SHOWTEC Digital Flex Strip RGB User Manual

Digital Flex Strip RGB V1

Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Ordercode: 42773

MANUAL

ENGLISH

Ordercode: 42773

Digital Flex Strip RGB

Table of contents

Warning ............................................................................................................................................................................... 2

Safety Instructions ......................................................................................................................................................... 2

Operating Determinations .......................................................................................................................................... 4

Connection with the mains......................................................................................................................................... 4

Return Procedure .......................................................................................................................................................... 5

Claims .............................................................................................................................................................................. 5

Description of the device ................................................................................................................................................. 6

Features .......................................................................................................................................................................... 6

Overview ........................................................................................................................................................................ 6

Installation ........................................................................................................................................................................... 7

Set Up and Operation ....................................................................................................................................................... 8

Remote Control ............................................................................................................................................................. 8

Power Switch ON/OFF ............................................................................................................................................... 8

Cold/Warm White ...................................................................................................................................................... 8

IC Settings .................................................................................................................................................................... 9

Color Modes ............................................................................................................................................................... 9

LED Effects ................................................................................................................................................................... 9

Auto ............................................................................................................................................................................10

Flash ............................................................................................................................................................................10

Jump ..........................................................................................................................................................................10

Meteor .......................................................................................................................................................................10

Maintenance ....................................................................................................................................................................11

Troubleshooting ...............................................................................................................................................................11

No Light .........................................................................................................................................................................11

Product Specifications ....................................................................................................................................................12

Notes ..................................................................................................................................................................................13

1

Ordercode: 42773

Digital Flex Strip RGB

Your shipment includes:

 Showtec Digital Flex Strip RGB
 RGBW controller
 IR remote control
 12V DC power adapter with power cable (1,5 m)
 User manual

 be qualified

 follow the instructions of this manual

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.

LED Expected Lifespan

LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.

Safety Instructions

Every person involved with the installation, operation and maintenance of this device has to:

2

Ordercode: 42773

Digital Flex Strip RGB

Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.

Please consider that damages caused by manual modifications to the device are not subject to
warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.

• Never let the power cord come into contact with other cables! Handle the power cord and all

connections with the mains with particular caution!

• Never remove warning or informative labels from the unit.

• Never use anything to cover the ground contact.

• Never place any material over the LEDs.

• Never look directly into the light source.

• Never leave any cables lying around.

• Never use the Digital Flex Strip in sealed or hot places.

• Do not connect this device to a dimmerpack.

• Do not switch the device on and off in short intervals, as this will reduce the device’s life.

• Do not shake the device. Avoid brute force when installing or operating the device.

• Only use the device indoors, avoid contact with water or other liquids.

• Only operate the device after having familiarized with its functions.

• Avoid flames and do not put close to flammable liquids or gases.

• Always disconnect power from the mains, when device is not used or before cleaning! Only handle

the power cord holding it by the plug. Never pull out the plug by tugging the power cord.

• Always mount the Digital Flex Strip on aluminum or metal surface, for best heat dissipation.

• Make sure that the device is not exposed to extreme heat, moisture or dust.

• Make sure that the available voltage is not higher than stated on the rear panel.

• Make sure that the power cord is never crimped or damaged. Check the device and the power

cord from time to time.

• If the LEDs are obviously damaged, they need to be replaced.

• If device was dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

• If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.

• If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

• The user is responsible for correct positioning and operating of the Digital Flex Strip. The manufacturer

will not accept liability for damages caused by the misuse or incorrect installation of this device.

• This device falls under protection class I. Therefore it is essential to connect the yellow/green

conductor to earth.

• Repairs, servicing and electric connection must be carried out by a qualified technician.

• WARRANTY: Till one year after date of purchase.

3

Ordercode: 42773

Digital Flex Strip RGB

International

EU Cable

UK Cable

US Cable

Pin

L

BROWN

RED

YELLOW/COPPER

PHASE

N

BLUE

BLACK

SILVER

NEUTRAL

YELLOW/GREEN

GREEN

GREEN

PROTECTIVE GROUND

Operating Determinations

• This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

• The minimum distance between light output and the illuminated surface must be bigger than 1

meter.

• The maximum ambient temperature t

• The relative humidity must not exceed 50 % with an ambient temperature of 40° C.

• If this device is operated in any other way than the one described in this manual, the product may

suffer damages and the warranty becomes void.

• Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.

= 40°C must never be exceeded.

a

You endanger your own safety and the safety of others!

Connection with the mains

Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.

Make sure that the device is always properly connected to the earth!

Improper installation can cause serious injuries and/or damage of property!

4
