SHUOYING UMPC9901 User Manual

Table of Contents

1. Overview ........................................................................................................................................................................................ 2

2. Structure.......................................................................................................................................................................................... 2

3. Operation Instructions.................................................................................................................................................................... 4

3.1 Turn-on.............................................................................. ............................................................................................. 4

3.2 Turn-off........................................................................................................................................................................... 4

3.3 Reset............................................................................................................................................................................... 4

3.4 Charge............................................................................................................................................................................. 5

3.5 Network Setup................................................................................................................................................................5

3.6 Website Browse................................. ................................................ ............................................................................. 5

3.7 Instant Communication ..................................................................................................................................................5

3.8 One Button Internet Access............................................................................................................................................ 5

3.9 Office Software............................................................................................................................................................... 6

3.10 Media Playback............................................................................................................................................................6

3.11 File Management..........................................................................................................................................................7

1. Overview
The Internet Access Laptop is a mini multifunctional laptop equipped with low power consumption ARM926-EJS based on
AK7802 CPU and pre-installed the Microsoft Windows CE 5.0 operating system. As for its functions, please refer to the
following:

1) Wireless Internet Access

2) Wire Internet Access
Media Playback
Mobile Office
Games and Entertainment
The mini laptop is also characterized by features like low power consumption (the battery operation time is way longer than that
of normal laptop batteries), small size and light weight and so on, suitable for internet access, entertainment, basic computer
operation learning as well as computer-aid learning for children etc.

2. Structure

2.1 Outer Structure

2.2.1 Keyboard and Mouse Ports

4. Cautions.......................................................................................................................................................................................... 8

Appendix: Internet Access Instructions............................................................................................................................................10

1

2

SD Card Socket

Headset Sockets

Keyboard and Mouse Ports

Notes: The both ports are only available for keyboard and mouse but not for memory stick.

2.2.2 Memory Stick Port, Internet Access and External Power Sockets

Internet Access Sockets External Power Sockets

Memory Stick Port

2.2.3 SD Card, Headset and Microphone Sockets

3

Microphone Sockets

3. Operation Instructions

3.1 Turn-on

Press and hold the Power button till relevant text message appears on the LCD screen and the Turn-on indicator lights up
simultaneously, indicating that the laptop is on, and then release the power button.

3.2 Turn-off

There are alternatives offered to turn off the laptop:
Alternative I: Hardware off: Press and hold the Power button till the Turnoff image shown below appears and then release the

Power button.

Alternative II: Software off: Click Startup, select Power Off and in the following dialogue box, select Yes to turn off and No to

quit.

3.3 Reset

When the operating system runs into a deadlock, poke the Reset Hole next to the Battery Chamber Cover at the bottom of the
laptop with a pointed object to shut down the system.

4

3.4 Charge

Plug in the external power adapter and the Charge Indicator turns on. When charge is over, the indicator turns off automatically.

3.5 Network Setup

Refer to the “Internet Access Instructions” and set up the network to make sure the laptop is able to access to the internet
normally.

3.6 Website Browse

The precondition for internet website browse is to ensure that the laptop connects to the internet normally via either wire and
wireless internet access devices or ADSL according to the Internet Access Instructions.

Internet Explorer

Double click the Internet Explorer icon on the Desktop to start surfing the internet.

3.7 Instant Communication

3.7.1 MSN

MSN Instant Communication
Double click the Messenger icon on the Desktop to launch the program, click “Click here to log in” and select “Net Messaging
Service” and then press OK. Enter username and password and click OK to log into the MSN interface.

3.8 One Button Internet Access

To enable the said function, you have to set up a shortcut key in compliance with the Section 4.3 “Shortcut Keys Setup”.

3.8.1 Internet Surfing
Press F6 directly to surf the internet.

5

3.9 Office Software

3.9.1 Word

Word Program

Double click the Microsoft Word icon on the Desktop to start editing text.

3.9.2 Excel

Excel Program

Double click the Excel icon on the Desktop to start processing spreadsheet.

3.10 Media Playback

3.10.1 Windows Media Player
Due to its built-in hardware video decoder, the Window Media Player is able to play back video files with large bit-rate faster
