Silverline Hot Air Gun 2000W User Manual [en, de, es, fr, it]

ESP

3 Year Guarantee

Garantie 3 Ans

Enregistrement sur le site dans les 30 jours* Acceptation des conditions

3 Jahre Garantie

Registrieren Sie sich online innerhalb von 30 Tagen* Bedingungen gelten

3 Años de Garantía

Regístrese online dentro de 30 días* Sujeta a términos y condiciones

3 Anni di Garanzia

Registrati on-line entro 30 giorni* Condizioni di applicazione

3 Jaar Garantie

Registreer online binnen 30 dagen* Algemene voorwaarden van toepassing

DIY

2000W Hot Air Gun

ESP

127655

2000W Hot Air Gun Pistolet à Air Chaud 2000W Heißluftpistole, 2000W Pistola de Aire Caliente de 2000W Pistola ad Aria Calda - 2000W 2000W Heteluchtpistool

www.silverlinetools.com

2000W Hot Air Gun

DIY

English .................. 4

Français ................ 8

Deutsch ................. 12

Español ................. 16

Italiano .................. 20

Nederlands ............ 24

www.silverlinetools.com

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.

Wear hearing protection. Wear eye protection. Wear breathing protection. Wear head protection.

Wear hand protection.

Read instruction Manual.

Double insulated for additional protection.

Be aware of hot surfaces.

Conforms to relevant legislation and safety standards.

Environmental Protection

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice.

Speciﬁcation

Voltage .................................................230V~

Frequency ............................................50Hz

Power ...................................................2000W

Max outlet temperature ........................600˚C

Max air ﬂow rate ..................................650L/min

Protection class ....................................

The sound intensity level for the operator may exceed

85dB(A) and sound protection measures are necessary.

As part of our ongoing product development, speciﬁcations

of Silverline products may alter without notice

General Safety

Carefully read and understand this manual and any label attached to the tool before use. Keep these instructions with the product for future reference. Ensure all persons who use this product are fully acquainted with this manual. Even when used as prescribed it is not possible to eliminate all residual risk factors. Use with caution. If you are at all unsure of the correct and safe manner in which to use this tool, do not attempt to use it.

Keep guards in position

Always keep guards in position, in good working order, correctly adjusted • and aligned. Never attempt to use a tool if any of the supplied guards are missing. If any guards are damaged, replace before use.

Remove adjusting keys

Always check to see that keys and adjusting devices are removed from • the tool before use.

Clean the work area

Accidents can occur where benches and work areas are cluttered or • dirty, ﬂoors must be kept clear, avoid working where the ﬂoor is slippery. If working outdoors, make yourself aware of all potential slip and trip hazards before using this tool.

Children and pets

Children and pets should always be kept at a safe distance from your • work area. Lock tools away where children can’t get access to them. Do not allow children, or untrained persons to use this tool.

Use the correct tool

Don’t force, or attempt to use a tool for a purpose it was not designed. • This tool is not intended for industrial use.•

Wear suitable clothing and footwear

Don’t wear loose ﬁtting clothing, neckties, jewellery, or other items which • may become caught. Wear non slip footwear, or footwear with protective toe caps where appropriate. Long hair should be covered or tied back.

Keep your balance

Don’t over reach, keep proper footing at all times, do not use tools when • standing on an unstable surface.

Accessories

The use of any attachment or accessory other than those mentioned • in this manual could result in damage or injury. The use of improper accessories could be dangerous, and may invalidate your warranty.

Secure work

Where possible, always secure work. If appropriate use a clamp or vice, it • will allow you to use both hands to operate your tool.

Check for damaged or missing parts

Before each use, check if any part of the tool is damaged or missing, • check carefully that it will operate properly and perform its intended function. Check alignment of moving parts for binding. Any guard or other part that is damaged should be immediately repaired or replaced by an authorised service centre. DO NOT USE IF DEFECTIVE.

Electrical Safety

The wires in this product are coloured:

Blue Neutral Brown Live Green & Yellow Earth

This appliance must be protected by a suitable fuse.• To prevent ﬁre or shock hazard, do not expose this product to rain, water •

or moisture. There are no user serviceable parts inside except those referred to in •

this manual. Always refer servicing to qualiﬁed service personnel. Never remove any •

part of the casing unless qualiﬁed to do so; this unit contains dangerous voltages.

Use of a residual current device will reduce the risk of electric shock.•

Dangerous environment

Do not use power tools in damp or wet conditions, or expose them to • rain. Provide adequate surrounding work space and keep area well lit. Do not use power tools where there is a risk of explosion or ﬁre from combustible material, ﬂammable liquids, ﬂammable gases, or dust of an explosive nature. When using power tools avoid contact with any earthed items such as pipes, radiators, cookers, refrigerators, metal baths and taps.

Protect yourself from vibration

Hand held power tools may produce vibration. Vibration can cause • disease. Gloves to keep the operator warm may help to maintain good blood circulation in the ﬁngers. Hand held tools should not be used for

127655

long periods without a break.

Maintain your power tool

Ensure all ventilation holes are kept clear at all times. Overheating and • ﬁre may otherwise result.

Always Disconnect

Before changing ﬁttings or accessories, always ensure that your tool is • disconnected from the power source.

Switch off before connecting

Ensure that the power tool is switched off before connecting to the power • source. If the power tool stops unexpectedly, turn the power switch to off.

Do not abuse the power cord

Be sure your cable or extension cable is in good condition. Always have • a damaged cable or extension cable replaced at an authorised service centre before using it. Never yank or pull the cable to disconnect it from the power socket. Never carry your tool by its cable. Keep the cable away from damp, heat, oil, solvents and sharp edges.

Don’t leave the tool running unattended

Always wait until your tool has completely stopped functioning, and has • been unplugged, before leaving it.

Hot Air Gun Safety

Never allow any air vents to become blocked, or allow vents to be • obscured during use.

Obscured inlet or outlet vents will cause the tool to rapidly overheat.• Parts of this tool will become extremely hot during use. Do not touch any •

part of the tool, other than the handle whilst in use. Always switch off, and allow to cool fully before handling, or attempting •

to change any ﬁttings. Do not leave this tool unattended whilst hot. Heat may be conducted to hidden areas, or materials near to the work •

area. Ensure that there are no ﬂammable materials in the vicinity of the work area.

Never aim the hot air gun towards people, or animals.• Do not hold the outlet nozzle against any material.• Always keep the outlet nozzle at least 25mm away from the work •

surface. Do not allow any object to enter the nozzle when the tool is connected to the power supply.

Do not allow paint, or any other waste, to accumulate on the outlet nozzle • or scrapers. Residual heat may cause waste material to ignite, even after the tool has been switched off.

When working on a vertical surface, always aim the heat gun downwards • to prevent debris from falling into the machine.

Use of the hot air gun on certain materials may result in toxic fumes • being emitted. Always allow adequate ventilation. Do not use in conﬁned spaces.

A good quality breathing mask, or respirator, should always be worn • when using this tool.

If working on pre-1960 paint ﬁnishes, there is an increased chance of • encountering lead based paint.

Lead is especially toxic to children, pregnant women, or people with high • blood pressure. If working on pre-1960 paint ﬁnishes such people should not be allowed near to the work area, even if provided with appropriate breathing protection.

This tool should never be used in conjunction with chemical paint or • varnish strippers. Use of heat guns with chemical strippers can produce extremely harmful fumes.

Never use this tool near to any kind of fuel tank or gas cylinder.• Always dispose of waste material responsibly.•

2000W Hot Air Gun

www.silverlinetools.com

Product Familiarisation

1 Outlet nozzle 2 Inlet vents 3 On/Off switch 4 Accessory nozzles

Unpacking and Assembling your Hot Air Gun

Carefully unpack and inspect the hot air gun. Fully familiarise yourself • with all features and functions of the tool.

If any parts are damaged or missing, have these parts repaired or • replaced before use.

Fitting Accessories

NOTE: Always ensure that the hot air gun is unplugged, and fully cooled before attempting to ﬁt accessories.

The accessory nozzles (4) supplied, allow the hot air gun to be used for a • variety of different tasks.

Accessories are a push ﬁt onto the outlet nozzle (1).•

Operating Instructions

Always hold the machine by the handle provided.• Do not obscure the inlet vents (2).• Always wear appropriate personal protective equipment for the job that •

you are to do. Use of this machine requires ear defenders, safety goggles, gloves, and a breathing mask.

Switching on

The outlet has two preset temperatures. This can be adjusted by • changing the position of the on/off switch (3).

For the lower setting (300ºC) move the switch into the “I” position.• For the higher setting (600ºC) move the switch into the “II” position.• To turn the hot air gun off move the on/off switch to the “O” position.• Be aware that the metal parts of the tool will remain hot for some time •

after switching off. Allow at least 30mins for the gun to cool before leaving unattended.

Paint stripping

Connect the tool to the mains supply, and switch on.• Direct the hot air onto the paint to be removed, keeping the nozzle at •

least 25mm away from the surface.

NOTE: Take extra care when removing paint from window frames. The heat from this tool can cause damage to glass if used carelessly.

Allow the paint to soften, and remove using a suitable scraper.• Do not overheat the paint, if you notice smoke or blackening, stop •

heating. Do not allow waste to build up, or drop into the outlet nozzle (1) as it will •

be a ﬁre hazard.

Pipe defrosting

This hot air gun can be used to defrost frozen water pipes.• Using a suitable attachment, aim hot air at the frozen pipe. Move the hot •

air gun along the pipe so that the whole length defrosts evenly. Be aware of overheating areas directly behind the pipe being defrosted.• Do not attempt to defrost PVC pipe as the heat of the air may cause •

permanent damage.

Drying

This hot air gun can be used to dry damp wood or other materials.• Be very careful when operating power tools near damp materials, the •

presence of water greatly increases the danger of electric shock.

Always refer to the product manufacturers instructions if using the hot • air gun to dry plaster, paint, or other ﬁnishes. Do not use the hot air gun on any ﬂammable material, or any material than may produce hazardous fumes.

Stationary use

This hot air gun can also be used statically, keeping hands free to • manipulate the workpiece.

The hot air gun is designed to stand upright on a suitable workbench. • The outlet nozzle (1) should point straight upwards. The nozzle must not contact the workbench, or any other object.

Ensure that the power cable is well supported, and will not become • caught as you work.

Switch the hot air gun on, and move workpiece into the hot air ﬂow. Take • care to keep your hands and face away from the hot air.

Maintenance

Cleaning

Disconnect the machine from the mains supply before cleaning.• Keep your machine clean. Always clean dust and particles away, and •

never allow ventilation holes to become blocked. Do not allow waste to collect on any part of the tool. Use a soft brush, or dry cloth to clean the machine, if available blow through the ventilation holes with clean, dry, compressed air.

Disposal

Do not dispose of power tools, or other waste electrical and electronic • equipment, with household waste.

Contact your local waste disposal authority for information on the proper • way to dispose of tools.

Silverline Tools Guarantee

This Silverline product comes with a 3 year guarantee.

To qualify you must register this product at silverlinetools.com within 30 days of purchase. The guarantee period begins on the date of purchase as detailed on your sales receipt.

Terms & Conditions

This Guarantee and guarantee period becomes effective at the date of retail purchase as detailed on your sales receipt.

PLEASE KEEP YOUR SALES RECIEPT

If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.

If this product develops a fault after the 30 day period, return it to:

Silverline Tools Service Centre PO Box 2988 Yeovil BA21 1WU, UK

The guarantee claim must be submitted during the guarantee period. You must provide the original sales receipt indicating the purchase date, your

name, address and place of purchase before any work can be carried out. You must provide precise details of the fault requiring correction. All claims will be veriﬁed by Silverline Tools that the deﬁciencies are of a

material or manufacturing fault within the guarantee period. We do not refund carriage. All products should be in a suitably clean and

safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.

All work will be carried out by Silverline Tools or its authorised repair agents. The repair or replacement of the product will not extend the period of

guarantee. Defects recognised by us as being covered by the guarantee shall be

corrected by means of repair of the tool free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.

Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.

2000W Hot Air Gun127655

Registering your purchase

Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-

Your personal details• Details of the product and purchase information •

Once this information is entered your guarantee certiﬁcate will be created in PDF format for you to print out and keep with your purchase.

The repair or replacement of your product under guarantee provides beneﬁts which are additional to and do not affect your statutory rights as a consumer.

What is covered:

The repair of the product, if it can be veriﬁed to the satisfaction of the Silverline Tools that the deﬁciencies were due to faulty materials or workmanship within the guarantee period of purchase.

If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.

Use of the product in the EU.

What is not covered:

Silverline Tools does not guarantee repairs required as a result of: Normal wear and tear caused by use in accordance with the operating

instructions eg blades, brushes, belts, bulbs, batteries etc. The replacement of any provided accessories drill bits, blades, sanding

sheets, cutting discs and other related items. Accidental damage, faults caused by negligent use or care, misuse, neglect,

careless operation or handling of the product. Use of the product for anything other than normal domestic purposes. Change or modiﬁcation of the product in any way. Use of parts and accessories which are not Silverline Tools genuine

components. Faulty installation (except installed by Silverline Tools). Repairs or alterations carried out by parties other than Silverline Tools or its

authorised repair agents. Claims other than the right to correction of faults on the tool named in these

guarantee conditions are not covered by the guarantee.

EC Declaration of Conformity

The undersigned: Mr Philip Ellis as authorized by: Silverline Tools

Declares that the

Name/ model: Hot Air Gun Type/ serial no: 127655

Net installed power: 230V~ 50Hz 2000W Conforms to the following Directives:

Electromagnetic Compatibility Directive 2004/108/EC• Low Voltage Directive 2006/95/EC• EN50366/A1:2006• EN55014-1/A2:2002• EN55014-2/A1:2001• EN60335-1/A2:2006• EN60335-2-45:2002• EN61000-3-2/A2:2005• EN61000-3-3/A2:2005•

The technical documentation is kept by: Silverline Tools

Notiﬁed body: TUV SUD

Place of declaration: Munich, Germany

Date: 20/04/10

Signed by:

Position in Company: Director

Name and address of Manufacturer or Authorised representative:

Silverline Tools, Boundary Way, Lufton Trading Estate, Yeovil, Somerset, BA22

8HZ United Kingdom

www.silverlinetools.com

Description des Symboles

La plaque de valeur nominale sur votre outil peut afﬁcher des symboles. Ces symboles constituent des informations importantes concernant le produit ou des instructions sur son utilisation.

Port de protection anti-bruit. Port de lunettes de sécurité. Port de masques respiratoires. Protection principale d'usure.

Protection de main d'usage.

Lisez le manuel d’instruction.

Double isolation pour une protection supplémentaire.

Attention ! Surfaces chaudes.

Conforme à la réglementation et aux normes de sécurité pertinentes.

Protection De L’environnement

Les déchets de produits électriques ne doivent pas être mis au rebut avec les ordures ménagères. Veuillez les recycler dans les centres existants. Consultez les autorités locales ou votre revendeur sur la façon de recycler.

Spéciﬁcation

Tension.................................................230V~

Fréquence ............................................50Hz

Puissance .............................................2000W

Température de sortie maximale ..........600°C

Débit d’air maximum ............................650L/min

Classe de protection .............................

L’intensité saine pour l’opérateur peut dépasser 85dB(A)

et mesures de protection de bruit sont nécessaires

Du fait de l’évolution constante de notre développement

produits, les spéciﬁcations des produits Silverline peuvent

changer sans notiﬁcation préalable.

Conditions Générales de Sécurité

Lisez attentivement ce manuel ainsi que toute étiquette apposée sur l’outil, et assurez-vous d’en comprendre le sens, avant l’utilisation. Rangez ces consignes avec l’outil, pour référence ultérieure. Assurez-vous que toutes les personnes qui utilisent cet outil ont attentivement pris connaissance de ce manuel.

Sachez qu’utiliser un outil conformément aux prescriptions, n’élimine pas tout facteur de risque résiduel. Utilisez avec prudence. N’utilisez pas cet outil si vous avez des doutes quant à la manière de le faire de façon sûre et correcte.

Conservez les éléments de protection à leur place

Conservez les éléments de protection à leur place, en bon état de • fonctionnement, correctement réglés et alignés. N’utilisez jamais un outil si l’un des éléments de protection fournis est manquant. Si l’un des éléments de protection est endommagé, remplacez-le avant toute utilisation.

Retirez les clés de réglage

Assurez-vous que les clés et autres dispositifs de réglage ont été retirés • de l’outil avant de l’utiliser.

Nettoyez la zone de travail

Des accidents peuvent se produire quand les établis et zones de travail • sont encombrés ou sales ; pareillement, le sol doit être dégagé et vous devez éviter de travailler sur un sol glissant. En cas de travail à l’extérieur, appréciez les risques de glissement ou de chute avant d’utiliser l’outil.

Enfants et animaux

Maintenez une distance de sécurité entre les enfants ou les animaux et • votre zone de travail. Rangez les outils dans un lieu sûr fermé à clé, hors de portée des enfants. Ne laissez pas les enfants ou des personnes non formées utiliser cet outil.

Utilisation de l’outil correct

Ne tentez pas d’utiliser un outil à des ﬁns pour lesquelles il n’est pas conçu. • Cet outil n’est pas conçu pour un usage industriel.•

Port de vêtements et de chaussures adaptés

Ne portez pas des vêtements amples, cravate, bijoux ou autre élément qui • pourraient être happés. Au besoin, portez des chaussures antidérapantes ou équipées d’une coque de protection des orteils. Les cheveux longs doivent être couverts ou noués vers l’arrière.

Conservez l’équilibre

Ne tentez pas de travailler dans des endroits hors de portée, conservez • une stabilité correcte en permanence, n’utilisez pas d’outils quand vous êtes sur une surface instable.

Accessoires

L’utilisation de tout équipement ou accessoire différents de ceux • mentionnés dans ce manuel peut provoquer des dommages ou des blessures. L’utilisation d’accessoires inadéquats peut être dangereuse et, en outre, annule la garantie.

Ne vous tenez droit sur l’outil

En vous tenant sur l’outil ou son support, vous pouvez être gravement • blessé si l’outil venait à être mis en service par inadvertance, ou encore s’il s’écrasait. Ne rangez pas du matériel au-dessus ou à proximité de l’outil et de telle sorte qu’il faille se tenir sur l’outil ou son support pour atteindre ce matériel.

Travail en sécurité

Dans la mesure du possible, immobilisez la pièce sur laquelle vous • travaillez. Si cela est possible, serrez la pièce dans un étau ou maintenez-la par une attache de manière à disposer des deux mains pour manier l’outil.

Assurez-vous de l’absence de pièces endommagées ou manquantes

Avant chaque utilisation, assurez-vous qu’aucune pièce ne manque ou • n’est endommagée ; assurez-vous également du fonctionnement correct et de la bonne marche des fonctions voulues. Vériﬁez l’alignement et assurez-vous de l’absence de gommage des pièces mobiles. Toute protection et autre pièce endommagées doivent être immédiatement réparées ou remplacées par un centre de service agréé. N’UTILISEZ

AUCUN OUTIL DÉFECTUEUX.

Sécurité Électrique

Cet outil doit être protégé par un fusible adapté.• Pour prévenir tout risque d’électrocution et d’incendie, n’exposez pas cet •

outil à la pluie, à l’eau ou à l’humidité. Aucune pièce interne ne peut être réparée par l’utilisateur hormis celles •

mentionnées dans ce manuel. Conﬁez toutes les interventions à du personnel d’entretien qualiﬁé. •

Ne déposez aucune pièce de carrosserie de l’outil à moins que vous ne soyez qualiﬁé pour le faire ; des tensions dangereuses existent à l’intérieur de l’outil.

L’utilisation d’un interrupteur de protection contre les courants de court-• circuit réduit les risques d’électrocution.

Environnements dangereux

N’utilisez pas les outils électriques dans une ambiance humide; • n’exposez aucun outil à la pluie. Prévoyez un espace de travail adéquat et assurez un éclairage correct de la zone. N’utilisez aucun outil électrique en présence d’un risque d’explosion ou d’incendie dû à des matières

+ 19 hidden pages

Silverline Hot Air Gun 2000W User Manual [en, de, es, fr, it]

Specifications and Main Features

Frequently Asked Questions

User Manual
