1: Introduction
The Sierra Wireless EM7511 Embedded Module is an M.2 module that provides LTE,
UMTS, and GNSS connectivity for notebook, ultrabook, tablet computers, and M2M
applications over several radio frequency bands.
Accessories
A hardware development kit is available for AirPrime M.2 modules. The kit contains
hardware components for evaluating and developing with the module, including:
• Development board
• Cables
• Antennas
• Other accessories
For over-the-air LTE testing, ensure that suitable antennas are used.
Required Connectors
Table 1-1 describes the connectors used to integrate the EM7511 Embedded Module
into your host device.
1
Table 1-1: Required Host–Module Connectors
Connector type Description
RF cables • Mate with M.2-spec connectors
• Three connector jacks (I-PEX 20448-001R-081 or equivalent)
EDGE (67 pin) • Slot B compatible—Per the M.2 standard ([8] PCI Express NGFF
SIM • Industry-standard connector.
(M.2) Electromechanical Specification Revision 1.0), a generic
75 pin position EDGE connector on the motherboard uses a
mechanical key to mate with the 67 pin notched module connector.
• Manufacturers include LOTES (part #APCI0018-P001A01),
Kyocera, JAE, Tyco, and Longwell.
Rev Apr.18 5
2: Power
Power Supply
The host provides power to the EM7511 through multiple power and ground pins. The
host must provide safe and continuous power (via battery or a regulated power
supply) at all times; the module does not have an independent power supply, or
protection circuits to guard against electrical issues.
For detailed pinout and voltage/ current requirements of this module, see the AirPrime
EM7511 Product Technical Specification.
Module Power States
The module has five power states, as described in Table 2-1.
Table 2-1: Module Power States
2
State Details
Normal
(Default
state)
Low power
(‘Airplane
mode’)
Sleep • Normal state of module between calls or data connections
• Module is active
• Default state. Occurs when VCC is first applied, Full_Card_Power_Off# is deasserted
(pulled high), and W_DISABLE# is deasserted
• Module is capable of placing/receiving calls, or establishing data connections on the
wireless network
• Current consumption is affected by several factors, including:
• Radio band being used
• Transmit power
• Receive gain settings
• Data rate
• Module is active
• Module enters this state:
• Under host interface control:
· Host issues AT+CFUN=0 (AT Command Set for User Equipment (UE) (Release 6)
(Doc# 3GPP TS 27.007))), or
· Host asserts W_DISABLE#, after AT!PCOFFEN=0 has been issued.
• Automatically, when critical temperature or voltage trigger limits have been reached))
• Module cycles between wake (polling the network) and sleep, at network provider-deter-
mined interval.
Host is powered
USB interface active
RF enabled
Rev Apr.18 6
Table 2-1: Module Power States (Continued)
State Details
Off • Host keeps module powered off by asserting Full_Card_Power_Off# (signal pulled low or
left floating)
• Module draws minimal current
Power
Host is powered
USB interface active
RF enabled
Disconnected • Host power source is disconnected from the module and all voltages associated with the
module are at 0 V.
Rev Apr.18 7
3: RF Specifications
The EM7511 operates on the frequency bands listed below.
3
Table 3-1: LTE Frequency Band Support
Band Frequency (Tx) Frequency (Rx)
B1 1920–1980 MHz 2110–2170 MHz
B2 1850–1910 MHz 1930–1990 MHz
B3 1710–1785 1805–1880 MHz
B4 1710–1755 2110–2155 MHz
B5 824–849 MHz 869–894 MHz
B7 2500–2570 MHz 2620–2690 MHz
B8 880–915 MHz 925–960 MHz
B9 1749.9–1784.9 MHz 1844.9–1879.9 MHz
B12 699–716 MHz 729–746 MHz
B13 777–787 MHz 746–756 MHz
B14 788–798 MHz 758–768 MHz
B18 815–830 MHz 860–875 MHz
B19 830–845 MHz 875–890 MHz
B20 832–862 MHz 791–821 MHz
a
B26 814–849 MHz 859–894 MHz
B29 n/a 717–728 MHz
B30 2305–2315 MHz 2350–2360 MHz
B32 n/a 1452–1496 MHz
B41 2496–2690 MHz (TDD)
B42 3400–3600 MHz (TDD)
B43 3600–3800 MHz (TDD)
B46 n/a 5150–5925 MHz (TDD)
B48 3550–3700 MHz (TDD)
B66 1710–1780 MHz 2110–2200 MHz
a. For bandwidth support details, see 3GPP TS 36.521-1 v11.3.0, table
5.4.2.1-1
Rev Apr.18 8
Table 3-2: WCDMA Frequency Band Support
RF Specifications
a
Band
Band 1 1920–1980 MHz 2110–2170 MHz
Band 2 1850–1910 MHz 1930–1990 MHz
Band 4 1710–1755 MHz 2110–2155 MHz
Band 5 824–849 MHz 869–894 MHz
Band 6 830–840 MHz 875–885 MHz
Band 8 880–915 MHz 925–960 MHz
Band 9 1749.9–1784.9 MHz 1844.9–1879.9 MHz
Band 19 830–845 MHz 875–890 MHz
a. WCDMA channel spacing is 5 MHz, but this can be adjusted to optimize
performance in a particular deployment scenario.
Frequency (Tx) Frequency (Rx)
Table 3-3: GNSS Frequency Band Support
Band Frequencies
Narrow-band GPS, Galileo Rx: 1575.42 MHz
Wide-band GPS + GLONASS Rx: 1559–1606 MHz
Narrow-band BeiDou Rx: 1561.098 MHz
Narrow-band GLONASS Rx: 1601.72 MHz
Narrow-band QZSS Rx: 1572.42 MHz
RF Connections
When attaching antennas to the module:
• Use RF plug connectors that are compatible with the following RF receptacle
connectors: Foxconn (KK12011-02-7H), Longwell (911-002-0006R),
Speedtech (C87P101-00001-H), Murata (MM4829-2702RA4 (HSC)), IPEX
(20449-001E (MHF4)).
• Match coaxial connections between the module and the antenna to 50 .
• Minimize RF cable losses to the antenna; the recommended maximum cable
loss for antenna cabling is 0.5 dB.
• To ensure best thermal performance, use the mounting hole (if possible) to
attach (ground) the device to a metal chassis.
Note: If the antenna connection is shorted or open, the modem will not sustain permanent
damage.
Shielding
The module is fully shielded to protect against EMI and must not be removed.
Rev Apr.18 9
Product Technical Specification
Antenna and Cabling
When selecting the antenna and cable, it is critical to RF performance to match
antenna gain and cable loss.
Choosing the Correct Antenna and Cabling
When matching antennas and cabling:
• The antenna (and associated circuitry) should have a nominal impedance of
50 with a return loss of better than 10 dB across each frequency band of
operation.
• The system gain value affects both radiated power and regulatory (FCC, IC,
CE, etc.) test results.
Designing Custom Antennas
Consider the following points when designing custom antennas:
• A skilled RF engineer should do the development to ensure that the RF
performance is maintained.
• If both UMTS and CDMA modules will be installed in the same platform, you
may want to develop separate antennas for maximum performance.
Determining the Antenna’s Location
When deciding where to put the antennas:
• Antenna location may affect RF performance. Although the module is
shielded to prevent interference in most applications, the placement of the
antenna is still very important—if the host device is insufficiently shielded,
high levels of broadband or spurious noise can degrade the module’s performance.
• Connecting cables between the module and the antenna must have 50
impedance. If the impedance of the module is mismatched, RF performance
is reduced significantly.
• Antenna cables should be routed, if possible, away from noise sources
(switching power supplies, LCD assemblies, etc.). If the cables are near the
noise sources, the noise may be coupled into the RF cable and into the
antenna.
Disabling the Diversity Antenna
Use the AT command !RXDEN=0 to disable receive diversity or !RXDEN=1 to
enable receive diversity.
Note: A diversity antenna is used to improve connection quality and reliability through
redundancy. Because two antennas may experience difference interference effects (signal
distortion, delay, etc.), when one antenna receives a degraded signal, the other may not be
similarly affected.
Rev Apr.18 10
RF Specifications
Ground Connection
When connecting the module to system ground:
• Prevent noise leakage by establishing a very good ground connection to the
module through the host connector.
• Connect to system ground using the module’s mounting hole.
• Minimize ground noise leakage into the RF.
Depending on the host board design, noise could potentially be coupled to
the module from the host board. This is mainly an issue for host designs that
have signals traveling along the length of the module, or circuitry operating at
both ends of the module interconnects.
Interference and Sensitivity
Several interference sources can affect the module’s RF performance
(RF desense). Common sources include power supply noise and devicegenerated RF.
RF desense can be addressed through a combination of mitigation techniques
(Methods to Mitigate Decreased Rx Performance on page 12) and radiated
sensitivity measurement (Radiated Sensitivity Measurement on page 12).
Note: The EM7511 is based on ZIF (Zero Intermediate Frequency) technologies. When
performing EMC (Electromagnetic Compatibility) tests, there are no IF (Intermediate
Frequency) components from the module to consider.
Interference From Other Wireless Devices
Wireless devices operating inside the host device can cause interference that
affects the module.
To determine the most suitable locations for antennas on your host device,
evaluate each wireless device’s radio system, considering the following:
• Any harmonics, sub-harmonics, or cross-products of signals generated by
wireless devices that fall in the module’s Rx range may cause spurious
response, resulting in decreased Rx performance.
• The Tx power and corresponding broadband noise of other wireless devices
may overload or increase the noise floor of the module’s receiver, resulting in
Rx desense.
The severity of this interference depends on the closeness of the other antennas
to the module’s antenna. To determine suitable locations for each wireless
device’s antenna, thoroughly evaluate your host device’s design.
Host-generated RF Interference
All electronic computing devices generate RF interference that can negatively
affect the receive sensitivity of the module.
Rev Apr.18 11
Product Technical Specification
Proximity of host electronics to the antenna in wireless devices can contribute to
decreased Rx performance. Components that are most likely to cause this
include:
• Microprocessor and memory
• Display panel and display drivers
• Switching-mode power supplies
Device-generated RF Interference
The module can cause interference with other devices. Wireless devices such as
AirPrime embedded modules transmit in bursts (pulse transients) for set durations
(RF burst frequencies). Hearing aids and speakers convert these burst
frequencies into audible frequencies, resulting in audible noise.
Methods to Mitigate Decreased Rx Performance
It is important to investigate sources of localized interference early in the design
cycle. To reduce the effect of device-generated RF on Rx performance:
• Put the antenna as far as possible from sources of interference. The
drawback is that the module may be less convenient to use.
• Shield the host device. The module itself is well shielded to avoid external
interference. However, the antenna cannot be shielded for obvious reasons.
In most instances, it is necessary to employ shielding on the components of
the host device (such as the main processor and parallel bus) that have the
highest RF emissions.
• Filter out unwanted high-order harmonic energy by using discrete filtering on
low frequency lines.
• Form shielding layers around high-speed clock traces by using multi-layer
PCBs.
• Route antenna cables away from noise sources.
Radiated Spurious Emissions (RSE)
When designing an antenna for use with AirPrime embedded modules, the host
device with an AirPrime embedded module must satisfy any applicable
standards/local regulatory bodies for radiated spurious emission (RSE) for
receive-only mode and for transmit mode (transmitter is operating).
Note that antenna impedance affects radiated emissions, which must be
compared against the conducted 50-ohm emissions baseline. (AirPrime
embedded modules meet the 50-ohm conducted emissions requirement.)
Radiated Sensitivity Measurement
A wireless host device contains many noise sources that contribute to a reduction
in Rx performance.
Rev Apr.18 12
RF Specifications
To determine the extent of any receiver performance desensitization due to selfgenerated noise in the host device, over-the-air (OTA) or radiated testing is
required. This testing can be performed by Sierra Wireless or you can use your
own OTA test chamber for in-house testing.
Rev Apr.18 13
4: Regulatory Compliance and Industry Certifications
This module is designed to meet, and upon commercial release, will meet the
requirements of the following regulatory bodies and regulations, where applicable:
• Federal Communications Commission (FCC) of the United States
• The Certification and Engineering Bureau of Industry Canada (IC)
• The National Communications Commission (NCC) of Taiwan, Republic of China
Upon commercial release, the following industry certifications will have been
obtained, where applicable:
• GCF
• PTCRB
Additional certifications and details on specific country approvals may be obtained
upon customer request — contact your Sierra Wireless account representative for
details.
Additional testing and certification may be required for the end product with an
embedded EM7511 module and are the responsibility of the OEM. Sierra Wireless
offers professional services-based assistance to OEMs with the testing and
certification process, if required.
4
Important Notice
Because of the nature of wireless communications, transmission and reception of
data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or
be totally lost. Although significant delays or losses of data are rare when wireless
devices such as the Sierra Wireless module are used in a normal manner with a wellconstructed network, the Sierra Wireless module should not be used in situations
where failure to transmit or receive data could result in damage of any kind to the user
or any other party, including but not limited to personal injury, death, or loss of
property. Sierra Wireless and its affiliates accept no responsibility for damages of any
kind resulting from delays or errors in data transmitted or received using the Sierra
Wireless module, or for failure of the Sierra Wireless module to transmit or receive
such data.
Safety and Hazards
Do not operate your EM7511 module:
• In areas where blasting is in progress
• Where explosive atmospheres may be present including refuelling po
pots, and chemical plants
de
• Near medical equipment, life support equipment, or any equipment which may be
susceptible to any form of radio interference. In such areas, the EM7511 module
MUST BE POWERED OFF. Otherwise, the EM7511 module can transmit sign
t
hat could interfere with this equipment.
ints, fuel
als
Rev Apr.18 14
Regulatory Compliance and Industry Certifications
In an aircraft, the EM7511 module MUST BE POWERED OFF. Otherwise, the
EM7511 module can transmit signals that could interfere with various onboard
systems and may be dangerous to the operation of the aircraft or disrupt the
cellular network. Use of a cellular phone in an aircraft is illegal in some
jurisdictions. Failure to observe this instruction may lead to suspension or denial
of cellular telephone services to the offender, or legal action or both.
Some airlines may permit the use of cellular phones while the aircraft is on the
ground and the door is open. The EM7511 module may be used normally at this
time.
Important Compliance Information for United States and Canada
The EM7511 module, upon commercial release, will have been granted modular
approval for mobile applications. Integrators may use the EM7511 module in their
final products without additional FCC/ IC (Industry Canada) certification if they
meet the following conditions. Otherwise, additional FCC/IC approvals must be
obtained.
1. At least 20 cm separation distance between the antenna and the user’s bo
t be maintained at all times.
mus
2. To comply with FCC/ IC regulations limiting both maximum RF output power
and human exposure to RF radiation, the maximum antenna gain including
cable loss in a mobile-only exposure condition must not exceed the limit
ulated in Table 4-1 on page 16.
stip
3. The EM7511 module may transmit simultaneously with other collocated radi
ransmitters within a host device, provided the following conditions are met:
t
· Each collocated radio transmitter has been certified by FCC / IC for mobile
application.
· At least 20 cm separation distance between the antennas of the collocate
ransmitters and the user’s body must be maintained at all times.
t
· The radiated power of a collocated transmitter must not exceed th
tipulated in Table 4-1 on page 16
limit s
.
dy
s
o
d
e EIRP
Rev Apr.18 15
Product Technical Specification
Table 4-1: Antenna Gain and Collocated Radio Transmitter Specifications
EM7511
Embedded
Module
Tx Freq
Operating mode
WCDMA Band 2/
LTE B2
WCDMA Band 4/
LTE B4
WCDMA Band 5/
LTE B5
LTE B7 2500 2570 23.8 9 4 32.8
LTE B1 2 699 716 24 6 4 30
LTE B1 3 777 787 24 6 4 30
LTE B1 4 788 798 24 6 4 30
LTE B2 6 814 849 24 6 4 30
LTE B3 0 2305 2315 23 1* 1* 32
LTE B4 1 2496 2690 23.8 9 4 32.8
LTE B6 6 1710 1780 24 6 4 30
WLAN 2.4 GHz 2400 2500 30
Range
(MHz)
1850 1910 24 6 4 30
1710 1755 24 6 4 30
824 849 24 6 4 30
Max Time-Avg
Cond Power
(dBm)
Antenna Gain Limit (dBi) EIRP
Standalone Collocated
Limits
(dBm)
Collocated
transmitters
WLAN 5 GHz 5150 5850 30
BT 2400 2500 16
WiGig 58320 62640 25
*Important: The FCC and IC have a strict EIRP limit in Band 30 for mobile and portable stations in order to protect
adjacent satellite radio, aeronautical mobile telemetry, and deep space network operations. Mobile and porta ble stations
must not have antenna gain exceeding 1 dBi in Band 30. Additionally, both the FCC and IC prohibit the use of external
vehicle-mounted antennas for mobile and portable stations in this band.
Fixed stations may use antennas with higher gain in Band 30 due to relaxed EIRP limits. EM751 1 modules used as fixed
subscriber stations in Canada or fixed customer premises equipment (CPE) stations in the United States may have an
antenna gain up to 10 dBi in Band 30, however, the use of outdoor antennas or outdoor station installations are
prohibited except if professionally installed in locations that are at least 20 meters from roadways or in locations where it
can be shown that the ground power level of -44 dBm per 5 MHz in the bands 2305–2315 MHz and 2350–2360 MHz or
-55 dBm per 5 MHz in the bands 2315–2320 MHz and 2345–2350 MHz will not be exceeded at the nearest roadway. For
the purposes of this notice, a roadway includes a highway, street, avenue, parkway, driveway, square, place, bridge,
viaduct or trestle, any part of which is intended for use by the general public for the passage of vehicles.
Mobile carriers often have limits on total radiated power (TRP), which requires an efficient antenna. The end product with
an embedded module must output sufficient power to meet the TRP requirement but not too much to exceed FCC/IC's
EIRP limit. If you need assistance in meeting this requirement, please contact Sierra Wireless.
Rev Apr.18 16
Regulatory Compliance and Industry Certifications
4. A label must be affixed to the outside of the end product into which the
EM7511 module is incorporated, with a statement similar to the following:
· This device contains FCC ID: N7NEM75S
Contains transmitter module IC: 2417C-EM75S where 2417C-EM75S is
the module’s certification number.
5. A user manual with the end product must clearly indicate the operatin
r
equirements and conditions that must be observed to ensure compliance
with current FCC/ IC RF exposure guidelines.
The end product with an embedded EM7511 module may also need to pass the
FCC Part 15 unintentional emission testing requirements and be properly
authorized per FCC Part 15.
Note: If this module is intended for use in a portable device, you are responsible
for separate approval to satisfy the SAR requirements of FCC Part 2.1093 and
IC RSS-102.
g
Rev Apr.18 17
A: Acronyms
Table A-1: Acronyms and Definitions
Acronym or term Definition
A
3GPP
BeiDou
BER
BLER
dB
dBm
DC-HSPA+
EMC
EMI
FCC
3rd Generation Partnership Project
BeiDou Navigation Satellite System
A Chinese system that uses a series of satellites in geostationary and middle
earth orbits to provide navigational data.
Bit Error Rate—A measure of receive sensitivity
Block Error Rate
Decibel = 10 x log10 (P1/P2)
P1 is calculated power; P2 is reference power
Decibel = 20 x log
V1 is calculated voltage, V2 is reference voltage
A logarithmic (base 10) measure of relative power (dB for decibels); relative to
milliwatts (m). A dBm value will be 30 units (1000 times) larger (less negative)
than a dBW value, because of the difference in scale (milliwatts vs. watts).
Dual Carrier HSPA+
Electromagnetic Compatibility
Electromagnetic Interference
Federal Communications Commission
The U.S. federal agency that is responsible for interstate and foreign
communications. The FCC regulates commercial and private radio spectrum
management, sets rates for communications services, determines standards for
equipment, and controls broadcast licensing. Consult www.fcc.gov.
(V1/V2)
10
Galileo
GCF
GLONASS
GNSS
GPS
Host
HSDPA
HSPA+
HSUPA
A European system that uses a series of satellites in middle earth orbit to provide
navigational data.
Global Certification Forum
Global Navigation Satellite System—A Russian system that uses a series of 24
satellites in middle circular orbit to provide navigational data.
Global Navigation Satellite Systems (GPS, GLONASS, BeiDou, and Galileo)
Global Positioning System
An American system that uses a series of 24 satellites in middle circular orbit to
provide navigational data.
The device into which an embedded module is integrated
High Speed Downlink Packet Access
Enhanced HSPA, as defined in 3GPP Release 7 and beyond
High Speed Uplink Packet Access
Rev Apr.18 18
Table A-1: Acronyms and Definitions (Continued)
Acronym or term Definition
Acronyms
Hz
IC
IF
IS
LTE
MHz
OEM
OTA
PCB
PCS
PTCRB
QZSS
Hertz = 1 cycle/second
Industry Canada
Intermediate Frequency
Interim Standard.
After receiving industry consensus, the TIA forwards the standard to ANSI for
approval.
Long Term Evolution—a high-performance air interface for cellular mobile
communication systems.
Megahertz = 10e6 Hz
Original Equipment Manufacturer—a company that manufactures a product and
sells it to a reseller.
‘Over the air’ (or radiated through the antenna)
Printed Circuit Board
Personal Communication System
A cellular communication infrastructure that uses the 1.9 GHz radio spectrum.
PCS Type Certification Review Board
Quasi-Zenith Satellite System—Japanese system for satellite-based
augmentation of GPS.
RF
RSE
Sensitivity (RF)
SNR
TIA/EIA
UMTS
USB
VCC
WCDMA
WLAN
ZIF
Radio Frequency
Radiated Spurious Emissions
Measure of lowest power signal at the receiver input that can provide a prescribed
BER/BLER/SNR value at the receiver output.
Signal-to-Noise Ratio
Telecommunications Industry Association / Electronics Industry Association.
A standards setting trade organization, whose members provide communications
and information technology products, systems, distribution services and
professional services in the United States and around the world. Consult
www.tiaonline.org.
Universal Mobile Telecommunications System
Universal Serial Bus
Supply voltage
Wideband Code Division Multiple Access (also referred to as UMTS)
Wireless Local Area Network
Zero Intermediate Frequency
Rev Apr.18 19
Loading...
