Silverline Impact Driver User Manual [en, de, es, fr, it]

3 Year Guarantee

*Register online within 30 days. Terms & Conditions apply

Garantie de 3 ans *Enregistrez votre produit en ligne dans les 30 jours. Sous réserve des termes et conditions appliquées

3 Jahre Garantie *Registrieren Sie sich innerhalb von 30 Tagen online. Es gelten die allgemeinen Geschäftsbedingungen

3 años de garantía

*Regístrese online dentro de 30 días. Se aplican los términos y condiciones

3 anni di garanzia *Registrarsi on-line entro 30 giorni. Termini e Condizioni si applicano

3 Jaar Garantie *Registreer online binnen 30 dagen. Algemene voorwaarden van toepassing

www.silverlinetools.com

527958

10.8V Impact Driver

10.8V Impact Driver Visseuse à choc 10,8 V 10,8-V-Akkuschlagschrauber Atornillador de impacto de 10,8 V Avvitatore ad impulso 10,8 V Accuschroefmachine, 10,8 V

www.silverlinetools.com

2 3

10.8V Impact Driver

English .................. 4

Français ................ 8

Deutsch ................. 12

Español ................. 16

Italiano .................. 20

Nederlands ............ 24

www.silverlinetools.com

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.

Wear hearing protection Wear eye protection Wear breathing protection Wear head protection

Wear hand protection

Read instruction manual

Double insulated for additional protection

Conforms to relevant legislation and safety standards.

Environmental Protection

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice.

Speciﬁcation

Driver:

Voltage: ................................. 10.8V DC

No load speed: ...................... 0-2200min

Max torque: ........................... 90Nm

Sound pressure: .................... 77dB(A)

Sound power: ........................ 88dB(A)

Uncertainty: ........................... 5.16m/s

Weighted vibration: ............... 1,5m/s2

Weight................................... 1.0kg

Battery:

Voltage: ................................. 10.8V DC

Capacity: ............................... 1.3Ah

Type: ..................................... Li-ion

Charger:

Charging time: ..................... Max 5 hours

Output voltage: ...................... 12V DC

Supply type: .......................... 230-240V AC

Protection class: ....................

As part of our ongoing product development, speciﬁcations of

Silverline products may alter without notice.

The sound intensity level for the operator may exceed 85dB(A) and

sound protection measures are necessary.

-1

Sound and vibration levels in the speciﬁcation are determined according to EN 60745. The ﬁgures given can be used to compare similar tools tested to this standard. These ﬁgures may be used to assess exposure to noise and vibration levels.

The ﬁgures represent normal use for the tool in normal working condition. A poorly maintained, incorrectly assembled or mis-used tool may produce increased levels of noise and vibration. The total working period that you can operate this tool must factor in periods where the tool is idle or switched off. Allow frequent rest breaks when operating this tool.

It is in the interest of users to maximise their safety using the correct safety equipment like ear defenders that protect against loud or repetitive noise and anti-vibration gloves that minimise vibration. Do not operate the tool with your hands below a normal comfortable temperature as vibration will have a greater effect.

www.osha.europa.eu provides information on sound and vibration levels in the workplace that may be useful to domestic users who use tools for long periods of time

Carefully read and understand this manual and any label attached to the tool before use. Keep these instructions with the product for future reference. Ensure all persons who use this product are fully acquainted with this manual.

Even when used as prescribed it is not possible to eliminate all residual risk factors. Use with caution. If you are at all unsure of the correct and safe manner in which to use this tool, do not attempt to use it.

General Power Tool Safety Warnings

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/ or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work Area Safety

a) Keep work area clean and well lit. Cluttered or dark areas invite

accidents

b) Do not operate power tools in explosive atmospheres, such as

in the presence of ﬂammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes

c) Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control

Electrical Safety

a) Power tool plugs must match the outlet. Never modify the plug in

any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodiﬁed plugs and matching outlets will reduce risk

of electric shock

b) Avoid body contact with earthed or grounded surfaces, such as

pipes, radiators, ranges and refrigerators. There is an increased

risk of electric shock if your body is earthed or grounded

c) Do not expose power tools to rain or wet conditions. Water

entering a power tool will increase the risk of electric shock

d) Do not abuse the cord. Never use the cord for carrying, pulling or

unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the

risk of electric shock

e) When operating a power tool outdoors, use an extension cord

suitable for outdoor use. Use of a cord suitable for outdoor use

reduces the risk of electric shock

f) If operating a power tool in a damp location is unavoidable, use

a residual current device (RCD) protected supply. Use of an RCD

reduces the risk of electric shock

10.8V Impact Driver527958

NOTE: The term “residual current device (RCD)” may be replaced by

the term “ground fault circuit interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.

Personal Safety

a) Stay alert, watch what you are doing and use common sense

when operating a power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication.

A moment of inattention while operating power tools may result in serious personal injury

b) Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries

c) Prevent unintentional starting. Ensure the switch is in the

off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your

ﬁnger on the switch or energising power tools that have the switch on invites accidents

d) Remove any adjusting key or wrench before turning the power

tool on. A wrench or a key left attached to a rotating part of the power

tool may result in personal injury

e) Do not overreach. Keep proper footing and balance at all times.

This enables better control of the power tool in unexpected situations

f) Dress properly. Do not wear loose clothing or jewellery. Keep your

hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts

g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards

Power Tool Use & Care

a) Do not force the power tool. Use the correct power tool for your

application. The correct power tool will do the job better and safer at

the rate for which it was designed

b) Do not use the power tool if the switch does not turn it on and off.

Any power tool that cannot be controlled with the switch is dangerous and must be repaired

c) Disconnect the plug from the power source and/or the battery

pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive

safety measures reduce the risk of starting the power tool accidentally

d) Store idle power tools out of the reach of children and do

not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous

in the hands of untrained users

e) Maintain power tools. Check for misalignment or binding of

moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly

maintained power tools

f) Keep cutting tools sharp and clean. Properly maintained cutting

tools with sharp cutting edges are less likely to bind and are easier to control

g) Use the power tool, accessories and tool bits etc. in accordance

with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for

operations different from those intended could result in a hazardous situation

Service

a) Have your power tool serviced by a qualiﬁed repair person using

only identical replacement parts. This will ensure that the safety of

the power tool is maintained

This device is not intended for use by persons (including children) with reduced physical, sensory or mental abilities or lacking experience and/or knowledge, unless they are supervised by a person responsible for their safety or are instructed by these persons on the use of the device. Children should be supervised, to ensure that they do

not play with the device.

Battery & Battery Charger

Use the battery charger correctly

• Refer to the section of this manual relating to use of the battery charger before attempting to charge the battery

• Do not attempt to use the charger with any batteries other than those supplied. Keep the battery charger clean; foreign objects or dirt may cause a short or block air vents. Failure to follow these instructions may cause overheating or ﬁre

Use batteries correctly

• Only charge batteries using the charger provided. Only use batteries provided with this power tool, or others recommended by the supplier. Keep batteries clean; foreign objects or dirt may cause a short. Allow batteries to cool for 15 minutes after charging or heavy use. Failure to follow these instructions may cause overheating or ﬁre

• When not in use, batteries should be stored in a dry place, near to room temperature (20˚C). Ensure that batteries cannot accidentally short in storage

www.silverlinetools.com

Product Familiarisation

1 Bit Holder

2 Sleeve 3 Reverse Switch 4 Battery Pack 5 Battery Charge Level Indicator Button 6 Trigger Switch 7 LED Guide Light

8 Charger

Unpacking Your Tool

• Carefully unpack and inspect your tool. Fully familiarise yourself with all its features and functions

• Ensure that all parts of the tool are present and in good condition. If any parts are missing or damaged, have such parts replaced before attempting to use this tool

Operating Instructions

WARNING: Never ﬁt any attachment with a maximum speed lower than the no load speed of the machine.

Fitting a Bit

1. Pull the Sleeve (2) forward and insert the bit into the Bit Holder (1)

2. Release the sleeve

3. Pull on the bit to check that it is securely ﬁtted. If the bit is not secure,

repeat the above procedure

Direction Control

• The direction of rotation can be set using the Reverse Switch (3)

• To make the driver rotate clockwise, push the reverse s witch to the left

• To make the driver rotate anti-clockwise, push the reverse s witch to the right

• When the reverse switch is in the central position, the driver is locked

WARNING: Do not attempt to move the reverse switch when the driver is running.

Switching On

• To start the driver, squeeze the Trigger Switch (6). The LED Guide Light (7) will illuminate automatically

NOTE: The speed of the driver is controlled by the movement of the trigger, the further the trigger is depressed, the faster the driver will run.

Checking the Battery Level

• To check the level of charge in the battery, press the Battery Charge Level Indicator Button (5) in the base of the Battery Pack (4)

• There are three indicator lights: red, amber and green

• When all lights are illuminated, the battery is fully charged. When only the red light is illuminated, the battery charge level is low

• The battery can be placed on charge at any time as the intelligent charger will charge from any level of existing charge in the battery

Charging the Battery

Note: Before charging check the contacts of the battery and charger battery

socket are clean and in good condition

1. Depress the clip at the back of the Battery Pack (9) to remove the battery from the tool

2. Connect the Charger (11) to the mains power. The green light on the charger will illuminate

3. Insert the battery into charger so it is fully recessed into the charger battery socket . This ensures the battery and charger contacts are connected correctly. The red light will ﬂash evenly, indicating the battery is receiving charge

4. If both the red and green lights illuminate, the battery is not fully inserted in the charger. Adjust position of battery until it is fully inserted and red light begins to ﬂash evenly

5. When the battery has reached 90% charge, the green LED will ﬂash. At 100% charge the green LED will display solid green

6. After charging, allow 15 minutes for the battery to cool before use

7. Disconnect the charger from the power supply and store in a clean, dry environment out of the reach of children

8. Do not leave batteries on charge for extended periods and do not store batteries on charge

WARNING

• Do not store battery pack for long periods discharged. Always fully charge the battery pack before long term storage

• There are 3 battery cell protection features built into this product that protect the battery from being fully discharged, over-charged and from excessive current demands from the tool

IMPORTANT: Failure to follow the correct charging procedure may result in permanent damage to the batteries

Maintenance

Cleaning

• Keep your machine clean at all times. Dirt and dust will cause internal parts to wear quickly, and shorten the machine’s ser vice life. Clean the body of your machine with a soft brush or dry cloth. If available, use clean, dry, compressed air to blow through the ventilation holes

Storage

• Store this tool and accessories in a dry, secure place out of the reach of children

Disposal

• Do not dispose of power tools, or other waste electrical and electronic equipment, with household waste

• Contact your local waste disposal authority for information on the correct way to dispose of tools

Silverline Tools Guarantee

This Silverline product comes with a 3 year guarantee

Register this product at www.silverlinetools.com within 30 days of purchase in order to qualify for the 3 year guarantee. Guarantee period begins according to the date of purchase on your sales receipt.

Terms & Conditions

Guarantee period becomes effective from the date of retail purchase as detailed on your sales receipt.

PLEASE KEEP YOUR SALES RECEIPT

If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.

If this product develops a fault after the 30 day period, return it to:

Silverline Tools Service Centre PO Box 2988 Yeovil BA21 1WU, UK

The guarantee claim must be submitted during the guarantee period. You must provide the original sales receipt indicating the purchase date,

your name, address and place of purchase before any work can be carried out.

You must provide precise details of the fault requiring correction. Claims made within the guarantee period will be veriﬁed by Silverline Tools

to establish if the deﬁciencies are related to material or manufacturing of the product.

Carriage will not be refunded. Items for return must be in a suitably clean and safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.

All work will be carried out by Silverline Tools or its authorized repair agents.

The repair or replacement of the product will not extend the period of guarantee

Defects recognised by us as being covered by the guarantee shall be corrected by means of repair of the tool, free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.

Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.

CE Declaration of Conformity

The undersigned: Mr Darrell Morris as authorised by: Silverline Tools

Declares that

Identiﬁcation code: 527958 Description: 10.8V Impact Driver

Conforms to the following directives and standards:

• Machinery Directive 2006/42/EC

• Low Voltage Directive 2006/95/EC

• EMC Directive 2004/108/EC

• ROHS Directive 2011/65/EU

• EN 60745-1:2009 • EN 60745-2-2:2010

• EN 55014-1:2006+A1:2009+A2:2011

• EN 55014-2:1997+A1:2001+A2:2008

• EN 60335-1:2002+A1+A11+A12+A2+A13+A14+A15

• EN 60335-2-29:2004+A2 • EN 62233:2008

• EN 61000-3-2:2006+A1+A2 • EN 61000-3-3:2008

10.8V Impact Driver527958

Registering your purchase

Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-

• Your personal details

• Details of the product and purchase information Once this information is entered your guarantee certiﬁcate will be created

in PDF format for you to print out and keep with your purchase.

The repair or replacement of your product under guarantee provides beneﬁts which are additional to and do not affect your statutory rights as a consumer.

What is covered:

The repair of the product, if it can be veriﬁed to the satisfaction of Silverline Tools that the deﬁciencies were due to faulty materials or workmanship within the guarantee period.

If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.

Use of this product in the EU.

What is not covered:

Silverline Tools does not guarantee repairs required as a result of: Normal wear and tear caused by use in accordance with the operating

instructions eg blades, brushes, belts, bulbs, batteries etc. The replacement of any provided accessories drill bits, blades, sanding

sheets, cutting discs and other related items. Accidental damage, faults caused by negligent use or care, misuse,

neglect, careless operation or handling of the product. Use of the product for anything other than normal domestic purposes. Change or modiﬁcation of the product in any way. Use of parts and accessories which are not genuine Silverline Tools

components. Faulty installation (except installed by Silverline Tools). Repairs or alterations carried out by parties other than Silverline Tools or its

authorized repair agents. Claims other than the right to correction of faults on the tool named in

these guarantee conditions are not covered by the guarantee.

Notiﬁed body: Intertek Testing Services, Shanghai, China

The technical documentation is kept by: Silverline Tools

Date: 17/12/13

Signed:

Director

Name and address of manufacturer:

Powerbox International Ltd., Boundary Way, Lufton Trading Estate, Yeovil,

Somerset, BA22 8HZ, United Kingdom

www.silverlinetools.com

Description des Symboles

La plaque signalétique ﬁgurant sur votre outil peut présenter des symboles. Ces symboles constituent des informations importantes relatives au produit ou des instructions concernant son utilisation.

Port de protection auditive Port de lunettes de sécurité Port de masques respiratoires

Port du casque

Lire le manuel d’instructions

Conforme à la réglementation et aux normes de sécurité pertinentes

Protection de l’environnement Les produits électriques usagés ne doivent pas être jetés avec les ordures ménagères. Veuillez les recycler dans les centres prévus à cet effet. Pour de plus amples informations, veuillez contacter votre municipalité ou point de vente

Port de gants

Double isolation pour une protection supplémentaire

Caractéristiques techniques

Visseuse-dévisseuse :

Tension:...................................10,8 V CC

Vitesse a vide: .........................0-2200 min

Couple maximal : ....................90 Nm

Pression sonore:......................77 dB(A)

Puissance sonore: ...................88 dB(A)

Incertitude: ..............................5,16 m/s

Vibrations pondérées:..............1,5 m/s

Poids .......................................1,0 kg

Batterie:

Tension:...................................10,8 V CC

Capacité: .................................1,3 Ah

Type: .......................................Li-ion

Chargeur:

Temps de chargement: ...........Max 5 heures

Tension: ..................................12 V CC

Tension d’alimentation : ..........230-240 V CA

Classe de protection: ...............

Du fait de l’évolution constante de notre développement produit, les caractéristiques techniques des produits Silverline peuvent changer

L’intensité sonore peut dépasser 85 dB(A) et il est recommandé que

sans notiﬁcation préalable.

l’opérateur prenne des mesures de protection sonore.

-1

Les niveaux sonores et vibratoires des caractéristiques techniques sont déterminés en fonction de la norme EN60745. Ces données peuvent être utilisées pour comparer des outils similaires et testés selon cette norme. Ces données peuvent être aussi pour estimer l’exposition aux niveaux sonores et vibratoires.

Ces données correspondent à un usage normale de l’appareil, et ce dans des conditions de travail normales. Un appareil mal entretenu, mal assemblé ou mal utilisé peut augmenter les niveaux sonores et vibratoires. La durée totale d’utilisation sur laquelle vous utilisez l’appareil doit prendre en compte les périodes ou l’appareil est éteint ou à l’arrêt. Faites des pauses régulièrement lorsque vous utilisez cette appareil.

C’est dans l’intérêt de l’utilisateur d’assurer au maximum sa sécurité en s’équipant de protection de sécurité comme des casques anti- bruit qui protègent contre les bruits répétitifs et forts, et des gants anti-vibration pour diminuer les effets vibratoires. Ne pas utilisez cet appareil avec vos mains sous des conditions en dessous de températures normales, car l’effet vibratoire en est accentué.

Pour plus d’informations sur la directive des émissions sonores, visitez le site http://osha.europa.eu/fr.

Lisez attentivement ce manuel ainsi que toute étiquette apposée sur l’outil et assurez-vous d’en comprendre le sens avant utilisation. Rangez ces consignes avec l’outil, pour référence ultérieure. Assurez-vous que toute personne venant à utiliser cet outil ait attentivement pris connaissance de ce manuel.

Sachez qu’utiliser un outil conformément aux prescriptions ne garantit pas l’élimination de tous les facteurs de risque. Procédez avec prudence. N’utilisez pas cet outil si vous avez des doutes quant à la manière sûre et correcte de procéder.

Consignes générales de sécurité relatives aux appareils électriques

AVERTISSEMENT Veuillez lire l’intégralité des consignes de sécurité et des instructions. Le non-respect de ces consignes et instructions peut

entraîner un risque de choc électrique, d’incendie et/ou se traduire par des blessures graves

Veuillez conserver ces instructions et consignes de sécurité pour référence ultérieure.

L’expression « appareil électrique » employée dans les présentes consignes recouvre aussi bien les appareils ﬁlaires à brancher sur le secteur que les appareils sans ﬁls fonctionnant sous batterie.

Sécurité sur la zone de travail

a) Maintenir une zone de travail propre et bien éclairée. Des zones

encombrées et mal éclairées sont sources d’accidents.

b) Ne pas utiliser d’outils électriques dans des environnements

explosifs, tels qu’à proximité de liquides, de gaz ou de poussières inﬂammables. Les appareils électriques produisent des étincelles

susceptibles d’enﬂammer la poussière ou les vapeurs présentes.

c) Eloigner les enfants et les passants pendant l’utilisation d’un

appareil électrique. Ceux-ci peuvent provoquer une perte d’attention

et faire perdre la maîtrise de l’appareil.

Sécurité électrique

a) La prise d’un appareil électrique doit être adaptée à la prise du

secteur. Ne jamais modiﬁer la prise en aucune façon. Ne jamais utiliser d’adaptateur sur la prise électrique d’appareil mis à la terre. Des prises non modiﬁées, adaptées aux boîtiers de prise de

courant, réduiront le risque de décharge électrique.

b) Eviter le contact corporel avec les surfaces mises à la terre telles

que tuyaux, radiateurs, cuisinières et réfrigérateurs. Le risque de

décharge électrique est plus important si le corps est mis à la terre.

+ 19 hidden pages
