The Sierra Wireless EM7565-9 Embedded Module is an M.2 module that provides
LTE, UMTS, and GNSS connectivity for notebook, ultrabook, tablet computers, and
M2M applications over several radio frequency bands.
Accessories
A hardware development kit is available for AirPrime M.2 modules. The kit contains
hardware components for evaluating and developing with the module, including:
•Development board
•Cables
•Antennas
•Other accessories
For over-the-air LTE testing, ensure that suitable antennas are used.
Required Connectors
Table 1-1 describes the connectors used to integrate the EM7565-9 Embedded
Module into your host device.
1
Table 1-1: Required Host–Module Connectors
Connector typeDescription
RF cables•Mate with M.2-spec connectors
•Three connector jacks (I-PEX 20448-001R-081 or equivalent)
EDGE (67 pin)•Slot B compatible—Per the M.2 standard ([8] PCI Express NGFF
SIM•Industry-standard connector.
(M.2) Electromechanical Specification Revision 1.0), a generic
75 pin position EDGE connector on the motherboard use s a
mechanical key to mate with the 67 pin notched module connector.
•Manufacturers include LOTES (part #APCI0018-P001A01),
Kyocera, JAE, Tyco, and Longwell.
Rev 1 Oct.17541111663
2: Power
Power Supply
The host provides power to the EM7565-9 through multiple power and ground pins.
The host must provide safe and continuous power (via battery or a regulated power
supply) at all times; the module does not have an independent power supply, or
protection circuits to guard against electrical issues.
For detailed pinout and voltage/ current requirements of this module, see the AirPrime EM7565-9 Product Technical Specification.
Module Power States
The module has five power states, as described in Table 2-1.
Table 2-1: Module Power States
2
StateDetails
Normal
(Default
state)
Low power
(‘Airplane
mode’)
Sleep•Normal state of module between calls or data connections
•Module is active
•Default state. Occurs when VCC is first applied, Full_Card_Power_Off# is deasserted
(pulled high), and W_DISABLE# is deasserted
•Module is capable of placing/receiving calls, or establishing data connections on the
wireless network
•Current consumption is affected by several factors, including:
• Radio band being used
• Transmit power
• Receive gain settings
• Data rate
•Module is active
•Module enters this state:
• Under host interface control:
·Host issues AT+CFUN=0 (AT Command Set for User Equipment (UE) (Release 6)
(Doc# 3GPP TS 27.007))), or
·Host asserts W_DISABLE#, after AT!PCOFFEN=0 has been issued.
• Automatically, when critical temperature or voltage trigger limits have been reached))
•Module cycles between wake (polling the network) and sleep, at network provider-deter-
mined interval.
Host is powered
USB interface active
RF enabled
Rev 1 Oct.17641111663
Table 2-1: Module Power States (Continued)
StateDetails
Off•Host keeps module powered off by asserting Full_Card_Power_Off# (signal pulled low or
left floating)
•Module draws minimal current
Power
Host is powered
USB interface active
RF enabled
Disconnected •Host power source is disconnected from the module and all voltages associated with the
module are at 0 V.
Rev 1 Oct.17741111663
