Silverline SDS Plus Hammer Drill User Manual [en, de, es, fr, it]

3 Year Guarantee

*Register online within 30 days. Terms & Conditions apply

Garantie de 3 ans *Enregistrez votre produit en ligne dans les 30 jours. Sous réserve des termes et conditions appliquées

3 Jahre Garantie *Registrieren Sie sich innerhalb von 30 Tagen online. Es gelten die allgemeinen Geschäftsbedingungen

3 años de garantía

*Regístrese online dentro de 30 días. Se aplican los términos y condiciones

3 anni di garanzia *Registrarsi on-line entro 30 giorni. Termini e Condizioni si applicano

3 Jaar Garantie *Registreer online binnen 30 dagen. Algemene voorwaarden van toepassing

www.silverlinetools.com

DIY

633821

850W SDS Plus Hammer Drill

850W SDS Plus Hammer Drill Marteau perforateur SDS-Plus 850 W SDS-Plus-Bohrhammer, 850 W

www.silverlinetools.com

Taladro percutor SDS Plus 850 W SDS Plus martello perforatore 850W 850 W SDS-Plus boorhamer

1 2

DIY

850W SDS Plus Hammer Drill

English .................. 4

Français ................ 8

Deutsch ................. 12

Español ................. 16

Italiano .................. 20

Nederlands ............ 24

www.silverlinetools.com

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.

Wear hearing protection Wear eye protection Wear breathing protection Wear head protection

Wear hand protection

Read instruction manual

Double insulated for additional protection

Conforms to relevant legislation and safety standards

Environmental Protection

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice

Speciﬁcation

Voltage: ....................................................................230V~50Hz

Motor: ...................................................................... 850W

No load speed: ......................................................... 800rpm

Safety Clutch (operates at or below): ....................... 56.4Nm

Impact rate: ............................................................. 3200bpm

Impact energy: ......................................................... 1.5J

Max drilling capacity:

-Concrete & stone ................................................... dia 26mm

-Wood .....................................................................dia 40mm

-Steel ...................................................................... dia 13mm

Fuse rating .............................................................. 13A

Protection class: ......................................................

Ingress protection rating: ......................................... IP20

Power cable length: ................................................. 2M

Power cable type: .................................................... H07RN-F

Weight: .................................................................... 4.7kg

As part of our ongoing product development, speciﬁcations of Silverline

Sound and Vibration Information

Weighted vibration (hammer drill):.............24.184m/s2(main handle)

14.583m/s2 (aux. handle)

Weighted vibration (chisel mode):..............20.473m/s2(main handle)

14.360m/s2(aux. handle)

Uncertainty: ............................................................. 1.5m/s

Sound pressure:....................................................... 96.1dB(A)

Sound power: .......................................................... 107.1dB(A)

Uncertainty .............................................................. 3dB(A)

The sound intensity level for the operator may exceed 85dB(A) and sound

products may alter without notice.

protection measures are necessary.

WARNING: Always wear ear protection where the sound level exceeds 85dB(A) and limit the time of exposure if necessary. If sound levels are uncomfortable, even with ear protection, stop using the tool immediately and check the ear protection is correctly ﬁtted and provides the correct level of sound attenuation for the level of sound produced by your tool.

WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness, tingling and reduced ability to grip. Long term exposure can lead to a chronic condition. If necessary, limit the length of time exposed to vibration and use anti-vibration gloves. Do not operate the tool with hands below a normal comfortable temperature, as vibration will have a greater effect. Use the ﬁgures provided in the speciﬁcation relating to vibration to calculate the duration and frequency of operating the tool.

Sound and vibration levels in the speciﬁcation are determined according to EN60745 or similar international standards. The ﬁgures represent normal use for the tool in normal working conditions. A poorly maintained, incorrectly assembled, or misused tool, may produce increased levels of noise and vibration. www.osha.europa.eu provides information on sound and vibration levels in the workplace that may be useful to domestic users who use tools for long periods of time.

Carefully read and understand this manual and any label attached to the tool before use. Keep these instructions with the product for future reference. Ensure all persons who use this product are fully acquainted with this manual.

Even when used as prescribed it is not possible to eliminate all residual risk factors. Use with caution. If you are at all unsure of the correct and safe manner in which to use this tool, do not attempt to use it.

Safety Information

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/or serious injury.

WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children must be supervised to ensure that they do not play with the appliance.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work Area Safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents b) Do not operate power tools in explosive atmospheres, such as in the presence

of ﬂammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes

c) Keep children and bystanders away while operating a power tool. Distractions

can cause you to lose control

Electrical Safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do

not use any adapter plugs with earthed (grounded) power tools. Unmodiﬁed

plugs and matching outlets will reduce risk of electric shock

b) Avoid body contact with earthed or grounded surfaces, such as pipes,

radiators, ranges and refrigerators. There is an increased risk of electric shock if

your body is earthed or grounded

c) Do not expose power tools to rain or wet conditions. Water entering a power tool

will increase the risk of electric shock

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging

the power tool. Keep cord away from heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase the risk of electric shock

e) When operating a power tool outdoors, use an extension cord suitable for

outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric

shock

f) If operating a power tool in a damp location is unavoidable, use a residual

current device (RCD) protected supply. Use of an RCD reduces the risk of electric

shock

NOTE: The term “residual current device (RCD)” may be replaced by the term “ground fault circuit interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.

Personal Safety

a) Stay alert, watch what you are doing and use common sense when operating a

power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication. A moment of inattention while operating power

tools may result in serious personal injury

b) Use personal protective equipment. Always wear eye protection. Protective

equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries

c) Prevent unintentional starting. Ensure the switch is in the off-position before

connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your ﬁnger on the switch or energising power tools

that have the switch on invites accidents

d) Remove any adjusting key or wrench before turning the power tool on. A

wrench or a key left attached to a rotating part of the power tool may result in personal injury

e) Do not overreach. Keep proper footing and balance at all times. This enables

better control of the power tool in unexpected situations

633821 850W SDS Plus Hammer Drill

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing

and gloves away from moving parts. Loose clothes, jewellery or long hair can be

caught in moving parts

g) If devices are provided for the connection of dust extraction and collection

facilities, ensure these are connected and properly used. Use of dust collection

can reduce dust-related hazards

Power Tool Use & Care

a) Do not force the power tool. Use the correct power tool for your application.

The correct power tool will do the job better and safer at the rate for which it was designed

b) Do not use the power tool if the switch does not turn it on and off. Any power

tool that cannot be controlled with the switch is dangerous and must be repaired

c) Disconnect the plug from the power source and/or the battery pack from the

power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power

tool accidentally

d) Store idle power tools out of the reach of children and do not allow persons

unfamiliar with the power tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained users

e) Maintain power tools. Check for misalignment or binding of moving parts,

breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents

are caused by poorly maintained power tools

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp

cutting edges are less likely to bind and are easier to control

g) Use the power tool, accessories and tool bits etc. in accordance with these

instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could

result in a hazardous situation

Service

a) Have your power tool serviced by a qualiﬁed repair person using only identical

replacement parts. This will ensure that the safety of the power tool is maintained

Additional Safety for SDS Drills

• Important: It is imperative to follow all national safety regulations concerning the type of work being undertaken, operation and maintenance

• Do not allow anyone under the age of 18 years to use this tool, and ensure that operators are qualiﬁed and familiar with the operating and safety instructions

• Masonry drilling or chiselling can create sharp particles that will impact the operator. Wear impact-resistant safety glasses and protective clothing, including safety boots

• Core drills should only be used with SDS drills featuring a safety clutch to prevent jamming, which could cause an injury to the operator

• If the safety clutch is activated during use, quickly release the trigger and remove the core drill or bit from the masonry surface being drilled. Do not continue work until the cause of the safety clutch operating is understood

• Do not operate SDS drills whilst up a ladder or in any location where there is a risk of falling. SDS drills are heavy and produce strong vibration and high torque in use

• Wear suitable protective anti-vibration gloves that are non-fabric or coated fabric to prevent loose strands of material catching in the rotating drill bit. Discard gloves immediately if material is visibly frayed

• Drilling can produce large volumes of dust and debris that may be toxic. Wear respiratory protection suitable for the work being undertaken. A minimum rating of FFP2 is recommended

• SDS drills produce high volumes of noise and suitable ear protection must be worn at all times while operating the tool

• SDS drills produce a very high level of vibration when operating in hammer or chisel mode. Frequent breaks are advised

• Use metal and voltage detectors to locate concealed electric, water or gas lines. Avoid touching live components or conductors

• Extension cable reels used with this tool must be completely unwound. Minimum conductor cross section: 1.25mm

• Extension reels used outside should be designed for outdoor use and should feature water-protected sockets and correct cable insulation

• When using an SDS drill outdoors, an RCD device must be used either by connecting to a socket which incorporates an RCD, or through use of an inline RCD

• Ensure that the chisel or drill bit is securely ﬁxed in the chuck before operating the tool. Insecure drill bits can be ejected from the machine, causing a hazard

• Ensure lighting is adequate

• Use both hands when operating this tool

• Use the auxiliary handle supplied with the tool

• Do not place pressure on the tool - to do so could shorten its service life

• Drill bits become hot during operation. Allow to cool prior to handling

• If you are interrupted when operating the drill, complete the process and switch off before diverting your attention elsewhere

• Always disconnect the SDS drill from the electric supply before changing a chisel or drill bit

• Examine the chuck regularly for signs of wear or damage. Have damaged parts repaired by a qualiﬁed service centre

• Always wait until the drill has come to a complete stop before placing it down

• On completion of the work, disconnect the tool from the power source and remove the chisel/bit from the machine

• Periodically check all nuts, bolts and other ﬁxings and tighten where necessary

• Visibly check the tool after use, especially the power cable, which can be damaged by sharp masonry

• Always ﬁt the dust guard to the bit in use to prevent damage from debris entering the SDS chuck

• If operating the tool causes discomfort in any way, stop immediately and review your method of use

Product Familiarisation

1 SDS Plus Chuck

2 Chuck Protective Cover 3 Rotation Selection Switch 4 Gearbox Cover 5 On/Off Trigger 6 Hammer Selection Switch 7 Brush Access Cover 8 Auxiliary Handle

9 Depth Stop Mounting 10 Dust Guard 11 Depth Stop 12 Gearbox Pin Spanner 13 Pot of Grease

Additional Supplied Accessories (not shown):

Blow moulded case

Unpacking Your Tool

• Carefully unpack and inspect your tool. Fully familiarise yourself with all its features and functions

• Ensure that all parts of the tool are present and in good condition. If any parts are missing or damaged, have such parts replaced before attempting to use this tool

www.silverlinetools.com

Operating Instructions

IMPORTANT: Before ﬁrst use and after every 6 hours (approx.) of use, ﬁll the gearbox cavity with gearbox grease. A Pot of Grease (13) is supplied for initial use. See ‘Gearbox Maintenance’ for application guidance

• Always check that there is sufﬁcient grease in the gearbox cavity before using the drill

Operating the Chuck

Note: The SDS Plus system allows the bit to move slightly within the chuck when inserted

correctly. The SDS Plus drill or chisel bit does not lock in position like a conventional chuck.

• To ﬁt a bit to the machine, ﬁrst grease the tail end of the bit. The Pot of Grease (13) supplied is suitable for this. Pull back the Chuck Protective Cover (2), and hold. Push and rotate the bit into the SDS Plus Chuck (1), as far as it will go. Release the chuck cover

• The bit should now be locked into the machine. Check by pulling the bit. If the bit can be removed, repeat the above procedure until the bit is held securely

• To remove a bit from the chuck, pull the chuck protective cover back and hold. The bit can then be removed from the drill

Note: The Dust Guard (10) should be used by ﬁtting to the drill or chisel bit to prevent debris and dust entering the chuck. This is especially important when the drill is used at a raised angle when working on walls or ceilings. For larger drill or chisel bits it may need to be ﬁtted before the bit is inserted in the chuck.

Selecting the required function Hammer Selection

• The drill can be used in either hammer drill mode (for masonry work), or conventional rotary drill mode (for wood, metal etc)

• To select hammer drilling mode, rotate the Hammer Selection Switch (6) to the left

• To select rotary drilling mode, rotate the hammer selection switch to the right

• Do not attempt to move the hammer selection switch whilst the drill is running

• Do not attempt to run the drill with the hammer selection switch in a mid position

Rotation Selection

• The drill can be used in either rotation mode (for drilling), or roto-stop mode (for chiselling)

• To select rotation mode, twist the Rotation Selection Switch (3) to the left

• To select roto-stop mode, twist the rotation selection switch to the right

• Do not attempt to move the rotation selection switch whilst the drill is running

• Do not attempt to run the drill with the rotation selection switch in a mid position

Depth Stop

1. To ﬁt the Depth Stop (11) , loosen the Auxiliary Handle (8) by turning the handle grip

anti-clockwise

2. Lift the auxiliary handle up to a horizontal position

3. Insert the depth stop into the Depth Stop Mounting (9) in the auxiliary handle

4. Rotate the handle grip clockwise to re-tighten which will secure the depth stop and

the auxiliary handle position

Auxiliary Handle

• The Auxiliary Handle (8) should always be used when drilling

• Always hold the drill ﬁrmly using both hands

• The auxiliary handle position can be adjusted to best suit the work to be performed

On/Off Trigger Switch

• To start the drill, squeeze the On/Off Trigger (5)

• To stop the drill, release the On/Off Trigger (5)

CAUTION: The drill is not designed to be permanently switched on and there is no lock-on feature. Do not attempt to improvise such a feature.

WARNING: This is a single-speed drill without variable speed adjustment. Any drill bit or core drill that states a maximum rotation speed of less than 800rpm must not be used.

Drilling Concrete

• Using hammer drill mode and rotation mode, apply pressure to the rear of the drill in line with the drill bit

• For efﬁcient drilling, it is advisable to use TCT (tungsten carbide tipped) drill bits. Ensure that drill bit size is within the maximum capacity of the drill

Chiselling

• Using hammer drill mode and roto-stop mode, apply pressure to the rear of the drill in line with the chisel

• Be aware that when chiselling, there is a high risk of chips, and other waste, being ejected from the workpiece

Safety Clutch

In the event that a drill bit or core drill becomes locked in the workpiece while operating and cannot rotate, or is forced to operate at a very low rotational speed, the safety clutch will disengage the drive.

In this event quickly release the trigger which will help prevent injury and reduce wear on the safety clutch mechanism.

After the safety clutch has activated, completely recheck all equipment is correctly set up and the drill bit or core drill is not badly worn or damaged. It may be necessary to work at a slower rate. In some instances you may ﬁnd the drill is not suitable especially if using large core drills.

WARNING: Do not rely on the safety clutch. Always conﬁgure your equipment for safe use so that the safety clutch will not operate.

Drilling wood and metal

Note: A conventional 13mm (1/2”) keyed chuck is available for this product. This is

available in the Silverline 13mm Chuck & SDS Plus Adaptor Kit, product code 292703

1. Screw the SDS plus arbor to the keyed chuck

2. Insert the chuck assembly into the SDS plus chuck

3. Insert a conventional drill bit for either wood or metal into the chuck and tighten the chuck with the chuck key. See speciﬁcation for maximum drilling capacity in wood and metal

CAUTION: The keyed chuck is not for masonry bits and will be damaged if used in hammer mode. Always use SDS Plus masonry bits ﬁtted directly into the SDS Plus chuck for masonry use.

Drilling Wood

• Use rotary drill mode only

• Ensure drill bits are suitable for wood, and are within the maximum capacity of this drill

Drilling Metal

• Use rotary drill mode only

• To ensure accuracy, mark the intended hole position using a hammer and centre punch

• Ensure drill bits are suitable for the grade of metal being drilled, and are within the maximum capacity of the drill

• To ensure efﬁcient cutting, and prolong drill bit life, use a suitable lubricant/cutting ﬂuid

CAUTION: Applying excess pressure does not result in faster or more efﬁcient drilling. If the pressure applied to the drill has a noticeable effect on the speed of the drill then reduce the pressure. Overloading the drill will reduce its service life.

• As the drill bit penetrates the material being drilled, it may 'catch' or 'snag'. This can cause the machine to suddenly 'kick', to prevent any possibility of injury always hold the drill securely, use the auxiliary handle, and use sharp drill bits

• Always ensure material is secure. If appropriate use a vice or clamp to hold the work, always keep two hands on the drill

Maintenance

WARNING: Always remove the plug from the mains power supply before carrying out any maintenance/cleaning.

Gearbox Maintenance

After every 6 hours of use (approx.), the gearbox must be regreased

1. Use the Gearbox Pin Spanner (13) to unscrew the Gearbox Cover (4)

2. Use a spatula or similar instrument to apply grease into the gearbox cavity

until it is full

3. Be careful not to scratch or damage the mechanism

4. Replace the Gearbox Cover (4)

NOTES:

• A Pot of Grease (13) is supplied for the ﬁrst few regreases but additional grease will be required. When purchasing additional grease, select a general purpose lithium-based grease

• Do not over-tighten the gearbox cover or overﬁll the gearbox with grease

• If you run out of grease, or are not sure how to change the grease, take your product to the nearest authorised service centre and ask a qualiﬁed person replace the grease

Cleaning

• Keep your machine clean at all times. Dirt and dust will cause internal parts to wear quickly, shortening the machine’s service life. Clean the body of your machine with a soft brush or dry cloth. If available, use clean, dry, compressed air to blow through the ventilation holes

Brushes

• Over time the carbon brushes inside the motor may become worn

• Excessively worn brushes may cause loss of power, intermittent failure, or visible sparking

• To replace the brushes, remove the Brush Access Cover (7) and the cover on the opposite side. The worn brushes can then be withdrawn, and replaced with new. Always replace worn brushes in pairs. Reﬁt the brush access covers. Alternatively, have the machine serviced at an authorised service centre

A range of accessories for this product are available from your Silverline dealer including SDS plus drill and chisel bits. Carbon brushes are available from www.toolsparesonline. com or your Silverline dealer.

Disposal

Always adhere to national regulations when disposing of power tools that are no longer functional and are not viable for repair.

• Do not dispose of power tools, or other waste electrical and electronic equipment (WEEE), with household waste

• Contact your local waste disposal authority for information on the correct way to dispose of power tools

Silverline Tools Guarantee

This Silverline product comes with a 3 year guarantee

Register this product at silverlinetools.com within 30 days of purchase in order to qualify for the 3 year guarantee. Guarantee period begins according to the date of purchase on your sales receipt.

Terms & Conditions

Guarantee period becomes effective from the date of retail purchase as detailed on your sales receipt.

PLEASE KEEP YOUR SALES RECEIPT

If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.

If this product develops a fault after the 30 day period, return it to:

Silverline Tools Service Centre PO Box 2988 Yeovil BA21 1WU, UK

The guarantee claim must be submitted during the guarantee period. You must provide the original sales receipt indicating the purchase date,

your name, address and place of purchase before any work can be carried out.

You must provide precise details of the fault requiring correction. Claims made within the guarantee period will be veriﬁed by Silverline Tools

to establish if the deﬁciencies are related to material or manufacturing of the product.

Carriage will not be refunded. Items for return must be in a suitably clean and safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.

All work will be carried out by Silverline Tools or its authorized repair agents.

The repair or replacement of the product will not extend the period of guarantee

Defects recognised by us as being covered by the guarantee shall be corrected by means of repair of the tool, free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.

Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.

CE Declaration of Conformity

The undersigned: Mr Darrell Morris as authorised by: Silverline Tools

Declares that

Identiﬁcation code: 633821 Description: 850W SDS Plus Hammer Drill

Conﬁrms to the following directives and standards:

• Machinery Directive 2006/42/EC

• EMC Directive 2004/108/EC

• ROHS Directive 2011/65/EC

• EN60745-1+A11:2010

• EN 60745-2-6:2010

• EN 55014-1:2009

• EN 55014-2+A2:2008

• EN61000-3-2+A2:2009

• EN61000-3-3+A2:2008

850W SDS Plus Hammer Drill633821

Registering your purchase

Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-

• Your personal details

• Details of the product and purchase information Once this information is entered your guarantee certiﬁcate will be created

in PDF format for you to print out and keep with your purchase.

The repair or replacement of your product under guarantee provides beneﬁts which are additional to and do not affect your statutory rights as a consumer.

What is covered:

The repair of the product, if it can be veriﬁed to the satisfaction of Silverline Tools that the deﬁciencies were due to faulty materials or workmanship within the guarantee period.

If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.

Use of this product in the EU.

What is not covered:

Silverline Tools does not guarantee repairs required as a result of: Normal wear and tear caused by use in accordance with the operating

instructions eg blades, brushes, belts, bulbs, batteries etc. The replacement of any provided accessories drill bits, blades, sanding

sheets, cutting discs and other related items. Accidental damage, faults caused by negligent use or care, misuse,

neglect, careless operation or handling of the product. Use of the product for anything other than normal domestic purposes. Change or modiﬁcation of the product in any way. Use of parts and accessories which are not genuine Silverline Tools

components. Faulty installation (except installed by Silverline Tools). Repairs or alterations carried out by parties other than Silverline Tools or its

authorized repair agents. Claims other than the right to correction of faults on the tool named in

these guarantee conditions are not covered by the guarantee.

Notiﬁed body: Jiangsu TUV Product Services Ltd, Shanghai, China

The technical documentation is kept by: Silverline Tools

Date: 29/07/13

Signed by:

Director

Name and address of Manufacturer or Authorised representative:

Powerbox International Ltd, Boundary Way, Lufton Trading Estate, Yeovil,

Somerset, BA22 8HZ United Kingdom

www.silverlinetools.com

Description des symboles

La plaque signalétique ﬁgurant sur votre outil peut présenter des symboles. Ces symboles constituent des informations importantes relatives au produit ou des instructions concernant son utilisation.

Port de protection auditive Port de lunettes de sécurité Port du masque respiratoire Port du casque

Port de gants

Lire le manuel d’instructions

Double isolation pour une protection supplémentaire

Conforme à la règlementation et aux normes européennes de sécurité pertinentes

Protection de l’environnement

Les produits électriques usagés ne doivent pas être jetés avec les ordures ménagères. Veuillez les recycler dans les centres prévus à cet effet. Pour de plus amples informations, veuillez contacter votre municipalité ou point de vente.

Caractéristiques techniques

Tension : .................................................................. 230 V~ 50 Hz

Puissance : .............................................................. 850 W

Vitesse à vide : ......................................................... 800 tr/min

Frappe : ................................................................... 3200 coups/min

Énergie de frappe :.......................... ........................ 1,5 J

Enclenchement de l’embrayage de sécurité

(à et en dessous de) : ............................................... 56,4 Nm

Capacité de perçage maximale :

- Béton .................................................................... 26 mm

- Bois ...................................................................... 40 mm

- Acier ..................................................................... 13 mm

Fusible : .................................................................. 13 A

Classe de protection : ..............................................

Indice de protection : ............................................... IP20

Longueur du câble d’alimentation : .......................... 2 m

Type du câble : ........................................................HO7RN-F

Poids : ...................................................................... 4,7 kg

Du fait de l’évolution constante de notre développement produit, les

caractéristiques des produits Silverline peuvent changer sans notiﬁcation

Informations sur le niveau sonore et vibratoire

Vibration pondérée (mode percussion) : ................... 24,184 m/s²

(poignée principale) 14,583 m/s² (poignée auxiliaire)

Vibration pondérée (mode burin) : ............................ 20,473 m/s²

(poignée principale) 14,360 m/s² (poignée principale)

Incertitude :..............................................................1,5 m/s²

Pression sonore : ..................................................... 96,1 dB(A)

Puissance sonore : ................................................... 107,1 dB(A)

Incertitude :.............................................................. 3 dB(A)

L’intensité sonore peut dépasser 85 dB(A) et il est nécessaire que l’utilisateur

prenne des mesures de protection sonore.

préalable.

Attention : Toujours porter des protections sonores lorsque le niveau d’intensité est supérieur à 85 dB(A) et limiter le temps d’exposition si nécessaire. Si l’intensité sonore devient inconfortable, même avec les protections, arrêter immédiatement d’utiliser l’appareil, vériﬁer que les protections soient bien mises et qu’elles soient adéquates avec le niveau sonore produit par l’appareil.

Attention : L’exposition de l’utilisateur aux vibrations peut engendrer une perte du toucher, des engourdissements, des picotements et ainsi réduire la capacité de préhension. De longues expositions peuvent également provoquer ces symptômes de façon chronique. Si nécessaire, limiter le temps d’exposition aux vibrations, et porter des gants antivibrations. Ne pas utilisez cet appareil avec vos mains sous des conditions en dessous de températures normales, car l’effet vibratoire en est accentué. Se référer au cas de ﬁgures des caractéristiques relatives aux vibrations pour calculer le temps et fréquence d’utilisation de l’appareil.

Les niveaux sonores et vibratoires des caractéristiques techniques sont déterminés en fonction de la norme EN60745 ou autres normes internationales. . Ces données correspondent à un usage normale de l’appareil, et ce dans des conditions de travail normales. Un appareil mal entretenu, mal assemblé ou mal utilisé peut augmenter les niveaux sonores et vibratoires. Pour plus d’informations sur la directive des émissions sonores et vibratoires, visitez le site http://osha.europa.eu/fr.

Lisez attentivement ce manuel ainsi que toute étiquette apposée sur l’outil et assurezvous d’en comprendre le sens avant utilisation. Rangez ces consignes avec l’outil, pour référence ultérieure. Assurez-vous que toute personne venant à utiliser cet outil ait attentivement pris connaissance de ce manuel.

Sachez qu’utiliser un outil conformément aux prescriptions ne garantit pas l’élimination de tous les facteurs de risque. Procédez avec prudence. N’utilisez pas cet outil si vous avez des doutes quant à la manière sûre et correcte de procéder.

Consignes générales de sécurité relatives aux appareils électriques

AVERTISSEMENT Veuillez lire l’intégralité des consignes de sécurité et des instructions. Le non-respect de ces consignes et instructions peut entraîner un risque de

choc électrique, d’incendie et/ou se traduire par des blessures graves.

Attention : Cet appareil n’est pas conçu pour être utilisé par des personnes (enfants compris) ayant des capacités physiques ou mentales réduites, ou n’ayant pas la connaissance ou l’expérience requise, à moins d’être sous la supervision d’une personne responsable de leur sécurité ou d’avoir reçu les instructions nécessaires. Les enfants ne doivent pas s’approcher et jouer avec cet appareil.

Veuillez conserver ces instructions et consignes de sécurité pour référence ultérieure.

L’expression « appareil électrique » employée dans les présentes consignes recouvre aussi bien les appareils ﬁlaires à brancher sur le secteur que les appareils sans ﬁls fonctionnant sous batterie.

Sécurité sur la zone de travail

a) Maintenir une zone de travail propre et bien éclairée. Des zones encombrées et

mal éclairées sont sources d’accidents.

b) Ne pas utiliser d’outils électriques dans des environnements explosifs, tels

qu’à proximité de liquides, de gaz ou de poussières inﬂammables. Les appareils

électriques produisent des étincelles susceptibles d’enﬂammer la poussière ou les vapeurs présentes.

c) Eloigner les enfants et les passants pendant l’utilisation d’un appareil

électrique. Ceux-ci peuvent provoquer une perte d’attention et faire perdre la

maîtrise de l’appareil.

Sécurité électrique

a) La prise d’un appareil électrique doit être adaptée à la prise du secteur. Ne

jamais modiﬁer la prise en aucune façon. Ne jamais utiliser d’adaptateur sur la prise électrique d’appareil mis à la terre. Des prises non modiﬁées, adaptées aux

boîtiers de prise de courant, réduiront le risque de décharge électrique.

b) Eviter le contact corporel avec les surfaces mises à la terre telles que tuyaux,

radiateurs, cuisinières et réfrigérateurs. Le risque de décharge électrique est plus

important si le corps est mis à la terre.

c) Ne pas exposer l’appareil électrique à la pluie ou à l’humidité. L’inﬁltration d’eau

dans un appareil électrique accroît le risque de décharge électrique.

d) Ne pas maltraiter le cordon électrique. Ne jamais utiliser le cordon électrique

pour porter, tirer ou débrancher l’appareil. Protéger le cordon électrique de la chaleur, du contact avec l’essence, des bords tranchants et pièces rotatives.

Un cordon électrique endommagé ou entortillé accroît le risque de décharge électrique.

e) Lors d’une utilisation de l’appareil électrique en extérieur, se servir d’une

rallonge appropriée à une utilisation en extérieur. Cela réduit le risque de

décharge électrique.

f) Si une utilisation de l’appareil électrique dans un environnement humide

ne peut être évitée, utiliser une alimentation protégée par un disjoncteur différentiel. L’utilisation d’un disjoncteur différentiel réduit le risque de décharge

électrique.

Sécurité des personnes

a) Rester vigilent et faire preuve de bon sens lors de la manipulation de l’appareil.

Ne pas utiliser un appareil électrique lorsque l’on se trouve dans un état de fatigue, ou sous l’inﬂuence de drogues, d’alcool ou de médicaments. Un

moment d’inattention pendant l’utilisation d’un outil électrique peut se traduire par des blessures graves.

+ 19 hidden pages

Silverline SDS Plus Hammer Drill User Manual [en, de, es, fr, it]

Specifications and Main Features

Frequently Asked Questions

User Manual
