1/3
Enjoy gas cooking thanks to the Domino cooktop with its
elegantly lustrous, easy-to-clean glass ceramic surface.
✓
Precise heat control and full heating power instantly available
thanks to gas cooking.
✓
Extremely heat-resistant and easy to clean – the modern glass
ceramic surface.
✓
The 30 cm wide gas cooktop is ideal for combining with other
Domino or faceted design cooktops.
Features
Technical Data
Product name/family : Vario/Domino gas hob w control
Built-in / Free-standing : CONSTR_TYPE.Built-in
Energy input : Gas
Total number of positions that can be used at the same time : 2
Required niche size for installation (HxWxD) : 45 x 270 x 490-500
Width of the product (mm) : 302
Dimensions of the product (mm) : 45 x 302 x 520
Net weight (kg) : 7.0
Gross weight (kg) : 7.0
Residual heat indicator : without
Location of control panel : Hob front
Basic surface material : Ceramic
Color of surface : Black, Stainless steel
Color of frame : Black, Stainless steel
Approval certificates : CE
Length electrical supply cord (cm) : 100
EAN code : 4242003601259
Electrical connection rating (W) : 1
Gas connection rating (W) : 4700
Current (A) : 3
Voltage (V) : 240
Frequency (Hz) : 50
Included accessories
1 x cross support for espresso
1 x governor 10mbar NG (AU)
1 x test point
'!2E20AD-gabcfj!
Optional accessories
HZ394301 Connecting strip
HZ298105 Simmer plate
iQ700
ER326BB70A
30 cm Gas Cooktop, Black ceramic
glass
iQ700
ER326BB70A
30 cm Gas Cooktop, Black ceramic
glass
Features
Design
●
2 burner Black gas cooktop
●
Connecting cable 1 m with plug
●
Facette design with stainless steel side profiles and beveled
ceramic glass front
●
Enamelled cast-iron pan supports with non-scratch rubber feet
●
Can be combined with other 3- or 4-series Domino cooktops
Convenience
●
One-hand ignition
●
1 NO_FEATURE
●
Dishwasher safe pan supports
Power and Mode of Operation
●
1 rapid, 1 standard burner
●
Front: Standard burner 7.9 Mj
●
Rear: Rapid speed burner 11.5 Mj
●
Suitable for natural gas (factory set-up) or LPG (via included
conversion kit)
Safety and Environment
●
Flame failure device fitted to each individual burner
2/3
iQ700
ER326BB70A
30 cm Gas Cooktop, Black ceramic
glass
Dimensioned drawings
