Siemens HB237A0R0A Specifications Sheet
1/3
Shorten your cooking time thanks to fast preheat.
✓
fastPreheat: reach the required baking temperature sooner.
✓
granite Glance Enamel: high-quality coating for easy cleaning.
✓
ecoClean: effortless cleaning thanks to a special coating of the rear
wall that automatically absorbs grime.
✓
cookControl10: automatic programs ensure best results.
Features
Technical Data
Color / Material Front : Stainless steel
Built-in / Free-standing : Built-in
Integrated Cleaning system : No
Required niche size for installation (HxWxD) : 585-595 x 560-568 x
550
Dimensions of the product (mm) : 595 x 594 x 548
Dimensions of the packed product (HxWxD) (mm) : 675 x 690 x 660
Control Panel Material : Glass
Door Material : Glass
Net weight (kg) : 33.535
Usable volume of cavity (l) : 71
Cooking method : Bottom heat, Conventional heat, Full width grill,
Heißluft sanft, Hot Air, Hot air grilling, Pizza setting
First cavity material : Other
Number of interior lights : 1
Approval certificates : CE, VDE
Length electrical supply cord (cm) : 120
Interior Lights - cavity 1 : 1
Clock function : Alarm, Off, On
Included accessories cavity 1 : 1 x combination grid, 1 x universal pan
Broil Element Wattages cavity 1 (W) : 2700
Convection Element Wattages cavity 1 (W) : 2200
Energy efficiency class (2010/30/EC) : A
Energy consumption per cycle conventional (2010/30/EC) : 0.97
Energy consumption per cycle forced air convection (2010/30/EC) :
0.81
Energy efficiency index (2010/30/EC) : 95.3
Electrical connection rating (W) : 3600
Current (A) : 16
Voltage (V) : 220-240
Frequency (Hz) : 50; 60
Plug type : no plug
Color / Material Front : Stainless steel
Energy input : Electric
Approval certificates : CE, VDE
Required cutout/niche size for installation (in) : x x
Dimensions of the packed product (in) : 26.57 x 25.98 x 27.16
Net weight (lbs) : 74.000
Gross weight (lbs) : 78
Length electrical supply cord (cm) : 120
Net weight (kg) : 33.535
Gross weight (kg) : 36.0
'!2E20AD-ibejgd!
iQ500
Oven HB237A0R0A
60cm Built-in Stainless Steel Oven
Included accessories
1 x combination grid
1 x universal pan
Optional accessories
HZ915003 : Glass roasting dish, 5,4 L , HZ66X650 : Cover Strip ,
HZ638300 : 3 level telescopic rails, full ext , HZ638200 : 2 level
telescopic shelf rails, full ext , HZ634000 : Baking and roasting
grid (standard) , HZ538S00 : 3level telescopic rails incl 1 varioClip ,
HZ538200 : 2 level telescopic shelf rails , HZ538000 : varioClip rail ,
HZ532010 : Universal pan, non-stick ceramic coated , HZ532000 :
Multipurpose pan, grey enamelled , HZ531010 : Baking tray, nonstick ceramic coated , HZ531000 : Baking tray, grey enamelled ,
HZ327000 : Baking stone , HZ317000 : Pizza pan, grey enamelled ,
HZ29041 : Conversion cabinet , HZ29020 : Conversion cabinet
Manufactured by <BSH Legal Name> under Trademark License of Siemens AG
iQ500
Oven HB237A0R0A
60cm Built-in Stainless Steel Oven
Features
Heating Modes
●
Oven with 7 heating methods: 3D hotAir plus, Conventional heat,
hotAir grilling, Full width grill, Pizza setting, Bottom heat, hotAir
gentle
Design:
●
LCD Display (white)
●
Bar handle
●
Cavity inner surface: Enamel grey
●
Halogen interior lighting
Comfort:
●
Cavity volume: 71 l
●
Maximum window temperature 40 °C
●
Temperature range 50 °C - 275 °C
●
Triple glazed door with heat reflective glass
●
Ecolyse features: ecoClean
●
childproof lock
●
10 automatic programs
●
Integral cooling fan
●
varioClip rail, with Stop function
●
Electronic functions: heating-up control, automatic start,
cookControl
Technical Info:
●
Appliance dimension (hxwxd): 595 mm x 594 mm x 548 mm
●
Niche dimension (hxwxd): 585 mm - 595 mm x 560 mm - 568 mm
x 550 mm
●
Total connected load electric: 3.6 KW
●
Plug type_old: no plug
●
Length of mains cable: 120 cm
