Silicon Laboratories SI5351A-B-C User Manual

Download

Si5351A/B/C

Si5351A

Multi

Synth

N = 2 or 7

SSEN

OEB

Multi

Synth

Multi Synth

Si5351B

PLL

VCXO

I2C

SSEN

OEB

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Si5351C

PLLA

CLKIN

PLLB

I2C

INTR

OEB

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

OSC

PLLB

PLLA

OSC

10-MSOP

24-QSOP

20-QFN

I2C-PROGRAMMABLE ANY-FREQUENCY CMOS CLOCK GENERATOR + VCXO

Features

 Generates up to 8 non-integer-rel ated

 I  Exact frequency synthesis at each output

 Highly linear VCXO  Optional clock input (CLKIN)  Low output period jitter: 100 ps pp  Configurable spread spec trum selectable

 Operates from a low-cost, fixed frequency  Supports static phase offset

 Programmable rise/fall time contro l

Applications

 HDTV, DVD/Blu-ray, set-top box  Audio/video equip me nt, gaming  Printers, scanners, projectors

Description

The Si5351 is an I2C configurable clock generator that is ideally suited for replacing crystals, crystal oscillators, VCXOs, phase-locked loops (PLLs), and fanout buffers in cost-sensitive applications. Based on a PLL/VCXO + high resolution MultiSynth fractional divider architecture, the Si5351 can generate any frequency up to 160 MHz on each of its outputs with 0 ppm error. Three versions of the Si5351 are available to meet a wide variety of applications. The Si5351A generates up to 8 free-running clocks using an internal oscillator for replacing crystals and crystal oscillators. The Si5351B adds an internal VCXO and provides the flexibility to replace both free-running clocks and synchronous clocks. The Si5351B eliminates the need for high er cost, custom pullable crystals while providing reliable operation over a wide tuning range. The Si5351C offers the same flexibility but synchronizes to an external reference clock (CLKIN).

frequencies from 8 kHz to 160 MHz

C user definable configuration

(0 ppm error)

at each output crystal: 25 or 27 MHz

 Glitchless frequency changes  Separate voltage supply pins:

Core VDD: 2.5 or 3.3 V Output VDDO: 1.8, 2.5, or 3.3 V

 Excellent PSRR eliminates extern al

power supply filtering

 Very low power consumption  Adjustable output-output delay  Available in 3 packages types:

10-MSOP: 3 outputs 24-QSOP: 8 outputs 20-QFN (4x4 mm): 8 outputs

 PCIE Gen 1 compliant  Supports HCSL compatible swing

 Residential gatew ays  Networking/communication  Servers, storage  XO replacement

Ordering Information:

See page 66

Functional Block Diagram

This information applies to a product under development. Its characteristics and specifications are subject to change without notice.

Si5351A/B/C

2 Preliminary Rev. 0.95

Si5351A/B/C

TABLE OF CONTENTS

Section Page

1. Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2. Detailed Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.1. Input Stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.2. Synthesis Stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.3. Output Stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

3.4. Spread Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.5. Control Pins (OEB, SSEN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

4. I2C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

5. Configuring the Si5351 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

5.1. Writing a Custom Configuration to RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

5.2. Si5351 Application Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

5.3. Replacing Crystals and Crystal Oscillators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

5.4. Replacing Crystals, Crystal Oscillators, and VCXOs . . . . . . . . . . . . . . . . . . . . . . . .19

5.5. Replacing Crystals, Crystal Oscillators, and PLLs . . . . . . . . . . . . . . . . . . . . . . . . . .19

5.6. Replacing a Crystal with a Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

5.7. HCSL Compatible Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

6. Design Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

6.1. Power Supply Decoupling/Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

6.2. Power Supply Sequencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

6.3. External Crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

6.4. External Crystal Load Capacitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

6.5. Unused Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.6. Trace Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

7. Register Map Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

8. Register Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

9. Si5351A Pin Descriptions (20-Pin QFN, 24-Pin QSOP) . . . . . . . . . . . . . . . . . . . . . . . . . .62

10. Si5351B Pin Descriptions (20-Pin QFN, 24-Pin QSOP) . . . . . . . . . . . . . . . . . . . . . . . . .63

11. Si5351C Pin Descriptions (20-Pin QFN, 24-Pin QSOP) . . . . . . . . . . . . . . . . . . . . . . . . .64

12. Si5351A Pin Descriptions (10-Pin MSOP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

13. Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

14. Package Outline (24-Pin QSOP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

15. Package Outline (20-Pin QFN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

16. Package Outline (10-Pin MSOP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Document Change List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Preliminary Rev. 0.95 3

Si5351A/B/C

1. Electrical Specifications

Table 1. Recommended Operating Conditions

Parameter Symbol Test Condition Min Typ Max Unit

Ambient Temperature T

–402585°C

3.0 3.3 3.60 V

Core Supply Voltage V

2.25 2.5 2.75 V

1.71 1.8 1.89 V

Output Buffer Voltage V

DDOx

2.25 2.5 2.75 V

3.0 3.3 3.60 V

Notes:All minimum and maximum specifications are guaranteed and apply across the recommended operating conditions.

Typical values apply at nominal supply voltages and an operating temperature of 25 °C unless otherwise noted. VDD and VDDOx can be operated at independent voltages. Power supply sequencing for VDD and VDDOx requires that both voltage rails are powered at the same time.

Table 2. DC Characteristics

(VDD= 2.5 V ±10%, or 3.3 V ±10%, TA= –40 to 85 °C)

Parameter Symbol Test Condition Min Typ Max Unit

Enabled 3 outputs — 22 35 mA

Core Supply Current I

Output Buffer Supply Current (Per Output)*

DDOx

Enabled 8 outputs — 27 45 mA

Power Down (PDN = V

)— — 20 µA

CL=5pF — 2.2 5 mA

CLKIN, SDA, SCL

Vin < 3.6 V

VC — — 30 µA

Input Current

CLKIN

8 mA output drive current.

Output Impedance Z

See "6. Design Consider-

ations" on page 21.

*Note: Output clocks less than or equal to 10 0 MHz.

4 Preliminary Rev. 0.95

——10 µA

—85— 

Si5351A/B/C

Table 3. AC Characteristics

(VDD= 2.5 V ±10%, or 3.3 V ±10%, TA= –40 to 85 °C)

Parameter Symbol Test Condition Min Typ Max Unit

From VDD=V

Power-up Time T

RDY

output clock, C

>1MHz

CLKn

From OEB pulled low to valid

Output Enable Time T

Output Phase Offset P Spread Spectrum Frequency

Deviation Spread Spectrum Modulation

Rate

STEP

DEV

MOD

clock output, C

>1MHz

CLKn

Down spread –0.1 — –2.5 %

Center spread ±0.1 — ±1.5 %

VCXO Specifications (Si5351B onl y)

VCXO Control Voltage Range Vc 0 V VCXO Gain (configurable) Kv Vc = 10–90% of V VCXO Control Voltage Linearity KVL Vc = 10–90% of V VCXO Pull Range

(configurable)

PR V

= 3.3 V* ±30 0 ±240 ppm

VCXO Modulation Bandwidth — 10 — kHz

*Note: Contact Silicon Labs for 2.5 V VCXO operation.

to valid

DDmin

=5pF,

—110ms

——10 µs

— 333 — ps/step

30 31.5 33 kHz

/2 V

, VDD = 3.3 V 18 — 150 ppm/V

–5 — +5 %

Table 4. Input Clock Characteristics

(VDD= 2.5 V ±10%, or 3.3 V ±10%, TA= –40 to 85 °C)

Parameter Symbol Test Condition Min Typ Max Units

CLKIN Input Low Voltage V CLKIN Input High Voltage V CLKIN Frequency Range f

CLKIN

–0.1 — 0.3 x V

0.7 x V

—3.60V

10 — 100 MHz

Preliminary Rev. 0.95 5

Si5351A/B/C

Table 5. Output Clock Characteristics

(VDD= 2.5 V ±10%, or 3.3 V ±10%, TA=–40 to 85°C)

Parameter Symbol Test Condition Min Typ Max Units

Frequency Range F

CLK

Load Capacitance C

Duty Cycle DC

Rise/Fall Time

t Output High Voltage V Output Low Voltage V Period Jitter J Period Jitter VCXO J Cycle-to-Cycle Jitter J Cycle-to-Cycle Jitter

VCXO RMS Phase Jitter J RMS Phase Jitter VCXO J

PER

PER_VCXO

CC_VCXO

RMS

RMS_VCXO

0.008 — 160 MHz

Measured at V

=50MHz

CLK

20%–80%, CL=5pF,

Drive Strength = 8 mA

/2,

—515pF

45 50 55 %

0.5 1 1.5 ns

0.5 1 1.5 ns – 0.6 — — V

CL=5pF

——0.6V — 35 100 ps pk-pk

Measured over 10k cycles

— 60 110 ps pk-pk —3090ps pk

Measured over 10k cycles

—5095ps pk

— 3.5 11 ps rms

12 kHz–20 MHz

— 8.5 18.5 ps rms

Table 6. Crystal Requirements

Parameter

Crystal Frequency f Load Capacitance C Equivalent Series Resistance r Crystal Max Drive Level d

Notes:

1. Crystals which require load capacitances of 6, 8, or 10 pF should use the device’s internal load capacitance for

optimum performance. See register 183 bits 7:6. A crystal with a 12 pF load capacitance requirement should use a combination of the internal 10 pF load capacitors in addition to external 2 pF load capacitors.

2. Refer to “AN551: Crystal Selection Guide” for more details.

1,2

Symbol Min Typ Max Unit

XTAL

ESR

25 — 27 M Hz

6—12pF ——150 ——100µW

6 Preliminary Rev. 0.95

Si5351A/B/C

Table 7. I2C Specifications (SCL,SDA)

Parameter

LOW Level Input Voltage

HIGH Level Input Voltage

Hysteresis of Schmitt Trigger Inputs

LOW Level Output Voltage (open drain or open collector) at 3 mA Sink Current

Input Current I Capacitance for

Each I/O Pin

C Bus

Timeout

Symbol Test Condition Standard Mode

–0.5

ILI2C

IHI2C

HYS

= 2.5/3.3 V 0 0.4 0 0.4 V

DDI2C

= 1.8 V — — 0 0.2 x V

OLI2C

II2C

VIN= –0.1 to V

II2C

DDI2C

Timeout Enabled 25 35 25 35 ms

DDI2C

Fast Mode

100 kbps

Min Max Min Max

0.7 x V

0.3 x V

DDI2

3.63 0.7 x V

400 kbps

–0.5 0.3 x V

DDI2C

3.63 V

Unit

——0.1 —V

DDI2C

–10 10 –10 10 µA

—4 — 4pF

Notes:

1. Refer to NXP’s UM10204 I

www.nxp.com/acrobat_download/usermanuals/UM10204_3.pdf.

2. Only I2C pullup voltages (VDDI2C) of 2.25 to 3.63 V are supported.

C-bus specification and user manual, revision 03, for further details, go to:

Table 8. Thermal Characteristics

Parameter Symbol Test Condition Package Value Unit

10-MSOP 131 °C/W

Thermal Resistance Junction to Ambient

Thermal Resistance Junction to Case



Still Air

24-QSOP 80 °C/W

20-QFN 51 °C/W 10-MSOP 43 °C/W 24-QSOP 31 °C/W

20-QFN 16 °C/W

Preliminary Rev. 0.95 7

Si5351A/B/C

Table 9. Absolute Maximum Ratings

Parameter Symbol Test Condition Value Unit

DC Supply Voltage V

Input Voltage

Junction Temperature T Soldering Temperature (Pb-free

profile) Soldering Temperature Time at

TPEAK (Pb-free profile)

Notes:

1. Permanent de vice damage may occur if the absolute maximum ratings are exceeded. Functional operation should be restricted to the conditions as specified in the operational sections of this data sheet. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

2. The device is compliant with JEDEC J-STD-020.

DD_max

IN_CLKIN

IN_VC

IN_XA/B

PEAK

CLKIN, SCL, SDA –0.5 to 3.8 V

VC –0.5 to (VDD+0.3) V

Pins XA, XB –0.5 to 1.3 V V

–0.5 to 3.8 V

–55 to 150 °C

260 °C

20–40 Sec

8 Preliminary Rev. 0.95

2. Detailed Block Diagrams

PLL

SDA

SCL

OSC

VDDO

CLK0

CLK1

CLK2

Mu lt iSynth

VDD

GND

10-MSOP

Si5351A 3-Output

CLK0 CLK1

VDDOA

CLK2 CLK3

VDDOB

CLK4 CLK5

VDDOC

CLK6 CLK7

VDDOD

MultiSynth

Mu lt iSynth

VDD

GND

20-QFN, 24-QSOP

SCL

SDA

Control

Logic

OEB

SSEN

I2C

Interface

Si5351A 8-Output

I2C

Interfa ce

PLL

OSC

Si5351A/B/C

Figure 1. Block Diagrams of 3-Output and 8-Output Si5351A Devices

Preliminary Rev. 0.95 9

Si5351A/B/C

OSC

PLL

VCXO

CLK0 CLK1

VDDOA

CLK2 CLK3

VDDOB

CLK4 CLK5

VDDOC

CLK6 CLK7

VDDOD

MultiSynth

VDD

GND

Si5351B

SCL

SDA

Control

Logic

OEB

SSEN

I2C

Interface

20-QFN, 24-QSOP

CLK0 CLK1

VDDOA

CLK2 CLK3

VDDOB

CLK4 CLK5

VDDOC

CLK6 CLK7

VDDOD

MultiSynth

VDD

GND

Si5351C

PLL

OSC

CLKIN

SCL

SDA

Control

Logic

INTR

OEB

I2C

Interface

20-QFN, 24-QSOP

Figure 2. Block Diagrams of Si5351B and Si5351C 8-Output Devices

10 Preliminary Rev. 0.95

Si5351A/B/C

Input

Stage

Synthesis

Stage 1

PLL B

(VCXO)

PLL A

(SSC)

VCXO

OSC

XTAL

CLKIN

Div

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

Synthesis

Stage 2

Output

Stage

CLK0 CLK1

VDDOA

CLK2 CLK3

VDDOB

CLK4 CLK5

VDDOC

CLK6 CLK7

VDDOD

Selectable internal

load capacitors

6 pF, 8 pF, 10 pF

Optional

Additional external

load capacitors

2 pF)

3. Functional Description

The Si5351 is a versatile I2C programmable clock generator that is ideally suited for replacing crystals, crystal oscillators, VCXOs, PLLs, and buffers. A block diagram showing the general architecture of the Si5351 is shown in Figure 3. The device consists of an input stage, two synthesis stages, and an output stage.

The input stage accepts an external crystal (XTAL), a clock input (CLKIN), or a control voltage input (VC) depending on the version of the device (A/B/C). The first stage of synthesis multiplies the input frequencies to an high-frequency intermediate clock, while the second stage of synthesis uses high resolution MultiSynth fractional dividers to generate the desired output frequencies. Additional integer division is provided at the output stage for generating output frequencies as low as 8 kHz. Crosspoint switches at each of the synthesis stages allows total flexibility in routing any of the inputs to any of the outputs.

Because of this high resolution and flexible synthesis architecture, the Si5351 is capable of generating synchronous or free-running non-integer related clock frequencies at each of its outputs, enabling one device to synthesize clocks for multiple clock domains in a design.

Figure 3. Si5351 Block Diagram

3.1. Input Stage

3.1.1. Crystal Inputs (XA, XB)

The Si5351 uses a fixed-frequency standard AT-cut crystal as a reference to the internal oscillator. The output of the oscillator can be used to provide a free-running reference to one or both of the PLLs for generating asynchronous clocks. The output frequency of the oscillator will operate at the crystal frequency, either 25 MHz or 27 MHz. The crystal is also used as a reference to the VCXO to help maintain its frequency accuracy.

Internal load capacitors (C to the Si5351. Options for internal load capacitors are 6, 8, or 10 pF. Crystals with alternate load capacitance requirements are supported using additional external load capacitors as shown in Figure 4. Refer to application note AN551 for crystal recommendations.

) are provided to eliminate the need for external components when connecting a crystal

Figure 4. External XTAL with Optional Load Capacitors

Preliminary Rev. 0.95 11

Si5351A/B/C

CLK0

Multi Synth

CLK1

CLK2

Additional MultiSynths

can be “linked” to the

VCXO to generate

additional clock

frequencies

XA XB

OSC

VCXO

Multi Synth

Control Voltage

Fixed Frequency

Crystal (non-pullable)

The clock frequency

generated from CLK0 is

controlled by the VC input

3.1.2. External Clock Input (CLKIN)

The external clock input is used as a clock reference for the PLLs when generating synchronous clock outputs. CLKIN can accept any frequency from 10 to 100 MHz. A divider at the input stage limits the PLL inp ut freq uen cy to 30 MHz.

3.1.3. Voltage Control Input (VC)

The VCXO architecture of the Si5350B eliminates the need for an external pullable crystal. Only a standard, lowcost, fixed-frequency (25 or 27 MHz) AT-cut crystal is required.

The tuning range of the VCXO is configurable allowing for a wide variety of applications. Key advantages of the VCXO design in the Si5351 include high linearity, a wide operating range (linear from 10 to 90% of VDD), and reliable startup and operation. Refer to Table 3 on page 5 for VCXO specification details.

A unique feature of the Si5351B is its ability to generate multiple output frequencies controlled by the same control voltage applied to the VC pin. This replaces multiple PLLs or VCXOs that would normally be locked to the same reference. An example is illustrated in Figure 9 on page 15.

3.2. Synthesis Stages

The Si5351 uses two stages of synthesis to generate its final output clocks. The first stage uses PLLs to multiply the lower frequency input references to a high-frequency intermediate clock. The second stage uses highresolution MultiSynth fractional dividers to generate frequencies in the range of 1 MHz to 100 MHz. It is also possible to generate two unique frequencies up to 160 MHz on two or more of the outputs.

A crosspoint switch at the input of the first stage allows each of the PLLs to lock to the CLKIN or the XTAL input. This allows each of the PLLs to lock to a diff erent source for g enerating in dependent fr ee-running and synchronous clocks. Alternatively, both PLLs could lock to the same source. The crosspoint switch at the input of the second stage allows any of the MultiSynth dividers to connect to PLLA or PLLB. This flexible synthesis architecture allows any of the outputs to generate synchronou s or non-synchronous clocks, with spre ad spectrum or without spread spectrum, and with the flexibility of generating non-integer related clock frequencies at each output.

Since the VCXO already generates a high-frequency intermediate clock, it is fed directly into the second stage of synthesis. The MultiSynth high-resolution dividers synthesize the VCXO center frequency to any frequency in the range of ~391 kHz to 160 MHz. The center frequency is then controlled (or pulled) by the VC input. An interesting feature of the Si5351 is that the VCXO output can be routed to more than one MultiSynth divider. This creates a VCXO with multiple output frequencies controlled from one VC input as shown in Figure 5.

Frequencies down to 8 kHz can be generated by applying the R divider at the output of the Multisynth (see Figure 5 below).

Figure 5. Using the Si5351 as a Multi-Output VCXO

3.3. Output Stage

An additional level of division (R) is available at the output stage for generating clocks as low as 8 kHz. All output drivers generate CMOS level outputs with sep arate output volt age supply pins (VDDOx) allowing a dif ferent vo ltage signal level (1.8, 2.5, or 3.3 V) at each of the four 2-output banks.

12 Preliminary Rev. 0.95

Si5351A/B/C

Reduced

Amplitude

and EMI

Down Spread

Reduced

Amplitude

and EMI

Center Spread

No Spread

Spectrum

Center

Frequency

Amplitude

3.4. Spread Spectrum

Spread spectrum can be enabled on any of the clock outputs that use PLLA as its reference. Spread spectrum is useful for reducing electromagnetic interference (EMI). E nab ling spre ad spectrum on a n output clock modu lates its frequency, which effectively reduces the overall amplitude of its radiated energy. See “AN554: Si5350/51 PCB Layout Guide” for details. Note that spread spectrum is not available on clocks synchronized to PLLB or to the VCXO.

The Si5351 supports several levels of spread spectrum allowing the designer to chose an ideal compromise between system performance and EMI comp lia nce .

Figure 6. Available Spread Spectrum Profiles

3.5. Control Pins (OEB, SSEN)

The Si5351 offers control pins for enabling/disabling clock outputs and spread spectrum.

3.5.1. Output Enable (OEB)

The output enable pin allows enabling or disabling outputs clocks. Output clocks are enabled when the OEB pin is held low, an d disabled when pulle d high. When disabled, the output state is configur able as disa bled high , disa bled low, or disabled in high-impedance.

The output enable control circuitry ensures glitchless op eration by st arting th e output clock cycle on the first lea ding edge after OEB is pulled low. When OEB is pulled high, the clock is allowed to complete its full clock cycle before going into a disabled state.

3.5.2. Spread Spectrum Enable (SSEN)—Si5351A and Si5351B only

This control pin allows disabling the spread spectrum feature for all outputs that were configured with spread spectrum enabled. Hold SSEN low to disable spread spectrum. The SSEN pin provides a convenient method of evaluating the effect of using spread spectrum clocks during EMI compliance testing.

Preliminary Rev. 0.95 13

Si5351A/B/C

SCL

VDD

SDA

I2C Bus

INTR

C Address Select:

Pull-up to VDD (A0 = 1)

Pull-down to GND (A0 = 0)

Si5351

>1k

4.7 k

Slave Address

1 1 0 0 0 0 0/1

0123456

4. I2C Interface

Many of the functions and features of the Si5351 are controlled by reading and writing to the RAM space using the

C interface. The following is a list of the common features that are controllable through the I2C interface. A

summary of register functions is shown in Section 7.

 Read Status Indicators

Loss of signal (LOS) for the CLKIN input Loss of lock (LOL) for PLLA and PLLB

 Configuration of multiplication and divider values for the PLLs, MultiSynth dividers  Configuration of the Spread Spectru m profile (down or center spread, modulation percentage)  Control of the cross point switch selection for each of the PLLs and MultiSynth dividers  Set output clock options

Enable/disable for each clock output Invert/non-invert for each clock output

Output divider values (2 Output state when disabled (stop hi, stop low, Hi-Z) Output phase offset

The I2C interface operates in slave mode with 7-bit addressing and can operate in Standard-Mode (100 kbps) or Fast-Mode (400 kbps) and supports burst data transfer with auto address increments.

The I

C bus consists of a bidirectional serial data line (SDA) and a serial clock input (SCL) as shown in Figure 7.

Both the SDA and SCL pins must be connected to the VDD supply via an external pull-up as recommended by the

C specification.

, n=1.. 7)

Figure 7. I2C and Control Signals

The 7-bit device (slave) address of the Si5351 consist of a 6-bit fixed address plus a user selectable LSB bit as shown in Figure 8. The LSB bit is selectable as 0 or 1 using the optional A0 pin which is useful for applications that require more than one Si5351 on a single I

C bus.

Figure 8. Si5351 I2C Slave Address

Data is transferred MSB first in 8-bit words as specified by the I2C specification. A write command consists of a 7bit device (slave) address + a write b it, an 8-bit register ad dress, and 8 bits of data as shown in Figure 9. A write burst operation is also shown where every additional data word is written using to an auto-incremented address.

14 Preliminary Rev. 0.95

Si5351A/B/C

1 – Read 0 – Write A – Acknowledge (SDA LOW ) N – Not Acknowledge (SDA HIGH) S – START condition P – STOP c o n d it io n

From slave to master From master to slave

Write Operation – Single Byte

S 0 A Re g A ddr [7:0 ]Slv Addr [6:0] A Da ta [7:0] PA

Write Operation - Burst (Auto Address Increment)

Reg Addr +1

S 0 A Re g A ddr [7:0 ]Slv A d d r [6 :0 ] A Data [7 :0] A Da ta [ 7 :0 ] PA

1 – Read 0 – Write A – Acknowledge (SDA LOW ) N – Not Acknowledge (SDA HIGH) S – START condition P – STOP c o n d it io n

From slave to master From master to slave

Re a d O pera tio n – Sin gle B y te

S 0 A Re g A ddr [7:0 ]Slv Addr [6:0] A P

Re ad Ope ra tion - Burs t (Auto Add res s In c re ment)

Reg Addr +1

S 1 ASlv A d d r [6 :0 ] Data [7 :0 ] PN

S 0 A R e g A ddr [7:0 ]Slv A d d r [6 :0 ] A P

S 1 ASlv A d d r [6 :0 ] Data [7 :0 ] A PNData [7 :0 ]

Figure 9. I2C Write Operation

A read operation is performed in two stages. A data write is used to set the register address, then a data read is performed to retrieve the data from the set address. A read burst operation is also supported. This is shown in Figure 10.

Figure 10. I2C Read Operation

AC and DC electrical specifications for the SCL and SDA pins are shown in Table 7. The timing specifications and timing diagram for the I with SMBus interfaces.

C bus is compatible with the I2C-Bus Standard. SDA timeout is supported for compatibility

Preliminary Rev. 0.95 15

Si5351A/B/C

Power-Up

RAM

NVM

(OTP)

Default

Config

5. Configuring the Si5351

The Si5351 is a highly flexible clock generator which is entirely configurable through its I2C interface. The device’s default configuration is stored in non-volatile memory (NVM) as shown in Figure 11. The NVM is a one time programmable memory (OTP) which can store a custom user configuration at power-up. This is a useful feature for applications that need a clock present at power-up (e.g., for providing a clock to a processor).

Figure 11. Si5351 Memory Configuration

During a power cycle the contents of the NVM are copied into random access memory (RAM), which sets the device configuration that will be used during normal operation. Any changes to the device configuration after power-up are made by reading and writing to registers in the RAM space through the I register map is shown in Section "8. Register Descriptions" on page 25.

C interface. A detailed

5.1. Writing a Custom Configuration to RAM

To simplify device configuration, Silicon Labs has released the ClockBuilder Desktop. The software serves two purposes: to configure the Si5351 with optimal configuration based on the desired frequencies and to control the EVB when connected to a host PC.

The optimal configuration can be saved from the software in text files that can be used in any system, which configures the device over I runs on Windows XP, Windows Vista, and Windows 7.

Once the configuration file has been saved, the device can be progr am med via I Figure 12.

C. ClockBuilder Desktop can be downloaded from www.silabs.com/ClockBuilder and

C by following the steps shown in

16 Preliminary Rev. 0.95

Disable Outputs

Set CLKx_DIS high; Reg. 3 = 0xFF

Powerdown all output drivers

Reg. 16, 17, 18, 19, 20, 21, 22, 23 =

0x80

Set interrup t masks

(see register 2 description)

Write new configuration to device using

the contents of the register map

generated by ClockBuilder Desktop. This

step also powers up the output drivers.

(Registers 15-92 and 149-170)

Apply PLLA and PLLB soft reset

Reg. 177 = 0xAC

Enable desired outputs

(see Register 3)

Use ClockBuilder

Desktop v3.1 or later

Map

Si5351A/B/C

Figure 12. I2C Programming Procedure

Preliminary Rev. 0.95 17

Si5351A/B/C

48 MHz

USB

Controller

28.322 MHz

125 MHz

Video/Audio

Processor

74.25/1.001 MHz

24.576 MHz

OSC

CLK0

CLK1

CLK2

CLK3

CLK4

CLK5

PLL

Multi

Synth

Multi

Synth

Multi

Synth

74.25 MHz

27 MHz

Si5351A

Multi

Synth

Multi

Synth

Multi

Synth

Multi

Synth

HDMI

Port

Ethernet

PHY

Multi

Synth

22.5792 MHz

CLK6

33.3333 MHz

CLK7

CPU

Note: Si5351A replaces crystals, XOs, and PLLs.

5.2. Si5351 Application Examples

The Si5351 is a versatile clock generator which serves a wide variety of applications. The following examples show how it can be used to replace crystals, crystal oscillators, VCXOs, and PLLs.

5.3. Replacing Crystals and Crystal Oscillators

Using an inexpensive external crystal, the Si5351A can generate up to 8 different free-running clock frequencies for replacing crystals and crystal oscillators. A 3-output version packaged in a small 10-MSOP is also available for applications that require fewer clocks. An example is shown in Figure 13.

Figure 13. Using the Si5351A to Replace Multiple Crystals, Crystal Oscillators, and PLLs

18 Preliminary Rev. 0.95

Si5351A/B/C

Ethernet

PHY

USB

Controller

HDMI

Port

28.322 MHz

48 MHz

125 MHz

Video/Audio

Processor

74.25/1.001 MHz

24.576 MHz

OSC

CLK0

CLK1

CLK2

CLK3

CLK4

CLK5

PLL

VCXO

Multi Synth

74.25 MHz

27 MHz

Si5351B

Multi Synth

Free-running

Clocks

Synchronous

Clocks

Note: FBW = 10 kHz

Ethernet

PHY

USB

Controller

HDMI

Port

28.322 MHz

48 MHz

125 MHz

Video/Audio

Processor

74.25/1.001 MHz

24.576 MHz

OSC

CLK0

CLK1

CLK2

CLK3

CLK4

CLK5

PLL

Multi

Synth

Multi

Synth

Multi

Synth

74.25 MHz

CLKIN

25 MHz

Si5351C

Multi

Synth

Multi

Synth

Multi

Synth

54 MHz

Free-running

Clocks

Synchronous

Clocks

5.4. Replacing Crystals, Crystal Oscillators, and VCXOs

The Si5351B combines free-running clock generation and a VCXO in a single package for cost sensitive video applications. An example is shown in Figure 14.

Figure 14. Using the Si5351B to Replace Crystals, Crystal Oscillators, VCXOs, and PLLs

5.5. Replacing Crystals, Crystal Oscillators, and PLLs

The Si5350C generates synchronous clocks for applications that require a fully integrated PLL instead of a VCXO. Because of its dual PLL architecture, the Si5351C is capable of generating both synchronous and free-running clocks. An example is shown in Figure 15.

Figure 15. Using the Si5351C to Replace Crystals, Crystal Oscillators, and PLLs

Preliminary Rev. 0.95 19

Si5351A/B/C

Multi

Synth

Multi

Synth

Multi

Synth

PLLB

PLLA

OSC

VIN = 1 V

25/27 MHz

Note: Float the XB input while driving

the XA input with a clock

0.1 µF

Multi

Synth

Multi

Synth

Multi

Synth

PLLB

PLLA

OSC

Note: The complementary -180 degree out of phase output clock is generated using the INV function

511 

240 

ZO = 70 

0 

HCSL CLKIN

511 

240 

ZO = 70 

0 

5.6. Replacing a Crystal with a Clock

The Si5351 can be driven with a clock signal through the XA input pin.

Figure 16. Si5351 Driven by a Clock Signal

5.7. HCSL Compatible Outputs

The Si5351 can be configured to support HCSL compatible swing when the VDDO of the output pair of interest is set to 2.5 V (i.e., VDDOA must be 2.5 V when using CLK0/1; VDDOB must be 2.5 V for CLK2/3 and so on).

The circuit in the figure below must be applied to each of the two clocks used, and one of the clocks in the pair must also be inverted to generate a differential pair. See register setting CLKx_INV.

Figure 17. Si5350C Output is HCSL Compatible

20 Preliminary Rev. 0.95

Si5351A/B/C

6. Design Considerations

The Si5351 is a self-contained clock generator that requires very few external components. The following general guidelines are recommended to ensure optimum performance. Refer to “AN554: Si5350/51 PCB Layout Guide” for additional layout recommendations.

6.1. Power Supply Decoupling/Filtering

The Si5351 has built-in power supply filtering circuitry and extensive internal Low Drop Out (LDO) voltage regulators to help minimize the number of external bypass components. All that is recommended is one 0.1 µF decoupling capacitor per power supply pin. This capacitor should be mounted as close to the VDD and VDDOx pins as possible without using vias.

6.2. Power Supply Sequencing

The VDD and VDDOx (i.e., VDDO0, VDDO1, VDDO2, VDDO3) power supply pins have been separated to allow flexibility in output signal levels. If a minimum output-to-output skew is important, then all VDDOx must be applied before VDD. Unused VDDOx pins should be tied to VDD.

6.3. External Crystal

The external crystal should be mounted as close to the pins as possible using short PCB traces. The XA and XB traces should be kept away from other high-speed signal traces. See “AN551: Crystal Selection Guide” for more details.

6.4. External Crystal Load Capacitors

The Si5351 provides the option of using internal and external crystal load capacitors. If internal load capacitance is insufficient, capacitors of value < capacitors are used, they should be placed as close to the XA/XB pads as possible. See AN554 for more details.

2 pF may be used to increased equivalent load capacitance. If external load

6.5. Unused Pins

Unused voltage control pin should be tied to GND. Unused CLKIN pin should be tied to GND. Unused XA/XB pins should be left floating. Refer to "5.6. Replacing a Crystal with a Clock" on page 20 when using

XA as a clock input pin. Unused output pins (CLK0–CLK7) should be left floating. Unused VDDOx pins should be tied to VDD.

Preliminary Rev. 0.95 21

Si5351A/B/C

ZO = 85 ohms

Length = No Restrictions

CLK

(Op tio n a l re s ist o r fo r EMI management)

R = 0 ohms

6.6. Trace Characteristics

The Si5351A/B/C features various output current drives ranging from 2 to 8 mA (default). It is recommended to configure the trace characteristics as shown in Figure 18 when an output drive setting of 8 mA is used.

Figure 18. Recommended Trace Characteristics with 8 mA Drive Strength Setting

Note: Jitter is only specified at 6 and 8 mA drive strength.

22 Preliminary Rev. 0.95

Si5351A/B/C

7. Register Map Summary

The following is a summary of the register map used to read status, co ntrol, and configure the Si5351.

0 SYS_INIT LOL_B LOL_A LOS REVID[1:0] 1 SYSCAL_

STKY

2 SYSCAL_

MASK

3 CLK7_EN CLK6_EN CLK5_EN CLK4_EN CLK3_EN CLK2_EN CLK1_EN CLK0_EN

4–8 Reserved

9 OEB_CLK7 OEB_CLK6 OEB_CLK5 OEB_CLK4 OEB_CLK3 OEB_CLK2 OEB_CLK1 OEB_CLK0

10–14 Reserved

15 0 0 0 0 PLLB_SRC PLLA_SRC 0 0 16 CLK0_PDN MS0_INT MS0_SRC CLK0_INV CLK0_SRC[1:0] CLK0_IDRV[1:0] 17 CLK1_PDN MS1_INT MS1_SRC CLK1_INV CLK1_SRC[1:0] CLK1_IDRV[1:0] 18 CLK2_PDN MS2_INT MS2_SRC CLK2_INV CLK2_SRC[1:0] CLK2_IDRV[1:0] 19 CLK3_PDN MS3_INT MS3_SRC CLK3_INV CLK3_SRC[1:0] CLK3_IDRV[1:0] 20 CLK4_PDN MS4_INT MS4_SRC CLK4_INV CLK4_SRC[1:0] CLK4_IDRV[1:0] 21 CLK5_PDN MS5_INT MS5_SRC CLK5_INV CLK5_SRC[1:0] CLK5_IDRV[1:0] 22 CLK6_PDN FBA_INT MS6_SRC CLK6_INV CLK6_SRC[1:0] CLK6_IDRV[1:0] 23 CLK7_PDN FBB_INT MS6_SRC CLK7_INV CLK7_SRC[1:0] CLK7_IDRV[1:0] 24 CLK3_DIS_STATE CLK2_DIS_STATE CLK1_DIS_STATE CLK0_DIS_STATE 25 CLK7_DIS_STATE CLK6_DIS_STATE CLK5_DIS_STATE CLK4_DIS_STATE

26–41 PLL, MultiSynth, and output clock delay offset Configuration Registers.

42 MS0_P3[15:8] 43 MS0_P3[7:0] 44 R0_DIV[2:0] MS0_P1[17:16] 45 MS0_P1[15:8] 46 MS0_P1[7:0] 47 MS0_P3[19:16] MS0_P2[19:16] 48 MS0_P2[15:8] 49 MS0_P2[7:0] 50 MS1_P3[15:8] 51 MS1_P3[7:0] 52 R1_DIV[2:0] MS1_P1[17:16] 53 MS1_P1[15:8] 54 MS1_P1[7:0] 55 MS1_P3[19:16] MS1_P2[19:16] 56 MS1_P2[15:8] 57 MS1_P2[7:0] 58 MS2_P3[15:8] 59 MS2_P3[7:0] 60 R2_DIV[2:0] MS2_P1[17:16] 61 MS2_P1[15:8] 62 MS2_P1[7:0] 63 MS2_P3[19:16] MS2_P2[19:16] 64 MS2_P2[15:8] 65 MS2_P2[7:0]

LOS_B_

STKY

LOS_B_

MASK

LOL_A_

STKY

LOL_A _

MASK

Use ClockBuilder Desktop Software to Determine These Register Values.

LOS_

STKY

LOS_

MASK

Preliminary Rev. 0.95 23

Si5351A/B/C

66 MS3_P3[15:8] 67 MS3_P3[7:0] 68 R3_DIV[2:0] MS3_P1[17:16] 69 MS3_P1[15:8] 70 MS3_P1[7:0] 71 MS3_P3[19:16] MS3_P2[19:16] 72 MS3_P2[15:8] 73 MS3_P2[7:0] 74 MS4_P3[15:8] 75 MS4_P3[7:0] 76 R4_DIV[2:0] MS4_P1[17:16] 77 MS4_P1[15:8] 78 MS4_P1[7:0] 79 MS4_P3[19:16] MS4_P2[19:16] 80 MS4_P2[15:8] 81 MS4_P2[7:0] 82 MS5_P3[15:8] 83 MS5_P3[7:0] 84 R5_DIV[2:0] MS5_P1[17:16] 85 MS5_P1[15:8] 86 MS5_P1[7:0] 87 MS5_P3[19:16] MS5_P2[19:16] 88 MS5_P2[15:8] 89 MS5_P2[7:0] 90 MS6_P1[7:0] 91 MS7_P1[7:0] 92 R7_DIV[2:0] R6_DIV[2:0]

93–164 PLL, MultiSynth, and output clock delay offset Configuration Registers.

165 CLK0_PHOFF[7:0] 166 CLK1_PHOFF[7:0] 167 CLK2_PHOFF[7:0] 168 CLK3_PHOFF[7:0] 189 CLK4_PHOFF[7:0] 170 CLK5_PHOFF[7:0]

173–176 Reserved

177 PLLB_RST PLLA_RST

178–182 Reserved

183 XTAL_CL

184–255 Reserved

Use ClockBuilder Desktop Software to Determine These Register Values.

24 Preliminary Rev. 0.95

Si5351A/B/C

8. Register Descriptions

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7SYS_INITSystem Initialization Status.

6LOL_BPLLB Loss Of Lock Status.

SYS_INIT LOL_B LOL_A LOS REVID[1:0]

RRRRRR R

During power up the device copies the content of the NVM into RAM and performs a system initialization. The device is not operational until initialization is complete. It is not recommended to read or write registers in RAM through the I plete. An interrupt will be triggered (INTR pin = 0, Si5351C only) during the system initialization period.

0: System initialization is complete. Device is ready. 1: Device is in system initialization mode.

Si5351A/C only . PLLB will operate in a locked state when it has a valid reference from CLKIN or XTAL. A loss of lock will occur if the frequency of the reference clock forces the PLL to operate outside of its lock rang e as specified in Table 3, or if the reference clock fails to meet the minimum requirements of a valid input signal as specified in Table 4. An interrupt will be triggered (INTR pin = 0, Si5351C) during a LOL condition.

0: PLL B is locked. 1: PLL B is unlocked. When the device is in this state it will trigger an interrupt causing the

INTR pin to go low (Si5351C only).

C interface until initialization is com-

5LOL_APLL A Loss Of Lock Status.

PLL A will operate in a locked state when it has a valid reference from CLKIN or XTAL. A loss of lock will occur if the frequency of the reference clock forces the PLL to operate outside of its lock range as specified in Table 3, or if the reference clock fails to meet the minimum requirements of a valid input signal as specified in Table 4. An interrupt will be triggered (INTR pin = 0, Si5351C only ) durin g a LO L co nd itio n.

0: PLL A is operating normally. 1: PLL A is unlocked. When the device is in this state it will trigger an interrupt causing the

INTR pin to go low (Si5351C only).

4LOSCLKIN Loss Of Signal (Si5351C Only).

A loss of signal status indicates if the reference clock fails to meet the minimum requirements of a valid input signal as specified in Table 4. An interrupt will be triggered (INTR pin = 0, Si5351C only) during a LOS condition. 0: Valid clock signal at the CLKIN pin.

1: Loss of signal detected at the CLKIN pin. 3:2 Reserved Leave as default. 1:0 REVID[1:0] Revision ID. Device revision number. Set at the factory.

Preliminary Rev. 0.95 25

Si5351A/B/C

Bit D7 D6 D5 D4 D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 SYS_INIT_STKY System Calibratio n Status Sticky Bit.

6 LOL_B_STKY PLLB Loss Of Lock Status Sticky Bit.

5 LOL_A_STKY PLLA Loss Of Lock Status Sticky Bit.

SYS_INIT_STKY LOL_B_STKY LOL_A_STKY LOS_STKY

R/W R/W R/W R/W R/W R/W R/W R/W

The SYS_INIT_STKY bit is triggered when the SYS_INIT bit (register 0, bit 7) is triggered high. It remains high until cleared. Writing a 0 to this register bit will cause it to clear.

0: No SYS_INIT interrupt has occurred since it was last cleared. 1: A SYS_INIT interrupt has occurred since it was last cleared.

The LOL_B_STKY bit is triggered when the LOL_B bit (register 0, bit 6) is triggered high. It remains high until cleared. Writing a 0 to this register bit will cause it to clear.

0: No PLL B interrupt has occurred since it was last cleared. 1: A PLL B interrupt has occurred since it was last cleared.

The LOL_A_STKY bit is triggered when the LOL_A bit (register 0, bit 5) is triggered high. It remains high until cleared. Writing a 0 to this register bit will cause it to clear. 0: No PLLA interrupt has occurred since it was last cleared.

1: A PLLA interrupt has occurred since it was last cleared.

4LOS_STKYCLKIN Loss Of Signal Sticky Bit (Si5351C Only).

The LOS_STKY bit is triggered when the LOS bit (register 0, bit 4) is triggered high. It remains high until cleared. Writing a 0 to this register bit will cause it to clear.

0: No LOS interrupt has occurred since it was last cleared. 1: A LOS interrupt has occurred since it was last cleared.

3:0 Reserved Leave as default.

26 Preliminary Rev. 0.95

Si5351A/B/C

Bit D7 D6 D5 D4 D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 SYS_INIT_MASK System Initialization Status Mask.

6 LOL_B_MASK PLLB Loss Of Lock Status Mask.

5 LOL_A_MASK PLL A Loss Of Lock Status Mask.

SYS_INIT_MASK LOL_B_MASK LOL_A_MASK LOS_MASK

R/W R/W R/W R/W R/W R/W R/W R/W

Use this mask bit to prevent the INTR pin (Si5351C only) from going low when SYS_INIT is asserted.

0: Do not mask the SYS_INIT interrupt. 1: Mask the SYS_INIT interrupt.

Use this mask bit to prevent the INTR pin (Si5351C only) from going low when LOL_B is asserted.

0: Do not mask the LOL_B interrupt. 1: Mask the LOL_B interrupt.

Use this mask bit to prevent the INTR pin (Si5351C only) from going low when LOL_A is asserted. 0: Do not mask the LOL_A interrupt.

1: Mask the LOL_A interrupt.

4 LOS_MASK CLKIN Loss Of Signal Mask (Si5351C Only).

Use this mask bit to prevent the INTR pin (Si5351C only) from going low when LOS is asserted.

0: Do not mask the LOS interrupt. 1: Mask the LOS interrupt.

3:0 Reserved Leave as default.

Preliminary Rev. 0.95 27

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7:0 CLKx_OEB Output Disable for CLKx.

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

CLK7_OEB CLK6_OEB CLK5_OEB CLK4_OEB CLK3_OEB CLK2_OEB CLK1_OEB CLK0_OEB

R/W R/W R/W R/W R/W R/W R/W R/W

Where x = 0, 1, 2, 3, 4, 5, 6, 7 0: Enable CLKx output. 1: Disable CLKx output.

OEB_CLK7 OEB_CLK6 OEB_CLK5 OEB_CLK4 OEB_CLK3 OEB_CLK2 OEB_CLK1 OEB_CLK0

R/W R/W R/W R/W R/W R/W R/W R/W

Bit N ame Function

7:0 OEB_CLKx OEB pin enable control of CLKx.

Where x = 0, 1, 2, 3, 4, 5, 6, 7

0: OEB pin controls enable/disable state of CLKx output.

1: OEB pin does not control enable/disable state of CLKx output.

28 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7:4 Reserved Leave as default.

3 PLLB_SRC Input Source Select for PLLB.

2 PLLA_SRC Input Source Select for PLLA.

1:0 Reserved Leave as default.

R/W R/W R/W R/W R/W R/W R/W R/W

0: Select the XTAL input as the reference clock for PLLB (Si5351A/C only). 1: Select the CLKIN input as the reference clock for PLLB (Si5351C only).

0: Select the XTAL input as the reference clock for PLLA. 1: Select the CLKIN input as the reference clock for PLLA (Si5351C only).

PLLB_SRC PLLA_SRC

Preliminary Rev. 0.95 29

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK0_PDN Clock 0 Power Down.

6MS0_INTMultiSynth 0 Integer Mode.

5MS0_SRCMultiSynth Source Select for CLK0.

4 CLK0_INV Output Clock 0 Invert.

CLK0_PDN MS0_INT MS0_SRC CLK0_INV CLK0_SRC[1:0] CLK0_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK0 output driver to conserve power when the output is unused.

0: CLK0 is powered up. 1: CLK0 is powered down.

This bit can be used to force MS0 into Integer mode to improve jitter perfor mance. Note that the fractional mode is necessary when a delay offset is specified for CLK0.

0: MS0 operates in fractional division mode. 1: MS0 operates in integer mode.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 0 is not inverted. 1: Output Clock 0 is inverted.

3:2 CLK0_SRC[1:0] Output Clock 0 Input Source.

These bits determine the input source for CLK0. 00: Select the XT AL a s the clock source for CLK0. This option by-p asses both synthesis

stages (PLL/VCXO & MultiSynth) and connects CLK0 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock source for CLK0. This by-passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK0 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input.

10: Reserved. Do not select this option. 11: Select MultiSynth 0 as the sour ce for CLK0. Select this option when using the

Si5351 to generate free-running or synchronous clocks.

1:0 CLK0_IDRV[1:0] CLK0 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

30 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK1_PDN Clock 1 Power Down.

6MS1_INTMultiSynth 1 Integer Mode.

5 MS1_SRC MultiSynth Source Select for CLK1.

4 CLK1_INV Output Clock 1 Invert.

CLK1_PDN MS1_INT MS1_SRC CLK1_INV CLK1_SRC[1:0] CLK1_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK1 output driver to conserve power when the output is unused.

0: CLK1 is powered up. 1: CLK1 is powered down.

This bit can be used to force MS1 into Integer mode to impro ve jitter pe rformanc e. Note that the fractional mode is necessary when a delay offset is specified for CLK1.

0: MS1 operates in fractional division mode. 1: MS1 operates in integer mode.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 1 is not inverted. 1: Output Clock 1 is inverted.

3:2 CLK1_SRC[1:0] Output Clock 1 Input Source.

These bits determine the input source for CLK1. 00: Select the XT AL as the clock source for CLK1. This option by-passes both synthesis

stages (PLL/VCXO & MultiSynth) and connects CLK1 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock source for CLK1. This by-passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK1 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input.

10: Reserved. Do not select this option. 11: Select MultiSynth 0 as the source for CLK1. Select this option when using the

Si5351 to generate free-running or synchronous clocks.

1:0 CLK1_IDRV[1:0] CLK1 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

Preliminary Rev. 0.95 31

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK2_PDN Clock 2 Power Down.

6MS2_INTMultiSynth 2 Integer Mode.

5MS2_SRCMultiSynth Source Select for CLK2.

4 CLK2_INV Output Clock 2 Invert.

CLK2_PDN MS2_INT MS2_SRC CLK2_INV CLK2_SRC[1:0] CLK2_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK2 output driver to conserve power when the output is unused.

0: CLK2 is powered up. 1: CLK2 is powered down.

This bit can be used to force MS2 into Integer mode to improve jitter performance. Note that the fractional mode is necessary when a delay offset is specified for CLK2.

0: MS2 operates in fractional division mode. 1: MS2 operates in integer mode.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 2 is not inverted. 1: Output Clock 2 is inverted.

3:2 CLK2_SRC[1:0] Output Clock 2 Input Source.

These bits determine the input source for CLK2. 00: Select the XTAL as the clock source for CLK2. This option by-passes both synthesis

stages (PLL/VCXO & MultiSynth) and connects CLK2 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock source for CLK2. This by-passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK2 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input.

10: Reserved. Do not select this option. 1 1: Select MultiSynth 0 as the source for CLK2. Select this option when using the Si5351

to generate free-running or synchronous clocks.

1:0 CLK2_IDRV[1:0] CLK2 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

32 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7CLK3_PDNCloc k 3 Pow e r Do wn .

6 MS3_INT MultiSynth 3 Integer Mode.

5MS3_SRCMultiSynth Source Select for CLK3.

4CLK3_INVOutput Clock 3 Invert.

CLK3_PDN MS3_INT MS3_SRC CLK3_INV CLK3_SRC[1:0] CLK3_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK3 output driver to conserve power when the output is unused.

0: CLK3 is powered up. 1: CLK3 is powered down.

This bit can be used to force MS3 into Integer mode to improve jitter performance. Note that the fractional mode is necessary when a delay offset is specified for CLK3.

0: MS3 operates in fractional division mode. 1: MS3 operates in integer mode.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 3 is not inverted. 1: Output Clock 3 is inverted.

3:2 CLK3_SRC[1:0] Output Clock 3 Input Source.

These bits determine the input source for CLK3.

1:0 CLK3_IDRV[1:0] CLK3 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

Preliminary Rev. 0.95 33

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK4_PDN Clock 4 Power Down.

6MS4_INTMultiSynth 4 Integer Mode.

5MS4_SRCMultiSynth Source Select for CLK4.

4 CLK4_INV Output Clock 4 Invert.

CLK4_PDN MS4_INT MS4_SRC CLK4_INV CLK4_SRC[1:0] CLK4_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK4 output driver to conserve power when the output is unused.

0: CLK4 is powered up. 1: CLK4 is powered down.

This bit can be used to force MS4 into Integer mode to improve jitter performance . Note that the fractional mode is necessary when a delay offset is specified for CLK4.

0: MS4 operates in fractional division mode. 1: MS4 operates in integer mode.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 4 is not inverted. 1: Output Clock 4 is inverted.

3:2 CLK4_SRC[1:0] Output Clock 4 Input Source.

These bits determine the input source for CLK4. 00: Select the XTAL as the clock source for CLK4. This option by-passes both synthe-

sis stages (PLL/VCXO & MultiSynth) and connects CLK4 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock sour ce for CL K4. Th is by- passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK4 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input.

10: Reserved. Do not select this option. 11: Select MultiSynth 0 as the sour ce for CLK4. Select this option when using the

Si5351 to generate free-running or synchronous clocks.

1:0 CLK4_IDRV[1:0] CLK4 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

34 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK5_PDN Clock 5 Power Down.

6MS5_INTMultiSynth 5 Integer Mode.

5MS5_SRCMultiSynth Source Select for CLK5.

CLK5_PDN MS5_INT MS5_SRC CLK5_INV CLK5_SRC[1:0] CLK5_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK5 output driver to conserve power when the output is unused. 0: CLK4 is powered up.

1: CLK4 is powered down.

This bit can be used to force MS5 into Integer mode to improve jitter performance . Note that the fractional mode is necessary when a delay offset is specified for CLK4.

0: MS5 operates in fractional division mode. 1: MS5 operates in integer mode.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

4 CLK5_INV Output Clock 5 Invert.

0: Output Clock 5 is not inverted. 1: Output Clock 5 is inverted.

3:2 CLK5_SRC[1:0] Output Clock 5 Input Source.

These bits determine the input source for CLK5. 00: Select the XTAL as the clock source for CLK5. This option by-passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK5 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock sour ce for CL K5. Th is by- passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK5 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input. 10: Reserved. Do not select this option. 11: Select MultiSynth 0 as the sour ce for CLK5. Select this option when using the Si5351 to generate free-running or synchronous clocks.

1:0 CLK5_IDRV[1:0] CLK5 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

Preliminary Rev. 0.95 35

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK6_PDN Clock 7 Power Down.

6 FBA_INT FBA MultiSynth Integer Mode.

5MS6_SRCMultiSynth Source Select for CLK6.

4 CLK6_INV Output Clock 6 Invert.

CLK6_PDN FBA_INT MS6_SRC CLK6_INV CLK6_SRC[1:0] CLK6_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK6 output driver to conserve power when the output is unused.

0: CLK6 is powered up. 1: CLK6 is powered down.

Set this bit according to ClockBuilder Desktop generated register map file.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 6 is not inverted. 1: Output Clock 6 is inverted.

3:2 CLK6_SRC[1:0] Output Clock 0 Input Source.

These bits determine the input source for CLK6. 00: Select the XTAL as the clock source for CLK6. This option by-passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK6 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock sour ce for CL K6. Th is by- passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK6 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input. 10: Reserved. Do not select this option. 11: Select MultiSynth 0 as the sour ce for CLK6. Select this option when using the Si5351 to generate free-running or synchronous clocks.

1:0 CLK6_IDRV[1:0] CLK6 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

36 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7 CLK7_PDN Clock 7 Power Down.

6 FBB_INT FBB MultiSynth Integer Mode.

5MS7_SRCMultiSynth Source Select for CLK7.

4 CLK7_INV Output Clock 7 Invert.

CLK7_PDN FBB_INT MS7_SRC CLK7_INV CLK7_SRC[1:0] CLK7_IDRV[1:0]

R/W R/W R/W R/W R/W R/W

This bit allows powering down the CLK7 output driver to conserve power when the output is unused.

0: CLK7 is powered up. 1: CLK7 is powered down.

Set this bit according to ClockBuilder Desktop generated register map file.

0: Select PLLA as the source for MultiSynth0. 1: Select PLLB (Si5351A/C only) or VCXO (Si5351B only) MultiSynth0.

0: Output Clock 7 is not inverted. 1: Output Clock 7 is inverted.

3:2 CLK7_SRC[1:0] Output Clock 0 Input Source.

These bits determine the input source for CLK7. 00: Select the XTAL as the clock source for CLK7. This option by-passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK7 directly to the oscillator which generates an output frequency determined by the XTAL frequency. 01: Select CLKIN as the clock sour ce for CL K7. Th is by- passes both synthesis stages (PLL/VCXO & MultiSynth) and connects CLK7 directly to the CLKIN input. This essentially creates a buffered output of the CLKIN input. 10: Reserved. Do not select this option. 11: Select MultiSynth 0 as the sour ce for CLK7. Select this option when using the Si5351 to generate free-running or synchronous clocks.

1:0 CLK7_IDRV[1:0] CLK7 Output Rise and Fall time / Drive Strength Control.

00: 2 mA 01: 4 mA 10: 6 mA 11: 8 mA

Preliminary Rev. 0.95 37

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7:0 CLKx_DIS_STATE Clock x Disable State.

BitD7D6D5D4D3D2D1D0

Name

CLK3_DIS_STATE CLK2_DIS_STATE CLK1_DIS_STATE CLK0_DIS_STATE

R/W R/W R/W R/W

Where x = 0, 1, 2, 3. These 2 bits determine the state of the CLKx output when disabled. Individual output clocks can be disabled using register Output Enable Con- trol located at address 3. Outputs are also disabled using the OEB pin. 00: CLKx is set to a LOW state when disabled.

01: CLKx is set to a HIGH state when disabled. 10: CLKx is set to a HIGH IMPEDANCE state when disabled. 11: CLKx is NEVER DISABLED.

CLK7_DIS_STATE CLK6_DIS_STATE CLK5_DIS_STATE CLK4_DIS_STATE

Type

Reset value = 0000 0000

Bit Name Function

7:0 CLKx_DIS_STATE Clock x Disable State.

R/W R/W R/W R/W

Where x = 4, 5, 6, 7. These 2 bits determine the state of th e CLKx o utput wh en disabled. Individual output clocks can be disabled using register Output Enable Con- trol located at address 3. Outputs are also disabled using the OEB pin.

00: CLKx is set to a LOW state when disabled. 01: CLKx is set to a HIGH state when disabled. 10: CLKx is set to a HIGH IMPEDANCE state when disabled. 11: CLKx is NEVER DISABLED.

38 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

MS0_P3[15:8]

Type

Reset value = xxxx xxxx

Bit Name Function

7:0 MS0_P3[15:8] Multisynth0 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the fractional part of the MultiSynth0 Divider.

BitD7D6D5D4D3D2D1D0

Name MS0_P3[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS0_P3[7:0] Multisynth0 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the fractional part of the MultiSynth0 Divider.

R/W

Preliminary Rev. 0.95 39

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name R0_DIV[2:0] MS0_P1[17:16]

Type

Reset value = xxxx xxxx

Bit Name Function

7 Unused

6:4 R0_DIV[2:0] R0 Output Divider.

3:2 Reserved 1:0 MS0_P1[17:16] Multisynth0 Parameter 1.

R/W R/W R/W R/W R/W

000b: Divide by 1 001b: Divide by 2 010b: Divide by 4 011b: Divide by 8 100b: Divide by 16 101b: Divide by 32 110b: Divide by 64 111b: Divide by 128

This 18-bit number is an encoded representation of the integer part of the MultiSynth0 divider.

BitD7D6D5D4D3D2D1D0

Name MS0_P1[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS0_P1[15:8] Multisynth0 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the MultiSynth1 divider.

40 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS0_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS0_P1[7:0] Multisynth0 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the MultiSynth1 divider.

BitD7D6D5D4D3D2D1D0

Name MS0_P3[19:16] MS0_P2[19:16]

Type R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7:4 MS0_P3[19:16] Multisynth0 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the fractional part of the MultiSynth0 Divider

3:0 MS0_P2[19:16] Multisynth0 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional part of the MultiSynth1 Divider.

BitD7D6D5D4D3D2D1D0

Name MS0_P2[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS0_P2[15:8] Multisynth0 Parameter 2.

This 20-bit number is an encoded representation of the num erat or for the fractiona l part of the MultiSynth1 Divider.

Preliminary Rev. 0.95 41

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS0_P2[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS0_P2[7:0] Multisynth0 Parameter 2.

This 20-bit number is an encoded representation of the num erat or for the fractiona l part of the MultiSynth1 Divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P3[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P3[15:8] Multisynth1 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the fractional part of the MultiSynth1 Divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P3[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P3[7:0] Multisynth1 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the fractional part of the MultiSynth1 Divider.

42 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

R1_DIV[2:0] MS1_P1[17:16]

Type

Reset value = xxxx xxxx

Bit Name Function

7 Unused

6:4 R1_DIV[2:0] R1 Output Divider.

3:2 Reserved 1:0 MS1_P1[17:16] Multisynth1 Parameter 1.

R/W R/W R/W R/W R/W

000b: Divide by 1 001b: Divide by 2 010b: Divide by 4 011b: Divide by 8 100b: Divide by 16 101b: Divide by 32 110b: Divide by 64 111b: Divide by 128

This 18-bit number is an encoded representation of the integer part of the MultiSynth1 divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P1[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P1[15:8] Multisynth1 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the MultiSynth1 divider.

Preliminary Rev. 0.95 43

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS1_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P1[7:0] Multisynth1 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the MultiSynth1 divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P3[19:16] MS1_P2[19:16]

Type R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7:4 MS1_P3[19:16] Multisynth1 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the fractional part of the Multisynth1 Divider

3:0 MS1_P2[19:16] Multisynth1 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fr actional part of the MultiSynth1 Divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P2[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P2[15:8] Multisynth1 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional part of the MultiSynth1 divider.

44 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS1_P2[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P2[7:0] Multisynth1 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional part of the MultiSynth1 divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P3[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P3[15:8] Multisynth1 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra ctional part of the MultiSynth1 divider.

BitD7D6D5D4D3D2D1D0

Name MS1_P3[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS1_P3[7:0] Multisynth1 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra ctional part of the MultiSynth1 divider.

Preliminary Rev. 0.95 45

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name R2_DIV[2:0] MS2_P1[17:16]

Type R/W R/W R/W R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7 Unused

6:4 R2_DIV[2:0] R2 Output Divider.

000b: Divide by 1 001b: Divide by 2 010b: Divide by 4 011b: Divide by 8 100b: Divide by 16 101b: Divide by 32 110b: Divide by 64

111b: Divide by 128 3:2 Reserved 1:0 MS2_P1[17:16] Multisynth2 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth2 divider.

BitD7D6D5D4D3D2D1D0

Name MS2_P1[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS2_P1[15:8] Multisynth2 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth2 divider.

46 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS2_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS2_P1[7:0] Multisynth2 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth2 divider.

BitD7D6D5D4D3D2D1D0

Name MS2_P3[19:16] MS2_P2[19:16]

Type R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7:4 MS2_P3[19:16] Multisynth2 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the frac-

tional part of the Multisynth2 divider 3:0 MS2_P2[19:16] Multisynth2 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fr actional

part of the MultiSynth2 divider.

BitD7D6D5D4D3D2D1D0

Name MS2_P2[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS2_P2[15:8] Multisynth2 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth2 divider.

Preliminary Rev. 0.95 47

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS2_P2[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS2_P2[7:0] Multisynth2 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth2 divider.

BitD7D6D5D4D3D2D1D0

Name MS3_P3[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS3_P3[15:8] Multisynth3 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra c-

tional part of the Multisynth3 divider.

BitD7D6D5D4D3D2D1D0

Name MS3_P3[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS3_P3[7:0] Multisynth3 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra c-

tional part of the Multisynth3 divider.

48 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name R3_DIV[2:0] MS3_P1[17:16]

Type R/W R/W R/W R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7 Unused

6:4 R3_DIV[2:0] R3 Output Divider.

000b: Divide by 1

001b: Divide by 2

010b: Divide by 4

011b: Divide by 8

100b: Divide by 16

101b: Divide by 32

110b: Divide by 64

111b: Divide by 128 3:2 Reserved 1:0 MS3_P1[17:16] Multisynth3 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth3 divider.

BitD7D6D5D4D3D2D1D0

Name MS3_P1[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS3_P1[15:8] Multisynth3 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth3 divider.

Preliminary Rev. 0.95 49

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS3_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS3_P1[7:0] Multisynth3 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth3 divider.

BitD7D6D5D4D3D2D1D0

Name MS3_P3[19:16] MS3_P2[19:16]

Type R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7:4 MS3_P3[19:16] Multisynth3 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the frac-

tional part of the Multisynth3 divider 3:0 MS3_P2[19:16] Multisynth3 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fr actional

part of the MultiSynth3 divider.

BitD7D6D5D4D3D2D1D0

Name MS3_P2[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS3_P2[15:8] Multisynth3 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth3 divider.

50 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS3_P2[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS3_P2[7:0] Multisynth3 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth3 divider.

BitD7D6D5D4D3D2D1D0

Name MS4_P3[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS4_P3[15:8] Multisynth4 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra c-

tional part of the Multisynth4 divider.

BitD7D6D5D4D3D2D1D0

Name MS4_P3[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS4_P3[7:0] Multisynth4 Parameter 3.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth4 divider.

Preliminary Rev. 0.95 51

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name R4_DIV[2:0] MS4_P1[17:16]

Type R/W R/W R/W R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7 Unused

6:4 R4_DIV[2:0] R4 Output Divider.

000b: Divide by 1

001b: Divide by 2

010b: Divide by 4

011b: Divide by 8

100b: Divide by 16

101b: Divide by 32

110b: Divide by 64

111b: Divide by 128 3:2 Reserved 1:0 MS4_P1[17:16] Multisynth4 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth4 divider.

BitD7D6D5D4D3D2D1D0

Name MS4_P1[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS4_P1[15:8] Multisynth4 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth4 divider.

52 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS4_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS4_P1[7:0] Multisynth4 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth4 divider.

BitD7D6D5D4D3D2D1D0

Name MS4_P3[19:16] MS4_P2[19:16]

Type R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7:4 MS4_P3[19:16] Multisynth4 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the frac-

tional part of the Multisynth4 divider 3:0 MS4_P2[19:16] Multisynth4 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fr actional

part of the MultiSynth4 divider.

BitD7D6D5D4D3D2D1D0

Name MS4_P2[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS4_P2[15:8] Multisynth4 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth4 Divider.

Preliminary Rev. 0.95 53

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS4_P2[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS4_P2[7:0] Multisynth4 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth4 divider.

BitD7D6D5D4D3D2D1D0

Name MS5_P3[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS5_P3[15:8] Multisynth5 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra c-

tional part of the Multisynth5 divider.

BitD7D6D5D4D3D2D1D0

Name MS5_P3[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS5_P3[7:0] Multisynth5 Parameter 3.

This 20-bit number is an encoded represen ta tio n of th e de no m ina to r fo r the fra c-

tional part of the Multisynth5 divider.

54 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name R5_DIV[2:0] MS5_P1[17:16]

Type R/W R/W R/W R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7 Unused

6:4 R5_DIV[2:0] R5 Output Divider.

000b: Divide by 1

001b: Divide by 2

010b: Divide by 4

011b: Divide by 8

100b: Divide by 16

101b: Divide by 32

110b: Divide by 64

111b: Divide by 128 3:2 Reserved 1:0 MS5_P1[17:16] Multisynth5 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth5 divider.

BitD7D6D5D4D3D2D1D0

Name MS5_P1[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS5_P1[15:8] Multisynth5 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth5 divider.

Preliminary Rev. 0.95 55

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS5_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS5_P1[7:0] Multisynth5 Parameter 1.

This 18-bit number is an encoded representation of the integer part of the

Multisynth5 divider.

BitD7D6D5D4D3D2D1D0

Name MS5_P3[19:16] MS5_P2[19:16]

Type R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7:4 MS5_P3[19:16] Multisynth5 Parameter 3.

This 20-bit number is an encoded representation of the denominator for the frac-

tional part of the Multisynth5 divider 3:0 MS5_P2[19:16] Multisynth5 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fr actional

part of the MultiSynth5 divider.

BitD7D6D5D4D3D2D1D0

Name MS5_P2[15:8]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS5_P2[15:8] Multisynth5 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth5 Divider.

56 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name MS5_P2[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS5_P2[7:0] Multisynth5 Parameter 2.

This 20-bit number is an encoded representation of the numerator for the fractional

part of the Multisynth5 Divider.

BitD7D6D5D4D3D2D1D0

Name MS6_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS6_P1[7:0] Multisynth6 Parameter 1.

This 8-bit number is the Multisynth6 divide ratio. Multisynth6 divide ratio can only be

even integers greater than or equal to 6. All other divide values are invalid.

BitD7D6D5D4D3D2D1D0

Name MS7_P1[7:0]

Type R/W

Reset value = xxxx xxxx

Bit Name Function

7:0 MS7_P1[7:0] Multisynth7 Parameter 1.

This 8-bit number is the Multisynth6 divide ratio. Multisynth6 divide ratio can only be

even integers greater than or equal to 6. All other divide values are invalid.

Preliminary Rev. 0.95 57

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name R7_DIV[2:0] R6_DIV[2:0]

Type R/W R/W R/W R/W

Reset value = xxxx xxxx

Bit Name Function

7 Reserved Leave as default.

6:4 R7_DIV[2:0] R7 Output Divider.

000b: Divide by 1

001b: Divide by 2

010b: Divide by 4

011b: Divide by 8

100b: Divide by 16

101b: Divide by 32

110b: Divide by 64

111b: Divide by 128

3 Reserved Leave as default.

1:0 R6_DIV[2:0] R6 Output Divider.

000b: Divide by 1

001b: Divide by 2

010b: Divide by 4

011b: Divide by 8

100b: Divide by 16

101b: Divide by 32

110b: Divide by 64

111b: Divide by 128

58 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

R/W R/W R/W R/W R/W R/W R/W R/W

Reset value = 0000 0000

Bit Name Function

7 Reserved Only write 0 to this bit.

6:0 CLK0_PHOFF[6:0] Clock 0 Initial Phase Offset.

CLK0_PHOFF[6:0] is an unsigned integer with one LSB equivalent to a time delay of Tvco/4, where Tvco is the period of the VCO/PLL associated with this output.

BitD7D6D5D4D3D2D1D0

Name

Type

R/W R/W R/W R/W R/W R/W R/W R/W

CLK0_PHOFF[6:0]

CLK1_PHOFF[6:0]

Reset value = 0000 0000

Bit Name Function

7 Reserved Only write 0 to this bit.

6:0 CLK1_PHOFF[6:0] Clock 1 Initial Phase Offset.

CLK1_PHOFF[6:0] is an unsigned integer with one LSB equivalent to a time delay of Tvco/4, where Tvco is the period of the VCO/PLL associated with this output.

BitD7D6D5D4D3D2D1D0

Name

Type

R/W R/W R/W R/W R/W R/W R/W R/W

CLK2_PHOFF[6:0]

Reset value = 0000 0000

Bit Name Function

7 Reserved Only write 0 to this bit.

6:0 CLK2_PHOFF[6:0] Clock 2 Initial Phase Offset.

CLK2_PHOFF[6:0] is an unsigned integer with one LSB equivalent to a time delay of Tvco/4, where Tvco is the period of the VCO/PLL associated with this output.

Preliminary Rev. 0.95 59

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

R/W R/W R/W R/W R/W R/W R/W R/W

Reset value = 0000 0000

Bit Name Function

7 Reserved Only write 0 to this bit.

6:0 CLK3_PHOFF[6:0] Clock 3 Initial Phase Offset .

CLK3_PHOFF[6:0] is an unsigned integer with one L SB e quivalent to a time de lay of Tvco/4, where Tvco is the period of the VCO/PLL associated with this output.

BitD7D6D5D4D3D2D1D0

Name

Type

R/W R/W R/W R/W R/W R/W R/W R/W

CLK3_PHOFF[6:0]

CLK4_PHOFF[6:0]

Reset value = 0000 0000

Bit Name Function

7 Reserved Only write 0 to this bit.

6:0 CLK4_PHOFF[6:0] Clock 4 Initial Phase Offset .

CLK4_PHOFF[6:0] is an unsigned integer with one L SB e quivalent to a time de lay of Tvco/4, where Tvco is the period of the VCO/PLL associated with this output.

BitD7D6D5D4D3D2D1D0

Name

Type

R/W R/W R/W R/W R/W R/W R/W R/W

CLK5_PHOFF[6:0]

Reset value = 0000 0000

Bit Name Function

7 Reserved Only write 0 to this bit.

6:0 CLK5_PHOFF[6:0] Clock 5 Initial Phase Offset.

CLK5_PHOFF[6:0] is an unsigned integer with on e LSB equivale nt to a time de lay of Tvco/4, where Tvco is the period of the VCO/PLL associated with this output.

60 Preliminary Rev. 0.95

Si5351A/B/C

BitD7D6D5D4D3D2D1D0

Name

Type

Reset value = 0000 0000

Bit Name Function

7PLLB_RSTPLLB_Reset.

6 Reserved Leave as default. 5PLLA_RSTPLLA_Reset.

4:0 Reserved Leave as default.

BitD7D6D5D4D3D2D1D0

Name

PLLB_RST PLLA_RST

R/W R/W R/W R/W R/W R/W R/W R/W

Writing a 1 to this bit will reset PLLB. This is a self clearing bit (Si5351A/C only).

Writing a 1 to this bit will reset PLLA. This is a self clearing bit.

XTAL_CL[1:0]

Type

Reset value = 11xx xxxx

Bit Name Function

7:6 XTAL_CL[1:0] Crystal Load Capacitance Selection.

5:0 Reserved Leave as default.

R/W R/W R/W R/W R/W R/W R/W R/W

These 2 bits determine the internal load capacitance value for the crystal. See "3.1.1. Crystal Inputs (XA, XB)" on page 11. 00: Reserved. Do not select this option.

01: Internal CL = 6 pF. 10: Internal CL = 8 pF. 11: Internal CL = 10 pF (default).

Preliminary Rev. 0.95 61

Si5351A/B/C

1 2 3

4 5

15 14 13

191817

XA XB

SCL

SDA

OEB

CLK3

CLK2

VDDOB

SSEN

Si5351A 20-QFN

Top View

GND PAD

CLK6

CLK5

VDDOC

CLK4

VDD

VDDOA

CLK1

CLK0

VDDOD

CLK7

Si5351A 24-QSOP

Top View

CLK7

CLK6

CLK0

VDD0D

GND

CLK1

GND

VDDOA

CLK2

VDD0B

OEB

CLK3

VDDOC

CLK5

VDD

CLK4

GND

SCL

SSEN

SDA

9. Si5351A Pin Descriptions (20-Pin QFN, 24-Pin QSOP)

Table 10. Si5351A Pin Descriptions

Pin Name

Pin Type* Function

20-QFN 24-QSOP

XA 1 6 I Input pin for external crystal.

XB 2 7 I Input pin for external crystal. CLK0 13 21 O Output clock 0. CLK1 12 20 O Output clock 1. CLK2 9 15 O Output clock 2. CLK3 8 14 O Output clock 3. CLK4 19 3 O Output clock 4. CLK5 17 1 O Output clock 5. CLK6 16 24 O Output clock 6. CLK7 15 23 O Output clock 7.

Pin Number

A0 3 9 I I

SCL 4 10 I I

SDA 5 11 I/O I

C address bit.

C bus serial clock input. Pull-up to VDD core with 1 k

C bus serial data input. Pull-up to VDD core with 1 k

SSEN 6 12 I Spread spectrum enable. High = enabled, Low = disabled.

OEB 7 13 I Output driver enable. Low = enabled, High = disabled.

VDD 20 4 P Core voltage supply pin. See 6.2. VDDOA 11 18 P Output voltage supply pin for CLK0 and CLK1. See 6.2. VDDOB 10 16 P Output voltage supply pin for CLK2 and CLK3. See 6.2. VDDOC 18 2 P Output voltage supply pin for CLK4 and CLK5. See 6.2. VDDOD 14 22 P Output voltage supply pin for CLK6 and CLK7. See 6.2.

62 Preliminary Rev. 0.95

GND Center Pad 5, 8, 17, 19 P Ground. Use multiple vias to ensure a solid path to GND.

1. I = Input, O = Output, P = Power.

2. Input pins are not internally pulled up.

10. Si5351B Pin Descriptions (20-Pin QFN, 24-Pin QSOP)

1 2 3

15 14 13

191817

XA XB

SCL

SDA

OEB

CLK3

CLK2

VDDOB

SSEN

Si5351B 20-QFN

Top View

GND PAD

CLK6

CLK5

VDDOC

CLK4

VDD

VDDOA

CLK1

CLK0

VDDOD

CLK7

Si5351B 24-QSOP

Top View

VDDOC

CLK5

VDD

CLK4

GND

SCL

SSEN

SDA

CLK7

CLK6

CLK0

VDD0D

GND

CLK1

GND

VDDOA

CLK2

VDD0B

OEB

CLK3

Table 11. Si5351B Pin Descriptions

Si5351A/B/C

Pin Name

Pin Type* Function

20-QFN 24-QSOP

XA 1 6 I Input pin for external crystal

XB 2 7 I Input pin for external crystal CLK0 13 21 O Output clock 0 CLK1 12 20 O Output clock 1 CLK2 9 15 O Output clock 2 CLK3 8 14 O Output clock 3 CLK4 19 3 O Output clock 4 CLK5 17 1 O Output clock 5 CLK6 16 24 O Output clock 6 CLK7 15 23 O Output clock 7

VC 3 9 I VCXO control voltage input

Pin Number

SCL 4 10 I I

SDA 5 11 I/O I

C bus serial clock input. Pull-up to VDD core with 1 k

C bus serial data input. Pull-up to VDD core with 1 k

SSEN 6 12 I Spread spectrum enable. High = enabled, Low = disabled.

OEB 7 13 I Output driver enable. Low = enabled, High = disabled.

VDD 20 4 P Core voltage supply pin VDDOA 11 18 P Output voltage supply pin for CLK0 and CLK1. See 6.2 VDDOB 10 16 P Output voltage supply pin for CLK2 and CLK3. See 6.2 VDDOC 18 2 P Output voltage supply pin for CLK4 and CLK5. See 6.2 VDDOD 14 22 P Output voltage supply pin for CLK6 and CLK7. See 6.2

*Note: I = Input, O = Output, P = Power *Note: Input pins are not internally pull ed up.

GND Center Pad 5, 8, 17, 19 P Ground

Preliminary Rev. 0.95 63

Si5351A/B/C

1 2 3

15 14 13

191817

XA XB

INTR

SCL

SDA

OEB

CLK3

CLK2

VDDOB

CLKIN

Si5351C 20-QFN

Top View

GND PAD

CLK6

CLK5

VDDOC

CLK4

VDD

VDDOA

CLK1

CLK0

VDDOD

CLK7

Si5351C 24-QSOP

Top View

VDDOC

CLK5

VDD

CLK4

GND

SCL

INTR

CLKIN

SDA

CLK7

CLK6

CLK0

VDD0D

GND

CLK1

GND

VDDOA

CLK2

VDD0B

OEB

CLK3

11. Si5351C Pin Descriptions (20-Pin QFN, 24-Pin QSOP)

Table 12. Si5351C Pin Descriptions

Pin Name

Pin Number

20-QFN 24-QSOP

Pin Type* Function

XA 1 6 I Input pin for external crystal.

INTR 3 9 O Interrupt pin. Open drain active low output, requires a pull-up

resistor greater than 1 k

SCL 4 10 I I

SDA 5 11 I/O I

C bus serial clock input. Pull-up to VDD core with 1 k

C bus serial data input. Pull-up to VDD core with 1 k

CLKIN 6 12 I PLL clock input.

OEB 7 13 I Output driver enable. Low = enabled, High = disabled.

GND Center Pad 5, 8, 17, 19 P Ground.

Notes:

I = I nput, O = Output, P = Power.

64 Preliminary Rev. 0.95

2. Input pins are not internally pulled up.

12. Si5351A Pin Descriptions (10-Pin MSOP)

Si5351A 10-MSOP

Top View

VDD

SCL

CLK1

CLK0

VDDO

GND

SDA

CLK2

Table 13. Si5351A 10-MSOP Pin Descriptions

Pin Name

XA 2 I Input pin for external crystal. XB 3 I Input pin for external crystal.

Number

10-MSOP

Pin Type* Function

Si5351A/B/C

CLK0 10 O Output clock 0. CLK1 9 O Output clock 1. CLK2 6 O Output clock 2.

SCL 4 I

Serial clock input for the I

C bus. This pin must be pulled-up using a pull-

up resistor of at least 1 k.

SDA 5 I/O Serial data input for the I

C bus. This pin must be pulled-up using a pull-up

resistor of at least 1 k.

VDD 1 P Core voltage supply pin.

VDDO 7 P Output voltage supply pin for CLK0, CLK1, and CLK2. See "6.2. Power

Supply Sequencing" on page 21.

GND 8 P Ground.

*Note: I = Input, O = Output, P = Power

Preliminary Rev. 0.95 65

Si5351A/B/C

Si5351X

A = Product Revision A

A = Crystal In B = Crystal In + VCXO C = Crystal In + CLKIN

GT = 10-MSOP* GM = 20-QFN GU = 24-QSOP

*Note: The 10-MSOP is only available in the Si5351A variant.

Si535X

EVB

XXXXX

XXXXX =

EVB = Evaluation Kit

20-QFN 24-QSOP

13. Ordering Information

Figure 19. Device Part Numbers

An evaluation kit containing ClockBuilder Desktop software and hardware enable easy evaluatin of the Si5351A/B/C. The orderable part numbers for the evaluation kits are provided in Figure 20.

Figure 20. Si5351A/B/C Evaluation Kit

66 Preliminary Rev. 0.95

14. Package Outline (24-Pin QSOP)

Si5351A/B/C

Table 14. 24-QSOP Package Dimensions

Dimension Min Nom Max

A——1.75

A1 0.10 — 0.25

b 0.19 — 0.30

c 0.15 — 0.25 D 8.558.658.75 E 6.00 BSC

E1 3.81 3.90 3.99

e 0.635 BSC

L 0.40 — 1.27

L2 0.25 BSC

q0—8

aaa 0.10 bbb 0.17 ccc 0.10

Notes:

All dimensions shown are in millimeters (mm) unless otherwise noted.

2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3. This drawing conforms to the JEDEC Solid State Outline MO-137, Variation C

4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body

Components.

Preliminary Rev. 0.95 67

Si5351A/B/C

15. Package Outline (20-Pin QFN)



Table 15. Package Dimensions

Dimension Min Nom Max

A 0.800.850.90

A1 0.00 0.02 0.05

b 0.180.250.30 D 4.00 BSC

D2 2.65 2.70 2.75

e 0.50 BSC E 4.00 BSC

E2 2.65 2.70 2.75

L 0.300.400.50

aaa 0.10 bbb 0.10 ccc 0.08 ddd 0.10 eee 0.10

Notes:

All dimensions shown are in millimeters (mm) unless otherwise noted.

2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3. This drawing conforms to the JEDEC Outline MO-220, variation VGGD-8.

4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body

Components.

68 Preliminary Rev. 0.95

16. Package Outline (10-Pin MSOP)



Si5351A/B/C

Table 16. 24-QSOP Package Dimensions

Dimension Min Nom Max

A——1.10

A1 0.00 — 0.15 A2 0.75 0.85 0.95

b 0.17 — 0.33

c 0.08 — 0.23 D 3.00 BSC E 4.90 BSC

E1 3.00 BSC

Notes:

2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3. This drawing conforms to the JEDEC Solid State Outline MO-137, Variation C

4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body

e 0.50 BSC

L 0.400.600.80

L2 0.25 BSC

q0—8

aaa — — 0.20 bbb — — 0.25 ccc — — 0.10 ddd — — 0.08

All dimensions shown are in millimeters (mm) unless otherwise noted.

Components.

Preliminary Rev. 0.95 69

Si5351A/B/C

DOCUMENT CHANGE LIST

Revision 0.1 to Revision 0.9

 Updated max output frequency.  Updated kV values in Table 3 on page 5.  Updated "3.4. Spread Spectrum" on page 13.  Added "5.1. Writing a Custom Configuration to RAM"

on page 16.

 Added "5.7. HCSL Compatible Outputs" on page 20.  Added "6.6. Trace Characteristics" on page 22.  Updated "8. Register Descriptions" on page 25.

Added register descriptions.

Revision 0.9 to Revision 0.95

 Added 1.8 V VDDO support.  Updated Table 2, “DC Characteristics,” on page 4.  Added soldering profile specs to Table 9, “Absolute

Maximum Ratings

,” on page 8.

70 Preliminary Rev. 0.95

NOTES:

Si5351A/B/C

Preliminary Rev. 0.95 71

Si5351A/B/C

The information in this document is believed to be accurate in all respects at the time of publication but is subject to change without notice. Silicon Laboratories assumes no responsibility for errors and omissions, and disclaims responsibility for any consequences resulting from the use of information included herein. Additionally, Silicon Laboratories assumes no responsibility for the functioning of undescribed features or parameters. Silicon Laboratories reserves the right to make changes without further notice. Silicon Laboratories makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does Silicon Laboratories assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages. Silicon Laboratories products are not designed, intended, or authorized for use in applications intended to support or sustain life, or for any other application in which the failure of the Silicon Laboratories product could create a situation where personal injury or death may occur. Should Buyer purchase or use Silicon Laboratories products for any such unintended or unauthorized application, Buyer shall indemnify and hold Silicon Laboratories harmless against all claims and damages.

CONTACT INFORMATION

Silicon Laboratories Inc.

400 West Cesar Chavez Austin, TX 78701 Tel: 1+(512) 416-8500 Fax: 1+(512) 416-9669 Toll Free: 1+(877) 444-3032

Please visit the Silicon Labs Technical Support web page:

https://www.silabs.com/support/pages/contacttechnicalsupport.aspx

and register to submit a technical support request.

Silicon Laboratories and Silicon Labs are trademarks of Silicon Laboratories Inc. Other products or brandnames mentioned herein are trademarks or registered trademarks of their respective holders.

72 Preliminary Rev. 0.95

Silicon Laboratories SI5351A-B-C User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Electrical Specifications

2. Detailed Block Diagrams

3. Functional Description

3.1. Input Stage

3.1.1. Crystal Inputs (XA, XB)

3.1.2. External Clock Input (CLKIN)

3.1.3. Voltage Control Input (VC)

3.2. Synthesis Stages

3.3. Output Stage

3.4. Spread Spectrum

3.5. Control Pins (OEB, SSEN)

3.5.1. Output Enable (OEB)

3.5.2. Spread Spectrum Enable (SSEN)—Si5351A and Si5351B only

4. I2C Interface

5. Configuring the Si5351

5.1. Writing a Custom Configuration to RAM

5.2. Si5351 Application Examples

5.3. Replacing Crystals and Crystal Oscillators

5.4. Replacing Crystals, Crystal Oscillators, and VCXOs

5.5. Replacing Crystals, Crystal Oscillators, and PLLs

5.6. Replacing a Crystal with a Clock

5.7. HCSL Compatible Outputs

6. Design Considerations

6.1. Power Supply Decoupling/Filtering

6.2. Power Supply Sequencing

6.3. External Crystal

6.4. External Crystal Load Capacitors

6.5. Unused Pins

6.6. Trace Characteristics

7. Register Map Summary

8. Register Descriptions

9. Si5351A Pin Descriptions (20-Pin QFN, 24-Pin QSOP)

10. Si5351B Pin Descriptions (20-Pin QFN, 24-Pin QSOP)

11. Si5351C Pin Descriptions (20-Pin QFN, 24-Pin QSOP)

12. Si5351A Pin Descriptions (10-Pin MSOP)

13. Ordering Information

14. Package Outline (24-Pin QSOP)

15. Package Outline (20-Pin QFN)

16. Package Outline (10-Pin MSOP)

DOCUMENT CHANGE LIST

CONTACT INFORMATION
