560W SDS Plus Hammer Drill
560W SDS Plus Hammer Drill
Marteau perforateur SDS-Plus 560 W
SDS-Plus-Bohrhammer, 560 W
www.silverlinetools.com
Taladro percutor SDS Plus 560 W
Martello perforatore SDS Plus 560 W
560 W SDS-Plus boorhamer
2
1
3
4
5
6
7
8
10
2
9
R
E
L
V
I
N
L
I
E
S
DIY
R
E
A
G
N
®
560W SDS Plus Hammer Drill
English .................. 4
Français ................ 8
Deutsch ................. 12
Español ................. 16
Italiano .................. 20
Nederlands ............ 24
www.silverlinetools.com
3
GB
Description of Symbols
The rating plate on your tool may show symbols. These represent important information
about the product or instructions on its use.
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Read instruction manual
Double insulated for additional protection
Conforms to relevant legislation and safety standards
Environmental Protection
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your local authority or
retailer for recycling advice
Specification
Voltage: ................................................................. 230V~ 50Hz
Power: .................................................................. 560W
No load speed: ...................................................... 0-1100min-1
Impact rate: .......................................................... 0-3900BPM
Impact energy: ...................................................... 1.5J
Safety Clutch (operates at or below): .................... 56Nm
Max drilling capacity:
- Concrete ............................................................ 20mm
- Wood .................................................................. 30mm
- Steel ................................................................... 13mm
Protection Class: ....................................................
Ingress Protection: ................................................ IP20
Power Cable Type: ................................................ H07RN-F
Weight: ................................................................. 2.3kg
As part of our ongoing product development, specifications of Silverline
Sound and Vibration Data
Weighted vibration:..................................13.643m/s2 (Main Handle),
11.359m/s2 (Side Handle)
Uncertainty: .......................................................... 1.5m/s2
Sound pressure(LPA): ............................................. 86.9dB(A)
Sound power(LWA): ................................................ 97.9dB(A)
Uncertainty: .......................................................... 3dB(A)
products may alter without notice.
Safety Information
Carefully read and understand this manual and any label attached to the tool before use.
Keep these instructions with the product for future reference. Ensure all persons who use
this product are fully acquainted with this manual.
Even when used as prescribed it is not possible to eliminate all residual risk factors. Use
with caution. If you are at all unsure of the correct and safe manner in which to use this
tool, do not attempt to use it.
WARNING: Always wear ear protection where the sound level exceeds 85dB(A) and
limit the time of exposure if necessary. If sound levels are uncomfortable, even with ear
protection, stop using the tool immediately and check the ear protection is correctly fitted
and provides the correct level of sound attenuation for the level of sound produced by
your tool.
WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness,
tingling and reduced ability to grip. Long term exposure can lead to a chronic condition. If
necessary, limit the length of time exposed to vibration and use anti-vibration gloves. Do
not operate the tool with hands below a normal comfortable temperature, as vibration will
have a greater effect. Use the figures provided in the specification relating to vibration to
calculate the duration and frequency of operating the tool.
Sound and vibration levels in the specification are determined according to EN60745 or
similar international standards. The figures represent normal use for the tool in normal
working conditions. A poorly maintained, incorrectly assembled, or misused tool, may
produce increased levels of noise and vibration.
www.osha.europa.eu provides information on sound and vibration levels in the workplace
that may be useful to domestic users who use tools for long periods of time.
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
WARNING: This appliance is not intended for use by persons (including children) with
reduced, physical or mental capabilities or lack of experience or knowledge unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children must be supervised to ensure that they do not play
with the appliance.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
Work Area Safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents
b) Do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools create sparks which may ignite
the dust or fumes
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control
Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded
c) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock
NOTE: The term “residual current device (RCD)” may be replaced by the term
“ground fault circuit interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.
Personal Safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your finger on the switch or energising power tools
that have the switch on invites accidents
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury
4
574483 560W SDS Plus Hammer Drill
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards
Power Tool Use & Care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power
tool accidentally
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation
Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained
Additional Safety for SDS Drills
• Important: It is imperative to follow all national safety regulations concerning the type of
work being undertaken, operation and maintenance
• Do not allow anyone under the age of 18 years to use this tool, and ensure that
operators are qualified and familiar with the operating and safety instructions
• Masonry drilling or chiselling can create sharp particles that will impact the operator.
Wear impact-resistant safety glasses and protective clothing, including safety boots
• Core drills should only be used with SDS drills featuring a safety clutch to prevent
jamming, which could cause an injury to the operator
• If the safety clutch disengages the drive during use, quickly release the trigger and
remove the core drill or bit from the masonry surface being drilled. Do not continue
operation until the cause of the disengagement is understood
• Do not operate SDS drills whilst up a ladder or in any location where there is a risk of
falling. SDS drills are heavy and produce strong vibration and high torque in use
• Wear suitable protective anti-vibration gloves that are non-fabric or coated fabric
to prevent loose strands of material catching in the rotating drill bit. Discard gloves
immediately if material is visibly frayed
• Drilling can produce large volumes of dust and debris that may be toxic. Wear
respiratory protection suitable for the work being undertaken. A minimum rating of
FFP2 is recommended
• SDS drills produce high volumes of noise and suitable ear protection must be worn at all
times while operating the tool
• SDS drills produce a very high level of vibration when operating in hammer or chisel
mode. Frequent breaks are advised
• Use metal and voltage detectors to locate concealed electric, water or gas lines. Avoid
touching live components or conductors
• Extension cable reels used with this tool must be completely unwound. Minimum
conductor cross section: 1.25mm2
• Extension reels used outside should be designed for outdoor use and should feature
water-protected sockets and correct cable insulation
• When using an SDS drill outdoors, an RCD device must be used either by connecting to
a socket which incorporates an RCD, or through use of an inline RCD
• Ensure that the chisel or drill bit is securely fixed in the chuck before operating the tool.
Insecure drill bits can be ejected from the machine, causing a hazard
• Ensure lighting is adequate
• Use both hands when operating this tool
• Always use the auxiliary handle supplied with the tool
• Do not place pressure on the tool - to do so could shorten its service life
• Drill bits become hot during operation. Allow to cool prior to handling
• If you are interrupted when operating the drill, complete the process and switch off
before diverting your attention elsewhere
• Always disconnect the SDS drill from the electric supply before changing a chisel or
drill bit
• Examine the chuck regularly for signs of wear or damage. Have damaged parts repaired
by a qualified service centre
• Always wait until the drill has come to a complete stop before placing it down
• On completion of the work, disconnect the tool from the power source and remove the
chisel/bit from the machine
• Periodically check all nuts, bolts and other fixings and tighten where necessary
• Visibly check the tool after use, especially the power cable, which can be damaged by
sharp masonry
• Always fit the dust guard to the bit in use to prevent damage from debris entering the
SDS chuck
• If operating the tool causes discomfort in any way, stop immediately and review your
method of use
Product Familiarisation
1 Chuck Key
2 3 Jaw Chuck
3 Chuck SDS Plus Arbor
4 SDS Plus Chuck
5 Depth Stop Clamp
6 Depth Stop Rod
7 Hammer Switch
8 On/Off Trigger
9 Lock On Switch
10 Side Handle
Additional Supplied Accessories (not shown)
4x SDS Plus TCT Masonry Bits (6, 8, 10 & 12mm)
Blow-moulded case
www.silverlinetools.com
5
GB
Unpacking Your Tool
• Carefully unpack and inspect your tool. Familiarise yourself with all its features and
functions.
• Ensure that all parts of the tool are present and in good condition. If any parts are
missing or damaged, have such parts replaced before attempting to use this tool.
Operating Instructions
Side handle
• The Side Handle (10) should always be used when drilling
• The side handle can be adjusted to best suit the work to be performed
• To adjust the side handle, rotate the grip anti-clockwise, this will loosen the handle
assembly. Move the side handle to the required position, and secure by turning
clockwise
Operating the SDS Plus chuck
Note: Unlike a conventional chuck the SDS Plus chuck system allows the bit to move
slightly within the chuck when inserted correctly. The bit can move slightly forward and
backward. This is normal and not a fault.
• Always grease the tail end of SDS bits. A general purpose lithium-based grease can be
used. Bits should always be freshly greased, and free from dirt and dust before use. Pull
back the chuck collar and hold. Push and rotate the bit into the SDS Plus Chuck (4), as
far as it will go. Release the chuck collar
• The bit should now be locked into the machine. Check this by pulling the bit. If the bit
can be removed, repeat the above procedure until secure
• To remove a bit from the chuck, pull the chuck collar back, and hold. The bit can then be
removed from the machine
WARNING: This power drill does not feature a rota-stop mode to allow hammer action
without rotating and is therefore not suitable for chisels or other bits that require no
rotation. Do not attempt to use such bits with this power tool.
WARNING: Never fit any drill bit with a maximum speed lower than the maximum no load
speed of this drill. Although this drill features a variable speed trigger action do not attempt
to operate low-speed drill bits or accessories by only partially holding in the trigger. Those
accessories are designed for drills that can pre-set their maximum speed before use or
operate permanently below the speed of the bit or accessory.
On/off trigger
• Always hold the drill firmly, using both hands
• To start the drill, squeeze the On/Off Trigger (8)
• To stop the drill, release the on/off trigger
• Whilst drilling, the on/off trigger can be locked by pressing the
Lock On Switch (9)
• To release the lock on switch, squeeze the on/off trigger again
• The speed of the drill is variable by how far the trigger is pressed but the lock on switch
can only function while the drill operates at maximum speed
Hammer selection
• The drill can be used in either rotary or rotary hammer mode
• To select rotary hammer mode, rotate the Hammer Switch (7) down, to the 'I' position
• To select rotary drilling mode, rotate the hammer switch up, to the '0' position
• Do not attempt to move the hammer selector whilst the drill is running
• Do not attempt to run the drill with the hammer selector in mid position
Using the 3-Jaw Chuck
• The drill is supplied with a 3-Jaw Chuck (2) and Chuck SDS Plus Arbor (3). This allows
conventional drill bits to be used with your SDS drill for drilling metal, wood and other
materials that do not require hammer action
• The 3-jaw chuck is a screw fit onto the arbor. Remove the locking screw from the arbor
by turning clockwise. The chuck can be secured on the arbor by inserting the locking
screw through the body of the chuck and it secures by turning anti-clockwise
• The chuck SDS Plus arbor fits into the SDS Plus chuck in the same way as an SDS
drill bit
NOTE: Due to the SDS Plus chuck mounting, the 3-jaw chuck will have a small amount of
forward and backward movement in use. It should not affect normal operation for most
drilling but be aware that when you use the power drill there may be a small amount of
travel after the drill bit contacts the surface before the drill is effective and starts drilling.
Also when removing the drill bit from the surface there will be a small amount of travel of
the drill body before the drill bit starts to be removed.
WARNING: Do not attempt to use hammer mode with the 3-jaw chuck fitted to the drill.
This could result in severe damage to the chuck and will invalidate your guarantee. Only
use SDS Plus masonry bits fitted to the SDS Plus chuck for masonry work.
Drilling concrete
• Insert a suitable masonry SDS Plus drill bit into the SDS Plus Chuck (4)
• Using rotary hammer drill mode, apply pressure to the rear of the drill, in line with
the drill bit
• For efficient drilling, it is advisable to use TCT (tungsten carbide tipped) drill bits. Ensure
that the drill bit diameter is within the maximum capacity of the drill and that the
maximum speed of the drill bit equals or exceeds the maximum no load speed of the
drill (see specifications)
• Do not apply too much pressure. If debris blocks the drill hole, run the drill slowly and
remove the bit from the hole. Repeat until hole is cleared
Drilling wood
• Use rotary drilling mode only with the 3-Jaw Chuck (2) fitted
• Ensure that the drill bit diameter is within the maximum capacity of the drill and that the
maximum speed of the drill bit equals or exceeds the maximum no load speed of the
drill (see specifications)
Drilling metal
• To ensure accuracy, mark the intended hole position using a hammer and centre punch
• Use rotary drill mode only with the 3-Jaw Chuck (2) fitted
• Ensure that drill bits are suitable for the grade of metal being drilled and that the
drill bit diameter is within the maximum capacity of the drill and that the maximum
speed of the drill bit equals or exceeds the maximum no load speed of the drill (see
specifications)
• To ensure efficient cutting, and prolong drill bit life, use a suitable lubricant or cutting
fluid, and drill at moderate speed
Using the depth stop feature
• This feature can be used to ensure holes are drilled to a required depth
• Insert the Depth Stop Rod (6) into the Depth Stop Clamp (5)
• Slide it forwards until it is aligned with the tip of the drill bit
• Slide the depth stop rod back towards the rear of the drill by the required distance (the
depth of hole required)
• Tighten the depth stop clamp
• Now when drilling into a flat surface such as a wall, the tip of the depth stop rod
touching the surface will indicate when the required depth of the hole is drilled
Caution
• Applying excess pressure does not result in faster or more efficient drilling. If the
pressure applied to the drill has a noticeable effect on the speed, reduce the pressure.
Overloading the drill will reduce its service life
• As the bit penetrates the material, it may catch or 'snag'. This can cause the machine
to suddenly 'kick'. To prevent any possibility of injury, always hold the drill securely by
using the side handle. Also, always use sharp drill bits of the correct type
• Always ensure that material is secure. If appropriate use a vice or clamp to hold the
work, always keep two hands on the drill
Safety Clutch
• In the event that a drill bit or core drill becomes locked in the workpiece while operating
and cannot rotate, or is forced to operate at a very low rotational speed, the safety
clutch will dis-engage the drive.
• In this event, quickly release the trigger which will help prevent injury and reduce wear
on the safety clutch mechanism.
• After the safety clutch has operated, completely recheck all equipment is correctly set
up and the drill bit or core drill is not badly worn or damaged. It may be necessary to
work at a slower rate. In some instances you may find the drill is not suitable especially
if using large core drills.
WARNING: Do not rely on the safety clutch. Always configure your equipment for safe use
so that the safety clutch will not operate.
Maintenance
WARNING: Always remove the plug from the mains power supply before carrying out any
maintenance/cleaning.
Cleaning
• Keep your machine clean at all times. Dirt and dust will cause internal parts to wear
quickly, shortening the machine’s service life.
• Clean the body of your machine with a soft brush, or dry cloth. If available, use clean,
dry, compressed air to blow through the ventilation holes
Brushes
• Over time the carbon brushes inside the motor may become worn. Excessively worn
brushes may cause loss of power, intermittent failure or visible sparking
• If you suspect that the brushes may be worn, have the machine serviced at an
authorised service centre
Disposal
• Do not dispose of power tools, or other waste electrical and electronic equipment, with
household waste
• Contact your local waste disposal authority for information on the correct way to
dispose of tools
6
Silverline Tools Guarantee
This Silverline product comes with a 3 year
guarantee
Register this product at www.silverlinetools.com within 30 days of
purchase in order to qualify for the 3 year guarantee. Guarantee period
begins according to the date of purchase on your sales receipt.
Terms & Conditions
Guarantee period becomes effective from the date of retail purchase as
detailed on your sales receipt.
PLEASE KEEP YOUR SALES RECEIPT
If this product develops a fault within 30 days of purchase, return it to the
stockist where it was purchased, with your receipt, stating details of the
fault. You will receive a replacement or refund.
If this product develops a fault after the 30 day period, return it to:
Silverline Tools Service Centre
PO Box 2988
Yeovil
BA21 1WU, UK
The guarantee claim must be submitted during the guarantee period.
You must provide the original sales receipt indicating the purchase date,
your name, address and place of purchase before any work can be
carried out.
You must provide precise details of the fault requiring correction.
Claims made within the guarantee period will be verified by Silverline Tools
to establish if the deficiencies are related to material or manufacturing of
the product.
Carriage will not be refunded. Items for return must be in a suitably clean
and safe state for repair, and should be packaged carefully to prevent
damage or injury during transportation. We may reject unsuitable or
unsafe deliveries.
All work will be carried out by Silverline Tools or its authorized
repair agents.
The repair or replacement of the product will not extend the period
of guarantee
Defects recognised by us as being covered by the guarantee shall be
corrected by means of repair of the tool, free of charge (excluding carriage
charges) or by replacement with a tool in perfect working order.
Retained tools, or parts, for which a replacement has been issued, will
become the property of Silverline Tools.
CE Declaration of Conformity
The undersigned: Mr Darrell Morris
as authorised by: Silverline Tools
Declares that the
Identification code: 574483
Description: 560W SDS Plus Hammer Drill
Conforms to the following Directives:
• Machinery Directive 2006/42/EC
• Low Voltage Directive 2006/95/EC
• EMC Directive 2004/108/EC
• ROHS Directive 2011/65/EU
• EN60745-1+A11:2010
• EN60745-2-6:2010
• EN55014-1+A1:2009
• EN55014-2+A2:2008
• EN61000-3-2+A2:2009
• EN61000-3-3:2008
560W SDS Plus Hammer Drill574483
Registering your purchase
Registration is made at silverlinetools.com by selecting the Guarantee
Registration button. You will need to enter:-
• Your personal details
• Details of the product and purchase information
Once this information is entered your guarantee certificate will be created
in PDF format for you to print out and keep with your purchase.
The repair or replacement of your product under guarantee provides
benefits which are additional to and do not affect your statutory rights as
a consumer.
What is covered:
The repair of the product, if it can be verified to the satisfaction of Silverline
Tools that the deficiencies were due to faulty materials or workmanship
within the guarantee period.
If any part is no longer available or out of manufacture, Silverline Tools will
replace it with a functional replacement part.
Use of this product in the EU.
What is not covered:
Silverline Tools does not guarantee repairs required as a result of:
Normal wear and tear caused by use in accordance with the operating
instructions eg blades, brushes, belts, bulbs, batteries etc.
The replacement of any provided accessories drill bits, blades, sanding
sheets, cutting discs and other related items.
Accidental damage, faults caused by negligent use or care, misuse,
neglect, careless operation or handling of the product.
Use of the product for anything other than normal domestic purposes.
Change or modification of the product in any way.
Use of parts and accessories which are not genuine Silverline Tools
components.
Faulty installation (except installed by Silverline Tools).
Repairs or alterations carried out by parties other than Silverline Tools or its
authorized repair agents.
Claims other than the right to correction of faults on the tool named in
these guarantee conditions are not covered by the guarantee.
Notified body: Jiangsu TUV Product Services Ltd. Shanghai, China
The technical documentation is kept by: Silverline Tools
Date: 15/05/13
Signed by:
Director
Name and address of Manufacturer or Authorised representative:
Powerbox International Ltd, Boundary Way, Lufton Trading Estate, Yeovil,
Somerset, BA22 8HZ United Kingdom
www.silverlinetools.com
7
F
Description des symboles
La plaque signalétique figurant sur votre outil peut présenter des symboles. Ces symboles
constituent des informations importantes relatives au produit ou des instructions
concernant son utilisation.
Port de protection auditive
Port de lunettes de sécurité
Port de masques respiratoires
Port du casque
Port de gants
Lire le manuel d’instructions
Double isolation pour une protection supplémentaire
Conforme à la réglementation et aux normes de sécurité pertinentes
Protection de l’environnement
Les produits électriques usagés ne doivent pas être jetés avec les ordures
ménagères. Veuillez les recycler dans les centres prévus à cet effet. Pour
de plus amples informations, veuillez contacter votre municipalité ou
point de vente
Caractéristiques techniques
Tension : ................................................................230 V~ 50 Hz
Puissance : ............................................................ 560 W
Vitesse à vide : ....................................................... 0 - 1100 min-1
Frappe : ................................................................. 0 - 3900
coups/min
Énergie de frappe : ................................................ 1,5 J
Enclenchement de l’embrayage de sécurité
(à et en dessous de) : ............................................. 56 Nm
Capacité de perçage maximale :
- Béton .................................................................. 20 mm
- Bois ..................................................................... 30 mm
- Acier .................................................................... 13 mm
Classe de protection : ............................................
Indice de protection : ............................................. IP20
Longueur du câble d’alimentation : ........................ 2 m
Type du câble : ......................................................HO7RN-F
Poids : .................................................................... 2,3 kg
Du fait de l’évolution constante de notre développement produit,
les caractéristiques des produits Silverline peuvent changer sans
Informations sur le niveau sonore et vibratoire
Vibration pondérée :....................13,643 m/s² (poignée principale)
11,359 m/s² (poignée auxiliaire)
Incertitude : ................................................. 1,5 m/s²
Pression sonore : ......................................... 86,9 dB(A)
Puissance sonore : ...................................... 97,9 dB(A)
Incertitude : ................................................. 3 dB(A)
L’intensité sonore peut dépasser 85 dB(A) et il est nécessaire que
l’utilisateur prenne des mesures de protection sonore.
notification préalable.
Lisez attentivement ce manuel ainsi que toute étiquette apposée sur l’outil et assurezvous d’en comprendre le sens avant utilisation. Rangez ces consignes avec l’outil, pour
référence ultérieure. Assurez-vous que toute personne venant à utiliser cet outil ait
attentivement pris connaissance de ce manuel.
Sachez qu’utiliser un outil conformément aux prescriptions ne garantit pas l’élimination de
tous les facteurs de risque. Procédez avec prudence. N’utilisez pas cet outil si vous avez
des doutes quant à la manière sûre et correcte de procéder.
Attention : Toujours porter des protections sonores lorsque le niveau d’intensité est
supérieur à 85 dB(A) et limiter le temps d’exposition si nécessaire. Si l’intensité sonore
devient inconfortable, même avec les protections, arrêter immédiatement d’utiliser
l’appareil, vérifier que les protections soient bien mises et qu’elles soient adéquates avec
le niveau sonore produit par l’appareil.
Attention : L’exposition de l’utilisateur aux vibrations peut engendrer une perte du toucher,
des engourdissements, des picotements et ainsi réduire la capacité de préhension. De
longues expositions peuvent également provoquer ces symptômes de façon chronique.
Si nécessaire, limiter le temps d’exposition aux vibrations, et porter des gants antivibrations. Ne pas utilisez cet appareil avec vos mains sous des conditions en dessous
de températures normales, car l’effet vibratoire en est accentué. Se référer au cas de
figures des caractéristiques relatives aux vibrations pour calculer le temps et fréquence
d’utilisation de l’appareil.
Les niveaux sonores et vibratoires des caractéristiques techniques sont déterminés
en fonction de la norme EN60745 ou autres normes internationales. Ces données
correspondent à un usage normale de l’appareil, et ce dans des conditions de travail
normales. Un appareil mal entretenu, mal assemblé ou mal utilisé peut augmenter les
niveaux sonores et vibratoires. Pour plus d’informations sur la directive des émissions
sonores et vibratoires, visitez le site http://osha.europa.eu/fr.
Consignes générales de
sécurité relatives aux appareils
électriques
AVERTISSEMENT Veuillez lire l’intégralité des consignes de sécurité et des
instructions. Le non-respect de ces consignes et instructions peut entraîner un risque de
choc électrique, d’incendie et/ou se traduire par des blessures graves
Attention : Cet appareil n’est pas conçu pour être utilisé par des personnes (enfants
compris) ayant des capacités physiques ou mentales réduites, ou n’ayant pas la
connaissance ou l’expérience requise, à moins d’être sous la supervision d’une personne
responsable de leur sécurité ou d’avoir reçu les instructions nécessaires. Les enfants ne
doivent pas s’approcher et jouer avec cet appareil.
Veuillez conserver ces instructions et consignes de sécurité pour référence
ultérieure.
L’expression « appareil électrique » employée dans les présentes consignes recouvre aussi
bien les appareils filaires à brancher sur le secteur que les appareils sans fils fonctionnant
sous batterie.
Sécurité sur la zone de travail
a) Maintenir une zone de travail propre et bien éclairée. Des zones encombrées et
mal éclairées sont sources d’accidents.
b) Ne pas utiliser d’outils électriques dans des environnements explosifs, tels
qu’à proximité de liquides, de gaz ou de poussières inflammables. Les appareils
électriques produisent des étincelles susceptibles d’enflammer la poussière ou les
vapeurs présentes.
c) Eloigner les enfants et les passants pendant l’utilisation d’un appareil
électrique. Ceux-ci peuvent provoquer une perte d’attention et faire perdre la
maîtrise de l’appareil.
Sécurité électrique
a) La prise d’un appareil électrique doit être adaptée à la prise du secteur. Ne
jamais modifier la prise en aucune façon. Ne jamais utiliser d’adaptateur sur la
prise électrique d’appareil mis à la terre. Des prises non modifiées, adaptées aux
boîtiers de prise de courant, réduiront le risque de décharge électrique.
b) Eviter le contact corporel avec les surfaces mises à la terre telles que tuyaux,
radiateurs, cuisinières et réfrigérateurs. Le risque de décharge électrique est plus
important si le corps est mis à la terre.
c) Ne pas exposer l’appareil électrique à la pluie ou à l’humidité. L’infiltration d’eau
dans un appareil électrique accroît le risque de décharge électrique.
d) Ne pas maltraiter le cordon électrique. Ne jamais utiliser le cordon électrique
pour porter, tirer ou débrancher l’appareil. Protéger le cordon électrique de la
chaleur, du contact avec l’essence, des bords tranchants et pièces rotatives.
Un cordon électrique endommagé ou entortillé accroît le risque de décharge
électrique.
e) Lors d’une utilisation de l’appareil électrique en extérieur, se servir d’une
rallonge appropriée à une utilisation en extérieur. Cela réduit le risque de
décharge électrique.
f) Si une utilisation de l’appareil électrique dans un environnement humide
ne peut être évitée, utiliser une alimentation protégée par un disjoncteur
différentiel. L’utilisation d’un disjoncteur différentiel réduit le risque de décharge
électrique.
Sécurité des personnes
a) Rester vigilent et faire preuve de bon sens lors de la manipulation de l’appareil.
Ne pas utiliser un appareil électrique lorsque l’on se trouve dans un état
de fatigue, ou sous l’influence de drogues, d’alcool ou de médicaments. Un
moment d’inattention pendant l’utilisation d’un outil électrique peut se traduire par
des blessures graves.
8
Loading...
