ENGLISH

WARNING!

USING THIS SYSTEM AT EXCESSIVE VOLUMES CAN CAUSE

PERMANENT HEARING DAMAGE. USE AS LOW A VOLUME AS POSSIBLE.

In order to use this system safely, avoid prolonged listening at excessive sound pressure levels. Please use the fol-lowing guidelines
established by the Occupational Safety Health Administration (OSHA) on maximum time exposure to sound pressure levels before
hearing damage occurs.

90 dB SPL at 8 hours

95 dB SPL at 4 hours

100 dB SPL at 2 hours

105 dB SPL at 1 hour

110 dB SPL at 1/2 hour

115 dB SPL at 15 minutes

120 dB SPL — avoid or hearing damage may occur

It is difcult to measure the exact Sound Pressure Levels (SPL) present at the eardrum in live applications. In addition to the volume
setting on the PSM, the SPL in the ear is affected by ambient sound from oor wedges or other devices. The isolation provided by
the t of quality earphones is also an important factor in determining the SPL in the ear.

Here are some general tips to follow in the use of this product to protect your ears from damage:

1. Turn up the volume control only far enough to hear properly.

2. Ringing in the ears may indicate that the gain levels are too high. Try lowering the gain levels.

3. Have your ears checked by an audiologist on a regular basis. If you experience wax buildup in your ears, stop using the sys­tem until an audiologist has examined your ears.

4. Wipe the earphones with an antiseptic before and after use to avoid infections. Stop using the earphones if they are causing
great discomfort or infection.

This symbol indicates important operating and

maintenance instructions in the literature accompanying this unit.

iii

PSM900

The PSM 900 Wireless Personal Monitor System from Shure of­fers an unprecedented combination of superb audio quality, robust
RF performance, and category-leading setup features for the most
demanding professional applications. All new, patent-pending
CueMode allows the sound engineer to monitor different stage mixes
with the touch of a button. Precision front-end RF filtering signifi­cantly reduces dropouts from RF interference, and the enhanced
digital stereo encoder provides excellent stereo separation and audio
clarity.

Superb audio quality

• Digital stereo encoder provides a wider stereo field with
exceptional separation, enhancing audio detail and clarity

• Patented Audio Reference Companding sounds more like
wired

• Available with Shure SE425 Sound Isolating™ Earphones
featuring dual high-definition MicroDrivers for accurate and
balanced audio response

Robust RF Performance

• Precision front-end RF filtering for a cleaner, stronger RF
signal and fewer dropouts and audible artifacts.

• Exceptional transmitter linearity vastly reduces frequency
intermodulation, allowing more channels per frequency
band.

• Automatic RF gain control prevents signal distortion due to
RF overload.

Advanced Setup and Operation

• Patent-pending CueMode allows monitoring of the stage
mixes of up to 20 separate transmitters from one bodypack.

• Front panel RF mute switch for disabling RF transmission
during setup

• Scan and Sync setup identifies the best group and channel
for your system and assigns it over a wireless IR link

• MixMode® Technology allows the bodypack user to adjust
their own onstage monitor mix

• High-frequency EQ boost on bodypack

Components

Features

• Rack unit with mounting hardware and
detachable antenna.

• Bodypack with detachable antenna.

UA506

1/2 RACK MOUNT HARDWARE

UA507

FULL RACK MOUNT HARDWARE

Frequency Scan

The scan feature analyzes the RF environment for
interference to identify available frequencies. The
PSM900 has two frequency scan modes:

• Channel Scan Press the scan button on the

bodypack. Finds the first available channel.

• Group Scan Press and hold the scan button

for two seconds. Finds the group with the
greatest number of available channels. (Each
group contains a set of frequencies that are
compatible when operating multiple systems in
the same environment.)

Sync

The PSM900 transfers settings in either direction:
from the bodypack to the rack unit, or from the
rack unit to the bodypack.

• Sending settings to the bodypack: Align
the IR windows and press the sync button on
the rack unit. The blue LED on the bodypack
flashes.

• Downloading settings from the bodypack:

First press the scan button on the bodypack.
Then align the IR windows and press the sync
button on the rack unit while the bodypack
display is flashing “SYNC NOW...”. The level
LEDs flash on the rack unit.

MixMode

Some performers need to hear more of their own
voice or instrument, while others want to hear
more of the band. With MixMode, the performer
creates their own mix using the balance control

(▼▲buttons)onthebodypack.

To use MixMode, send a solo mix of the perform­er to the CH. 1 IN input on the transmitter, and
send a band mix to the CH. 2 IN input.

Set the performers bodypack for MixMode. The
bodypack combines the two signals and sends
them to both earphones, while the balance control
on the bodypack adjusts the relative levels for
each.

CueMode

CueMode allows you to upload the name and fre­quency settings from multiple rack units and store
them as a list on a single bodypack. You can
then, at any time, scroll through that list to hear
the audio mix from each transmitter, just as each
performer does during a show.

CueMode lists are retained even if CueMode is
exited, the bodypack is turned off, or batteries are
removed.

level L R menu sync volume power

CLIP

sync

LOOP Applications

Use LOOP OUT L (left) and R (right) outputs to send a copy of the audio signal going into the transmit­ter to other devices. Following are a few of the many applications for these outputs.

Note: The input level control and the input pad do not affect the LOOP OUT signals.

Stereo for Multiple Systems

Send one stereo signal from the mixing console
the inputs on the first transmitter, then connect the
LOOP outputs to the inputs on the next transmit­ter. Repeat for all transmitters to form a chain.

level L R menu sync volume power

CLIP

sync

Floor Monitors

Send the audio from the LOOP outputs to onstage
loudspeakers. The bodypack and the onstage
monitors receive the same audio signals.

Recording Devices

To record a performance, connect the LOOP out­puts to the inputs of a recording device.

2

Controls and Connectors

P9T

www.shur e.com

L6E 656-692 MHz

power

level volumemenu

PSM 900 Transmitter P 9T

RL

clip

enter

exit

sync

sync

Front Panel Controls

① Input Level Control and Display Usethe▼▲buttonstoadjustthe

audio so that, for the average input signal level, the top two yellow LEDs
flicker and the lower LEDs are solid. The red clip LED indicates the inputs
are overdriven. Reduce the level at the audio source or change the input
sensitivity of the rack unit from the AUDIO>INPUT menu.
② Status Display and Menu Controls Use the enter and exit buttons
and the menu wheel to access the configuration menu. Push the menu
wheel to move the cursor to the next item. Turn the menu wheel to change
a parameter—the enter button flashes. Press it to save the value. Press
the exit button to cancel changes and return to the previous menu.
③ Synchronization Button Press the sync button while rack unit and
bodypack IR windows are aligned to transfer settings.
④ Headphone Monitoring The volume control adjusts signal output to
the 3.5 mm headphone jack. NOTE: it does not affect rear panel outputs.
⑤ RF switch mutes RF output. For setting up multiple systems or
adjusting settings without transmitting unwanted RF or audio signals.
⑥ Power Button Turns the unit on and off.

PSM 900 Transmitter

14-18V 550mA

P9 T

R L

LEFT/CH. 1 INDC INPUT RIGHT/CH. 2 IN ANTENNALOOP OUT

Rear Panel Connectors

⑦ Power Connect the transmitter to a power outlet using the supplied
power adapter.
⑧ LOOP OUTSends a copy of the audio signal going into the transmitter
to another device. See LOOP Applications.
⑨ Audio Inputs Connect to balanced or unbalanced outputs. Use either
connector for mono input. Accepts both 1/4-inch or male XLR connectors.
⑩ Antenna (BNC) Attach supplied antenna. If you are rack mounting, use
a front panel or remote mounting kit from Shure.

P9R

Bodypack Receiver

① Power Switch and Volume Control Turns the bodypack on and off
and adjusts earphone volume.

② 3.5 mm Earphone Jack Insert earphones here.
③ Scan Button Press the scan button to find an available frequency.

Press and hold for two seconds to find the group with the most available
channels.

④ IR Window For transmitting settings between bodypack and rack unit.
⑤ Battery Compartment Requires 2 AA batteries. Open by pressing the

latches on both sides and pulling.

⑥ Menu buttons Useinconjunctionwiththe▼▲buttonstoaccessthe

configuration menus.
⑦ ▼▲ Buttons Use to adjust the audio mix (in MixMode only), or in
conjunction with the menu buttons to change settings.

⑧ LCD Screen Displays current settings and menus.
⑨ Tri-Color Battery LED illuminates green, orange, red, or flashing

red, to indicate battery power. When flashing red, change batteries
immediately.
⑩ Blue RF LED Indicates the bodypack is receiving a signal from the
transmitter.

⑪ Detachable Antenna SMA Connector

Battery Indicator Tri-Color Battery

LED

Green 5–7 4

Green 3½–4 3–3½

Green 3–3½ 1½–2

Green 2–2½ ⅕

Orange ½–1 0

Red ⅕–½ 0

Approximate Hours Remain­ing

Alkaline NiMH (2450

mAh)

3

Quickstart Instructions

Multiple System Setup

CueMode

Bodypack

Insert batteries and attach antenna. Turn on using
the volume knob. The battery light illuminates.

Rack Unit

1. Connect to a power outlet using the supplied
power adapter.

2. Attach the supplied antenna to the ANTENNA
OUT BNC connector.

3. Connect the audio source, such as the output
of a mixer, to the audio inputs. You can use
both input jacks or choose either one for a
mono source.
– For mono (one input), access the AUDIO
menu and select MONO.

– Set the input sensitivity to match the source
by selecting AUDIO>INPUT from the LCD con­figuration menu: AUX –10dBV or LINE+4dBu.

4. Turn the power ON. Make sure the RF switch
is OFF.

5. Adjust the audio source level so that, for the
average input signal level, the top two yellow
LEDs flicker and the lower LEDs are solid.
– If the red clip LED illuminates, the inputs are

overdriven.Decreasethelevelusingthe▼▲

buttons or change the input sensitivity to –10
dBV.

– If the signal level is too low, change the input
sensitivity to +4dBu.

When setting up multiple systems, designate a
single bodypack to scan for available frequencies
and download them to all the rack units.

The bodypack must be from the same frequency
band as all the transmitters.

1. Power on all the rack units. Turn off the RF.

(This prevents them from interfering with the
frequency scan.)
Note: Turn on all other wireless or digital de­vices as they would be during the performance
or presentation (so the scan will detect and
avoid any interferance they generate).

2. Use the bodypack to scan for a group by
pressing and holding the scan button for two
seconds. The bodypack displays the group
and the number of available channels, and

flashes SYNC NOW....

Important: Note the number of available
channels. If you have more rack units than
available channels, eliminate potential sources
of interference and try again, or call Shure
Applications for assistance.

3. Sync the bodypack with the first rack unit by
aligning the IR windows and pressing sync.

4. Press scan again on the bodypack to find the
next available frequency.

5. Sync the bodypack with the next rack unit.

6. Repeat with all the rack units.

7. Sync each performer’s bodypack to its respec­tive rack unit by aligning the IR windows and
pressing snyc. DO NOT press scan on the
bodypacks.

8. Turn on the RF on all rack units. The systems
are ready to use.

Note: Set the channel frequency and assign dis­play names for each transmitter before creating
your CueMode list.

Adding Transmitters to the CueMode
List

Note: The transmitter must be from the same fre-

quency band as the bodypack.

1. Open the battery door and press the enter
button.

2. From the main menu, scroll to UTILITIES and
press enter. Select CueMode and press enter
again.

3. Align IR windows and press sync on the rack
unit.
The LCD displays SYNC SUCESS after fre­quency and name data are uploaded to the
CueMode list. It also displays the CueMode
number for that transmitter and the total num­ber of transmitters.

4. Repeat the above step for each transmitter.

Note: Syncing while in CueMode does not
change any of the settings on the bodypack.

Auditioning Mixes

1. Enter CueMode from the UTILITIES menu.

2. Usethe▼▲buttonstoscrollthroughyour
CueMode list to hear the mixes.

Exiting CueMode

Exit CueMode by pressing enter and selecting
EXIT CUEMODE.

Scan and Sync

1. Press the scan button. The display flashes

SYNC NOW....

2. Align the IR windows on the bodypack and
rack unit and press the sync button. The rack
unit level LEDs flash, and it displays SYNC
SUCCESS.

3. Turn the RF switch on. The blue RF LED il­luminates on the bodypack to indicate that it is
detecting the transmitter. The bodypack also
displays the RF signal strength (RF).

4. IMPORTANT: Turn bodypack volume down
before plugging in earphones.

5. Insert the earphones and slowly turn up the
volume.

MixMode for Multiple
Systems

Configure each system for MixMode. From the
mixing console, send a mix of the whole band
to input 2 of the first transmitter. Connect the
LOOP OUT R output to the CH. 2 IN input of the
next transmitter. Continue the chain with all the
transmitters.

Next, create solo mixes for each performer. Send
each mix to input 1 of the transmitter for that
performer.

Managing CueMode Mixes

While in Cue Mode, you can access the following
menu by pressing enter:

REPLACE MIX Select and press sync on a rack
unit to upload new data for the current mix (for
example, if you have changed the transmitter
frequency).

DELETE MIX Removes the selected mix.
DELETE ALL Removes all mixes.
EXIT CUEMODE Exits CueMode and returns the

bodypack to the previous frequency setting.

4

Configuration Menu

Press enter to access settings. After adjusting a setting, press enter to accept the change.

Note: Configuration menu items may vary with regional model variations.

P9T Rack Unit Transmitter

RF Settings

RADIO

G

CH

888.888MHz

RF POWER

Audio Settings

AUDIO

MODE

INPUT

Utilities and Display Settings

UTILITIES

EDIT NAME

DISPLAY

CONTRAST

LOCK PANEL

RX SETUP

CUSTOM GROUP

Sets the group number

Sets the channel number

Manual frequency selection

Select from 10, 50, or 100 mW (varies by region)

Selects monitor mode

STEREO/MX

MONO

Sets nominal input level

LINE +4 dBu

AUX –10dBV

Changes the name on the LCD display (this name is
uploaded to the bodypack with sync)

Changes the display format

Changes the display contrast

Press enter to lock the front panel controls. To un­lock, press exit, select OFF, and press enter.

These settings are sent to the bodypack during a
sync (when the sync direction is from the transmit­ter). The default KEEP parameter will not change the
bodypack settings.

LOCK

V LIMIT

LIM VAL

MODE

BAL MX

BAL ST

HIBOOST

For creating custom frequency groups

Transmits both channels

Transmits a mono signal to
bodypack

line level

aux level

Lock bodypack

Volume limiter

Volume limiter value

Stereo (ST) or MixMode (MX)

CH. 1 (L) and CH. 2 (R) mix for
MixMode

Left (L) and right (R) balance
for stereo mode

high frequency boost

P9R Bodypack Receiver

RF Settings

RADIO

G

CH

888.888MHz

Audio Settings

AUDIO

MODE

HIBOOST

V LIMIT

BAL ST / BAL MX Left and right balance for earphones when in stereo

Utilities and Display Settings

UTILITIES

CUEMODE

DISPLAY

CONTRAST

LOCK PANEL

Sets the group number

Sets the channel number

Manual frequency selection

Selects monitor mode

STEREO

MIXMODE

High-frequency EQ boost

OFF

6 dB

3 dB

ON

VALUE

mode, or mix of left and right channel for MixMode

Enters CueMode
(to exit, press enter
and select EXIT
CUEMODE)

Changes the dis­play format

Changes the dis­play contrast

Locks all controls
except power and
volume. To unlock,
press exit, select
OFF, and press
enter.

Stereo

MixMode

flat

+6 dB @ 10 kHz

+3 dB @ 6 kHz

Limits volume level

5–9: analogous to volume
knob position (for example, 5
is equal to the 5th dot on the
volume knob)

5

SPECIFICATIONS

PSM900

RF Carrier Range

470–952 MHz

Note: varies by region

Compatible Frequencies

Per band: 20

Tuning Bandwidth

US: 36–40 MHz

varies by region

Operating Range (environment dependent)

90 m (300 ft)

Audio Frequency Response

35 Hz–15 kHz

Stereo Separation

60 dB

Signal-To-Noise Ratio (A-Weighted)

90 dB (typical)

Total Harmonic Distortion (ref. ±34 kHz deviation
@1 kHz)

<0.8% (typical)

Companding

Patented Audio Reference Companding

Spurious Rejection (ref. 12dB SINAD)

>80 dB (typical)

Frequency Stability

±2.5 ppm

MPX Pilot Tone

19 kHz (±0.3 kHz)

Modulation

FM*, MPX Stereo

* ±34 kHz deviation (nominal)

Operating Temperature

-18°C–+57°C

P9R

Front-End RF Filtering

–3 dB at 30.5 MHz from center frequency

Active RF Gain Control

31 dB

Adjusts RF sensitivity to provide more RF dynamic range

RF Sensitivity (at 20 dB SINAD)

2.2 µV

Image Rejection

>100 dB

Adjacent Channel Rejection

>70 dB

Squelch Threshold

22 dB SINAD (±3 dB)

Intermodulation Attenuation

>70 dB

Blocking

>80 dB

Audio Output Voltage (1kHz @ <1% distortion, peak

power,@32Ω)

100 mW per output

Minimum Load Impedance

9.5Ω

High Boost

selectable: +2 dB @ 6 kHz , +4 dB @ 10 kHz

Volume Limiter

selectable: 3–9

Reduces maxium output level. Selected value analogous to vol­ume knob increment.

Net Weight

200 g (with batteries)

Dimensions

83 mm X 65 mm X 22 mm

Battery Life

5–7 hours (continuous use)

P9T

RF Output Power

selectable: 10, 50, 100 mW (+20 dBm)

varies by region

Antenna Input Impedance

50Ω(typical)

Net Weight

850 g

Dimensions

197 mm X 166 mm X 42 mm

Power Requirement (RF on, 100 mW power mode, no
audio)

120 VAC: 415 mA, typical

Audio Inputs

Combination XLR and 6.35 mm (1/4”) TRS

Polarity

XLR: Non-inverting (pin 2 positive with respect to pin 3)

6.35 mm (1/4”) TRS: Tip positive with respect to ring

Configuration

Electronically balanced

Impedance

70.2kΩ(actual)

Nominal Input Level

switchable: +4 dBu, –10 dBV

Maximum Input Level

+4 dBu: +23.3 dBu
–10 dBV: +12.5 dBu

Pin Assignments

XLR: 1=ground, 2=hot, 3=cold

6.35 mm (1/4”) TRS: Tip=hot, Ring=cold,

Sleeve=ground

Phantom Power Protection

up to 60 V DC

Outputs

6.35 mm (1/4”) TRS

Configuration

Electronically balanced

Impedance

Connected directly to inputs

Furnished Accessories

P9R Antenna

470–542 MHz UA700
596–692 MHz UA720
692–830 MHz UA730
830–952 MHz UA740

P9T Antenna

470–530 MHz UA820G
500–560 MHz UA820G7
518–578 MHz UA820H4
578–638 MHz UA820J
638–698 MHz UA820L3
690–746MHz UA820B
740–814 MHz UA820Q
900–952 MHz UA820X

Front Mount Antenna Cable 95A9023
Zipper Bag 95A2313
Rackmount Bracket, Long (1) 53A8612
Rackmount Bracket, Short (2) 53A8611
Link Bar (2) 53B8443
Hardware Kit (Rackmounting

Screws)

90AR8100

Bumper Kit 90B8977
Energy Efficient Switching Power Supply

USA PS41
Brazil PS41BR
Argentina PS41AR
Europe PS41E
United Kingdom PS41UK
Austrailia/New Zealand PS41AZ
China PS41CHN
Taiwan PS41TW
Japan PS41J

Optional Accessories

8-to-1 antenna combiner for
better RF performance

4-to-1 antenna combiner with
power distribution to 4 transmit­ters (better RF performance
and eliminates need for external
power supply)

Passive Directional Antenna PA805SWB
Helical Antenna HA-8000
Passive Omnidirectional

Antenna
4-Channel Personal Monitor

Mixer
Coaxial Cable, BNC-BNC,

RG58C/U type, 50 Ohm, 2 ft
length (0.6 m)

Coaxial Cable, BNC-BNC,
RG58C/U type, 50 Ohm, 6 ft
length (2 m)

Coaxial Cable, BNC-BNC,
RG8X/U type, 50 Ohm, 25 ft
length (7.5 m)

Coaxial Cable, BNC-BNC,
RG8X/U type, 50 Ohm, 50 ft
length (15 m)

Coaxial Cable, BNC-BNC,
RG213/U Type, 50 Ohm, 100 ft
length (30 m)

PA821SWB

PA421SWB

PA860SWB

P4M

UA802

UA806

UA825

UA850

UA8100

6

CERTIFICATION

P9T, P9R

This Class B digital apparatus complies with
Canadian ICES-003.

Cet appareil numérique de la classe B est con­forme à la norme NMB-003 du Canada.

P9T

Certified under FCC Parts 74. (FCC ID:
DD4P9TA, DD4P9TB, DD4P9TC, DD4P9TD,
DD4P9TJ). Certified by IC in Canada under RSS­123 and RSS-102. (IC: 616A-P9TA, 616A-P9TB,
616A-P9TC, 616A-P9TD). Meets essential re­quirements of European R&TTE Directive 99/5/
EC, eligible to bear the CE mark. Type approved
to EN 300 422 Parts 1 and 2. Meets requirements
of EMC Standard EN 301 489 Parts 1 and 9.

P9R

Approved under the Declaration of Conformity
(DoC) provision of FCC Part 15. Certified in
Canada by IC to RSS-123. (IC: 616A-P9RA,
616A-P9RB, 616A-P9RC, 616A-P9RD). Meets re­quirements of EMC standards EN 300 422 Parts 1
and 2 and EN 301 489 Parts 1 and 9.

Operation of this device is subject to the following
two conditions: (1) this device may not cause in­terference, and (2) this device must accept any in­terference, including interference that may cause
undesired operation of the device.

The Declaration of Conformity can be obtained
from Shure Incorporated or any of its European
representatives. For contact information
please visit www.shure.com The Declaration of
Conformity can be obtained from:

Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Wannenacker Str. 28
D-74078 Heilbronn, Germany
Phone: [phone]
Fax: [phone]
Email: [e-mail]

LICENSING INFORMATION

Licensing: A ministerial license to operate this
equipment may be required in certain areas.
Consult your national authority for possible
requirements. Changes or modifications not ex­pressly approved by Shure Incorporated could
void your authority to operate the equipment.
Licensing of Shure wireless microphone equip­ment is the user’s responsibility, and licensability
depends on the user’s classification and ap­plication, and on the selected frequency. Shure
strongly urges the user to contact the appropriate
telecommunications authority concerning proper
licensing, and before choosing and ordering
frequencies.

INFORMATION TO USER

This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These lim­its are designed to provide reasonable protection
against harmful interference in a residential instal­lation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communica­tions. However, there is no guarantee that inter­ference will not occur in a particular installation. If
this equipment does cause harmful interference
to radio or television reception, which can be de­termined by turning the equipment off and on, the
user is encouraged to try to correct the interfer­ence by one or more of the following measures:

• Relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.

• Consult the dealer.

Note: EMC conformance testing is based on the
use of supplied and recommended cable types.
The use of other cable types may degrade EMC
performance.

Changes or modifications not expressly ap­proved by the manufacturer could void the
user’s authority to operate the equipment.

7

www.shure.com

United States:

Shure Incorporated
5800 West Touhy Avenue
Niles, IL 60714-4608 USA

Phone: [phone]
Fax: [phone]
Email: [e-mail]

©2009 Shure Incorporated

Europe, Middle East, Africa:

Shure Europe GmbH
Wannenäckestr. 28,
74078 Heilbronn, Germany

Phone: [phone]
Fax: [phone]
Email: [e-mail]

Asia, Pacific:

Shure Asia Limited
Unit 301, 3rd Floor
Citicorp Centre
18, Whitfield Road
Causeway Bay, Hong Kong

Phone: [phone]
Fax: [phone]
Email: [e-mail]

Canada, Latin America,
Caribbean:

Shure Incorporated
5800 West Touhy Avenue
Niles, IL 60714-4608 USA

Phone: [phone]
Fax: [phone]
Email: [e-mail]
