SHOWTEC Node-1 User Manual

Node-1 V1

Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Ordercode: 50802

MANUAL

ENGLISH

Ordercode: 50802

Node-1

Table of contents

Warning ............................................................................................................................................................................... 2

Safety Instructions ......................................................................................................................................................... 2

Operating Determinations .......................................................................................................................................... 3

Return Procedure .......................................................................................................................................................... 4

Claims .............................................................................................................................................................................. 4

Description of the device ................................................................................................................................................. 5

Frontside.......................................................................................................................................................................... 5

Backside ......................................................................................................................................................................... 5

Installation ........................................................................................................................................................................... 6

Set Up and Operation ....................................................................................................................................................... 6

Start-up............................................................................................................................................................................ 6

Connections .................................................................................................................................................................. 7

Data Cabling ................................................................................................................................................................. 9

Maintenance ...................................................................................................................................................................... 9

Troubleshooting ................................................................................................................................................................. 9

No Light ........................................................................................................................................................................... 9

No Response to DMX..................................................................................................................................................10

Product Specifications ....................................................................................................................................................11

Dimensions ........................................................................................................................................................................11

Notes ..................................................................................................................................................................................12

1

Ordercode: 50802

Node-1

Your shipment includes:

 Showtec Node-1 DMX-ArtNet 2 way converter
 Cat cable
 Power adapter 5V-500mA

 User manual

 be qualified

 follow the instructions of this manual

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Safety Instructions

Every person involved with the installation, operation and maintenance of this device has to:

Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.

Please consider that damages caused by manual modifications to the device are not subject to
warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

2

Ordercode: 50802

Node-1

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.

• Never let the power cord come into contact with other cables! Handle the power cord and all

connections with the mains with particular caution!

• Never remove warning or informative labels from the unit.

• Never use anything to cover the ground contact.

• Never leave any cables lying around.

• Do not connect this device to a dimmerpack.

• Do not switch the device on and off in short intervals, as this will reduce the device’s life.

• Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).

Allow the fixture to cool for at least 5 minutes before handling.

• Do not shake the device. Avoid brute force when installing or operating the device.

• Only use the device indoors, avoid contact with water or other liquids.

• Only operate the device after having familiarized with its functions.

• Avoid flames and do not put close to flammable liquids or gases.

• Always keep the case closed while operating.

• Always disconnect power from the mains, when device is not used or before cleaning! Only handle

the power cord holding it by the plug. Never pull out the plug by tugging the power cord.

• Make sure that the device is not exposed to extreme heat, moisture or dust.

• Make sure that the available voltage is not higher than stated on the rear panel.

• Make sure that the power cord is never crimped or damaged. Check the device and the power

cord from time to time.

• If device was dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

• If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.

• If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

• For adult use only. The device must be installed beyond the reach of children. Never leave the unit

running unattended.

• Never attempt to bypass the thermostatic switch or fuses.

• For replacement use fuses of same type and rating only.

• The user is responsible for correct positioning and operating of the Node-1. The manufacturer will not

accept liability for damages caused by the misuse or incorrect installation of this device.

• This device falls under protection class I. Therefore it is essential to connect the yellow/green

conductor to earth.

• Repairs, servicing and electric connection must be carried out by a qualified technician.

• WARRANTY: Till one year after date of purchase.

Operating Determinations

• This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

• The maximum ambient temperature t

• The relative humidity must not exceed 50 % with an ambient temperature of 35° C.

• If this device is operated in any other way than the one described in this manual, the product may

suffer damages and the warranty becomes void.

• Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.

= 35°C must never be exceeded.

a

You endanger your own safety and the safety of others!

3

Ordercode: 50802

Node-1

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the

customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace

product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:

01) Your name

02) Your address

03) Your phone number

04) A brief description of the symptoms

Claims

The client has the obligation to check the delivered goods immediately upon delivery for any short­comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.
