Shuttle NC03U3 User Manual

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 1 5 May 2017

. Pictures for illustration purposes only.

Shuttle's XPC nano Series gets a performance boost

The NC03U series is powered by Intel's power-saving ULV (ultra-lowvoltage) processors of the Kaby Lake generation. Compared with the NC02U series, it brings higher clo ck frequencies, improved graphics perf ormance and support of faster DDR4 memory up to 2x 16 GB. Furthermore, one 2.5" drive up to 15 mm in height as well as one M.2-2280 NVMe SSD card can be installed. The DisplayP ort connector delivers video resolutions of up to 4K at 60 frames per second while a second di splay can be connected via HDMI. USB peripherals use either the type A or type C ports. Pro fessional users will appreciate Intel Gigabit-LAN and one serial port which indicates what purposes the NC03U series is mainly intended for: Digital Signage, POS, control, office or even multimedia.

Feature Highlights

Slim Design

 Slim plastic chassis, black, 835 ml  Dimensions: 142x142x42 mm (LWH) , 847 ml  Incl. Sta nd & VESA mount (75/100 mm)  Hole for Kensington Lock  Operating temp erature: max. 40 °C

Operating

System

 An operating system is not included  Supports Windows 10, Linux (64-bit only)

Processor

 Intel Core i3-7100U, 2.4 GHz “Kaby Lake”  Intel HD620 Graphics, supports 2160p/60

Memory

 Supports up to 2x16 GB DDR4-2133 SO-DIMM

Drive

Bay

 One 6.35 cm / 2.5” bay, 15 mm height

supports one SATA hard disk or SSD

M.2 Slot

 M.2-2280 slot supports SSD card (SATA+PCIe)

Connectors

 HDMI 1.4, DisplayPort 1.2 supports 2160p /60  2x USB 3.0 (Type A/C), 2x USB 2.0, Gigabit LAN  SD card reader, Audio Combo, COM port

WLAN

 Wireless LAN 802.11n, internal antenna

Power Supply

 External 65 W fanless power adapter

Applications

 Home Medi a, Office, Digital Signage, etc

Products of the Shuttle XPC nano Barebone NC03U Series

Product

Processo

Cores

Threads

CPU Clock

Cache

Graphics

GPU-Clock

NC03U

Celeron 3865U

2 2 1.8 GHz

2 MB

HD 610

300~900 MHz

NC03U3

Core i3-7100U

2 4 2.4 GHz

3 MB

HD 620

300~1000 MHz

NC03U5

Core i5-7200U

2

4

2.5~3.1 GHz

3 MB

HD 620

300~1000 MHz

NC03U7

Core i7-7500U

2

4

2.7~3.5 GHz

4 MB

HD 620

300~1050 MHz

XPC nano Barebone

NC03U3 (Core i3)

Images for illustration purposes only.

This product does include the stand and

VESA mount, but does not include memory,

storage and operating system.

40°C

Dual

Video

COM

RS232

2 Slots

M.2 + 2.5”

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 2 5 May 2017

. Pictures for illustration purposes only.

Shuttle XPC nano Barebone NC03U3 – Product Views

Front

Rear

A

C

D

E

F

K

L

M

N

O

P

G

H

I

H

R

Q

J

S

T

B

Bottom side

Monitor

A

USB 3.0 Type A

K

DC input for power adapter

B

USB 3.0 Type C

L

HDMI

C

SD Card reader

M

DisplayPort

D

Hard disk LED indicator

N

Gigabit LAN (RJ45)

E

On/Off Button

O

2x USB 2.0

F

Power-on LED indicator

P

Audio Combo (Headphones & Mic)

G

2x perforation for optional WLAN antenna

Q

4x Mounting hole for vertical stand

H

Vents

R

RS232/422/485 COM port *)

I

Hole for Kensington Lock

S

4x Rubber foot

J

2x Vertical stand

T

VESA mounting kit (2 pieces)

*) Note: The serial connector (COM port) cannot be used , if NC03U3 is operated in vertical position.

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 3 5 May 2017

. Pictures for illustration purposes only.

Required Components

1~2 memory modules

up to 2x 16 GB DDR4-2133 in SO-DIMM format

One M.2 SSD storage

M.2-2242/2260/2280 SATA or PCIe interface

One 2.5“ drive

SSD or HDD with SATA connector (up to 15 mm in height)

1

2

3

Operating Positions

1. Horizontal

2. Vertical with Stand

3. VESA-mounted behind a monitor

Stand and VESA mount with screws are included.

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 4 5 May 2017

. Pictures for illustration purposes only.

Product Features

42

142 mm

142

Stylish and absolutely small

The black plastic case with its c urves and coppery elements is certain to be the eyecatcher on your desk. Its volume o f barely 850 ml makes it hardly noticabl e as a PC, particularly when it is hi dden behind monitors thanks to the suppl ied VESA mount. Despite its dinky dimens ions, it provides generous connectivity options and even room for one 2.5 inch drive which can be an SSD or HDD .

Easy installation

Remove just two screws to unmount the two chass is co vers.

SD Card Reader

The built-in SD card reader at the front side makes file tra nsfer from and to a digital camera easy. It takes SD, SDHC and SDXC memory flash cards in standard size format and also supports booting from bootable SD cards.

M.2-2280-Slot for SSD cards

The M.2-2280 BM slot supports M.2 SSD storage cards with SATA or with the more advanced PCIe interface with NVMe support. Type 2280 means, it sup ports the usual M.2 cards with a width of 22 mm and a length of 80 mm, but also 2242 and 2260 standard cards are supported.

Serial Port

Many PCs do not have these legacy ports any longer, since they have been superseded and replaced by USB for most consumer applications, but they are still commonly used for applicati ons such as industrial automation s ystems, scientific analysis, POS systems and other such fields. The Shuttle XPC nano B arebone NC03U3 feat ur es on e serial RS-232 interface with t he traditional 9-pin D-Sub connector for easy connection of appropriate components. Not e: The serial connector (COM port) cannot be used , if NC03U3 is op erated in vertical position.

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 5 5 May 2017

. Pictures for illustration purposes only.

Dual Monitoring via HDMI and DisplayPort

The NC03U3 can connect two d igital displays through its HDMI and DisplayPort. Dual monitoring helps improve on productivity by a llowing for spreading multiple windows across two monitors while working with them simultaneously. Note: Dual channel memory (two identi cal modules) is requir ed to support 4K Ultra-HD resolution (2160p).

Supports 4K Ultra HD at 60 Hz

The NC03U3 supports displays running at 4K (3840 x 2160 / 2160p) high resolution at 60Hz frames per second when connected to its DisplayPort video output. Being the successor to t he Full HD standard, Ultra HD delivers a fo ur times higher resolution wit h a w ider colour space and colour depth. Note: dual chann el memory (two identical modules) is required.

USB 3.0 type A and type C

The Shuttle XPC nano Barebon e NC03U3 has four USB ports, two of which are USB 3.0. USB 3.0 "SuperSpeed" provides a significant performance increase over pr evious USB generations making it the ideal interface for demanding, external peripherals. USB 3.0 supports up to 5Gb/s full duplex which mea ns an up to 10 t imes greater performance than USB 2.0. One of the USB 3 .0 connectors is a "type-C" connector with reversible plug orientation. This type of conn ector is especially intended to connect new-generation mobile devices.

Supports high-capacity drives

The NC03U3 supports 2.5 inch drives up t o a maximum hei ght of 15 mm. This makes overall capacities of up to 4 TB possible, while many other PCs in a similar form factor are limited to drives with a maximum height of 7 to 9.5 mm.

Power-on after Power Fail

The BIOS setup provides a "Power-on after Power Fail " function that can be found under "Power Management Configuration". As the name indicates, this fu nction det ermines the PC's behaviour after power failure. As a matter of the nature of this function, it may fail after short power failures. This is why the NC03U3 also comes with a hardwarebased solution. By remo ving Jumper JP1 (see Quick Installation Guide), the system will start unconditionally once power is appl ied.

Kensington Lock

This is a small, m etal-reinforced hole as part of an anti-theft syst em. The Shuttle XPC nano Barebone NC03U3 provides an appropriate hole on both sides of its chassis. The lock -and-cable is not included.

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 6 5 May 2017

. Pictures for illustration purposes only.

Shuttle XPC nano Series – Comparison

NC02U Series

NC03U Series

Chassis

142 x 142 x 42 mm (847 ml)

Processor

Celeron, Core i3, Core i5 or Core i7 Intel “Skylake-U” (6th Gen), ULV Technology: 14 nm, TDP: 15 W

Celeron, Core i3, Core i5 or Core i7 Intel “Kaby Lake-U” (7th Gen), ULV Technology: 14 nm, TDP: 15 W

Graphics

Intel HD510 / HD520, Dual Display

Intel HD610 / HD620, Dual Display

Operation System

Windows 7 / 8.1 / 10, Linux, 64-bit only

Windows 10, Linux, 64-bit only

4K/UHD Support

Yes

Memory Support

2x SO-DIMM with 204 pins max. 2x 16 GB DDR3L-1600

2x SO-DIMM with 260 pins max. 2x 16 GB DDR4-2133

Audio

Realtek ALC662

Ethernet LAN

Intel i211 Gigabit

Drive Bay

2.5” / 15 mm SATA

SSD card slot

M.2-2280 supports SATA and PCIe X4

WLAN

M.2-2230 card Realtek RTL8188EE supports 802.11n (1T1R)

Connectors Front Panel

Power button, 2x LED, SD card reader 2x USB 3.0 (Type A and Type C)

Connectors Back Panel

DisplayPort 1.2, HDMI 1.4b 2x USB 2.0, Gigabit LAN, Audio Combo DC input, 2x perforation for opt. antenna

Left Side

1x RS232 COM port

Jumper

Always-on-Jumper, Clear CMOS Jumper

Supplied Accessories

Vertical Stand (aluminium with screws) VESA mounting kit

Operation Temp.

max. 40 °C

Power Adapter

65 W / 19 V

Front View Rear View

Product models and processor features:

Shuttle

Product

Processor

Model

Cores /

Threads

Clock /

Turbo

L3-

Cache

Intel

Graphics

EUs

GPU Clock

TDP

NC02U

Celeron 3855U

2 / 2

1.6 / – GHz

2 MB

HD 510

12

300 ~ 800 MHz

15 W

NC02U3

Core i3-6100U

2 / 4

2.3 / – GHz

3 MB

HD 520

24

300 ~ 1000 MHz

15 W

NC02U5

Core i5-6200U

2 / 4

2.3 / 2.8 GHz

3 MB

HD 520

24

300 ~ 1000 MHz

15 W

NC02U7

Core i7-6500U

2 / 4

2.5 / 3.1 GHz

4 MB

HD 520

24

300 ~ 1050 MHz

15 W

NC03U

Celeron 3865U

2 / 2

1.8 / – GHz

2 MB

HD 610

12

300 ~ 900 MHz

15 W

NC03U3

Core i3-7100U

2 / 4

2.4 / – GHz

3 MB

HD 620

24

300 ~ 1000 MHz

15 W

NC03U5

Core i5-7200U

2 / 4

2.5 / 3.1 GHz

3 MB

HD 620

24

300 ~ 1000 MHz

15 W

NC03U7

Core i7-7500U

2 / 4

2.7 / 3.5 GHz

4 MB

HD 620

24

300 ~ 1050 MHz

15 W

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 7 5 May 2017

. Pictures for illustration purposes only.

Shuttle XPC nano Barebone NC03U3 - Specifications

Chassis

Barebone PC with a black plastic chassis Dimensions: 142 x 142 x 42 mm (LWH) = 835 ml Weight: 0.4 kg net , 1.2 kg gross Hole for Kensington Lock Includes vertical stand a nd 75 / 100 mm VESA mount

Low Power

Consumption

Power consumption in idle mode under W indows 10: ca. 5 W

Operation

Position

1) Horizontal

2) Vertical with stand

3) VESA-mounted behind an appropriate monitor

Operation

System

This barebone system comes without operatin g system. It is compatible with:

- Windows 10, 64-bit

- Linux 64-bit

Processor

Model: Intel Core i3-7100U (ULV) System-on-a- chip architecture (SoC): no chipset required BGA1356 package - directly soldered onto the mainboard Code name: Kaby Lake-U (7th Generation Intel Core) Cores / Threads: 2 / 4 Clock rate: 2.4 GHz L1/L2/L3 Cache: 128 kB / 512 kB / 3072 kB Memory controller: DDR4 -2133 D ual Channel (1.2 V) TDP wattage: 15 W maximum Manufacturing process: 14 nm Maximum Tjunction Temperature: 100 °C Supports Hyper- Threading (HT), 64-bit , VT-x (EPT), VT-d, Enhanced SpeedStep, NX bit , AES NI, SSE 4.1/4.2 Integrated graphics engine

Cooling fan

Built-in CPU cooling fan with 4-pin connector Supports temperature-controlled RPM fan speed

Integrated

Graphics

Intel HD graphics 620 GPU clock frequency: 300~1000 MHz Execution Units (EUs): 24 Two digital audio/video ports sup port two independent screens (dual monitoring): Supports Ultra HD / 4K resolution at 3840 x 2160 Pixels

1) DisplayPort 1.2 [1] supports U ltra HD @ 60 Hz

2) HDMI 1.4b supports Ultra HD @ 30 Hz

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 8 5 May 2017

. Pictures for illustration purposes only.

Mainboard

& BIOS

AMI BIOS in 8 MByte EEPROM with SPI interface Supports resume after power failure Supports Wake on LAN (WOL) Supports Power on by RTC Alarm Supports booting from USB devices and SD card reader Supports hardware monitoring and watch dog function Supports Unified Extensible Firmware Interface (UEFI)

Power

Adapter

External 65 W power adapter (fanless) Input: 100~240 V A C, 50/60 Hz, ma x. 1.6 A Output: 19 V DC, max. 3.42 A, max. 65 W DC Connector: 5.5/2.5 mm (outer/inn er diameter)

Memory

support

2x SO-DIMM slots with 260 pins Supports DDR4-2133 (PC4-17000) SDRAM at 1.2 V Supports Dual Channel mode Supports a maximum of 16 GB per DIMM, maximum total size: 32 GB Supports two unbuffered DIMM modules (no ECC or registered)

2.5" Drive Bay

Supports one Serial ATA hard disk or one SATA SSD drive in 6.35 cm / 2 .5" f ormat Device height: 15 mm (max.) Supports Serial-ATA III, 6 Gb/s (600 MB/s) bandwidth

Card Reader

Integrated SD card reader Supports SD, SDHC and SDXC memory flash cards Supports booting from SD card

M.2 Slot for

SSDs

The M.2 2280 BM slot provides the following interfaces:

- PCI-Express G en. 2.0 X4 with up to 32 Gbps Data Trans fer Speed

- SATA v3.0 (max. 6 Gbps) It supports M.2 cards with a width of 22 mm and a length of 42 , 60 or 80 mm (type 2242, 2260, 2280). Supports M.2 SATA SSDs (with B+M key) and M.2 PCIe SSDs (w ith M key)

Audio

Audio Realtek® ALC 662 High-Definition Audio Codec

3.5 mm / 4-pole combo audio connector for headphones and microphone [2] Digita l multi -channel audio output: via HDMI and DisplayPort

Gigabit LAN

Ethernet Controller Intel i211 Supports 10 / 100 / 1.000 MBit/s operation (Gigabit) Supports WAKE ON LAN (WOL) Supports network boot by Preboot eXecution Envir onment (PX E) IEEE 802.3az Energy Efficient Ethernet (EEE) Interface: PCIe v2.1

Wireless Network

(WLAN)

Built-in M.2-2230-A/E WLAN card and internal antenna Single-Chip 1T1R WLAN Controller Realt ek RTL8188 EE Supports IEEE 802.11b/g/n, max. 150Mbps up-/downstream Security: WPA/WPA2(-PSK), WEP 64/128-bit, IEEE 802.11x/i

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 9 5 May 2017

. Pictures for illustration purposes only.

Front Panel connectors

USB 3.0 type A USB 3.0 type C SD card reader (supports SD, S DH C, SDXC) Power button Power LED (blue, flashing when in suspend mode) HDD LED (or ange)

Back Panel

connectors

DisplayPort 1.2 [1] HDMI 1.4b 2x USB 2.0 Gigabit LAN (RJ45) Audio Combo Port for headphones and microphone (3.5 mm jack, 4 -pole) [2] DC-input conn ector for externa l pow er adapter 2x perforation for optional external WLAN antennas

Left Side

connectors

Serial RS232 COM port (D-Sub, 9-pin) This port is switchable to RS422 and RS485 in the BIOS setup Note: The serial connector (COM port) cannot be us ed, if the NC03U3 is operated in vertical position.

Always-On

Jumper

By removing Jumper JP1 (please refer to the Quick Installation Guide), the system will start unconditionally once power is applied. [4]

Clear CMOS

Jumper

Short Jumper JP2 for about 10 seconds to restore factory settings of BIOS .

Supplied

Accessories

Multi-languag e Quick Installation Guide Driver DVD for Windows VESA mount set (two parts, made of steel, with 6 screws) 2x aluminium stand with screws for vertical operation Bracket for a 2.5" drive with 8 screws Power adapter with AC power cord

Environ-

mental Spec

Operating temperature range: 0~40 °C [3] Relative humidity range: 10~90% (non- condensing)

Conformity & Certification s

EMI: CE, FCC, BSMI, RCM , R&TTE, VCCI Safety: CB, BSMI, ETL, CCC Other: RoHS, Energy Star, ErP This device is classed as a techn ical information equipment (ITE) in class B and is intended for use in living room and office. The CE -mark approves the conform ity b y the EU dir ectives: (1) 2004/108/EC relating to electromagnetic compatibility (EMC), (2) 2006/95/EC relating to Electr ical Equipment designed for use within certain volta ge limits (LVD), (3) 2009/125/EC relating to ecodesign requirements for energy-related products (ErP), (4) 1999/5/EC related t o Rad io an d Telecommunicat ions Terminal Equipm ent (R&TTE)

Product Specifications

w w w . s h u t t l e . e u

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 10 5 May 2017

. Pictures for illustration purposes only.

[1] How to convert DisplayPort into HDMI/D VI The DisplayPort outputs can be converted to HDMI or DVI by an additional, passive adapter cable. For e xample: DELOCK 82590: 1 m, DisplayPort (male, 20p) to HDMI -A (male, 19p) DELOCK 82435: 5 m, DisplayPort (male, 20p) to DVI-D (male, 24p) The integrated graphics automatically detects the connected display and puts out the appropriate electric signal either DisplayPort (without an adapter) or HDMI/DVI (with an adapter). However, a monitor with a DisplayPort connector cannot be connected to the HDMI port with a simple, passive adapter. In t his case an act ive adapter like Delock 62496 is required. Connecting a UHD/4K display via the present HDMI port means the refr eshing rat e is limited to 24 Hz. 60 Hz can only be achieved by using the DisplayPort port. Should your display have a HDMI 2.0 connector, a refreshing rate of 60 Hz can be achieved by using an active adapter such as the Club 3D CAC -1070 for example.

[2] Audio connector The 3.5 mm audio jack at the back panel of this device supports both a 4 -pole connector for headphon es and microphone and headphones with only a 3-pole connector. Headsets with separate connectors for headphones and microphone, though, require an appropr iate adapter, if also the microphone should be used.

[3] Caution: For high ambient temperatures over 35 °C we strongly recommend to use SSDs (supp ortin g at least 70 °C) instead of hard disks.

[4] Power-on after Pow er Fail: The BIOS setup provides a "Pow er-on after Power Fail" function that can be found und er "Power Management Configuration ". This function determines the PC's behaviour after power failure. As a matter of the nature of this function, it may fail after short power failures. This is why this P C also comes with a hardware-based solution. By removing Jumper JP1 (please refer to the Quick Installation Guide) , the system will start unconditionally once power is applied.

Shuttle NC03U3 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
