MOTIVTM Digital Microphones and Recording Solutions
PLUG AND PLAY RECORDING, AT HOME ANYWHERE.
MV88
MV51
Digital stereo condenser microphone for iPhone, iPod and iPad
Stereo recording, on the go.
Convenience and control come together with a Lightning connector and ve DSP preset modes for voice and instruments. Together with the free ShurePlus MOTIV mobile app, any iOS device can record 24-bit/48 kHz audio and take advantage of advanced settings including adjustable stereo width, EQ and limiter/compressor.
Matched capsules and mid-side design for clear, detailed stereo capture
Shure tested, all-metal construction withstands the most demanding conditions
90° hinge with left/right rotation for exible audio and video recording
Lightning connector for use with iPhone, iPod, and iPad
Digital large-diaphragm condenser microphone for Mac, PC, iPhone, iPod, iPad and Android devices
Recording gets real with real-time monitoring and ve DSP presets.
The MV51 combines seamless 24-bit/48kHz digital recording, vintage styling and the durability of all-metal construction for grab-and-go portability. A unique touch panel puts gain, mute and headphone volume controls right up front for total control, with positioning exibility via the built-in kickstand.
1" (25mm) microphone element captures every detail
Built-in kickstand mounts to any standard mic stand
Integrated headphone output for real-time monitoring
INCLUDES USB + Lightning Cables
BLACK
GRAY
MV5
Digital condenser microphone for Mac, PC, iPhone, iPod, iPad and Android devices
Put quality, power and style to work.
A solid choice, take after take, the MV5 is engineered for convenience and exibility, making plug-and-play 24-bit/48kHz digital recording easy. Three onboard DSP preset modes can dial in the optimal sound— perfect for podcasting, voiceovers or tracking vocals and instruments.
Microphone capsule optimized
Integrated headphone output for real-time monitoring
to deliver best in class audio
Detachable aluminum desktop stand
MVi
Digital audio interface for Mac, PC, iPhone, iPod, iPad and Android devices
Simple and exible digital recording now goes anywhere.
With an XLR + ¼" combo jack input for microphones and instruments, ve DSP presets and unique touch panel for volume, gain and mode, the MVi brings ultimate control to the creative process. Phantom power for condenser microphones and rugged, all-metal construction make reliable, 24-bit/48kHz quality digital recording possible wherever you go.
Class A preamplier input ensures consistent tone and clarity
1/8" (3.5 mm) headphone jack for real-time monitoring
XLR + 1/4" input connects microphones and instruments
OPTIONS USB Cable USB + Lightning Cables
OPTIONS USB Cable USB + Lightning Cables
TM
ShurePlus
High quality recording on any Apple lightning device, deliv­ered. The MOTIV app is loaded with smart features for digital recording on the go. It enables 24bit/48khz recording with all MOTIV products along with full control of the MV88 digital stereo condenser mic. Whether you’re music recording, eld recording, interviewing or capturing video, the ve preset modes (speech, singing, acoustic, loud, at) automatically adjust gain, stereo width, equalization and compression for pro results. The app also includes advanced features to further optimize your recordings.
MOTIV
TM
Mobile App
MVL
Omnidirectional Condenser Lavalier Microphone for iOS and Android devices.
Superior audio recording with a smartphone.
The MOTIV MVL Omnidirectional Condenser Lavalier Microphone is a quick and easy solution for clear audio in close-mic digital speech recording applications. Works with any mobile phone or tablet equipped with recording capabilities by plugging directly into the headphone jack.
Foam windscreen for clarity of speech
Omnidirectional condenser microphone with exceptional signal-to-noise ratio
Tie clip for easy attachment
MV88 Settings Screen
Select DSP Preset, Mic Gain,
and Adjustable Stereo Width
MV88 Advanced Settings Screen
Polar Pattern Select, 5-Band EQ, Wind Reduction,
Compressor, Limiter, Left/Right Channel Swap
24-bit/48 kHz .wav Format, Real-time Gain Adjustment,
High-Resolution Metering
MOTIV Record Screen
1/8" (3.5mm) TRRS connector
The free ShurePlus MOTIV mobile app is available on the Apple App Store.
MAKE ANY ROOM THE CONTROL ROOM.
Legendary performances can happen anywhere. Capture them with plug-and-play digital recording that comes with ninety years of experience. MOTIV™ Digital Microphones and Recording Solutions are the powerfully compact, stylish and solid choice. With seamless Mac/PC/iOS integration, and the free ShurePlus™ MOTIV™ mobile app for recording and monitoring with all of the MOTIV products, the focus is on getting the best take—at home or on the go.
SPECIFICATIONS
MFi Certied Yes Yes Yes Yes No
MV88 MV51 MV5 MVi MVL
DSP Modes (Presets)
Transducer Type
Polar Pattern
Recording Quality Up to 24bit/ 48 kHz Up to 24bit/ 48 kHz Up to 24bit/ 48 kHz Up to 24bit/ 48 kHz
Frequency Response 20 Hz to 20,000 Hz 20 Hz to 20,000 Hz 20 Hz to 20,000 Hz 20 Hz to 20,000 Hz 45 Hz to 20,000 Hz
Adjustable Gain Range 0 to +36 dB 0 to +36 dB 0 to +36 dB
Sensitivity -37 dBFS/Pa at 1 kHz -39 dBFS/Pa at 1 kHz - 40 dBFS/Pa at 1 kHz
Maximum SPL 120 dB SPL 130 dB SPL 130 dB SPL 124 dB SPL
Headphone Output
Power Requirements
Phantom Power +48V USB/+12V iOS
Mic Mute Switch Yes Yes Yes
Mounting Stand Built-in Included
Speech / Singing / Acoustic / Loud / Flat
Cardioid (1 cm)/ Bidirectional Condenser Cartridge (1 cm)
Adjustable Width Stereo / Mono Bidirectional / Mono Cardioid / Mid-Side
Available through Apple device
Powered through Lightning connector only
Speech / Singing / Acoustic / Loud / Flat
Electret Condenser (25 mm)
Unidirectional (Cardioid)
3.5 mm (1/8") 3.5 mm (1/8") 3.5 mm (1/8")
Powered through USB or Lightning connector
Voice / Instrument / Flat
Electret Condenser (16 mm)
Unidirectional (Cardioid)
Powered through USB or Lightning connector
Speech / Singing / Acoustic / Loud / Flat
3-pin XLR: 0 to +36 dB
6.35 mm (1/4") TRS: +9 dB
Powered through USB or Lightning connector
MEMS, Condenser
Omnidirectional
-44.0 dBFS/Pa @ 1 kHz (Ref. 1 kHz)
Powered through microphone input jack
Stand Adapter
Housing All metal construction All metal construction
Net Weight
Dimensions (H × W × D)
Cable
40.5 g (1.43oz.)
67 × 25 × 35 mm 128 × 86 × 70 mm
5/8" 27 thread mount (standard mic stand mount)
574.7 g (20.27oz.)
1 m USB cable, 1 m Lightning cable
1/4" 20 thread (standard tri-pod mount)
Die cast metal frame with ABS housing
Without desk stand:
0.09 kg (3.17oz.) With mounting stand:
0.16 kg (5.64oz.)
Without stand: 66 × 67 × 65 mm With stand: 89 × 142 × 97 mm
1 m USB cable 1 m Lightning cable (LTG models only)
All metal construction Cast Zinc
310.0 g (10.93 oz.)
42 × 84 × 72 mm
1 m USB cable, 1 m Lightning cable
8.0 g (.28 oz)
5.5 mm dia. × 15.2 mm × 132 cm (with cable)
1/8" (3.5 mm) TRRS
1.6 mm (0.06 in.) diameter
Made for iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPad Air 2, iPad mini 3, iPad Air, iPad mini 2, iPad (4th generation), iPad mini, iPod touch (5th generation).
iPad, iPhone, iPod, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. iPad Air, iPad mini, and Lightning are trademarks of Apple Inc.
MOTIV™ Digital Microphones and Recording Solutions are compatible with Android devices that support USB Audio Class 2.0 and Micro-B OTG (On-The-Go) connectivity. Not all Android devices are compatible. Android is a trademark of Google Inc.
