Page 7
General Remarks7
1General Remarks
2-
General Remarks0
Required Documents0
•Generator Wiring Diagram
- X2169 for POLYDOROS LX 30/50(Lite) LX80
•Adjustment and Configuration Instructions
Required Tools and Test Equipment0
•Standard installation tool kit
•Service PCper ARTD
•PC connection cable, 5 m99 00 440
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 7 of 146
Page 8
8General Remarks
General Safety Information0
Safety Note 0
WARNING
Safety Notes!
¹ When carrying out the work steps and checks, the prod-
uct-specific safety information contained n the documents as well as the general safety information must be
observed.
Safety Measures0
•Prior to taking any action in the generator, it must be switched off using the power OFF
switch on the D160 .
WARNING
Line voltage!
¹ With the generator switched off, there is line power
present on the T1 transformer and at the D160 switch-on
circuit (see Wiring Diagram X2169-10/X2206-10). After
switching off the generator, there are still approx. 600 V
DC present for the inverter! This is indicated by the LEDs
V135 and V136 on the D110 (X2169-16/X2206-16) and LED
V89 on the D220 goes on (X2169-19/X2206-19). The voltage dissipates within approx. 1.5 minutes to 0 V; the
LEDs go off at approx. 30 V.
•To switch off power to all parts of the system (generator and connected equipment), set
the system switch to the OFF position.
•To prevent unintentional triggering of high voltage or of radiation, set the SS switch (S1)
on the D100 to OFF.
•Remove or install the component only with the generator switched off; when doing this,
observe ESD guidelines.
WARNING
While performing these work steps, provide appropriate radiation
safety measures.
¹ Checks or adjustments that must be performed with radi-
ation switched on are labeled with the radiation warning
symbol x .
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 8 of 146
Medical Solutions
Page 9
General Remarks9
Product-specific Notes0
Cage Clamp Technique0
StepInstallation Step
Insert the screwdriver into the
square actuation opening all the
way until it stops. The screwdriver
blade automatically holds the cage
clamp open.
Fig. 1:Cage clamp technique, Step 1
Fig. 2:Cage clamp technique, Step 2
Insert the lead into the oval connection opening.
Pull the screwdriver back out.
When this is done, the clamp
closes and the lead is securely
clamped.
Fig. 3:Cage clamp technique, Step 3
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 9 of 146
Page 10
10POLYDOROS LX 30/50
2POLYDOROS LX 30/50
3-
Overview of Components0
Fig. 4:POLYDOROS LX30/50
No.POLYDOROS LX30/50 Illustration
1D100 master board
(D100 Master Board, Part No.: 11 71 169 / p. 17)
(D100 Master Board, Part No.: 37 75 256 / p. 18)
(D100 Master Board, Part No.: 57 61 270 / p. 19)
2Inverter (incl. D110) (Inverter, Part No.: 11 75 293 / p. 58)
3D115 Starter (D115 Starter, Part No.: 11 71 201 / p. 20)
4D160 switch-on circuit (D160 Switch-on Circuit, Part No.: 11 71 227 / p. 23)
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 10 of 146
Medical Solutions
Page 11
POLYDOROS LX 30/5011
No.POLYDOROS LX30/50 Illustration
5D200 system controller (D200 XCS System Controller, Part No.: 11 72
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 19 of 146
Page 20
20POLYDOROS LX 30/50
D115 Starter, Part No.: 11 71 2010
Used with:
•POLYDOROS LX30/50 up to Serial Nos.:
Replacement:
•D115, Part No.: 71 25 086
Fig. 10: D115 Starter
Pos. 12 Allen screws
Pos. 2D115.X20
Replacing the D115
•D115, 2 items Remove the M5 Allen screws (1/Fig. 10 / p. 20) with lock washer and
washer.
•Remove the 5 plastic nuts.
•Disconnect the D115.X20 cable (2/Fig. 10 / p. 20).
•Take the D115 board off the studs by pulling it forward.
•Apply a thin layer of heat conducting paste to the IGBT module on the new D115 board.
•Install the D115 board and loosely secure it in place with the plastic nuts.
•Tighten the two M5 Allen screws with lock washer and washer through the board
(1/Fig. 10 / p. 20).
•Tighten the 5 plastic washers.
•Plug in the X20 cable to the D115 (2/Fig. 10 / p. 20).
•Plug any disconnected leads back into the D115 board per the designations.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 20 of 146
Medical Solutions
Page 21
POLYDOROS LX 30/5021
D115 Starter, Part No.: 71 25 0860
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.:
Jumpers and Bridges:
•With D100, Part No.: 5761270, the D115 board with SMD resistor, R1001, is operated
without change.
•With D100, Part No.: 1171169 und 3775256, the SMD resistor, R1001, (0 Ohm)
(Fig. 11 / p. 22) on the D115 board must be removed (unsoldered).
Replacing the D115
•D115, 2 items Remove the M5 Allen screws (1/Fig. 12 / p. 22) with lock washer and
washer.
•Remove the 5 plastic nuts.
•Disconnect the D115.X20 cable (2/Fig. 12 / p. 22).
•Remove the D115 board off the spacer studs towards the front.
•Apply heat conducting paste to the IGBT module on the new D115 board.
•Insert the new D115 board and loosely fasten it in place with the plastic nuts.
•Tighten the two M5 Allen screws with lock washer and washer through the board
(1/Fig. 12 / p. 22).
•5 pc. Tighten the plastic screws.
•Plug in the X20 cable to the D115 (2/Fig. 12 / p. 22).
•If needed, plug the disconnected cables back on the D115 per the designations.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 21 of 146
Page 22
22POLYDOROS LX 30/50
Fig. 11: D115, Part No.: 7125086: R1001
Fig. 12: D115 Starter
Pos. 12 Allen screws
Pos. 2D115.X20
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 22 of 146
Medical Solutions
Page 23
POLYDOROS LX 30/5023
D160 Switch-on Circuit, Part No.: 11 71 2270
Jumpers and Bridges:
•X20 - X21 - X22 - X23 - X24 - X25 = 50Hz/60Hz power line frequency adaptation:
Power Line
Frequency
50 HzX20---X21X23---X24
60 HzX21---X22X24---X25
D160 Jumper Settings
•X38 = radiation display:
- for main contact (HK) X38.1---2
- for prep X38.2---3
Replacing the D160
•A mechanical replacement only, no adjustment is required.
•For the programming, see the section: Jumpers and Bridges.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 23 of 146
Page 24
24POLYDOROS LX 30/50
D165 Rectifier, Part No.: 11 71 2430
Replacing the D165
•A mechanical replacement only; no programming or adjustment is required.
NOTE
Fig. 13: D165 rectifier board, Rev.00
The D165 rectifier board, Rev.01 (Fig. 14 / p. 24) is a larger design
than the D164, Rev.00 (Fig. 13 / p. 24). An additional protective circuit for the rectifier module has been integrated on the D165,
Rev.01. In a replacement situation, the D165, Rev. 01 is shipped;
this is fully compatible with Rev.00.
Fig. 14: D165 rectifier board, Rev.01
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 24 of 146
Medical Solutions
Page 25
POLYDOROS LX 30/5025
D200 XCS System Controller, Part No.: 11 72 7200
Replacing the D200
•Save the data to a backup diskette using the service software found on-site.
- Insert the backup diskette into drive A:.
- Select “XCS Service Application - Main Program / Data / Backup to disk” in the window and perform the routine.
•Disconnect the cables connected to the D200 board.
•Remove the two mounting screws on the D200 board and remove the board.
•Switch the D200.J20/J21 PROM set from the replaced board to the new board.
•Switch the D200.J44 PROM from the replaced board to the new board.
•Install the new D200 board and secure it in place with the screws.
•Plug in the cables for the D200 board.
•Switch the generator ON
•Connect the Service PC to the XCU.
•Log in to the XCU using the XCS SSW.
•Insert the XCU Loadware diskette into the SPC drive.
•Select the window “XCS Service Application-Main Program / Data / Download to Unit”.
•In the service screen, select the line XCU Vxxxx and select download withStart.
•Acknowledge the message with OK and exit with Done.
•Perform a restore of the previously made backup.
- Insert the backup diskette into drive A:
- Select “XCS Service Application - Main Program / Data / Restore from disk” in the
window and perform the routine.
NOTE
Make sure there is good seating of the XCS cable connection and
of the terminal connector, Part No.: 31 57 174!
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 25 of 146
Page 26
26POLYDOROS LX 30/50
D201 Printer Interface, Part No.: 31 57 281 (Option)0
Prerequisites:
•D291 board, Part No.: 37 73 764
See also RX63-020.033.01..., “Printer Connection” Installation and Setting Instructions.
Replacing the D201:
•A mechanical replacement only; no programming or adjustment required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 26 of 146
Medical Solutions
Page 27
POLYDOROS LX 30/5027
D220 Heating Circuit Board, Part No.: 86 08 4160
Used in:
•POLYDOROS LX30/50 up to Serial No. 02325
Replacement:
•D220 Update Kit, Part No.: 87 14 453, see Service Instructions AX035/99/I
Replacing the D220
•A mechanical replacement only; no programming or adjustment required.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 27 of 146
Page 28
28POLYDOROS LX 30/50
D220 Heating Circuit Board, Part No.: 87 14 3620
Used in:
•POLYDOROS LX30/50 beginning with Serial Nos.: 02326 to 04621
Replacement:
•D220, Part No: 56 58 864
Replacing the D220
•A mechanical replacement only; no programming or adjustment required.
Speed Info R 118-980
The new D220 heating circuit board with Part No.: 56 58 864 is compatible with Part No.:
87 14 362 (in POLYDOROS SX 65/80 & LX 30/50 & LX 30/50 Lite & TOSRAD Generator
80KW) and to Part No.: 97 51 876 (in POLYDOROS SX 50/80) and in the future will be
shipped as the replacement.
In a replacement situation, depending on the generator, program the X200 and X201
jumpers on the D220.
Fig. 15:
For the POLYDOROS LX 30/50:
JumperPosition
X2001 --- 2 installed
X2011 --- 2 installed
D220 (Part No.: 56 58 864) board layout
X200
X201
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 28 of 146
Medical Solutions
Page 29
POLYDOROS LX 30/5029
D220 Heating Board, Part No.: 56 58 8640
Used with:
•POLYDOROS LX30/50 beginning with Serial No. 04622
Jumpers and Bridges:
•Depending on the generator, the new D220 heating circuit board with Part No.:
56 58 864 must be programmed.
For the POLYDOROS LX 30/50:
JumperPosition
X2001 --- 2 installed
X2011 --- 2 installed
D220 (Part No.: 56 58 864) board layout
Fig. 16:
X200
Replacing the D220
X201
•A mechanical replacement only; no adjustment is required.
•For programming, see the section: Jumpers and Bridges.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 29 of 146
Page 30
30POLYDOROS LX 30/50
D230 Console Controller, Part No.: 11 75 5740
Used with:
•SX control console, Part No.: 31 57 554 up to Serial No.: 05480
Replacement:
•D230 console controller, 48 19 640
Jumpers and Bridges
•D230.S5 must be on XCS.
Replacing the D230
•Take the D230.J12 PROM from the replaced board and install it on the new board.
Speed Info R 002-99 0
NOTICE
Risk of short circuit!
¹ Prior to beginning service work on the touchscreen con-
trol console (unplugging or plugging in the D230.X48 or
D160.X9 console cable) must be disconnected from line
power over the main system switch in the generator. Otherwise there is a risk of generating short circuits on the
D230.X48 or D160.X9 console connector, because the
+24V control voltage that is present from the generator
switch-on circuit can damage the D230 board in the control console.
¹ If the touchscreen control console or the D230 board is
replaced in a replacement part situation, be careful of the
X-console firmware (D230.J12). The replacement part
(touchscreen control console and D230) is always
shipped with the currently valid version for exposure stations. If a lower or a higher version is released per the
System Compatibility List, the X-console firmware
(D230.J12) from the console to be replaced should be
installed.
Speed Info R 146-980
In a service situation, the entire control console with Part No.: 31 57 554 X2076 had to be
replaced up to this time. For cost reasons, a decision has been made to make the D230
console controller available for shipment as a replacement part.
The Part Number of the D230 is: 48 19 640 X2076
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 30 of 146
Medical Solutions
Page 31
POLYDOROS LX 30/5031
Touchscreen Screen Saver
•Hardware Requirements:
The D230 with Part No.: 48 19 640 has the hardware requirements for screen saver
operation.
The cable required for connection of the D230.X1 --- Display.J3 is shipped along with
the D230 replacement part.
Display.J3
4
3
2
1
Fig. 17:
D230.X1
3
2
1
D230.X1
•Software Requirements
Display.J3
- Beginning with control console FW "VC00X" (D230.J12), screen saver operation is
possible.
•Connection of D230.X1 --- Display.J3 Cable
D230El. Display
to the ventilator
X1
5n.c.
4
3
2
1
Fig. 18:
5
4
3
3
2
1
n.c.
D230.X1
Screen Saver
n.c.
n.c.
4
3
2
1
Display.J3
4
3
J3
2
1
•Select the generator in the SSW and under <Configure> <Site Structure> <Site Adjust-
ments> in the "turn on after" checkbox = activate and set 20 (min).
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 31 of 146
Page 32
32POLYDOROS LX 30/50
D230 Console Controller, Part No.: 48 19 6400
Used with:
•SX control console, Part No.: 31 57 554 beginning with Serial No.: 05481
Jumpers and Bridges
•D230.S5 must be set on XCS.
Replacing the D230
•Take the D230.J12 PROM from the replaced board and install it on the new board.
•Perform the language download for the displayed texts on the touchscreen console
(possible only beginning with D230.J12, version "VC01A"):
- SSW: Select <Component> <PLSX Desk>
- Select Desk language to be loaded and the appropriate language.
- Select Load language data set.
- Exit the service window with Done.
- Perform the backup on site data disk 6.
- Exit the XCS service.
- Switch the system off and back on.
Speed Info R 002-99 0
NOTICE
Risk of short circuit!
¹ Prior to beginning service work on the touchscreen con-
trol console (unplugging or plugging in the D230.X48 or
D160.X9 console cable) must be disconnected from line
power over the main system switch in the generator. Otherwise there is a risk of generating short circuits on the
D230.X48 or D160.X9 console connector, because the
+24V control voltage that is present from the generator
switch-on circuit can damage the D230 board in the control console.
¹ If the touchscreen control console or the D230 board is
replaced in a replacement part situation, be careful of the
X-console firmware (D230.J12). The replacement part
(touchscreen control console and D230) is always
shipped with the currently valid version for exposure stations. If a lower or a higher version is released per the
System Compatibility List, the X-console firmware
(D230.J12) from the console to be replaced should be
installed.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 32 of 146
Medical Solutions
Page 33
POLYDOROS LX 30/5033
D290 KK Interface, Part No.: 11 72 7870
Replacement:
•KK Interface, Part No.: 37 73 756.
Replacing the D290
•A mechanical replacement only; no programming or adjustment required.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 33 of 146
Page 34
34POLYDOROS LX 30/50
D291 KK Interface, Part No.: 37 73 7640
Replacing the D291:
•Only a mechanical replacement, no programming or adjustment is required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 34 of 146
Medical Solutions
Page 35
POLYDOROS LX 30/5035
LX Control Console, Part No.: 11 75 6400
Replacement:
•The SX control console, Part No.: 31 57 554 can also be connected.
Replacing the LX Control Console
•Switch the D230.J6 PROM from the replaced control console to the new D230 board in
the new control console.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 35 of 146
Page 36
36POLYDOROS LX 30/50
SX control console, Part No.: 12 90 3730
Replacement:
•SX control console, Part No.: 31 57 554
Replacing the Control Console
•Switch the D230.J12 PROM from the replaced control console to the new D230 board
in the new control console.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 36 of 146
Medical Solutions
Page 37
POLYDOROS LX 30/5037
SX control console, Part No.: 31 57 5540
Jumpers and Bridges
•D230.S5 must be on XCS.
Replacing the SX Control Console
•Switch the D230.J12 PROM from the replaced control console to the new D230 board
in the new control console.
Speed Info R 002-99 0
NOTICE
Risk of short circuit!
¹ Prior to beginning service work on the touchscreen con-
trol console (unplugging or plugging in the D230.X48 or
D160.X9 console cable), the line power must be switched
off using the main system switch in the generator. Otherwise there is a risk of generating short circuits on the
D230.X48 or D160.X9 console connector, because the
+24V control voltage that is present from the generator
switch-on circuit can damage the D230 board in the control console.
¹ If the touchscreen control console or the D230 board is
replaced in a replacement part situation, be careful of the
X-console firmware (D230.J12). The replacement part
(touchscreen control console and D230) is always
shipped with the currently valid version for exposure stations. If a lower or a higher version is released per the
System Compatibility List, the X-console firmware
(D230.J12) from the console to be replaced should be
installed.
Speed Info R 146-980
In a service situation, the entire control console with Part No.: 31 57 554 X2076 had to be
replaced up to this time. For cost reasons, a decision has been made to make the D230
console controller available for shipment as a replacement part.
The Part Number of the D230 is: 48 19 640 X2076
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 37 of 146
Page 38
38POLYDOROS LX 30/50
Touchscreen Screen Saver
•Hardware Requirements:
The D230 with Part No.: 48 19 640 has the hardware requirements for screen saver
operation.
The cable required for connection of the D230.X1 --- Display.J3 is shipped along with
the D230 replacement part.
Display.J3
4
3
2
1
Fig. 19:
D230.X1
3
2
1
D230.X1
•Software Requirements
Display.J3
Beginning with control console FW "VC00X" (D230.J12), screen saver operation is
possible.
•Connection of D230.X1 --- Display.J3 Cable
D230El. Display
to the ventilator
X1
5n.c.
4
3
2
1
Fig. 20:
5
4
3
3
2
1
n.c.
D230.X1
Screen Saver
n.c.
n.c.
4
3
2
1
Display.J3
4
3
J3
2
1
Select the generator in the SSW and under <Configure> <Site Structure> <Site Adjustments> in the "turn on after" checkbox = activate and set 20 (min).
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 38 of 146
Medical Solutions
Page 39
POLYDOROS LX 30/5039
H1 High Voltage Transformer, Part No.: 11 73 0170
Replacing the High Voltage Transformer
•Only a mechanical replacement, no programming or adjustment is required.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 39 of 146
Page 40
40POLYDOROS LX 30/50
K1 Power Breaker, Part No.: 46 69 8340
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 05966 and 05969 / 05970
Breaker Attachments:
•RC element, Part No.: 73 60 985
Replacement:
•K1 Power Breaker, Part No.: 77 50 248
NOTE
If the K1 Power Breaker, Part No.: 46 69 834 is replaced with Part
No.: 77 50 248, the following breaker accessories must be ordered
at the same time:
•RC element, Part No.: 77 50 214
•Auxiliary switch, Part No.: 77 50 206
Replacing the K1
•a mechanical replacement only
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 40 of 146
Medical Solutions
Page 41
POLYDOROS LX 30/5041
K1 Power Breaker, Part No.: 77 50 2480
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 05971 and 059967 / 05968
Breaker Attachments:
•RC element, Part No.: 77 50 214
•Auxiliary switch, Part No.: 77 50 206
NOTE
Replacing the K1
Auxiliary switch, Part No.: 7750206 no longer has screw connectors, but uses the cage clamp technique (Cage Clamp
Technique/p.9).
•a mechanical replacement only
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
Required relabeling of the connection cables for the "new" breaker
Cable label (“old”)Name
K2.21Auxiliary switch
K2.22Auxiliary switch
K2.L1BreakerK2.1Breaker
K2.T1BreakerK2.2Breaker
Part
No.:”old”
46 82 49830 74 721 3TX 4401-1A 3RH 1911-1FA20
block
block
Part
No.:”new”/Model ”old”Model ”new”
Connections on
the breaker
(“new”)
K2.R1Breaker
K2.R2Breaker
Name
K2.L2BreakerK2.3Breaker
K2.T2BreakerK2.4Breaker
K2.13BreakerK2.53Auxiliary switch
block
K2.14BreakerK2.54Auxiliary switch
block
NOTE
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
The new breaker is a hum-free DC voltage breaker with integrated
rectifier jumper; because of this, an RC circuit is no longer needed!
The noise suppression function is handled by the rectifier jumper.
10.05CSPS 211
Page 42 of 146
Medical Solutions
Page 43
POLYDOROS LX 30/5043
K3 Stator Breaker, Part No.: 46 85 8710
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 05908
Breaker Attachments:
•Overvoltage limiter, Part No.: 46 87 166
Replacing the K3
•a mechanical replacement only
•Connecting the Stator Cable
StatorK3 connection
Tube unit 1.IK3. R2
Tube unit 1.0K3. R4
Tube unit 1.IIK3. R6
Tube unit 2.lK3. 2
Tube unit 2.0K3. 4
Tube unit 2.lIK3. 6
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 43 of 146
Page 44
44POLYDOROS LX 30/50
K31 / K32 Stator Breaker, Part No.: 30 77 8800
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 05909
Replacing the K31 / K32
•a mechanical replacement only
•Connecting the Stator Cable
StatorK31, K32 connection
Tube unit 1.IK31.R2
Tube unit 1.0K31.R4
Tube unit 1.IIK32.R2
Tube unit 2.lK31.2
Tube unit 2.0K31.4
Tube unit 2.lIK32.2
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 44 of 146
Medical Solutions
Page 45
POLYDOROS LX 30/5045
K4 Unit Breaker, Part No.: 46 70 8990
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 05966 and 05969 / 05970
Breaker Attachments:
•RC element, Part No.: 73 60 985
Replacing the K4
•a mechanical replacement only
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 45 of 146
Page 46
46POLYDOROS LX 30/50
K4 Unit Breaker, Part No.: 77 50 2300
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 05971 and 05967 / 05968
Breaker Attachments:
•RC element, Part No.: 77 50 222
NOTE
K4 Unit Breaker, Part No.: 77 50 230, is available in 2 versions:
•Model 3RT1016-1AX21-0AA3 with AC combination coil
With this model, the RC element, Part No.: 7750222 must be installed.
•Model 3RT1016-1GX21-0AA2 with DC coil and integrated jump-
er rectifier (hum-free version)
With this model, the RC element, Part No.: 7750222 can (but
does not have to be) removed, because its function is already
implemented by the integrated jumper rectifier.
Replacing the K4
•a mechanical replacement only
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 46 of 146
Medical Solutions
Page 47
POLYDOROS LX 30/5047
K5 Starter Breaker, Part No.: 30 77 8800
Replacement:
K2/K5 Breaker Set, Part No.: 57 61 403, includes:
•Breaker, Part No.: 30 77 880
•Auxiliary switch block, Part No.: 30 74 721 (not required for replacement of the K5)
Relabeling of the connection cables for the "new" breaker is not necessary!
NOTE
The new breaker is a hum-free DC voltage breaker with integrated
rectifier jumper; because of this, an RC circuit is no longer needed!
The noise suppression function is handled by the rectifier jumper.
Part
No.:”old”
Part
No.:”new”/Model ”old”Model ”new”
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 47 of 146
Page 48
48POLYDOROS LX 30/50
KK Interface, Part No.: 37 73 7560
Replacing the KK Interface
•Only a mechanical replacement, no programming or adjustment is required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 48 of 146
Medical Solutions
Page 49
POLYDOROS LX 30/5049
R1 / R2 Resistor in the M16, Part No.: 46 75 9710
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 06111
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 49 of 146
Page 50
50POLYDOROS LX 30/50
R1 / R2 Resistor in the M16, Part No.: 77 56 9630
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 06112
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 50 of 146
Medical Solutions
Page 51
POLYDOROS LX 30/5051
R4 Resistor in the M16, Part No.: 46 75 9630
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 06111
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 51 of 146
Page 52
52POLYDOROS LX 30/50
R4 Resistor in the M16, Part No.: 77 56 9550
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 06112
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 52 of 146
Medical Solutions
Page 53
POLYDOROS LX 30/5053
SNT circuit power supply, Part No.: 46 93 5290
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 06094
Replacement:
•SNT replacement part set, Part No.: 74 63 248
Replacing the Circuit Power Supply
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The output voltages from the circuit power supply are pre-set.
Fig. 21: Circuit power supply, Part No.: 46 93 529
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 53 of 146
Page 54
54POLYDOROS LX 30/50
SNT replacement part set, Part No.: 74 63 2480
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 06095
Replacing the Circuit Power Supply
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The SNT replacement part set is comprised of a power supply
mount, cable set and circuit power supply. The replacement part
set is already installed, i.e., the power supply is installed on the
power supply mount and the cable set is connected. With this circuit power supply, only an adjustment of the 5V is possible; the
+15V and -15V output voltages come from the adjusted 5V.
Fig. 22: Circuit power supply, Part No.: 74 63 248
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 54 of 146
Medical Solutions
Page 55
POLYDOROS LX 30/5055
T1 Transformer, Part No.: 87 14 3470
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 03589
Replacing the T1 Transformer
•Remove the D160.
•Replace the T1.
•Reinstall the D160.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 55 of 146
Page 56
56POLYDOROS LX 30/50
T1 Transformer, Part No.: 97 51 8840
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 03590
Replacing the T1 Transformer
•Remove the D160.
•Replace the T1.
•Reinstall the D160.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 56 of 146
Medical Solutions
Page 57
POLYDOROS LX 30/5057
T2 440/480V Pre-transformer, Part No.: 97 51 6520
Replacing the T2 Transformer
•Only a mechanical replacement, no programming or adjustment is required.
•Connect the cables as indicated in Wiring Diagram, X26910 *2 (440V / 480V)..
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 57 of 146
Page 58
58POLYDOROS LX 30/50
Inverter, Part No.: 11 75 2930
Replacing the Inverter:
•Only a mechanical replacement, no programming or adjustment is required.
Speed Info 098/2000/AX0
In the following generators, only the inverter needs to be replaced completely in a replacement part situation:
•POLYDOROS SX65/80
- Inverter replacement part
•POLYDOROS LX30/50
- Inverter replacement part
•POLYDOROS LX30/50 Lite
- Inverter replacement part
•POLYDOROS LX80
- Inverter replacement part
Part No.: 38 27 172
Part No.: 11 75 293
Part No.: 38 48 897
Part No.: 57 59 134
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 58 of 146
Medical Solutions
Page 59
POLYDOROS LX 30/5059
Z1 Line Filter, Part No.: 46 88 4040
Used with:
•POLYDOROS LX30/50 up to Serial Nos.: 02709
Replacing the Line Filter
•Only a mechanical replacement, no programming or adjustment is required.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 59 of 146
Page 60
60POLYDOROS LX 30/50
Z1 Line Filter, Part No.: 46 95 5570
Used with:
•POLYDOROS LX30/50 beginning with Serial Nos.: 02710
Replacing the Line Filter
•Only a mechanical replacement, no programming or adjustment is required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 60 of 146
Medical Solutions
Page 61
POLYDOROS LX 30/50 Lite61
3POLYDOROS LX 30/50 Lite
4-
Overview of Components0
Fig. 23: POLYDOROS LX30/50 Lite
No.POLYDOROS LX30/50 Lite Illustration
1D100 master board
(D100 Master Board, Part No.: 37 75 256 / p. 66)
(D100 Master Board, Part No.: 57 61 270 / p. 67)
2Inverter (incl. D110) (Inverter, Part No.: 38 48 897 / p. 102)
3D115 Starter
(D115 Starter, Part No.: 11 71 201 / p. 68)
(D115 Starter, Part No.: 71 25 086 / p. 21)
4D160 switch-on circuit (D160 Switch-on Circuit, Serial No.: 11 71 227 / p. 71)
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 61 of 146
Page 62
62POLYDOROS LX 30/50 Lite
No.POLYDOROS LX30/50 Lite Illustration
5D200 system controller (D200 XCS System Controller, Part No.: 11 72
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 67 of 146
Page 68
68POLYDOROS LX 30/50 Lite
D115 Starter, Part No.: 11 71 2010
Used with:
•POLYDOROS LX30/50 up to Serial No.:
Replacement:
•D115, Part No.: 71 25 086
Fig. 27: D115 Starter
Pos. 12 Allen screws
Pos. 2D115.X20
Replacing the D115
•D115, 2 items Remove the M5 Allen screws (1/Fig. 27 / p. 68) with lock washer and
washer.
•Remove the 5 plastic nuts.
•Disconnect the D115.X20 cable (2/Fig. 27 / p. 68).
•Remove the D115 board off the spacer studs towards the front.
•Apply a thin layer of heat conducting paste to the IGBT module on the new D115 board.
•Insert the new D115 board and loosely fasten it in place with the plastic nuts.
•Tighten the two M5 Allen screws with lock washer and washer through the board
(1/Fig. 27 / p. 68).
•5 items Tighten the plastic screws.
•Plug in the X20 cable to the D115 (2/Fig. 27 / p. 68).
•If needed, plug the disconnected cables back on the D115 per the designations.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 68 of 146
Medical Solutions
Page 69
POLYDOROS LX 30/50 Lite69
D115 Starter, Part No.: 71 25 0860
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.:
Jumpers and Bridges:
•With D100, Part No.: 5761270, the D115 board with SMD resistor, R1001, is operated
without change.
•With D100, Part No.: 3775256, the SMD resistor, R1001, (0 Ohm) (Fig. 28 / p. 70) on
the D115 board must be removed (unsoldered).
Replacing the D115
•D115, 2 items Remove the M5 Allen screws (1/Fig. 29 / p. 70) with lock washer and
washer.
•Remove the 5 plastic nuts.
•Disconnect the D115.X20 cable (2/Fig. 29 / p. 70).
•Remove the D115 board off the spacer studs towards the front.
•Apply heat conducting paste to the IGBT module on the new D115 board.
•Insert the new D115 board and loosely fasten it in place with the plastic nuts.
•Tighten the two M5 Allen screws with lock washer and washer through the board
(1/Fig. 29 / p. 70).
•5 pc. Tighten the plastic screws.
•Plug in the X20 cable to the D115 (2/Fig. 29 / p. 70).
•If needed, plug the disconnected cables back on the D115 per the designations.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 69 of 146
Page 70
70POLYDOROS LX 30/50 Lite
Fig. 28: D115, Part No.: 7125086: R1001
Fig. 29: D115 Starter
Pos. 12 Allen screws
Pos. 2D115.X20
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 70 of 146
Medical Solutions
Page 71
POLYDOROS LX 30/50 Lite71
D160 Switch-on Circuit, Serial No.: 11 71 2270
Jumpers and Bridges:
•X20 - X21 - X22 - X23 - X24 - X25 = 50Hz/60Hz power line frequency adaptation:
Power line frequency
50 HzX20---X21X23---X24
60 HzX21---X22X24---X25
D160 jumper position
•X38 = radiation display:
- with HK X38.1---2
- with ZB (prep) X38.2---3
Replacement for D160
•Only a mechanical replacement, no programming is required.
•For the programming, see the section: Jumpers and Bridges
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 71 of 146
Page 72
72POLYDOROS LX 30/50 Lite
D165 Rectifier, Part No.: 11 71 2430
Replacement of the D165
•Only a mechanical replacement, no programming or adjustment is required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 72 of 146
Medical Solutions
Page 73
POLYDOROS LX 30/50 Lite73
D200 XCS System Controller, Part No.: 11 72 7200
Replacing the D200
•Save the data on a backup diskette using the service software that is present on site.
- Insert the backup diskette into drive A:
- Select “XCS Service Application - Main Program / Data / Backup to disk“ in the window and perform the backup.
•Unplug the cable connected on the D200 board.
•Remove the two mounting screws on the D200 board and remove the board.
•Take the D230.J12/J21 PROM set from the replaced board and install it on the new
board.
•Take the D200.J44 PROM from the replaced board and install it on the new board.
•Install the new D200 board and secure it in place.
•Plug the cables for the D200 board back in.
•Switch the generator ON.
•Connect the Service PC to the XCU.
•Log in to the XCU in the XCS SSW.
•Insert the XCU loadware diskette into the SPC drive.
•Select the “XCS Service Application-Main Program/Data/ Download to Unit“ window.
•Select the XCU Vxxxx line in the service screen and select the download with Start.
•Confirm the message with OK and exit with Done.
•Perform a restore of the previously made backup.
- Insert the backup diskette into drive A:
- Select “XCS Service Application - Main Program / Data / Restore from disk“ in the
window and perform the restore.
NOTE
Make sure there is good contact of the XCS cable connections and
of the terminal connector, Part No.: 31 57 174!
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 73 of 146
Page 74
74POLYDOROS LX 30/50 Lite
D210 Printer Interface, Part No.: 31 57 281 (Option)0
Requirements:
•D291 board, Part No.: 37 73 764
See also RX63-020.033.01... “Printer Connection” Installation and Setting Instructions.
Replacing the D201:
•Only a mechanical replacement, no programming or adjustment is required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 74 of 146
Medical Solutions
Page 75
POLYDOROS LX 30/50 Lite75
D220 Heating Circuit Board, Part No.: 87 14 3620
Used in:
•POLYDOROS LX30/50 Lite up to Serial No.: 01310
Replacement:
•D220, Part No.: 56 58 864
Replacing the D220
•A mechanical replacement only; no programming or adjustment required.
Speed Info R 118-980
The new D220 heating circuit board with Part No.: 56 58 864 is compatible with Part No.:
87 14 362 (for POLYDOROS SX 65/80 & LX 30/50 & LX 30/50 Lite & TOSRAD Generator
80KW) and with Part No.: 97 51 876 (for POLYDOROS SX 50/80) and in the future will be
shipped as the replacement.
In a replacement situation, depending on the generator, program the X200 and X201
jumpers on the D220.
Fig. 30:
With the POLYDOROS LX 30/50 Lite:
JumperPosition
X2001 --- 2 installed
X2011 --- 2 installed
D220 (Part No.: 56 58 864) board layout
X200
X201
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 75 of 146
Page 76
76POLYDOROS LX 30/50 Lite
D220 Heating Circuit Board, Part No.: 56 58 8640
Used in:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 01311
Jumpers and Bridges:
•Depending on the generator, the new D220 heating circuit board with Part No.:
56 58 864 must be programmed.
With the POLYDOROS LX 30/50 Lite:
JumperPosition
X2001 --- 2 installed
X2011 --- 2 installed
D220 (Part No.: 56 58 864) board layout
Fig. 31:
X200
Replacing the D220
X201
•A mechanical replacement only; no adjustment is required.
•For programming, see the section: Jumpers and Bridges.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 76 of 146
Medical Solutions
Page 77
POLYDOROS LX 30/50 Lite77
D230 Console Controller, Part No.: 11 75 5740
Used with:
•SX control console, Part No.: 31 57 554 up to Serial No.: 05480
Replacement:
•D230 console controller, 48 19 640
Jumpers and Bridges
•D230.S5 must be on XCS.
Replacing the D230
•Take the D230.J12 PROM from the replaced board and install it on the new board.
Speed Info R 002-99 0
NOTICE
Risk of short circuit!
¹ Prior to beginning service work on the touchscreen con-
trol console (unplugging or plugging in the D230.X48 or
D160.X9 console cable) must be disconnected from line
power over the main system switch in the generator. Otherwise there is a risk of generating short circuits on the
D230.X48 or D160.X9 console connector, because the
+24V control voltage that is present from the generator
switch-on circuit can damage the D230 board in the control console.
¹ If the touchscreen control console or the D230 board is
replaced in a replacement part situation, be careful of the
X-console firmware (D230.J12). The replacement part
(touchscreen control console and D230) is always
shipped with the currently valid version for exposure stations. If a lower or a higher version is released per the
System Compatibility List, the X-console firmware
(D230.J12) from the console to be replaced should be
installed.
Speed Info R 146-980
In a service situation, the entire control console with Part No.: 31 57 554 X2076 had to be
replaced up to this time. For cost reasons, a decision has been made to make the D230
console controller available for shipment as a replacement part.
The Part Number of the D230 is: 48 19 640 X2076
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 77 of 146
Page 78
78POLYDOROS LX 30/50 Lite
Touchscreen Screen Saver
•Hardware Requirements:
The D230 with Part No.: 48 19 640 has the hardware requirements for screen saver
operation.
The cable required for connection of the D230.X1 --- Display.J3 is shipped along with
the D230 replacement part.
Display.J3
4
3
2
1
Fig. 32:
D230.X1
3
2
1
D230.X1
•Software Requirements
Display.J3
- Beginning with control console FW "VC00X" (D230.J12), screen saver operation is
possible.
•Connection of D230.X1 --- Display.J3 Cable
D230El. Display
to the ventilator
X1
5n.c.
4
3
2
1
Fig. 33:
5
4
3
3
2
1
n.c.
D230.X1
Screen Saver
n.c.
n.c.
4
3
2
1
Display.J3
4
3
J3
2
1
•Select the generator in the SSW and under <Configure> <Site Structure> <Site Adjust-
ments> in the "turn on after" checkbox = activate and set 20 (min).
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 78 of 146
Medical Solutions
Page 79
POLYDOROS LX 30/50 Lite79
D230 Console Controller, Part No.: 48 19 6400
Used with:
•SX control console, Part No.: 31 57 554 beginning with Serial No.: 05481
Jumpers and Bridges
•D230.S5 must be set on XCS.
Replacing the D230
•Take the D230.J12 PROM from the replaced board and install it on the new board.
•Perform the language download for the displayed texts on the touchscreen console
(possible only beginning with D230.J12, version "VC01A"):
- SSW: Select <Component> <PLSX Desk>
- Select Desk language to be loaded and the appropriate language.
- Select Load language data set.
- Exit the service window with Done.
- Perform the backup on site data disk 6.
- Exit the XCS service.
- Switch the system off and back on.
Speed Info R 002-99 0
NOTICE
Risk of short circuit!
¹ Prior to beginning service work on the touchscreen con-
trol console (unplugging or plugging in the D230.X48 or
D160.X9 console cable) must be disconnected from line
power over the main system switch in the generator. Otherwise there is a risk of generating short circuits on the
D230.X48 or D160.X9 console connector, because the
+24V control voltage that is present from the generator
switch-on circuit can damage the D230 board in the control console.
¹ If the touchscreen control console or the D230 board is
replaced in a replacement part situation, be careful of the
X-console firmware (D230.J12). The replacement part
(touchscreen control console and D230) is always
shipped with the currently valid version for exposure stations. If a lower or a higher version is released per the
System Compatibility List, the X-console firmware
(D230.J12) from the console to be replaced should be
installed.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 79 of 146
Page 80
80POLYDOROS LX 30/50 Lite
LX Control Console, Part No.: 11 75 6400
Replacement:
•The SX control console, Part No.: 31 57 554 can also be connected.
Replacing the LX Control Console
•Switch the D230.J6 PROM from the replaced control console to the new D230 board in
the new control console.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 80 of 146
Medical Solutions
Page 81
POLYDOROS LX 30/50 Lite81
SX Control Console, Part No.: 12 90 3730
Replacement:
•SX Control Console, Part No.: 31 57 554
Replacing the Control Console
•Switch the D230.J12 PROM from the replaced control console to the new D230 board
in the new control console.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 81 of 146
Page 82
82POLYDOROS LX 30/50 Lite
SX Control Console, Part No.: 31 57 5540
Jumpers and Bridges
•D230.S5 must be on XCS.
Replacing the SX Control Console
•Switch the D230.J12 PROM from the replaced control console to the new D230 board
in the new control console.
Speed Info R 002-99 0
NOTICE
Risk of short circuit!
¹ Prior to beginning service work on the touchscreen con-
trol console (unplugging or plugging in the D230.X48 or
D160.X9 console cable), the line power must be switched
off using the main system switch in the generator. Otherwise there is a risk of generating short circuits on the
D230.X48 or D160.X9 console connector, because the
+24V control voltage that is present from the generator
switch-on circuit can damage the D230 board in the control console.
¹ If the touchscreen control console or the D230 board is
replaced in a replacement part situation, be careful of the
X-console firmware (D230.J12). The replacement part
(touchscreen control console and D230) is always
shipped with the currently valid version for exposure stations. If a lower or a higher version is released per the
System Compatibility List, the X-console firmware
(D230.J12) from the console to be replaced should be
installed.
Speed Info R 146-980
In a service situation, the entire control console with Part No.: 31 57 554 X2076 had to be
replaced up to this time. For cost reasons, a decision has been made to make the D230
console controller available for shipment as a replacement part.
The Part Number of the D230 is: 48 19 640 X2076
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 82 of 146
Medical Solutions
Page 83
POLYDOROS LX 30/50 Lite83
Touchscreen Screen Saver
•Hardware Requirements:
The D230 with Part No.: 48 19 640 has the hardware requirements for screen saver
operation.
The cable required for connection of the D230.X1 --- Display.J3 is shipped along with
the D230 replacement part.
Display.J3
4
3
2
1
Fig. 34:
D230.X1
3
2
1
D230.X1
•Software Requirements
Display.J3
Beginning with control console FW "VC00X" (D230.J12), screen saver operation is
possible.
•Connection of D230.X1 --- Display.J3 Cable
D230El. Display
to the ventilator
X1
5n.c.
4
3
2
1
Fig. 35:
5
4
3
3
2
1
n.c.
D230.X1
Screen Saver
n.c.
n.c.
4
3
2
1
Display.J3
4
3
J3
2
1
Select the generator in the SSW and under <Configure> <Site Structure> <Site Adjustments> in the "turn on after" checkbox = activate and set 20 (min).
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 83 of 146
Page 84
84POLYDOROS LX 30/50 Lite
H1 High Voltage Transformer, Part No.: 47 98 5130
Replacing the high voltage transformer
•A mechanical replacement only; no programming or adjustment required.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 84 of 146
Medical Solutions
Page 85
POLYDOROS LX 30/50 Lite85
K1 Power Breaker, Part No.: 46 69 8340
Used with:
•POLYDOROS LX30/50 up to Serial No.: 03897
Breaker Accessories:
•RC element, Part No.: 73 60 985
Replacement:
•K1 Power Breaker, Part No.: 77 50 248
NOTE
If the K1 Power Breaker, Part No.: 46 69 834 is replaced with Part
No.: 77 50 248, the following breaker accessories must be ordered
at the same time:
•RC element, Part No.: 77 50 214
•Auxiliary switch, Part No.: 77 50 206
Replacing the K1
•A mechanical replacement only.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 85 of 146
Page 86
86POLYDOROS LX 30/50 Lite
K1 Power Breaker, Part No.: 77 50 2480
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 03898
Breaker Accessories:
•RC element, Part No.: 77 50 214
•Auxiliary switch, Part No.: 77 50 206
NOTE
Replacing the K1
Auxiliary switch, Part No.: 7750206 no longer has screw connectors, but uses the cage clamp technique (Cage Clamp
Required relabeling of the connection cables for the "new" breaker
Cable label (“old”)Name
K2.21Auxiliary switch
K2.22Auxiliary switch
K2.L1BreakerK2.1Breaker
K2.T1BreakerK2.2Breaker
Part
No.:”old”
46 82 49830 74 721 3TX 4401-1A 3RH 1911-1FA20
block
block
Part
No.:”new”/Model ”old”Model ”new”
Connections on
the breaker
(“new”)
K2.R1Breaker
K2.R2Breaker
Name
K2.L2BreakerK2.3Breaker
K2.T2BreakerK2.4Breaker
K2.13BreakerK2.53Auxiliary switch
block
K2.14BreakerK2.54Auxiliary switch
block
NOTE
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
The new breaker is a hum-free DC voltage breaker with integrated
rectifier jumper; because of this, an RC circuit is no longer needed!
The noise suppression function is handled by the rectifier jumper.
Page 87 of 146
10.05CSPS 211
Page 88
88POLYDOROS LX 30/50 Lite
K3 Stator Breaker, Part No.: 46 85 8710
NOTE
Breaker Accessories:
The K3 and K5 breakers are available only with the “Connection of
2-phase Tube Units” option.
•Overvoltage Limiter, Part No.: 46 87 166
Replacing the K3
•A mechanical replacement only.
•Connecting the Stator Cable
StatorK3 connection
Tube unit 1.IK3. R2
Tube unit 1.0K3. R4
Tube unit 1.IIK3. R6
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 88 of 146
Medical Solutions
Page 89
POLYDOROS LX 30/50 Lite89
K31 / K32 Stator Breaker, Part No.: 30 77 8800
NOTE
Replacing the K31 / K32
The K31 / K32 and K5 breakers are available only with the “Connection of 2-phase Tube Units” option.
•A mechanical replacement only.
•Connecting the Stator Cable
StatorK31, K32 connection
Tube unit 1.IK31.R2
Tube unit 1.0K31.R4
Tube unit 1.IIK32.R2
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 89 of 146
Page 90
90POLYDOROS LX 30/50 Lite
K4 Unit Breaker, Part No.: 46 70 8990
Used with:
•POLYDOROS LX30/50 up to Serial No.: 03897
Breaker Accessories:
•RC element, Part No.: 73 60 985
Replacing the K4
•A mechanical replacement only.
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 90 of 146
Medical Solutions
Page 91
POLYDOROS LX 30/50 Lite91
K4 Unit Breaker, Part No.: 77 50 2300
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 03898
Breaker Accessories:
•RC element, Part No.: 77 50 222
NOTE
K4 Unit Breaker, Part No.: 77 50 230, is available in 2 versions:
•Model 3RT1016-1AX21-0AA3 with AC combination coil
With this model, the RC element, Part No.: 7750222 must be installed.
•Model 3RT1016-1GX21-0AA2 with DC coil and integrated jump-
er rectifier (hum-free version)
With this model, the RC element, Part No.: 7750222 can (but
does not have to be) removed, because its function is already
implemented by the integrated jumper rectifier.
Replacing the K4
•A mechanical replacement only.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 91 of 146
Page 92
92POLYDOROS LX 30/50 Lite
K5 Starter Breaker, Part No.: 30 77 8800
NOTE
Replacement:
K2/K5 Breaker Set, Part No.: 57 61 403, includes:
The K3 and K5 breakers are available only with the “Connection of
2-phase Tube Units” option.
•Breaker, Part No.: 30 77 880
•Auxiliary switch block, Part No.: 30 74 721 (not required for replacement of the K5)
Relabeling of the connection cables for the "new" breaker is not necessary!
NOTE
Part No.:
"Old"
The new breaker is a hum-free DC voltage breaker with integrated
rectifier jumper; because of this, an RC circuit is no longer needed!
The noise suppression function is handled by the rectifier jumper.
Part No.:
"New"/
Type ”Old"Type ”New"
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 92 of 146
Medical Solutions
Page 93
POLYDOROS LX 30/50 Lite93
KK Interface, Part No.: 37 73 7560
Replacing the KK Interface
•Only a mechanical replacement, no programming or adjustment is required.
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 93 of 146
Page 94
94POLYDOROS LX 30/50 Lite
R1 / R2 Resistor in the M16, Part No.: 46 75 9710
Used with:
•POLYDOROS LX30/50 up to Serial No.: 03983
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 94 of 146
Medical Solutions
Page 95
POLYDOROS LX 30/50 Lite95
R1 / R2 Resistor in the M16, Part No.: 77 56 9630
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 03984
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 95 of 146
Page 96
96POLYDOROS LX 30/50 Lite
R4 Resistor in the M16, Part No.: 46 75 9630
Used with:
•POLYDOROS LX30/50 up to Serial No.: 03983
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 96 of 146
Medical Solutions
Page 97
POLYDOROS LX 30/50 Lite97
R4 Resistor in the M16, Part No.: 77 56 9550
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 03984
Replacing the Resistors
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The R1, R2 and R4 resistors in the M16 must be the same model
and design:
•R1, R2, Part No.: 46 75 971 with R4, Part No.: 46 75 963 (30W re-
sistors)
•R1, R2, Part No.: 77 56 963 with R4, Part No.: 77 56 955 (40W re-
sistors)
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 97 of 146
Page 98
98POLYDOROS LX 30/50 Lite
SNT circuit power supply, Part No.: 46 93 5290
Used with:
•POLYDOROS LX30/50 up to Serial No.: 03976
Replacement:
•SNT replacement part set, Part No.: 74 63 248
Replacing the Circuit Power Supply
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The output voltages from the circuit power supply are pre-set.
Fig. 36: Circuit power supply, Part No.: 46 93 529
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 98 of 146
Medical Solutions
Page 99
POLYDOROS LX 30/50 Lite99
SNT replacement part set, Part No.: 74 63 2480
Used with:
•POLYDOROS LX30/50 Lite beginning with Serial No.: 03977
Replacing the Circuit Power Supply
•Only a mechanical replacement, no programming or adjustment is required.
NOTE
The SNT replacement part set is comprised of a power supply
mount, cable set and circuit power supply. The replacement part
set is already installed, i.e., the power supply is installed on the
power supply mount and the cable set is connected. With this circuit power supply, only an adjustment of the 5V is possible; the
+15V and -15V output voltages come from the adjusted 5V.
Fig. 37: Circuit power supply, Part No.: 74 63 248
Siemens AGRX63-020.841.01.06.02POLYDOROS LX 30/50
Medical Solutions
10.05CSPS 211
Page 99 of 146
Page 100
100POLYDOROS LX 30/50 Lite
T1 Transformer, Part No.: 97 51 8840
Replacing the T1 Transformer
•Remove the D160
•Replace the T1
•Reinstall the D160
POLYDOROS LX 30/50RX63-020.841.01.06.02Siemens AG
10.05CSPS 211
Page 100 of 146
Medical Solutions
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
