Shure VP83 User Guide

VP83

LensHopper™ Camera-Mount Condenser Microphone

The Shure professional shotgun microphone, VP83, user guide.

Version: 1.1 (2020-H)

Shure Incorporated

Table of Contents

VP83 LensHopper™ Camera-Mount Condenser Micro-
phone	3
General Description	3
Features	3
VP83	3
Mounting the Microphone	4
On a Camera:	4
Installing Batteries	5

Audio Configuration	5
Low-cut Filter	7
Monitoring the Audio Signal	7
Why Gain Settings are Important	7
Troubleshooting	7
Specifications	7
Battery Life	9
Accessories and Replacement Parts	10
Certifications	10

2/10

Shure Incorporated

VP83

LensHopper™ Camera-Mount Condenser Microphone

General Description

Designed for use with DSLR and video cameras, the Shure VP83 condenser microphone enables videographers to capture professional quality audio. Adjustable gain, superior off-axis rejection, and a selectable low-cut filter provide exceptional definition and clarity. Consistent with Shure's commitment to quality and durability, the VP83 features a lightweight, all-metal housing and a built-in shock mount for reliable use in the field.

Features

•Supercardioid/lobar pattern rejects unwanted off-axis sounds

•Low-cut and gain switches for maximum adaptability

•Integrated shock mount

•130 hours of battery life

•Built-in 3.5 mm audio output cable

•Superior RF immunity

•Durable, all-metal housing

•Shoe mount adapter for easy installation

VP83
