Silverline Hot Air Gun Adjustable 2000W User Manual [en, de, es, fr, it]
3 Year Guarantee
*Register online within 30
days. Terms & Conditions apply
Garantie de 3 ans
*Enregistrez votre produit en ligne
dans les 30 jours. Sous réserve des
Conditions Générales d’utilisation
3 Jahre Garantie
*Registrieren Sie sich innerhalb von 30
Tagen online. Es gelten die allgemeinen
Geschäftsbedingungen
3 años de garantía
*Regístrese online dentro de 30 días.
Se aplican los términos y condiciones
3 anni di garanzia
*Registrarsi on-line entro 30 giorni.
Termini e Condizioni si applicano
3 Jaar Garantie
*Registreer online binnen 30 dagen.
Algemene voorwaarden van toepassing
www.silverlinetools.com
R
E
L
I
V
N
L
I
E
S
R
E
A
G
N
125963
600°C
2000W Hot Air Gun
2000W Hot Air Gun
Pistolet décapeur 2000 W
Heißluftgebläse, 2000 W
Decapador de Aire
Caliente 2000 W
Pistola termica sverniciatore 2000 W
Heteluchtpistool 2000W
www.silverlinetools.com
2
3
4
1
5
2
R
E
L
I
V
N
L
I
E
S
R
E
A
G
N
®
600°C
2000W Hot Air Gun
English .................. 4
Français ................ 8
Deutsch ................. 12
Español ................. 16
Italiano .................. 20
Nederlands ............ 24
www.silverlinetools.com
3
GB
Description of Symbols
The rating plate on your tool may show symbols. These represent important
information about the product or instructions on its use.
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
Read instruction Manual
Double insulated for additional protection
Be aware of hot surfaces
Conforms to relevant legislation and safety standards
Environmental Protection
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with
your local authority or retailer for recycling advice
Specification
Voltage: ................................................230V~
Frequency: ...........................................50Hz
Power: ..................................................2000W
Max outlet temperature: .......................600˚C
Max air flow rate: .................................500L/min
Protection class: ...................................
The sound intensity level for the operator may exceed
85dB(A) and sound protection measures are necessary.
As part of our ongoing product development, specifications
of Silverline products may alter without notice.
Carefully read and understand this manual and any label attached to
the tool before use. Keep these instructions with the product for future
reference. Ensure all persons who use this product are fully acquainted
with this manual.
Even when used as prescribed it is not possible to eliminate all residual risk
factors. Use with caution. If you are at all unsure of the correct and safe
manner in which to use this tool, do not attempt to use it.
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire and/
or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work Area Safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents
b) Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control
Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk
of electric shock
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the
risk of electric shock
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock
NOTE: The term “residual current device (RCD)” may be replaced by
the term “ground fault circuit interrupter (GFCI)” or “earth leakage
circuit breaker (ELCB)”.
4
125963
2000W Hot Air Gun
Personal Safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you
are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in
serious personal injury
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries
c) Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that have the switch on
invites accidents
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the power
tool may result in personal injury
e) Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations
f) Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts
g) If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and properly
used. Use of dust collection can reduce dust-related hazards
Power Tool Use & Care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed
b) Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired
c) Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users
e) Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may
affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly
maintained power tools
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control
g) Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working
conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous
situation
Service
a) Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of
the power tool is maintained
Hot Air Gun Safety
• Never allow any air vents to become blocked or obscured during use.
Obscured inlet or outlet vents will cause the tool to rapidly overheat
• Parts of this tool will become extremely hot during use. Do not touch any
part of the tool, other than the handle whilst in use
• Always switch off and allow to cool fully before handling or attempting to
change any fittings. Do not leave this tool unattended whilst hot
• Heat may be conducted to hidden areas or materials near to the work
area. Ensure that there are no flammable materials in the vicinity of the
work area
• Never aim the hot air gun towards people or animals
• Do not hold the outlet Nozzle (1) against any material
• Always keep the outlet Nozzle (1) at least 25mm away from the work
surface. Do not allow any object to enter the nozzle when the tool is
connected to the power supply
• Do not allow paint, or any other waste, to accumulate on the outlet nozzle
or scrapers. Residual heat may cause waste material to ignite, even after
the tool has been switched off
• When working on a vertical surface, always aim the heat gun downwards
to prevent debris from falling into the machine
• Use of the hot air gun on certain materials may result in toxic fumes
being emitted. Always allow adequate ventilation. Do not use in confined
spaces
• A good quality breathing mask, or respirator, should always be worn
when using this tool
• If working on pre-1960 paint finishes, there is an increased chance of
encountering lead-based paint. Lead is especially toxic to children,
pregnant women, or people with high blood pressure. If working on pre1960 paint finishes such people should not be allowed near to the work
area, even if provided with appropriate breathing protection
• This tool should never be used in conjunction with chemical paint or
varnish strippers. Use of heat guns with chemical strippers can produce
extremely harmful fumes
• Never use this tool near to any kind of fuel tank or gas cylinder
• Always dispose of waste material responsibly
www.silverlinetools.com
5
GB
Product Familiarisation
1 Outlet Nozzle
2 Temperature Control Dial
3 Inlet Vents
4 On/Off Switch
5 Accessory Nozzles
Unpacking your tool
• Carefully unpack and inspect the hot air gun. Fully familiarise yourself
with all features and functions of the tool.
• If any parts are damaged or missing, have these parts repaired or
replaced before use.
Fitting Accessories
NOTE: Always ensure that the hot air gun is unplugged and fully cooled
before attempting to fit accessories.
• The Accessory Nozzles (5) supplied allow the hot air gun to be used for a
variety of different tasks
• Accessories are a push fit onto the Outlet Nozzle (1)
Operating Instructions
• Always hold the machine by the handle provided
• Do not obscure the Inlet Vents (3)
• Always wear appropriate personal protective equipment for the job that
you are to do. Use of this machine requires ear defenders, safety goggles,
gloves, and a breathing mask
Switching on
• The outlet air temperature is controlled using the Temperature Control
Dial (2). To increase the temperature, rotate the dial clockwise. To reduce
the temperature, rotate the dial anti-clockwise
• The fan speed is controlled using the On/Off Switch (4)
• To start the fan, slide the switch upwards until the figure “I” is visible. The
fan speed is now on its lower setting. To increase the fan speed, slide the
switch upwards until the figure “II” is visible
• Always return the switch to the downward position “0” before placing
the tool down
• Be aware that the metal parts of the tool will remain hot for some time
after switching off. Allow at least 30mins for the gun to cool before
leaving unattended
Paint stripping
• Connect the tool to the mains supply, and switch on
• Direct the hot air onto the paint to be removed, keeping the nozzle at
least 25mm away from the surface
NOTE: Take extra care when removing paint from window frames. The heat
from this tool can cause damage to glass if used carelessly.
• Allow the paint to soften and remove using a suitable scraper
• Do not overheat the paint, if you notice smoke or blackening, stop heating
• Do not allow waste to build up, or drop into the Outlet Nozzle (1) as it will
be a fire hazard
Pipe defrosting
• This hot air gun can be used to defrost frozen water pipes
• Using a suitable attachment, aim hot air at the frozen pipe. Move the hot
air gun along the pipe so that the whole length defrosts evenly
• Be aware of overheating areas directly behind the pipe being defrosted
• Do not attempt to defrost PVC pipe as the heat of the air may cause
permanent damage
Drying
• This hot air gun can be used to dry damp wood or other materials
• Be very careful when operating power tools near damp materials, the
presence of water greatly increases the danger of electric shock
• Always refer to the product manufacturers instructions if using the hot
air gun to dry plaster, paint, or other finishes. Do not use the hot air gun
on any flammable material, or any material that may produce hazardous
fumes
Stationary use
• This hot air gun can also be used statically, keeping hands free to
manipulate the workpiece
• The hot air gun is designed to stand upright on a suitable workbench.
The Outlet Nozzle (1) should point straight upwards. The nozzle must not
contact the workbench, or any other object
• Ensure that the power cable is well supported and will not become
caught as you work
• Switch the hot air gun on, and move workpiece into the hot air flow. Take
care to keep your hands and face away from the hot air
Maintenance
WARNING: Always remove the plug from the mains power supply before
carrying out any maintenance/cleaning.
Cleaning
• Keep your machine clean at all times. Dirt and dust will cause internal
parts to wear quickly, shortening the machine’s service life.
• Clean the body of your machine with a soft brush, or dry cloth. If
available, use clean, dry, compressed air to blow through the ventilation
holes
Disposal
• Do not dispose of power tools, or other waste electrical and electronic
equipment, with household waste
• Contact your local waste disposal authority for information on the correct
way to dispose of tools
6
Silverline Tools Guarantee
This Silverline product comes with a 3 year
guarantee
Register this product at silverlinetools.com within 30 days of purchase
in order to qualify for the 3 year guarantee. Guarantee period begins
according to the date of purchase on your sales receipt.
Terms & Conditions
Guarantee period becomes effective from the date of retail purchase as
detailed on your sales receipt.
PLEASE KEEP YOUR SALES RECEIPT
If this product develops a fault within 30 days of purchase, return it to the
stockist where it was purchased, with your receipt, stating details of the
fault. You will receive a replacement or refund.
If this product develops a fault after the 30 day period, return it to:
Silverline Tools Service Centre
PO Box 2988
Yeovil
BA21 1WU, UK
The guarantee claim must be submitted during the guarantee period.
You must provide the original sales receipt indicating the purchase date,
your name, address and place of purchase before any work can be
carried out.
You must provide precise details of the fault requiring correction.
Claims made within the guarantee period will be verified by Silverline Tools
to establish if the deficiencies are related to material or manufacturing of
the product.
Carriage will not be refunded. Items for return must be in a suitably clean
and safe state for repair, and should be packaged carefully to prevent
damage or injury during transportation. We may reject unsuitable or
unsafe deliveries.
All work will be carried out by Silverline Tools or its authorized
repair agents.
The repair or replacement of the product will not extend the period
of guarantee
Defects recognised by us as being covered by the guarantee shall be
corrected by means of repair of the tool, free of charge (excluding carriage
charges) or by replacement with a tool in perfect working order.
Retained tools, or parts, for which a replacement has been issued, will
become the property of Silverline Tools.
EC Declaration of Conformity
The undersigned: Mr Darrell Morris
as authorised by: Silverline Tools
Declares that the
Name/ model: 2000W Hot Air Gun
Type/ serial no: 125963
Net installed power: 230V~ 50Hz 2000W
Conforms to the following Directives:
• EMC DIRECTIVE 2004/108/EC
• LOW VOLTAGE DIRECTIVE 2006/95/EC
• ROHS DIRECTIVE 2002/95/EC
• EN60335-2-45:2002, EN60335-1:2002+A11,A1:04+A12,A2:06
• EN50366:2003+A1:06
• EN55014-1:2006, EN55014-2:1997+A1:2001
• EN61000-3-2:2006, EN61000-3-3:1995+A1:2001+A2:2005
2000W Hot Air Gun125963
Registering your purchase
Registration is made at silverlinetools.com by selecting the Guarantee
Registration button. You will need to enter:-
• Your personal details
• Details of the product and purchase information
Once this information is entered your guarantee certificate will be created
in PDF format for you to print out and keep with your purchase.
The repair or replacement of your product under guarantee provides
benefits which are additional to and do not affect your statutory rights as
a consumer.
What is covered:
The repair of the product, if it can be verified to the satisfaction of Silverline
Tools that the deficiencies were due to faulty materials or workmanship
within the guarantee period.
If any part is no longer available or out of manufacture, Silverline Tools will
replace it with a functional replacement part.
Use of this product in the EU.
What is not covered:
Silverline Tools does not guarantee repairs required as a result of:
Normal wear and tear caused by use in accordance with the operating
instructions eg blades, brushes, belts, bulbs, batteries etc.
The replacement of any provided accessories drill bits, blades, sanding
sheets, cutting discs and other related items.
Accidental damage, faults caused by negligent use or care, misuse,
neglect, careless operation or handling of the product.
Use of the product for anything other than normal domestic purposes.
Change or modification of the product in any way.
Use of parts and accessories which are not genuine Silverline Tools
components.
Faulty installation (except installed by Silverline Tools).
Repairs or alterations carried out by parties other than Silverline Tools or its
authorized repair agents.
Claims other than the right to correction of faults on the tool named in
these guarantee conditions are not covered by the guarantee.
The technical documentation is kept by: Silverline Tools
Notified body: Intertek Testing Services
Place of declaration: Shanghai, China
Date: 15/02/12
Signed by:
Director
Name and address of Manufacturer or Authorised representative:
Silverline Tools, Boundary Way, Lufton Trading Estate, Yeovil, Somerset,
BA22 8HZ United Kingdom
www.silverlinetools.com
7
F
Description des Symboles
La plaque de valeur nominale sur votre outil peut afficher des symboles.
Ces symboles constituent des informations importantes concernant le
produit ou des instructions sur son utilisation.
Port de protection auditive
Port de lunettes de sécurité
Port de masques respiratoires
Port du casque
Port de gants
Lire le manuel d’instructions
Double isolation pour une protection supplémentaire
Attention ! Surfaces chaudes
Conforme à la réglementation et aux normes de sécurité
pertinentes
Protection de l’environnement
Les produits électriques usagés ne doivent pas être jetés
avec les ordures ménagères. Veuillez les recycler dans
les centres prévus à cet effet. Pour de plus amples informations,
veuillez contacter votre municipalité ou point de vente
Caractéristiques techniques
Tension : ...............................................230 V~
Fréquence : ..........................................50 Hz
Puissance : ...........................................2000 W
Température de sortie maximale : ........600 °C
Débit d’air maximum : ..........................500 l/min
Classe de protection : ...........................
L’intensité sonore peut dépasser 85 dB(A) et il est
recommandé que l’opérateur prenne des mesures de
Du fait de l’évolution constante de notre développement
produits, les spécifications des produits Silverline peuvent
Lisez attentivement ce manuel ainsi que toute étiquette apposée sur l’outil
et assurez-vous d’en comprendre le sens avant utilisation. Rangez ces
consignes avec l’outil, pour référence ultérieure. Assurez-vous que toute
personne venant à utiliser cet outil ait attentivement pris connaissance de
ce manuel.
Sachez qu’utiliser un outil conformément aux prescriptions ne garantit
pas l’élimination de tous les facteurs de risque. Procédez avec prudence.
N’utilisez pas cet outil si vous avez des doutes quant à la manière sûre et
correcte de procéder.
protection sonore.
changer sans notification préalable.
Consignes générales de
sécurité relatives aux appareils
électriques
AVERTISSEMENT Veuillez lire l’intégralité des consignes de sécurité
et des instructions. Le non-respect de ces consignes et instructions peut
entraîner un risque de choc électrique, d’incendie et/ou se traduire par des
blessures graves
Veuillez conserver ces instructions et consignes de sécurité pour
référence ultérieure.
L’expression « appareil électrique » employée dans les présentes consignes
recouvre aussi bien les appareils filaires à brancher sur le secteur que les
appareils sans fils fonctionnant sous batterie.
Sécurité sur la zone de travail
a) Maintenir une zone de travail propre et bien éclairée. Des zones
encombrées et mal éclairées sont sources d’accidents.
b) Ne pas utiliser d’outils électriques dans des environnements
explosifs, tels qu’à proximité de liquides, de gaz ou de poussières
inflammables. Les appareils électriques produisent des étincelles
susceptibles d’enflammer la poussière ou les vapeurs présentes.
c) Eloigner les enfants et les passants pendant l’utilisation d’un
appareil électrique. Ceux-ci peuvent provoquer une perte d’attention
et faire perdre la maîtrise de l’appareil.
Sécurité électrique
a) La prise d’un appareil électrique doit être adaptée à la prise du
secteur. Ne jamais modifier la prise en aucune façon. Ne jamais
utiliser d’adaptateur sur la prise électrique d’appareil mis à la
terre. Des prises non modifiées, adaptées aux boîtiers de prise de
courant, réduiront le risque de décharge électrique.
b) Eviter le contact corporel avec les surfaces mises à la terre telles
que tuyaux, radiateurs, cuisinières et réfrigérateurs. Le risque de
décharge électrique est plus important si le corps est mis à la terre.
c) Ne pas exposer l’appareil électrique à la pluie ou à l’humidité.
L’infiltration d’eau dans un appareil électrique accroît le risque de
décharge électrique.
d) Ne pas maltraiter le cordon électrique. Ne jamais utiliser le
cordon électrique pour porter, tirer ou débrancher l’appareil.
Protéger le cordon électrique de la chaleur, du contact avec
l’essence, des bords tranchants et pièces rotatives. Un cordon
électrique endommagé ou entortillé accroît le risque de décharge
électrique.
e) Lors d’une utilisation de l’appareil électrique en extérieur, se
servir d’une rallonge appropriée à une utilisation en extérieur.
Cela réduit le risque de décharge électrique.
f) Si une utilisation de l’appareil électrique dans un environnement
humide ne peut être évitée, utiliser une alimentation protégée par
un disjoncteur différentiel. L’utilisation d’un disjoncteur différentiel
réduit le risque de décharge électrique.
Sécurité des personnes
a) Rester vigilent et faire preuve de bon sens lors de la manipulation
de l’appareil. Ne pas utiliser un appareil électrique lorsque l’on
se trouve dans un état de fatigue, ou sous l’influence de drogues,
d’alcool ou de médicaments. Un moment d’inattention pendant
l’utilisation d’un outil électrique peut se traduire par des blessures
graves.
b) Porter un équipement de protection approprié. Toujours porter
une protection oculaire. Le port de masque à poussières, chaussures
de sécurité antidérapantes, casque de sécurité et protections antibruit
adaptés aux différentes conditions de travail réduit le risque de
blessures corporelles.
c) Eviter tout démarrage accidentel. S’assurer que l’interrupteur
marche-arrêt soit en position d’arrêt avant de brancher l’appareil
sur l’alimentation secteur ou d’installer la batterie, de prendre
l’appareil ou de le transporter. Porter un appareil électrique tout en
maintenant le doigt posé sur l’interrupteur ou brancher un appareil
électrique dont l’interrupteur est sur la position de marche est source
d’accidents.
8
Loading...
