CLCK=? +CLCK: (list of supported <fac>s)
OK
+CME ERROR: <err>
Write Command Response
AT+CLCK=<fac>,<mo de> [,<passwd>[,<class>]]
+CME ERROR: <err>
when <mode>=2 and command successful:
+CLCK: <status>[,<class1> [<CR><LF>+CLCK: <status>,<class2> [...]] OK
Defined values
<fac>
"PF" lock Phone to the very First inserted SIM card or USIM card "SC" lock SIM ca rd or USIM card "AO" Barr All Outgoing Calls "OI" Barr Outgoing International Calls "OX" Barr Outgoing International Calls except to Home Country "AI" Barr All Incoming Calls "IR" Barr Incoming Calls when roaming outside the home country "AB" All Barring services "AG" All outGoing barring services "AC" All inComing barring services "FD" SIM fixed dialing memory feature "PN" Network Personalization "PU" network subset Personalization "PP" service Provider Personalization "PC" Corporate Personalization
<mode>
0 unlock
1 lock
SIM5210_ATC_V1.60 58 3/28/2008
SIM5210 AT Commands Set
2 query status <status>
0 not active
1 active <passwd> password.
Implementation
AT+CLCK="SC",2 +CLCK: 0 OK
6.5 Change password (AT+CPWD)
Description
Write command sets a new password for the facility lock function defined by command Facility Lock
+CLCK.
Test command returns a list of pairs which present the available facilities and the maximum length of
their password.
Syntax
Test Command Response
AT+CPWD=? +CPWD: (list of supported (<fac>,<pwdlength>)s)
OK
+CME ERROR: <err>
Write Command Response
AT+CPWD=<fac>, <oldpwd>,<newpwd >
OK
+CME ERROR: <err>
Defined values
<fac> refer Facility Lock +CLCK for other values
"SC" SIM or USIM PIN1
"P2" SIM or USIM PIN2
<oldpwd> shall be the same as password specified for the facility from the ME user interface or with
command Change Password +CPWD. String type.
<newpwd> is the new password; maximum length of password can be determined with <pwdlength>.
String type.
Implementation
AT+CPWD=? +CPWD: ("AB",4),("SC",8),("P2",8) OK
6.6 Calling line identification presentation (AT+CLIP)
Description
The command refers to the GSM/UMTS supplementary service CLIP (Calling Line Identification
Presentation) that enables a called subscriber to get the calling line identity (CLI) of the calling party when receiving a mobile terminated call.
SIM5210_ATC_V1.60 59 3/28/2008
SIM5210 AT Commands Set
Write command enables or disables the presentation of the CLI at the TE. It has no effect on the
execution of the supplementary service CLIP in the network.
When the presentation of the CLI at the TE is enabled (and calling subscriber allows), +CLIP:
<number>,<type>,,[,[<alpha>][,<CLI validity>]] response is returned after every RING (or +CRING: <type>; refer sub clause "Cellular result codes +CRC") result code sent from TA to TE. It is manufacturer specific if this response is used when normal voice call is answered.
Syntax
Test Command Response
AT+CLIP=? +CLIP: (list of supported <n>s)
OK
Read Command Response
AT+CLIP? +CLIP: <n>,<m>
OK
+CME ERROR: <err>
Write Command Response
AT+CLIP=<n> OK
Execution Command Response
AT+CLIP
set default value
<n>=0, <m>=0)
OK
Defined values
<n> (parameter sets/shows the result code presentation status in the TA)
0 disable 1 enable
<m>
0 CLIP not provisioned 1 CLIP provisioned
2 unknown (e.g. no network, et c.) <number> string type phone number of calling address in format specified ty <type> <type> type of address octet in integer format; 128 Restricted number type includes unknown type and format 145 International number type 129 Otherwise <alpha> string type alphanumeric representation of <number> corresponding to the entry found
in phone book
<CLI validity> 0 CLI valid
1 CLI has been withheld by the originator
2 CLI is not available due to interworking problems or limitations of originating
network
Implementation
AT+CLIP=1 OK RING (with incoming call)
SIM5210_ATC_V1.60 60 3/28/2008
SIM5210 AT Commands Set
+CLIP: "02152063113",128,,,"gongsi",0
6.7 Calling line identification restriction (AT+CLIR)
Description
The command refers to CLIR-service that allows a calling subscriber to enable or disable the
presentation of the CLI to the called party when originati ng a call .
Write command overrides the CLIR subscription (default is restricted or allowed) when temporary mode is provisioned as a default adjustment for all following outgoing calls. This adjustment can be revoked by using the opposite command.. If this command is used by a subscriber without provision of CLIR in permanent mode the network will act.
Read command gives the default adjustment for all outgoing calls (given in <n>), and also triggers an interrogation of the provision status of the CLIR service (given in <m>).
Test command returns values supported as a compound value.
Syntax:
Test Command Response
AT+CLIR =? +CLIR: (list of supported <n>s)
OK
Read Command Response
AT+CLIR? +CLIR: <n>,<m>
OK
+CME ERROR: <err>
Write Command Response
AT+CLIR =<n> OK
+CME ERROR: <err>
Defined values:
<n>
0 presentation indicator is used according to the subscription of the CLIR service 1 CLIR invocation 2 CLIR suppression
<m>
0 CLIR not provisioned 1 CLIR provisioned in permanent mode 2 unknown (e.g. no network, etc.) 3 CLIR temporary mode presentation restricted 4 CLIR temporary mode presentation allowed
Implementation:
AT+CLIR=?
+CLIR: (0-2)
OK
6.8 Connected line identification presentation (AT+COLP)
SIM5210_ATC_V1.60 61 3/28/2008
SIM5210 AT Commands Set
Description
The command refers to the GSM/UMTS supplementary service COLP (Connected Line Identification Presentation) that enables a calling subscriber to get the connected line identity (COL) of the called party after setting up a mobile originated call. The command enables or disables the presentation of the COL at the TE. It has no effect on the execution of the supplementary service COLR in the network.
When enabled (and called subscriber allows), +COLP:<number>, <type> [,<subaddr>, <satype> [,<alpha>]] intermediate result code is returned from TA to TE before any +CR responses.
Syntax
Test Command Response
AT+COLP=? +COLP: (list of supported <n>s)
OK
Read Command Response
AT+COLP? +COLP: <n>,<m>
OK
+CME ERROR: <err>
Write Command Response
AT+COLP =<n> OK
Execution Command Response AT+COLP
set default value (<n>=0, <m>=0)
OK
Defined values
<n> (parameter sets/shows the result code presentation status in the TA)
0 disable 1 enable
<m>
0 COLP not provisioned 1 COLP provisioned 2 unknown (e.g. no network, etc.)
Implementation
AT+COLP=1
OK
RING (with incoming call)
ATA (answer incoming call)
OK
+COLP: "02152063113",128,,,"gongsi"
6.9 Closed user group (AT+CCUG)
Description
The command allows control of the Closed User Group supplementary service. Set command enables the served subscriber to select a CUG index, to suppress the Outgoing Access (OA), and to suppress the preferential CUG.
Syntax
SIM5210_ATC_V1.60 62 3/28/2008
SIM5210 AT Commands Set
Test Command Response
AT+CCUG=? OK
Read Command Response
AT+CCUG? +CCUG: <n>,<index>,<info>
Write Command Response
AT+CCUG=<n> [,<index>[,<info>]]
Execution Command Response AT+CCUG
Defined values
<n>
0 disable CUG temporary mode 1 enable CUG temporary mode
<index>
0...9 CUG index 10 no index (preferred CUG taken from subscriber data)
<info>
0 no information 1 suppress OA 2 suppress preferential CUG 3 suppress OA and preferential CUG
Implementation
AT+CCUG?
+CCUG: 0,0,0
OK
OK
OK
set default value (<n>=0, <index>=0, <info>= 0)
OK
6.10 Call forwarding number and conditions (AT+CCFC)
Description
The command allows control of the call forwarding supplementary service. Registration, erasure, activation, deactivation, and status query are supported.
Syntax
Test Command Response
AT+CCFC=? +CCFC: (list of supported <reason>s)
OK
Write Command Response
AT+CCFC=<reason>, <mode>[,<number> [,<type>[,<class> [,<subaddr>[,<satype >[,<time> ]]]]]]
SIM5210_ATC_V1.60 63 3/28/2008
when <mode>=2 and command successful:
+CCFC: <status>,<class1>[,<number>,<type> [,<subaddr>,<satype>[,<time>]]][ <CR><LF>+CCFC: <status>,<class2>[,<number>,<type> [,<subaddr>,<satype>[,<time>]]][...]] OK
SIM5210 AT Commands Set
+CME ERROR: <err>
Defined values
<reason>
0 unconditional 1 mobile busy 2 no reply 3 not reachable 4 all call forwarding 5 all conditional call forwarding
<mode>
0 disable 1 enable 2 query status 3 registration
4 erasure <number> string type phone number of forwarding address in format specified by <type>. <type> type of address octet in integer forma; default 145 when dialing string includes
international access code character "+", otherwise 129. <subaddr> string type sub address of format specified by <satype>. <satype> type of sub address octet in integer format, default 128. <classx> is a sum of integers each representing a class of information (default 7):
1 voice (telephony) 2 data (refers to all bearer services) 4 fax (facsimile services) 8 short message service 16 data circuit sync 32 data circuit async 64 dedicated packet access 128 dedicated PAD access
<time>
1...30 when "no reply" is enabled or queried, this gives the time in seconds to wait before call is forwarded, default value 20.
<status>
0 not active 1 active
Implementation
AT+CCFC=? +CCFC: (0,1,2,3,4,5) OK AT+CCFC=0,2 +CCFC: 0,255 OK
SIM5210_ATC_V1.60 64 3/28/2008
SIM5210 AT Commands Set
6.11 Call waiting (AT+CCWA)
Description:
The command allows control of the Call Waiting supplementary service. Activation, deactivation and status query are supported. When querying the status of a network service (<mode>=2) the response line for 'not active' case (<status>=0) should be returned only if service is not active for any <class>. Parameter <n> is used to disable/enable the presentation of an unsolicited result code +CCWA: <number>,<type>,<class>,[<alpha>][,<CLI validity>] to the TE when call waiting service is enabled. Command should be abortable when network is interrogated.
Syntax:
Test Command Response
AT+CCWA=? +CCWA: (list of supported <n>s)
OK
Read Command Response
AT+CCWA? +CCWA: <n>
OK
Write Command Response
AT+CCWA=<n> [,<mode>[,<class>]]
Execution Command Response AT+CCWA
Defined values:
<n> (sets/shows the result code presentation status in the TA)
0 disable 1 enable
<mode> (when <mode> parameter is not given, network is not interrogated)
0 disable 1 enable 2 query status
<class> is a sum of integers each representing a class of information (default 7)
1 voice (telephony) 2 data (refers to all bearer services) 4 fax (facsimile services) 7 voice,data and fax(1+2+4) 8 short message service 16 data circuit sync 32 data circuit async 64 dedicated packet access 128 dedicated PAD access
+CME ERROR: <err>
when <mode>=2 and command successful
+CCWA: <status>,<class>[<CR><LF>+CCWA: <status>, <class>[...]]
OK
set default value (<n>=0)
OK
SIM5210_ATC_V1.60 65 3/28/2008
SIM5210 AT Commands Set
<status>
0 not active
1 active <number> string type phone number of calling address in format specified by <type>. <type> type of address octet in integer format; default 145 when dialing string includes
international access code character "+", otherwise 129.
<alpha> optional string type alphanumeric representation of <number> corresponding to the entry
found in phonebook; used character set should be the one selected with command Select TE Character Set +CSCS.
<CLI validity>
0 CLI valid
1 CLI has been withheld by the originator.
2 CLI is not available due to interworking problems or limitations of originating network.
Implementation:
AT+CCWA=? +CCWA: (0-1) OK AT+CCWA? +CCWA: 0 OK
6.12 Call related supplementary services (AT+CHLD)
Description
The command allows the control of the following call related services:
1. A call can be temporarily disconnected from the ME but the connection is retained by the network
2. Multiparty conversation (conference calls)
3. The served subscriber who has two calls (one held and the other either active or alerting) can connect
the other parties and release the served subscriber's own connection
Calls can be put on hold, recovered, released, added to conversation, and transferred.
Syntax
Test Command Response
AT+CHLD=? +CHLD: (list of supported <n>s)
OK
ERROR
Write Command Response
AT+CHLD=<n> OK
ERROR
Defined values
<n>:
0 Terminate all held calls; or set User Determined User Busy for a waiting call
1 Terminate all active calls and accept the other call (waiting call or held call)
1X Terminate the active call X
SIM5210_ATC_V1.60 66 3/28/2008
SIM5210 AT Commands Set
2 Place all active calls on hold and accept the other call (waiting call or held call) as the active
call 2X Place all active calls except call X on hold 3 Add the held call to the active calls 4 Connect two calls and cut off the connection between users and them simultaneously
Implementation
AT+CHLD=? +CHLD: (0,1,1x,2,2x,3,4) OK
6.13 Unstructured supplementary service data (AT+CUSD)
Description
The command allows control of the Unstructured Supplementary Service Data (USSD). Both network and mobile initiated operations are supported. Parameter <n> is used to disable/enable the presentation of an unsolicited result code (USSD response from the network, or network initiated operation) +CUSD: <m>[,<str>,<dcs>] to the TE. In addition, value <n>=2 is used to cancel an ongoing USSD session.
Syntax
Test Command Response
AT+CUSD=? +CUSD: (list of supported <n>s)
OK
Read Command Response
AT+CUSD? +CUSD: <n>
OK
Write Command Response
AT+CUSD=<n> [,<str>[,<dcs>]]
Execution Command Response AT+CUSD
Defined values
<n>
0 disable the result code presentation in the TA 1 enable the result code presentation in the TA
2 cancel session (not applicable to read command response) <str> string type USSD-string <dcs> Cell Broadcast Data Coding Scheme in integer format (default 0) <m>
0 no further user action required (network initiated USSD-Notify, or no further information
needed after mobile initiated operation)
1 further user action required (network initiated USSD-Request, or further information needed
after mobile initiated operation)
2 USSD terminated by network
OK
ERROR
set default value (<n>=0)
OK
SIM5210_ATC_V1.60 67 3/28/2008
SIM5210 AT Commands Set
4 operation not supported
5 network time out
Implementation
AT+CUSD? +CUSD: 1 OK AT+CUSD=0 OK
6.14 Advice of charge (AT+CAOC)
Description
The refers to Advice of Charge supplementary service that enables subscriber to get information about
the cost of calls. With <mode>=0, the execute command returns the current call meter value from the ME.
The command also includes the possibility to enable an unsolicited event reporting of the CCM
information. The unsolicited result code +CCCM: <ccm> is sent when the CCM value changes, but not more that every 10 seconds. Deactivation of the unsolicited event reporting is made with the same command.
Syntax:
Test Command Response
AT+CAOC=? +CAOC: (list of supported <mode>s)
OK
Read Command Response
AT+CAOC? +CAOC: <mode>
OK
Write Command Response
AT+CAOC=<mode> +CAOC: <ccm>
OK
ERROR
Execution Command Response AT+ CAOC
Defined values
<mode>:
0 query CCM value
1 deactivate the unsolicited reporting of CCM value
2 activate the unsolicited reporting of CCM value <ccm> string type, three bytes of the current call meter value in hexadecimal format (e.g. "00001E"
indicates decimal value 30), value is in home units and bytes are similarly coded as ACMmax value in the SIM.
Implementation:
AT+CAOC=0 +CAOC: "000000" OK
set default value (<mode>=1)
OK
SIM5210_ATC_V1.60 68 3/28/2008
SIM5210 AT Commands Set
6.15 Supplementary service notifications (AT+CSSN)
Description
The command refers to supplementary service related network initiated notifications. The set command
enables/disables the presentation of notification result codes from TA to TE.
When <n>=1 and a supplementary service notification is received after a mobile originated call setup,
intermediate result code +CSSI: <code1>[,<index>] is sent to TE before any other MO call setup result codes presented in the present document. When several different <code1>s are received from the network, each of them shall have its own +CSSI result code.
When <m>=1 and a supplementary service notification is received during a mobile terminated call
setup or during a call, or when a forward check supplementary service notification is received, unsolicited result code +CSSU: <code2>[,<index>[,<number>,<type>[,<subaddr>,<satype>]]] is sent to TE. In case of MT call setup, result code is sent after every +CLIP result code (refer command "Calling line identification presentation +CLIP") and when several different <code2>s are received from the network, each of them shall have its own +CSSU result code.
Syntax
Test Command Response
AT+CSSN=? +CSSN: (list of supported <n>s),(list of supported <m>s)
OK
Read Command Response
AT+CSSN? +CSSN: <n>,<m>
OK
Write Command Response
AT+CSSN=<n>[,<m>] OK
ERROR
Defined values
<n> (parameter sets/shows the +CSSI result code presentation status in the TA)
0 disable
1 enable <m> (parameter sets/shows the +CSSU result code presentation status in the TA)
0 disable
1 enable <code1> (it is manufacturer specific, which of these codes are supported)
0 unconditional call forwarding is active
1 some of the conditional call forwarding are active
2 call has been forwarded
3 call is waiting
4 this is a CUG call (also <index> present)
5 outgoing calls are barred
6 incoming calls are barred
7 CLIR suppression rejected
8 call has been deflected <index> refer "Closed user group +CCUG"
SIM5210_ATC_V1.60 69 3/28/2008
SIM5210 AT Commands Set
<code2> (it is manufacturer specific, which of these codes are supported)
0 this is a forwarded call (MT call setup)
1 this is a CUG call (also <index> present) (MT call setup)
2 call has been put on hold (during a voice call)
3 call has been retrieved (during a voice call)
4 multiparty call entered (during a voice call)
5 call on hold has been released (this is not a SS notification) (during a voice call)
6 forward check SS message received (can be received whenever)
7 call is being connected (alerting) with the remote party in alerting state in explicit call transfer
operation (during a voice call)
8 call has been connected with the other remote party in explicit call transfer operation (also
number and sub address parameters may be present) (during a voice call or MT call setup)
9 this is a deflected call (MT call setup) <number> string type phone number of format specified by <type>. <type> type of address octet in integer format; default 145 when dialing string includes
international access code character "+", otherwise 129. <subaddr> string type sub address of format specified by <satype>. <satype> type of sub address octet in integer format, default 128.
Implementation
AT+CSSN=1,1 OK AT+CSSN? +CSSN: 1,1 OK
6.16 List current calls (AT+CLCC)
Description
Return list of current calls of ME. If command succeeds but no calls are available, no information
response is sent to TE.
Syntax
Test Command Response
AT+CLCC=? OK
Execution Command Response AT+CLCC +CLCC: <id1>,<dir>,<stat>,<mode>,<mpty>[,
<number>,<type>[,<alpha>]] [<CR><LF>+CLCC: <id2>,<dir>,<stat>,<mode>,<mpty>[, <number>,<type>[,<alpha>]] [...]] OK
+CME ERROR: <err>
Defined values
<idx> integer type, call identification number, this number can be used in +CHLD command
operations.
SIM5210_ATC_V1.60 70 3/28/2008
SIM5210 AT Commands Set
<dir>
0 mobile originated (MO) call 1 mobile terminated (MT) call
<stat> (state of the call)
0 active 1 held 2 dialing (MO call) 3 alerting (MO call) 4 incoming (MT call) 5 waiting (MT call)
<mode> (bearer/teleservice)
0 voice 1 data 2 fax 9 unknown
<mpty>
0 call is not one of multiparty (conference) call parties
1 call is one of multiparty (conference) call parties <number> string type phone number in format specified by <type>. <type> type of address octet in integer format, default 145 when dialing string includes
international access code character "+", otherwise 129.
<alpha> string type alphanumeric representation of <number> corresponding to the entry found in
phonebook; used character set should be the one selected with command Select TE Character Set +CSCS.
Implementation
ATD10011; OK AT+CLCC +CLCC: 1,0,0,0,0,"10011",129,"sm" OK RING (with incoming call) AT+CLCC +CLCC: 1,1,4,0,0,"02152063113",128,"gongsi" OK
6.17 Preferred operator list (AT+CPOL)
Description
The command is used to edit the SIM preferred list of networks.
Syntax
Test Command Response
AT+CPOL=? +CPOL: (list of supported <index>s), (list of supported
<format>s) OK
SIM5210_ATC_V1.60 71 3/28/2008
SIM5210 AT Commands Set
+CME ERROR: <err>
Read Command Response
AT+CPOL? +CPOL: <index1>,<format>,<oper1>
[<CR><LF>+CPOL: <index2>,<format>,<oper2> [...]] OK
+CME ERROR: <err>
Write Command Response
AT+CPOL=<index> [, <format>[,<oper>]]
OK
+CME ERROR: <err>
Defined values
<indexn> integer type, the order number of operator in the SIM preferred operator list. <format>
0 long format alphanumeric <oper>
1 short format alphanumeric <oper>
2 numeric <oper> <oper> string type.
Implementation
AT+CPOL? +CPOL: 1,"46001" OK AT+CPOL=? +CPOL: (1-10),(0-2) OK
6.18 Read operator names (AT+COPN)
Description
Execute command returns the list of operator names from the ME. Each operator code <numericn> that
has an alphanumeric equivalent <alphan> in the ME memory shall be returned.
Syntax
Test Command Response
AT+COPN=? OK
Execution Command Response AT+COPN +COPN: <numeric1>,<alpha1>
[<CR><LF>+COPN: <numeric2>,<alpha2> [...]] OK
+CME ERROR: <err>
Defined values
<numericn> string type, operator in numeric format (see +COPS).
SIM5210_ATC_V1.60 72 3/28/2008
SIM5210 AT Commands Set
<alphan> string type, operator in long alphanumeric format (see +COPS).
Implementation
AT+COPN +COPN: "46000","China Mobile Com" +COPN: "46001"," China Unicom" …… OK
6.19 Preferred mode selection (AT+CNMP)
Description
The command is used to select or set the state of the mode preference.
Syntax
Test Command Response
AT+CNMP=? +CNMP: (list of supported <mode>s)
OK
Read Command Response
AT+CNMP? +CNMP: <mode>
OK
Write Command Response
AT+CNMP=<mode> OK
Defined values
<mode>
1 Dig ital Only 2 Automatic 3 Emergency Call Only 13 GSM Only 14 WCDMA Only
Implementation
AT+CNMP=13 OK AT+CNMP? +CNMP: 2 OK
6.20 Preferred band selection (AT+CNBP)
Description
The command is used to select or set the state of the band preference.
Syntax
Read Command Response
AT+CNBP? +CNBP: <mode>
OK
Write Command Response
AT+CNBP=<mode> OK
SIM5210_ATC_V1.60 73 3/28/2008
SIM5210 AT Commands Set
ERROR
Defined values
<mode> 64bit number, the value is “1” << “<pos>” , then or by bit <pos> value:
0xFFFFFFFF7FFFFFFF Any (any value 7 GSM_DCS_1800 8 GSM_EGSM_900 9 GSM_PGSM_900 16 GSM_450 17 GSM_480 18 GSM_750 19 GSM_850 20 GSM_RGSM_900 21 GSM_PCS_1900 22 WCDMA_IMT_2000 23 WCDMA_PCS_1900 24 WCDMA_III_1700 25 WCDMA_IV_1700 26 WCDMA_850 27 WCDMA_800 48 WCDMA_VII_2600 49 WCDMA_VIII_900 50 WCDMA_IX_1700
Implementation
AT+CNBP=0x000700000FFF0380 OK AT+CNBP? +CNBP: 0xFFFFFFFF3FFFFFFF OK
6.21 Acquisitions order preference (AT+CNAOP)
Description
Write command resets the state of acquisitions order preference.
Syntax
Test Command Response
AT+CNAOP=? +CNAOP: (list of supported <mode>s)
OK
Read Command Response
AT+CNAOP? +CNAOP: <mode>
OK Write Command Response AT+CNAOP=<mode> OK
SIM5210_ATC_V1.60 74 3/28/2008
SIM5210 AT Commands Set
ERROR
Defined values
<mode>
0 Automatic 1 GSM,WCDMA 2 WCDMA,GSM
Implementation
AT+CNAOP=1 OK AT+CNAOP? +CNAOP: 2 OK
6.22 Preferred service domain selection (AT+CNSDP)
Description
Write command resets the state of the service domain preference.
Syntax
Test Command Response
AT+CNSDP=? +CNSDP: (list of supported <mode>s)
OK
Read Command Response
AT+CNSDP? +CNSDP: <mode>
OK
Write Command Response
AT+CNSDP=<mode> OK
ERROR
Defined values
<mode>
0 CS Only 1 PS Only 2 CS+PS
Implementation
AT+CNSDP=2 OK AT+CNSDP? +CNSDP: 0 OK
6.23 Inquiring UE system information (AT+CPSI)
Description
The command returns the UE system information; currently show the information of GSM only.
SIM5210_ATC_V1.60 75 3/28/2008
SIM5210 AT Commands Set
Syntax
Test Command Response
AT+CPSI=? +CPSI: (scope of <time>)
OK
Read Command Response
AT+CPSI? +CPSI: <System Mode>, <Operation Mode>, <Location Area
ID>,<Cell ID>,<Absolute RF Ch Num>, <RX Level>, <Track LO Adjust>,<C1-C2> OK
Write Command Response
AT+CPSI=<time> OK
ERROR
Defined values
<time> the range is 0-255, unit is second, after set <time> will report the system
information every the seconds. <System Mode> system mode, values: “NO SERVICE”, “GSM” or “WCDMA”. <Operation Mode> UE operation mode, values: “Online”, “Factory Test Mode”, “Reset”,
“Low Power Mode” <Location Area ID> LAI for service-cell, using the format of Hex or empty if PLMN is
undefined. <Cell ID> service-cell ID of GSM. <Absolute RF Ch Num> AFRCN for service-cell. <RX Level> RX level <Track LO Adjust> Track LO Adjust
Implementation
AT+CPSI? +CPSI: GSM,Online,460-00 0x182d,12401,27 EGSM 900,-64,2110,42-42 OK AT+CPSI=? +CPSI: (0-255) OK
6.24 Show network system mode (AT+CNSMOD)
Description
The command returns the current network system mode.
Syntax
Test Command Response
AT+CNSMOD=? +CNSMOD: (list of supported <n>s)
OK
Read Command Response
AT+CNSMOD? +CNSMOD: <n>,<stat>
OK
SIM5210_ATC_V1.60 76 3/28/2008
SIM5210 AT Commands Set
Write Command Response
AT+CNSMOD=<n> OK
Defined values
<n>
0 disable auto report the network system mode information 1 auto report the network system mode information, command: +CNSMOD:<stat>
<state>
0 no service 1 GSM 2 GPRS 3 EGPRS(EDGE) 4 WCDMA 5 HSDPA
Implementation
AT+CNSMOD? +CNSMOD: 0,2 OK
+CME ERROR: <err>
ERROR
SIM5210_ATC_V1.60 77 3/28/2008
SIM5210 AT Commands Set
7 Mobile Equipment Control and Status Commands
7.1 Phone activity status (AT+CPAS)
Description
Execution command returns the activity status <pas> of the ME. It can be used to interrogate the ME
before requesting action from the phone.
Syntax
Test Command Response
AT+CPAS=? +CPAS: (list of supported <pas>s)
OK
+CME ERROR: <err>
Execution Command Response
AT+CPAS +CPAS: <pas>
OK
+CME ERROR: <err>
Defined values
<pas>
0 ready (ME allows commands from TA/TE) 1 unavailable (ME does not allow commands from TA/TE) 2 unknown (ME is not guaranteed to respond to instructions) 3 ringing (ME is ready for commands from TA/TE, but the ringer is active) 4 call in progress (ME is ready for commands from TA/TE, but a call is in progress) 5 asleep (ME is unable to process commands from TA/TE because it is in a low functionality
state)
Implementation
RING (with incoming call) AT+CPAS +CPAS: 3 OK AT+CPAS=? +CPAS: (0,3,4) OK
7.2 Set phone functionality (AT+CFUN)
Description
The command selects the level of functionality <fun> in the ME. Level "full functionality" is where the
highest level of power is drawn. "Minimum functionality" is where minimum power is drawn. Level of functionality between these may also be specified by manufacturers. When supported by manufacturers, ME resetting with <rst> parameter may be utilized.
NOTE: Use AT+CFUN=6 after AT+CFUN=7.
SIM5210_ATC_V1.60 78 3/28/2008
SIM5210 AT Commands Set
Syntax
Test Command Response
AT+CFUN=? +CFUN: (list of supported <fun>s), (list of supported <rst>s)
Read Command Response
AT+CFUN? +CFUN: <fun>
Write Command Response
AT+CFUN=[<fun>[,<rst >]]
Defined values
<fun>
0 minimum functionality 1 full functionality, online mode 4 disable phone both transmit and receive RF circuits 5 Factory Test Mode 6 Reset 7 Offline Mode
<rst>
0 do not reset the ME before setting it to <fun> power level 1 reset the ME before setting it to <fun> power level
Implementation
AT+CFUN? +CFUN: 1 OK AT+CFUN=0 OK
OK
+CME ERROR: <err>
OK
+CME ERROR: <err>
OK
+CME ERROR: <err>
7.3 Enter PIN (AT+CPIN)
Description
The command sends to the ME a password which is necessary before it can be operated (SIM PIN, SIM
PUK, PH-SIM PIN, etc.). If the PIN is to be entered twice, the TA shall automatically repeat the PIN. If no PIN request is pending, no action is taken towards MT and an error message, +CME ERROR, is returned to TE.
If the PIN required is SIM PUK or SIM PUK2, the second pin is required. This second pin, <newpin>,
is used to replace the old pin in the SIM.
Syntax
Test Command Response
SIM5210_ATC_V1.60 79 3/28/2008
SIM5210 AT Commands Set
AT+CPIN=? OK
Read Command Response
AT+CPIN? +CPIN: <code>
OK
+CME ERROR: <err>
Write Command Response
AT+CPIN=<pin>[,<new pin>]
OK
+CME ERROR: <err>
Defined values
<pin> string type values <newpin> string type values <code> values reserved by the present document:
READY ME is not pending for any password SIM PIN ME is waiting SIM PIN to be given SIM PUK ME is waiting SIM PUK to be given PH-SIM PIN ME is waiting phone-to-SIM card password to be given SIM PIN2 ME is waiting SIM PIN2 to be given SIM PUK2 ME is waiting SIM PUK2 to be given PH-NET PIN ME is waiting network personalization password to be given
Implementation
AT+CPIN? +CPIN: SIM PUK2 OK
7.4 Signal quality (AT+CSQ)
Description
Execution command returns received signal strength indication <rssi> and channel bit error rate <ber>
from the ME. Test command returns values supported by the TA as compound values.
Syntax
Test Command Response
AT+CSQ=? +CSQ: (list of supported <rssi>s),(list of supported <ber>s)
OK
Execute Command Response
AT+CSQ +CSQ: <rssi>,<ber>
OK
+CME ERROR: <err>
Defined values
<rssi>
0 -113 dBm or less 1 -111 dBm
SIM5210_ATC_V1.60 80 3/28/2008
SIM5210 AT Commands Set
2...30 -109... -53 dBm 31 -51 dBm or greater 99 not known or not detectable
<ber> (in percent)
0 <0.01% 1 0.01% --- 0.1% 2 0.1% --- 0.5% 3 0.5% --- 1.0% 4 1.0% --- 2.0% 5 2.0% --- 4.0% 6 4.0% --- 8.0% 7 >=8.0% 99 not known or not detectable
Implementation
AT+CSQ +CSQ: 22, 99 OK
7.5 Battery capacity query (AT+CBC)
Description
Execution command returns battery connection status <bcs> and battery charge level <bcl> of the ME.
Test command returns values supported by the TA as compound values.
Syntax
Test Command Response
AT+CBC=? +CBC: (list of supported <bcs>s),(list of supported <bcl>s)
OK
Execute Command Response
AT+CBC +CBC: <bcs>,<bcl>
OK
+CME ERROR: <err>
Defined values
<bcs>
0 ME is powered by the battery 1 ME has a battery connected, but is not powered by it 2 ME does not have a battery connected 3 Recognized power fault, calls inhibited
<bcl>
0 battery is exhausted, or ME does not have a battery connected
1...100 battery has 1-100 percent of capacity remaining
Implementation
AT+CBC +CBC: 0,100
SIM5210_ATC_V1.60 81 3/28/2008
SIM5210 AT Commands Set
OK
7.6 Mobile Equipment control mode (AT+CMEC)
Description
The command selects the equipment, which operates ME keypad, writes to ME display and sets ME
indicators. If operation mode is not allowed by the ME, +CME ERROR: <err> is returned.
Syntax
Test Command Response
AT+CMEC=? +CMEC: (list of supported <keyp>s),(list of supported
<disp>s),(list of supported <ind>s)
OK
Read Command Response
AT+CMEC? +CMEC: <keyp>,<disp>,<ind>
OK
Write Command Response
AT+CMEC=<keyp>[,<d isp>[,<ind>]]
Defined values
<keyp>
0 ME can be operated only through its keypad (execute command of +CKPD cannot be used) 1 ME can be operated only from TE (with command +CKPD)
2 ME can be operated from both ME keypad and TE <disp> default 0 <ind> default 0.
Implementation
AT+CMEC? +CMEC: 2,0,0 OK AT+CMEC=? +CMEC: (0- 2),(0),(0) OK
OK
+CME ERROR: <err>
7.7 Keypad control (AT+CKPD)
Description
The command emulates ME keypad by giving each keystroke as a character in a string <keys>.
Syntax
Test Command Response
AT+CKPD=? OK
Write Command Response
AT+CKPD=<keys>[,<ti me>[,<pause>]]
SIM5210_ATC_V1.60 82 3/28/2008
OK
+CME ERROR: <err>
SIM5210 AT Commands Set
Defined values
<keys> string of characters representing keys as listed in the following table
Char IRA (dec) Comment (+ some know n key symbo ls)
# 35 hash (number sign) % 37 percent sign (P) * 42 star (*)
0... 9 48... 57 number keys : 58 escape character for manufacturer specific keys ; 59 escape character for string entering < 60 left arrow > 62 right arrow @ 64 alpha key ( /ABC)  A/a 65/97 channel A (A) B/b 66/98 channel B (B) C/c 67/99 clear display (C/CLR) D/d 68/100 volume down E/e 69/101 connection end (END) F/f 70/102 function (FCN) L/l 76/108 phone lock (LOCK) M/m 77/109 menu (MENU) P/p 80/112 power (PWR) Q/q 81/113 quiet/mute (MUTE) R/r 82/114 recall last number (R/RCL/MR) S/s 83/115 connection start (SEND) T/t 84/116 store/ memory (STO/M/M+) U/u 85/117 volume up V/v 86/118 down arrow W/w 87/119 pause character X/x 88/120 auxiliary (AUX) Y/y 89/121 delete last character (C) [ 91 soft key 1 ] 93 soft key 2 ^ 94 up arrow
<time> 0…255 seconds(default values are manufacturer specific, but should be so long that a
normal ME can handle keystrokes correctly)
<pause> 0…255 seconds (default values are manufacturer specific, but should be so long that a
normal ME can handle keystrokes correctly)
Implementation
AT+CKPD=1234,,20 OK
7.8 Accumulated call meter (AT+CACM)
Description
SIM5210_ATC_V1.60 83 3/28/2008
SIM5210 AT Commands Set
The command resets the Advice of Charge related accumulated call meter value in SIM file EFACM.
Syntax
Test Command Response
AT+CACM=? OK
Read Command Response
AT+CACM? +CACM: <acm>
OK
+CME ERROR: <err>
Write Command Response
AT+CACM=<passwd> OK
+CME ERROR: <err>
Execute Command
AT+CACM +CME ERROR: <err>
Defined values
<passwd> string type, SIM PIN2. <acm> string type, accumulated call meter value similarly coded as <ccm> under +CAOC.
Implementation
AT+CACM? +CACM: "000000" OK
Response
7.9 Accumulated call meter maximum (AT+CAMM)
Description
The command sets the Advice of Charge related accumulated call meter maximum value in SIM file
EFACMmax.
Syntax
Test Command Response
AT+CAMM=? OK
Read Command Response
AT+CAMM? +CAMM: <acmmax>
OK
+CME ERROR: <err>
Write Command Response
AT+CAMM=<acmmax> [,<passwd>]
Defined values
<acmmax> string type, accumulated call meter maximum value similarly coded as <ccm> under
+CAOC, value zero disables ACMmax feature.
OK
+CME ERROR: <err>
SIM5210_ATC_V1.60 84 3/28/2008
SIM5210 AT Commands Set
<passwd> string type, SIM PIN2.
Implementation
AT+CAMM? +CAMM: "000000" OK
7.10 Price per unit and currency table (AT+CPUC)
Description
The command sets the parameters of Advice of Charge related price per unit and currency table in SIM
file EFPUCT.
Syntax
Test Command Response
AT+CPUC=? OK
Read Command Response
AT+CPUC? +CPUC: [<currency>,<ppu>]
OK
+CME ERROR: <err>
Write Command Response
AT+CPUC=<currency> ,<ppu>[,<passwd>]
Defined values
<currency> string type, three-character currency code (e.g. "GBP", "DEM"), character set as specified
by command Select TE Character Set +CSCS. <ppu> string type, price per unit, dot is used as a decimal separator. (e.g. "2.66") <passwd> string type, SIM PIN2.
Implementation
AT+CPUC? +CPUC: “GBP”,2.66 OK
OK
+CME ERROR: <err>
7.11 Control phone to power down (AT$QCPWRDN)
Description
The command controls the phone to power down.
Syntax
Execute Command Response
AT$QCPWRDN OK
ERROR
Defined values
None.
Implementation
SIM5210_ATC_V1.60 85 3/28/2008
SIM5210 AT Commands Set
AT$QCPWRDN OK
7.12 Report Mobile Equipment error (AT+CMEE)
Description
The command disables or enables the use of result code +CME ERROR: <err> as an indication of an
error relating to the functionality of the ME.
Syntax
Test Command Response
AT+CMEE=? +CMEE: (list of supported <n>s)
OK
Read Command Response
AT+CMEE? +CMEE: <n>
OK
Write Command Response
AT+CMEE=<n> OK
ERROR
Execute Command Response
AT+CMEE OK
Defined values
<n>
0 disable +CME ERROR: <err> result code and use ERROR instead 1 enable +CME ERROR: <err> result code and use numeric <err> values (refer next subclause) 2 enable +CME ERROR: <err> result code and use verbose <err> values (refer next subclause)
Implementation
AT+CMEE? +CMEE: 2 OK AT+CPIN="1234","1234" +CME ERROR: incorrect password AT+CMEE=0 OK AT+CPIN="1234","1234" ERROR AT+CMEE=1 OK AT+CPIN="1234","1234" +CME ERROR: 16
ERROR
7.13 Mobile Equipment error result code (+CME ERROR)
SIM5210_ATC_V1.60 86 3/28/2008
SIM5210 AT Commands Set
Description
The operation of +CME ERROR: <err> result code is similar to the regular ERROR result code: if
+CME ERROR: <err> is the result code for any of the commands in a command line, none of the following commands in the same command line is executed (neither ERROR nor OK result code shall be returned as a result of a completed command line execution). The format of <err> can be either numeric or verbose. This is set with command +CMEE (refer previous subclause).
Syntax
+CME ERROR: <err>
Defined values
<err> values (numeric format followed by verbose format):
0 phone failure 1 no connection to phone 2 phone-adaptor link reserved 3 operation not allowed 4 operation not supported 5 PH-SIM PIN required 6 PH-FSIM PIN required 7 PH-FSIM PUK required 10 SIM not inserted 11 SIM PIN required 12 SIM PUK required 13 SIM failure 14 SIM busy 15 SIM wrong 16 incorrect password 17 SIM PIN2 required 18 SIM PUK2 required 20 memory full 21 invalid index 22 not found 23 memory failure 24 text string too long 25 invalid characters in text string 26 dial string too long 27 invalid characters in dial string 30 no network service 31 network timeout 32 network not allowed - emergency calls only 40 network personalization PIN required 41 network personalization PUK required 42 network subset personalization PIN required 43 network subset personalization PUK required 44 service provider personalization PIN required 45 service provider personalization PUK required
SIM5210_ATC_V1.60 87 3/28/2008
SIM5210 AT Commands Set
46 corporate personalization PIN required 47 corporate personalization PUK required 100 unknown 103 Illegal MS (#3) 106 Illegal ME (#6) 107 GPRS services not allowed (#7) 111 PLMN not allowed (#11) 112 Location area not allowed (#12) 113 Roaming not allowed in this location area (#13) 132 service option not supported (#32) 133 requested service option not subscribed (#33) 134 service option temporarily out of order (#34) 149 PDP authentication failure 150 invalid mobile class 148 unspecified GPRS error 151 VBS/VGCS not supported by the network 152 No service subscription on SIM 153 No subscription for group ID 154 Group Id not activated on SIM 155 No matching notification 156 VBS/VGCS call already present 157 Congestion 158 Network failure 159 Uplink busy 160 No access rights for SIM file 161 No subscription for priority 162 operation not applicable or not possible
Implementation
AT+CPIN="1234","1234" +CME ERROR: incorrect password
7.14 Switch device between UART & USB (AT+CUUSWITCH)
Description
Execution command causes module to switch AT command communication device between UART and
USB.
Syntax
Read Command Response
AT+CUUSWITCH? +CUUSWITCH: <arg>
OK
ERROR
Write Command Response
SIM5210_ATC_V1.60 88 3/28/2008
SIM5210 AT Commands Set
AT+CUUSWITCH=<ar g>
Defined values
OK
ERROR
<arg>
0 UART device 1 USB device (default)
Implementation
AT+CUUSWITCH? +CUUSWITCH: 1 OK
7.15 Set CSQ report (AT+AUTOCSQ)
Description
The command causes the module to disable and enable auto report CSQ information, if we enable auto
report, the module reports CSQ information every five seconds, the format of report is +CSQ: <rssi>,<ber>. 0 for default.
Syntax
Test Command Response
AT+AUTOCSQ=? +AUTOCSQ: (list of supported <arg>s)
OK
Read Command Response
AT+AUTOCSQ? +AUTOCSQ: <arg>
OK
Write Command Response
AT+AUTOCSQ=<arg> OK
ERROR
Defined values
<arg>
0 disable auto report 1 enable auto report
Implementation
AT+AUTOCSQ=1 OK +CSQ: 23,99
7.16 Low voltage Alarm (AT+CVALARM)
Description
Open or close the low voltage alarm function. 0 for default.
Syntax
Test Command Response
AT+CVALARM = ? +CVALARM: (list of supported < enable>s)
SIM5210_ATC_V1.60 89 3/28/2008
SIM5210 AT Commands Set
Write Command Response
OK
AT+CVALARM=<ena ble>
Defined values
< enable>
0 Close
1 Open. If voltage<3.45V,every 20 seconds will report a string :
warning! Voltage is low:<voltage value>
Implementation
AT+ CVALARM =1 OK AT+ CVALARM = ? + CVALARM:(0,1) OK
OK
ERROR
7.17 Set Trigger mode of interrupt GPIO (AT+CGPIO)
Description
Set GPIO interrupt trigger mode.
Syntax
Write Command Response
AT+CGPIO=<detect>,< polarity>
Defined values
<detect>
0 LEVEL trigger mode 1 EDGE trigger mode
<polarity>
0 trigger when low level 1 trigger when high level
Implementation
AT+ CGPIO =1,1 OK
OK
ERROR
7.18 Read ICCID in SIM card (AT+CICCID)
Description
Read the ICCID in SIM card.
Syntax
Test Command Response
AT+CICCID=? OK
SIM5210_ATC_V1.60 90 3/28/2008
SIM5210 AT Commands Set
Write Command Response
AT+CICCID +ICCID:<ICCID>
OK
+CME ERROR: <err>
Defined values
<ICCID> Integrate circuit card identity, a standard ICCID is a 20-digit serial number of the SIM card it presents the publish state, network code, publish area, publish date, publish manufacture
and press serial number of the SIM card.
Implementation
AT+CICCID +ICCID: 898600700907A6019125 OK
7.19 Read values from register of IIC device (AT+CRIIC)
Description
Read values from register of IIC device.
Syntax
Test Command Response
AT+CRIIC=? OK
Write Command Response
AT+CRIIC=<addr><reg ><len>
Defined values
<addr> device address. Input format must be hex, such as 0xFF. <reg> register address. Input format must be hex, such as 0xFF. <len> read length. Range: 1-4; unit: byte <data> data read. Input format must be hex, such as 0xFF - 0xFFFFFFFF.
Implementation
AT+CRIIC=0x0F, 0x0F, 2 +CRIIC: 0xFFFF OK
+CRIIC: <data> OK
ERROR
7.20 Write values to register of IIC device (AT+CWIIC)
Description
Write values to register of IIC device.
Syntax
Test Command Response
AT+CWIIC=? OK
Write Command Response
SIM5210_ATC_V1.60 91 3/28/2008
SIM5210 AT Commands Set
AT+CWIIC=<addr><re g><data><len>
Defined values
<addr> device address. Input format must be hex, such as 0xFF. <reg> register address. Input format must be hex, such as 0xFF. <len> read length. Range: 1-4; unit: byte. <data> data written. Input format must be hex, such as 0xFF - 0xFFFFFFFF.
Implementation
AT+CWIIC=0x0F, 0x0F, 0x1234, 2 +CWIIC: 0x1234 OK
OK
ERROR
7.21 Switch between Windows & Linux system support (AT+COMSWITCH)
Description
The command is used to control the switch between Windows and Linux system support. If switch to
support Linux, the device is a standard modem device (CDC), for CDC device need no extra driver in Linux and Mac OS. It may need a reboot for data card or module to take effect.
NOTE: This command is used just under non-test mode. Refer command AT+CSWITCHTEST for test
mode.
Syntax
Write Command Response
AT+COMSWITCH=<ar g>
Read Command Response
AT+COMSWITCH? +COMSWITCH: <arg_status>
Defined values
<arg>
1 Linux Modem device 2 Windows Modem device
<arg_status>
3 Windows Modem state 4 Linux and Mac Modem state 5 switch Windows Modem to Linux Modem success state 6 switch Linux Modem to Windows Modem success state
Implementation
AT+COMSWITCH? +COMSWITCH: 5 OK
OK
ERROR
OK
7.22 Open or Close Test Mode (AT+CSWITCHTEST)
SIM5210_ATC_V1.60 92 3/28/2008
SIM5210 AT Commands Set
Description
The command is used to control the open or close of the test (download) mode. If openthe Diag port
could be used to download (update)software and parameter adjust. The module will reboot when using AT+CSWITCHTEST=1 to open the test mode.
Syntax
Write Command Response
AT+CSWITCHTEST=< arg>
+CSWITCHTEST: SUCCEED OK
+CSWITCHTEST: REPEAT OK
+CSWITCHTEST: FAIL OK
ERROR
Read Command Response
AT+CSWITCHTEST? +CSWITCHTEST: <arg>
Defined values
<arg>
0 Close test (download) mode 1 Open test (download) mode, default value after update.
Implementation
AT+CSWITCHTEST? +CSWITCHTEST: 1 OK AT+CSWITCHTEST=1 +CSWITCHTEST: REPEAT OK AT+CSWITCHTEST=0 +CSWITCHTEST: SUCCEED OK
OK
SIM5210_ATC_V1.60 93 3/28/2008
SIM5210 AT Commands Set
8 Phonebook Related Commands
All phonebook, the maximum length of the phone number is 20 digits, the range of the name length
depends on the SIM card.
8.1 Select phonebook memory storage (AT+CPBS)
Description
The command selects phonebook memory storage <storage>, which is used by other phonebook
commands. If setting fails, +CME ERROR: <err> is returned.
Syntax
Test Command Response
AT+CPBS=?
Read Command Response
AT+CPBS? +CPBS: <storage>[,<used>,<total>]]
+CPBS: (list of supported <storage>s) OK
OK
+CME ERROR: <err>
Write Command Response
AT+CPBS=<storage> OK
+CME ERROR: <err>
Defined values
<storage> values reserved by the present document:
"DC" ME dialed calls list "MC" ME missed (unanswered received) calls list "RC" ME received calls list "SM" SIM phonebook "ME" UE phonebook "FD" SIM fixdialling-phonebook "ON" MSISDN list "LD" Last number dialed phonebook
"EN" Emergency numbers <used> integer type value indicating the number of used locations in selected memory. <total> integer type value indicating the total number of locations in selected memory.
Implementation
AT+CPBS=? +CPBS: ("SM","DC","FD","LD","MC","ME","RC","EN","ON") OK AT+CPBS=”SM” OK
SIM5210_ATC_V1.60 94 3/28/2008
SIM5210 AT Commands Set
AT+CPBS? +CPBS: "SM",1,200 OK
8.2 Read phonebook entries (AT+CPBR)
Description
The command gets the record information from the selected memory storage in phonebook. if the
storage is selected as “SM” then the command will return the record in SIM phonebook, the same to others.
Syntax
Test Command Response
AT+CPBR=? +CPBR: (list of supported <index>s), [<nlength>],
[<tlength>] OK
+CME ERROR: <err>
Write Command Response
AT+CPBR=<index1> [,<index2>]
[+CPBR: <index1>,<number>,<type>,<text>[[...] <CR><LF>+CPBR: <index2>,<number>,<type>,<text>]] OK
+CME ERROR: <err>
Defined Values
<index1>, <index2>, <index>
integer type value in the range of location numbers of phonebook memory.
<number> string type, phone number of format <type>, the maximum length is < nlength >
<type> type of phone number octet in integer format, default 145 when dialing string includes
international access code character "+", otherwise 129. <text> string type field of maximum length <tlength>; Often this value is set as name <nlength> integer type value indicating the maximum length of field <number>. <tlength> integer type value indicating the maximum length of field <text>.
Implementation
AT+CPBS? +CPBS: "SM",2,200 OK
AT+CPBR=1,10
record information in SIM card) +CPBR: 1,"12345678901234567890",129,"Gjmjojggjmtpgj" +CPBR: 2,"0987654321",129,"zuohongyan" OK
AT+CPBS=”DC”
dialed calls information) OK AT+CPBR=1,10 +CPBR: 1,"10010",129,""
SIM5210_ATC_V1.60 95 3/28/2008
SIM5210 AT Commands Set
+CPBR: 2,"10010",129,"" +CPBR: 3,"10010",129,"" +CPBR: 4,"521",129,"" +CPBR: 5,"114",129,"" +CPBR: 6,"13918723549",129,"" +CPBR: 7,"10010",129,"" +CPBR: 8,"13918723549",129,"" +CPBR: 9,"13918723549",129,"" +CPBR: 10,"13918723549",129,"" OK
AT+ CPBS="MC"
missed calls information) OK AT+CPBR=1,10 +CPBR: 1,"13918723549",129,"" OK
AT+ CPBS="RC"
received calls information) OK AT+CPBR=1,10 +CPBR: 1,"02152063113",129,"" +CPBR: 2,"02152063113",129,"" +CPBR: 3,"13918723549",129,"" OK
8.3 Find phonebook entries (AT+CPBF)
Description
The command finds the record in phonebook(from the current phonebook memory storage selected
with +CPBS) which alphanumeric field has substring <findtext>.
Syntax
Test Command Response
AT+CPBF=? +CPBF: [<nlength>],[<tlength>]
OK
+CME ERROR: <err>
Write Command Response
AT+CPBF=<findtext> [+CPBF: <index1>,<number>,<type>,<text>[[...]
<CR><LF>+CBPF: <index2>,<number>,<type>,<text>]] OK
+CME ERROR: <err>
Defined values
<findtext> string type, this value is used to find the record. <index1>, <index2> integer type values in the range of location numbers of phonebook memory.
SIM5210_ATC_V1.60 96 3/28/2008
SIM5210 AT Commands Set
<number> string type, phone number of format <type>, the maximum length is
< nlength >
<type> type of phone number octet in integer format, default 145 when dialing string
includes international access code character "+", otherwise 129. <text> string type field of maximum length <tlength>; Often this value is set as name <nlength> integer type value indicating the maximum length of field <number>. <tlength> integer type value indicating the maximum length of field <text>.
Implementation
AT+CPBF="Gjmjo" +CPBF: 1,"12345678901234567890",129,"Gjmjojggjmtpgj" OK
8.4 Write phonebook entry (AT+CPBW)
Description
The command writes phonebook entry in location number <index> in the current phonebook memory
storage selected with +CPBS.
Syntax
Test Command Response
AT+CPBW=? +CPBW: (list of supported <index>s),[<nlength>],
(list of supported <type>s),[<tlength>] OK
+CME ERROR: <err>
Write Command Response
AT+CPBW=<index> [,<number>[,<type>[,<text
>]]]
OK
+CME ERROR: <err>
Defined values
<index> integer type value, appo inting the location where the entry stored . <number> string type, phone number of format <type>, the maximum length is < nlength >.
<type> type of phone number octet in integer format, default 145 when dialing string includes
international access code character "+", otherwise 129. <text> string type field of maximum length <tlength>; Often this value is set as name. <nlength> integer type value indicating the maximum length of field <number>. <tlength> integer type value indicating the maximum length of field <text>.
Implementation
AT+CPBW=2,"0987654321",129,"qwertyuiop" OK
SIM5210_ATC_V1.60 97 3/28/2008
SIM5210 AT Commands Set
9 V24-V25 Command
9.1 Set local baud rate temporarily (AT+IPR)
Description
The command sets the baud rate of module’s serial interface temporarily, after reboot the baud rate is
set to default.
Syntax
Test Command Response
AT+IPR=?
Read Command Response
AT+IPR?
Write Command Response
AT+IPR=<speed>
Defined values
<speed> Baud rate per second 300 600 1200 2400 4800 9600 19200 38400 57600 115200 230400 460800
Implementation
AT+IPR? +IPR: 115200 OK AT+IPR=? +IPR: (300,600,1200,2400,4800,9600,19200,38400,57600,115200,230400,460800) OK AT+IPR=115200
+IPR: (list of supported<speed>s) OK
+CME ERROR: <err>
+IPR: <speed> OK
+CME ERROR: <err>
OK
SIM5210_ATC_V1.60 98 3/28/2008
SIM5210 AT Commands Set
OK
9.2 Set local baud rate permanently (AT$QCTER)
Description
The command sets the baud rate of module’s serial interface permanently, after reboot the baud rate is
also valid.
Syntax
Test Command Response
AT$QCTER=?
Read Command Response
AT$QCTER?
Write Command Response
AT$QCTER=<speed>
Defined values
<speed> Baud rate per second 300 600 1200 2400 4800 9600 19200 38400 57600 115200 230400 460800
Implementation
AT$QCTER? $QCTER: 115200 OK AT$QCTER=? $QCTER: (300,600,1200,2400,4800,9600,19200,38400,57600,115200,230400,460800) OK AT$QCTER=115200 OK
$QCTER: (list of supported<speed>s) OK
+CME ERROR: <err>
$QCTER: <speed> OK
+CME ERROR: <err>
OK
9.3 Set control character framing (AT+ICF)
SIM5210_ATC_V1.60 99 3/28/2008
SIM5210 AT Commands Set
Description
The command sets character framing which contain data bit, stop bit and parity bit.
Syntax
Test Command Response
AT+ICF=?
+ICF: (list of supported<format>s), (list of supported<parity>s) OK
+CME ERROR: <err>
Read Command Response
AT+ICF?
+ICF: <format>,<parity> OK
+CME ERROR: <err>
Write Command Response
AT+ICF=<format>,<parit
OK
y>
Defined values
<format> (only support value “3” at moment)
0 auto detect 1 data bit 8, stop bit 2 2 data bit 8, stop bit 1, parity bit 1 3 data bit 8, stop bit 1 4 data bit 7, stop bit 2 5 data bit 7, stop bit 1, parity bit 1 6 data bit 7, stop bit 1
<parity>
0 Odd 1 Even 2 mark 3 none
Implementation
AT+ICF? +ICF: 3,3 OK AT+ICF=? +ICF: (3),(0-3) OK AT+ICF=3,3 OK
9.4 Set local data flow control (AT+IFC)
Description
SIM5210_ATC_V1.60 100 3/28/2008
