Shure E5c, E1c User Manual

Earphone User Guide

E1c E2c E5c

27A8809 (BI)

©2002, Shure Incorporated

Printed in U.S.A.

ENGLISH

1

27A8809 (BI)

2002, Shure Incorporated

Printed in U.S.A.

WARNING!

USING THESE EARPHONES AT EXCESSIVE VOLUMES

CAN CAUSE PERMANENT HEARING DAMAGE.
USE THE LOWEST VOLUME LEVEL POSSIBLE.

WARNING!

DUE TO THE ISOLATING CHARACTERISTICS OF THESE EARPHONES, DO NOT

USE THEM WHILE DRIVING OR WHILE BIKING, W ALKING OR JOGGING WHERE

VEHICULAR TRAFFIC IS PRESENT, OR IN ANY OTHER ACTIVITY WHERE A

FAILURE TO HEAR SURROUNDING SOUNDS COULD BE DANGEROUS.

CAUTIONS

Here are some general tips to follow for safe use of this product:

S Turn up the volume control only far enough to hear properly.
S Ringing in the ears may indicate that the volume level is too high. Try lowering

the volume.

S If you are connecting these earphones to an airplane’s sound system, listen at low

levels so when loud messages from the pilot break into the program you do not experi­ence discomfort.

S Shure recommends that you have your ears checked by an audiologist on a regular

basis. If you experience wax buildup in your ears, stop using the earphones until an
audiologist has examined your ears.

S Wipe the earphones with an antiseptic before and after use to avoid infections.

Stop using the earphones if they are causing great discomfort or infection.

ENGLISH

2

EARPHONE FEATURES

The Shure E1c, E2c and E5c earphones are ideally suited for use with CD players, MP3
players, and any other listening device that has a 3.5 mm (

1

/8-inch ) stereo output.

Features:

E1c/E5c

E2c

Low-mass, high-energy transducer

n f

Full–range dynamic transducer

f n

Universal fit

n n

Variety of isolating sleeves included

n n

Custom-molded sleeves optional E1c only

f

Adjustment tube for securing cables

n n

Tool for removing wax buildup in earphone

n f

Wax guard to prevent wax buildup
in earphone

f n

n = Model has listed feature.
f = Model does not have listed feature.

ENGLISH

3

EARPHONE COMPONENTS

The earphone components are illustrated below, using the E5c and E2c models as exam­ples. Your earphone shape may vary, depending on the model.

Ê

Earphones. For models E1c and E5c, the earphone with the BLUE marking fits in the
left ear, while the earphone with the RED marking fits in the right ear. For model E2c,

the bi-colored earphone fits in the right ear, while the earphone that is all one color fits
in the left ear. When properly inserted, the Shure logo will appear right-side up on the
outside of the earphone with the cable exit pointing upwards.

Ë

Sleeves. The E1c and E5c earphones come with a pair of foam sleeves (installed),
and a trial assortment of flex sleeves —small, medium, and large. The E2c earphones

come with a pair of flex sleeves (installed) and a trial assortment of foam and flex
sleeves in a variety of sizes. See Sleeve Varieties on page 5.

Ì

Adjustment Tube. For a secure fit, slide the adjustment tube back and forth to adjust
the slack of the cables leading to the earphones.

Í

Input Connector. 3.5 mm (1/8-inch) plug connects to the 3.5 mm stereo earphone
output of a listening device.

Î

Wax Guard. (model E2c only) The earphones come with special wax guards (not
installed) for keeping unwanted wax out of the nozzle.
