Personal Monitoring Bodypack
P9HW
USER GUIDE
Le Guide de l’Utilisateur
Bedienungsanleitung
Manuale d’uso
Guia del Usuario
Guida dell’Utente
Руководство пользователя
Gebruikershandleiding
Pengguna Panduan
ユーザーガイド
사용자 안내서
用户指南
取扱説明書
© 2014 Shure Incorporated
27A23052 (rev. 1)
Printed in China
IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Allow sufficient
distances for adequate ventilation and install in
accordance with the manufacturer’s instructions.
8. DO NOT install near any heat sources such as open flames, radiators,
heat registers, stoves, or other apparatus (including amplifiers) that
produce heat. Do not place any open flame sources on the product.
9. DO NOT defeat the safety purpose of the polarized or groundingtype plug.
A polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wider blade or
the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms or
when unused for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15. DO NOT expose the apparatus to dripping and splashing. DO NOT
put objects filled with liquids, such as vases, on the apparatus.
16. The MAINS plug or an appliance coupler shall remain readily operable.
17. The airborne noise of the Apparatus does not exceed 70dB (A).
18. Apparatus with CLASS I construction shall be connected to a
MAINS socket outlet with a protective earthing connection.
19. To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
20. Do not attempt to modify this product. Doing so could
result in personal injury and/or product failure.
21. Operate this product within its specified operating temperature range.
SAFETY PRECAUTIONS
The possible results of incorrect use are marked by one of the two
symbols—"WARNING" and "CAUTION"—depending on the imminence of
the danger and the severity of the damage.
WARNING: Ignoring these warnings may cause severe injury or
death as a result of incorrect operation.
CAUTION: Ignoring these cautions may cause moderate injury
or property damage as a result of incorrect operation.
CAUTION
• Never disassemble or modify the device, as failures may result.
• Do not subject to extreme force and do not pull on the cable or failures
may result.
• Keep the product dry and avoid exposure to extreme temperatures and
humidity.
WARNING
• If water or other foreign objects enter the inside of the device, fire or
electric shock may result.
• Do not attempt to modify this product. Doing so could result in personal
injury and/or product failure.
This device is able to produce sound volume higher than 85 dB SPL.
Please check your maximum allowed continuous noise exposure level
based on your national employment protection requirements.
WARNING: This product contains a chemical known to the State of
California to cause cancer and birth defects or other reproductive harm.
WARNING
LISTENING TO AUDIO AT EXCESSIVE VOLUMES CAN CAUSE
PERMANENT HEARING DAMAGE. USE AS LOW A VOLUME AS
POSSIBLE. Over exposure to excessive sound levels can damage your
ears resulting in permanent noise-induced hearing loss (NIHL). Please
use the following guidelines established by the Occupational Safety Health
Administration (OSHA) on maximum time exposure to sound pressure levels
before hearing damage occurs.
90 dB SPL
at 8 hours
110 dB SPL
at ½ hour
95 dB SPL
at 4 hours
115 dB SPL
at 15 minutes
100 dB SPL
at 2 hours
120 dB SPL
Avoid or damage may occur
105 dB SPL
at 1 hour
1
General Description
Instrument mix
Vocal mix
௦
௧
௨
௩
௪
Setup
The Shure P9HW is a wired, two-channel stereo bodypack system designed
to replace loudspeakers used for onstage monitoring. The portable, lightweight
P9HW has several advantages over onstage monitor loudspeakers: it is less
visible, offers improved clarity and control of sound, reduces the chances of
feedback, and reduces stage clutter. It is a versatile system, designed for use
in sound reinforcement applications including public address, live music, studio
recording, broadcast, and theater.
P9HW Bodypack
④ Battery LED
Indicates battery health
Note: see the battery life table for
specific runtime values
⑤ Headphone Output
Use earphones or headphones
with a 3.5 mm (1/8-inch) plug
⑥ Display
Shows settings and menu
navigation
⑦ Navigation buttons (▲▼)
Use to scroll through menu and
adjust settings
⑧ Exit button
Press to return to previous screen
① Insert batteries
Use the Shure SB900 rechargeable battery pack or two AA batteries.
② Connect the bodypack to an audio source using the supplied
Y-splitter cable
Connect the 5-pin LEMO connector to the bodypack, with the red dot on
the cable aligned with the notch inside the bodypack connector. Route the
two XLR connectors on the cable to the appropriate mixer outputs. See
the system overview diagram for a signal routing example.
Note: the bodypack can connect either directly to the mixer or through a patch
bay on stage.
③ Put on the earphones and connect them to the headphone output
The P9HW is designed to perform best with Shure earphones, but works
with any headphones or in-ear monitors that have a standard 1/8-inch (3.5
mm) stereo plug.
④ Turn the power on
Turn the volume knob clockwise until it clicks to turn on the power.
Caution: do not turn the volume knob all the way up when turning
the power on.
⑤ Slowly increase the volume until it reaches a comfortable level for
listening
To set a maximum volume limit, use the VLIMIT function. See the utilities
section of this guide for more information.
① Audio Input
Use the supplied Y-splitter cable
to connect up to two sources.
Important:
the cable with the notch inside the
bodypack input.
② Clip Indicator
Illuminates when the input is
overloaded. Turn the volume
down at the mixer until the light
remains off.
③ Volume Knob / Power Switch
Turn to power on/off and adjust
headphone volume
Align the red dot on
⑨ Enter button
Press to enter a menu screen or to
confirm a setting
⑩ Factory Service Window
Used for importing firmware onto
the bodypack at the factory (not
user-serviceable)
⑪ Battery Compartment
Uses a Shure SB900 rechargeable
battery or two AA batteries
⑫ Removable AA Adapter
Remove to use with a Shure
SB900 rechargeable battery
Note:
To remove, open the door and
slide the adapter out. To reinstall,
press the adapter into place—there is
an audible click when seated.
System Overview
2
Audio Settings
15
10
5
0
-15
-10
-5
20 100 1k 10k 20k
dB
(Hz)
GAIN
FREQUENCY
Q
LOW LOW-MID HIGH-MID HIGH
+6 dB
-6 dB
= Selectable frequencies
Left (Channel 1)
Right (Channel 2)
Utilities
MODE
STEREO: Audio from channel 1 is heard on the left earphone; audio
from channel 2 is on the right earphone.
MIXMODE: Both channels are heard on the left and right earphones.
The blend between mixes is adjustable.
EQ
The parametric equalizer is divided into four frequency bands:
LOW, LOW MID, HIGHMID, and HIGH. When the equalizer is enabled, the
following parameters are adjustable:
FREQUENCY: Select the center frequency of the band to boost/cut
Q: Adjusts the width and slope of the frequency
band (measured in octaves)
GAIN: Adjustable in 2 dB increments from -6 dB (cut) to +6 dB (boost)
Note:
HIGH and LOW are shelf filters, and therefore do not have adjustable
Q widths. The HIGH shelf is fixed at 10 kHz; the LOW shelf is fixed at 100 Hz.
VLIMIT (Maximum Volume)
Set a value (-3 to -21 dB) to attenuate the highest possible volume
level. Turning the volume knob through its entire range of motion still
affects volume; the limit simply narrows the range of dB adjustment.
Note:
The VLIMIT does not compress the audio.
BAL MX / BAL ST (Balance)
The behavior of the balance control depends on which mode the
bodypack is set to:
STEREO: Adjusts the left/right balance
MIXMODE: Adjusts the blend between channel one and channel two
INPUT
Line (+4 dBu): Use with mixers and other professional devices that
send a line-level signal
AUX (-10 dBV): Use with consumer electronic devices, such as MP3
players or computers.
CONTRAST
Customize the display screen contrast by selecting a setting between
low and high
LOCK PANEL
Locks all controls except the volume knob to prevent accidental changes
to settings
Lock: Select UTILITIES > LOCK PANEL
Unlock: Press the exit button and select OFF when the
lock setting screen appears. Press enter to confirm.
BATTERY
Displays remaining battery runtime (hours:minutes), health, temperature,
status, cycle count, and voltage.
RESTORE
Restores bodypack to factory default settings
AUTO OFF
Automatically turns off the bodypack after a selectable amount of time
(5, 30, or 60 min.) while it is in power-save mode or when connected to a
charger with the power on. To restore power to the bodypack, the power
switch must be turned off and then on again.
Note: SB900 batteries charge fastest when the bodypack is off
MixMode and Stereo Monitoring
The bodypack can operate in either of the following listening modes:
Stereo (default)
To operate in stereo mode, enter the menu and select AUDIO > MODE >
STEREO .
In stereo mode, audio from channel 1 is heard on the left earphone, while
audio from channel 2 is heard on the right earphone. Listening in stereo
increases clarity and separation between the sources on each channel.
Adjusting Balance
To adjust the left/right balance, select AUDIO > BAL ST. Use the ▲▼ buttons
to change the setting.
3
MixMode
MIXMODE
10L
Instruments
Vocals
Instruments
Vocals
MIXMODE
10R
Instruments
Vocals
Instruments
Vocals
LED
To operate in MixMode, enter the menu and select AUDIO > MODE > MIXMODE.
In MixMode, the blend between two monitoring mixes (an instrumental mix and
a vocal mix, for example) is adjustable. The signal is mono, which means each
mix is heard through both the left and right earphones.
Adjusting mix blend
To adjust the blend between channel 1 and channel 2, enter the menu and
select AUDIO > BAL MX. Use the arrow buttons (▲▼) to make adjustments.
In this scenario, an instrumental mix is on channel 1 (left) and a vocal mix is on
channel 2 (right):
To hear more of channel
one (instruments), shift the
balance towards the left.
Shure SB900 Rechargeable Battery
Shure SB900 lithium-ion batteries offer a rechargeable option for powering
the bodypack. Batteries quickly charge to 50% capacity in one hour and
reach full charge within three hours.
Single chargers and multiple bay chargers are available to recharge the
Shure batteries.
Caution: Only charge Shure rechargeable batteries with a Shure battery
charger.
Single Bay Charger
The SBC-100 single bay charger offers a compact charging solution.
1. Plug the charger into an AC power source or USB port.
2. Insert a battery into the charging bay.
3. Monitor the charging status LEDs until charging is complete.
Charging Status LED
Color Status
Red Charging
Green Charging Complete
Amber Flashing Fault: check
connections and
battery
Off No battery in bay
To hear more of channel
two (vocals), shift the
balance towards the right.
Balance and Mix Adjustments from the Home Screen
To make quick adjustments to the stereo balance or mixmode blend, use
the arrow buttons (▲▼) while in the home screen. If necessary, use the lock
feature to prevent any accidental adjustments.
Multiple Bay Chargers
Shure offers three models of multiple bay chargers:
• SBC200 two bay charger
• SBC210 two bay charger
• SBC800 eight bay charger
Multiple bay chargers can charge individual batteries or batteries installed in
bodypacks.
1. Plug the charger into an AC power source.
2. Insert batteries or transmitters into the charging bay.
3. Monitor the charging status LEDs until charging is complete.
4
Charging Status LED
Color Status
Green Charging Complete
Green/Red Charge level above 90%
Red Charging
Amber Flashing Fault: check connections and battery
Off No battery in bay
Important Tips for Care and Storage of Shure
Rechargeable Batteries
Proper care and storage of Shure batteries results in reliable performance and
ensures a long lifetime.
• Always store batteries and bodypacks at room temperature
• Ideally, batteries should be charged to approximately 40% of capacity for
long-term storage
• During storage, check batteries every 6 months and recharge to 40% of
capacity as needed
Battery Life
Optional Accessories and
Replacement Parts
Dual-XLR to 5-pin LEMO cable PA720
Shure Lithium-Ion Rechargeable Battery SB900
AA battery adapter 65A15224
Dynamic MicroDriver earphones SE112
Dynamic MicroDriver earphones SE215
High-definition MicroDriver earphones with tuned bass port SE315
High-definition earphones with dual MicroDrivers SE425
High-definition earphones with triple MicroDrivers SE535
High-definition earphones with quad MicroDrivers SE846
Battery
Indicator
Total Battery Life 9:00 9:50
Note: Battery life using Energizer™ brand AA Alkaline batteries and the
following conditions:
• Receiver audio set to EQ = OFF, V LIMIT = OFF
• Audio output at bodypack: Pink noise at 100 dB SPL in ear with SE425
earphones (impedence at 20 Ω)
Power-save mode: When there are no earphones plugged in for 5 minutes,
the receiver enters power-save mode to preserve battery life. The LED slowly
fades on/off in this mode and continues to display the color that represents the
remaining battery life.
Tri-Color
Battery
LED
Green 9:00 to 7:10 9:50 to 7:50
Green 7:10 to 5:25 7:50 to 5:55
Green 5:25 to 3:35 5:55 to 3:55
Green 3:35 to 1:45 3:55 to 2:00
Amber 1:45 to 0:50 2:00 to 1:00
Red < 0:50 < 1:00
Approximate Hours Remaining (h:mm)
Alkaline Shure SB900 Rechargeable
Battery
5
Pin Assignments
1
1
2
2
3
3
4 4
5 5
Bodypack 5-pin connector (female)
Cable 5-pin connector (male)
Red dot = Pin 1
XLR connectors marked: L= Left /
R=Right
Pin Signal Right XLR Left XLR
1 Shield 1 1
2 + 2 -3 - -- 3
4 + 3 -5 - -- 2
Certifications
This product meets the Essential Requirements of all relevant European
directives and is eligible for CE marking.
Meets essential requirements of the following European Directives:
• Low Voltage Directive 2006/95/EC
• EMC Directive 2004/108/EC
• WEEE Directive 2002/96/EC, as amended by 2008/34/EC
• RoHS Directive 2002/95/EC, as amended by 2008/35/EC
Note:
Please follow your regional recycling scheme for batteries and electronic
waste
Industry Canada ICES-003 Compliance Label:
CAN ICES-3 (B)/NMB-3(B)
The CE Declaration of Conformity can be obtained from Shure Incorporated
or any of its European representatives. For contact information please visit
www.shure.com
The CE Declaration of Conformity can be obtained from: www.shure.com/
europe/compliance
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Jakob-Dieffenbacher-Str. 12
75031 Eppingen, Germany
Phone: 49-7262-92 49 0
Fax: 49-7262-92 49 11 4
Email: EMEAsupport@shure.de
Note: EMC conformance testing is based on the use of supplied and
recommended cable types. The use of other cable types may degrade
EMC performance.
Please follow your regional recycling scheme for batteries, packaging, and
electronic waste.
6
Specifications
Audio Frequency Response
20 Hz–20 kHz (±3 dB)
Signal-To-Noise Ratio
A-Weighted
98 dB (typical)
Total Harmonic Distortion
@ 1 kHz, typical
<0.2%
Channel Separation
@ 1 kHz
>55 dB
Operating Temperature
-18°C to +63°C
Minimum Load Impedance
9.5 Ω
Dimensions
99 x 66 x 23 mm (3.9 in. x 2.6 in. x 0.9 in.) H x W x D
Net Weight
196 g (6.6 oz) (with batteries)
Battery Life
9 hours (continuous use) AA batteries
Audio Input
Connector Type
LEMO
Configuration
Electronically balanced
Input Impedance
Line 45 kΩ
Aux 66 kΩ
Nominal Input Level
switchable: +4 dBu(Line), –10 dBV(Aux)
Maximum Input Level
+4 dBu(Line) +20 dBu
-10 dBV(Aux) +8 dBu
Phantom Power Protection
Up to 60 V DC
Audio Output
Connector Type
3.5 mm (1/8")
7
Europe, Middle East, Africa:
PT. GOSHEN SWARA INDONESIA
Kompleks Harco Mangga Dua Blok L No. 35 Jakarta Pusat
I.16.GSI31.00501.0211
Loading...
