Siemens ER626PB70A Specifications Sheet
1/2
The gas cooktop with a heat-resistant, easy-to-clean ceramic
glass surface.
✓
Extremely convenient to clean thanks to modern, dishwasher proof
pan supports.
✓
High-quality materials and workmanship – continuous cast-iron
pan supports.
Features
Technical Data
Product name/family : gas hob w integrated controls
Construction type : Built-in
Energy input : Gas
Total number of positions that can be used at the same time : 4
Type of control setting devices : cylindrical knobs
Required niche size for installation (HxWxD) : 45 x 560-560 x 490-490
Width of the product (mm) : 602
Dimensions of the product (mm) : 45 x 602 x 520
Net weight (kg) : 11.0
Gross weight (kg) : 12.0
Residual heat indicator : without
Location of control panel : Hob front
Basic surface material : Ceramic
Color of surface : Black, Stainless steel
Color of frame : Black, Stainless steel
Approval certificates : CE
Length electrical supply cord (cm) : 100
EAN code : 4242003601334
Electrical connection rating (W) : 1
Gas connection rating (W) : 7700
Current (A) : 3
Voltage (V) : 240
Frequency (Hz) : 50
Included accessories
1 x cross support for espresso
1 x governor 10mbar NG (AU)
1 x test point
'!2E20AD-gabdde!
Optional accessories
HZ298105 Simmer plate
iQ700
ER626PB70A
60 cm Gas Cooktop, Black ceramic
glass
iQ700
ER626PB70A
60 cm Gas Cooktop, Black ceramic
glass
Features
Design
●
4 burner Black gas cooktop
●
Connecting cable 1 m with plug
●
Facette design with stainless steel side profiles and beveled
ceramic glass front
●
Enamelled cast-iron pan supports with non-scratch rubber feet
Convenience
●
One-hand ignition
●
1 NO_FEATURE
●
Dishwasher safe pan supports
Power and Mode of Operation
●
1 high-speed burner, 1 economy burner, 1 wok burner and 2
standard burners
●
Front left: Standard burner 7.9 Mj
●
Rear left: Economy burner 4.5 Mj
●
Rear right: High-speed burner 11.5 Mj
●
Front right: Standard burner 8.1 Mj
●
Suitable for natural gas (factory set-up) or LPG (via included
conversion kit)
Safety and Environment
●
Flame failure device fitted to each individual burner
