Performer 2000 RGBAL V1
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 33038
MANUAL
ENGLISH
1
Ordercode: 33038
Performer 2000 RGBAL
Table of contents
Warning ............................................................................................................................................................................... 3
Safety Instructions ......................................................................................................................................................... 3
Operating Determinations .......................................................................................................................................... 5
Rigging ............................................................................................................................................................................ 5
Connection with the mains......................................................................................................................................... 6
Return Procedure .......................................................................................................................................................... 7
Claims .............................................................................................................................................................................. 7
Description of the device ................................................................................................................................................. 8
Features .......................................................................................................................................................................... 8
Frontside.......................................................................................................................................................................... 8
Backside ......................................................................................................................................................................... 9
Installation ........................................................................................................................................................................... 9
Set Up and Operation ....................................................................................................................................................... 9
Color Frame Retaining Clip .......................................................................................................................................10
Setting the Angle ........................................................................................................................................................10
Control Modes .............................................................................................................................................................11
One Performer (Stand-alone) ...............................................................................................................................11
Multiple Performers (Master/Slave control) ........................................................................................................11
Multiple Performers (DMX Control) .......................................................................................................................12
Fixture Linking ...............................................................................................................................................................13
Data Cabling ...............................................................................................................................................................13
Control Panel ...............................................................................................................................................................14
Control Mode ..............................................................................................................................................................14
DMX Addressing ..........................................................................................................................................................14
Menu Overview ...........................................................................................................................................................15
Main Menu Options ....................................................................................................................................................16
1. Manual Mode ......................................................................................................................................................16
1.1. Mode 1 ...............................................................................................................................................................17
1.2. Mode 2 ...............................................................................................................................................................17
1.3. Mode 3 ...............................................................................................................................................................17
1.4. Mode 4 ...............................................................................................................................................................18
2. Static ......................................................................................................................................................................18
3. Preset Colors .........................................................................................................................................................19
4. Address ..................................................................................................................................................................19
5. Run Mode ..............................................................................................................................................................20
6. Personality .............................................................................................................................................................20
7. Setting ....................................................................................................................................................................20
7.1. Upload ................................................................................................................................................................21
7.2. Reset ...................................................................................................................................................................21
7.3. Color ...................................................................................................................................................................21
7.4. Dimmer ...............................................................................................................................................................21
7.5. DMX Error ............................................................................................................................................................22
7.6. Performance .....................................................................................................................................................22
7.7. MCON (DMX data transfer) ............................................................................................................................22
7.8. PWM Rate (refresh rate) ..................................................................................................................................23
7.9. Power CCT (correlated color temperature) ...............................................................................................23
8. Key ..........................................................................................................................................................................23
9. Calibration.C ........................................................................................................................................................24
9.1. White ...................................................................................................................................................................24
9.2. RGBtoW ..............................................................................................................................................................24
9.3. Calibration.R (reset) .........................................................................................................................................24
10. Info ........................................................................................................................................................................25
10.1. Version ..............................................................................................................................................................25
10.2. RDM ...................................................................................................................................................................25
2
Ordercode: 33038
Performer 2000 RGBAL
DMX Channels .............................................................................................................................................................25
8 channels (HSIC) .....................................................................................................................................................25
10 channels (SSP) .....................................................................................................................................................26
13 channels (TOUR) .................................................................................................................................................27
19 channels (TR16) ...................................................................................................................................................29
Cleaning ............................................................................................................................................................................31
Cleaning the Glass Lens ............................................................................................................................................31
Maintenance ....................................................................................................................................................................32
Replacing the Fuse .....................................................................................................................................................32
Troubleshooting ...............................................................................................................................................................32
No Light .........................................................................................................................................................................32
No Response to DMX..................................................................................................................................................33
Product Specifications ....................................................................................................................................................34
Dimensions ........................................................................................................................................................................35
Notes ..................................................................................................................................................................................36
3
Ordercode: 33038
Performer 2000 RGBAL
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
● Showtec Performer 2000 RGBAL
● Pro power cable (1,5 m)
● 1 x safety cable
● User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
● be qualified
● follow the instructions of this manual
4
Ordercode: 33038
Performer 2000 RGBAL
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
● Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
● Never remove warning or informative labels from the unit.
● Never use anything to cover the ground contact.
● Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
● Never place any material over the lens.
● Never look directly into the light source.
● Never leave any cables lying around.
● Do not insert objects into air vents.
● Do not connect this device to a dimmer pack.
● Do not switch the device on and off in short intervals, as this will reduce the device’s life.
● Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
● Do not shake the device. Avoid brute force when installing or operating the device.
● Only use the device indoors, avoid contact with water or other liquids.
● Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
● Only operate the device after having familiarized with its functions.
● Avoid flames and do not put close to flammable liquids or gases.
● Always keep the case closed while operating.
● Always allow a free air space of at least 50 cm around the unit for ventilation.
● Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
● Make sure that the device is not exposed to extreme heat, moisture or dust.
● Make sure that the available voltage is not higher than stated on the rear panel.
● Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
● If the lens is obviously damaged, it has to be replaced.
● If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
● If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
● For adult use only. Never leave the unit running unattended.
● Never attempt to bypass the thermostatic switch or fuses.
● For replacement use fuses of same type and rating only.
● The user is responsible for correct positioning and operating of the Performer. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
● This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
● Repairs, servicing and electric connection must be carried out by a qualified technician.
● WARRANTY: Till one year after date of purchase.
5
Ordercode: 33038
Performer 2000 RGBAL
Operating Determinations
● This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
● The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
● To eliminate wear and improve lifespan, during periods of non-use, completely disconnect from
power via breaker or by unplugging.
● The maximum ambient temperature t
a
= 40°C must never be exceeded.
● The relative humidity must not exceed 50 % with an ambient temperature of 40°C.
● If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
● Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
● If the Performer is lowered from the ceiling or high joists, professional trussing systems have to be used.
● Use a clamp to mount the Performer, with the mounting bracket, to the trussing system.
● The Performer must never be fixed swinging freely in the room.
● The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
● When rigging, derigging or servicing the Performer, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
Improper installation can cause serious injuries and/or damage of property!
6
Ordercode: 33038
Performer 2000 RGBAL
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
7
Ordercode: 33038
Performer 2000 RGBAL
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any shortcomings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.
8
Ordercode: 33038
Performer 2000 RGBAL
Description of the device
Features
The Showtec Performer 2000 RGBAL is a theater spotlight with high output and great effects.
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 230W
Light source: 1 x 240W LED Array 5-in-1
Drive current: 1,5A
Refresh rate: 600Hz to 25kHz
Light output: 55000 Lux @1m (15º zoom)
Max flux: 5300 Lumen
Peak intensity: 41900 cd
Color rendering: >90Ra (2700-4500K), >85Ra (5600-8000K)
Color temperature: 2700-8000K
Dimmer: 0-100%
Dimming curves: Dimm4 technology, 4 presets
Dimmer resolution: 16bit
Strobe: 0-25Hz
Control protocol: RDM, DMX-512
DMX channels: 8, 10, 13, 19 channels
Motorized zoom: 15-45º
Field angle: 25-76º
Control modes: Stand-alone, Master/Slave, DMX-512/RDM
Connections: 3-pin/5-pin XLR signal connectors IN/OUT, Pro power connectors Blue IN/Gray OUT
Housing: Extruded aluminum & flame retardant plastic
Color: Black
Cooling: Internal fan
IP rating: IP20
Fuse: T6,3AL/250V
Dimensions: 455 x 285 x 435 mm (LxWxH)
Weight: 7,5 kg
Optional accessories
33041 – Barndoor Performer 2000
33042 – Filter Frame Performer 2000
Frontside
Fig. 01
01) Mounting bracket
02) Adjustment screw
03) Color frame retaining clip
04) Lens
9
Ordercode: 33038
Performer 2000 RGBAL
Backside
Fig. 02
05) 100-240V Pro power connector Blue IN
06) 3-pin DMX signal connector IN
07) 5-pin DMX signal connector IN
08) 3-pin DMX signal connector OUT
09) 5-pin DMX signal connector OUT
10) 100-240V Pro power connector Gray OUT
11) Fuse T6,3AL/250V
12) LCD display + control buttons
Installation
Remove all packing materials from the Performer 2000 RGBAL. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
10
Ordercode: 33038
Performer 2000 RGBAL
Color Frame Retaining Clip
The color frame holder is equipped with a spring-loaded retaining clip. This prevents color frames and
accessories from falling out.
Make sure that all color frame accessories are locked in position with the retaining clip
before hanging the Performer 2000 RGBAL.
01) Release the retaining clip by pressing the lock towards the lens and pressing the longer side of the
screw. The retaining clip will open.
02) Insert the color frame(s).
03) Lock the retaining clip by pressing the retaining clip towards the lens.
Fig. 03
Setting the Angle
01) Loosen the adjustment screw (do not remove it).
02) Tilt the fixture to the desired position.
03) Tighten the adjustment screw to secure the fixture in position.
Fig. 04
11
Ordercode: 33038
Performer 2000 RGBAL
Control Modes
There are 3 modes:
• Stand-alone
• Master/Slave
• RDM/DMX-512 (8CH, 10CH, 13CH, 19CH)
One Performer (Stand-alone)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Performer is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 16-25 for more information.
Multiple Performers (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin/5-pin XLR cable to connect the Performer.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 16-25. This means that
you can set your desired operation mode on the master device and all slave devices will react the
same as the master device.
Multiple Performers (Master/Slave control)
Fig. 05
12
Ordercode: 33038
Performer 2000 RGBAL
Multiple Performers (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Performers and other devices.
04) Link the units as shown in fig. 06. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Pro power socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Performers DMX Set Up
Fig. 06
Note : Link all cables before connecting electric power
13
Ordercode: 33038
Performer 2000 RGBAL
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a power link @110V: 4 fixtures
Maximum recommended number of fixtures on a power link @230V: 8 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
● DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
● DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
● DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
● DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
● DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
14
Ordercode: 33038
Performer 2000 RGBAL
The Performer 2000 RGBAL can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) MENU button
B) ENTER button
C) LCD display
D) DOWN button
E) UP button
F) Control 1
G) Control 2
H) Control 3
Fig. 07
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Performer will respond to the controller.
Please note, when you use the controller, the unit has 19 channels.
When using multiple Performers, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Performer should be 1(001); the DMX address of the second
Performer should be 1+19=20 (020); the DMX address of the third Performer should be 20+19=39 (039),
etc. Please, be sure that you do not have any overlapping channels in order to control each Performer
correctly. If two or more Performers are addressed similarly, they will work similarly.
Controlling:
After having addressed all Performer fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Performer will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the “LED“ on the control panel will not flash.
If not, the problem may be:
● The XLR cable from the controller is not connected with the input of the Performer 2000 RGBAL.
● The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MENU, UP, DOWN or ENTER button. Once you have pressed
the button, the display will light up.
15
Ordercode: 33038
Performer 2000 RGBAL
Menu Overview
16
Ordercode: 33038
Performer 2000 RGBAL
Main Menu Options
01) On start-up, the display will show information about the device’s current status:
02) Press the ENTER button to open the main menu.
03) Press the UP/DOWN buttons to toggle through the 10 main menu options:
04) Press the ENTER button to open the desired submenu.
1. Manual Mode
In this menu you can set and adjust the desired manual mode.
01) While in main menu, press the UP/DOWN buttons until the display shows MANUAL MODE.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to select the desired manual mode (1-4).
04) Press the ENTER button to activate the previously chosen mode.
17
Ordercode: 33038
Performer 2000 RGBAL
1.1. Mode 1
In this menu you can set the dimmer, zoom and CCT.
01) Turn the controls (F/G/H) to adjust settings.
02) The adjustment ranges are:
(F)
Dimmer: 0-100% (from dark to brightest)
(G)
Zoom: 0-100% (from small to big)
(H)
CCT: 2700K, 3000K, 3200K, 3500K, 4000K, 4200K, 4500K, 5600K, 6000K, 6500K, 7200K, 8000K
1.2. Mode 2
In this menu you can set the dimmer, zoom and choose a color preset.
01) Turn the controls (F/G/H) to adjust settings.
02) The adjustment ranges are:
(F)
Dimmer: 0-100% (from dark to brightest)
(G)
Zoom: 0-100% (from small to big)
(H)
Color presets: L106, R05, L194, R54, L019, R08, R89, R86, L213, R377, R80, L202, L328, R3314,
L101, L768
1.3. Mode 3
In this menu you can set the hue, saturation and intensity.
01) Turn the controls (F/G/H) to adjust settings.
02) The adjustment ranges are:
(F)
Hue: 0-100%
(G)
Saturation: 0-100%
(H)
Intensity: 0-100% (from dark to brightest)
18
Ordercode: 33038
Performer 2000 RGBAL
1.4. Mode 4
In this menu you can set the dimmer, CCT and green.
01) Turn the controls (F/G/H) to adjust settings.
02) The adjustment ranges are:
(F)
Dimmer: 0-100% (from dark to brightest)
(G)
CCT: 2700K, 3000K, 3200K, 3500K, 4000K, 4200K, 4500K, 5600K, 6000K, 6500K, 7200K, 8000K
(H)
Green: -10 to +10
2. Static
In this menu you can manually set the colors, zoom and the strobe.
01) While in main menu, press the UP/DOWN buttons until the display shows STATIC.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle through the 7 options:
RED (0-255, from dark to brightest)
GREEN (0-255, from dark to brightest)
BLUE (0-255, from dark to brightest)
AMBER (0-255, from dark to brightest)
LIME (0-255, from dark to brightest)
ZOOM (0-255, from small to big)
STROBE (0-25, from low to high strobe frequency)
04) Press the ENTER button to open the desired option.
05) Press the UP/DOWN buttons to adjust settings.
06) Repeatedly press the ENTER button to toggle through the other available options and repeat step 5.
07) You can combine RED, GREEN, BLUE, AMBER and LIME to create an infinite range of colors (0-255).
19
Ordercode: 33038
Performer 2000 RGBAL
3. Preset Colors
In this menu you can choose the desired color preset.
01) While in main menu, press the UP/DOWN buttons until the display shows PRESET COLOR.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle through the 16 color presets: L106, R05, L194, R54, L019, R08,
R89, R86, L213, R377, R80, L202, L328, R3314, L101, L768.
4. Address
In this menu you can set the desired DMX starting address.
01) While in main menu, press the UP/DOWN buttons until the display shows ADDRESS.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to set the desired DMX starting address. The adjustment range is
between 001-512.
20
Ordercode: 33038
Performer 2000 RGBAL
5. Run Mode
In this menu you can set the device as a master or slave.
01) While in main menu, press the UP/DOWN buttons until the display shows RUN MODE.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the 2 options: DMX and SLAVE.
04) If the display shows DMX, the Performer will become a master device and will utilize the DMX
protocol to determine its performance.
05) If the display shows SLAVE, the Performer will become a slave device and will react the same as the
master device.
6. Personality
In this menu you can set the desired DMX channel mode (personality).
01) While in main menu, press the UP/DOWN buttons until the display shows PERSONALITY.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle through the 4 channel modes:
HSIC
8-channel mode
SSP
10-channel mode
TOUR
13-channel mode
TR16
19-channel mode
7. Setting
In this menu you can adjust the device’s special settings.
01) While in main menu, press the UP/DOWN buttons until the display shows SETTING.
02) Press the ENTER button to open the menu.
03) The display will show PASS CODE and you will need to insert a key combination which will unlock this
hidden menu. To do so, press the buttons in the following order: UP, DOWN, UP, DOWN, ENTER.
04) Press the UP/DOWN buttons to toggle through the following options:
UPLOAD
RESET
COLOR
DIMMER
DMX ERROR
PERFORMANCE
MCON
PWM_RATE
POWER_CCT
21
Ordercode: 33038
Performer 2000 RGBAL
7.1. Upload
In this menu you can send the custom programs to the slave devices.
01) When the display shows UPLOAD, press the ENTER button to open the menu.
02) The display will show PASS CODE and you will need to insert a key combination which will unlock this
hidden menu. To do so, press the buttons in the following order: UP, DOWN, UP, DOWN, ENTER.
03) While exporting, the slave devices will light in yellow.
04) If there are any problems with exporting, the master and the slave devices will light in red.
05) If the operation was completed successfully, the master and the slave devices will light in green.
7.2. Reset
In this menu you can reset the settings.
01) When the display shows RESET, press the ENTER button to open the menu.
02) The display will show PASS CODE and you will need to insert a key combination which will unlock this
hidden menu. To do so, press the buttons in the following order: UP, DOWN, UP, DOWN, ENTER.
03) The device will now reset its settings.
7.3. Color
In this menu you can set the color mixing.
01) When the display shows COLOR, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose one of the 3 color mixing options:
UC: The RGB output is adjusted to a standard preset universal color. In this way, different
Performer versions are color-balanced, in order to match each other.
RGBtoW: RGB = 255, 255, 255. The displayed color is the specific color which you have calibrated
in Calibration menu (see page 24).
OFF: The RGB settings are: 255, 255, 255. The RGB values are not adjusted and the output is the
most powerful.
7.4. Dimmer
In this menu you can set the dimmer speed.
01) When the display shows DIMMER, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle through the 5 options:
OFF: Dimmer speed is off
DIM1-DIM4: Dimmer speed, from fast to slow
22
Ordercode: 33038
Performer 2000 RGBAL
7.5. DMX Error
In this menu you can determine what the device will do in case of a DMX signal error.
01) When the display shows DMX ERROR, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options: SAVE and BLACK.
03) If the display shows SAVE, the Performer will utilize the last working DMX signal, which will ensure
undisrupted performance.
04) If the display shows BLACK, the Performer will black out.
7.6. Performance
In this menu you can set the performance of the cooling fan.
01) When the display shows PERFORMANCE, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle through the 3 modes:
LIVE: Default mode. It provides a compromise between output quality and noise level.
STUDIO: Noise level-oriented mode. It emits little noise and operates at moderate power level.
POWER: Output-oriented mode. The device does not offer any consideration for noise level and
operates at full power.
7.7. MCON (DMX data transfer)
In this menu you can set the DMX data transfer settings.
01) When the display shows MCON, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options:
SELF: DMX data transfer OFF
MASTER: DMX data transfer ON
23
Ordercode: 33038
Performer 2000 RGBAL
7.8. PWM Rate (refresh rate)
In this menu you can set the refresh rate.
01) When the display shows PWM_RATE, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle through the 6 options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz,
25000Hz.
7.9. Power CCT (correlated color temperature)
In this menu you can set the correlated color temperature.
01) When the display shows POWER_CCT, press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle through the 5 options: 3200K, 4200K, 5600K, 10000K, NORMAL.
8. Key
In this menu you can set the safety lock.
01) While in main menu, press the UP/DOWN buttons until the display shows KEY.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between ON and OFF to activate/deactivate the safety lock.
04) When set to ON, you will need to insert the safety key combination every time the display turns off.
05) When set to OFF, the Settings menu will not get locked, providing that it was active when the display
turned off. Otherwise, you will need to insert the key combination anyway.
24
Ordercode: 33038
Performer 2000 RGBAL
9. Calibration.C
In this menu you can set the color calibration.
01) While in main menu, press the UP/DOWN buttons until the display shows CALIBRATION.C.
02) Press the ENTER button to open the menu.
03) The display will show PASS CODE and you will need to insert a key combination which will unlock this
hidden menu. To do so, press the buttons in the following order: UP, DOWN, UP, DOWN, ENTER.
04) Press the UP/DOWN buttons to choose one of the 3 options:
WHITE
RGBtoW
CALIBRATION.R
05) Press the ENTER button to open the desired menu.
9.1. White
01) Press the UP/DOWN buttons to choose one of the 13 white color presets (2700K-10000K).
02) Press the ENTER button to open the submenu.
03) Press the UP/DOWN buttons to toggle through RED, GREEN, BLUE, AMBER and LIME.
04) Press the ENTER button to choose the desired color.
05) Press the UP/DOWN buttons to increase/decrease the intensity of the chosen color. The adjustment
range of each color is between 0-255, from OFF to FULL ON.
06) Repeatedly press the ENTER button to proceed to the other colors and repeat step 5.
9.2. RGBtoW
01) Press the UP/DOWN buttons to choose one of the 3 colors: RED, GREEN, BLUE.
02) Press the ENTER button to choose the desired color.
03) Press the UP/DOWN buttons to increase/decrease the intensity of the chosen color. The adjustment
range of each color is between 0-255, from OFF to FULL ON.
04) Repeatedly press the ENTER button to proceed to the other colors and repeat step 3.
9.3. Calibration.R (reset)
01) Press the ENTER button to open the menu.
02) The display will show PASS CODE and you will need to insert a key combination which will unlock this
hidden menu. To do so, press the buttons in the following order: UP, DOWN, UP, DOWN, ENTER.
03) The calibration settings will now be reset. The display will show OK!.
25
Ordercode: 33038
Performer 2000 RGBAL
10. Info
In this menu you can view the device’s status.
01) While in main menu, press the UP/DOWN buttons until the display shows INFO.
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the 2 options: VERSION and RDM.
04) Press the ENTER button to open the menu.
10.1. Version
The display will show the current software version.
10.2. RDM
01) Press the UP/DOWN buttons to toggle between UID and LABEL.
02) Press the ENTER button to view the desired RDM menu.
DMX Channels
8 channels (HSIC)
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Hue (color variations) CH1 must be open
0-255
Gradual adjustment hue, from 0-100%
Channel 3 – Hue fine (color variations) CH1-2 must be open
0-255
Fine adjustment hue, from 0-100%
Channel 4 – Red color saturation CH1 must be open
0-255
Saturation adjustment, from 0-100%
Channel 5 – CCT CH1 must be open
0-10
Not functional
11-30
2700K
31-50
3000K
51-70
3200K
71-90
3500K
91-110
4000K
111-130
4200K
131-150
4500K
151-170
5600K
171-190
6000K
191-210
6500K
26
Ordercode: 33038
Performer 2000 RGBAL
211-230
7200K
231-255
8000K
Channel 6 –Strobe CH1-4 must be open
0-9
Not functional
10-99
Strobe flash frequency, from low to high frequency
100-109
Not functional
110-179
Pulse strobe, from low to high frequency
180-189
Not functional
190-255
Random strobe, from low to high frequency
Channel 7 – Zoom
0-255
Gradual adjustment zoom, from small to big
Channel 8 – Dimmer speed
0-9
Preset dimmer speed from the device’s menu
10-29
Linear dimmer
30-69
Non-linear dimmer 1 (fastest)
70-129
Non-linear dimmer 2
130-189
Non-linear dimmer 3
190-255
Non-linear dimmer 4 (slowest)
10 channels (SSP)
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Red CH1 must be open, CH7 must be closed
0-255
Gradual adjustment Red, from 0-100%
Channel 3 – Green CH1 must be open, CH7 must be closed
0-255
Gradual adjustment Green, from 0-100%
Channel 4 – Blue CH1 must be open, CH7 must be closed
0-255
Gradual adjustment Blue, from 0-100%
Channel 5 – Amber CH1 must be open, CH7 must be closed
0-255
Gradual adjustment Amber, from 0-100%
Channel 6 – Lime CH1 must be open, CH7 must be closed
0-255
Gradual adjustment Lime, from 0-100%
Channel 7 – Color presets CH1 must be open
0-10
Not functional
11-20
L106
21-30
R05
31-40
L194
41-50
R54
51-60
L019
61-70
R08
71-80
R89
81-90
R86
91-100
L213
27
Ordercode: 33038
Performer 2000 RGBAL
101-110
R377
111-120
R80
121-130
L202
131-140
L328
141-150
R3314
151-160
L101
161-170
L768
171-255
Not functional
Channel 8 –Strobe CH1 must be open; CH2-6 or CH7 must be open
0-9
Not functional
10-99
Strobe flash frequency, from low to high frequency
100-109
Not functional
110-179
Pulse strobe, from low to high frequency
180-189
Not functional
190-255
Random strobe, from low to high frequency
Channel 9 – Zoom
0-255
Gradual adjustment zoom, from small to big
Channel 10 – Dimmer speed
0-9
Preset dimmer speed from the device’s menu
10-29
Linear dimmer
30-69
Non-linear dimmer 1 (fastest)
70-129
Non-linear dimmer 2
130-189
Non-linear dimmer 3
190-255
Non-linear dimmer 4 (slowest)
13 channels (TOUR)
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Red CH1 must be open; CH7-8 must be closed
0-255
Gradual adjustment Red, from 0-100%
Channel 3 – Green CH1 must be open; CH7-8 must be closed
0-255
Gradual adjustment Green, from 0-100%
Channel 4 – Blue CH1 must be open; CH7-8 must be closed
0-255
Gradual adjustment Blue, from 0-100%
Channel 5 – Amber CH1 must be open; CH7-8 must be closed
0-255
Gradual adjustment Amber, from 0-100%
Channel 6 – Lime CH1 must be open; CH7-8 must be closed
0-255
Gradual adjustment Lime, from 0-100%
Channel 7 – Color presets CH1 must be open
0-10
Not functional
11-20
L106
21-30
R05
31-40
L194
28
Ordercode: 33038
Performer 2000 RGBAL
41-50
R54
51-60
L019
61-70
R08
71-80
R89
81-90
R86
91-100
L213
101-110
R377
111-120
R80
121-130
L202
131-140
L328
141-150
R3314
151-160
L101
161-170
L768
171-255
Not functional
Channel 8 – Macros CH1 must be open
0-10
Not functional
11-30
Red 100% / Green Up / Blue 0%
31-50
Red Down / Green 100% / Blue 0%
51-70
Red 0% / Green 100% / Blue Up
71-90
Red 0% / Green Down / Blue 100%
91-110
Red Up / Green 0% / Blue 100%
111-130
Red 100% / Green 0% / Blue Down
131-150
Red 100% / Green Up / Blue Up
151-170
Red Down / Green Down / Blue 100%
171-195
Red 100% / Green 100% / Blue 100% / White 100%
196-200
2700K
201-205
3000K
206-210
3200K
211-215
3500K
216-220
4000K
221-225
4200K
226-230
4500K
231-235
5600K
236-240
6000K
241-245
6500K
246-250
7200K
251-255
8000K
Channel 9 –Strobe CH1 must be open; CH2-6 or CH7-8 must be open
0-9
Not functional
10-99
Strobe flash frequency, from low to high frequency
100-109
Not functional
110-179
Pulse strobe, from low to high frequency
180-189
Not functional
190-255
Random strobe, from low to high frequency
Channel 10 – Zoom
0-255
Gradual adjustment zoom, from small to big
Channel 11 – Built-in programs
0-40
Not functional
41-60
Auto 1
61-80
Auto 2
81-100
Auto 3
101-120
Auto 4
29
Ordercode: 33038
Performer 2000 RGBAL
121-140
Auto 5
141-160
Auto 6
161-180
Auto 7
181-200
Auto 8
201-220
Auto 9
221-255
Auto 10
Channel 12 – Program speed CH11 must be set between 41-255
0-255
Program speed adjustment, from slow to fast
Channel 13 – Dimmer speed
0-9
Preset dimmer speed from the device’s menu
10-29
Linear dimmer
30-69
Non-linear dimmer 1 (fastest)
70-129
Non-linear dimmer 2
130-189
Non-linear dimmer 3
190-255
Non-linear dimmer 4 (slowest)
19 channels (TR16)
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Fine dimmer CH1 must be open; CH13-14 must be closed
0-255
Fine dimmer adjustment, from dark to brightest 0-100%
Channel 3 – Red CH1 must be open; CH13-14 must be closed
0-255
Gradual adjustment Red, from 0-100%
Channel 4 – Fine Red CH1 and CH3 must be open; CH13-14 must be closed
0-255
Fine adjustment Red, from 0-100%
Channel 5 – Green CH1 must be open; CH13-14 must be closed
0-255
Gradual adjustment Green, from 0-100%
Channel 6 – Fine Green CH1 and CH5 must be open; CH13-14 must be closed
0-255
Fine adjustment Green, from 0-100%
Channel 7 – Blue CH1 must be open; CH13-14 must be closed
0-255
Gradual adjustment Blue, from 0-100%
Channel 8 – Fine Blue CH1 and CH7 must be open; CH13-14 must be closed
0-255
Fine adjustment Blue, from 0-100%
Channel 9 – Amber CH1 must be open; CH13-14 must be closed
0-255
Gradual adjustment Amber, from 0-100%
Channel 10 – Fine Amber CH1 and CH9 must be open; CH13-14 must be closed
0-255
Fine adjustment Amber, from 0-100%
30
Ordercode: 33038
Performer 2000 RGBAL
Channel 11 – Lime CH1 must be open; CH13-14 must be closed
0-255
Gradual adjustment Lime, from 0-100%
Channel 12 – Fine Lime CH1 and CH11 must be open; CH13-14 must be closed
0-255
Fine adjustment Lime, from 0-100%
Channel 13 – Color presets CH1 must be open
0-10
Not functional
11-20
L106
21-30
R05
31-40
L194
41-50
R54
51-60
L019
61-70
R08
71-80
R89
81-90
R86
91-100
L213
101-110
R377
111-120
R80
121-130
L202
131-140
L328
141-150
R3314
151-160
L101
161-170
L768
171-255
Not functional
Channel 14 – Macros CH1 must be open
0-10
Not functional
11-30
Red 100% / Green Up / Blue 0%
31-50
Red Down / Green 100% / Blue 0%
51-70
Red 0% / Green 100% / Blue Up
71-90
Red 0% / Green Down / Blue 100%
91-110
Red Up / Green 0% / Blue 100%
111-130
Red 100% / Green 0% / Blue Down
131-150
Red 100% / Green Up / Blue Up
151-170
Red Down / Green Down / Blue 100%
171-195
Red 100% / Green 100% / Blue 100% / White 100%
196-200
2700K
201-205
3000K
206-210
3200K
211-215
3500K
216-220
4000K
221-225
4200K
226-230
4500K
231-235
5600K
236-240
6000K
241-245
6500K
246-250
7200K
251-255
8000K
31
Ordercode: 33038
Performer 2000 RGBAL
Channel 15 –Strobe CH1 must be open; CH2-12 or CH13-14 must be open
0-9
Not functional
10-99
Strobe flash frequency, from low to high frequency
100-109
Not functional
110-179
Pulse strobe, from low to high frequency
180-189
Not functional
190-255
Random strobe, from low to high frequency
Channel 16 – Zoom
0-255
Gradual adjustment zoom, from small to big
Channel 17 – Built-in programs
0-40
Not functional
41-60
Auto 1
61-80
Auto 2
81-100
Auto 3
101-120
Auto 4
121-140
Auto 5
141-160
Auto 6
161-180
Auto 7
181-200
Auto 8
201-220
Auto 9
221-255
Auto 10
Channel 18 – Program speed CH17 must be set between 41-255
0-255
Program speed adjustment, from slow to fast
Channel 19 – Dimmer speed
0-9
Preset dimmer speed from the device’s menu
10-29
Linear dimmer
30-69
Non-linear dimmer 1 (fastest)
70-129
Non-linear dimmer 2
130-189
Non-linear dimmer 3
190-255
Non-linear dimmer 4 (slowest)
Cleaning
Please follow the next recommendations when cleaning and inspecting lenses and reflectors:
Do not use glass or window type cleaners on lenses (glass or polymer) or reflectors.
Do not use abrasive materials such as steel wool.
Replace lenses if they contain visible damage (cracks or deep scratches) which that may impair their
effectiveness.
Cleaning the Glass Lens
01) Remove the front cap.
02) Dampen a clean lint-free cloth with vinegar or household ammonia. You may also use water, but it
will leave spots that can be removed by gently polishing the front lens with a clean and dry cloth.
03) Starting from the center, gently wipe the lens.
04) Re-attach the front cap.
32
Ordercode: 33038
Performer 2000 RGBAL
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The Performer 2000 RGBAL requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light
output very quickly.
Please clean internal components once a year with a light brush and vacuum cleaner.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the
fuse burns out, the product will not function whatsoever. If this happens, follow the directions below:
01) Unplug the unit from electric power source.
02) Insert a flat-head screwdriver into a slot in the fuse cover. Turn the screwdriver to the left, at the same
time gently push a bit (Turn and Push). The fuse will come out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover. Be sure to
use a fuse of the same type and specification. See the product specification label for details.
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
No Light
If the light effect does not operate properly, refer servicing to a technician.
Suspect three potential problem areas as: the power supply, the LEDs, the fuse.
01) Power supply. Check if the unit is plugged into an appropriate power supply.
02) The LEDs. Return the Performer to your Showtec dealer.
03) The fuse. Replace the fuse. See page 32 for replacing the fuse.
04) If all of the above appears to be O.K., plug the unit in again.
05) If you are unable to determine the cause of the problem, do not open the Performer, as this may
damage the unit and the warranty will become void.
06) Return the device to your Showtec dealer.
33
Ordercode: 33038
Performer 2000 RGBAL
No Response to DMX
Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem
Probable cause(s)
Solution
One or more
fixtures do not
function at all
No power to the fixture
• Check if power is switched on and
cables are plugged in
Primary fuse blown
• Replace fuse
Fixtures reset
correctly, but all
respond
erratically or not
at all to the
controller
The controller is not connected.
• Connect controller
3-pin/5-pin XLR Out of the
controller does not match XLR Out
of the first fixture on the link (i.e.
signal is reversed)
• Install a phase reversing cable
between the controller and the
first fixture on the link
Fixtures reset
correctly, but
some respond
erratically or not
at all to the
controller
Poor data quality
• Check data quality. If much lower
than 100 percent, the problem
may be a bad data link
connection, poor quality or
broken cables, missing termination
plug, or a defective fixture
disturbing the link
Bad data link connection
• Inspect connections and cables.
Correct poor connections. Repair
or replace damaged cables
Data link not terminated with 120
Ohm termination plug
• Insert termination plug in output
jack of the last fixture on the link
Incorrect addressing of the fixtures
• Check address setting
One of the fixtures is defective and
disturbs data transmission on the
link
• Bypass one fixture at a time until
normal operation is restored:
unplug both connectors and
connect them directly together.
• Have the defective fixture
serviced by a qualified technician
3-pin/5-pin XLR Out on the fixtures
does not match (pins 2 and 3
reversed)
• Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture that behaves
erratically
No light or LEDs
cut out
intermittently
Fixture is too hot
• Allow the fixture to cool down
• Clean the fan
• Make sure air vents in control
panel and the front lens are not
blocked
• Turn up the air conditioning
LEDs damaged
• Disconnect the fixture and return it
to your dealer
The power supply settings do not
match local AC voltage and
frequency
• Disconnect fixture. Check settings
and correct if necessary
34
Ordercode: 33038
Performer 2000 RGBAL
Product Specifications
Model:
Showtec Performer 2000 RGBAL
Input voltage:
100-240V AC, 50/60Hz
Power consumption:
230W (full output)
DMX linking:
30pcs
Fuse:
T6,3AL/250V
Dimensions:
455 x 285 x 435 mm (LxWxH)
Weight:
7,5 kg
Operating and Programming:
Signal pin OUT:
Pin 1 (earth), pin 2 (-), pin 3 (+)
DMX Mode:
8, 10, 13, 19 channels
Signal input:
3-pin/5-pin XLR IN
Signal output:
3-pin/5-pin XLR OUT
Electro-mechanical effects:
Light source:
1 x 240W LED Array 5-in-1
Light output:
55000 Lux @1m (15º zoom)
Max flux:
5300 Lumen
Drive current:
1,5A
Motorized zoom:
15-45º
Field angle:
25-76º
Dimmer:
0-100%
Dimming curves:
Dimm4 technology, 4 presets
Dimmer resolution:
16bit
Strobe:
0-25Hz
Peak intensity:
41900cd
Color rendering:
>90Ra (2700-4500K), >85Ra (5600-8000K)
Color temperature:
2700-8000K
Refresh rate:
600Hz to 25kHz
Housing:
Extruded aluminum & flame retardant plastic
Color:
Black
Control protocol:
RDM, DMX-512
DMX control:
via standard DMX controller
Onboard:
LCD display for easy setup
Control:
Stand-alone, Master/Slave, DMX-512/RDM
Connections:
Pro power IN/OUT & dedicated data connector
IP rating:
IP20
Cooling:
Internal fan
Max. ambient temperature ta:
40°C
Max. housing temperature tB:
65°C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
1 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: service@highlite.nl
35
Ordercode: 33038
Performer 2000 RGBAL
Dimensions
36
Ordercode: 33038
Performer 2000 RGBAL
Notes
37
Ordercode: 33038
Performer 2000 RGBAL
38
Ordercode: 33038
Performer 2000 RGBAL
©2017 Showtec
Loading...
